DS-2CV2046G0-IDW
4 MP EXIR Fixed Bullet Wi-Fi Network Camera
Key Features
1/2.7" Progressive Scan CMOS
Human and Vehicle Classification
Strobe Light and Audible Warning
Built-in dual antenna 2.4G Wi-Fi, up to 120m
range in open area
Built-in microphone and speaker, support
two-way audio
H.265, H.264
EXIR, 30m IR range
IP66
Built-in micro SD/SDHC/SDXC card slot, up to 256
GB
Mobile monitoring via Hik-Connect
Specifications
Camera
Image Sensor
1/2.7" Progressive Scan CMOS
Min. Illumination
Color: 0.009 Lux @ (F1.6, AGC ON), 0 Lux with IR
Shutter Speed
1/3 s to 1/100,000 s
Slow Shutter
Yes
Wide Dynamic Range
120dB
Day & Night
ICR Cut
Angle Adjustment
Pan: 0° to 360°, tilt: 0° to90°, rotate: 0° to 360°
Lens
Lens Type & FOV
2.8 mm, horizontal FOV: 97°, vertical FOV: 52°, diagonal FOV: 114°;
4 mm, horizontal FOV: 79°, vertical FOV: 42°, diagonal FOV: 93°
Aperture
F1.6
Lens Mount
M12
Fixed Aperture
Yes
Illuminator
IR Range
up to 30 m
Wavelength
850 nm
Smart Supplement Light
Yes
Visual Alarm
Yes
Video
Max. Resolution
2560 × 1440
Main Stream
50Hz: 25fps (2560 × 1440, 1920 × 1080, 1280 × 720);
60Hz: 30fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Sub Stream
50Hz: 25fps (640 × 360);
60Hz: 30fps (640 × 360)
Video Compression
Main stream/Sub-stream: H.265/H.264
Video Bit Rate
32 Kbps to 8Mbps
H.264 Type
BaseLine Profile/Main Profile/High Profile
H.265 Type
Main Profile
Stream Type
Main stream and sub-stream
Region of Interest (ROI)
1 fixed region for main stream
Audio
Environment Noise Filtering
Yes
Audio Sampling Rate
8 kHz/16 kHz
Audio Compression
G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2)
Network
Simultaneous Live View
Up to 6 channels
API
SDK
Protocols
TCP/IP, ICMP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP,R TCP, NTP, UPnP, SMTP, IGMP,
QoS, IPv6, UDP, Bonjour, SSL/TLS
User/Host
Up to 32 users
3 levels: Administrator, Operator and User
Security
Password protection, complicated password, HTTPS encryption, 802.1X
authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic
and digest authentication for HTTP/HTTPS, WSSE and digest authentication for
ONVIF, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS
1.2
Network Storage
NAS(NFS,SMB/CIFS)
Client
iVMS-4200, Hik-Connect
Web Browser
Plug-in required live view: IE8+, Chrome41.0-44, Firefox30.0-51, Safari8.0-11;
Plug-in free live view: Chrome 45.0+, Firefox 52.0+
Day/Night Switch
Day/Night/Auto/Schedule
Image Enhancement
BLC, HLC, 3D DNR
Image Settings
Saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable
by client software or web browser
Interface
Audio
1 built-in microphone, 1 built-in speaker
On-board Storage
Built-in micro SD/SDHC/SDXC slot, up to 256 GB
Hardware Reset
Yes
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
Smart Feature-Set
Smart Event
Intrusion detection, line crossing detection, region entrance detection, region
exiting detection
Intelligent (Traditional Algorithm)
Basic Event
Motion detection, flashing alarm light output, audible alarm output, exception
(network disconnected, IP address conflict, illegal login, HDD full, HDD error)
General
Linkage Method
Upload to NAS/memory card, notify surveillance center, trigger record, trigger
capture, flashing alarm light output, audiable warning
Online Upgrade
Yes
Firmware Version
5.5.110
Web Client Language
32 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German,
Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian,
Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean,
Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese
(Brazil)
General Function
One-key reset, anti-flicker, heartbeat, mirror, password protection, watermark, IP
address filter, flash log, pixel counter
Software Reset
Yes
Storage Conditions
-30 °C to 60 °C (-22 °F to 140 °F)
Startup and Operating
Conditions
-30 °C to 60 °C (-22 °F to 140 °F)
Power Supply
12 VDC±25%, reverse polarity protection
Power Consumption and
Current
12 VDC, 0.67 A, max.8.0 W
Power Interface
Φ5.5 mm coaxial power plug
Material
Front cover: metal, back cover: plastic
Camera Dimension
175.6× 73.0 × 89.1mm (6.91" × 2.87" × 3.51")
Package Dimension
260 × 125 × 125 mm (10.24" × 4.92" × 4.92")
Camera Weight
450 g (0.99 lb.)
With Package Weight
770 g (1.70 lb.)
Approval
EMC
FCC ID (FCC Part 15.247(BT or 2.4G));
IC ID (RSS-247(BT or 2.4G));
CE-RED (EN 301489-1 V2.1.1(BT or 2.4G); EN 301489-17 V3.1.1(BT or 2.4G); EN
300328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G));
WPC (EN 301 489-1 V2.1.1(BT or 2.4G); EN 301 489-17 V3.1.1(BT or 2.4G); EN 300
328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G); EN 55032:2015; EN
61000-3-2:2014; EN 61000-3-3:2013; EN 50130-4:2011 +A1:2014);
KC (KN 32:2015; KN 35: 2015; KN 301489-1; KN 301489-17);
ICASA (EN 301 489-1 V2.1.1(BT or 2.4G); EN 301 489-17 V3.1.1(BT or 2.4G); EN 300
328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G); EN 55032:2015; EN
61000-3-2:2014; EN 61000-3-3:2013; EN 50130-4:2011 +A1:2014; EN
60950-1:2005 + Am 1:2009 + Am 2:2013)
EMC
FCC ID (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4:
2011 +A1: 2014);
RCM (AS/NZS CISPR 32: 2015);
IC (ICES-003: Issue 6, 2016);
KC (KN 32: 2015, KN 35: 2015)
Safety
UL (UL 60950-1);
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013);
CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013);
BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);
LOA (IEC/EN 60950-1)
Environment
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No
1907/2006)
Reach Regulation (EC) No 1907/2006
Protection
IP66 (IEC 60529-2013)
Wi-Fi
Encryption Mode
64/128-bit WEP, WPA-EAP/WPA2-EAP, WPA-PSK/WPA4-PSK
Wi-Fi Protocol
IEEE802.11b, 802.11g, 802.11n
Frequency Range
2.4 GHz - 2.4835 GHz
Channel Bandwidth
20/40MHz
Modulation
802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM
Wireless Range
120 m (The performance varies based on actual environment)
Available Model
DS-2CV2046G0-IDW (2.8/4 mm)
DS-1280ZJ-XS
Junction Box
Dimension
050511020191101
Accessory
