DS-1100KI Network Keyboard
User Manual
V 1.0
User Manual of DS-1100KI Network Keyboard
Preventive and Cautionary Tips
Before connecting and operating your keyboard, please be advised of the following tips:
•Ensure unit is placed in a well-ventilated, dust-free environment.
•Keep all liquids away from the keyboard.
•Please check the power supply to avoid the damage caused by voltage mismatch.
•Please make sure the keyboard work in the allowed range of temperature and humidity.
•Please keep the device horizontal and avoid the installation under severe vibration environment.
•The dust board will cause a short circuit after damping; Please dedust regularly for the board, connector, chassis fan etc with brush.
•Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or equivalent type only. Dispose of used batteries according to the instructions provided by the battery manufacturer.
1
User Manual of DS-1100KI Network Keyboard
Table of Contents
Chapter1 Introduction........................................................................................................................ |
3 |
1.1 Overview .............................................................................................................................. |
3 |
1.2 Features................................................................................................................................ |
3 |
1.3 Appearance .......................................................................................................................... |
4 |
Chapter2 Keyboard Configuration...................................................................................................... |
5 |
2.1 Keyboard Management........................................................................................................ |
6 |
2.1.1 Network Settings....................................................................................................... |
6 |
2.1.2 Hardware Settings ..................................................................................................... |
6 |
2.1.3 Time Settings............................................................................................................. |
7 |
2.1.4 Language ................................................................................................................... |
7 |
2.1.5 Screen Verify ............................................................................................................. |
7 |
2.1.6 Upgrade..................................................................................................................... |
8 |
2.2 Device Management ............................................................................................................ |
9 |
2.2.1 Add Device ................................................................................................................ |
9 |
2.2.2 Modify/Delete Device ............................................................................................. |
11 |
2.3 User Management ............................................................................................................. |
11 |
2.3.1 Add User.................................................................................................................. |
12 |
2.3.2 Related Device......................................................................................................... |
12 |
2.3.3 Modify User Password and Delete User.................................................................. |
13 |
2.3.4 Configure File .......................................................................................................... |
13 |
2.4 Default................................................................................................................................ |
13 |
2.5 Logout ................................................................................................................................ |
14 |
2.6 Reboot................................................................................................................................ |
14 |
2.7 Shutdown ........................................................................................................................... |
14 |
Chapter3 Keyboard Operation ......................................................................................................... |
15 |
3.1 Basic Operation .................................................................................................................. |
15 |
3.1.1 Device List ............................................................................................................... |
15 |
3.1.2 Input Settings .......................................................................................................... |
16 |
3.1.3 Output Settings ....................................................................................................... |
17 |
3.1.4 Macro Settings ........................................................................................................ |
18 |
3.1.5 Aux Settings............................................................................................................. |
19 |
3.1.6 Password Settings.................................................................................................... |
19 |
3.1.7 Logout ..................................................................................................................... |
19 |
3.1.8 Reboot..................................................................................................................... |
20 |
3.1.9 Shutdown ................................................................................................................ |
20 |
3.2 Shortcut Operation............................................................................................................. |
20 |
3.2.1 Local Preview........................................................................................................... |
21 |
3.2.2 Decoded Video Display on Monitor ........................................................................ |
21 |
3.2.3 PTZ Control.............................................................................................................. |
26 |
3.2.4 Aux Functions.......................................................................................................... |
31 |
Appendix 1: Specifications ............................................................................................................... |
33 |
Appendix 2: FTP Upgrade................................................................................................................. |
34 |
2 |
|
User Manual of DS-1100KI Network Keyboard
Chapter1 Introduction
1.1 Overview
DS-1100KI Network Keyboard can be used to control the speed dome and the display of decoded video on TV wall, as well as support 1 channel of video view at up to 1080P resolution. It is easy to operate and configure settings.
1.2 Features
Hardware
7’’ TFT touch screen at 800×480 resolution;
3-axis joystick;
Shortcut keys for dome control, setting and callup of preset, patrol and pattern;
Shortcut keys for playback operation;
Shortcut keys for input group and output group;
Shortcut keys for wiper and light control operation.
Software
Administrator and operator user management;
Support upgrade by U-flash disk;
Auto searching connected devices in the same network area;
Support 15 operators, and each user is allowed to operate 256 devices with up to 4096 channels;
Import and export of keyboard parameters;
Macro command operation;
Backup of record files to U-flash disk;
Voice talk.
Decoding Capability
Provide 1-ch video decoding and local decoding;
Support standard MPEG4, private H.264 and standard H.264 encoding formats;
Decoding at up to 1080P resolution.
Display of Decoded Video on Monitor
Display of decoded camera on selected window;
Display of decoded camera group on selected window;
Sequence display of decoded camera group on monitor;
Sequence display of decoded camera group on monitor group.
3
User Manual of DS-1100KI Network Keyboard
1.3 Appearance
Front View:
Interface Description:
4
User Manual of DS-1100KI Network Keyboard
Chapter2 Keyboard Configuration
Note: Please use the user name admin to log in the system for the first time. After keyboard startup, enter the user login
interface. Select the user name to admin and input the password of 12345. Click Login to enter the admin main interface.
Input method shift:
Click the tab
on the soft keyboard to enter
the interface for inputting the English letters, and
the |
can |
be used to switch |
the |
uppercase/lowercase.
Click the tab
on the soft keyboard to enter
the interface for inputting the numerals.
5
User Manual of DS-1100KI Network Keyboard
2.1 Keyboard Management
Click Keyboard on the admin main interface to enter the keyboard management menu.
2.1.1 Network Settings
Configure the network settings of the keyboard, including the Port, IP address, Subnet Mask and
Default Gateway, and finally click Apply to save the settings.
Note: Make sure the DHCP is supported by the router before enabling the function.
2.1.2 Hardware Settings
Key Sound/Alarm Sound/Key Light: Click the corresponding checkbox to
to enable the function, or remain it as
to disable the function.
Key Lock Timeout, Scr-close Timeout: Use the
or
to decrease or increase the key lock timeout and the screen-close timeout, with the max. value of 10s
and the min. value of 0s.
Transparency: Click
to select the value from the
drop-down menu, with the 3: 1, 1: 1, 1: 3 and non transparent optional.
Note: The Transparency refers to the contrast of the local decoded video and menu, and is valid only for the local live view.
Mouse Speed: Select the mouse speed to level 0~2 or 1~3.
Brightness: Select the screen brightness to level 0~3. Click Apply to save the settings.
6
User Manual of DS-1100KI Network Keyboard
2.1.3 Time Settings
Date: Click
to select the date from the calendar.
Time: Click
or
to decrease or increase the time value.
Click Apply to save the settings.
2.1.4 Language
Language: Click |
to select the option from the |
drop-down menu.
Click Apply to save the setting.
2.1.5 Screen Verify
In order to use the touch screen correctly, it needs to be calibrated properly.
Click Verify to start the calibration of touch screen positioning. The system will pop up the Attention message. Click Yes to continue the calibration.
7
User Manual of DS-1100KI Network Keyboard
Use the touch pen to click the three spots marked as “+” by following the hints and then the system will pop up the attention “Screen verify successfully”, click OK to finish the operation.
2.1.6 Upgrade
FTP Upgrade: input the address of the FTP server and then click FTP Upgrade to operate the upgrade.
Note: User must create the FTP server connection first by TFTP or WFTP in PC before operating the FTP upgrade. Please refer to Appendix2 for the upgrading.
If the upgrading is failed, the corresponding error message box will be popped up.
Note: When the upgrading is successful, the keyboard will restart automatically to complete the upgrade.
USB Upgrade: Insert the U flash disk to the USB interface and then click USB Upgrade to enter the USB upgrade interface. Select the upgrade file from the disk and finally click Upgrade to start upgrading.
Note: The upgrade file must be digicap.dav.
8
User Manual of DS-1100KI Network Keyboard
If the upgrading is failed, the corresponding error message box will pop up.
Note: When the upgrading is successful, the keyboard will restart automatically to complete the upgrade.
2.2 Device Management
Click Device on the admin main interface to enter the device management menu.
2.2.1 Add Device
Auto Search: Click Auto Search button at the upper left corner to enter the “Device-Auto Search” interface. Select the start IP and end IP of the device to be searched, and then click Search to start searching. After the searching is completed, all devices searched out and their information will be displayed in the list below. Select the device from the list, input its user name and password, and then click Add to add it to the system.
Note: Only the device that is in the same network area with the keyboard can be searched out by the keyboard.
Status: In the status bar, the icon
indicates the device is not added,
indicates the device is failed to be added, and the
indicates the device is successfully added.
9
User Manual of DS-1100KI Network Keyboard
User can also select multiple devices to be added each time.
If the adding is failed, in the status bar it will display
in
. If the adding is successful, it will display in
. Note: The devices for bulk adding must have the same user name and password.
After having added the devices, click Return to return to the “Device-List Management” interface, where user can view the information of added devices.
Add Device: Click Add Device to enter the “Add Device” interface. Input the device name, device IP, port, user name and password, and then click Add to add the device.
If the input message is incorrect or the device is offline, the message box “Add Device failed” will pop up.
10
