DS-2CD2721G0-I(Z)(S)
2 MP IR VF Dome Network Camera
BLC/3D DNR/ROI
Built-in micro SD/SDHC/SDXC card slot,
up to 128 GB
IP67, IK10
1/2.8" Progressive Scan CMOS
1920 × 1080@30fps
2.8 to 12 mm varifocal lens
Color: 0.01 Lux @(F1.2, AGC ON),
0.028Lux @(F2.0, AGC ON);
H.265+, H.265, H.264+, H.264
120dB WDR
2 Behavior analyses
Key Features
Specifications
Camera
Image Sensor
1/2.8" Progressive Scan CMOS
Min. Illumination
Color: 0.01 Lux @(F1.2, AGC ON), 0.028Lux @(F2.0, AGC ON);
B/W: 0.001 Lux @(F1.2, AGC ON), 0.0028 Lux @(F2.0, AGC ON), 0 Lux with IR
Shutter Speed
1/3 s to 1/100,000 s
Slow Shutter
Yes
Auto-Iris
No
Day & Night
IR Cut Filter
Digital Noise Reduction
3D DNR
WDR
120 dB
3-Axis Adjustment
Pan: 0° to 355°, tilt: 0° to 75°, rotation: 0° to 355°
Lens
Focal Length
2.8 to 12 mm
Aperture
F2.0
Focus
-Z: Auto
Without –Z: Manual
FOV
Horizontal FOV: 99.6° to 35°, vertical FOV: 53.5° to 20°, diagonal FOV: 118.6° to 40.2°
Lens Mount
Φ14
IR
IR Range
Up to 30 m
Wavelength
850nm
Compression Standard
Video Compression
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
H.264 Type
Baseline Profile/Main Profile/High Profile
H.264+
Main stream supports
H.265 Type
Main Profile
H.265+
Main stream supports
Video Bit Rate
32 Kbps to 8 Mbps
Audio Compression (-S)
G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate (-S)
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
Smart Feature-set
Behavior Analysis
Line crossing detection, intrusion detection
Region of Interest
1 fixed region for main stream
Max. Resolution
1920 × 1080
Main Stream
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Image Enhancement
BLC/3D DNR
Image Settings
Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web
browser
Target Cropping
No
Day/Night Switch
Day/Night/Auto/Schedule/Triggered by alarm in (-S)
Network
Network Storage
Support built-in microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Trigger
Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD
full, HDD error
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP,
SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
General Function
One-key reset, anti-flicker, heartbeat, three streams, mirror, password protection, privacy mask,
watermark, IP address filter
Firmware Version
V5.5.6
API
ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View
Up to 6 channels
User/Host
Up to 32 users
3 levels: Administrator, Operator and User
Client
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
Web Browser
IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Interface
Audio (-S)
1 input (line in), 1 output (line out), mono sound
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
Alarm (-S)
2 inputs, 2 outputs
Video Output (-S)
CVBS
On-board Storage
Built-in microSD/SDHC/SDXC slot, up to 128 GB
SVC
H.264 and H.265 encoding support
Reset Button
Yes
Audio (-S)
Environment Noise Filtering
Yes
Audio Sampling Rate
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
General
Operating Conditions
-30 °C to +60 °C (22 °F to +140 °F), humidity 95% or less (non-condensing)
Power Supply
12 VDC ± 25%, Φ 5.5 mm coaxial plug power
PoE (802.3af, class 3)
Power Consumption and
Current
-Z:
12 VDC, 0.8 A, max. 10 W
PoE: (802.3af, 36V-57V), 0.4 A to 0.2 A, max. 12 W
Without –Z:
12 VDC, 0.5 A, max. 6 W
PoE: (802.3af, 36V-57V), 0.3 A to 0.1 A, max. 8 W
Protection Level
IP67, IK10
Material
Front cover & Base: metal, bubble: plastic
Dimensions
Φ 153.3 × 111.6 mm (Φ 6" × 4.4")
Weight
Camera: approx. 880 g (1.9 lb.)
With package: approx. 1300 g (2.9 lb.)
Available Models:
DS-2CD2721G0-I(2.8 to 12 mm), DS-2CD2721G0-IZ(2.8 to 12 mm), DS-2CD2721G0-IS(2.8 to 12 mm),
DS-2CD2721G0-IZS(2.8 to 12 mm)
Unit: mm(inch)
153.3(6")
100.4(4")
111.6(4.4")
46(1.8")
83.5(3.3")
DS-1471ZJ-155
Pendant Mount
DS-1473ZJ-155
Wall Mount
DS-1475ZJ-SUS
Vertical Pole Mount
DS-1476ZJ-SUS
Corner Mount
DS-1280ZJ-DM55
Junction Box
Accessories
Dimensions
