Hitachi C43 Part list res

REPLACEMENT PARTS LIST

PRODUCT SAFETY NOTE : Components marked with a have special characteristics important to safety. Before replacing
any of these components, read carefully the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety
of the receiver through improper servicing.

ABBREVIATIONSABBREVIATIONS Capacitors............... CD:Ceramic disk, PF:Polyester film, EL:Electrolytic,

PP:Polypropylene, PR:Paper, TA:Tantalum, TM:Trimmer,
MYL:Mylar.

Resistors................. CF:Carbon film, CC:Carbon composition,

MF:Metal oxide film,VR:Variable resistor,WW:Wire wound,
FR:Fuse resistor, MG:Metal glazed

Semiconductors... TR:Transistor, DI:Diode, ZD:Zener diode, VA:Varistor,

TH:Thermistor, IC:IC

CIRCUIT BLOCK SECOND

CHARACTER OF
SYMBOL NO.

System Control
Tuner
Signal Processing
Audio Processing
(A2/Nicam/Vol/Sw)
Terminal
(Input/Output)

0
1
5
4

2

CIRCUIT BLOCK SECOND

PinP

Audio Processing

(SRS/BBE)
PinP Sub Tuner
Power Supply
VM
Control

CHARACTER OF
SYMBOL NO.

G
A

X

9
E
M

CIRCUIT BLOCK

CPT
Horizontal Deflection
Vertical Deflection
Dynamic Focus
Convergence
Sensor (Magic Focus)
Filter
Teletext

SECOND
CHARACTER OF
SYMBOL NO.

8
7
6
F
K
L
P
T

Note: The asterik (*) indicates difference in parts between C43-F550 and C43-F550P. The part with (*) only applies to C43-F550P
and C50-F550P (PinP models).

SYMBOL PART NO DESCRIPTION SYMBOL PART NO DESCRIPTION

NO. NO.

RESISTORS

R001 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R028 AQ11706R RES.CHIP RM06JT223(1608) 22K
R002 AQ11653R RES.CHIP RM06JT221(1608) 220 R029 AQ11644R RES.CHIP RM06JT101(1608) 100
R003 AQ11691R RES.CHIP RM06JT562(1608) 5.6K R030 AQ11644R RES.CHIP RM06JT101(1608) 100
R004 AQ11644R RES.CHIP RM06JT101(1608) 100 R031 AQ11644R RES.CHIP RM06JT101(1608) 100
R005 AQ11778R RES.CHIP RM06JT000(1608) R032 AQ11644R RES.CHIP RM06JT101(1608) 100
R006 AQ11691R RES.CHIP RM06JT562(1608) 5.6K R033 AQ11697R RES.CHIP RM06JT103(1608) 10K
R007 AQ11644R RES.CHIP RM06JT101(1608) 100 R034 AQ11697R RES.CHIP RM06JT103(1608) 10K
R008 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R035 AQ11697R RES.CHIP RM06JT103(1608) 10K
R009 AQ11691R RES.CHIP RM06JT562(1608) 5.6K R036 AQ11697R RES.CHIP RM06JT103(1608) 10K
R010 AQ11644R RES.CHIP RM06JT101(1608) 100 R037 AQ11697R RES.CHIP RM06JT103(1608) 10K
R011 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R041 AQ11697R RES.CHIP RM06JT103(1608) 10K
R012 AQ11691R RES.CHIP RM06JT562(1608) 5.6K R042 AQ11644R RES.CHIP RM06JT101(1608) 100
R013 AQ11644R RES.CHIP RM06JT101(1608) 100 R045 AQ11697R RES.CHIP RM06JT103(1608) 10K
R014 AQ11778R RES.CHIP RM06JT000(1608) R046 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R015 AQ11697R RES.CHIP RM06JT103(1608) 10K R054 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R016 AQ11644R RES.CHIP RM06JT101(1608) 100 R055 AQ11715R RES.CHIP RM06JT473(1608) 47K
R017 AQ11778R RES.CHIP RM06JT000(1608) R056 AQ11699R RES.CHIP RM06JT123(1608) 12K
R018 AQ11697R RES.CHIP RM06JT103(1608) 10K R057 AQ11688R RES.CHIP RM06JT472(1608) 4.7K
R019 AQ11644R RES.CHIP RM06JT101(1608) 100 R058 0114149M RES.-CAR. FILM SRD 1/4 PF 560-J
R020 AQ11778R RES.CHIP RM06JT000(1608) R059 AQ11706R RES.CHIP RM06JT223(1608) 22K
R021 AQ11644R RES.CHIP RM06JT101(1608) 100 R060 AQ11697R RES.CHIP RM06JT103(1608) 10K
R022 AQ11644R RES.CHIP RM06JT101(1608) 100 R061 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R023 AQ11644R RES.CHIP RM06JT101(1608) 100 R062 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R025 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R063 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R027 AQ11679R RES.CHIP RM06JT222(1608) 2.2K * R064 AQ11671R RES.CHIP RM06JT102(1608) 1.0K

PRODUCT SAFETY NOTE : Components marked with a have special characteristics important to safety. Before replacing
any of these components, read carefully the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety
of the receiver through improper servicing.

SYMBOL PART NO DESCRIPTION SYMBOL PART NO DESCRIPTION

NO. NO.

R028 AQ11706R RES.CHIP RM06JT223(1608) 22K R0A0 AQ11706R RES.CHIP RM06JT223(1608) 22K
R029 AQ11644R RES.CHIP RM06JT101(1608) 100 R0A1 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R030 AQ11644R RES.CHIP RM06JT101(1608) 100 R0A2 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R031 AQ11644R RES.CHIP RM06JT101(1608) 100 R0A3 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R032 AQ11644R RES.CHIP RM06JT101(1608) 100 R0A4 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R033 AQ11697R RES.CHIP RM06JT103(1608) 10K R0A5 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R034 AQ11697R RES.CHIP RM06JT103(1608) 10K R0A6 AQ11688R RES.CHIP RM06JT472(1608) 4.7K
R035 AQ11697R RES.CHIP RM06JT103(1608) 10K R0A7 AQ11697R RES.CHIP RM06JT103(1608) 10K
R036 AQ11697R RES.CHIP RM06JT103(1608) 10K R0A8 AQ11644R RES.CHIP RM06JT101(1608) 100
R037 AQ11697R RES.CHIP RM06JT103(1608) 10K R0A9 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R041 AQ11697R RES.CHIP RM06JT103(1608) 10K R0B0 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R042 AQ11644R RES.CHIP RM06JT101(1608) 100 R0B1 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R045 AQ11697R RES.CHIP RM06JT103(1608) 10K R0B2 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R046 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0B3 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R054 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0B5 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R055 AQ11715R RES.CHIP RM06JT473(1608) 47K R0B6 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R056 AQ11699R RES.CHIP RM06JT123(1608) 12K R0B7 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R057 AQ11688R RES.CHIP RM06JT472(1608) 4.7K R0B8 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R058 0114149M RES.-CAR. FILM SRD 1/4 PF 560-J R0B9 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R059 AQ11706R RES.CHIP RM06JT223(1608) 22K R0C0 AQ11706R RES.CHIP RM06JT223(1608) 22K
R060 AQ11697R RES.CHIP RM06JT103(1608) 10K R0C1 AQ11706R RES.CHIP RM06JT223(1608) 22K
R061 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0C2 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R062 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0C3 AQ11644R RES.CHIP RM06JT101(1608) 100
R063 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0C4 AQ11644R RES.CHIP RM06JT101(1608) 100

* R064 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0C5 AQ11671R RES.CHIP RM06JT102(1608) 1.0K

R065 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0C6 AQ11644R RES.CHIP RM06JT101(1608) 100
R066 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0C7 AQ11644R RES.CHIP RM06JT101(1608) 100
R067 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0C8 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R068 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0C9 AQ11706R RES.CHIP RM06JT223(1608) 22K
R069 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0D0 AQ11644R RES.CHIP RM06JT101(1608) 100
R070 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0D1 AQ11653R RES.CHIP RM06JT221(1608) 220
R071 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0D2 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R072 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0D3 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R073 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0D4 AQ11644R RES.CHIP RM06JT101(1608) 100
R076 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0D5 AQ11659R RES.CHIP RM06JT391(1608) 390
R077 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0D6 AQ11693R RES.CHIP RM06JT682(1608) 6.8K
R078 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0D7 AQ11678R RES.CHIP RM06JT202(1608) 2.0K
R079 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0D8 AQ11659R RES.CHIP RM06JT391(1608) 390
R080 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0D9 AQ11693R RES.CHIP RM06JT682(1608) 6.8K
R083 AQ11697R RES.CHIP RM06JT103(1608) 10K R0E0 AQ11678R RES.CHIP RM06JT202(1608) 2.0K
R084 AQ11644R RES.CHIP RM06JT101(1608) 100 R0E1 AQ11659R RES.CHIP RM06JT391(1608) 390
R085 AQ11644R RES.CHIP RM06JT101(1608) 100 R0E2 AQ11693R RES.CHIP RM06JT682(1608) 6.8K
R086 AQ11697R RES.CHIP RM06JT103(1608) 10K R0E3 AQ11678R RES.CHIP RM06JT202(1608) 2.0K
R089 AQ11644R RES.CHIP RM06JT101(1608) 100 R0E4 AQ11697R RES.CHIP RM06JT103(1608) 10K
R090 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0E5 AQ11644R RES.CHIP RM06JT101(1608) 100
R091 AQ11706R RES.CHIP RM06JT223(1608) 22K R0E6 AQ11644R RES.CHIP RM06JT101(1608) 100
R092 AQ11659R RES.CHIP RM06JT391(1608) 390 R0E7 AQ11644R RES.CHIP RM06JT101(1608) 100
R093 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0E8 AQ11697R RES.CHIP RM06JT103(1608) 10K
R094 AQ11697R RES.CHIP RM06JT103(1608) 10K R0E9 AQ11697R RES.CHIP RM06JT103(1608) 10K
R097 AQ11697R RES.CHIP RM06JT103(1608) 10K R0F0 AQ11702R RES.CHIP RM06JT153(1608) 15K
R098 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R0F1 AQ11704R RES.CHIP RM06JT183(1608) 18K
R099 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R0F2 AQ11697R RES.CHIP RM06JT103(1608) 10K

PRODUCT SAFETY NOTE : Components marked with a have special characteristics important to safety. Before replacing
any of these components, read carefully the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety
of the receiver through improper servicing.

SYMBOL PART NO DESCRIPTION SYMBOL PART NO DESCRIPTION

NO. NO.

R0F3 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R102 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R0F4 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R103 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R0F5 AQ11644R RES.CHIP RM06JT101(1608) 100 R104 AQ11644R RES.CHIP RM06JT101(1608) 100
R0F6 AQ11691R RES.CHIP RM06JT562(1608) 5.6K R105 AQ11644R RES.CHIP RM06JT101(1608) 100
R0F7 AQ11691R RES.CHIP RM06JT562(1608) 5.6K R106 AQ11644R RES.CHIP RM06JT101(1608) 100
R0F8 AQ11697R RES.CHIP RM06JT103(1608) 10K R107 AQ11631R RES.CHIP RM06JT330(1608) 33
R0F9 AQ11697R RES.CHIP RM06JT103(1608) 10K R108 AQ11631R RES.CHIP RM06JT330(1608) 33
R0G0 AQ11662R RES.CHIP RM06JT471(1608) 470 R109 AQ11617R RES.CHIP RM06JT100(1608) 10
R0G1 AQ11662R RES.CHIP RM06JT471(1608) 470 R110 AQ11699R RES.CHIP RM06JT123(1608) 12K
R0G2 AQ11662R RES.CHIP RM06JT471(1608) 470 R111 AQ11693R RES.CHIP RM06JT682(1608) 6.8K
R0G3 AQ11662R RES.CHIP RM06JT471(1608) 470 R112 AQ11644R RES.CHIP RM06JT101(1608) 100
R0G4 AQ11662R RES.CHIP RM06JT471(1608) 470 R113 AQ11695R RES.CHIP RM06JT822(1608) 8.2K
R0G5 AQ11662R RES.CHIP RM06JT471(1608) 470 R114 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R0G6 AQ11697R RES.CHIP RM06JT103(1608) 10K R115 AQ11679R RES.CHIP RM06JT222(1608) 2.2K
R0G7 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R116 AQ11646R RES.CHIP RM06JT121(1608) 120
R0G9 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R117 AQ11691R RES.CHIP RM06JT562(1608) 5.6K
R0H0 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R118 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R0H1 AQ11648R RES.CHIP RM06JT151(1608) 150 R119 AQ11715R RES.CHIP RM06JT473(1608) 47K
R0H2 AQ11644R RES.CHIP RM06JT101(1608) 100 R120 AQ11706R RES.CHIP RM06JT223(1608) 22K
R0H4 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R121 AQ11715R RES.CHIP RM06JT822(1608) 47K
R0H5 AQ11717R RES.CHIP RM06JT563(1608) 56K R122 AQ11684R RES.CHIP RM06JT822(1608) 3.3K
R0H6 AQ11697R RES.CHIP RM06JT103(1608) 10K R123 AQ11695R RES.CHIP RM06JT822(1608) 8.2K
R0H7 AQ11702R RES.CHIP RM06JT153(1608) 15K R124 AQ11679R RES.CHIP RM06JT222(1608) 2.2K
R0H8 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R125 AQ11653R RES.CHIP RM06JT221(1608) 220

R0J0 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R126 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R0J1 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R127 AQ11684R RES.CHIP RM06JT332(1608) 3.3K
R0J2 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R128 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R0J4 AQ11728R RES.CHIP RM06JT154(1608) 140K R129 AQ11646R RES.CHIP RM06JT121(1608) 120
R0J7 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R130 AQ11706R RES.CHIP RM06JT223(1608) 22K

R0J8 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R131 AQ11715R RES.CHIP RM06JT473(1608) 47K
R0K0 AQ11688R RES.CHIP RM06JT472(1608) 4.7K R135 AQ11682R RES.CHIP RM06JT272(1608) 2.7K
R0K1 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R136 AQ11682R RES.CHIP RM06JT272(1608) 2.7K
R0K2 AQ11697R RES.CHIP RM06JT103(1608) 10K R137 AQ11706R RES.CHIP RM06JT223(1608) 22K
R0K3 AQ11715R RES.CHIP RM06JT473(1608) 47K R138 AQ11706R RES.CHIP RM06JT223(1608) 22K
R0K4 AQ11691R RES.CHIP RM06JT562(1608) 5.6K R139 AQ11715R RES.CHIP RM06JT473(1608) 47K
R0K5 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R140 AQ11715R RES.CHIP RM06JT473(1608) 47K
R0K6 AQ11644R RES.CHIP RM06JT101(1608) 100 R141 AQ11675R RES.CHIP RM06JT152(1608) 1.5K
R0K7 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R142 AQ11715R RES.CHIP RM06JT473(1608) 47K
R0K8 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R143 AQ11706R RES.CHIP RM06JT223(1608) 22K
R0K9 AQ11644R RES.CHIP RM06JT101(1608) 100 R144 AQ11662R RES.CHIP RM06JT471(1608) 470
R0L0 AQ11644R RES.CHIP RM06JT101(1608) 100 R145 AQ11662R RES.CHIP RM06JT471(1608) 470
R0L1 AQ11644R RES.CHIP RM06JT101(1608) 100 R146 AQ11631R RES.CHIP RM06JT330(1608) 33
R0L2 AQ11644R RES.CHIP RM06JT101(1608) 100 R147 AQ11644R RES.CHIP RM06JT101(1608) 100
R0L3 AQ11697R RES.CHIP RM06JT103(1608) 10K R148 AQ11691R RES.CHIP RM06JT562(1608) 5.6K
R0L4 AQ11697R RES.CHIP RM06JT103(1608) 10K R149 AQ11691R RES.CHIP RM06JT562(1608) 5.6K
R0L5 AQ11697R RES.CHIP RM06JT103(1608) 10K R150 AQ11659R RES.CHIP RM06JT391(1608) 390
R0L6 AQ11697R RES.CHIP RM06JT103(1608) 10K R151 AQ11652R RES.CHIP RM06JT201(1608) 200
R0L7 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R152 AQ11648R RES.CHIP RM06JT151(1608) 150
R0L8 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R153 AQ11647R RES.CHIP RM06JT131(1608) 130
R0L9 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R154 AQ11644R RES.CHIP RM06JT101(1608) 100

R0M0 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R155 AQ11659R RES.CHIP RM06JT391(1608) 390

R101 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R157 AQ11662R RES.CHIP RM06JT471(1608) 470

R158 AQ11694R RES.CHIP RM06JT752(1608) 7.5K

PRODUCT SAFETY NOTE : Components marked with a have special characteristics important to safety. Before replacing
any of these components, read carefully the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety
of the receiver through improper servicing.

SYMBOL PART NO DESCRIPTION SYMBOL PART NO DESCRIPTION

NO. NO.

R159 AQ11644R RES.CHIP RM06JT101(1608) 100 R1E4 AQ11713R RES.CHIP RM06JT363(1608) 36K
R161 AQ11644R RES.CHIP RM06JT101(1608) 100 R1E5 AQ11697R RES.CHIP RM06JT103(1608) 10K
R162 AQ11644R RES.CHIP RM06JT101(1608) 100 R1E6 AQ11668R RES.CHIP RM06JT821(1608) 820
R163 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R1E8 AQ11662R RES.CHIP RM06JT471(1608) 470
R164 AQ11644R RES.CHIP RM06JT101(1608) 100 R1E9 AQ11664R RES.CHIP RM06JT561(1608) 560
R165 AQ11644R RES.CHIP RM06JT101(1608) 100 R1F0 AQ11644R RES.CHIP RM06JT101(1608) 100
R166 AQ11644R RES.CHIP RM06JT101(1608) 100 * R1F6 AQ11778R RES.CHIP RM06JT000(1608)JUMP.
R167 AQ11644R RES.CHIP RM06JT101(1608) 100 R1G2 AQ11722R RES.CHIP RM06JT823(1608) 82K
R168 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R1G3 AQ11715R RES.CHIP RM06JT473(1608) 47K
R169 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R1G4 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R170 AQ11686R RES.CHIP RM06JT392(1608) 3.9K R1G5 AQ11644R RES.CHIP RM06JT101(1608) 100
R176 AQ11644R RES.CHIP RM06JT101(1608) 100 R1G6 AQ11678R RES.CHIP RM06JT202(1608) 2.0K
R177 AQ11644R RES.CHIP RM06JT101(1608) 100 R1G7 AQ11662R RES.CHIP RM06JT471(1608) 470
R178 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R1G8 AQ11644R RES.CHIP RM06JT101(1608) 100
R179 AQ11644R RES.CHIP RM06JT101(1608) 100 R1G9 AQ11722R RES.CHIP RM06JT823(1608) 82K
R180 AQ11644R RES.CHIP RM06JT101(1608) 100 R1H0 AQ11715R RES.CHIP RM06JT473(1608) 47K
R181 AQ11644R RES.CHIP RM06JT101(1608) 100 R1H1 AQ11666R RES.CHIP RM06JT681(1608) 680
R182 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R1H2 AQ11644R RES.CHIP RM06JT101(1608) 100
R183 AQ11644R RES.CHIP RM06JT101(1608) 100 R1H3 AQ11677R RES.CHIP RM06JT182(1608) 1.8K
R184 AQ11644R RES.CHIP RM06JT101(1608) 100 R1H4 AQ11662R RES.CHIP RM06JT471(1608) 470
R185 AQ11702R RES.CHIP RM06JT153(1608) 15K R1H5 AQ11644R RES.CHIP RM06JT101(1608) 100
R186 AQ11724R RES.CHIP RM06JT104(1608) 100K R1H8 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R187 AQ11644R RES.CHIP RM06JT101(1608) 100 R1J0 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R188 AQ11653R RES.CHIP RM06JT221(1608) 220 R1J2 AQ11778R RES.CHIP RM06JT000(1608) JUMP
R190 AQ11679R RES.CHIP RM06JT222(1608) 2.2K R1J3 AQ11644R RES.CHIP RM06JT101(1608) 100
R191 AQ11659R RES.CHIP RM06JT391(1608) 390 R1J4 AQ11644R RES.CHIP RM06JT101(1608) 100
R192 AQ11628R RES.CHIP RM06JT270(1608) 27 R1J5 AQ11686R RES.CHIP RM06JT392(1608) 3.9K
R194 AQ11659R RES.CHIP RM06JT391(1608) 390 R1J6 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R195 AQ11644R RES.CHIP RM06JT101(1608) 100 R1J7 AQ11717R RES.CHIP RM06JT563(1608) 56K
R196 AQ11644R RES.CHIP RM06JT101(1608) 100 R201 AQ11641R RES.CHIP RM06JT750(1608) 75
R197 AQ11713R RES.CHIP RM06JT363(1608) 36K R202 AQ11641R RES.CHIP RM06JT750(1608) 75
R198 AQ11708R RES.CHIP RM06JT273(1608) 27K R203 AQ11641R RES.CHIP RM06JT750(1608) 75
R199 AQ11644R RES.CHIP RM06JT101(1608) 100 R204 AQ11641R RES.CHIP RM06JT750(1608) 75

R1A1 AQ11662R RES.CHIP RM06JT471(1608) 470 R205 AQ11644R RES.CHIP RM06JT101(1608) 100
R1A2 AQ11659R RES.CHIP RM06JT391(1608) 390 R206 AQ11644R RES.CHIP RM06JT101(1608) 100
R1A3 AQ11659R RES.CHIP RM06JT391(1608) 390 R207 AQ11657R RES.CHIP RM06JT331(1608) 330
R1A4 AQ11697R RES.CHIP RM06JT103(1608) 10K R209 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R1A5 AQ11644R RES.CHIP RM06JT101(1608) 100 R210 AQ11644R RES.CHIP RM06JT101(1608) 100
R1A6 AQ11668R RES.CHIP RM06JT821(1608) 820 R211 AQ11644R RES.CHIP RM06JT101(1608) 100
R1A7 AQ11662R RES.CHIP RM06JT471(1608) 470 R212 AQ11657R RES.CHIP RM06JT331(1608) 330
R1A8 AQ11662R RES.CHIP RM06JT471(1608) 470 R213 0114147M RES.-CARBON FLM 1/4W 470-JB
R1A9 AQ11644R RES.CHIP RM06JT101(1608) 100 R214 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R1B0 AQ11668R RES.CHIP RM06JT821(1608) 820 * R215 AQ11644R RES.CHIP RM06JT101(1608) 100
R1B2 AQ11644R RES.CHIP RM06JT101(1608) 100 * R216 AQ11644R RES.CHIP RM06JT101(1608) 100
R1B3 AQ11662R RES.CHIP RM06JT471(1608) 470 * R217 AQ11657R RES.CHIP RM06JT331(1608) 330
R1B5 AQ11668R RES.CHIP RM06JT821(1608) 820 * R218 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R1B6 AQ11662R RES.CHIP RM06JT471(1608) 470 * R219 AQ11644R RES.CHIP RM06JT101(1608) 100
R1C6 AQ11644R RES.CHIP RM06JT101(1608) 100 * R220 AQ11644R RES.CHIP RM06JT101(1608) 100
R1C7 AQ11671R RES.CHIP RM06JT102(1608) 1.0K * R221 AQ11657R RES.CHIP RM06JT331(1608) 330
R1C8 AQ11671R RES.CHIP RM06JT102(1608) 1.0K * R222 0114147M RES.-CARBON FLM 1/4W 470-JB
R1C9 AQ11644R RES.CHIP RM06JT101(1608) 100 R223 AQ11641R RES.CHIP RM06JT750(1608) 75

R1E0 AQ11778R RES.CHIP RM06JT000(1608) JUM. R224 AQ11641R RES.CHIP RM06JT750(1608) 75
R1E4 AQ11713R RES.CHIP RM06JT363(1608) 36K

PRODUCT SAFETY NOTE : Components marked with a have special characteristics important to safety. Before replacing
any of these components, read carefully the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety
of the receiver through improper servicing.

SYMBOL PART NO DESCRIPTION SYMBOL PART NO DESCRIPTION

NO. NO.

R1E5 AQ11697R RES.CHIP RM06JT103(1608) 10K R224 AQ11641R RES.CHIP RM06JT750(1608) 75
R1E6 AQ11668R RES.CHIP RM06JT821(1608) 820 R225 AQ11641R RES.CHIP RM06JT750(1608) 75
R1E8 AQ11662R RES.CHIP RM06JT471(1608) 470 R226 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R1E9 AQ11664R RES.CHIP RM06JT561(1608) 560 R227 AQ11644R RES.CHIP RM06JT101(1608) 100
R1F0 AQ11644R RES.CHIP RM06JT101(1608) 100 R228 AQ11679R RES.CHIP RM06JT222(1608) 2.2K
R1F5 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R229 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R1F6 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R230 AQ11715R RES.CHIP RM06JT473(1608) 47K

R1G2 AQ11722R RES.CHIP RM06JT823(1608) 82K R231 AQ11644R RES.CHIP RM06JT101(1608) 100
R1G3 AQ11715R RES.CHIP RM06JT473(1608) 47K R232 AQ11715R RES.CHIP RM06JT473(1608) 47K
R1G4 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R233 AQ11666R RES.CHIP RM06JT681(1608) 680
R1G5 AQ11644R RES.CHIP RM06JT101(1608) 100 R234 AQ11715R RES.CHIP RM06JT473(1608) 47K
R1G6 AQ11678R RES.CHIP RM06JT202(1608) 2.0K R235 AQ11644R RES.CHIP RM06JT101(1608) 100
R1G7 AQ11662R RES.CHIP RM06JT471(1608) 470 R236 AQ11715R RES.CHIP RM06JT473(1608) 47K
R1G8 AQ11644R RES.CHIP RM06JT101(1608) 100 R237 AQ11666R RES.CHIP RM06JT681(1608) 680
R1G9 AQ11722R RES.CHIP RM06JT823(1608) 82K R238 AQ11657R RES.CHIP RM06JT331(1608) 330
R1H0 AQ11715R RES.CHIP RM06JT473(1608) 47K R239 0114137M RES.-CAR. FILM 1/4W 180-JB
R1H1 AQ11666R RES.CHIP RM06JT681(1608) 680 R240 0114061M RES.-CAR. FILM SRD 1/4 P 68-J
R1H2 AQ11644R RES.CHIP RM06JT101(1608) 100 R241 AQ11724R RES.CHIP RM06JT104(1608) 100K
R1H3 AQ11677R RES.CHIP RM06JT182(1608) 1.8K R242 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R1H4 AQ11662R RES.CHIP RM06JT471(1608) 470 R243 AQ11724R RES.CHIP RM06JT104(1608) 100K
R1H5 AQ11644R RES.CHIP RM06JT101(1608) 100 R244 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R1H8 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R245 AQ11724R RES.CHIP RM06JT104(1608) 100K

R1J0 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R246 AQ11697R RES.CHIP RM06JT103(1608) 10K

R1J2 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R247 AQ11697R RES.CHIP RM06JT103(1608) 10K

R1J3 AQ11644R RES.CHIP RM06JT101(1608) 100 R248 AQ11697R RES.CHIP RM06JT103(1608) 10K

R1J4 AQ11644R RES.CHIP RM06JT101(1608) 100 R249 AQ11697R RES.CHIP RM06JT103(1608) 10K

R1J5 AQ11686R RES.CHIP RM06JT392(1608) 3.9K R250 AQ11778R RES.CHIP RM06JT000(1608) JB

R1J6 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R251 AQ11778R RES.CHIP RM06JT000(1608) JB

R1J7 AQ11717R RES.CHIP RM06JT563(1608) 56K R252 AQ11778R RES.CHIP RM06JT000(1608) JB
R201 AQ11641R RES.CHIP RM06JT750(1608) 75 * R253 AQ11778R RES.CHIP RM06JT000(1608) JB
R202 AQ11641R RES.CHIP RM06JT750(1608) 75 * R254 AQ11778R RES.CHIP RM06JT000(1608) JB
R203 AQ11641R RES.CHIP RM06JT750(1608) 75 R255 AQ11778R RES.CHIP RM06JT000(1608) JB
R204 AQ11641R RES.CHIP RM06JT750(1608) 75 R256 AQ11778R RES.CHIP RM06JT000(1608) JB
R205 AQ11644R RES.CHIP RM06JT101(1608) 100 R257 AQ11724R RES.CHIP RM06JT104(1608) 100K
R206 AQ11644R RES.CHIP RM06JT101(1608) 100 R258 AQ11666R RES.CHIP RM06JT681(1608) 680
R207 AQ11657R RES.CHIP RM06JT331(1608) 330 R259 AQ11724R RES.CHIP RM06JT104(1608) 100K
R209 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R261 AQ11778R RES.CHIP RM06JT000(1608) JB
R210 AQ11644R RES.CHIP RM06JT101(1608) 100 R262 AQ11778R RES.CHIP RM06JT000(1608) JB
R211 AQ11644R RES.CHIP RM06JT101(1608) 100 R264 AQ11778R RES.CHIP RM06JT000(1608) JB
R212 AQ11657R RES.CHIP RM06JT331(1608) 330 R265 AQ11778R RES.CHIP RM06JT000(1608) JB
R213 0114147M RES.-CARBON FLM 1/4W 470-JB R266 AQ11724R RES.CHIP RM06JT104(1608) 100K
R214 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R267 AQ11724R RES.CHIP RM06JT104(1608) 100K
R215 AQ11644R RES.CHIP RM06JT101(1608) 100 R269 AQ11688R RES.CHIP RM06JT472(1608) 4.7K
R216 AQ11644R RES.CHIP RM06JT101(1608) 100 R270 AQ11688R RES.CHIP RM06JT472(1608) 4.7K
R217 AQ11657R RES.CHIP RM06JT331(1608) 330 R271 AQ11666R RES.CHIP RM06JT681(1608) 680
R218 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R272 AQ11653R RES.CHIP RM06JT221(1608) 220
R219 AQ11644R RES.CHIP RM06JT101(1608) 100 R273 AQ11653R RES.CHIP RM06JT221(1608) 220
R220 AQ11644R RES.CHIP RM06JT101(1608) 100 R274 AQ11724R RES.CHIP RM06JT104(1608) 100K
R221 AQ11657R RES.CHIP RM06JT331(1608) 330 R275 AQ11724R RES.CHIP RM06JT104(1608) 100K
R222 0114147M RES.-CARBON FLM 1/4W 470-JB R276 AQ11778R RES.CHIP RM06JT000(1608) JB
R223 AQ11641R RES.CHIP RM06JT750(1608) 75 R277 AQ11778R RES.CHIP RM06JT000(1608) JB

PRODUCT SAFETY NOTE : Components marked with a have special characteristics important to safety. Before replacing
any of these components, read carefully the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety
of the receiver through improper servicing.

SYMBOL PART NO DESCRIPTION SYMBOL PART NO DESCRIPTION

NO. NO.

R278 AQ11778R RES.CHIP RM06JT000(1608) JB R459 AQ11724R RES.CHIP RM06JT104(1608) 100K
R279 AQ11724R RES.CHIP RM06JT104(1608) 100K R460 AT10673M CAR.- FILM RES. 1/10W 120
R280 AQ11724R RES.CHIP RM06JT104(1608) 100K R461 AT10673M CAR.- FILM RES. 1/10W 120
R287 AQ11706R RES.CHIP RM06JT223(1608) 22K R462 AQ11724R RES.CHIP RM06JT104(1608) 100K
R288 AQ11704R RES.CHIP RM06JT183(1608) 18K R463 AQ11631R RES.CHIP RM06JT330(1608) 33
R289 AQ11679R RES.CHIP RM06JT222(1608) 2.2K R465 AQ11778R RES.CHIP RM06JT000(1608) JB
R290 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R466 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R291 AQ11657R RES.CHIP RM06JT331(1608) 330 R467 AQ11715R RES.CHIP RM06JT473(1608) 47K
R292 AQ11706R RES.CHIP RM06JT223(1608) 22K R468 AQ11715R RES.CHIP RM06JT473(1608) 47K
R293 AQ11724R RES.CHIP RM06JT104(1608) 100K R469 AQ11778R RES.CHIP RM06JT000(1608) JB
R294 AQ11722R RES.CHIP RM06JT823(1608) 82K R470 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R295 AQ11706R RES.CHIP RM06JT223(1608) 22K R471 AQ11715R RES.CHIP RM06JT473(1608) 47K
R401 AQ11715R RES.CHIP RM06JT473(1608) 47K R472 AQ11715R RES.CHIP RM06JT473(1608) 47K
R403 AQ11697R RES.CHIP RM06JT103(1608) 10K R473 AQ11778R RES.CHIP RM06JT000(1608) JB
R405 AQ11697R RES.CHIP RM06JT103(1608) 10K R474 AQ11778R RES.CHIP RM06JT000(1608) JB
R406 AQ11778R RES.CHIP RM06JT000(1608) JB R475 AQ11644R RES.CHIP RM06JT101(1608) 100
R408 AQ11644R RES.CHIP RM06JT101(1608) 100 R476 AQ11644R RES.CHIP RM06JT101(1608) 100
R409 AQ11644R RES.CHIP RM06JT101(1608) 100 R479 AQ11644R RES.CHIP RM06JT101(1608) 100
R410 AQ11644R RES.CHIP RM06JT101(1608) 100 R480 AQ11644R RES.CHIP RM06JT101(1608) 100
R411 AQ11644R RES.CHIP RM06JT101(1608) 100 R481 AQ11644R RES.CHIP RM06JT101(1608) 100
R417 AQ11715R RES.CHIP RM06JT473(1608) 47K R482 AQ11644R RES.CHIP RM06JT101(1608) 100
R420 AQ11778R RES.CHIP RM06JT000(1608) JB R483 AQ11644R RES.CHIP RM06JT101(1608) 100
R421 AQ11778R RES.CHIP RM06JT000(1608) JB R484 AQ11644R RES.CHIP RM06JT101(1608) 100
R423 AQ11679R RES.CHIP RM06JT222(1608) 2.2K R485 AQ11644R RES.CHIP RM06JT101(1608) 100
R424 AQ11679R RES.CHIP RM06JT222(1608) 2.2K R486 AQ11644R RES.CHIP RM06JT101(1608) 100
R425 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R487 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R426 AQ11697R RES.CHIP RM06JT103(1608) 10K R488 AQ11644R RES.CHIP RM06JT101(1608) 100
R427 AQ11697R RES.CHIP RM06JT103(1608) 10K R489 AQ11711R RES.CHIP RM06JT333(1608) 33K
R428 AQ11679R RES.CHIP RM06JT222(1608) 2.2K R490 AQ11699R RES.CHIP RM06JT123(1608) 12K
R429 AQ11679R RES.CHIP RM06JT222(1608) 2.2K R491 AQ11644R RES.CHIP RM06JT101(1608) 100
R436 AQ11662R RES.CHIP RM06JT471(1608) 470 R492 AQ11675R RES.CHIP RM06JT152(1608) 1.5K
R437 AQ11715R RES.CHIP RM06JT473(1608) 47K R493 AQ11644R RES.CHIP RM06JT101(1608) 100
R438 AQ11724R RES.CHIP RM06JT104(1608) 100K R494 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R439 AQ11715R RES.CHIP RM06JT473(1608) 47K R496 AQ11662R RES.CHIP RM06JT471(1608) 470
R440 AQ11706R RES.CHIP RM06JT223(1608) 22K R4A1 AQ11706R RES.CHIP RM06JT223(1608) 22K
R441 AQ11715R RES.CHIP RM06JT473(1608) 47K R4A2 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R442 AQ11715R RES.CHIP RM06JT473(1608) 47K R4A3 AQ11719R RES.CHIP RM06JT683(1608) 68K
R443 AQ11724R RES.CHIP RM06JT104(1608) 100K R4A4 AQ11719R RES.CHIP RM06JT683(1608) 68K
R444 AQ11691R RES.CHIP RM06JT562(1608) 5.6K R4A6 AT03197S METAL OX. 2.2OHM 1W
R445 AQ11691R RES.CHIP RM06JT562(1608) 5.6K R4A7 AT03197S METAL OX. 2.2OHM 1W
R446 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R4A9 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R447 AQ11697R RES.CHIP RM06JT103(1608) 10K R4F4 AQ11778R RES.CHIP RM06JT000(1608) JB
R448 AQ11697R RES.CHIP RM06JT103(1608) 10K R4F5 AQ11644R RES.CHIP RM06JT101(1608) 100
R449 0113725M RES.- CAR.FILM SRD1/2P-B 100-J R4F6 AQ11644R RES.CHIP RM06JT101(1608) 100
R450 AQ11691R RES.CHIP RM06JT562(1608) 5.6K R4F7 AQ11644R RES.CHIP RM06JT101(1608) 100
R451 AQ11691R RES.CHIP RM06JT562(1608) 5.6K R501 AQ11644R RES.CHIP RM06JT101(1608) 100
R452 AQ11706R RES.CHIP RM06JT223(1608) 22K R502 AQ11644R RES.CHIP RM06JT101(1608) 100
R455 AQ11706R RES.CHIP RM06JT223(1608) 22K R504 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R456 AQ11666R RES.CHIP RM06JT681(1608) 680 R506 AQ11695R RES.CHIP RM06JT822(1608) 8.2K
R457 AQ11666R RES.CHIP RM06JT681(1608) 680 R507 AQ11658R RES.CHIP RM06JT361(1608) 360
R458 AQ11631R RES.CHIP RM06JT330(1608) 33 R508 AQ11671R RES.CHIP RM06JT102(1608) 1.0K

PRODUCT SAFETY NOTE : Components marked with a have special characteristics important to safety. Before replacing
any of these components, read carefully the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety
of the receiver through improper servicing.

SYMBOL PART NO DESCRIPTION SYMBOL PART NO DESCRIPTION

NO. NO.

R513 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R575 AQ11677R RES.CHIP RM06JT182(1608) 1.8K
R514 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R576 AQ11778R RES.CHIP RM06JT000(1608) JUMP
R515 AQ11684R RES.CHIP RM06JT332(1608) 3.3K R577 AQ11691R RES.CHIP RM06JT562(1608) 5.6K
R516 AQ11679R RES.CHIP RM06JT222(1608) 2.2K R578 AQ11697R RES.CHIP RM06JT103(1608) 10K
R517 AQ11697R RES.CHIP RM06JT103(1608) 10K R579 AQ11693R RES.CHIP RM06JT682(1608) 6.8K
R518 AQ11697R RES.CHIP RM06JT103(1608) 10K R580 AQ11724R RES.CHIP RM06JT104(1608) 100K
R519 AQ11695R RES.CHIP RM06JT822(1608) 8.2K R581 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R520 AQ11682R RES.CHIP RM06JT272(1608) 2.7K R583 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R521 AQ11644R RES.CHIP RM06JT101(1608) 100 R584 AQ11704R RES.CHIP RM06JT183(1608) 18K
R522 AQ11671R RES.CHIP RM06JT102(1608) 1.0K + R588 AQ11778R RES.CHIP RM06JT000(1608) JUM.
R523 AQ11671R RES.CHIP RM06JT102(1608) 1.0K + R589 AQ11778R RES.CHIP RM06JT000(1608) JUM.
R524 AQ11671R RES.CHIP RM06JT102(1608) 1.0K + R590 AQ11778R RES.CHIP RM06JT000(1608) JUM.
R525 AQ11671R RES.CHIP RM06JT102(1608) 1.0K + R591 AQ11778R RES.CHIP RM06JT000(1608) JUM.
R526 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R592 AQ11644R RES.CHIP RM06JT101(1608) 100
R527 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R593 AQ11644R RES.CHIP RM06JT101(1608) 100
R528 AQ11644R RES.CHIP RM06JT101(1608) 100 * R594 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R529 AQ11644R RES.CHIP RM06JT101(1608) 100 R595 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R530 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R596 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R531 AQ11697R RES.CHIP RM06JT103(1608) 10K R597 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R532 AQ11644R RES.CHIP RM06JT101(1608) 100 R5A0 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R533 AQ11644R RES.CHIP RM06JT101(1608) 100 R5A1 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R534 AQ11644R RES.CHIP RM06JT101(1608) 100 R5A2 AQ11697R RES.CHIP RM06JT103(1608) 10K
R535 AQ11644R RES.CHIP RM06JT101(1608) 100 R5A3 AQ11679R RES.CHIP RM06JT222(1608) 2.2K
R536 AQ11697R RES.CHIP RM06JT103(1608) 10K R5A4 AQ11684R RES.CHIP RM06JT332(1608) 3.3K
R537 AQ11673R RES.CHIP RM06JT122(1608) 1.2K R5A5 AQ11697R RES.CHIP RM06JT103(1608) 10K
R538 AQ11686R RES.CHIP RM06JT392(1608) 3.9K R5A6 AQ11644R RES.CHIP RM06JT101(1608) 100
R539 AQ11778R RES.CHIP RM06JT000(1608) JUMP. R5A7 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R540 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R5A8 AQ11691R RES.CHIP RM06JT562(1608) 5.6K
R541 AQ11708R RES.CHIP RM06JT273(1608) 27K R5A9 AQ11668R RES.CHIP RM06JT821(1608) 820
R542 AQ11682R RES.CHIP RM06JT272(1608) 2.7K R5B0 AQ11653R RES.CHIP RM06JT221(1608) 220
R547 AQ11644R RES.CHIP RM06JT101(1608) 100 R5B1 AQ11655R RES.CHIP RM06JT271(1608) 270
R550 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R5B2 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R551 AQ11631R RES.CHIP RM06JT330(1608) 33 R5B3 AQ11644R RES.CHIP RM06JT101(1608) 100
R552 AQ11653R RES.CHIP RM06JT221(1608) 220 R5B4 AQ11697R RES.CHIP RM06JT103(1608) 10K
R553 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R5B5 AQ11675R RES.CHIP RM06JT152(1608) 1.5K
R554 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R5B6 AQ11697R RES.CHIP RM06JT103(1608) 10K
R555 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R5B7 AQ11697R RES.CHIP RM06JT103(1608) 10K
R556 AQ11653R RES.CHIP RM06JT221(1608) 220 R5B8 AQ11687R RES.CHIP RM06JT432(1608) 4.3K
R558 AQ11653R RES.CHIP RM06JT221(1608) 220 R5B9 AQ11693R RES.CHIP RM06JT682(1608) 6.8K
R559 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R5C0 AQ11684R RES.CHIP RM06JT332(1608) 3.3K
R560 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R5C1 AQ11644R RES.CHIP RM06JT101(1608) 100
R561 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R5C7 AQ11644R RES.CHIP RM06JT101(1608) 100
R562 AQ11653R RES.CHIP RM06JT221(1608) 220 R5C9 AQ11644R RES.CHIP RM06JT101(1608) 100
R564 AQ11653R RES.CHIP RM06JT221(1608) 220 R5D1 AQ11644R RES.CHIP RM06JT101(1608) 100
R565 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R5D2 AQ11644R RES.CHIP RM06JT101(1608) 100
R566 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R5D3 AQ11644R RES.CHIP RM06JT101(1608) 100
R567 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R5D4 AQ11644R RES.CHIP RM06JT101(1608) 100
R568 AQ11653R RES.CHIP RM06JT221(1608) 220 R5D6 AQ11644R RES.CHIP RM06JT101(1608) 100
R570 AQ11706R RES.CHIP RM06JT223(1608) 22K * R5D7 AQ11644R RES.CHIP RM06JT101(1608) 100
R571 AQ11691R RES.CHIP RM06JT562(1608)5.6K * R5D8 AQ11644R RES.CHIP RM06JT101(1608) 100
R572 AQ11711R RES.CHIP RM06JT333(1608)33K * R5D9 AQ11644R RES.CHIP RM06JT101(1608) 100
R573 AQ11704R RES.CHIP RM06JT183(1608)18K * R5E0 AQ11644R RES.CHIP RM06JT101(1608) 100
R574 AQ11697R RES.CHIP RM06JT103(1608)10K * R5E1 AQ11644R RES.CHIP RM06JT101(1608) 100

Note: (+) For C43-F550 only.

PRODUCT SAFETY NOTE : Components marked with a have special characteristics important to safety. Before replacing
any of these components, read carefully the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety
of the receiver through improper servicing.

SYMBOL PART NO DESCRIPTION SYMBOL PART NO DESCRIPTION

NO. NO.

R5E2 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R647 AT10704M CAR. FILM RES. 1/10W 27K
R5E3 AQ11677R RES.CHIP RM06JT182(1608) 1.8K R648 AT10685M CAR. FILM RES. 1/10W 1.0K
R5E4 AQ11677R RES.CHIP RM06JT182(1608) 1.8K R649 0100053M RES.-CAR FLM 1/8W 330-JB
R5E5 AQ11677R RES.CHIP RM06JT182(1608) 1.8K R651 AT03859M RES.-CAR FLM RDS50 150OHM 1/2W
R5E6 AQ11666R RES.CHIP RM06JT681(1608) 680 R660 AT03857M RES.-CAR FLM RDS50 100OHM 1/2W
R5E7 AQ11666R RES.CHIP RM06JT681(1608) 680 R661 AT03857M RES.-CAR FLM RDS50 100OHM 1/2W
R5E8 AQ11666R RES.CHIP RM06JT681(1608) 680 R671 AT03857M RES.-CAR FLM RDS50 100OHM 1/2W
R5E9 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R672 AT03879M RES.-CAR FLM RDS50 4.7KOHM 1/2W
R5F0 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R673 AT03242S MET. OX. 100OHM 1W
R5F1 AQ11671R RES.CHIP RM06JT102(1608) 1.0K R674 AT10684M CAR. FILM RES. 1/10W 820
R5F6 AQ11644R RES.CHIP RM06JT101(1608) 100 R675 AT10705M CAR. FILM RES. 1/10W 33K
R5F7 AQ11644R RES.CHIP RM06JT101(1608) 100 R676 AT10697M CAR. FILM RES. 1/10W 8.2K
R5F8 AQ11644R RES.CHIP RM06JT101(1608) 100 R690 AT10707M CAR. FILM RES. 1/10W 47K

R5G2 AQ11744R RES.CHIP RM06JT564(1608) 560K R691 AT10707M CAR. FILM RES. 1/10W 47K

R601 AT10703M CAR. FILM RES. 1/10W 22K R692 AT03669M RES. -MET. GRAZD FILM 1/2W 2.2M
R602 AT10689M CAR. FILM RES. 1/10W 2.2K R693 AT03665M RES. -MET. GRAZD FILM 1/2W 1M
R603 AW00126 TRIMMER RES. (RT-06R103K1-10) R701 0145051S RES. -WIRE WOUND 7W 2.7K
R604 AT10692M CAR. FILM RES. 1/10W 3.3K R704 0100031M RES.-CAR FLM 1/8W 39-JB
R605 AT10698M CAR. FILM RES. 1/10W 10K R705 AT10691M CAR. FILM RES. 1/10W 2.7K
R606 AT10685M CAR. FILM RES. 1/10W 1.0K R706 AT10689M CAR. FILM RES. 1/10W 2.2K
R607 AT10685M CAR. FILM RES. 1/10W 1.0K R707 0100079M RES.-CAR FLM 1/8W 3.9K-JB
R608 AT10689M CAR. FILM RES. 1/10W 2.2K R708 AT10711M CAR. FILM RES. 1/10W 82K
R609 AT10689M CAR. FILM RES. 1/10W 2.2K R709 AT10698M CAR. FILM RES. 1/10W 10K
R610 AT10699M CAR. FILM RES. 1/10W 12K R710 AT10825M RES.-CAR. FILM RD1/6JT5132
R615 AT10701M CAR. FILM RES. 1/10W 15K R711 AT10693M CAR. FILM RES. 1/10W 3.9K
R616 AT10705M CAR. FILM RES. 1/10W 33K R712 AT10697M CAR. FILM RES. 1/10W 8.2K
R617 0119732M RES.-METAL OX. FILM 1.2-JB. R713 AT03858M RES.-CAR FLM RDS50 120OHM 1/2W
R618 AT10698M CAR. FILM RES. 1/10W 10K R714 AT03219S MET. OX. 15OHM 1W
R619 AT10685M CAR. FILM RES. 1/10W 1.0K R715 AT10706M CAR. FILM RES. 1/10W 39K
R620 AT10704M CAR. FILM RES. 1/10W 27K R716 AT10695M CAR. FILM RES. 1/10W 5.6K
R625 AT10688M CAR. FILM RES. 1/10W 1.8K R717 0113719M CAR. FILM RES. SRD1/2P-B 56-J
R626 AT10703M CAR. FILM RES. 1/10W 22K R718 AT03889M RES.-CAR FLM RDS50 27KOHM 1/2W
R627 0100063M RES.-CAR FLM 1/8W 820-JB R719 AT03893M RES.-CAR FLM RDS50 47KOHM 1/2W
R628 0100065M RES.-CAR FLM 1/8W 1K-JB R720 AT03411S MET. OX. 220OHM 2W
R629 AT10847M RES.-CAR. FILM RD1/6JT5753 R727 0100089M RES.-CAR FLM 1/8W 10K-JB
R630 AW00128 TRIMMER RES. (RT-06R303K1-10) R728 0100077M RES.-CAR FLM 1/8W 3.3K-JB
R631 AT03665M RES. -MET. GRAZD FILM 1/2W 1M R729 AT03865M RES.-CAR FLM RDS50 390KOHM 1/2W
R632 AT10707M CAR. FILM RES. 1/10W 47K R730 AT10698M CAR. FILM RES. 1/10W 10K
R633 AT10695M CAR. FILM RES. 1/10W 5.6K R731 0100127M RES.-CAR FLM 1/8W 390K-JB
R634 AT10709M CAR. FILM RES. 1/10W 68K R732 AT03251S MET. OX. 220OHM 1W
R635 AT10698M CAR. FILM RES. 1/10W 10K R733 AT03251S MET. OX. 220OHM 1W
R636 AT10705M CAR. FILM RES. 1/10W 33K R734 0100127M RES.-CAR FLM 1/8W 390K-JB
R637 AT10709M CAR. FILM RES. 1/10W 68K R740 AT10709M CAR. FILM RES. 1/10W 68K
R638 AT10686M CAR. FILM RES. 1/10W 1.2K R750 0113733M RES.-CAR. FILM SRD1/2P-B 220-J
R639 AT10708M CAR. FILM RES. 1/10W 56K R751 0100093M RES.-CAR FLM 1/8W 15K-JB
R640 0100047M RES.-CAR. FLM 1/8W 180-JB R752 AT10681M CAR. FILM RES. 1/10W 470OHM
R641 0119722M RES.-METAL OX. FILM 1.0-JB/W R753 AT03448S MET. OX. 5.6KOHM 2W
R642 0119722M RES.-METAL OX. FILM 1.0-JB/W R760 AT03559S MET. OX. 82OHM 3W
R644 AT10701M CAR. FILM RES. 1/10W 15K R761 AT03881M RES.-CAR FLM RDS50 5.6KOHM 1/2W
R645 0119731M RES.-METAL OX. 1W R68-K TAPE R762 AT03562S MET. OX. 100OHM 3W
R646 AT10698M CAR. FILM RES. 1/10W 10K R771 AT01531S MET. FILM RES. 1/2W 0.1OHM

PRODUCT SAFETY NOTE : Components marked with a have special characteristics important to safety. Before replacing
any of these components, read carefully the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety
of the receiver through improper servicing.

SYMBOL PART NO DESCRIPTION SYMBOL PART NO DESCRIPTION

NO. NO.

R801 0140326S RES. WIRE WOUND 5.6K-J 5W R933 AT10685M CAR. FILM RES. 1/10W 1K
R803 0113744M RES.- CAR. FLM SRD1/2P-B 560-J R934 0113797M RES.-CAR. FLM 1/2W 82K-JB
R806 0113815M RES.- CAR. FLM SRD1/2P-B 470K-J R935 AT10694M CAR. FILM RES. 1/10W 4.7K
R810 0100051M RES.-CAR. FLM 1/8W 270-JB R938 AT10685M CAR. FILM RES. 1/10W 1K
R811 0100057M RES.-CAR. FLM 1/8W 470-JB R939 AT10703M CAR. FILM RES. 1/10W 22K
R812 0100045M RES.-CAR. FLM 1/8W 150-JB R940 AT10692M CAR. FILM RES. 1/10W 3.3K
R815 0100063M RES.-CAR. FLM 1/8W 820-JB R941 AT10698M CAR. FILM RES. 1/10W 10K
R817 0100041M RES.-CAR. FLM 1/8W 100-JB R942 AT10687M CAR. FILM RES. 1/10W 1.5K
R818 0100039M RES.-CAR. FLM 1/8W 82-JB R943 AT10684M CAR. FILM RES. 1/10W 820
R821 0100063M RES.-CAR. FLM 1/8W 820-JB R944 AT10689M CAR. FILM RES. 1/10W 2.2K
R822 0100047M RES.-CAR. FLM 1/8W 180-JB R946 AT10666M CAR. FILM RES. 1/10W 39
R823 0100065M RES.-CAR. FLM 1/8W 1K-JB R947 AT10674M CAR. FILM RES. 1/10W 150
R825 0100021M RES.-CAR. FLM 1/8W 15-JB R948 AT10687M CAR. FILM RES. 1/10W 1.5K
R827 0100065M RES.-CAR. FLM 1/8W 1K-JB R952 AT10685M CAR. FILM RES. 1/10W 1.0K
R831 0140326S RES. WIRE WOUND 5.6K-J 5W R961 AT03661M RES. -MET. GRAZD FILM 1/2W 470K
R833 0113744M RES. CAR. FLM SRD1/2P-B 560-J R964 AT10692M CAR. FILM RES. 1/10W 3.3K
R836 0113815M RES. CAR. FLM SRD1/2P-B 470K-J R965 AT10696M CAR. FILM RES. 1/10W 6.8K
R840 0100051M RES.-CAR. FLM 1/8W 270-JB R966 AT10697M CAR. FILM RES. 1/10W 8.2K
R841 0100057M RES.-CAR. FLM 1/8W 470-JB R967 AT10691M CAR. FILM RES. 1/10W 2.7K
R842 0100041M RES.-CAR. FLM 1/8W 100-JB R975 AT03419S MET. OX. 2W 470OHM
R855 0100021M RES.-CAR. FLM 1/8W 15-JB R977 AT10707M CAR. FILM RES. 1/10W 47K
R861 0140326S RES. WIRE WOUND 5.6K-J 5W R978 AT10703M CAR. FILM RES. 1/10W 22K
R863 0113744M RES. CAR. FLM SRD1/2P-B 560-J R979 AT03608S MET. OX. 3W 5.6KOHM
R866 0113815M RES. CAR. FLM SRD1/2P-B 470K-J R980 AT10682M CAR. FILM RES. 1/10W 560
R870 0100051M RES.-CARBON FLM 1/8W 270-JB R982 AT10703M CAR. FILM RES. 1/10W 22K
R871 0100057M RES.-CARBON FLM 1/8W 470-JB R983 AT10689M CAR. FILM RES. 1/10W 2.2K
R872 0100043M RES.-CARBON FLM 1/8W 120-JB R984 AT10701M CAR. FILM RES. 1/10W 15K
R885 0100021M RES.-CARBON FLM 1/8W 15-JB R985 AT10689M CAR. FILM RES. 1/10W 2.2K

R9A1 AT03659M RES. -MET. GRAZD FILM 1/2W 390K R986 0140964M RES.-MET FILM 1/2W 1.0M-J
R9A2 AT10699M CAR. FILM RES. 1/10W 12K R988 AT10692M CAR. FILM RES. 1/10W 3.3K
R9A3 AT10695M CAR. FILM RES. 1/10W 5.6K RA02 AQ11671R RES.CHIP RM06JT102(1608) 1.0K

R902 AT10699M CAR. FILM RES. 1/10W 12K RA03 AQ11644R RES.CHIP RM06JT101(1608) 100
R903 AT03655M RES. -MET. GRAZD FILM 1/2W 220K RA04 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
R905 0110175M RES.-METAL OX. 18K-J TAPE RA05 AQ11679R RES.CHIP RM06JT222(1608) 2.2K
R906 0110175M RES.-METAL OX. 18K-J TAPE RA06 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R907 0100035M RES.-CARBON FLM 1/8W 56-JB RA07 AQ11644R RES.CHIP RM06JT101(1608) 100
R909 AT10683M CAR. FILM RES. 1/10W 680 RA08 AQ11644R RES.CHIP RM06JT101(1608) 100
R911 AT10689M CAR. FILM RES. 1/10W 2.2K RA10 AQ11679R RES.CHIP RM06JT222(1608) 2.2K
R912 0140955M RES.-MET. FILM 1/2W 220K-JB RA11 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R914 AT10672M CAR. FILM RES. 1/10W 100 RA19 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R915 AT10698M CAR. FILM RES. 1/10W 10K RA21 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R917 AT01534S MET. FILM 1/2W 0.22OHM RA22 AQ11715R RES.CHIP RM06JT473(1608) 47K
R918 AT01534S MET. FILM 1/2W 0.22OHM RA23 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R919 AT01534S MET. FILM 1/2W 0.22OHM RA24 AQ11715R RES.CHIP RM06JT473(1608) 47K
R925 AT10689M CAR. FILM RES. 1/10W 2.2K RA25 AQ11688R RES.CHIP RM06JT472(1608) 4.7K
R926 AT10704M CAR. FILM RES. 1/10W 27K RA26 AQ11697R RES.CHIP RM06JT103(1608) 10K
R927 AT10704M CAR. FILM RES. 1/10W 27K RA28 AQ11697R RES.CHIP RM06JT103(1608) 10K
R928 AT10695M CAR. FILM RES. 1/10W 5.6K RA54 AQ11724R RES.CHIP RM06JT104(1608) 100K
R929 AT10692M CAR. FILM RES. 1/10W 3.3K RA60 AQ11724R RES.CHIP RM06JT104(1608) 100K
R930 AT10701M CAR. FILM RES. 1/10W 15K RA77 AQ11716R RES.CHIP RM06JT513(1608) 51K
R931 0119695M RES.-METAL OX. FILM 1W 0.47-F RAG3 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
R932 AT10698M CAR. FILM RES. 1/10W 10K RAG6 AQ11778R RES.CHIP RM06JT000(1608) JUMP.

PRODUCT SAFETY NOTE : Components marked with a have special characteristics important to safety. Before replacing
any of these components, read carefully the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety
of the receiver through improper servicing.

SYMBOL PART NO DESCRIPTION SYMBOL PART NO DESCRIPTION

NO. NO.

RAI2 AQ11644R RES.CHIP RM06JT101(1608) 100 RF13 AT10701M CAR. FILM RES. 1/10W 15K

RAI4 AQ11644R RES.CHIP RM06JT101(1608) 100 RF14 AT10669M CAR. FILM RES. 1/10W 68

RAI5 AQ11644R RES.CHIP RM06JT101(1608) 100 RF15 AT03659M RES.MTL GRAZD FLM 1/2W 390K
RE01 AT03584S METAL OX. 680OHM 3W RF16 AT03659M RES.MTL GRAZD FLM 1/2W 390K
RE02 AT10711M CAR. FILM RES. 1/10W 82K RF17 AT03659M RES.MTL GRAZD FLM 1/2W 390K
RE03 AT10702M CAR. FILM RES. 1/10W 18K RF18 AT03662M RES.MTL GRAZD FLM 1/2W 560K
RE13 AT10703M CAR. FILM RES. 1/10W 22K RF19 AT03662M RES.MTL GRAZD FLM 1/2W 560K
RE14 AT10712M CAR. FILM RES. 1/10W 100K RF20 AT10672M CAR. FILM RES. 1/10W 100
RE15 AT10691M CAR. FILM RES. 1/10W 2.7K RF21 AT10694M CAR. FILM RES. 1/10W 4.7K
RE16 0113742M RES.-CAR. FLM 1/2W 470-JB RF22 AT10702M CAR. FILM RES 1/10W 18K
RE17 AT10706M CAR. FILM RES. 1/10W 39K RF23 AT10707M CAR. FILM RES. 1/10W 47K
RE18 AT10681M CAR. FILM RES. 1/10W 470 RF25 AT03662M RES.MTL GRAZD FLM 1/2W 560K
RE19 AT10712M CAR. FILM RES. 1/10W 100K RF26 AT03662M RES.MTL GRAZD FLM 1/2W 560K
RE20 AT10698M CAR. FILM RES. 1/10W 10K RF27 AT03661M RES.MTL GRAZD FLM 1/2W 470K
RE21 0100067M RES.-CAR FLM 1/8W 1.2K-JB RF28 AT10705M CAR. FILM RES. 1/10W 33K
RE22 AT10672M CAR.- FILM RES.1/10W 100 RF29 AT10687M CAR. FILM RES. 1/10W 1.5K
RE23 0113701M RES. CAR. FILM SRD1/2P-B 10-J RF30 AT03892M 39K 1/2W RDS50 CAR. FILM RES.
RE24 0100039M RES.-CAR FLM 1/8W 82-JB RF31 AT10697M CAR. FILM RES. 1/10W 8.2K
RE25 AT03873M 1.5K 1/2W RDS50 CAR. FILM RES. RF32 AT10685M CAR. FILM RES. 1/10W 1.0K
RE26 AT03872M 1.2K 1/2W RDS50 CAR. FILM RES. RF34 AT10689M CAR. FILM RES. 1/10W 2.2K
RE27 AT03895M 68K 1/2W RDS50 CAR. FILM RES. RF36 AT03857M 100 1/2W RDS50 CAR. FILM RES.
RE28 AT03895M 68K 1/2W RDS50 CAR. FILM RES. RF41 AT10692M CAR. FILM RES. 1/10W 3.3K
RE29 0113776M RES. CAR FILM SRD1/2P-B 12K-J RF42 AT10697M CAR. FILM RES. 1/10W 8.2K
RE30 0100039M RES.-CAR. FLM 1/8W 82-JB RF43 AT10685M CAR. FILM RES. 1/10W 1.0K
RE31 0100069M RES.-CAR FLM 1/8W 1.5K-JB RF44 AT10705M CAR. FILM RES. 1/10W 33K
RE32 0100067M RES.-CAR. FLM 1/8W 1.2K-JB RF45 AT10694M CAR. FILM RES. 1/10W 4.7K
RE33 0113704M RES. CAR. FILM SRD1/2P-B 13-J RF46 AT10698M CAR. FILM RES. 1/10W 10K
RE34 AT03579S METAL OX. 470OHM 3W RF47 AT10698M CAR. FILM RES. 1/10W 10K
RE35 0113686M RES.-CAR. FLM 1/2W 2.7-J RF49 AT03248S METAL OX. 180OHM 1W
RE36 0113686M RES.-CARBON FLM 1/2W 2.7-J * RG03 AQ11644R RES.CHIP RM06JT101(1608) 100
RE37 0113704M RES. CAR.- FILM SRD1/2P-B 13-J * RG04 AQ11644R RES.CHIP RM06JT101(1608) 100
RE38 AT03574S METAL OX. 300OHM 3W * RG05 AQ11644R RES.CHIP RM06JT101(1608) 100
RE39 AT10698M CAR.- FILM RES. 1/10W 10K * RG06 AQ11644R RES.CHIP RM06JT101(1608) 100
RE40 AT10682M CAR. FILM RES. 1/10W 560 * RG08 AQ11644R RES.CHIP RM06JT101(1608) 100
RE41 AT10679M CAR. FILM RES. 1/10W 390 * RG03 AQ11644R RES.CHIP RM06JT101(1608) 100
RE43 AT10684M CAR. FILM RES. 1/10W 820 * RG04 AQ11644R RES.CHIP RM06JT101(1608) 100
RE45 AT10672M CAR. FILM RES. 1/10W 100 * RG05 AQ11644R RES.CHIP RM06JT101(1608) 100
RE46 0113752M RES. CAR. FILM SRD1/2P-B 1.2K-J * RG06 AQ11644R RES.CHIP RM06JT101(1608) 100
RE47 AT10698M CAR. FILM RES. 1/10W 10K * RG08 AQ11644R RES.CHIP RM06JT101(1608) 100
RE48 AT03579S METAL OX. 470OHM 3W * RG09 AQ11644R RES.CHIP RM06JT101(1608) 100
RF01 AT10703M CAR. FILM RES. 1/10W 22K * RG10 AQ11644R RES.CHIP RM06JT101(1608) 100
RF02 AT10704M CAR. FILM RES. 1/10W 27K * RG11 AQ11644R RES.CHIP RM06JT101(1608) 100
RF03 AT10681M CAR. FILM RES. 1/10W 470 * RG12 AQ11655R RES.CHIP RM06JT271(1608) 270
RF04 AT10694M CAR. FILM RES. 1/10W 4.7K * RG13 AQ11778R RES.CHIP RM06JT000(1608) JUMP.
RF07 0100113M RES.-CAR. FLM 1/8W 100K-JB * RG16 AQ11644R RES.CHIP RM06JT101(1608) 100
RF08 AT10703M CAR. FILM RES. 1/10W 22K OHM * RG17 AQ11644R RES.CHIP RM06JT101(1608) 100
RF09 AT10698M CAR. FILM RES. 1/10W 10K OHM * RG18 AQ11644R RES.CHIP RM06JT101(1608) 100
RF10 AT03857M 100 1/2W RDS50 CAR. FILM RES. * RG19 AQ11657R RES.CHIP RM06JT331(1608) 330
RF11 AT10691M CAR. FILM RES. 1/10W 2.7K * RG20 AQ11778R RES.CHIP RM06JT000(1608)
RF12 0100113M RES.-CAR. FLM 1/8W 100K-JB * RG22 AQ11644R RES.CHIP RM06JT101(1608) 100

* RG23 AQ11664R RES.CHIP RM06JT561(1608) 560

PRODUCT SAFETY NOTE : Components marked with a have special characteristics important to safety. Before replacing
any of these components, read carefully the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety
of the receiver through improper servicing.

SYMBOL PART NO DESCRIPTION SYMBOL PART NO DESCRIPTION

NO. NO.

* RG24 AQ11728R RES.CHIP RM06JT154(1608) 140K RK19 0100125M RES.-CARBON FLM 1/8W 330K-JB
* RG25 AQ11662R RES.CHIP RM06JT471(1608) 470 RK22 AT10685M CAR. FILM RES. 1/10W 1.0K
* RG26 AQ11697R RES.CHIP RM06JT103(1608) 10K RK23 AT10696M CAR. FILM RES. 1/10W 6.8K
* RG27 AQ11655R RES.CHIP RM06JT271(1608) 270 RK24 AT10687M CAR. FILM RES. 1/10W 1.5K
* RG28 AQ11675R RES.CHIP RM06JT152(1608) 1.5K RK25 AT10707M CAR. FILM RES. 1/10W 47K
* RG29 AQ11697R RES.CHIP RM06JT103(1608) 10K RK26 AT10707M CAR. FILM RES. 1/10W 47K
* RG30 AQ11686R RES.CHIP RM06JT392(1608) 3.9K RK27 AT10698M CAR. FILM RES 1/10W 10K
* RG31 AQ11682R RES.CHIP RM06JT272(1608) 2.7K RK28 AT10672M CAR. FILM RES. 1/10W 100
* RG32 AQ11695R RES.CHIP RM06JT822(1608) 8.2K RK29 AT10672M CAR. FILM RES. 1/10W 100
* RG33 AQ11702R RES.CHIP RM06JT153(1608) 15K RK30 AT10672M CAR. FILM RES. 1/10W 100
* RG34 AQ11682R RES.CHIP RM06JT272(1608) 2.7K RK31 AT10685M CAR. FILM RES. 1/10W 1.0K
* RG35 AQ11686R RES.CHIP RM06JT392(1608) 3.9K RK32 AT10685M CAR. FILM RES. 1/10W 1.0K
* RG36 AQ11697R RES.CHIP RM06JT103(1608) 10K RK33 AT10685M CAR. FILM RES. 1/10W 1.0K
* RG37 AQ11699R RES.CHIP RM06JT123(1608) 12K RK34 AT10707M CAR. FILM RES. 1/10W 47K
* RG38 AQ11778R RES.CHIP RM06JT000(1608) JUMP RK35 AT10707M CAR. FILM RES. 1/10W 47K
* RG40 AQ11679R RES.CHIP RM06JT222(1608) 2.2K RK36 AT10707M CAR. FILM RES. 1/10W 47K
* RG42 AQ11655R RES.CHIP RM06JT271(1608) 270 RK37 AT10707M CAR. FILM RES. 1/10W 47K
* RG43 AQ11778R RES.CHIP RM06JT000(1608) JUMP. RK38 AT10707M CAR. FILM RES. 1/10W 47K
* RG44 AQ11778R RES.CHIP RM06JT000(1608) JUMP. RK39 AT10707M CAR. FILM RES. 1/10W 47K
* RG45 AQ11778R RES.CHIP RM06JT000(1608) JUMP. RK40 AT10692M CAR. FILM RES. 1/10W 3.3K
* RG46 AQ11778R RES.CHIP RM06JT000(1608) JUMP. RK42 AT03204S METAL OX. 3.9OHM 1W
* RG89 AQ11671R RES.CHIP RM06JT102(1608) 1.0K RK43 AT03411S METAL OX. 220OHM 2W
* RG90 AQ11671R RES.CHIP RM06JT102(1608) 1.0K RK44 AT10692M CAR. FILM RES. 1/10W 3.3K
* RG91 AQ11671R RES.CHIP RM06JT102(1608) 1.0K RK46 AT03199S METAL OX. 2.7OHM 1W
* RG92 AQ11671R RES.CHIP RM06JT102(1608) 1.0K RK47 AT03406S METAL OX. 150OHM 2W
* RG93 AQ11644R RES.CHIP RM06JT101(1608) 100 RK48 AT10692M CAR. FILM RES. 1/10W 3.3K
* RG94 AQ11644R RES.CHIP RM06JT101(1608) 100 RK50 AT03204S METAL OX. 3.9OHM 1W
* RG95 AQ11644R RES.CHIP RM06JT101(1608) 100 RK51 AT03411S METAL OX. 220OHM 2W
* RG96 AQ11675R RES.CHIP RM06JT152(1608) 1.5K RK52 AT10692M CAR. FILM RES. 1/10W 3.3K
* RG98 AQ11778R RES.CHIP RM06JT000(1608) JUMP. RK54 AT03199S METAL OX. 2.7OHM 1W
* RGA3 AQ11671R RES.CHIP RM06JT102(1608) 1.0K RK55 AT03406S METAL OX. 150OHM 2W
* RGA5 AQ11699R RES.CHIP RM06JT123(1608) 12K RK56 AT10692M CAR. FILM RESIS. 1/10W 3.3K
* RGA6 AQ11677R RES.CHIP RM06JT182(1608) 1.8K RK58 AT01558S METAL FILM RES.(4.7OHM 1W )
* RGA7 AQ11657R RES.CHIP RM06JT331(1608) 330 RK59 AT03411S METAL OX. 220OHM 2W
* RGA8 AQ11644R RES.CHIP RM06JT101(1608) 100 RK60 AT10692M CAR. FILM RES. 1/10W 3.3K

RK01 AT10691M CAR. FILM RES. 1/10W 2.7K RK62 AT03202S METAL OX. 3.3OHM 1W
RK02 AT10691M CAR. FILM RES. 1/10W 2.7K RK63 AT03406S METAL OX. 150OHM 2W
RK03 AT10691M CAR. FILM RES. 1/10W 2.7K RK64 AT10707M CAR. FILM RES. 1/10W 47K
RK04 AT10691M CAR. FILM RES. 1/10W 2.7K RK90 AT10698M CAR. FILM RES. 1/10W 10K
RK05 AT10691M CAR. FILM RES. 1/10W 2.7K RK94 AT10685M CAR FILM RES. 1/10W 1.0K
RK06 AT10691M CAR. FILM RES. 1/10W 2.7K RK97 AT03193S METAL OX. 1.5OHM 1W
RK07 AT10691M CAR. FILM RES. 1/10W 2.7K RK99 0113698M RES.-CAR. FLM 1/2W 8.2-J
RK08 AT10691M CAR. FILM RES 1/10W 2.7K RKA1 AT10712M CAR. FILM RES. 1/10W 100K
RK09 0100057M RES.-CARBON FLM 1/8W 470-JB RKA2 AT10709M CAR. FILM RES. 1/10W 68K
RK10 AT10686M CAR. FILM RES. 1/10W 1.2K RKA3 AT10698M CAR. FILM RES. 1/10W 10K
RK11 AT10685M CAR. FILM RES. 1/10W 1.0K RKA4 AT10684M CAR. FILM RES. 1/10W 820
RK12 AT10685M CAR. FILM RES. 1/10W 1.0K RL10 0100129M RES.-CAR. FLM 1/8W 470K-JB
RK13 AT10685M CAR. FILM RES. 1/10W 1.0K RL11 0100129M RES.-CAR. FLM 1/8W 470K-JB
RK14 AT10696M CAR. FILM RES. 1/10W 6.8K RL12 0100129M RES.-CAR. FLM 1/8W 470K-JB
RK15 AT10691M CAR. FILM RES. 1/10W 2.7K RL13 0100129M RES.-CAR. FLM 1/8W 470K-JB
RK16 AT10694M CAR. FILM RES 1/10W 4.7K

PRODUCT SAFETY NOTE : Components marked with a have special characteristics important to safety. Before replacing
any of these components, read carefully the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety
of the receiver through improper servicing.

SYMBOL PART NO DESCRIPTION SYMBOL PART NO DESCRIPTION

NO. NO.

RL14 0100129M RES.-CAR. FLM 1/8W 470K-JB RT30 AQ11778R RES.CHIP RM06JT000(1608) JUMP
RL15 0100129M RES.-CAR FLM 1/8W 470K-JB RT32 AQ11697R RES.CHIP RM06JT101(1608) 10K
RL16 0100129M RES.-CAR FLM 1/8W 470K-JB RT34 AQ11704R RES.CHIP RM06JT183(1608) 18K
RL17 0100129M RES.-CAR FLM 1/8W 470K-JB RT35 AQ11644R RES.CHIP RM06JT101(1608) 100
RL20 0100133M RES.-CAR FLM 1/8W 680K-JB RT36 AQ11697R RES.CHIP RM06JT103(1608) 10K
RL21 0100121M RES.-CAR FLM 1/8W 220K-JB RT37 AQ11778R RES.CHIP RM06JT000(1608) JUMP
RL22 0100133M RES.-CAR FLM 1/8W 680K-JB * RX01 AQ11697R RES.CHIP RM06JT103(1608) 10K
RL23 0100129M RES.-CAR FLM 1/8W 470K-JB * RX02 AQ11644R RES.CHIP RM06JT101(1608) 100
RL24 0100133M RES.-CAR FLM 1/8W 680K-JB * RX03 AQ11644R RES.CHIP RM06JT101(1608) 100
RL25 0100121M RES.-CAR FLM 1/8W 220K-JB * RX04 AQ11644R RES.CHIP RM06JT101(1608) 100
RL26 0100133M RES.-CAR FLM 1/8W 680K-JB * RX05 AQ11702R RES.CHIP RM06JT153(1608) 15K
RL27 0100129M RES.-CAR FLM 1/8W 470K-JB * RX06 AQ11706R RES.CHIP RM06JT223(1608) 22K
RL30 AT10672M CAR. FILM RES 1/10W 100 * RX07 AQ11662R RES.CHIP RM06JT471(1608) 470
RL31 AT10672M CAR. FILM RES. 1/10W 100 * RX08 AQ11631R RES.CHIP RM06JT330(1608) 33
RL32 AT10672M CAR. FILM RES. 1/10W 100 * RX09 AQ11631R RES.CHIP RM06JT330(1608) 33
RL33 AT10672M CAR. FILM RES. 1/10W 100 * RX10 AQ11617R RES.CHIP RM06JT100(1608) 10
RL34 AT10672M CAR. FILM RES. 1/10W 100 * RX11 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
RL35 AT10672M CAR. FILM RES. 1/10W 100 * RX12 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
RL36 AT10672M CAR. FILM RES. 1/10W 100 * RX13 AQ11706R RES.CHIP RM06JT223(1608) 22K
RL37 AT10672M CAR. FILM RES. 1/10W 100 * RX14 AQ11715R RES.CHIP RM06JT473(1608) 47K
RP01 AT03669M RES.MTL GRAZD FLM 1/2W 2.2M * RX15 AQ11706R RES.CHIP RM06JT223(1608) 22K
RP03 0147722 RES.-WIRE WOUND 10W 3.3-KM CEMENT * RX16 AQ11715R RES.CHIP RM06JT473(1608) 47K
RP04 0147722 RES.-WIRE WOUND 10W 3.3-KM CEMENT * RX17 AQ11695R RES.CHIP RM06JT822(1608) 8.2K
RP05 0174704G RES.-METAL OXIDE 10M-J TYPE V R68 * RX18 AQ11653R RES.CHIP RM06JT221(1608) 220
RT01 AQ11671R RES.CHIP RM06JT102(1608) 1.0K * RX19 AQ11679R RES.CHIP RM06JT222(1608) 2.2K
RT04 AQ11671R RES.CHIP RM06JT102(1608) 1.0K * RX20 AQ11646R RES.CHIP RM06JT121(1608) 120
RT05 AQ11697R RES.CHIP RM06JT103(1608) 10K * RX21 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
RT06 AQ11671R RES.CHIP RM06JT102(1608) 1.0K * RX22 AQ11684R RES.CHIP RM06JT332(1608) 3.3K
RT07 AQ11687R RES.CHIP RM06JT682(1608) 4.3K * RX23 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
RT08 AQ11707R RES.CHIP RM06JT243(1608) 24K * RX24 AQ11706R RES.CHIP RM06JT223(1608) 22K
RT09 AQ11688R RES.CHIP RM06JT472(1608) 4.7K * RX25 AQ11715R RES.CHIP RM06JT473(1608) 47K
RT10 AQ11688R RES.CHIP RM06JT472(1608) 4.7K * RX29 AQ11706R RES.CHIP RM06JT223(1608) 22K
RT11 AQ11644R RES.CHIP RM06JT101(1608) 100 * RX30 AQ11715R RES.CHIP RM06JT473(1608) 47K
RT12 AQ11644R RES.CHIP RM06JT101(1608) 100 * RX31 AQ11706R RES.CHIP RM06JT223(1608) 22K
RT13 AQ11697R RES.CHIP RM06JT103(1608) 10K * RX32 AQ11715R RES.CHIP RM06JT473(1608) 47K
RT14 AQ11666R RES.CHIP RM06JT681(1608) 680 * RX33 AQ11711R RES.CHIP RM06JT333(1608) 33K
RT15 AQ11644R RES.CHIP RM06JT101(1608) 100 * RX34 AW00107 TRIMMER RESISTOR
RT16 AQ11644R RES.CHIP RM06JT101(1608) 100 * RX35 AQ11778R RES.CHIP RM06JT000(1608) JB
RT17 AQ11644R RES.CHIP RM06JT101(1608) 100 * RX36 AQ11679R RES.CHIP RM06JT222(1608) 2.2K
RT18 AQ11751R RES.CHIP RM06JT105(1608) 1.0M * RX37 AQ11679R RES.CHIP RM06JT222(1608) 2.2K
RT19 AQ11702R RES.CHIP RM06JT153(1608) 15K * RX38 AQ11679R RES.CHIP RM06JT222(1608) 2.2K
RT20 AQ11702R RES.CHIP RM06JT153(1608) 15K * RX39 AQ11679R RES.CHIP RM06JT222(1608) 2.2K
RT21 AQ11704R RES.CHIP RM06JT183(1608) 18K * RX40 AQ11657R RES.CHIP RM06JT331(1608) 330
RT22 AQ11644R RES.CHIP RM06JT101(1608) 100 * RX41 AQ11657R RES.CHIP RM06JT331(1608) 330
RT23 AQ11666R RES.CHIP RM06JT681(1608) 680 * RX42 AQ11664R RES.CHIP RM06JT561(1608) 560
RT24 AQ11778R RES.CHIP RM06JT000(1608) JUMP * RX44 AQ11655R RES.CHIP RM06JT271(1608) 270
RT25 AQ11644R RES.CHIP RM06JT101(1608) 100 * RX45 AQ11655R RES.CHIP RM06JT271(1608) 270
RT26 AQ11666R RES.CHIP RM06JT681(1608) 680 * RX47 AQ11778R RES.CHIP RM06JT000(1608) JB
RT27 AQ11778R RES.CHIP RM06JT000(1608) JUMP * RX48 AQ11671R RES.CHIP RM06JT102(1608) 1.0K
RT28 AQ11644R RES.CHIP RM06JT101(1608) 100 * RX50 AQ11724R RES.CHIP RM06JT104(1608) 100K
RT29 AQ11666R RES.CHIP RM06JT681(1608) 680 * RX51 AQ11724R RES.CHIP RM06JT104(1608) 100K

PRODUCT SAFETY NOTE : Components marked with a have special characteristics important to safety. Before replacing
any of these components, read carefully the PRODUCT SAFETY NOTICE of this Service Manual. Don't degrade the safety
of the receiver through improper servicing.

SYMBOL PART NO DESCRIPTION SYMBOL PART NO DESCRIPTION

NO. NO.

* RX52 AQ11715R RES.CHIP RM06JT473(1608) 47K
* RX53 AQ11699R RES.CHIP RM06JT123(1608) 12K
* RX54 AQ11648R RES.CHIP RM06JT151(1608) 150

RM01 AT10685M CAR.- FILM RES. 1/10W 1.0K
RM02 AT10703M CAR.- FILM RES. 1/10W 22K
RM03 AT10689M CAR.- FILM RES. 1/10W 2.2K
RM04 0100065M RES.-CARBON FLM 1/8W 1K-JB
RM06 AT10685M CAR.- FILM RES. 1/10W 1.0K
RM07 AT10687M CAR.- FILM RES. 1/10W 1.5K
RM08 AT10691M CAR.- FILM RES. 1/10W 2.7K
RM09 AT10694M CAR.- FILM RES. 1/10W 4.7K
RM12 0114143M RES.-CAR. FLM 1/4W 330-JB
RM15 AT10698M CAR.- FILM RES. 1/10W 10K
RM20 0100041M RES.-CAR. FLM 1/8W 100-JB
RM21 AT10685M CAR.- FILM RES. 1/10W 1.0K
RM22 AT10685M CAR.- FILM RES. 1/10W 1.0K
RM23 AT10708M CAR.- FILM RES. 1/10W 56K
RM24 AT10689M CAR.- FILM RESISTOR 1/10W 2.2K
RM25 0100123M RES.-CAR. FLM 1/8W 270K-JB
RM26 AT10692M CAR.- FILM RES. 1/10W 3.3K
RM27 AT10708M CAR. FILM RES. 1/10W 56K
RM28 0100123M RES.-CAR. FLM 1/8W 270K-JB
RM29 AT10685M CAR.- FILM RES. 1/10W 1.0K
RM30 AT10685M CAR.- FILM RES. 1/10W 1.0K
RM31 0100041M RES.-CAR. FLM 1/8W 100-JB
RM32 AT10809M RES.CAR. FLM(RD1/6JT5750) 75
RM33 AT10809M RES.CAR. FLM RD1/6JT5750 75
RM34 AT10707M CAR. FILM RES. 1/10W 47K
RM35 AT10685M CAR. FILM RES. 1/10W 1.0K
RM36 AT10709M CAR. FILM RES. 1/10W 68K
RM37 AT10809M RES.CAR. FLM (RD1/6JT5750) 75
RM38 0100065M RES.-CAR. FLM 1/8W 1K-JB
RM40 0100043M RES.-CAR. FLM 1/8W 120-JB
RM41 0100043M RES.-CAR. FLM 1/8W 120-JB
RM44 AT10687M CAR.- FILM RES. 1/10W 1.5K
RM45 AT10684M CAR. FILM RES. 1/10W 820
