DS-2CE79H8T-AIT3ZF
5 MP Outdoor Varifocal Ultra-Low Light Turret Camera
• 5 MP High Performance CMOS
• Up to 2560 x 1944 Resolution
• 2.7 mm to 13.5 mm Motorized
Varifocal Lens
• EXIR
2.0 up to 260 ft (60 m) IR Range
• Smart IR
• 130dB True WDR, 3D DNR
• Multiprotocol Output:
TVI/AHD/CVI/CVBS
• Up-the-Coax (HIKVISION-C)
• IP67 Protection
The Hikvision DS-2CE79H8T-AIT3ZF 5 MP
Outdoor Varifocal Ultra-Low Light Turret
Camera provides high definition analog
output. TurboHD means that the analog
signal can be sent over existing coaxial
cable, eliminating the need to run new
cables for high definition video.
EXIR 2.0 is Hikvision’s proprietary IR
extended range technology, which has a
range of 260 feet (60 meters).
The 2.7 mm to 13.5 mm motorized varifocal
lens is optimized for viewing angles that
fit any situation. 130dB True WDR (Wide
Dynamic Range) ensures that ideal images
are captured regardless of the lighting
conditions.
Available models:
DS-2CE79H8T-AIT3ZF
Page 2
Specifications
DS-2CE79H8T-AIT3ZF
Camera
Image Sensor
5 MP progressive scan CMOS
Resolution
2560 (H) x 1944 (V)
Minimum Illumination
Color: 0.003 lux @ (f/1.2, AGC on), 0 lux with IR
Frame Rate
TVI: 2 MP @ 25 fps, 2 MP @ 30 fps, 4 MP @ 25 fps, 4 MP @ 30 fps, 5 MP @ 20 fps
CVBS: NTSC
Shutter Speed
1/30 s to 1/50, 000 s
Lens
2.7 mm to 13.5 mm motorized varifocal lens
Horizontal Field of View
92.3° to 29.3°
Lens Mount
Φ 14
Day/Night
ICR
Angle Adjustment
Pan: 0° to 360°; tilt: 0° to 75°; rotate: 0° to 360°
Signal System
NTSC
WDR
≥ 130dB
Menu
Image Mode
Standard/high-sat
AGC
Yes
Day/Night Mode
Auto/color/BW (black and white)
White Balance
Auto/manual
AE (Auto Exposure) Mode
WDR/BLC/global
Privacy Mask
4 programmable privacy masks
Motion Detection
4 programmable motion areas
Noise Reduction
3D DNR
Language
English
Functions
Brightness, sharpness, 3D DNR, mirror, Smart IR
Interface
Video Output
Switchable TVI/AHD/CVI/CVBS
General
Operating Conditions
-40° F to 140° F (-40° C to 60° C), humidity: 90% or less (non-condensation)
Power Supply
12 VDC ± 20%, 24 VAC ± 20%
Power Consumption
Maximum 10.5 W
Protection Level
IP67
Material
Metal
IR Range
Up to 260 ft (60 m)
Communication
Up-the-Coax, Protocol: HIKVISION-C (HD-TVI output)
Dimensions
4.88" x 5.29" x 4.34" (123.86 mm x 134.3 mm x 110.24 mm)
Weight
Approximately 1.39 lbs (630 g)
123.86 mm (4.88" )
110.24 mm (4.34" )
123.86 mm (4.88" )
134.
3 mm
(5.29" )
Ø 90 mm (3.54" )
3-Ø 4.5 mm
(0.18" )
120°
WML + PC130T
Pendant Cap
CBM
PM
CM
ABM
AHD: 4 MP @ 25 fps, 4 MP @ 30 fps, 5 MP @ 20 fps
CVI: 4 MP @ 25 fps, 4 MP @ 30 fps
Accessories
Wall Mount Long
with 130 mm
Conduit Base
Pole Mount
Corner Mount
Angled Base
Dimensions
