REPLACEMENT PARTS LIST
PRODUCT SAFETY NOTE : Components marked with a
have special characteristics important to safety. Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety
of the receiver through improper servicing.
ABBREVIATIONS |
Capacitors............... |
CD:Ceramic disk, PF:Polyester film, EL:Electrolytic, |
|
|
||||
|
|
|
|
PP:Polypropylene, PR:Paper, TA:Tantalum, TM:Trimmer, |
||||
|
|
|
|
MYL:Mylar. |
|
|
|
|
|
|
Resistors................. |
CF:Carbon film, CC:Carbon composition, |
|
|
|||
|
|
|
|
MF:Metal oxide film,VR:Variable resistor,WW:Wire wound, |
||||
|
|
|
|
FR:Fuse resistor, MG:Metal glazed |
|
|
||
|
|
Semiconductors... |
|
TR:Transistor, DI:Diode, ZD:Zener diode, VA:Varistor, |
|
|
||
|
|
|
|
TH:Thermistor, IC:IC |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
CIRCUIT BLOCK |
SECOND |
CIRCUIT BLOCK |
|
SECOND |
CIRCUIT BLOCK |
SECOND |
|
|
|
CHARACTER OF |
|
|
CHARACTER OF |
|
CHARACTER OF |
|
|
|
SYMBOL NO. |
|
|
SYMBOL NO. |
|
SYMBOL NO. |
|
|
|
|
|
|
|
|
|
|
|
System Control |
0 |
PinP |
|
G |
CPT |
8 |
|
|
Tuner |
1 |
Audio Processing |
|
A |
Horizontal Deflection |
7 |
|
|
Signal Processing |
5 |
(SRS/BBE) |
|
|
Vertical Deflection |
6 |
|
|
Audio Processing |
4 |
PinP Sub Tuner |
|
X |
Dynamic Focus |
F |
|
|
(A2/Nicam/Vol/Sw) |
|
Power Supply |
|
9 |
Convergence |
K |
|
|
Terminal |
2 |
VM |
|
E |
Sensor (Magic Focus) |
L |
|
|
(Input/Output) |
|
Control |
|
M |
Filter |
P |
|
|
|
|
|
|
|
Teletext |
T |
|
|
|
|
|
|
|
|
|
|
Note: The asterik (*) indicates difference in parts between C43-F550 and C43-F550P. The part with (*) only applies to C43-F550P and C50-F550P (PinP models).
SYMBOL |
PART NO |
DESCRIPTION |
SYMBOL |
PART NO |
DESCRIPTION |
|
NO. |
|
|
NO. |
|
|
|
|
|
DIODES |
|
|
|
|
D001 |
2331849M |
ZENER HZ12C3 (TA) SI 500MW |
D103 |
5339071 |
DIODE 1SS119-T |
|
D002 |
2331849M |
ZENER HZ12C3 (TA) SI 500MW |
D104 |
5339071 |
DIODE 1SS119-T |
|
D003 |
2331849M |
ZENER HZ12C3 (TA) SI 500MW |
D105 |
5339071 |
DIODE 1SS119-T |
|
D004 |
2331849M |
ZENER HZ12C3 (TA) SI 500MW |
D106 |
5339071 |
DIODE 1SS119-T |
|
D008 |
CC00003R |
DIODE.CHIP 1SS355 |
D201 |
5339071 |
DIODE 1SS119-T |
|
+ D010 |
CC00003R |
DIODE CHIP 1SS355 |
D203 |
2339812M |
ZENER HZS3A2 TA (SI.200MA) |
|
D017 |
CC00003R |
DIODE.CHIP 1SS355 |
D204 |
2339812M |
ZENER HZS3A2 TA (SI.200MA) |
|
D019 |
5339071 |
DIODE 1SS119-T |
D205 |
5339071 |
DIODE 1SS119-T |
|
D020 |
5339071 |
DIODE 1SS119-T |
D206 |
5339071 |
DIODE 1SS119-T |
|
D021 |
5339071 |
DIODE 1SS119-T |
D401 |
5339071 |
DIODE 1SS119-T |
|
D022 |
5339071 |
DIODE 1SS119-T |
D402 |
5339071 |
DIODE 1SS119-T |
|
D023 |
5339071 |
DIODE 1SS119-T |
D403 |
5339071 |
DIODE 1SS119-T |
|
D025 |
CC00003R |
DIODE.CHIP 1SS355 |
D404 |
5339071 |
DIODE 1SS119-T |
|
D026 |
CC00003R |
DIODE.CHIP 1SS355 |
D405 |
5339071 |
DIODE 1SS119-T |
|
D027 |
2331809M |
ZENER HZ-6 (C3) SI 500MW |
D406 |
5339071 |
DIODE 1SS119-T |
|
D028 |
2331809M |
ZENER HZ-6 (C3) SI 500MW |
D407 |
5339071 |
DIODE 1SS119-T |
|
D029 |
CC00003R |
DIODE.CHIP 1SS355 |
D408 |
5339071 |
DIODE 1SS119-T |
|
D031 |
CC00003R |
DIODE.CHIP 1SS355 |
D409 |
5339071 |
DIODE 1SS119-T |
|
D032 |
CC00003R |
DIODE.CHIP 1SS355 |
D410 |
5339071 |
DIODE 1SS119-T |
|
D033 |
CC00003R |
DIODE.CHIP 1SS355 |
D411 |
5339071 |
DIODE 1SS119-T |
|
D034 |
5339071 |
DIODE 1SS119-T |
D412 |
5339071 |
DIODE 1SS119-T |
|
D035 |
5339071 |
DIODE 1SS119-T |
D414 |
2331827M |
Z. DIO. HZ-9 |
(C1)SI 500MW 9.3V |
D036 |
5339071 |
DIODE 1SS119-T |
D415 |
2331827M |
Z. DIO. HZ-9 |
(C1)SI 500MW 9.3V |
D037 |
5339071 |
DIODE 1SS119-T |
D416 |
2331827M |
Z. DIO. HZ-9 |
(C1)SI 500MW 9.3V |
D101 |
2339971M |
ZENER HZS33-1 TA |
D417 |
2331827M |
Z. DIO. HZ-9 (C1)SI 500MW 9.3V |
|
D102 |
5339071 |
DIODE 1SS119-T |
D418 |
2331827M |
ZENER HZ-9(C1)SI 500MW 9.3V |
|
|
|
|
|
|
|
|
Note: (+) For C43-F550 only.
PRODUCT SAFETY NOTE : Components marked with a
have special characteristics important to safety. Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety
of the receiver through improper servicing.
|
SYMBOL |
PART NO |
DESCRIPTION |
|
SYMBOL |
PART NO |
DESCRIPTION |
||
|
|
NO. |
|
|
|
|
NO. |
|
|
|
|
D419 |
2331827M |
ZENER HZ-9(C1)SI 500MW 9.3V |
|
|
D730 |
5339071 |
DIODE 1SS119-T |
|
|
D420 |
2331827M |
ZENER HZ-9(C1)SI 500MW 9.3V |
|
|
D731 |
5339071 |
DIODE 1SS119-T |
|
|
D423 |
2331849M |
ZENER HZ12C3 (TA) SI 500MW |
|
|
D802 |
5339071 |
DIODE 1SS119-T |
|
|
D424 |
2331849M |
ZENER HZ12C3 (TA) SI 500MW |
|
|
D803 |
5339071 |
DIODE 1SS119-T |
|
|
D425 |
2339889M |
ZENER HZS12C3 (TA)SI 500MW |
|
|
D804 |
5339071 |
DIODE 1SS119-T |
|
|
D427 |
2339889M |
ZENER HZS12C3 (TA) SI 500MW |
|
|
D805 |
5339071 |
DIODE 1SS119-T |
|
|
D504 |
5339071 |
DIODE 1SS119-T |
|
|
D832 |
5339071 |
DIODE 1SS119-T |
|
|
D505 |
5339071 |
DIODE 1SS119-T |
|
|
D833 |
5339071 |
DIODE 1SS119-T |
|
|
D506 |
2339801M |
ZENER HZS-2 (B1)SI 400MW 2.0V |
|
|
D862 |
5339071 |
DIODE 1SS119-T |
|
|
D509 |
5339071 |
DIODE 1SS119-T |
|
|
D863 |
5339071 |
DIODE 1SS119-T |
|
|
D510 |
2339825M |
ZENER HZS-4(B2)SI 400MW 3.9V |
|
|
D901 |
2342061 |
DIODE D3SB (A) 60 |
|
|
|
|
||||||
|
|
|
|
||||||
|
|
D511 |
5339071 |
DIODE 1SS119-T |
|
|
D904 |
CH00174M |
DIODE DFM1SD6 (600V) TAPE |
|
|
D512 |
5339071 |
DIODE 1SS119-T |
|
|
D905 |
CH02011M |
DIODE 1SR153-400 |
|
|
D513 |
5339071 |
DIODE 1SS119-T |
|
|
D907 |
2339981M |
ZENER HZS36-1 TA |
|
|
D514 |
5339071 |
DIODE 1SS119-T |
|
|
D908 |
CH02011M |
DIODE 1SR153-400 |
|
|
D517 |
5339071 |
DIODE 1SS119-T |
|
|
D909 |
CH00174M |
DIODE DFM1SD6 (600V) TAPE |
|
|
D518 |
5339071 |
DIODE 1SS119-T |
|
|
D910 |
CH00174M |
DIODE DFM1SD6 (600V) TAPE |
|
|
D519 |
5339071 |
DIODE 1SS119-T |
|
|
D911 |
CH02011M |
DIODE 1SR153-400 |
|
|
D520 |
5339071 |
DIODE 1SS119-T |
|
|
D913 |
2338944 |
DIODE FML-G12S (F) (200V) |
|
|
D521 |
5339071 |
DIODE 1SS119-T |
|
|
D914 |
CH02132 |
DIODE 31DF4 |
|
|
D522 |
5339071 |
DIODE 1SS119-T |
|
|
D915 |
CH02132 |
DIODE 31DF4 |
|
|
D523 |
5339071 |
DIODE 1SS119-T |
|
|
D916 |
CH02132 |
DIODE 31DF4 |
|
|
D526 |
5339071 |
DIODE 1SS119-T |
|
|
D917 |
CH02001M |
DIODE 1SR139-400 |
|
|
D527 |
5339071 |
DIODE 1SS119-T |
|
|
D918 |
2339943M |
ZENER HZS24-3 TA |
|
|
D528 |
5339071 |
DIODE 1SS119-T |
|
|
D919 |
2338532M |
DIODE EG01A (V1) |
|
|
D605 |
5339071 |
DIODE 1SS119-T |
|
|
D921 |
5339071 |
DIODE 1SS119-T |
|
|
D606 |
5339071 |
DIODE 1SS119-T |
|
|
D923 |
CH00183R |
LED (SLZ-981C-06-T1) (T) |
|
|
D607 |
2334243M |
ZENER RD16E (B2T2/TP/TA) |
|
|
D929 |
CH02131 |
DIODE 31DF6 (600V) |
|
|
D608 |
2339847M |
ZENER HZS6C1 TA |
|
|
D931 |
2339961M |
ZENER HZS30-1 TA |
|
|
D611 |
CH02001M |
DIODE 1SR139-400 |
|
|
D932 |
5339071 |
DIODE 1SS119-T |
|
|
D612 |
2339876M |
ZENER HZS11B3 TA |
|
|
D933 |
2339863M |
ZENER HZS9A3 TA |
|
|
D613 |
5339071 |
DIODE 1SS119-T |
|
|
D934 |
CH02001M |
DIODE 1SR139-400 |
|
|
D615 |
5339071 |
DIODE 1SS119-T |
|
|
D935 |
5339071 |
DIODE 1SS119-T |
|
|
D617 |
5339071 |
DIODE 1SS119-T |
|
|
D937 |
CH02011M |
DIODE 1SR153-400 |
|
|
D621 |
CH02001M |
DIODE 1SR139-400 |
|
|
D938 |
5339071 |
DIODE 1SS119-T |
|
|
D622 |
5339071 |
DIODE 1SS119-T |
|
|
D940 |
2339854M |
ZENER HZS7B1 TA |
|
|
D626 |
5339071 |
DIODE 1SS119-T |
|
|
D946 |
CH00182R |
LED (SLZ-381C-06-T1) (T) |
|
|
D701 |
5339071 |
DIODE 1SS119-T |
|
|
D948 |
CH00182R |
LED (SLZ-381C-06-T1) (T) |
|
|
D702 |
2348511G |
DIODE RS3FS LF-U1 (014-201) |
|
|
D949 |
5339071 |
DIODE 1SS119-T |
|
|
||||||||
|
|
||||||||
|
|
D704 |
2336612M |
DIODE RU3AM TA |
|
|
D950 |
2339943M |
ZENER HZS24-3 TA |
|
|
||||||||
|
|
||||||||
|
|
D705 |
5339071 |
DIODE 1SS119-T |
|
|
D951 |
CH00182R |
LED (SLZ-381C-06-T1) (T) |
|
|
D706 |
5339071 |
DIODE 1SS119-T |
|
|
D952 |
2339846M |
ZENER HZS6B3 TA |
|
|
D708 |
5339071 |
DIODE 1SS119-T |
|
|
D955 |
5339071 |
DIODE 1SS119-T |
|
|
D709 |
2335042M |
ZENER HZ-22 (2L TP) |
|
|
D956 |
5339071 |
DIODE 1SS119-T |
|
|
|
|
||||||
|
|
|
|
||||||
|
|
D710 |
CH02001M |
DIODE 1SR139-400 |
|
|
D960 |
5339071 |
DIODE 1SS119-T |
|
|
D711 |
CH02102M |
DIODE 10ELS4 (400V) |
|
|
D962 |
5339071 |
DIODE 1SS119-T |
|
|
D712 |
CH02011M |
DIODE 1SR153-400 |
|
|
D963 |
2339932M |
DIODE HZS22-2 TA |
|
|
||||||||
|
|
||||||||
|
|
D713 |
CH00901M |
DIODE RGP02-15E 1550V 20A |
|
|
D964 |
5339071 |
DIODE 1SS119-T |
|
|
D714 |
CH00901M |
DIODE RGP02-15E 1550V 20A |
|
|
D965 |
5339071 |
DIODE 1SS119-T |
|
|
D716 |
CH02011M |
DIODE 1SR153-400 |
|
|
D973 |
CH02132 |
DIODE 31DF4 |
|
|
D717 |
2339612M |
ZENER HZS-3 TA (BLL) |
|
|
DA33 |
2339889M |
ZENER HZS12 C3 |
|
|
D718 |
5339071 |
DIODE 1SS119-T |
|
|
DA34 |
2339889M |
ZENER HZS12 C3 |
|
|
D719 |
CH02001M |
DIODE 1SR139-400 |
|
|
DE01 |
5339071 |
DIODE 1SS119-T |
|
|
|
|
|
|
|
|
|
|
