HP Z440 Workstation

Take your business to the next level of performance, expandability, and no compromise reliability in one complete package. Featuring a perfect mix of HP Z DNA in a performance workstation package with up to 8 discrete processor cores, up to 128 GB of RAM, and multiple storage and PCIe configuration options.

HP recommends Windows.

●

Windows 8.1

●

Intel® Xeon™ processors

Get the job done fast

Cross items off your to-do list fast. Achieve massive computational performance with a single processor

●

personal workstation delivering support for up to 8 cores of processing power. Add in powerful graphics and performance features like optional Thunderbolt™ 23, HP Z Turbo Drive4, and HP Remote Graphics Software,4and you get a world-class workstation experience that never slows you down.

Customize it to grow with you

When your job requires more, the HP Z440 Workstation, with its sleek 4U form factor, tool-less design, and built

●

in handles make it simple to expand. Easily configure memory, storage, graphics, and more to suit your needs.

Position for the future

Protect your investment and make downtime a thing of the past. Get no-compromise reliability and a standard

●

3/3/3 limited warranty from the HP Z440 Workstation.

Featuring:

Achieve the performance you need with next generation Intel® Xeon® processors for up to 8 processor cores in

●

one system.

Get serious about graphics and reach peak productivity with access to a breadth of AMD professional graphics

●

from entry to high-end 3D.

Take productivity up a notch with the ability to do more thanks to NVIDIA professional graphics cards in 2D or 3D.

●

Maximize your time and increase your capabilities with USB and SATA ports, plus lightning-fast data transfers

●

using optional Thunderbolt™ 2 technology.

A brand new tool-free chassis boasts low acoustics, single integrated Gb Ethernet and more.

●

Reduce boot up, calculation, and graphics response and revolutionize how your HP Z440 handles large files with

●

the HP Z Turbo Drive, a remarkably fast and innovative storage solution.

You’ll never run out of juice with the 700W Power Supply with two power cables for high-power professional

●

graphics.

Take multitasking to a new level with support for up to eight displays.

●

Optimize this HP Z440 for peak performance. HP Performance Advisor6configures your system with updated

●

settings and drivers to help maximize performance.

Datasheet

HP Z440 Workstation

Form Factor

Operating System

Processor Family

Processors

3,4

Chipset

Maximum Memory

Memory Slots

Drive Controllers

Internal Storage

Optical Storage

Additional Storage

Drive Bays (Internal)

Drive Bays (External)

Available Graphics

Expansion Slots

Ports and Connectors

Communications

Audio

Power

Input Device

Security

Software

Dimensions

Weight

Energy Efficiency Compliance

Environmental Certification

Compatible Displays

Warranty

Minitower

Windows 8.1 Pro 64 Windows 7 Professional 64 (available through downgrade rights from Windows 8.1 Pro 64) Windows 7 Professional 64 (National Academic)

HP Installer Kit for Linux

Intel® Xeon® E5 v3 processor

Intel® Xeon® E5-1680 v3 (3.2 GHz, 20 MB cache, 8 cores, Intel® vPro™); Intel® Xeon® E5-1660 v3 (3.0 GHz, 20 MB cache, 8 cores, Intel® vPro™); Intel® Xeon® E5-2630 v3 (2.4 GHz, 20 MB cache, 8 cores, Intel® vPro™); Intel® Xeon® E5-1650 v3 (3.5 GHz, 15 MB cache, 6 cores, Intel® vPro™); Intel® Xeon® E5-1630 v3 (3.7 GHz, 10 MB cache, 4 cores, Intel® vPro™); Intel® Xeon® E5-1620 v3 (3.5 GHz, 10 MB cache, 4 cores, Intel® vPro™); Intel® Xeon® E5-1607 v3 (3.1 GHz, 10 MB cache, 4 cores, Intel® vPro™); Intel® Xeon® E5-1603 v3 (2.8 GHz, 10 MB cache, 4 cores, Intel® vPro™)

Intel® C612

Up to 128 GB DDR4-2133 ECC Registered SDRAM Standard memory note: Actual memory speed dependent on processor. Only registered memory is supported.

8 DIMM

Integrated SATA 6.0 Gb/s; LSI 9217-4i4e 8-port SAS 6.0 Gb/s RAID (optional)

300 GB up to 600 GB SAS (15000 rpm) 300 GB up to 1.2 TB SAS (10000 rpm) 500 GB up to 3 TB SATA (7200 rpm) up to 500 GB SATASED 128 GB up to 1 TB SATA SSD up to 256 GB SATASE SSD 256 GB up to 512 GB HP Z Turbo Drive (PCIe SSD)

Slim SATA DVD-ROM; Slim SATASuperMulti DVD writer; Slim SATA Blu-ray writer

1 15-in-1 media card reader (optional)

Two 3.5"

Two 5.25"; One slim ODD

Professional 2D: NVIDIA NVS 310 (512 MB); NVIDIA NVS 315 (1 GB); NVIDIA NVS 510 (2 GB) Entry 3D: NVIDIA Quadro K420 (1 GB); NVIDIA Quadro K620 (2 GB) Mid-range 3D: NVIDIA Quadro K2200 (4 GB); AMD FirePro W2100 (2 GB); AMD FirePro W5100 (4 GB) High-end 3D: NVIDIA Quadro K4200 (4 GB); NVIDIA Quadro K5200 (8 GB); NVIDIA Quadro K6000 (12 GB)

2 PCIe Gen3 x16; 1 PCIe Gen3 x8 (open-ended); 1 PCIe Gen2 x4 (open-ended); 1 PCIe Gen2 x1 (open-ended); 1 PCI Open-ended connector allows a greater bandwidth card to be installed physicallyinto a lower bandwidth connector/slot.

Front: 4 USB 3.0; 1 microphone; 1 headset Back: 4 USB 3.0; 2 USB 2.0; 2 PS/2; 1 RJ-45; 1 audio line in; 1 audio line out Internal: 1 USB 2.0; 1 USB 3.0 Internal USB 2.0 available by the 2x5 header. Internal USB 3.0 available by the 2x10 header.

Integrated Intel I218LM PCIe GbE; Intel I210AT PCIe GbE (optional); HP X520 10 GbE Dual Port Adapter (optional); HP 10 GbE SFP+SR Transceiver (optional); HP 361T PCIe dual-port gigabit (optional); Intel 7260

802.11a/b/g/nPCIe WLAN (optional)

Integrated RealtekHD ALC221

700 W 90% efficient, wide-ranging, active PFC

HP PS/2 Keyboard; HP USB Keyboard; HP USB SmartCard Keyboard; HP Wireless Keyboardand Mouse HP PS/2 Mouse; HP USB Optical Mouse; HP USB 1000 dpi Laser Mouse; HP USB Optical 3-Button Mouse; HP SpaceMouse Pro USB 3D Controller; HP SpacePilot Pro 3D USB Intelligent Controller

HP Solenoid Hood Lock & Hood Sensor; HP Business PC Security Lock Kit

HP Performance Advisor; HP Remote Graphics Software (RGS) 6.0; Cyberlink Media Suite & PowerDVD; Foxit PhantomPDF Express; Buy Office

16.9 x 44.5 x 43.2 cm

11 kg Exact weight depends upon configuration.

ENERGY STAR®qualified and EPEAT®registered configurations available

Low halogen

HP Z Display Z30i 30-inch IPS LED Backlit Monitor; HP Z Display Z27i 27-inch IPS LED Backlit Monitor; HP Z Display Z24i 24-inch IPS LED Backlit Monitor; HP Z Display Z23i 23-inch IPS LED Backlit Monitor; HP Z Display Z22i 21.5-inch IPS LED Backlit Monitor; HP DreamColor Z27x Professional Display; HP DreamColor Z24x ProfessionalDisplay

3-year (3-3-3) limited warranty and service offering includes 3 years of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply.

HP recommends Windows.

6,7
