DS-2TD2617B-3/PA
Temperature Screening Thermographic Bullet Camera
Hikvision DS-2TD2617B Temperature Screening Thermographic Bullet camera is designed to detect elevated skin-surface
temperature with high accuracy in real time. It can be used for preliminary temperature screening in office buildings,
factories, stations, airports and other public places.
Key Feature
● 160 × 120 resolution in thermal channel, high sensitivity sensor.
● Temperature range: 30°C to 45°C; temperature accuracy: ±0.5 °C
● Reliable temperature exception alarm function
● 3D DNR, image detail enhancement
● Audio alarm
Specification
Thermal Module
Image Sensor
Vanadium Oxide Uncooled Focal Plane Arrays
Max. Resolution
160 × 120 (the resolution of output image is 320 × 240)
Pixel Interval
17μm
Response Waveband
8 μm to 14 μm
NETD (Noise Equivalent
Temperature Difference)
≤ 40 mk (@25 °C,F# = 1.1)
Lens (Focal Length)
3.1 mm
IFOV
5.48 mrad
Field of View
50° × 37.2° (H × V)
Min. Focusing Distance
0.2 m
Aperture
F 1.1
Optical Module
Max. Image Resolution
2688 × 1520
Image Sensor
1/2.7" Progressive Scan CMOS
Min. Illumination
Color: 0.0089 Lux @(F1.6, AGC ON), B/W: 0.0018 Lux @(F1.6, AGC ON)
Shutter Speed
1 s to 1/100,000 s
Lens (Focal Length)
4 mm
Field of View
84° × 44.8° (H × V)
WDR
120 dB
Day & Night
IR cut filter with auto switch
Image Function
Bi-spectrum Image Fusion
Fusion view of thermal view and overlaid details of the optical channel
Picture in Picture
Combines details of thermal and optical image PIP, overlay thermal image on optical
Smart Function
Temperature Measurement
3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1
line).
Temperature Range
30°C to +45 °C
Temperature Accuracy
± 0.5 °C
Infrared
IR Distance
Up to 40 m
IR Intensity and Angle
Automatically adjusted
Network
Main Stream
Visible Light: 50Hz: 25fps (2688 × 1520), 25fps (1920 × 1080), 25fps (1280 × 720)
Visible Light: 60Hz: 30fps (2688 × 1520), 30fps (1920 × 1080), 30fps (1280 × 720)
Thermal: 1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240
