Hikvision DS-KB8112-IM Quick Start Guide

Video Intercom Vandal-Resistant
Door Station
Quick Start Guide
UD03855B-B
Series
Model
Vandal-Resistant Door Station
DS-KB8112-IM
Quick Start Guide
© 2017 Hangzhou Hikvision Digital Technology Co., Ltd.
This quick start guide is intended for users of the models below:
It includes instructions on how to use the Product. The software
embodied in the Product is governed by the user license agreement covering that Product.
About this Manual
This Manual is subject to domestic and international copyright
protection. Hangzhou Hikvision Digital Technology Co., Ltd.
(“Hikvision”) reserves all rights to this manual. This manual cannot be
reproduced, changed, translated, or distributed, partially or wholly,
by any means, without the prior written permission of Hikvision.
Trademarks
Hikvision and are registered trademarks or the subject of applications for the same by Hikvision and/or its affiliates. Other trademarks
mentioned in this manual are the properties of their respective owners. No right of license is given to use such trademarks without
express permission.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,
HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF
and other Hikvision marks are the property of
ii
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, REGARDING THIS MANUAL. HIKVISION DOES NOT WARRANT,
GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE USE OF THE MANUAL, OR THE CORRECTNESS, ACCURACY, OR RELIABILITY OF INFORMATION CONTAINED HEREIN. YOUR USE OF THIS MANUAL
AND ANY RELIANCE ON THIS MANUAL SHALL BE WHOLLY AT YOUR OWN RISK AND RESPONSIBILITY.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO
EVENT WILL HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR
AGENTS BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION,
SECURITY BREACHES, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF OR RELIANCE ON THIS MANUAL, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.
SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY OR CERTAIN DAMAGES, SO SOME OR ALL OF THE ABOVE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO YOU.
Support
Should you have any questions, please do not hesitate to contact
your local dealer.
iii
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
iv
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
standards listed under the EMC Directive 2014/30/EU, the RoHS
Directive 2011/65/EU.
upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see:
www.recyclethis.info
information. The battery is marked with this symbol, which may
include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg).
For proper recycling, return the battery to your supplier or to a designated collection point. For more information see:
www.recyclethis.info
Industry Canada ICES-003 Compliance
therefore with the applicable harmonized European
2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper
recycling, return this product to your local supplier
2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the
product documentation for specific battery
v
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
vi
Warnings Follow these
safeguards to prevent serious injury or death.
Cautions Follow these precautions to prevent potential injury or material
damage.
Safety Instruction
These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss.
The precaution measure is divided into Warnings and Cautions:
Warnings: Neglecting any of the warnings may cause serious injury or
death.
Cautions: Neglecting any of the cautions may cause injury or
equipment damage.
Warnings
All the electronic operation should be strictly compliance with the
electrical safety regulations, fire prevention regulations and other
related regulations in your local region.
Please use the power adapter, which is provided by normal
company. The power consumption cannot be less than the required value.
Do not connect several devices to one power adapter as adapter
overload may cause over-heat or fire hazard.
vii
Please make sure that the power has been disconnected before
you wire, install or dismantle the device.
When the product is installed on wall or ceiling, the device shall be
firmly fixed.
If smoke, odors or noise rise from the device, turn off the power at
once and unplug the power cable, and then please contact the service center.
If the product does not work properly, please contact your dealer
or the nearest service center. Never attempt to disassemble the device yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.)
Cautions
Do not drop the device or subject it to physical shock, and do not
expose it to high electromagnetism radiation. Avoid the equipment installation on vibrations surface or places subject to
shock (ignorance can cause equipment damage).
Do not place the device in extremely hot (refer to the specification
of the device for the detailed operating temperature), cold, dusty or damp locations, and do not expose it to high electromagnetic
radiation.
The device cover for indoor use shall be kept from rain and
moisture.
Exposing the equipment to direct sun light, low ventilation or heat
source such as heater or radiator is forbidden (ignorance can cause
fire danger).
viii
Do not aim the device at the sun or extra bright places. A blooming
or smear may occur otherwise (which is not a malfunction
however), and affecting the endurance of sensor at the same time.
Please use the provided glove when open up the device cover,
avoid direct contact with the device cover, because the acidic sweat of the fingers may erode the surface coating of the device
cover.
Please use a soft and dry cloth when clean inside and outside
surfaces of the device cover, do not use alkaline detergents.
Please keep all wrappers after unpack them for future use. In case
of any failure occurred, you need to return the device to the
factory with the original wrapper. Transportation without the original wrapper may result in damage on the device and lead to additional costs.
Improper use or replacement of the battery may result in hazard of
explosion. Replace with the same or equivalent type only. Dispose of used batteries according to the instructions provided by the battery manufacturer.
ix
Table of Contents
1 Introduction .................................................................................... 1
1.1 Overview.................................................................................. 1
1.2 Features ................................................................................... 1
2 Appearance ..................................................................................... 3
3 Terminals and Wiring ...................................................................... 4
3.1 Terminals and Interfaces .......................................................... 4
3.2 Wiring Description ................................................................... 5
3.2.1 Door Lock Wiring .............................................................. 5
3.2.2 Door Magnetic Wiring ...................................................... 6
3.2.3 Exit Button Wiring ............................................................ 6
3.2.4 Alarm Device Input Wiring ................................................ 7
4 Installation ...................................................................................... 8
4.1.1 Wall Mounting Plate ......................................................... 8
4.1.2 Wall Mounting .................................................................. 9
5 Remote Operation ........................................................................ 12
5.1 Activating Device ................................................................... 12
5.1.1 Activation via Web Browser ............................................ 12
5.1.2 Activation via Batch Configuration Tool .......................... 13
5.2 Editing Network Parameters .................................................. 15
5.3 Adding Device ........................................................................ 16
5.3.1 Adding Online Device ..................................................... 16
5.3.2 Adding Device by IP Address ........................................... 18
5.4 Accessing via Web Browser .................................................... 19
6 Local Operation............................................................................. 21
7 Appendix....................................................................................... 23
Installation Notice ........................................................................ 23
Wiring Cables ............................................................................... 23
x
1 Introduction
1.1 Overview
The DS-KB8112-IM is a vandal- resistant door station, which has passed IK 9 (Impact Protection Level). The door station, featuring in
the vandal- resistant design, convenient installation, and easy
operation, supports the video intercom function, access control function, door magnetic alarm, motion detection, and so on. As an
intelligent device, the vandal-proof door station is mainly applied in the villa for improving the living security.
1.2 Features
Basic Functions
Video intercom function, supporting the communication with the
master station, and the indoor station
Access control function, supporting multiple door opening modes
(the indoor station, the master station, the client software, and the web)
Self-adaptive IR supplement with max. 5-meter IR distance High-performance embedded SOC processor IK 9 and IP 66
Video/Audio Functions
HD video surveillance with WDR wide angle and high performance
CMOS, up to 720P @ 30 fps
1
