DS-KD3002-VM
Video Intercom Metal Door Station
Key Features
Basic Functions
Video intercom function
Access control function
Issues cards via door station, up to Max. 2500 cards, via outer door station, up to 50000 cards
(This function will be invalid if the card has been issued via the client.)
Card readers supported
Self-adaptive visible light supplement
Video/Audio Functions
HD video surveillance with high performance CMOS
Noise suppression and echo cancellation
H.264 video compression
Low illumination
Remote Control
Remote unlocking via the client or the app
Remotely answering the call via the client or the app
Alarm Functions
Tampering alarm and door magnetic alarm supported
Auto-uploads alarm messages to master station or the client once the duress code is entered to
open the door
Additional Features
Message notification function
Auto-uploads captured pictures to FTP or the client while unlocking the door
Model
DS-KD3002-VM
System
parameters
Processor
High-Performance Embedded SOC Processor
Operation system
Embedded Linux Operation System
Video
parameters
Camera
CMOS Low Illumination 1.3 MP HD Colorful Camera
Video compression
standard
H.264
Resolution
1280 × 720
Video frame rate
PAL: 25 fps, NTSC: 30 fps
Display
parameters
Display screen
3.5-Inch Colorful TFT LCD
Display resolution
480 × 320
Operation method
Physical Touch Keypad
Operation interface
LCD Display, Easy Menu
Audio
parameters
Audio input
Built-in Omnidirectional Microphone
Audio output
Built-in Loudspeaker
Audio compression
standard
G.711 U
Audio compression
rate
64 Kbps
Audio quality
Noise Suppression and Echo Cancellation
Access
control
parameters
Internal card reader
Built-in IC Card Reader
External card reader
Wiegand 26, Wiegand 34, or RS-485 IC Reader
Door magnetic
detection
Detects Door Magnetic Status
Light
supplement
Light supplement
mode
Visible Light Supplement
Network
parameters
Ethernet
10/100/1000 Mbps Self-Adaptive Ethernet
Network protocol
TCP/IP, RTSP
Alarm
parameters
Alarm input
Door Magnetic Alarm, Tampering Alarm
Device
interfaces
Network interface
1 RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface
RS-485
1 RS-485 Half-Duplex Port
I/O input
4
I/O output
4
Wiegand
1 Wiegand Port for Accessing Wiegand IC Card Reader
USB
1 USB 2.0, Supporting U-Disk
General
Material
Aluminum Alloy
Power supply
12 VDC
Power consumption
≤15 W
Working temperature
-40° C to +60° C (-40° F to 140° F)
Working humidity
10% to 90%
IP protection level
IP65
Dimensions
(L × W × H)
357 mm × 124 mm × 55 mm (14.1" × 4.9" × 2.2")
Certification
FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
Specifications
DS-KD3002-VM
Typical Application
Available Model
PC Client
Center Master
Station
Network
Camera
Master Station
(Guarding Room)
Outer Door Station
Card Reader
Card Reader
Indoor
Extension1
Indoor
Extension2
Elevator Controller
LAN
1F
2F
22F
Resident 1Resident 2
Resident 1Resident 2
Resident 1Resident 2
A Building
Door Station
Index
Description
Index
Description
1
Low Illumination Supplement Light
6
Numeric Keypad
2
Loudspeaker
7
Call Key
3
Built-in Camera
8
Call Center Key
4
LCD Display Screen
9
Microphone
5
Card Induction Area
10
TAMPER
Appearance and Interfaces
20170817
