Hikvision DS-7308HQHI-SH-12TB, DS-7308HQHI-SH-16TB, DS-7308HQHI-SH-1TB, DS-7308HQHI-SH-2TB, DS-7308HQHI-SH-3TB Specsheet

DS-7300HQHI-SH SERIES TURBO HD DVR

Video Input and Transmission

 Connectable to HDTVI and analog cameras

 Up to 6/10/18-ch 1080p IP cameras input for DS-7304/7308/7316HQHI-SH

 Long distance transmission over UTP and coaxial cable

Compression and Recording

 Full channel recording at up to 1080p resolution

Video Output

 Simultaneous HDMI/VGA output at up to 1920×1080 resolution

 Independent CVBS output improves compatibility at the most possibility

Storage and Playback

 Four SATA interfaces (up to 6 TB capacity per HDD) and 1 eSATA interface

 4/8/16-ch synchronous playback at up to 1080p resolution

 Smart search for efficient playback

Smart Function

 Supports multiple VCA (Video Content Analytics) events for both analog and smart IP cameras

 VQD (Video Quality Diagnostics)

Network & Ethernet Access

 Hik Cloud P2P & HiDDNS (Dynamic Domain Name System) for easy network management

 One gigabit Ethernet network interface

Features and Functions

Model

DS-7304HQHI-SH

DS-7308HQHI-SH

DS-7316HQHI-SH

Video/Audio

input

Video compression

H.264

Analog and HDTVI

video input

4-ch

8-ch

16-ch

BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

Supported camera

types

720p25, 720p30, 720p50, 720p60, 1080p25, 1080p30, CVBS

IP video input

2-ch (up to 6-ch)

2-ch (up to 10-ch)

2-ch (up to 18-ch)

Up to 1080p resolution

Audio compression

G.711u

Audio input

4-ch, RCA (2.0 Vp-p, 1 KΩ)

Video/Audio

output

CVBS output

1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480

HDMI/VGA output

1920 × 1080/60Hz ,1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

Encoding resolution

1080p/720p/VGA/WD1/4CIF/CIF

Frame rate

Main stream:

1080p/720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

Sub-stream:

WD1/4CIF@12fps;

CIF/QCIF/QVGA@25fps (P)/30fps (N)

Video bit rate

32 Kbps to 10 Mbps

Audio output

2-ch, RCA (Linear, 1 KΩ, for VGA and CVBS output respectively)

Audio bit rate

64 Kbps

Dual stream

Support

Stream type

Video, Video & Audio

Synchronous playback

4-ch

8-ch

16-ch

Network
management

Remote connection

128

Network protocols

TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, SNMP,

NFS, iSCSI, UPnP™, HTTPS

Hard disk

SATA

4 SATA interfaces

eSATA

Support

Capacity

Up to 6 TB capacity for each disk

External
interface

Two-way audio input

1-ch, RCA (2.0 Vp-p, 1 KΩ)

Network interface

1, 10M/100M/1000M self-adaptive Ethernet interface

Serial interface

RS-232, RS-485, Keyboard

USB interface

3 × USB 2.0

Alarm in/out

16/4

General

Power supply

100 to 240 VAC

Consumption

(without HDD)

≤ 30 W

≤ 40 W

≤ 55 W

Working temperature

-10 ºC to +55 ºC (14 ºF to 131 ºF)

Working humidity

10% to 90%

Dimensions

(W × D × H)

445 × 390 × 70 mm (17.5 × 15.3 × 2.7 inch)

Weight
(without HDD)

≤ 5 kg (11.0 lb)

Specifications
