Hikvision DS-2CE76D3T-ITMF-2-8mm, DS-2CE76D3T-ITMF-3-6mm, DS-2CE76D3T-ITMF-6mm, DS-2CE76D3T-ITMFB-2-8mm, DS-2CE76D3T-ITMFB-3-6mm Specsheet



DS-2CE76D3T-ITMF(B)

2 MP Outdoor Ultra-Low Light Turret Camera

• 2 MP High Performance CMOS

• Up to 1080p Resolution

• Ultra-Low Light

• 2.8 mm, 3.6 mm, 6 mm Fixed Lens Options

• EXIR

• Smart IR

• 120 dB True WDR, 3D DNR

• Multiprotocol Output: TVI/AHD/CVI/CVBS

• Up-the-Coax (HIKVISION-C)

• Black-Finish Housing Available

2.0 up to 100 ft (30 m) IR Range

The Hikvision DS-2CE76D3T-ITMF(B) 2 MP
Outdoor Ultra-Low Light Turret Camera
provides high definition analog output.
TurboHD means that the analog signal can
be sent over existing coaxial cable,
eliminating the need to run new cables for
high definition video.

EXIR 2.0 is Hikvision’s proprietary IR
extended range technology, which has a
range of 100 feet (30 meters).

The 2.8 mm, 3.6 mm, and 6 mm lens
options are optimized for viewing angles
that fit any situation. True 120 db WDR
(Wide Dynamic Range) ensures that ideal
images are captured regardless of the
lighting conditions.

Available models:

DS-2CE76D3T-ITMF
DS-2CE76D3T-ITMFB

• IP67 Protection

Specifications

DS-2CE76D3T-ITMF

DS-2CE76D3T-ITMFB

Camera

Image Sensor

2.0 megapixel progressive scan CMOS

Signal System

NTSC

Video Frame Rate

1080p @ 30 fps

Resolution

1920 (H) × 1080 (V)

Minimum Illumination

Color: 0.005 lux @ (ƒ/1.2, AGC on), 0 lux with IR

Shutter Speed

1/30 s to 1/50,000s

Lens

2.8 mm, 3.6 mm, and 6 mm fixed lens options

Horizontal Field of View

106° (2.8 mm), 82° (3.6 mm), 51° (6 mm)

Lens Mount

M12

Day/Night

IR cut filter

Angle Adjustment

Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°

Synchronization

Internal synchronization

WDR (Wide Dynamic Range)

>120 dB

Menu

AGC

High/medium/low

D/N Mode

Auto/color/BW (black and white)

Image Mode

Standard/high-sat

BLC (Backlight Compensation)

Yes

WDR

Yes

3D DNR

Level 1 to 9

Language

English

Functions

Brightness, sharpness, 3D DNR, mirror, smart IR

Interface

Video Output

1 HD analog output

Switch Button

TVI/AHD/CVI/CVBS

General

Operating Conditions

-40° to 140° F (-40° to 60° C), humidity: 90% or less (non-condensing)

Power Supply

12 VDC ±25%

Power Consumption

Maximum 4.6 W

Ingress Protection

IP67

Material

Metal

Color

Hikvision White

Hikvision Black

IR Range

Up to 100 ft (30 m)

Dimensions

3.52" × 2.68" (89.47 mm × 68.2 mm)

Weight

Approximately 0.53 lbs (240 g)

89.47 mm (3.52")

68.2 mm (2.68")

WML + PC110T

Cap

PM

CM

CBXS

WMSB

CBXSB

Accessories (not included)

Wall Mount Long +

110 mm Pendant

Pole Mount

Corner Mount

Conduit Base

Wall Mount Short

(Black)

Conduit Base

(Black)

Dimensions
