Overview
Hikvision DS-2PT3306IZ-DE3(2mm) PanoVu Mini Series IR
Network PTZ Camera can be widely used in multiple
indoor scenes such as the store, classroom, office hall,
hotel lobby, and airport lobby, etc.
Functions
Three 1/2.8" progressive scan CMOS
Up to 3-ch 1920 × 1080@30fps resolution
Min. illumination:
Color: 0.05 Lux @(F2.0, AGC ON)
B/W: 0.01 Lux @(F2.0, AGC ON)
0 Lux with IR
Horizontal FOV: 128.5° × 3
Vertical FOV: 75.7°
Up to 10 m IR radius
DS-2PT3306IZ-DE3(2mm)
PanoVu Mini Series IR Network PTZ Camera
Specification
Camera
Image Sensor
Three 1/2.8" progressive scan CMOS
Min. Illumination
Color: 0.05 Lux @(F2.0, AGC ON)
B/W: 0.01 Lux @(F2.0, AGC ON)
0 Lux with IR
White Balance
Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent
Lamp/Sodium Lamp
Shutter Time
1/1 s to 1/30,000 s
Day & Night
IR Cut Filter
Focal Length
2 mm
Aperture Range
F2.0
FOV
Horizontal field of view: 128.5° × 3
Vertical field of view: 75.7°
Resolution
(Sub-stream enabled)
Main stream:
50 Hz: 20 fps (1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz: 20 fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-stream:
50 Hz: 20 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 20 fps (704 × 480, 640 × 480, 352 × 240)
Resolution
(Sub-stream not enabled)
Main stream:
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Video Compression
(Sub-stream enabled)
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG (MJPEG is only supported by channel 1)
H.264 with Main Profile/High Profile, H.265 with Main Profile
Video Compression
(Sub-stream not enabled)
Main stream: H.265/H.264/MJPEG(MJPEG is only supported by channel 1)
H.264 with Main Profile/High Profile, H.265 with Main Profile
Audio Compression
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2
IR Radius
10 m
Smart Coding
ROI, SVC
Smart Record
ANR (Automatic Network Replenishment)
Basic Event Detection
Motion Detection, Video Tampering Detection, Exception
Smart Event Detection
Audio Exception Detection, Intrusion Detection, Line Crossing Detection
(Smart event detection is only supported by channel 1)
Privacy Mask
4 × 3 programmable privacy masks
Smart Image Enhancement
Digital WDR/HLC/BLC/3D DNR/Defog/Regional Exposure
Network
Network Storage
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB
Protocols
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP,
RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour
API
Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party
Management Platform
User/Host
Up to 32 users
3 levels: Administrator, Operator and User
Security Measures
User authentication (ID and PW), Host authentication (MAC address); HTTPS
encryption; IEEE 802.1x port-based network access control; IP address filtering
Client
iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
Web Browser
IE8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51
Interface
Network Interface
1 RJ45 10 M/100 M Ethernet
Audio Interface
1-ch audio input and 1-ch audio output
