Model
DS-2CE71D8T-PIRL
TURBO HD
D8T PIR Series Turret
Camera
User Manual
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
This manual may contain technical incorrect places or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or
update the products or procedures described in the
manual.
0100001080320
Regulatory Information
FCC Information
Please take attention that changes or modification not
expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
FCC compliance: This equipment has been tested and
found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection
against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in
which case the user will be required to correct the
interference at his own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation.
EU Conformity Statement
This product and - if applicable - the
supplied accessories too are marked with
"CE" and comply therefore with the
standards listed under the Low Voltage Directive
2014/35/EU, the EMC Directive 2014/30/EU, the RoHS
Directive 2011/65/EU.
equipment, or dispose of it at designated collection
points. For more information see: www.recyclethis.info.
2006/66/EC (battery directive): This product contains
include lettering to indicate cadmium (Cd), lead (Pb),
or mercury (Hg). For proper recycling, return the
battery to your supplier or to a designated collection
point. For more information see:
applicable harmonized European
2012/19/EU (WEEE directive): Products
marked with this symbol cannot be
disposed of as unsorted municipal waste in
the European Union. For proper recycling,
return this product to your local supplier
upon the purchase of equivalent new
a battery that cannot be disposed of as
unsorted municipal waste in the European
Union. See the product documentation for
specific battery information. The battery is
marked with this symbol, which may
www.recyclethis.info.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A)
standards requirements.
Warning
This is a class A product. In a domestic environment this
product may cause radio interference in which case the
user may be required to take adequate measures.
Warnings Follow
these safeguards to
prevent serious injury
or death.
Cautions Follow these
precautions to prevent
potential injury or
material damage.
Safety Instruction
These instructions are intended to ensure that user can
use the product correctly to avoid danger or property
loss.
The precaution measure is divided into “Warnings” and
“Cautions”.
Warnings: Serious injury or death may occur if any of
the warnings are neglected.
Cautions: Injury or equipment damage may occur if any
of the cautions are neglected.
Warnings
In the use of the device, you must be in strict
compliance with the electrical safety regulations of
the nation and region.
Input voltage should meet both the SELV (Safety Extra
Low Voltage) and the Limited Power Source with 12
VDC according to the IEC60950-1 standard. Refer to
technical specifications for detailed information.
Do not connect multiple devices to one power
adapter to avoid over-heating or a fire hazard caused
by overload.
Make sure that the plug is firmly connected to the
power socket.
Make sure that the device is firmly fixed if wall
mounting or ceiling mounting is adopted.
If smoke, odor or noise rise from the device, turn off
the power at once and unplug the power cord, and
then contact the service center.
Never attempt to disassemble the camera by
unprofessional personal.
Cautions
Do not drop the camera or subject it to physical
shock.
Do not touch senor modules with fingers.
Do not place the camera in extremely hot, cold (the
operating temperature shall be -40°C to 60°C), dusty
or damp locations, and do not expose it to high
electromagnetic radiation.
If cleaning is necessary, use clean cloth with a bit of
ethanol and wipe it gently.
Do not aim the camera at the sun or extra bright
places.
The sensor may be burned out by a laser beam, so
when any laser equipment is in using, make sure that
the surface of sensor will not be exposed to the laser
beam.
Do not expose the device to high electromagnetic
radiation or extremely hot, cold, dusty or damp
environment.
To avoid heat accumulation, good ventilation is
required for the operating environment.
Mark
Description
DC Voltage
DC12VIN
Enclosure
Main Body
Mounting
Base
Power Cord
12 VDC
Video Cable (TVI)
White Light Source
PIR
Keep the camera away from liquid while in use for
non-water-proof device.
While in delivery, the camera shall be packed in its
original packing, or packing of the same texture.
Mark Description
Table 0-1 Mark Description
1 Introduction
1.1 Product Features
The main features are as follows:
High performance CMOS sensor
IR cut filter with auto switch
OSD menu with configurable parameters
Auto white balance
Internal synchronization
SMART IR mode
Visible alarm
PIR detection
3-axis adjustment
1.2 Overview
Figure 1-1 Overview of Type I Camera
Notch
Mark
Coin
Ø
85
mm
Ø
110 mm
73.6 mm
Ø
20
mm
Fixing Screw
Expansion Bolts
2 Installation
Before you start:
Make sure that the device in the package is in good
condition and all the assembly parts are included.
Make sure that all the related equipment is power-off
during the installation.
Check the specification of the products for the
installation environment.
Check whether the power supply is matched with
your required output to avoid damage.
Make sure the wall is strong enough to withstand
three times the weight of the camera, and the
mount.
If the wall is cement, insert expansion screws before
installing the camera. If the wall is wooden, use
self-tapping screw to secure the camera.
If the product does not function properly, contact
your dealer or the nearest service center. Do NOT
disassemble the camera for repair or maintenance by
yourself.
2.1 Ceiling/Wall Mounting without Junction Box
Steps:
1. Disassemble the camera.
1). Rotate the camera to align the notch to one of the
marks.
2). Pry the mounting base to remove the mounting base
with the camera body with a flat object, e.g., a coin.
2. Paste the drill template (supplied) to the place
where you want to install the camera.
3. Drill the screw holes, and the cable hole (optional)
in the ceiling/wall according to the drill template.
Note:
Drill the cable hole, when adopting the ceiling outlet
to route the cable
4. Attach the mounting base to the ceiling/wall, and
Figure 2-1 Drill Template
secure them with supplied screws
Figure 2-2 Attach the Mounting Base to the Ceiling
Rotation Position
[0°to 360°]
Tilt Position
[0°to 75°]
Pan Position
[0° to 360°]
Screw Hole
Cable
Hole
Note:
The supplied screw package contains self-tapping
screws, and expansion bolts.
For cement wall/ceiling, expansion bolts are
required to fix the camera. For wooden wall/ceiling,
self-tapping screws are required.
5. Route the cables through the cable hole, or the side
opening.
6. Align the camera with the mounting base, and
secure the camera on the mounting base.
Figure 2-3 Secure the Camera with Mounting Base
7. Connect the corresponding cables, such as power
cord, and video cable.
8. Power on the camera to check whether the image
on the monitor is gotten from the optimum angle. If
not, adjust the camera according to the figure below
to get an optimum angle.
1). Hold the camera body and rotate the enclosure
to adjust the pan position [0° to 360°].
2). Move the camera body up and down to adjust
the tilt position [0° to 75°].
3). Rotate the camera body to adjust the rotation
position [0° to 360°].
2.2 Mounting with Inclined Ceiling Mount
Before you start:
You need to purchase an inclined ceiling mount
separately.
Steps:
1. Paste the drill template (supplied) to the place
where you want to install the camera.
2. Drill screw holes, and the cable hole on the
ceiling/wall according to the supplied drill template.
Figure 2-4 3-axis Adjustment
3. Disassemble the inclined ceiling mount by the screw
driver.
Figure 2-5 The Drill Template
4. Install the turret camera’s mounting base on the
inclined ceiling mount’s cover with three PM4
screws.
Figure 2-6 Install Turret Camera’s Mounting Base
5. Install the inclined ceiling mount’s body on the
ceiling/wall with four PA4 × 25 screws, as shown in
Figure 2-8.
Figure 2-7 Fix the Inclined Ceiling Mount’s Body
6. Combine the inclined ceiling mount’s cover with its
body with supplied screws.
7. Repeat steps 5 to 8 of the 2.1 Ceiling/Wall Mounting
without Junction Box to complete the installation.
Figure 2-8 Fix the Camera to the Inclined Ceiling Mount
2.3 Ceiling/Wall Mounting with Junction Box
Before you start:
You need to purchase a junction box separately.
Steps:
1. Paste the drill template on the ceiling/wall.
2. Drill screw holes and the cable hole (optional) in the
ceiling/wall according to the holes of the drill
template.
Figure 2-9 Drill Template of the Junction Box
Note:
Drill the cable hole, when adopting the ceiling outlet
to route the cable.
3. Take apart the junction box, and align the screw
holes of the turret camera’s mounting base with
those on junction box’s cover.
4. Fix the mounting base on junction box’s cover by
supplied screws.
Figure 2-10 Install Turret Camera’s Mounting Base
5. Secure the junction box’s body with supplied screws
on the ceiling/wall.
Figure 2-11 Install the Junction Box’ Camera Body on
6. Combine the junction box’s cover with the junction
box’s body.
7. Repeat steps 5 to 8 of 2.1.1 Ceiling/Wall Mounting
without Junction Box to install the camera to the
junction box.
Ceilling/Wall
Figure 2-12 Fix the Camera to the Junction Box
2.4 Wall Mounting
Before you start:
You need to purchase a wall mount separately.
Steps:
1. Drill four screw holes in the wall according to the
holes of the mount.
2. Install the mount to the wall by aligning the four
screw holes of the bracket with expansion screws on
the wall.
3. Secure the mount with four hex nuts and washers.
Wall Mount
Figure 2-13 Install the Bracket
4. Install the mounting base of the turret camera to
the wall mount, and secure them with supplied
screws.
Figure 2-14 Install the Mounting Base to the Bracket
5. Route the cables through the mount.
6. Repeat steps 6 to 8 of 2.1.1 Ceiling/Wall Mounting
without Junction Box to complete the installation.
Camera
TVI DVR
Monitor
AE
AWB
BRIGHTNESS
MAIN MENU
FORMAT
DAY NIGHT
VIDEO
SETTING
FUNC
RESET
SAVE & EXIT
PRIVACY
EXPOSURE MODE
AGC
SENSE UP
MODE
RETURN
MODE
RETURN
CONTRAST
SHARPNESS
COLOR GAIN
3 DNR
MIRROR
RETURN
MOTION
CAM ID
RETURN
LANGUAGE
WHITE LIGHT
RETURN
DPC
PIR LEVEL
3 Menu Description
Purpose:
Call the menu by clicking button on the PTZ Control
interface, or call the preset No.95.
Steps:
1. Connect the camera with the TVI DVR, and the
monitor, shown as the figure 3-1.
2. Power on the analog camera, TVI DVR, and the
monitor to view the image on the monitor.
3. Click PTZ Control to enter the PTZ Control interface.
4. Call the camera menu by clicking button, or call
the preset No. 95.
Figure 3-1 Connection
5. Click the direction arrow to control the camera.
1). Click up/down direction button to select the
item.
2). Click Iris + to confirm the selection.
3). Click left/right direction button to adjust the
value of the selected item.
3.1 FORMAT
PAL (Phase Alternating Lines)
PAL is a color encoding system for analog television
used in broadcast television systems in most countries.
Figure 3-2 Main Menu Overview
MENU
FORMAT
LANGUAGE
WHITE LIGHT
TRIGGER MODE
ALARM MODE
TIME SETTINGS
MAIN MENU
PAL
ENGLISH
ALARM
CAMERA
SOLID
5 S
NTSC: (National Television System Committee)
NTSC is the analog television system that is used in
most of North America, parts of South America,
Myanmar, South Korea, etc.
3.2 LANGUAGE
Supports English, and Chinese.
3.3 WHITE LIGHT
The embedded white light source can be worked as the
visible alarm, or the lighting.
In the WHITE LIGHT mode, you can set the mode as
ALARM, LIGHTING, or OFF.
3.3.1 ALARM
When you select the WHITE LIGHT as ALARM, you can
set the parameters in the TRIGGER MODE, and the
ALARM MODE to meet your needs.
TRIGGER MODE
DVR
Select the TRIGGER MODE as DVR. In this way, the
alarm signal is sent from the DVR, and the camera
works as the alarm detector in the process. Besides, the
alarm type only supported by the DVR can also triggers
the visible alarm in the camera.
CAMERA
Select the TRIGGER MODE as CAMERA, the embedded
PIR module sends the alarm signal to the visible alarm
in the camera, when PIR module detected the alarm
source.
ALARM MODE
In the ALARM mode, you can select the ALARM MODE
as SOLID or FLASHING.
Figure 3-3 ALARM MODE
SOLID
Select the ALARM MODE as SOLID. In this way, the
white light source turns on, when the PIR module
received the alarm signal.
In the TIME SETTING you can set the time as 5 s, 10 s,
15 s, 30 s, or 60 s, which means that the solid mode
stays for the set time when the camera received one
alarm signal.
Note:
The solid mode will be stayed for another set time
when second alarm signal is rec eived, and the rest can
be done in the same way.
FLASHING
Select the ALARM MODE as FLASHING. In this way, the
white light source flashes when the PIR module
received the alarm signal.
MENU
FORMAT
LANGUAGE
WHITE LIGHT
LIGHTING MODE
MAIN MENU
PAL
ENGLISH
LIGHTING
SOLID
MENU
FORMAT
LANGUAGE
WHITE LIGHT
LIGHTING MODE
TRIGGER MODE
MAIN MENU
PAL
ENGLISH
LIGHTING
FLAS HING
CAMERA
3.3.2 LIGHTING
Select the LIGHTING mode, the embedded white light
source turns on in poor light conditions automatically.
You can set the LIGHTING MODE as SOLID, or
FLASHING.
Figure 3-4 LIGHTING MODE
SOLID
The white light source turns on in the poor light
conditions.
FLASHING
When you select the LIGHTING MODE as FLASHING ,
you can set the TRIGGER MODE as CAMERA, or DVR.
The white light source flashes in the poor light
conditions when receiving the alarm signal.
Figure 3-5 FLASHING
TRIGGER MODE
DVR
Select the TRIGGER MODE as DVR. In this way, the
alarm signal is sent from the DVR, and the camera
works as the alarm detector in the process. Besides, the
alarm type only supported by the DVR can also triggers
the visible alarm in the camera.
CAMERA
Select the TRIGGER MODE as CAMERA, the embedded
PIR module sends the alarm signal to the visible alarm
in the camera, when PIR module detected the alarm
source
Note:
Type I camera do not have LIGHTING mode.
Under the LIGHTING mode, the image is colored all
the time, and there’s no DAY NIGHT settings in the
menu.
3.3.3 OFF
Select OFF to give up this function.
3.4 MAIN MENU
3.4.1 AE (AUTO EXPOSURE)
Auto Exposure describes the brightness-related
parameters, which can be adjusted by BRIGHTNESS,
EXPOSURE MODE, AGC, and SENSE UP.
EXPOSURE
BRIGHTNESS
EXPOSURE MODE
AGC
SENSE UP
RETURN
5
GLOBAL
MIDDLE
0
Figure 3-6 AE
BRIGHTNESS
Brightness refers to the brightness of the image.
You can set the brightness value from 1 to 10 to darken
or brighten the image. The greater the value is, the
brighter the image is.
EXPOSURE MODE You can set the EXPOSURE MODE as GLOBAL, BLC, or
WDR.
GLOBAL
GLOBAL refers to the normal exposure mode which
adjusts lighting distribution, variations, and
non-standard processing.
BLC (Backlight Compensation)
BLC (Backlight Compensation) compensates light to the
object in the front to make it clear, but this may cause
the over-exposure of the background where the light is
strong.
When BLC is selected as the exposure mode, the BLC
level can be adjusted from 0 to 8.
WDR (Wide Dynamic Range)
The wide dynamic range helps the camera provide clear
images even under backlight circumstances. WDR
balances the brightness level of the whole image and
provides clear images with details.
AGC (Auto Gain Control)
It optimizes the clarity of the image in poor light
conditions. The GAIN level can be set as HIGH, MIDDLE,
or LOW. Select OFF to disable the GAIN function.
Note:
The noise will be amplified when the GAIN is on. SENSE UP
Sense up increases the exposure on a single frame,
which makes a camera more sensitive to the light so it
can produce images even in low lux conditions.
You can set the SENSE UP function as x0, x2, x4, x6, x8,
x10, x12, x14, or x16 according to the different light
conditions.
3.4.2 AWB (Auto White Balance)
White balance, the white rendition function of the
camera, is to adjust the color temperature according to
the environment. It can remove unrealistic color casts in
the image. You can set WB mode as ATW, or MWB.
ATW (Aoto Tracking White Balance)
Under ATW mode, white balance is being adjusted
automatically according to the color temperature of the
scene illumination.
MWB (Manual White Balance)
You can set the R GAIN/B GAIN value from 1 to 255 to
adjust the shades of red/blue color of the image.
WB
MODE
R GAIN
B GAIN
RETURN
MWB
5
5
DAY NIGHT
MODE
INFRARED
SMART IR
RETURN
AUTO
ON
4
VIDEO SETTING
CONTRAST
SHARPNESS
COLOR GAIN
3 DNR
MIRROR
RETURN
5
5
5
5
DEFAULT
Figure 3-7 MWB MODE
3.4.3 DAY NIGHT
COLOR, BW (Black White), and AUTO are selectable for
DAY and NIGHT switches.
Note:
Under the LIGHTING mode, the image is colored all the
time, and there’s no DAY NIGHT settings in the menu. COLOR
The image is colored in day mode all the time.
B/W
The image is black and white all the time, and the
infrared turns on in poor light conditions.
AUTO
You can turn on/off the INFRARED, and set the value of
SMART IR in this menu.
Figure 3-8 DAY NIGHT
INFRARED
You can turn on/off the infrared to meet the
requirements of different circumstances.
SMART IR
The Smart IR function is used to adjust the light to its
most suitable intensity, and prevent the image from
over exposure. The SMART IR value can be adjusted
from 1 to 8. The greater the value is, the more obvious
effects are.
3.4.4 VIDEO SETTING
Move the cursor to VIDEO SETTING and click Iris+ to
enter the submenu. CONTRAST, SHARPNESS, COLOR
GAIN, 3 DNR, and MIRROR are adjustable.
Figure 3-9 VIDEO SETTING
PRIVACY
MODE
AREA 0
AREA 1
AREA 2
AREA 3
COLOR
TRANSPARENCY
RETURN
ON
RED
OFF
CONTRAST
This feature enhances the difference in color and light
between parts of an image. You can set the CONTRAST
value from 1 to 10.
SHARPNESS
Sharpness determines the amount of detail an imaging
system can reproduce. You can set the SHARPNESS
value from 1 to 10.
COLOR GAIN
Adjust this feature to change the saturation of the color.
The value ranges from 1 to 10.
3 DNR (Digital Noise Reduction)
The 3 DNR function can decrease the noise effect,
especially when capturing moving images in poor light
conditions, and delivering more accurate and sharper
image. You can set the 3 DNR value from 1 to 10.
MIRROR
DEFAULT, H, V, and HV are selectable for mirror.
DEFAULT: The mirror function is disabled.
H: The image flips 180° horizontally.
V: The image flips 180° vertically.
HV: The image flips 180° both horizontally and
vertically.
3.4.5 FUNC (Functions)
In the FUNC sub-menu, you can set the PIR level,
privacy mask, the motion detection, camera ID, and
DPC of the camera.
PIR LEVEL
PIR LEVEL controls the sensitivity of the visible alarm
with the value ranging from 1 to 5, and the greater the
value is, the more sensitive the PIR module is.
PRIVACY
The privacy mask allows you to cover certain areas
which you don’t want to be viewed or recorded. Up to 4
privacy areas are configurable.
Figure 3-10 PRIVACY
Select a PRIVACY area. Set the MODE as ON. Click
up/down/left/down button to define the position, and
the size of the area.
MOTION
In the user-defined motion detection surveillance area,
the moving object can be detected and the alarm will
be triggered. Up to 4 motion detection areas can be
configured.
MOTION
MODE
AREA 0
AREA 1
AREA 2
AREA 3
SENSITIVITY
COLOR
TRANSPARENCY
RETURN
OFF
50
RED
OFF
CAM ID SETTING
MODE
CAM ID
X POSITION
Y POSITION
RETURN
ON
75
36
16
Figure 3-11 MOTION
Select a MOTION area. Set the MODE as ON. Click the
up/down/left/right button to define the position, and
the size of the area. Set the SENSITIVITY from 0 to 100.
CAMERA ID
Edit the camera ID on this section.
Figure 3-12 CAM ID SETTING
Set the MODE as ON. Click up/down/left/right button to
choose the camera ID, and the position.
DPC (Defective Pixel Correction)
Defective pixels are pixels in a CMOS image sensor, in
which fail to sense light levels correctly.
This series of camera supports defective pixel correction.
You can set the DPC as ON or OFF.
3.4.6 RESET
Reset all the settings to the factory default.
3.4.7 SAVE & EXIT
Move the cursor to SAVE & EXIT and click Iris+ to save
the setting, and exit the menu.
UD09304B
Loading...
