Quick Start Guide
Guide de demarrage rapide
Buttons and connections
Power turn on/off
What’s in the box
x 1
x 1
x 1
x 1
Speakerphone
LED indication
NFC pairing
Bluetooth®
Harman Kardon One
ONE
Harman Kardon One
Status LED indication
Slow blinking
Fast blinking
On
On
On
On
Off
Blinking
Pairing mode / Incoming call
Not connected
Product On
Connected
Low Power
Charging
Call not active
Product Off
Call active
Blinking
Phone ringing
Harman Kardon One
EN
• Model : Harman Kardon ONE
• Battery type: Lithium-ion polymer
(3.7V, 2000mAh)
• Battery charge time: 3 hour for adapter
• Music playing time: up to 5 hour (varies by
volume level and audio content)
• Bluetooth® version:
• Support: A2DP V1.2, AVRCP V1.4, HFP V1.6,
HSP V1.2
• Bluetooth® transmitter power: 0-4 dBm
• Bluetooth® transmitter frequency range:
2.402-2.480 GHz
• Bluetooth® transmitter modulation:
GFSK, π/4-DQPSK, 8DPSK
• Transducer: 2 x 40mm (1.5’’)
• Rated power: 2 x 6W
• Power Input: 5VDC, 1A
• Frequency response: 100Hz – 20kHz
• Signal-to-noise ratio: ≥80 dB
• Dimensions (H x W x D): xxxx (mm)
• Weight: xxxx g
TR00049_A
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
and any use of such marks by HARMAN International Industries, Incorporated is under license.
Other trademarks and trade names are those of their respective owners.
