Hikvision DS-2CE56H0T-IT3ZF User Manual

Key Features
5 MP high performance COMS 2560 × 1944 resolution 2.7 mm to 13.5 mm motorized vari-focal lens EXIR 2.0, smart IR, up to 40 m IR distance OSD menu, 2D DNR, DWDR 4 in 1 video output (switchable TVI/AHD/CVI/CVBS) IP67 Up the coax (HIKVISION-C)
DS-2CE56H0T-IT3ZF 5 MP Turret Camera
Camera
Image Sensor
5 MP CMOS image sensor
Resolution
2560 (H) × 1944 (V)
Min. Illumination
Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Time
PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s
Lens
2.7 mm to 13.5 mm motorized vari-focal lens
Horizontal Field of View
95.7° to 29.1°
Lens Mount
Φ 14
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 360°; Tilt: 0° to 75°; Rotate: 0° to 360°
Synchronization
Internal synchronization
Frame Rate
PAL: 5 MP@20fps, 4 MP@25fps, 1080p@25fps NTSC: 5 MP@20fps, 4 MP@30fps, 1080p@30fps
Menu
AGC
Support
D/N Mode
Auto/Color/BW (Black and White)
White Balance
ATW/MWB
BLC
Support
DWDR (Digital Wide Dynamic Range)
Support
Functions
Brightness, Sharpness, DNR, Mirror, Smart IR
Interface
Video Output
1 HD analog output
Switch Button
TVI/AHD/CVI/CVBS
General
Operating Conditions
-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
Power Supply
12 VDC ±25%
Power Consumption
Max. 6.3 W
Protection Level
IP67
Material
Metal
IR Range
Up to 40 m
Communication
Up the coax, Protocol: HIKVISION-C (TVI output)
Dimensions
123.86 mm × 134.3 mm × 110.11 mm (4.88" × 5.29" × 4.38")
Weight
Approx. 580 g (1.28 lb.)
Order Model
DS-2CE56H0T-IT3ZF
Dimension
123.86 mm (4.88" )
110.11 mm (4.38" )
123.86 mm (4.88" )
134.3 mm
(5.29" )
Ø 90 mm (3.54" )
3-Ø 4.5 mm
(0.18" )
120°
Accessory
DS-1273ZJ-130-TRL Wall Mount
DS-1275ZJ-SUS Vertical Pole Mount
DS-1276ZJ-SUS Corner Mount
DS-1280ZJ-M Junction Box
DS-1281ZJ-M Inclined Ceiling Mount
0100001080116
