Hikvision DS-2CE57D3T-VPITF-2-8mm, DS-2CE57D3T-VPITF-3-6mm, DS-2CE57D3T-VPITF-6mm Specsheet

Key Features

 2 MP high-performance CMOS

 Ultra low light

 1920 × 1080 resolution

 2.8 mm, 3.6 mm, 6 mm fixed lens

 EXIR 2.0, smart IR, up to 30 m IR distance

 OSD menu, 3D DNR, 120 dB true WDR, day/night switch

 4 in 1 video output (switchable TVI/AHD/CVI/CVBS)

 IP67, IK10

 Up the coax (HIKVISION-C)

DS-2CE57D3T-VPITF
2 MP EXIR Dome Camera

Specifications

Camera

Image Sensor

2.0 megapixel progressive scan CMOS

Signal System

PAL/NTSC

Video Frame Rate

PAL: 1080p@25fps
NTSC: 1080p@30fps

Resolution

1920 (H) ×1080 (V)

Min. Illumination

0.005 Lux@(F1.2, AGC ON), 0 Lux with IR

Shutter Time

PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s

Lens

2.8 mm, 3.6 mm, 6 mm

Horizontal Field of View

106° (2.8 mm), 82° (3.6 mm), 51° (6 mm)

Lens Mount

M12

Day & Night

IR cut filter

Angle Adjustment

Pan: 0° to 355°, Tilt: 0° to 75°, Rotation: 0° to 355°

Synchronization

Internal synchronization

WDR (Wide Dynamic Range)

≥ 120 dB

Menu

AGC

High/Medium/Low

D/N Mode

Auto/Color/BW (Black and White)

Image Mode

STD/HIGH-SAT

HLC (Highlight Compensation)

Yes

BLC (Backlight Compensation)

Yes

WDR

Yes

3D DNR

Level 1 to 9

Language

English

Functions

Brightness, Sharpness, 3D DNR, Mirror, Smart IR

Interface

Video Output

1 HD analog output

Switch Button

TVI/AHD/CVI/CVBS

General

Operating Conditions

-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)

Power Supply

12 VDC ±25%

*You are recommended to use one power adapter to supply the power for one camera.

Power Consumption

Max. 4.6 W

Protection Level

IP67, IK10

Material

Metal

IR Range

Up to 30 m

Dimensions

Ø 111 mm × 82.4 mm (Ø 4.4" × 3.2")

Weight

Approx. 487 g (1.07 lb.)
