HRBM417S
HRBM417C
2
Contents
Safety and warning information……....2
Installing your new appliance…………7
Description of the appliance……………12
Display controls…………………………13
Using your appliance…………………… 16
Cleaning and care………………………17
Helpful hints and tips……………………19
Troubleshooting………………………….21
Disposal of the appliance………………22
Safety and warning information
For your safety and correct usage, before installing and first using the
appliance, read this user manual carefully, including its hints and warnings. To
avoid unnecessary mistakes and accidents, it is important to make sure that all
people using the appliance are thoroughly familiar with its operation and safety
features. Save these instructions and be sure that they remain with the
appliance if it is moved or sold, so that anyone using it throughout its life, will
●
be properly informed on its usage and safety notices.
For the safety of life and property, keep the precautions of these user's
instructions as the manufacturer is not responsible for damages caused by
omission.
Safety for children and others who are vulnerable people●
●
According to EN standard
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
●
According to IEC standard
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person being responsible for their safety.
Keep all packaging away from children as there is risk of suffocation.
If you are discarding the appliance, pull the plug out of the socket, cut the
connection cable (as close to the appliance as you can) and remove the
door to prevent children playing from suffering an electric shock or from
closing themselves inside it.
If this appliance, featuring a magnetic door seals, is to replace an older
appliance having a spring lock (latch) on the door or lid, be sure to make
the spring lock unusable before you discard the old appliance. This will
prevent it from becoming a death trap for a child.
3
General safety
WARNING —This appliance is intended to be used in household
and similar applications such as
-staff kitchen areas in shops, offices and other working environments;
-farm houses and hotels, motels and other residential type environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
WARNING — Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
WARNING — If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to
avoid a hazard.●
WARNING — Keep ventilation openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
WARNING — Do not use mechanical devices or other means to
accelerate the defrosting process, other than those recommended by the
manufacturer.
WARNING — Do not damage the refrigerant circuit.
WARNING — Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type recommended
by the manufacturer.
WARNING — The refrigerant and insulation blowing gas are flammable.
When disposing of the appliance, do so only at an authorized waste
disposal centre. Do not expose to flame.
WARNING — When positioning the appliance, ensure the supply cord is
not trapped or damaged.
WARNING — Do not locate multiple portable socket-outlets or portable
power supplies at the rear of the appliance.●
Replacing the illuminating lamps
WARNING— The illuminating lamps must not be replaced by the user! If
the illuminating lamps is damaged, contact the customer helpline for
assistance. This warning is only for refrigerators that contain illuminating
lamps.
Refrigerant
The refrigerant isobutene (R600a) is contained within the refrigerant circuit of
the appliance, a natural gas with a high level of environmental compatibility,
which is nevertheless flammable. During transportation and installation of the
appliance, ensure that none of the components of the refrigerant circuit
becomes damaged.
The refrigerant (R600a) is flammable.
4
WARNING — Refrigerators contain refrigerant and gases in the insulation.
Refrigerant and gases must be disposed of professionally as they may cause
eye injuries or ignition. Ensure that tubing of the refrigerant circuit is not
damage prior to proper disposal.
It is hazardous for anyone other than an Authorized Service Person to service
this appliance. In Queensland the Authorized Service Person Must hold a Gas
Work Authorized for hydrocarbon refrigerants to carry out servicing or repairs
which involve removal of covers.
WARNING: Risk of fire / flammable materials
The symbol is a warning and indicates the refrigerant and insulation blowing
gas are flammable.
If the refrigerant circuit should be damaged:
-●Avoid opening flames and sources of ignition.
-Thoroughly ventilate the room in which the appliance is situated.
It is dangerous to alter the specifications or modify this product in any way.
Any damage to the cord may cause a short circuit, fire, and/or electric shock.
Electrical safety
1.The power cord must not be lengthened.
2. Make sure that the power plug is not crushed or damaged. A crushed or
damaged power plug may overheat and cause a fire.
3. Make sure that you can access the main plug of the appliance.
4. Do not pull the main cable.
5. If the power plug socket is loose, do not insert the power plug. There is a risk
of electric shock or fire.
6.You must not operate the appliance without the interior lighting lamp cover.
7.The fridge is only applied with power supply of single phase alternating
current of 220~240V/50Hz. If fluctuation of voltage in the district of user is so
large that the voltage exceeds the above scope, for safety sake, be sure to
apply A.C. automatic voltage regulator of more than 350W to the fridge. The
fridge must employ a special power socket instead of common one with other
electric appliances. Its plug must match the socket with ground wire.
Daily use
Do not store flammable gases or liquids in the appliance, There is a risk of
an explosion.●
Do not operate any electrical appliances in the appliance (e.g. electric ice
cream makers, mixers etc.).
When unplugging always pull the plug from the mains socket, do not pull
on the cable.
Do not place hot items near the plastic components of this appliance.
5
Do not place food products directly against the air outlet on the rear wall.
Store pre-packed frozen food in accordance with the frozen food
manufacture’s instructions.
The appliances manufactures storage recommendations should be strictly
adhered to relevant instructions for storage.
Do not place carbonated or fizzy drinks in the freezer compartment as it
creates pressure on the container, which may cause it to explode, resulting
in damage to the appliance.
Frozen food can cause frost burns if consumed straight from the freezer
compartment.
Do not place the appliance in direct sunlight.
Keep burning candles, lamps and other items with naked flames away
from the appliance so that do not set the appliance on fire.
The appliance is intended for keeping food stuff and/or beverages in
normal household as explained in this● instruction booklet . You should take
care when move it as the appliance is heavy.
Do not remove nor touch items from the freezer compartment if your hands
are damp/wet, as this could cause skin abrasions or frost/freezer burns.
Never use the base, drawers, doors etc. to stand on or as supports.
Frozen food must not be refrozen once it has been thawed out.
Do not consume ice popsicles or ice cubes straight from the freezer as this
can cause freezer burn to the mouth and lips.
To avoid items falling and causing injury or damage to the appliance, do
not overload the door racks or put too much food in the crisper drawers.
Caution!
Care and cleaning
Before maintenance, switch off the appliance and disconnect the mains
plug from the mains socket.
Do not clean the appliance with metal objects, steam cleaner, ethereal oils,
organic solvents or abrasive cleansers.
Do use a plastic scraper instead of a sharp objects to remove frost from
the appliance.
Installation Important!
For electrical connection carefully, follow the instructions given in this
manual. Unpack the appliance and check if there are damages on it.
Do not connect the appliance if it is damaged. Report possible damages
immediately to the place you bought it. In● this case retain packing.
It is advisable to wait at least four hours before connecting the appliance to
allow the oil to flow back in the compressor.
Adequate air circulation should be around the appliance, lacking this leads
to overheating. To achieve sufficient ventilation, follow the instructions
relevant to installation.
6
Wherever possible, the back of the product should not be too close to a
wall to avoid touching or catching warm parts (compressor, condenser) to
prevent the risk of a fire, follow the instructions relevant to installation.
The appliance must not be located close to radiators or cookers.
Make sure that the mains plug is accessible after the installation of the
appliance.
Service
Any electrical work required to do the servicing of the appliance should be
carried out by qualified electrician or competent person.
This product must be serviced by an authorized Service
Center, and ●only genuine spare parts must be used.
1) If the appliance is Frost Free.●
2) If the appliance contains freezer compartment.
Note:
Children aged from 3 to 8 years are allowed to load and unload
refrigerating appliances. (This clause applies only to the EU region.)
7
Installing your new appliance
Before using the appliance for the first
time, you should be informed of the
following tips.
Warning!
For proper installation, this refrigerator
must be placed on a level surface of hard
material that is the same height as the rest
of the flooring. This surface should be
strong enough to support a fully loaded
refrigerator.●
The rollers, which● are not castors, should
be only used for forward or backward
movement. Moving the refrigerator
sideways may damage your floor and the
rollers.
Ventilation of appliance
In order to improve efficiency of
the cooling system and save
energy, it is necessary to maintain good
ventilation around the appliance for the
dissipation of heat. For this reason,
sufficient clear space should be available
around the refrigerator.
Suggest: It is advisable for there to be at
least 50mm of space from the back of
appliance to the wall, at least 100mm from
its top, at least 50mm from its side to the
wall and a clear space in front to allow the
doors to open 130°. As shown in follow
diagrams.
Note:
This appliance performs well within the
climate class from SN to T showed in the
table below. It may not work properly if being
left at a temperature above or below the
indicated range for a long period.
Climate class Ambient temperature
SN +10°C to +32°C
N +16°C to +32°C
ST +16°C to +38°C
T +16°C to +43°C
Stand your appliance in a dry place to
avoid high moisture.
Keep the appliance out of direct sunlight,
rain or frost. Stand the appliance away from
heat sources such as stoves, fires or
heaters.
8
Leveling of appliance
For sufficient leveling and air circulating in
the lower rear section of the appliance, the
bottom feet may need to be adjusted. You
can adjust them manually by hand or by
using a suitable spanner.
To allow the doors to self-close, tilt the top
backwards by 10-15mm.
Reversing the door●
The side at which the door opens can be
changed, from the right side (as supplied) to
the left side if required.
Warning! When reversing the door, the
appliance must not be connected to the
Power, Ensure that the plug is removed from
the power socket.
Wrench(8mm) Philips Screwdriver
Thin-blade
screwdriver
Additional parts (in the plastic bag)
Allen Wrench(4mm)
Upper Hinge-Left
S●crew Hole
Cover-right
Not provided
Monkey wrench
Upper Hinge
Cover-left
Middle Hinge-left
Stop Block-left *2 Door Stopper-left *2
9
Note: If required, you may lay the
refrigerator on its back in order to gain
access to the base, you should rest it on soft
foam packaging or similar material to avoid
damaging the backboard of the refrigerator.
To reverse the door, the following steps
generally recommended.
1. Stand the refrigerator upright. Open the
door to take out all door racks (to avoid
damage) and then close the door.●
Caution!
Please slightly squeeze the door rack from
two sides toward center and inside of door
rack, and then move it upward when taking
out the upper rack and lower rack.
2. Remove upper hinge cover-right ①from
the right-top corner of cabinet. Remove the
temperature sensor from the cabinet and
right upper hinge cover, Install it on the
upper hinge cover-left (provided in the
plastic accessory bag). Unscrew the 3
screws ② which are used for fixing the
upper hinge-right (see the picture below)
and take down the upper hinge-right ③.
3. Remove the upper door from the middle
hinge by carefully lifting the door straight
up. Then place the upper door on a
smooth surface with its panel upwards.
4. Unscrew screw ③ and take down part
② and part ①, Install replacement door
stopper-left ④ and stop block-left ⑤
(provided in the plastic accessory bag) to
the left side with screw ③. Keep part ①
and part ② with the appliance for future
reference.
10
5. Use the Allen wrench (provided in the
plastic accessory bag) to unscrew the
screws used to fix the middle hinge-right
and remove middle hinge●-right. Then
remove the lower door.
7. Install screw hole cover-right ①
(provided in the plastic accessory bag) to
the right-top corner of cabinet. Remove
screw hole cover-left ② from the left-top
corner of cabinet with thin-blade
screwdriver and Put the screw hole
cover-left and upper hinge -right into the
plastic accessory bag for future reference.
6●. Place the lower door on a smooth
surface with its panel upwards. Unscrew
screw ③ and take down part ② and part
① , Install replacement door stopper-left
④ and stop block-left ⑤ (provided in the
plastic accessory bag) to the left side with
screw ③. Keep part ① and part ② with
the appliance for future reference.
8. Change screw hole covers and screw
on middle cover plate from left to right (as
shown in figure below).
9.Lie the refrigerator backwards, Remove
part ④ (right), Remove 3 self-tapping
screws from the lower hinge -right.
Unscrew the lower hinge-right axis then
11
install it on the reverse hole site, and
tighten into position (change it into lower
hinge-left) . Remove the lower hinge-left to
the left-bottom corner of cabinet, Then fix it
with 3 screws, finally install part ④ on the
left-bottom corner and right-bottom corner
of cabinet.
12. Carefully slot the upper door onto the
middle hinge pin and hold in position.
Move the upper door to an appropriate
position, adjust the upper hinge-left
(provided in the plastic accessory bag) and
upper door, then fit the hinge pin into the
hinge hole at the top of the upper door to
secure it in place. Then fix the upper hinge
part with screws (Please carefully hold the
upper door by hand when installing)
11●. Stand the refrigerator upright and
carefully slot the lower door onto the lower
hinge-left pin and hold it in position.
Install middle hinge-left (provided in the
plastic accessory bag) and ensure the
lower door in place.●
13. Install the temperature sensor part on
the upper hinge cover-left (provided in the
plastic accessory bag). Assemble the
upper hinge cover-left to match the hinge.
Install the door racks to original position.
Keep the upper hinge cover-right with the
appliance for future reference.
12
Description of the appliance
Note●！！！！
Due to unceasing modification of our products, your refrigerator may be slightly different
from this instruction manual, but its functions and using methods remain the same.
To get the best energy efficiency of this product, please place all shelves, drawers and
baskets on their original position as the illustration above.
13
Display Controls
Use your appliance according to the following control regulations, your appliance has the
corresponding functions and modes as the display panels showed in the pictures below.
When the appliance is powered on for the first time, the backlighting of the icons on
display panel starts working. If no buttons have been pressed and the doors are closed,
the backlighting will turn off.
Controlling the temperature●
We recommend that when you start your
refrigerator for the first time, the
temperature for the refrigerator is set to
4°C and the freezer to -18°C. If you want
to change the temperature, follow the
instructions below.
POWER
Hold 3 seconds on POWER Control to
turn the power on, and press 3 seconds
to turn the power off.
Setting Compartment Temperatures
Caution! When you set a temperature,
you set an average temperature for the
whole refrigerator cabinet. Temperatures
14
inside each compartment may vary from
the temperature displayed on the panel,
depending on how much food you store
and where you place them. Ambient
temperature may also affect the actual
temperature inside the appliance.
1.● Refrigerator (Fridge) Compartment
Temperature
① Press ZONE repeatedly until the
Fridge icon appears.
② When Fridge is on, is
illuminated and then press TEMP.
repeatedly to cycle through the
available temperature settings,
from 8°C to 2°C.
NOTE: Each press of the button
advances the setting by one
degree.
③ Release the TEMP. Control when
the desired temperature setting
appears.
2. Freezer Compartment Temperature
① Press ZONE repeatedly until the
Freezer Choice appears.
② When Freezer is on,
is
illuminated and then press TEMP.
repeatedly to cycle through the
available temperature settings,
from -14°C to -24°C.
NOTE: Each press of the button
advances● the setting by one
degree.
③ Release the TEMP. Control when
the desired temperature setting
appears.
3. Super Cool
The Super Cool feature helps to keep
food stored in the refrigerator at the set
temperature during periods of high usage,
large grocery loads, or temporarily warm
room temperatures. The Super Cool
feature lowers the temperature in the
fridge compartment to 2°C to cool food
faster.
① Press MODE repeatedly until the
Super Cool icon appears.
NOTE: When Super Cool is on,
is illuminated and 2°C
appears in the temperature
display.
② Press MODE or adjust fridge
compartment temperature
according to the step 1 to turn off
Super Cool manually and the
fridge temperature will return to
the previous temperature setting.
NOTE: Super Cool will
automatically turn off after 3 hours,
and the fridge will return to the
previous temperature setting.
4. Super Freeze
The Super Freeze feature helps to keep
the food stored in the freezer at the set
temperature during periods of high usage,
large grocery loads, or temporarily warm
room temperatures.
The Super Freeze feature lowers the
temperature in the freezer compartment
15
to -24°C to freeze food faster.
① Press MODE repeatedly until the
Super Freeze icon
appears.
NOTE: When Super Freeze is on,
is● illuminated and -24°C appears
in the temperature display.●
② Press MODE or adjust freezer
compartment temperature according
to the step 2 to turn off Super Freeze
manually and the freezer temperature
will return to the previous temperature
setting.
NOTE: Super Freeze will
automatically turn off after 52 hours,
and the freezer will return to the
previous temperature setting.
5. Holiday
If leaving the appliance for a long period
of time, you can switch the appliance
over to the holiday mode.
Important!
Do not store any food in the fridge
compartment during this time.
1. Press MODE until the Holiday icon
appears. The appliance automatically
sets the following temperatures:
• Fridge compartment: 15 °C
• Freezer compartment: -18°C
2. Press MODE or TEMP. to turn off
Holiday mode and the refrigerator
temperature will revert to its previous
temperature setting.
Door Open Alarm
If the fridge door is opened for longer
than 2 minutes, the control panel will
display “dr”, and the buzzer will sound 3
times every minute for 8 minutes.
• To turn off the alarm, close the fridge
door completely.
16
Using your appliance
Your appliance has the accessories as the“Description of the appliance” showed in
general, with this part instruction you can have the right way to use them.. We recommend
that you read through them carefully before using the appliance
Door rack
It is suitable for the storage● of canned
liquid, bottled drinks and packed food, etc.
Do not place too many heavy things in the
racks.
Shelf in Refrigerator chamber
1.There are shelves in refrigerator
chamber, and they can be taken out to be
cleaned.
2.The crisper is suitable for storage of
vegetables and fruit, etc.
Firstly Pull the crisper out in level,
Secondly tip up it then you can take out
the crisper.
According to the opposite sequence you
can position the crisper rightly.
●
Freezer chamber
The freezer chamber is suitable for
storage of foods required to be frozen,
such as meat, ice.
Caution! Never close the freezer door
while the drawers, installation bracket, ice
tray are extended. It may damage the unit.
Ensure that drink bottles are not left in the
freezer for a longer time than needed as
freezing liquid may cause the bottle to
break.
Twistable ice tray
Twistable ice tray produce and store
abundant ice cubes.
1.Pull out the twistable ice tray from the
installation bracket.
2.Fill with drinking water below the
maximum level mark.
3.Place the filled ice tray back to bracket.
4.Await for around 3 hours, twist the knobs
clockwise and the ice will drop into the ice
box below.
17
Cleaning and care
For hygienic reasons the appliance
(including exterior and interior accessories)
should be cleaned regularly (at least every
two months.●
Warning!
The appliance must not be connected to
the mains during cleaning as there is a
danger of electrical shock! Before cleaning
switch the appliance off and remove the
plug from the mains socket.
Exterior cleaning
Wipe the control panel with a clean, soft
cloth.
Spray water onto the cleaning cloth
instead of spraying directly on the surface
of the appliance. This helps ensure an
even distribution of moisture to the
surface.
Clean the doors, handles and cabinet
surfaces with a mild detergent and then
wiped dry with a soft cloth.
Interior cleaning
You should clean the appliance interior
regularly. It will be easier to clean when
food stocks are low. Wipe the inside of the
fridge freezer with a weak solution of
bicarbonate of soda, and then rinse with
warm water using a wrung-out sponge or
cloth. Wipe completely dry before replacing
the shelves and baskets. Thoroughly dry all
surfaces and removable parts before
putting them back into place.
●
Caution!
Don’t use sharp objects as they are likely
to scratch the surface.
Don’t use thinner, car detergent, clorox,
ethereal oil, abrasive cleansers or organic
solvent such as Benzene for cleaning.
They may damage the surface of the
appliance and may cause fire.
Although this appliance automatically
defrosts, a layer of frost may occur on the
freezer compartment’s interior walls if the
freezer door is opened frequently or kept
open too long. If the frost is too thick,
choose a time when the freezer is nearly
empty and proceed as follow:
1. Remove existing food and accessories
baskets, unplug the appliance from the
mains power and leave the doors open.
Ventilate the room thoroughly to accelerate
the process.
2. When defrosting is completed, clean
18
your freezer as described above.
Caution!
Do not use sharp objects to remove frost
from the freezer compartment.● Only after
the interior is completely dry should the
appliance be switched back on and
plugged back into the mains socket.
Door seals cleaning
Take care to keep door seals clean. Sticky
food and drinks can cause seals to stick to
the cabinet and tear when you open the
door. Wash seal with a mild detergent and
warm water. Rinse and dry it thoroughly
after cleaning.
Caution! Only after the door seals are
completely dry should the appliance be
powered on
Replacing the LED light:
Warning:
The LED light should be replaced by a
professional. If the LED light is damaged,
contact the customer helpline for
assistance. To replace the LED light, the
below steps can be followed:
1. Unplug your appliance.
2. Push the 3 buttons are located the back
of control display part with a Thin-blade
screwdriver , and then pull it downward.
3. Hold the control display part with one
hand and pull it with the● other hand while
pressing the connector latch.
4. Replace LED light and snap it correctly in
place.
19
Helpful hints and tips
Energy saving tips
We recommend that you follow the tips
●
below to save energy.
Try to avoid keeping the door open for
long periods in order to conserve energy.
Ensure the appliance is away from any
sources of heat (Direct sunlight, electric
oven or cooker etc.)
Don‘t set the temperature colder than
necessary.
Don’t store warm food or evaporating
liquid in the appliance.
Place the appliance in a well ventilated,
humidity free, room. Please refer to
Installing your new appliance chapter.
If the diagram shows the correct
combination for the drawers, crisper and
shelves, do not adjust the combination as
this is designed to be the most energy
efficient configuration.
Hints for fresh food refrigeration
Do not place hot food directly into the
refrigerator or freezer, the internal
temperature will increase resulting in the
compressor having to work harder and will
consume more energy.
Do cover or wrap the food，particularly if it
has a strong flavor.
Place food properly so that air can
circulate freely around it.
Hints for refrigeration
Meat (All Types) Wrap in polythene food:
wrap and place on the glass shelf above
the vegetable drawer. Always follow food
storage times and use by dates suggested
by manufacturers.
Cooked food, cold dishes, etc.: ●
They should be covered and may be
placed on any shelf.
Fruit and vegetables:
They should be stored in the special
drawer provided.
Butter and cheese:
Should be wrapped in airtight foil or plastic
film wrap.
Milk bottles:
Should have a lid and be stored in the
door racks.
Hints for freezing
When first starting-up or after a period
out of use, let the appliance run at least 2
hours on the higher settings before putting
food in the compartment.
Prepare food in small portions to enable
it to be rapidly and completely frozen and
to make it possible to subsequently thaw
only the quantity required.
Wrap up the food in aluminum foil or
polyethylene food wraps which are airtight,
Do not allow fresh ， unfrozen food to
touch the food which is already frozen to
avoid temperature rise of the latter.
Iced products，if consumed immediately
after removal from the freezer
compartment, will probably cause frost
burns to the skin.
It is recommended to label and date each
frozen package in order to keep track of
the storage time.
Hints for the storage of frozen food
Ensure that frozen food has been stored
correctly by the food retailer
Once defrosted ， food will deteriorate
rapidly and should not be re-frozen. Do not
exceed the storage period indicated by the
food manufacturer.
Switching off your appliance
If the appliance needs to be switched off
for an extended period, the following steps
20
should be taken prevent it to go mouldy.
1. Remove all food.
2. Remove the power plug from the mains
socket.●
3. Clean and dry the interior thoroughly.
4. Ensure that all the doors are wedged
open slightly to allow air to circulate.
21
Troubleshooting●
If you experience a problem with your appliance or are concerned that the appliance is not
functioning correctly, you can carry out some easy checks before calling for service,
please see below.
Warning! Don’t try to repair the appliance yourself. If the problem persists after you have
made the checks mentioned below, contact a qualified electrician, authorized service
engineer or the shop where you purchased the product.
Problem Possible cause & Solution
Appliance is not working
correctly
●
Check whether the power cord is plugged into the power outlet
properly.
Check whether the “Power” function is on by pressing the
“power” button for 1 second.
Check the fuse or circuit of your power supply, replace if
necessary.
It is normal that the freezer is not operating during the defrost
cycle, or for a short time after the appliance is switched on to
protect the compressor.
Odours from the
compartments
Noise from the appliance
The motor runs
continuously
The interior may need to be cleaned
Some food, containers or wrapping cause odours.
The sounds below are quite normal:
Compressor running noises.
Air movement noise from the small fan motor in the freezer
compartment or other compartments.
Gurgling sound similar to water boiling.
Popping noise during automatic defrosting.
Clicking noise before the compressor starts.
Other unusual noises are due to the reasons below and may
need you to check and take action:
The cabinet is not level.
The back of appliance touches the wall.
Bottles or containers fallen or rolling.
It is normal to frequently hear the sound of the motor, it will
need to run more when in following circumstances:
Temperature setting is set colder than necessary
Large quantity of warm food has recently been stored within
the appliance.
The temperature outside the appliance is too high.
Doors are kept open too long or too often.
After your installing the appliance or it has been switched off
for a long time.
22
A layer of frost● occurs in
the compartment
Check that the air outlets are not blocked by food and ensure
food is placed within the appliance to allow sufficient ventilation.
Ensure that door is fully closed. To remove the frost, please
refer to the“Cleaning and care” chapter.
Temperature inside is
too warm
Temperature inside is
too cold
Doors can’t be closed
easily
You may have left the doors open too long or too frequently; or
the doors are kept open by some obstacle; or the appliance is
located with insufficient clearance at the sides, back and top
Increase the temperature by following the “Display controls”
chapter.
Check whether the top of the refrigerator is tilted back by
10-15mm to allow the doors to self close, or if something inside
is preventing the doors from closing.
Disposal of the appliance●
It is prohibited to dispose of this appliance as household waste.
Packaging materials
Packaging materials with the recycle symbol are recyclable. Dispose of the packaging into
a suitable waste collection container to recycle it.
Before disposal of the appliance
1. Pull out the mains plug from the mains socket.
2. Cut off the power cord and discard with the mains plug
Warning! Refrigerators contain refrigerant and gases in the insulation. Refrigerant and
gases must be disposed of professionally as they may cause eye injuries or ignition.
Ensure that tubing of the refrigerant circuit is not damage prior to proper disposal.
This symbol on the product or in its packing indicates that this product may
not be treated as household waste. Instead, it should be taken to the
appropriate waste collection point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human
health, which could otherwise be caused by the inappropriate waste handling
of this product. For more detailed information about the recycling of this
product, please contact your local council your household waste disposal
service, or the shop where you purchased the product.
Correct Disposal of this product
23
To avoid contamination of food, please respect the following instructions
- Opening the door for long periods can cause a significant in crease of the temperature in
the compartments of the appliance.●
- Clean regularly surfaces that can come in contact with food and accessible drainage
systems.
- Store raw meat and fish in suitable containers in the refrigerator, so that it is not in
contact with or drip onto other food.
- Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or
making icecream and making ice cubes.
- One-, two- and three- star compartments are not suitable for the freezing of fresh food.
Order
Compartments
TYPE
Target storage
temp.[ °C]
Appropriate food
Eggs, cooked food, packaged food, fruits
1 Fridge +2~+8
and vegetables, dairy products, cakes,
Drinks and other foods which are not
suitable for freezing.
Seafood(fish, shrimp, shellfish), freshwater
aquatic products and meat
2 (***)*-Freezer
≤-18
products(recommended time is 3 months –
nutrition values and taste decrease with
time), suitable for frozen fresh food.
Seafood(fish, shrimp, shellfish), freshwater
aquatic products and meat
3 ***●-Freezer
≤-18
products(recommended time is 3 months –
nutrition values and taste decrease with
time). Not suitable for freezing fresh food.
Seafood(fish, shrimp, shellfish), freshwater
aquatic products and meat
4 **-Freezer
≤-12
products(recommended time is 2 months –
nutrition values and taste decrease with
time). Not suitable for freezing fresh food.
Seafood(fish, shrimp, shellfish), freshwater
aquatic products and meat
5 *-Freezer
≤-6
products(recommended time is 1 month –
nutrition values and taste decrease with
time). Not suitable for freezing fresh food.
Fresh pork, beef, fish, chicken, some
6 0-star -6~0
packaged processed foods,
etc.(Recommended to eat within the same
day, preferably not later than 3 days).
Fresh/frozen pork, beef, fish, chicken,
7 Chill -2~+3
freshwater aquatic prodects, etc.(7 days
below 0°C and above 0°C is recommended
24
for consumption within that day, preferably
no more than 2 days●). Seafood(less than 0
for 15 days, it is not recommended to store
above 0°C).
Fresh pork, beef, fish, chicken, cooked food,
8 Fresh Food 0~+4
etc.(Recommended to eat within the same
day, preferably no more than 3 days).
9 Wine +5~+20 red wine, white wine, sparkling wine etc.
Note: please store different foods according to the compartments or target storage
temperature of your purchased products.
- If the refrigerating appliance is left empty for long preiods, switch off, defrost, clean, dry,
and leave the door open to prevent mould developing within the appliance.
Water dispenser cleaning (special for water dispenser products):
- Clean water tanks if they have not been used for 48h; flush the water system connected
to a water supply if water has not been drawn for 5 days.
WARNING! Food needs to be packed in bags before putting into the refrigerator, and
liquids need to be packed in bottles or capped containers to avoid the problem that the
product design structure is not easy to clean.
Loading...
