HIT BG17SS
Cooking with your microwave
Instruction booklet
GB
Safety
First aid
Treat scalding by:
1 Quickly placing the scald
under cold running water
for at least 10 minutes.
2 Cover with a clean dr y
dressing. Do not use
creams, oils or lotions.
Fire
In the event of fire:
1 Keep the oven door
closed.
2 Turn off the power.
3 Unplug from mains.
GB-2
Impor tant Safety Instructions
l
Please Read Carefully and
Keep for Future Reference
Maintenance of your Microwave
It is hazardous for anyone other than a
qualified technician to carry out any
service or repair operation which involves
the removal of a cover which gives
protection against exposure to microwave
energy.
l If the door is damaged, the oven must
not be operated until it has been repaired
by a competent person.
l If smoke is obser ved, switch off or unplug
the appliance and keep the door closed in
order to contain any flames.
l If the supply cord is damaged, it must be
replaced by a ser vice agent or similar
qualified technician.
l If you have a pacemaker, please contact
your doctor before using a microwave
oven.
Microwave use
l This microwave is not intended for
commercial use.
l It should never be used for dr ying clothes
or other non-food purposes.
l The microwave should not be left
unattended when in use.
l Only use utensils that are suitable for
microwave use.
l Care should be taken so metal objects are
not left in the microwave
l The temperature of accessible surfaces
may be high when the appliance is
operating.
l To prevent high moisture content gather
inside the oven cavity, open the door
immediately after the cooking function
has stopped to allow steam to escape.
Only use utensils that are suitable for
microwave use. Refer to the section on the
correct utensils to use in this appliance.
l Care should be taken so metal objects are
not left in the microwave
These include :
¨ Metal cooking utensils
¨ Metal plates or trays
¨ Wire twist ties
¨ Crockery with metal trims
¨ Meat thermometer
Care should be taken when using paper,
l
plastic, wooden or other combustible
materials in the oven as they can catch
fire
l
Oil & fat for deep fr ying should not
heated in the microwave
l
Only use cling film designed for
microwave use & take extra care when
removing the film to avoid steam burns
Only heat popcorn that has been
l
designed for microwave use.
Cooking use
As the power of different microwave ovens
can vary considerably, care must be taken
when first using this appliance as it may
cook faster than your old unit.
l Do not leave the appliance unattended
during use.
l Only allow children to use the oven
without supervision when adequate
instructions have been given so that the
child is able to use the oven in a safe
way and understands the hazards of
improper use;
l Take care when cooking food with a high
sugar or fat content, such as Christmas
pudding or fruitcake. The sugar or fat can
overheat and in some cases catch fire.
Cleaning
The oven should be cleaned regularly and
food deposits removed. Failure to maintain
the oven in a clean condition can affect the
life of the appliance and possibly result in a
hazardous situation.
(See cleaning your microwave )
Containers
l Pressure will build up in sealed containers
and can cause them to explode. Therefore
do not use the following in your
microwave:
Sealed containers
· Capped bottles
· Vacuum containers
· Sealed jars
· Hard-boiled egg
· Eggs in their shells
· Nuts
l Always pierce the skin of fruit and
vegetables, such as potatoes.
Delayed boiling
Liquids heated in a microwave can boil up
when removing them from the microwave.
Take the following precautions :
l Always stir liquids, before & after
cooking
l Allow them to stand
l Use containers that are wider at the top
than the bottom
Preparing Food for babies
Extra care must be taken when preparing
food or drink for babies and small children.
l
Always test the food or liquid
temperature before giving it to
baby.
l When using a baby bottle, ensure the teat
is removed before heating.
l When warming milk, ensure the bottle is
shaken.
Caution
!
During convection and grill modes outer
surface will become hot, do not touch outer
casing of appliance. Care should be taken
not to store any items on top of your
microwave oven.
Contents
Contents
Unpacking and getting ready page 4
Introducing microwave cooking page 6
Setting the child lock page 11
Using the microwave page 12
Quick Start Cooking page 14
Auto Menu page 15
Setting the Clock page 17
Program Set In Advance page 18
Multi-stage cooking page 19
Inquiring Function page 20
Defrosting page 21
Cleaning your microwave page 23
Using aluminium foil in your microwave page 24
Questions and answers page 25
Specification page 27
Installation instructions page 28
GB-3
Unpacking
This microwave oven is
designed for home use. It
should not be used for
commercial catering.
Unpacking and getting ready
After unpacking your oven, check that it has not been damaged whilst in
the box. Make sure there are no dents, that the door closes properly.
1
A dented or damaged oven could allow microwave energy to escape.
Make sure that you have taken all the packaging from inside the oven.
Choose a flat work surface for your microwave away from heat sources
such as radiators or fires, and away from anywhere that is very cold.
2
You should allow a 10cm space all around the oven and
30cm above so that warm air can escape from the
vents during cooking – it is not designed to be built in.
Plug your oven into a standard household electrical socket
(240 volt, 13 amp rated).
3
10 cm
30 cm
10 cm
GB-4
Avoid using a socket that also has an adaptor and other equipment
plugged in.
Put the turntable ring inside the oven and place the glass turntable on
top of the ring. The turntable is shaped to sit securely on the spindle.
4
You must always use the turntable and ring whenever you use the
microwave.
Turntable spindle
Accessories: (included)
Glass turntable
Grill rack
Turntable ring
Grill Rack
LED display
Shows the clock or
cooking time/setting
Defrost by weight
buttons
Use this button to select
the defrost by weight
function
Auto Menu buttons
To quickly set cooking
times for certain foods
Quick Start/Start
button
Use this button once, one
minute to cook instantly
and to start cooking
Timer/Power/
Weight setting
For setting time, power
and weight
Display
Shows the clock and cooking
time/setting
Control panel
The oven beeps when you choose a
setting on the control panel
Getting to know your
microwave
Clock/Pre-set buttons
Use this button to set clock and
preset
Defrost by time button
Use this button to sett defrost by
time
Cancel/Stop button
This button will stop cooking and
clear cooking settings.
Microwave/Grill/
Combination button
Use this button to select the
function of microwave, grill,
microwave & grill combination
GB-5
Introducing microwave
cooking
Introducing microwave cooking
Always remember the basic safeguards you would follow when using any
cooking equipment or handling hot food.
This page gives some of the basic guidelines for microwave cooking.
If you are unfamiliar with using a microwave, there is more information
at the back of this instruction booklet.
Cooking with a microwave
Cooking with a microwave is much faster than
conventional cooking and, whilst you should make
sure that food is fully cooked, you should be careful
not to overcook it.
If you are cooking a number of individual foods at the
same time, such as baked potatoes or small cakes,
arrange them evenly on the turntable so that they cook
evenly. Never stack food in your microwave.
Meat and poultr y which is cooked for 15 minutes
or more will brown lightly in it is own fat.
Anything cooked for a shorter time can be brushed
with a browning sauce to give an appetising colour.
You should always have your microwave checked
if it is dropped or damaged.
Microwave energy can heat unevenly so stirring to
distribute heat is ver y impor tant. Always stir from the
outside towards the centre.
Tur n larger foods such as meat roasts and poultry
during cooking so that the top and bottom cook
evenly. It is also a good idea to turn chops and
chicken pieces, especially if they contain the bone.
Strips of aluminium foil can be used to cover the
thinner pieces of food to stop them overcooking
before the thicker parts of the food have had a
chance to cook. Use the foil sparingly and wrap
around the food or container carefully to stop it
touching the inside of the oven which could cause
sparks.
GB-6
Microwave ovens cook food using microwave energy that is
similar to naturally occurring radio waves. Normally, these
"waves" would fade as they disappeared into the atmosphere,
but in a microwave oven they are concentrated onto food
causing it to heat up.
Microwave energy can not pass through metal – so it can not
escape from inside your microwave oven – but it can pass
through materials like glass, porcelain, plastic, and paper.
These are the things used to make
microwave-safe
cooking
equipment.
Microwave-safe cooking equipment will still get hot as the
food it contains heats up.
Checking your cooking utensils
The microwave energy focuses on the moisture in the
food causing lots of tiny vibrations. The vibrations get so
great that the moisture – and the food – heat up.
Introducing microwave
cooking
Safety
Never use equipment
made of metal, except
foil in your microwave
oven.
The microwave energy
can not pass through the
metal so it bounces off
and sparks against the
inside of the oven.
Stop the microwave straight
away if any equipment does
cause sparks.
Remember that some crocker y
has a metal trim around the
edge. Even this trim can cause
sparks.
Most heat-resistant, non-metallic cooking utensils are safe to use in your
microwave. If you are not sure you can use a utensil in your microwave,
follow this simple test:
1 Make sure that the grill is positioned in the upwards position to
the top of the microwave (Do not use your hands to touch the grill
as it may already be hot).
2 Put the utensil into the oven next to a cup of water – use a cup
that you know is microwave-safe. Close the door
3 Turn the microwave oven on for 30 seconds only.
4 At the end of the time, carefully check to see if the water has
warmed up. If the water has not warmed up but the utensil has, the
utensil is not microwave-safe and should not be used in the oven.
Safety
Never use scratched,
cracked or damaged
glass in a microwave.
Damaged glass can
explode.
GB-7
Introducing microwave
cooking
More about getting the most from microwave cooking
Microwave heating categories
Your oven has been tested and labelled to meet the government's
voluntar y agreement on the reheating of pre-cooked food.
Remember
Always check that the food is
evenly cooked and piping hot
before you ser ve it.
700W
D
The heating characteristics and output power levels of microwave
ovens are usually calculated using a relatively large portion of food
(a 1000 gram load, IEC 705) but many packs of pre-cooked food
are sold in smaller packs, often about 350 grams. The government,
in partnership with food companies and microwave manufacturers,
have set up a system of heating categories to help you choose the
reheating time for pre-cooked food.
700W is the output power of
the oven.
D is the heating categor y for your
oven.
Check the cooking times for categor y
D on the food's packaging to see
how long it should be cooked for.
To Microwave:Remove outer packaging.
Pierce film lid SEVERAL TIMES.
Place on a microwaveable plate. Heat on
full power. Turn halfway through heating.
To Microwave from Frozen: Remove outer
packaging. Pierce film lid SEVERAL TIMES.
Place on a microwaveable plate. Heat on
full power. Turn halfway through heating.
GB-8
Steam
When you microwave food, steam is created as water in the
food heats up and evaporates.
The steam formed during microwave cooking is entirely safe. It has
to escape from the microwave to prevent pressure from building up
inside the oven. It does this through the vents on the back of the oven
and from around the door.
Condensation
As the steam cools, you may find the condensation gathers in small
pools inside your microwave and on the work surface beneath the
door and vents.
Always dr y the oven after cooking foods with a high moisture
content.
Introducing microwave
cooking
Your microwave is designed to let steam escape from the vents
and around the door without microwave energy escaping.
There is no danger of microwave energy escaping with the steam.
GB-9
Introducing microwave
cooking
Checking your microwave
Check your microwave is working after unpacking and whenever
you think it might not be working properly.
Safety
For your safety, the
microwave stops if the oven
door is opened during
cooking. Close the door to
continue the cooking cycle.
Hint
Push button to open the door.
Put the turntable ring inside the oven and place the glass turntable on
1
top of the ring. The turntable is shaped to sit securely on the spindle.
You must always use the turntable and ring whenever you use the
microwave.
Place a cup of water on the turntable. Make sure the cup is
microwave-safe – it should not have any decorative metal trim.
Close the oven door.
2
Press the "Cancel/Stop" button to clear any settings that have already been made.
3
Press the "Quick Start/Start" button once.
4
The oven light comes on during cooking.
You can stop cooking at
any time so that you can;
check the food, turn the food
over, stir it or leave the food to
stand.
GB-10
When cooking finishes, the water should be hot - be careful when you take the
5
cup out of the oven.
Press the "Cancel/Stop" button
Setting the Child Lock
The child lock is a safety feature which when set will lock all of the buttons on your
microwave. This prevents your microwave being used accidentally though your
microwave door will still open.
Lock: In waiting state, press "Cancel/Stop" for 3 seconds, there will be a long beep
1
denoting entering the children-lock state and oven will display " ".
Lock quitting: In locked state, press "Cancel/Stop" for 3 seconds, there will be a long
2
"beep" denoting that the lock is released.
Setting the child lock
Hint
Your oven has a safety
feature that prevents children
from using your oven. Once
the child lock is set, you will
be unable to use any functions
and no cooking can take
place. However your child can
still open the oven door.
GB-11
Using the microwave
Hint:
Starting and stopping
cooking
It is possible to check cooking
progress at any time, by
opening the door and
inspecting the food. This
interrupts the emission of
microwave energy and the
oven stops working until the
door is closed again.
To resume cooking, close the
door, and press the
Quick Start/Start button.
Using the microwave
Basic microwave cooking and reheating
Press the "Cancel/Stop" button.
1
Make sure the glass turntable and the turntable ring
are inside the oven.
2
GB-12
Press "Micro./Grill/Combi." and turn "Timer/Power/Weight" to select the function
3
you want. Press "Micro./Grill/Combi." and turn "Timer/Power/Weight" to select
the cooking time.
Press "Quick Start/Start" to start cooking.
4
Example: If you want to use 80% microwave to cook food for 20 minutes,
you can operate the oven as the following steps.
1) Press "Micro./Grill/Combi.", the screen display "P100".
2) Turn "Timer/Power/Weight" to adjust 80% microwave power
until the oven displays "P 80".
3) Press "Micro./Grill/Combi." to confirm, the screen displays
"P 80".
4) Turn "Timer/Power/Weight" to adjust the cooking time until
the oven displays "20:00".
5) Press "Quick Start/Start" to start cooking or press
"Cancel/Stop" to cancel the settings.
"Micro./Grill/Combi." Pad instructions
Order
LED Display
Microwave
Power
Grill
Power
Using the microwave
1
2
3
4
5
6
7
8
100%
80%
50%
30%
10%
0%
55%
36%
100%
45%
64%
Hint
If you do not open the oven
door or press "Cancel/Stop"
when cooking time has
elapsed, your microwave
power will stop automatically.
GB-13
Microwave cooking
Hint
The quick start feature allows
you to set one minute intervals
of HIGH power cooking with
the touch of the "Quick Start/
Start" button.
Quick star t cooking
This function is useful when heating small amounts of food or drink, or for
adding an extra one minute when cooking time has already elapsed.
Put the turntable ring inside the oven and place the glass turntable on
top of the ring. The turntable is shaped to sit securely on the spindle.
1
You must always use the turntable and ring whenever you use the
microwave.
Close the oven door.
When the oven is in the waiting state, Press "Quick Start/Start" to start
2
cooking food with full microwave power for 1 minute. Each press will
increase one minute. The maximum cooking time is 95 minutes.
GB-14
Auto Menu
Example: If you want to use "Auto Menu" to cook fish of 250g.
Press "Auto Menu" , " " and " " will light.
1
Turn "Timer/Power/Weight" to select the function you want.
2
Press "Auto Menu" button to confirm.
3
Turn "Timer/Power/Weight" to select the weight of fish. "g" will light.
4
Microwave cooking
Press "Quick Start/Start" to start. "g" will go out, " " and " " will flash.
5
GB-15
Microwave cooking
The automatic menu procedure:
Menu
A-1
Auto Reheat
A-2
Vegetable
A-3
Fish
A-4
Meat
A-5
Pasta
A-6
Potato
A-7
Pizza
A-8
Soup
Order
1
2
3
4
5
6
7
8
Weight
200 g
400 g
600 g
200 g
300 g
400 g
250 g
350 g
450 g
250 g
350 g
450 g
50 g
100 g
200 g
400 g
600 g
200 g
400 g
200 ml
400 ml
Display
Cooking Time
2'00"
3'10"
4'30"
4'30"
5'00"
6'10"
4'50"
5'40"
7'20"
5'20"
6'20"
7'40"
18'00"
22'00"
5'00"
8'40"
10'10"
2'50"
4'25"
2'00"
3'10"
Make sure food is thoroughly heated through.
Add a few tablespoons of water, cover with cling film for
microwave use and pierce with a fork. Be cautious of steam
burns when removing the cling film.
Make sure thicker cuts are cooked through before consuming.
Make sure thicker cuts are cooked through before consuming.
50g Pasta + 450g cold water.
100g Pasta + 800g cold water.
For best results, once the potatoes are cooked wrap them in tin
foil for at least 5 minutes to cook through.
This setting is designed for re-heating fresh pizza slices (not
frozen pizza).
Place in a microwave safe dish, cover with cling film and pierce
with a fork.
GB-16
Setting the clock
When the microwave oven is electrified, the oven will display "0:00", buzzer will ring once.
Press "Clock/Pre-Set", the hour figures will flash, and the indicator for clock " "
1
will light.
Turn "Timer/Power/Weight" to adjust the hour figures, the input time should be
within 0--23.
2
Press "Clock/Pre-Set", the minute figures will flash.
3
Turn "Timer/Power/Weight" to adjust the minute figures, the input time should
be within 0--59.
4
Microwave cooking
Press " Clock/Pre-Set" to finish clock setting. The indicator for clock " " will go out,
":" will flash, and the time will light.
5
GB-17
Microwave cooking
Program set in Advance
Set the clock first. (Consult the instruction of clock setting.)
1
Input the cooking program. Three stage power levels can be set at most. Defrost should
2
always be set as the first stage, if it is included in the multi-level program.
Please do not press "Quick Start/Start" to start cooking at the last step.
Press "Clock/Pre-Set", the hour figures will flash, and the indicator " " will light.
3
Turn "Timer/Power/Weight" to adjust the hour figures, the input time should be within
4
0--23.
GB-18
Press "Clock/Pre-Set", the minute figures will flash.
5
Turn "Timer/Power/Weight" to adjust the minute figures, the input time should be within
6
0--59.
Press "Quick Start/Start" to finish setting. The indicator for clock " " will flash. If the
7
door is closed, buzzer will ring twice when the time arrives, then cooking will start automatically
and the indicator for clock " " will go out.
Multi-section cooking
At most 3 sections can be input for cooking. In multi-section cooking, if one section is defrosting, then
defrosting shall be placed in the first section.
Example: If you want to use "20 minutes of 100% microwave power + 5 minutes of 80% microwave
power " to cook food.
Press "Micro./Grill/Combi." pad , the screen display "P100".
1
Press "Micro./Grill/Combi." to select 100% microwave power.
2
Turn "Timer/Power/Weight" to select cooking time.
3
Microwave cooking
Press "Micro./Grill/Combi." pad , the screen display "P100".
4
Turn "Timer/Power/Weight" to select 80% microwave power.
5
Press "Micro./Grill/Combi." pad, then turn "Timer/Power/Weight" to select
6
cooking time of 80% microwave power.
Press "Quick Start/Start" to start cooking or press "Cancel/Stop" to cancel
7
the setting. The unit will turn back to the clock state.
Hint
During two stage
cooking the oven door can be
opened and food checked.
Close the oven door and press
Quick Start/Start and the
cooking stage will continue.
If you wish to clear the
programme press "Cancel/
Stop"twice.
GB-19
Microwave cooking
Inquiring Function
In microwave, grill or combination cooking state, press "Micro./Grill/Combi.", the
current power will be displayed for 4 seconds. After 4 seconds, the oven will turn back
to the former state;
In cooking state, press "Clock/Pre-Set" to inquire the present time and the time will
flash for 4 seconds.
In preset state, press "Clock/Pre-Set" to inquire the preset time and it will flash for
4 seconds.
GB-20
Defrosting
Defrost by weight
Defrosting
Make sure the glass turntable, turntable ring and defrost rack
are inside the oven.
1
After putting your frozen food in the oven on the defrost rack,
close the door.
Press the "Cancel/Stop" button.
Press "Defrost By Wt." button. LED will display "dEF1", " "
2
and " " will light.
Turn "Timer/Power/Weight" to select the weight of food, "g" will light.
3
Press "Quick Start/Start" to start defrosting food. " " and " "
4
will flash.
Hint
You may wish to place the
frozen food onto a plate or
dish before placing it onto the
defrost rack. This will ensure
the food load is contained
While the Oven is defrosting,
open the oven door, turn the
food over and separate to
ensure even thawing, close the
door. Press the "Cancel/Stop"
button
Your oven will not stop
defrosting unless the door is
opened.
GB-21
Defrosting
Defrost By Time
Make sure the glass turntable, turntable ring and defrost rack
are inside the oven.
1
After putting your frozen food in the oven on the defrost rack,
close the door.
Press the "Cancel/Stop" button.
Press "Defrost By Time" button. LED will display "dEF2", " " and " "
2
will light.
Turn "Timer/Power/Weight" to select the cooking time.
3
GB-22
Press "Quick Start/Start" to start defrosting food. " " and " "
4
will flash.
Cleaning your microwave
Cleaning
Cleaning your oven each time you use it will help to prevent stubborn marks that can be difficult to clean.
Keep the front of the
oven clean so that the
The oven walls have a special
enamel coating which makes
cleaning ver y easy. Use a soft
damp cloth to wipe off any
splashes or a paper towel to mop
up any spills. Wipe off grease with
a damp cloth and a little detergent.
Dr y thoroughly. As with any oven,
if grease is left to accumulate, it
can smoke and even catch fire.
Make sure you
keep the outlet
grids clean.
Check that the door
catches are clean.
Do not remove any fixed parts from the inside
of your microwave oven during cleaning or at
any other time.
Keep the inside of the door clean with a damp cloth. Use
warm soapy water for stubborn marks and dry
thoroughly.
The inside of the door has a special coating and must not
be cleaned with abrasive pads or cleaning powders
Wash racks in warm water.
Do not use very hot water
on the racks which could
make them warp.
door can close
properly.
Clean behind
the door ledge.
Be careful not to spill
water into the vents.
Use warm soapy water to
clean the outside of the
oven. Do not use abrasive
pads or powders that
could scratch the surface.
Unplug the oven before
cleaning the power lead.
Wipe with a damp cloth
and leave to dr y before
plugging it back in.
Unplug your oven
before you clean it.
Treat the turntable as
you would any glass
plate. After you ave
used it for more than 15
minutes, allow it to cool
down before you use it
again. Do not wash the
turntable in ver y hot
water that could crack it.
Make sure the turntable
is dr y before you put it
back in the oven.
Caution
Pay attention to the area around
the wave guide cover which if not
regularly cleaned can collect food
residue creating a potential fire
hazard.
Warning
Ensure you unplug your
microwave from the mains and
wait for the oven to cool down
completely before cleaning.
GB-23
Using aluminium foil
Using aluminium foil in your
microwave
It is safe to use aluminium foil in your microwave oven as long as you follow these safety guidelines.
As with all metal, microwave energy
can not pass through foil, but provided
that you keep the foil away from the
side of the oven it will not cause sparks
and there will not be any damage to
your oven.
Using foil is a good way of shielding
parts of food that you do not want to
cook as quickly as others – perhaps
where the food is narrower and
would other wise overcook.
Place the foil over the area you want
to shield, taking care that the foil
will not touch the sides of the oven
when the turntable rotates. Only use
one piece of foil at a time so that you
do not get sparks between the separate
pieces.
Follow these guidelines when using
foil in your microwave:
Remove foil lids from containers
before using in the microwave.
Some lids are made of card
with a foil covering – these
should be removed too.
Use a microwave-safe
transparent lid if possible.
Stir food during cooking if the
container has a lid or film
cover.
Always use the glass turntable.
Use shallow containers with a
large surface area. Do not use
containers that are more than
1.25in (3.5cm) deep.
Do not completely cover food
with foil. The microwave energy
cannot pass through the foil so
the food will not cook.
Do not let aluminium foil touch
the inside of the oven.
Do not use more than one piece
of foil in the oven at the same
time.
GB-24
Use oven gloves when handling
hot foil containers.
Questions and answers
Questions and answers
Q
A
Q
A
Q
A
Why does not food seem to cook?
Check that:
• the cooking time has been set
• the door is closed
• the power socket is not overloaded causing a fuse
to blow.
Why does the food seem undercooked or
overcooked?
Check that:
• the correct cooking time has been set
• the correct power setting has been used.
How can I stop eggs from popping?
When you bake or poach eggs in the microwave,
the yolk can sometimes pop as steam builds up
inside it. You can stop the egg from popping by
piercing the yolk with a toothpick before cooking.
Never cook eggs that are still in their shells.
Q
A
Q
A
Q
Why is it so important that I allow
standing time after cooking?
With microwave cooking, many foods build up
enough heat inside them to continue cooking even
after they have been taken out of the oven. Because
microwave cooking works from the outside of food
inwards, standing time lets you cook the centre of
the food just right without the outside being
overcooked.
Why does my oven sometimes take longer
to cook than it says in the recipe?
First check that the oven was set just as the recipe
said.
Cooking times and heat settings are suggestions to
help prevent overcooking but differences in the
weight, size, shape and starting temperature of
food will all affect how long it takes to cook – just
as it does with a conventional oven.
Use your judgement along with the recipe to check
whether food has been cooked properly.
Why do I get condensation on the inside of
the oven door?
If you have a problem
that can not be answered
by these points, please
contact your nearest
store.
Please note: If you call a
Mastercare engineer out to
your home and the product is
found not to be faulty, or the
instruction book has not been
followed, our product
guarantee is not applicable
and a call-out fee will be
charged.
A
Condensation is perfectly normal, especially when
you are cooking food with a high moisture content
such as potatoes.
GB-25
Questions and answers
Q
A
Q
A
Q
A
Does the microwave energy get through
the window on the door?
No. The door has a special metal screen with holes
in that lets you see inside but stops microwave
energy from getting out.
Steam comes out of the side of the door
and vents. Can microwave energy get out
too?
No. The door and vents are carefully designed to
let steam out during cooking but keep microwave
energy in. The gaps are not big enough for
microwave energy to escape.
What happens if the microwave is
switched on while the oven is empty?
The microwave will be damaged. Do not switch the
microwave on when there is nothing inside the oven.
It is a good idea to keep a cup of water in the oven
just in case someone accidentally starts the
microwave.
Q
A
Q
A
Q
A
Q
Why will not the oven light come on?
Open the door. If the light does not come on, the
bulb has probably blown. Call a qualified repairer
– do not try to change the bulb yourself.
There are sparks inside the oven when I
use the microwave. Will this cause any
damage?
Yes. Make sure that you are not using any metal
utensils and that your containers do not have a metal
trim. You must not use metal in your microwave,
except foil, when you cook.
Light is showing through the vents and
door. Does this mean the microwave
energy can escape?
No. It is normal for the light to be visible and is
nothing to be concerned about.
Why do I get interference on my TV and
radio when I use the microwave?
GB-26
A
Microwave ovens use radio waves similar to those
received by TVs and radios. You can lessen the
interference by moving your microwave fur ther
away from the TV or radio.
Specification
Input 230V~ 50Hz
Output 700 Watts
Microwave frequency 2450MHz
Outside dimensions 595mm wide x 382mm high x 316mm deep
Power consumption
Microwave 1150 Watts
Grill 1000 Watts
Complies with EEC directives 89/336/EEC and 92/31/EEC.
Dimensions shown are approximate.
Because we continually strive to improve our products, we may change specifications without prior notice.
Specification
This symbol on the product or in the
instructions means that your electrical
equipment should be disposed at the end
of life separately from your household
waste. There are separate collection
systems for recycling in the EU. For more
information, please contact the local
authority or your retailer where you
purchased the product.
HITACHI Europe Ltd.
GB-27
HIT BG17SS
Please read these instructions carefully before installing
Installation Instructions
Please Note
Electrical connection
The oven is fitted with a plug and must be only connected to a properly installed earthed
socket. In accordance with the appropriate regulations, the socket must only be installed and
the connecting cable must only be replaced by a qualified electrician.
It is recommended that the plug be accessible after installation. If this is not possible, an
all-pole isolating switch must be present on the installation side with a contact gap of at least
3mm.
GB - 28
A. Built-in furniture
The built-in cabinet shall not have a rear wall behind the appliance.
Minimum installation height is 850mm.
Do not cover ventilation slots and air intake points.
1.
2.
GB - 29
B. Install the Oven
1. Fix SCREW A on the UPPER AIR TUNNEL of the oven, and then install the
oven into the cabinet.
z Adjust the height of SCREW A to make 1mm gap between SCREW A and
the top of the cabinet.
z Do not trap or kink the power cord.
z Make sure that the oven is installed in the centre of the cabinet.
2. Open the oven door. Insert SCREW C into the INSTALLATION HOLE and attach
the TRIM KIT to the bracket. Then fix the TRIM-KIT PLASTIC COVER to the
INSTALLATION HOLE.
GB - 30
Loading...
