Hikvision AE-DN2016-F3 Specsheet

AE-DN2016-F3 1080P HD Dashboard Camera

 Up to 1080P full HD camera, wide field angle up to 135°(diagonal)
 Support built-in MIC and speaker for audio in and out

 Built-in WIFI module and WIFI AP function supported

 Built-in G-Sensor module, support video recording linkage at car crash or strong vibration (Linkage

video record can be configured be no-overwritten )

 SD card for video recording, up to 128GB (Overwriting supported )

 Phone App: live view, record playback and parameter configuration

 Magnetic connection between camera and bracket, easy for disassemble

 Easy installation and user friendly, plug and play (Automatically recording after power on )

 Low power consumption and high performance

Key Features

Specifications

Dashboard Cmaera

Image Sensor

1/3” Progressive Scan CMOS

Camera Resolution

1080P(1920*1080)

View Angle

135°( diagonal), 115°(horizontal)

Recoding Resolution

1080P@25fps, 720P@25fps (1080P default)

Video Compression

H.264

Picture Format

JPEG

OSD Overlay

Date, time

Storage

1 TF card, up to 128GB

Communication module

WIFI

Sensor

Built-in G-sensor

Interfaces

USB port

1 USB2.0

Audio

Built-in MIC and speaker

General

Working
Temperature/Humidity

-10°C to 60°C (14°F to 140°F), Humidity 95% or less (non-condensing)
Power Supply

5VDC 2A

Power Consumption

MAX. 2W

Dimension

44.5mm×44.5mm×52mm (1.75"×1.75"×2.47")

Weight

Approx. 120g (0.265lb)

Order Models

AE-DN2016-F3
