CATIA V5
Revision Level
Drawing Part
02.1 Design Release
State
4.70
±0.20
-
Revision Record Changed Date Approved Date
SEE ECN#
014539
CTF 07/27/2018 TAT 07/27/2018
02.1
CLIP
24.9( )
12.0( )
TYPE SUGGESTED DIAMETER RANGE*
HARNESS 23.0MM - 28.5MM
HOSE 23.0MM - 28.5MM
HARD PIPE/TUBE 25.9MM - 29.0MM
====±I
*RECOMMENDED SIZES MAY DIFFER DEPENDING ON THE
APPLICATION , PRODUCT REQUIREMENTS AND MATERIALS USED
==-1
25.8( )
SEE DIAMETER
RANGE CHART
210.4
±5.0
CABLE TIE
02.1
SERRATED SIDE
1.4
CLIP 360
ROTATABLE
ISOMETRIC VIEW
SCALE 1:2
±0.2
**PATENT PENDING 29/582,271
GLOBAL PART DESCRIPTION
T50SMVCMOC26M-PA66HIRHSUV-BK 2 TO 50 14-0606-012-CSU PA66HIRHSUV BLACK 16-0325-000-CSU PA66HIRHSUV BLACK
Material Units millimeters
SEE CHART
COLOR:
SEE CHART
Tolerance defined on
each dimension
02.1
BUNDLE
RANGE
The copyright of this
drawing is reserved by
HellermannTyton. It is
issued on condition that it is
not reproduced, copied or
disclosed to a third party,
either wholly or in part,
without the consent of
HellermannTyton.
DRAWING MATERIAL COLOR DRAWING MATERIAL COLOR
Drawn
Approved Title
ermanniijf[too
02.1
CABLE TIE CLIP**
TAT 5/17/17
EJH 5/31/17
North America
Article/Type-No Scale
T50SMVC CABLE TIE COUPLED TO 26MM
02.1
Drawing-No
T50SMVCMOC26M
MOC
16-0325-302-CSU
02.1
02.1
PRODUCTION
: Phase
Project Number
Format
Sheet
1:1
16-0325
AH
1
/
1
