AVR 120 Audio/VideoReceiver

OWNER’S MANUAL

AVR 120

Power for the Digital Revolution

™

®®

2 TABLE OF CONTENTS

3 Introduction 4 Safety Information 4 Unpacking 5 Front Panel Controls 7 Front Panel Information Display

9 Rear Panel Connections 11 Remote Control Functions 14 Installation and Connections 14 System Installation 14 Audio Equipment Connections 14 Video Equipment Connections 15 Power Connections 16 System Configuration 16 Speaker Selection and Placement 17 System Setup 17 Speaker Setup 18 Output Level Adjustment 19 Delay Settings 20 Additional Input Adjustments 21 Operation 21 Basic Operation 21 Source Selection 21 Volume Control 22 Surround Mode Chart 23 Surround Mode Selection 23 Digital Audio Playback 23 Selecting a Digital Source 24 Digital Status Indicators 24 Night Mode 25 MP3 Audio Playback 25 Tuner Operation 26 Tape Recording 26 Output Level Trim Adjustment 26 Display Brightness 27 Programming the Remote 27 Direct Code Entry 27 Auto Search Method 27 Code Readout 28 Macro Programming 28 Programmed Device Functions 29 Punch-Through Programming 29 Volume Punch-Through 29 Channel Control Punch-Through 30 Transport Control Punch-Through 30 Reassigning Device Control

Selectors

30 Resetting the Remote Memory 31 Function List 33 Setup Code Tables 42 Troubleshooting Guide 42 Processor Reset 43 Technical Specifications

AVR 120 Audio/VideoReceiver

Typographical Conventions

In order to help you use this manual with the remote control, front panel controls and rear panel connections, certain conventions have been used.

EXAMPLE – (bold type) indicates a specific remote control or front panel button, or rear panel connection jack

EXAMPLE – (OCR type) indicates a message that is visible on the front panel information display 1 – (number in a square) indicates a specific front panel control ¡ – (number in a circle) indicates a rear panel connection

a – (number in an oval) indicates a button or indicator on the remote A – (letter in a square) indicates an indicator in the front panel display

3 INTRODUCTION

Introduction

Thank you for choosing Harman Kardon!

With the purchase of a Harman Kardon AVR 120 you are about to begin many years of listening enjoyment. The AVR 120 has been custom-designed to provide all the excitement and detail of movie soundtracks and every nuance of musical selections.With onboard Dolby* Digital and DTS

decoding, the AVR 120 delivers six discrete channels of audio that take advantage of the digital soundtracks from the latest DVD and LD releases and Digital Television broadcasts.

While complex digital systems are hard at work within the AVR 120 to make all of this happen, hookup and operation are simple. Color-keyed connections and a programmable remote control make the AVR 120 easy to use. To obtain the maximum enjoyment from your new receiver, we urge you to take a few minutes to read through this manual. This will ensure that connections to speakers, source playback units and other external devices are made properly. In addition, a few minutes spent learning the functions of the various controls will enable you to take advantage of all the power the AVR 120 is able to deliver.

If you have any questions about this product, its installation or its operation, please contact your retailer or custom installer. They are your best local sources of information.

Description and Features

The AVR 120 is among the most versatile and multifeatured A/V receivers available, incorporating a wide range of listening options. In addition to Dolby Digital and DTS decoding for digital sources, a broad choice of analog surround modes are available for use with sources such as CD,VCR, TV broadcasts and the AVR 120’s own FM/AM tuner.Along with the latest Dolby Pro Logic* II decoding technology, Dolby 3 Stereo and custom Hall and Theater modes, only Harman Kardon receivers offer Logic 7

to create a wider, more enveloping field environment and more defined fly-overs and pans.Another Harman Kardon exclusive is VMAx

, which uses proprietary processing to create an open, spacious sound field even when only two front speakers are available. Finally, the AVR 120 is among the very few A/V receivers that offer decoding of MP3 data, so that you may listen to the latest music selections directly from compatible computers or playback devices with the power and fidelity you expect from Harman Kardon.

In addition to providing a wide range of listening options, the AVR 120 is easy to configure so that it provides the best results with your speakers and specific listening-room environment.

For the ultimate in flexibility, the AVR 120 features connections for five video devices, all with both composite and S-Video inputs, including the front panel inputs.Two additional audio inputs are available, and a total of six digital inputs make the AVR 120 capable of handling all the latest digital audio sources. Coax and optical digital outputs are also available for direct connection to digital recorders.The AVR 120’s powerful amplifier uses traditional Harman Kardon high-current design technologies to meet the wide dynamic range of any program selection.

Harman Kardon invented the high-fidelity receiver more than forty-seven years ago.With state-of-the-art circuitry and time-honored circuit designs, the AVR 120 is one of the finest receivers ever offered by Harman Kardon.

■ Onboard Dolby Digital and DTS

Decoding Using Crystal

Chip

Technology

■ Harman Kardon’s Exclusive Logic 7 and

VMAx Modes

■ Dolby Laboratories’ Latest Pro Logic II

Decoding Technology

■ MP3 Decoding for Use With Computers

and Digital Audio Players

■ Front Panel Digital Inputs for Easy

Connection to Portable Digital Devices and the Latest Video Game Consoles

■ Multiple Digital Inputs and Outputs

■ Color-Coded Input, Output and

Speaker Terminals Comply With the Latest CEA Standards for Easy Installation

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: To prevent electric shock,

do not use this (polarized)

plug with an extension cord,

receptacle or other outlet

unless the blades can

be fully inserted to

prevent blade exposure.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated

“dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the

literature accompanying the appliance.

4 SAFETY INFORMATION

Safety Information

Important Safety Information

Verify Line Voltage Before Use

Your AVR 120 has been designed for use with 120-volt AC current. Connection to a line voltage other than that for which it is intended can create a safety and fire hazard and may damage the unit.

If you have any questions about the voltage requirements for your specific model, or about the line voltage in your area, contact your selling dealer before plugging the unit into a wall outlet.

Do Not Use Extension Cords

To avoid safety hazards, use only the power cord attached to your unit. We do not recommend that extension cords be used with this product. As with all electrical devices, do not run power cords under rugs or carpets or place heavy objects on them. Damaged power cords should be replaced immediately by an authorized service depot with a cord meeting factory specifications.

Handle the AC Power Cord Gently

When disconnecting the power cord from an AC outlet, always pull the plug, never pull the cord. If you do not intend to use the unit for any considerable length of time, disconnect the plug from the AC outlet.

Do Not Open the Cabinet

There are no user-serviceable components inside this product. Opening the cabinet may present a shock hazard, and any modification to the product will void your guarantee. If water or any metal object such as a paper clip, wire or a staple accidentally falls inside the unit, disconnect it from the AC power source immediately, and consult an authorized service station.

CATV or Antenna Grounding

If an outside antenna or cable system is connected to this product, be certain that it is grounded so as to provide some protection against voltage surges and static charges. Section 810 of the National Electrical Code, ANSI/NFPA No. 70-1984, provides information with respect to proper grounding of the mast and supporting structure, grounding of the leadin wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes and requirements of the grounding electrode.

NOTE TO CATV SYSTEM INSTALLER:This reminder is provided to call the CATV (Cable TV) system installer’s attention to article 82040 of the NEC that provides guidelines for

proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as possible.

Installation Location

■To ensure proper operation and to avoid the

potential for safety hazards, place the unit on a firm and level surface.When placing the unit on a shelf, be certain that the shelf and any mounting hardware can support the weight of the product.

■ Make certain that proper space is provided

both above and below the unit for ventilation. If this product will be installed in a cabinet or other enclosed area, make certain that there is sufficient air movement within the cabinet. Under some circumstances a fan may be required.

■ Do not place the unit directly on a carpeted

surface.

■Avoid installation in extremely hot or cold

locations, or an area that is exposed to direct sunlight or heating equipment.

■Avoid moist or humid locations.

■ Do not obstruct the ventilation slots on the

top of the unit, or place objects directly over them.

Cleaning

When the unit gets dirty, wipe it with a clean, soft, dry cloth. If necessary, wipe it with a soft cloth dampened with mild soapy water, then a fresh cloth with clean water. Wipe dry immediately with a dry cloth. NEVER use benzene, aerosol cleaners, thinner, alcohol or any other volatile cleaning agent. Do not use abrasive cleaners, as they may damage the finish of metal parts.Avoid spraying insecticide near the unit.

Moving the Unit

Before moving the unit, be certain to disconnect any interconnection cords with other components, and make certain that you disconnect the unit from the AC outlet.

Important Information for the User

This equipment has been tested and found to comply with the limits for a Class-B digital device, pursuant to Part 15 of the FCC Rules. The limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio-frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that harmful interference will

not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

■ Reorient or relocate the receiving antenna.

■ Increase the separation between the equip-

ment and receiver.

■ Connect the equipment into an outlet on a

circuit different from that to which the receiver is connected.

■ Consult the dealer or an experienced

radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept interference received, including interference that may cause undesired operation.

NOTE: Changes or modifications may cause this unit to fail to comply with Part 15 of the FCC Rules and may void the user’s authority to operate the equipment.

Unpacking

The carton and shipping materials used to protect your new receiver during shipment were specially designed to cushion it from shock and vibration. We suggest that you save the carton and packing materials for use in shipping if you move, or should the unit ever need repair.

To minimize the size of the carton in storage, you may wish to flatten it. This is done by carefully slitting the tape seams on the bottom and collapsing the carton. Other cardboard inserts may be stored in the same manner. Packing materials that cannot be collapsed should be saved along with the carton in a plastic bag.

If you do not wish to save the packaging materials, please note that the carton and other sections of the shipping protection are recyclable. Please respect the environment and discard those materials at a local recycling center.

At this time you should remove the protective plastic film from the front-panel lens. Leaving the film in place may affect the performance of your remote control.

5 FRONT PANEL CONTROLS

1 Main Power Switch: Press this button to apply power to the AVR 120. When the switch is pressed in, the unit is placed in a Standby mode, as indicated by the amber LED

3 sur-

rounding the

System Power Control 2.

This button MUST be pressed in to operate the unit. To turn the unit off and prevent the use of the remote control, this switch should be pressed until it pops out from the front panel so that the word “OFF” may be read at the top of the switch.

NOTE: This switch is normally left in the “ON” position.

2 System Power Control:When the Main Power Switch

is “ON,” press this button to turn on the AVR 120; press it again to turn the unit off. Note that the

Power Indicator

surrounding the switch will turn green

when the unit is on.

3 Power Indicator:This LED will be illumi- nated in amber when the unit is in the Standby mode to signal that the unit is ready to be turned on. When the unit is in operation, the indicator will turn green. Should the indicator turn red, turn the unit off using the

Main

Power Switch

1 and check the speaker wire connections to make certain that there are no short circuits.

4 Headphone Jack:This jack may be used to listen to the AVR 120’s output through a pair of headphones. Be certain that the headphones have a standard

/4" stereo phone plug. Note that the main room speakers will automatically be turned off when the headphone jack is in use.

5 Selector Buttons: When you are establish- ing the AVR 120’s configuration settings,use these buttons to select from the choices available, as shown in the Main Information Display Û.

6 Tone Mode: Pressing this button enables or disables the Bass and Treble tone controls. When the button is pressed so that the words TONE IN appear in the

Main Information

Display

Û, the settings of the Bass & and

Treble ( controls may be used to adjust the

output signals.When the button is pressed so that the words TONE OUT appear in the

Main

Information Display

Û, the output signal will be “flat,” without any bass or treble alter- ation, no matter how the actual

Bass and

Treble Controls &( are adjusted.

7 Surround Mode Selector: Press this but- ton to change the surround mode by scrolling through the list of available modes. Note that depending on the type of input, some modes are not always available. (See page 22 for more information about surround modes.)

Front Panel Controls

1 Main Power Switch 2 System Power Control 3 Power Indicator 4 Headphone Jack 5 Selector Buttons 6 Tone Mode 7 Surround Mode Selector 8 Tuning Selector 9 Tuner Band Selector ) Preset Stations Selector

! Input Source Selector @ FM Mode Selector # Digital Optical 3 Input $ Digital Coax 3 Input % Video 4 Video Input Jacks ^ Video 4 Audio Input Jacks & Bass Control * Balance Control ( Treble Control Ó Volume Control

Ô Set Button  Input Indicators Ò Delay Ú Digital Input Selector Û Main Information Display Ù Channel Select Button ı Speaker Select Button ˆ Test Tone Selector ˜ Surround Mode Indicators ¯ Remote Sensor Window

)

* &

(



AVR 120

6 FRONT PANEL CONTROLS

Front Panel Controls

8 Tuning Selector: Press the left side of the button to tune lower-frequency stations and the right side of the button to tune higher-frequency stations.When a station with a strong signal is reached, the

TUNED Indicator Q will be

illuminated in the

Main Information

Display

Û .

To tune manually, tap the button lightly and note that the tuner will step up one frequency increment per button press.When the button is held for a few seconds you will note that the unit will quickly search the frequency band. Release it once the fast tuning starts; the tuner will automatically scan for the next station with an acceptable signal and then stop.

9 Tuner Band Selector: Pressing this button will automatically switch the AVR 120 to the Tuner mode. Pressing it again will switch between the AM and FM frequency bands. (See page 25 for more information on the tuner.)

) Preset Stations Selector: Press this button to scroll up or down through the list or stations that have been entered into the preset memory. (See page 26 for more information on tuner presets.)

! Input Source Selector: Press this button to change the input by scrolling up or down through the list of input sources.

@ FM Mode Selector: Press this button to select Auto or Manual tuning. When the button is pressed so that the

AUTO Indicator R

lights, the tuner will search for the next station with an acceptable signal when the

Tuning

Selector

8u is pressed. When the button is

pressed so that the

AUTO Indicator R is not

lit, each press of the

Tuning Selector 8u

will increase the frequency.This button may also be used to switch between Stereo and Mono modes for FM radio reception.When weak reception is encountered, press the button until the

STEREO Indicator P goes out to switch

to Mono reception. Press and hold again to switch back to STEREO mode. (See page 25 for more information on using the tuner.)

# Digital Optical 3 Input: Connect the opti- cal digital output of an audio or video product to this jack. When the input is not in use, be certain to keep the plastic cap installed to avoid dust contamination that might degrade future performance.

$ Digital Coax 3 Input: This jack is used for connection to the output of portable audio devices, video game consoles or other products that have a coax digital jack.

% Video 4 Video Input Jacks: These jacks may be used for temporary connection to the composite or S-Video output of video games, camcorders or other portable video products.

^ Video 4 Audio Input Jacks: These audio jacks may be used for temporary connection to video games or portable audio/video products such as camcorders and portable audio players.

& Bass Control: Turn this control to modify the low-frequency output of the left/right channels by as much as ±10dB, when the unit is in the “Surround Off” mode. Set this control to a suitable position for your taste or room acoustics.

* Balance Control: Turn this control to change the relative volume for the front left/right channels.

NOTE: For proper operation of the surround modes this control should be at the midpoint or “12 o’clock” position.

( Treble Control:Turn this control to modify the high frequency output of the left/right channels by as much as ±10dB, when the unit is in the “Surround Off” mode. Set this control to a suitable position for your taste or room acoustics.

Ó Volume Control: Turn this knob clockwise to increase the volume, counterclockwise to decrease the volume. If the AVR 120 is muted, adjusting the

Volume Control Ó will

automatically release the unit from the silenced condition.

Ô Set Button: When making choices during the setup and configuration process, press this button to enter the desired setting as shown in the

Main Information Display Û into the

AVR 120’s memory. The set button may also be used to change the display brightness. (See page 26.)

 Input Indicators: A green LED will light in front of the input that is currently being used as the source for the AVR 120.

Ò Delay: Press this button to begin the sequence of steps required to enter delay time settings. (See page 19 for more information on delay times.)

Ú Digital Input Selector: When playing a source that has a digital output, press this button to select between the

Optical #d

and Coaxial $e Digital inputs. (See pages 23–25 for more information on digital audio.)

Û Main Information Display: This display delivers messages and status indications to help you operate the receiver. (See pages 7–8 for a complete explanation of the Information Display.)

Ù Channel Select Button: Press this button to begin the process of trimming the channel output levels using an external audio source. (For more information on output level trim adjustment, see page 26.)

ı Speaker Select Button: Press this button to begin the process of configuring the unit to match the type of speakers used in your listening room. (See pages 16–19 for more information on speaker setup and configuration.)

ˆ Test Tone Selector: Press this button to begin the process of adjusting the channel output levels using the internal test tone as a reference. (For more information on output level adjustment, see page 18.)

˜ Surround Mode Indicators: A green LED will light in front of the surround mode that is currently in use.

¯ Remote Sensor Window: The sensor behind this window receives infrared signals from the remote control. Aim the remote at this area and do not block or cover it.

7 FRONT PANEL INFORMATION DISPLAY

Front Panel Information Display

MEM PRESET

SLEEP

AUTOANALOGCOAX 123OPT 123DTS

MP3 PCM

TUNED ST

D PL II 3ST DSP VMAx NF LOGIC 7 CM

KHz

MHz

NIGHT

SL SR

LFE

S RTU Q PO M L

C D E

FG H I

A Bitstream Indicators B DTS Mode Indicator C Dolby Digital Indicator D Dolby Pro Logic II Indicator E Dolby 3 Stereo Indicator F Main Information Display G DSP Mode Indicator H VMAx Mode Indicators

I Logic 7 Mode Indicators J Preset Number/Sleep Timer K Night Mode Indicator L Speaker/Channel Input Indicators M Preset Indicator N Sleep Indicator O Memory Indicator P Stereo Indicator

Q Tuned Indicator R Auto Indicator S Analog Input Indicator T Coaxial Digital Input Indicators U Optical Digital Input Indicators

A Bitstream Indicators: When the input is a

digital source, one of these indicators will light to display the specific type of data signal in use.

B DTS Mode Indicator: This indicator lights when a DTS-encoded source is playing.

C Dolby Digital Indicator: This indicator lights when a Dolby Digital source is being played.

D Dolby Pro Logic II Indicator: This indica- tor lights when the Dolby Pro Logic II mode has been selected.

NOTE: It is possible to see the Dolby Pro Logic II indicator lit simultaneously with the Dolby Digital indicator, even though the Dolby Digital surround mode has been selected. This is due to the specifications for Dolby Digital processing, which require that the Dolby Pro Logic II mode apply any time a 2-channel Dolby signal is detected. If you desire 5.1-channel audio, check the audio settings in the menus for both your DVD player and your DVD disc to make sure that a 5.1-channel Dolby Digital sound track is available and has been selected.

E Dolby 3 Stereo Indicator: This indicator lights when the Dolby 3 Stereo mode has been selected.

F Main Information Display: This display shows messages relating to the status, input source, surround mode, tuner, volume level or other aspects of the AVR 120’s operation.

G DSP Mode Indicator: This indicator lights when any of the surround modes created by Digital Signal Processing, or DSP are in use. These modes include Hall 1, Hall 2,Theater and 5-Channel Stereo.

H VMAx Mode Indicators: This indicator lights when the VMAx mode is in use. VMAx F appears when the Far Field VMAx mode is selected;

VMAx N appears when the Near Field VMAx mode is selected. (See page 22 for a description of the VMAx modes.)

I Logic 7 Mode Indicators: These indica- tors light when the Logic 7 mode is in use. LOGIC 7C appears for the Cinema version of Logic 7;

LOGIC 7M appears for the Music version of Logic 7. (See page 22 for a description of the Logic 7 modes.)

J Preset Number/Sleep Timer: When the tuner is in use, these numbers indicate the specific preset memory location in use. (See page 26 for more information on preset stations.) When the Sleep function is in use, these numbers show how many minutes remain before the unit goes into the Standby mode.

K Night Mode Indicator: This indicator lights when the AVR 120 is in the Night mode, which preserves the dynamic range of digital program material at low volume levels.

L Speaker/Channel Input Indicators: These indicators are multipurpose, indicating either the speaker type selected for each channel or the

incoming data-signal configuration.The left, center, right, right surround and left surround speaker indicators are composed of three boxes, while the subwoofer is a single box. The center box lights when a “small” speaker is selected, and the two outer boxes light when “large” speakers are selected.When none of the boxes are lit for the center, surround or subwoofer channels, no speaker has been assigned to one of those positions. (See page 17 for more information on configuring speakers.) The letters inside each of the center boxes display active input channels. For standard analog inputs, only the L and R will light, indicating a stereo input. When a digital source is playing, the indicators will light to display the channels being received at the digital input. When the letters flash, the digital input has been interrupted. (See pages 18–19 for more information on the Channel Indicators.)

M Preset Indicator: This indicator lights when the tuner is in use to show that the Preset Number/Sleep Timer J is showing the station’s preset memory number. (See page 26 for more information on tuner presets.)

N Sleep Indicator: This indicator lights when the Sleep function is in use.The numbers in the Preset Number/Sleep Timer Indicators will show the minutes remaining before the AVR 120 goes into the Standby mode. (See page 21 for more information on the Sleep function.)

8 FRONT PANEL INFORMATION DISPLAY

Front Panel Information Display

Memory Indicator: This indicator flashes

when entering presets and other information into the tuner’s memory.

P Stereo Indicator: This indicator lights when an FM station is being tuned in stereo.

Tuned Indicator:

This indicator lights when a station is being received with sufficient signal strength to provide acceptable listening quality.

R Auto Indicator: This indicator lights when the tuner’s Auto mode is in use.

S Analog Input Indicator: This indicator lights when an analog input source has been selected.

T Coaxial Digital Input Indicators: These indicators light to show when a Coaxial Digital Input has been selected.

U Optical Digital Input Indicators: These indicators light to show when an Optical Digital Input has been selected.

9 REAR PANEL CONNECTIONS

Rear Panel Connections

AC INPUT

~120V/60HZ A

TAPE

FRONT SPKRS (8Ω)

RIGHT LEFT

CENTER

SPKR (8Ω)

ANTENNA

DIGITAL IN

DIGITAL OUT

VID 3 VID 3

VID 2

OPT

COAX

VID 1 VID 1

DVD DVD

MON.

OUT

GND

75Ω

OUT

L R L R

VIDEO S-VIDEO

–

SURR. SPKRS (8Ω)

SERIAL NO.

RIGHT LEFT

›ﬁ

ﬂ

‡

•

‚

™

∞ ¶

⁄

SUBWOOFER

‹

MODEL NO. AVR 120

¡ Tape Inputs ™ Tape Outputs £ Video 1 Audio Inputs ¢ AM Antenna ∞ Video 1 Audio Outputs

§ DVD Audio Inputs ¶ FM Antenna

• CD Inputs ª Optical Digital Output ‚ Coaxial Digital Output

⁄ DVD Video Inputs ¤ Video Monitor Outputs ‹ Subwoofer Output › Front Speaker Outputs ﬁ Surround Speaker Outputs ﬂ Switched AC Accessory Outlet ‡ Unswitched AC Accessory Outlet ° AC Power Cord

· Video 1 Video Outputs a Video 1 Video Inputs

b Video 2 Video Inputs c Video 3 Video Inputs d Optical Digital Inputs e Coaxial Digital Inputs f Video 3 Audio Inputs g Video 2 Audio Inputs

10 REAR PANEL CONNECTIONS

Rear Panel Connections

¡ Tape Inputs: Connect these jacks to the PLAY/OUT jacks of an audio recorder.

™ Tape Outputs: Connect these jacks to the RECORD/INPUT jacks of an audio recorder.

£ Video 1 Audio Inputs: Connect these jacks to the

PLAY/OUT audio jacks on a VCR

or other video source.

¢ AM Antenna: Connect the AM loop antenna supplied with the receiver to these terminals. If an external AM antenna is used, make connections to the

AM and GND terminals in accordance

with the instructions supplied with the antenna.

∞ Video 1 Audio Outputs: Connect these jacks to the

RECORD/INPUT audio jacks on

a VCR.

§ DVD Audio Inputs: Connect these jacks to the analog audio jacks on a DVD or other video source.

NOTE: The default setting for the audio input associated with DVD is the

Coaxial Digital

Input 1

e. If you connect the audio outputs of a DVD player to these jacks, change the input setting as shown on page 20.

¶ FM Antenna: Connect the supplied indoor or an optional external FM antenna to this terminal.

• CD Inputs: Connect these jacks to the out- put of a compact disc player or CD changer.

ª Optical Digital Output: Connect this jack to the matching digital input connector on a digital recorder such as CD-R or MiniDisc recorder.

‚ Coaxial Digital Output: Connect this jack to the matching digital input connector on a digital recorder such as a CD-R or MiniDisc recorder.

⁄ DVD Video Inputs: Connect these jacks to the composite or S-Video output jacks on a DVD or other video source.

¤ Video Monitor Outputs: Connect this jack to the composite or S-Video input of a TV monitor or video projector to view the output of any standard video source selected by the receiver’s video switcher.

‹ Subwoofer Output: Connect this jack to the line-level input of a powered subwoofer. If an external subwoofer amplifier is used, connect this jack to the subwoofer amplifier input.

› Front Speaker Outputs: Connect these outputs to the matching + or – terminals on your front speakers.When making speaker connections, always make certain to maintain correct polarity by connecting the black terminal to the negative (–) terminal on the speakers. Connect the white terminal to the positive (+) terminal on the left front speaker, the red terminal to the positive (+) terminal on the right front speaker and the green terminal to the positive (+) terminal on the center front speaker. Newer speakers will have matching color terminals in accordance with the new CEA specifications, while existing speakers typically use a red terminal for the positive (+) speaker wire connection. (See page 14 for more information on speaker polarity.)

ﬁ Surround Speaker Outputs: Connect these outputs to the matching + or – terminals on your left and right surround speakers.When making speaker connections always make certain to maintain correct polarity by connecting the black terminal to the negative (–) terminal on the speakers. Connect the blue terminal to the positive (+) terminal on the left surround speaker and the gray terminal to the positive (+) terminal on the right surround speaker. Newer speakers will have matching color terminals in accordance with the new CEA specifications, while existing speakers typically use a red terminal for the positive (+) speaker wire connection. (See page 14 for more information on speaker polarity.)

ﬂ Switched AC Accessory Outlet: This outlet may be used to power any device you wish to have turned on when the AVR 120 is turned on with the

System Power Control

Switch

‡ Unswitched AC Accessory Outlet: This outlet may be used to power any AC device. The power will remain on at this outlet regardless of whether the AVR 120 is on or off.

NOTE: The total power consumption of all devices connected to the accessory outlets should not exceed 100 watts.

° AC Power Cord: Connect the AC plug to an unswitched AC wall output.

· Video 1 Video Outputs: Connect these jacks to the

RECORD/INPUT composite or

S-Video jack on a VCR.

a Video 1 Video Inputs: Connect these jacks to the

PLAY/OUT composite or S-Video

jacks on a VCR or other video source.

b Video 2 Video Inputs: Connect these jacks to the

PLAY/OUT composite or S-Video

jacks on a TV, VCR or other video source.

c Video 3 Video Inputs: Connect these jacks to the

PLAY/OUT composite or S-Video

jacks on a cable television box, satellite dish receiver, VCR or other video source.

d Optical Digital Inputs: Connect the opti- cal digital output from a DVD player, HDTV receiver, LD player, satellite receiver, cable box, MiniDisc player or recorder, or CD player to these jacks.The signal may be either a Dolby Digital signal, a DTS signal or a standard PCM digital source.

e Coaxial Digital Inputs: Connect the coax digital output from a DVD player, HDTV receiver, LD player, satellite receiver, cable box, MiniDisc recorder or CD player to these jacks.The signal may be either a Dolby Digital signal, DTS signal or a standard PCM digital source. Do not connect the RF digital output of an LD player to these jacks.

f Video 3 Audio Inputs: Connect these jacks to the

PLAY/OUT audio jacks on a VCR,

satellite receiver, cable box, video game or other composite video source.

g Video 2 Audio Inputs: Connect these jacks to the

PLAY/OUT audio jacks on a VCR,

satellite receiver, cable box, video game or other composite video source.

11 REMOTE CONTROL FUNCTIONS

●

Remote Control Functions

POWER

MUTE

AVR

DVD

AM/FM

TAPE

VID 2

VCR

CBL/SAT

VID 4VID 1

VID 3

OFF

SLEEP

T/V

SURR.

CH.

VOL.

SET

TUN-M

MEM

D.SKIP

DIRECT

TUNING

PRESET

CLEAR

TEST

NIGHT

120

SKIP

a Power Off Button b IR Transmitter Window c Program Indicator d Power On Button e Input Selectors f AVR Selector g AM/FM Tuner Select h Test Button i Sleep Button j Surround Mode Selector k Night Mode l Channel Select Button m⁄Button n‹Button o Set Button p Digital Select q¤Button r Numeric Keys s Tuner Mode t Direct Button u Tuning Up/Down v Macro Buttons w Transport Controls x Skip Up/Down Buttons y Disc Skip Button z Preset Up/Down ` Clear Button

Memory Button

Delay/Prev. Ch.

›

Button

Speaker Select

Spare Button

Volume Up/Down

TV/Video Selector

Mute

NOTE: The function names shown here refer to each button’s feature when used with the AVR 120. Most buttons have additional functions when used with other devices. See pages 31–32 for a list of these functions.

12 REMOTE CONTROL FUNCTIONS

Remote Control Functions

IMPORTANT NOTE: The AVR 120’s remote

may be programmed to control up to eight devices, including the AVR 120. Before using the remote, it is important to remember to press the Input Selector Button e that corresponds to the unit you wish to operate. In addition, the AVR 120’s remote is shipped from the factory to operate the AVR 120 and most Harman Kardon CD or DVD players and cassette decks.The remote is also capable of operating a wide variety of other products using the control codes that are part of the remote. Before using the remote with other products, follow the instructions on pages 27–30 to program the proper codes for the products in your system.

It is also important to remember that many of the buttons on the remote take on different functions, depending on the product selected using the Device Control Selectors.The descriptions shown here primarily detail the functions of the remote when it is used to operate the AVR 120. (See pages 31–32 for information about alternate functions for the remote’s buttons.)

a Power Off Button: Pressing this button turns off (places in the Standby mode) the device that was last selected by pressing one of the Input Selectors e.To place the AVR 120 in the Standby mode, first press the

AVR Selector

Button

f and then press this button.

b IR Transmitter Window: Point this win-

dow towards the AVR 120 when pressing buttons on the remote to make certain that infrared commands are properly received.

c Program Indicator: This three-color indi- cator is used to guide you through the process of programming the remote. (See pages 27–30 for information on programming the remote.)

d Power On Button: Press this button to turn on power to the device that was last selected by pressing one of the

Input Selectors e. To turn on the AVR 120, press the AVR Selector Button

e Input Selectors: Pressing one of these

buttons will perform three actions at the same time. First, if the AVR 120 is not turned on, this will power up the unit. Next, it will select the source shown on the button as the input to the AVR 120. Finally, it will change the remote control so that it controls the device selected. After pressing one of these buttons you must press the

AVR Selector Button f again to oper-

ate the AVR 120’s functions with the remote.

f AVR Selector: Pressing this button will switch the remote so that it will operate the AVR 120’s functions. If the AVR 120 is in the Standby mode, it will also turn the AVR 120 on.

g AM/FM Tuner Select: Press this button to select the AVR 120’s tuner as the listening choice. Pressing this button when the tuner is already in use will switch between the AM and FM bands.

h Test Button: Press this button to begin the sequence used to calibrate the AVR 120’s output levels. (See pages 18–19 for more infor- mation on calibrating the AVR 120.)

i Sleep Button: Press this button to place the unit in the Sleep mode.After the time shown in the display, the AVR 120 will automatically go into the Standby mode. Each press of the button changes the time until turn-off in the following order:

Note that this button is also used to change channels on your TV when the TV is selected.

This button is also used to end the process of creating a macro command. (See page 28 for more information on creating macros.)

jSurround Mode Selector: Press this but- ton to begin the process of changing the surround mode.After the button has been pressed, use the

⁄/¤

Buttons mq to select the

desired surround mode. (See page 22 for more information.) Note that this button is also used to tune channels when the TV is selected using the device

Input Selector e. This button is

also used in part of the process of erase stored macro commands. (See page 28 for more information on macros.)

NOTE: The Sleep Button i and Surround Mode Selector

j may also function as the Channel + and – keys when the remote is programmed for use with TVs, cable boxes,VCRs, satellite receivers or other video devices with tuners. See page 29 for information on programming the remote for Channel Control Punch-Through capability so that you may change channels on a separate device when the remote is in AVR mode.

k Night Mode: Press this button to activate the Night mode.This mode is available in specially encoded digital sources, and it preserves

dialog (center channel) intelligibility at low volume levels.

l Channel Select Button: This button is used to start the process of setting the AVR 120’s output levels to an external source. Once this button is pressed, use the

⁄/¤

Buttons mq

to select the channel being adjusted, then press the

Set Button o, followed by the

⁄/¤

Buttons mq again, to change the level set- ting. (See page 26 for more information.)

m⁄Button: This multipurpose button is used to change or scroll through items in the menus, or to change configuration settings such as output levels.When changing an item such as the surround mode or digital input directly, first press the function or mode to be changed (e.g., press the

Surround Mode Selector j to

select a surround mode or the

Digital Select

Button

p to change the digital input) and then press this button to scroll through the list of available choices.

n‹Button: This button is used to change the menu selection or setting during some of the setup procedures for the AVR 120.

o Set Button: This button is used to enter settings into the AVR 120’s memory. It is also used in the setup procedures for delay time, speaker configuration and channel output level adjustment.

p Digital Select: Press this button to assign one of the digital inputs

de#$ to a source. (See page 23 for more information on using digital inputs.)

q¤Button: This multipurpose button is used to change or scroll through items in the menus, or to change configuration settings such as output levels.When changing an item such as the surround mode or digital input directly, first press the function or mode to be changed (e.g., press the

Surround Mode Selector j to

select a surround mode or the

Digital Select

Button

p to change the digital input) and then press this button to scroll through the list of available choices.

r Numeric Keys: These buttons serve as a ten-button numeric keypad to enter tuner preset positions.They are also used to select channel numbers when

TV has been selected on the

remote, or to select track numbers on a CD, DVD or LD player, depending on how the remote has been programmed.

min80min70min60min50min

min

min20min10min

OFF

13 REMOTE CONTROL FUNCTIONS

s Tuner Mode: Press this button when the tuner is in use to select between automatic tuning and manual tuning. When the button is pressed so that the

AUTO Indicator R goes

out, pressing the

Tuning Buttons u8 will

move the frequency up or down in single-step increments.When the FM band is in use, pressing this button when a station’s signal is weak will change to monaural reception. (See page 25 for more information.)

t Direct Button: Press this button when the tuner is in use to start the sequence for direct entry of a station’s frequency. After pressing the button simply press the proper Numeric Keys r to select a station. (See page 25 for more information on the tuner.)

u Tuning Up/Down: When the tuner is in use, these buttons will tune up or down through the selected frequency band. If the

Tuner Mode

Button

s@ has been pressed so that the

AUTO Indicator R is illuminated, pressing and holding either of the buttons for three seconds will cause the tuner to seek the next station with acceptable signal strength for quality reception. When the

AUTO Indicator R is NOT illumi-

nated, pressing these buttons will tune stations in single-step increments. (See page 25 for more information.)

v Macro Buttons: Press these buttons to store or recall a “Macro”, which is a preprogrammed sequence of commands stored in the remote. (See page 28 for more information on storing and recalling macros.)

w Transport Controls: These buttons do not have any functions for the AVR 120, but they may be programmed for the forward/ reverse play operation of a wide variety of CD or DVD players, and audio or video cassette recorders. (See page 30 for more information on programming the Transport Control PunchThrough capability of the remote.)

x Skip Up/Down Button: These buttons have no direct function with the AVR 120, but when used with a compatibly programmed CD or DVD changer they will change the disc currently being played in the changer.

y Disc Skip Button: This button has no direct function for the AVR 120, but is often used when the remote is programmed to operate a CD or DVD changer to change the discs in the changer. (See page 28 for more information on using the remote with other devices.)

z Preset Up/Down: When the tuner is in use, press these buttons to scroll through the stations programmed into the AVR 120’s memory.When some source devices, such as CD players,VCRs and cassette decks, are selected using the device

Input Selectors e, these

buttons may function as Chapter Step or Track Advance.

` Clear Button: Press this button to clear incorrect entries when using the remote to directly enter a radio station’s frequency.

Memory Button: Press this button to enter

a radio station into the AVR 120’s preset memory. Once the

MEMORY Indicator O flashes, you

have five seconds to enter a preset memory location using the

Numeric Keys r (See

page 26 for more information.)

Delay/Prev Ch.: Press this button to

begin the process for setting the delay times used by the AVR 120 when processing surround sound. After pressing this button, the delay times are entered by pressing the

Set Button

o and then using the

⁄/¤

Buttons mq

to change the setting. Press the Set Button o again to complete the process. (See page 19 for more information.)

›

Button: Press this button to change a

setting or selection when configuring many of the AVR 120’s settings.

Speaker Select: Press this button to

begin the process of configuring the AVR 120’s bass management system for use with the type of speakers used in your system. Once the button has been pressed, use the

⁄/¤

Buttons mq to select the channel you wish to set up. Press the

Set Button o and

then select another channel to configure. When all adjustments have been completed, press the

Set Button o twice to exit the

settings and return to normal operation. (See page 17 for more information.)

Spare Button: This button does not have

any function for the operation of the AVR 120, but it is available for use when programmed with the code from another remote. (See page 27 for information on programming the remote with codes for other devices.)

Volume Up/Down: Press these buttons to

raise or lower the system volume. See page 29 for more information on programming the

Volume Control Punch-Through capability of the remote, which allows you to change the AVR 120’s volume while the remote is set to control another device.

TV/Video Selector: This button does not

have a direct function on the AVR 120, but when used with a compatibly programmed VCR, DVD or satellite receiver that has a “TV/Video” function, pressing this button will switch between the output of the player or receiver and the external video input to that player. Consult the owner’s manual for your specific player or receiver for the details of how it implements this function.

Mute: Press this button to momentarily

silence the AVR 120 or TV set being controlled, depending on which device has been selected. When the AVR 120 is muted, press this button or use the

Volume Control Ó to return

to the previous volume level. When the AVR 120 remote is being programmed to operate another device or when a macro command is being programmed, this button is pressed with the

Input

Selector Button

e to begin the programming process. (See page 27 for more information on programming the remote.)

Remote Control Functions

14 INSTALLATION AND CONNECTIONS

System Installation

After unpacking the unit, and placing it on a solid surface capable of supporting its weight, you will need to make the connections to your audio and video equipment.

Audio Equipment Connections

We recommend that you use high-quality interconnect cables when making connections to source equipment and recorders to preserve the integrity of the signals.

When making connections to audio source equipment or speakers it is always a good practice to unplug the unit from the AC wall outlet. This prevents any possibility of accidentally sending audio or transient signals to the speakers that may damage them.

1. Connect the analog output of a CD player to the

CD Inputs •.

NOTE: When the CD player has both fixed and

variable audio outputs it is best to use the fixed output unless you find that the input to the receiver is so low that the sound is noisy, or so high that the signal is distorted.

2. Connect the analog Play/Out jacks of a cassette deck, MD, CD-R or other audio recorder to the

Tape Input Jacks ¡. Connect the analog

Record/In jacks on the recorder to the

Tape

Output Jacks

™ on the AVR 120.

3. Connect the output of any digital sources to the appropriate input connections on the AVR 120 rear panel. Note that the

Optical

and Coaxial Digital Inputs de#$ may be used with a Dolby Digital or DTS source or the output of a conventional CD or LD player’s PCM (S/P-DIF) output. To take advantage of the AVR 120’s built-in MP3-decoding capabilities, you may also connect the digital output of a computer or sound card to this input, provided that the signal from the computer is in the S/P-DIF format. Check your computer or sound card’s instructions to verify the type of output signal or use a transcoder such as the Harman Kardon DAL 150.

4. Connect the

Optical Digital Output ª or

Coaxial Digital Output ‚ on the rear panel of

the AVR 120 to the matching digital input connections on a CD-R or MiniDisc recorder.

5. Assemble the AM Loop Antenna supplied with the unit as shown below. Connect it to the AM and GND Screw Terminals ¢ .

6. Connect the supplied FM antenna to the

Antenna (75 ohm) Connection

¶. The FM antenna may also be an external roof antenna, an inside powered or wire lead antenna or a connection from a cable TV system. Note that if the antenna or connection uses 300-ohm twinlead cable, you must use the 300-ohm-to-75ohm adapter supplied with the unit to make the connection.

7. Connect the front, center and surround Speaker Outputs ›ﬁ to the respective speakers.

To ensure that all the audio signals are carried to your speakers without loss of clarity or resolution, we suggest that you use high-quality speaker cable. Many brands of cable are available and the choice of cable may be influenced by the distance between your speakers and the receiver, the type of speakers you use, personal preferences and other factors.Your dealer or installer is a valuable resource to consult in selecting the proper cable.

Regardless of the brand of cable selected, we recommend that you use a cable constructed of fine, multistrand copper with a gauge of 14 or smaller. Remember that in specifying cable, the lower the number, the thicker the cable.

Cable with a gauge of 16 may be used for short runs of less than ten feet. We do not recommend that you use cables with an AWG equivalent of 18 or higher due to the power loss and degradation in performance that will occur.

Cables that are run inside walls should have the appropriate markings to indicate listing with UL, CSA or other appropriate testing agency standards. Questions about running cables inside walls should be referred to your installer or a licensed electrical contractor who is familiar with the NEC and/or the applicable local building codes in your area.

When connecting wires to the speakers, be certain to observe proper polarity. Remember to connect the “negative” or “black” wire to the same terminal on both the receiver and the

speaker. The AVR 120 is one of the first audio products with the latest CEA-recommended color-coding for speaker terminals.Accordingly, the positive (+) terminal, which was previously red, is now a specific color to assist you in making the correct connections. If your speakers have color-coded connections, match the terminal on the AVR 120 to the like terminal on your speakers. For existing speakers with a red terminal for the positive connection, the connections on the AVR 120 are as follows:

Left Front = White Right Front = Red Center = Green Left Surround = Blue Right Surround = Grey

NOTE: While most speaker manufacturers adhere to an industry convention of using black terminals for negative and red ones for positive, some manufacturers may vary from this configuration. To ensure proper phase and optimal performance, consult the identification plate on your speaker or the speaker’s manual to verify polarity. If you do not know the polarity of your speaker, ask your dealer for advice before proceeding, or consult the speaker’s manufacturer.

We also recommend that the length of cable used to connect speaker pairs be identical. For example, use the same length piece of cable to connect the front-left and front-right or surround-left and surround-right speakers, even if the speakers are a different distance from the AVR 120.

8. Connections to a subwoofer are normally made via a line-level audio connection from the Subwoofer Output ‹ to the line-level input of a subwoofer with a built-in amplifier. When a passive subwoofer is used, the connection first goes to a power amplifier, which will be connected to one or more subwoofer speakers. If you are using a powered subwoofer that does not have line-level input connections, follow the instructions furnished with the speaker for connection information.

Video Equipment Connections

Video equipment is connected in the same manner as audio components.Again, the use of highquality interconnect cables is recommended to preserve signal quality.

1. Connect a VCR’s audio and video Play/Out jacks to the

Video 1 Input Jacks £a on

the rear panel. The Audio and Video Record/In jacks on the VCR should be connected to the

Video 1 Out Jacks ∞· on the AVR 120.

Installation and Connections

15 INSTALLATION AND CONNECTIONS

Installation and Connections

2. Connect the analog audio and video outputs of a satellite receiver, cable TV converter or television set or any other video source to the Video 2 or Video 3 Jacks bcfg.

3. Connect the analog audio and video outputs of a DVD or laser disc player to the DVD Jacks §⁄. When a digital audio con- nection is used for your DVD player, the default connection is the

Coaxial Digital

Input 1 Jack

e. However, the connection

may also be made to any of the

Optical d#

or Coaxial e$ Digital Inputs, provided that the digital input source selection is changed as shown on page 23.

4. Connect the digital audio outputs of a DVD player, satellite receiver, cable box or HDTV converter to the appropriate

Optical or Coaxial

Digital Inputs

de#$.

5. Connect the

Video Monitor Output ¤

jacks on the receiver to the composite or S-Video input of your television monitor or video projector.

Video Connection Note:

• Composite and S-Video signals may only be viewed in their native formats.

Power Connections

This unit is equipped with two accessory AC outlets.They may be used to power accessory devices, but they should not be used with highcurrent draw equipment such as power amplifiers.The total power draw to each outlet may not exceed 100 watts.

The

Switched AC Accessory Outlet ﬂ will

receive power only when the unit is on. This is recommended for devices that have no power switch or a mechanical power switch that may be left in the “ON” position.

NOTE: Many audio and video products go into a Standby mode when they are used with switched outlets, and cannot be fully turned on using the outlet alone without a remote control command.

The

Unswitched AC Accessory Outlet ‡

will receive power as long as the unit is plugged into a powered AC outlet.

Finally, when all connections are complete, plug the

Power Cord ° into a nonswitched

120-volt AC wall outlet. You’re almost ready to enjoy the AVR 120!

16 SYSTEM CONFIGURATION

System Configuration

When all audio, video and system connections have been made, there are a few configuration adjustments that must be made.A few minutes spent to correctly configure and calibrate the unit will greatly add to your listening experience.

Speaker Selection and Placement

The placement of speakers in a multichannel home theater system can have a noticeable impact on the quality of sound reproduced.

No matter which type or brand of speakers is used, the same model or brand of speaker should be used for the left front, center and right front speakers.This creates a seamless front soundstage and eliminates the possibility of distracting sonic disturbances that occur when a sound moves across mismatched front-channel speakers.

Speaker Placement

Depending on the type of center-channel speaker in use and your viewing device, place the center speaker either directly above or below your TV, or in the center behind a perforated front projection screen.

Once the center-channel speaker is installed, position the left front and right front speakers so that they are as far away from one another as the center-channel speaker is from the preferred listening position. Ideally, the front-channel speakers should be placed so that their tweeters are no more than 24" above or below the tweeter in the center-channel speaker.

Depending on the specifics of your room acoustics and the type of speakers in use, you may find that imaging is improved by moving the left front and right front speakers slightly forward of the center-channel speaker. If possible, adjust all front loudspeakers so that they are aimed at ear height when you are seated in the listening position.

Using these guidelines, you’ll find that it takes some experimentation to find the correct location for the front speakers in your particular installation. Don’t be afraid to move things around until the system sounds correct. Optimize your speakers so that audio transitions across the front of the room sound smooth, and that sounds from all speakers appear to arrive at the

C) Optimal placement of surround speaker

listening position at the same time (without delay from the center speaker compared to the left and right speakers).

Surround speakers should be placed on the side walls of the room, at or slightly behind the listening position. The center of the speaker should face into the room. The speakers should be located so that the bottom of the cabinet is at least two feet higher than the listeners’ ears when the listeners are seated in the desired area.

If side-wall mounting is not practical, the speakers may be placed on a rear wall, behind the listening position. Again, they should be located so that the bottom of the cabinet is at least two feet higher than the listeners’ ears. The speakers should be no more than six feet behind the rear of the seating area.

Subwoofers produce nondirectional sound, so they may be placed almost anywhere in a room. Actual placement should be based on room size and shape and the type of subwoofer used. One method of finding the optimal location for a subwoofer is to begin by placing it in the front of the room, about six inches from a wall, or near the front corner of the room. Another method is to temporarily place the subwoofer at your normal listening position, and then walk around the room until you find a spot where the subwoofer sounds best. Place the subwoofer in that spot. You should also follow the instructions of the subwoofer’s manufacturer, or you may wish to experiment with the best location for a subwoofer in your listening room.

Once the speakers have been placed in the room and connected, the remaining steps in the setup process are to program the AVR 120’s bass management system for the type of speakers used in your system, calibrate the output levels, and set the delay times used by the surround sound processor.

A) Front-Channel Speaker Installation with Direct-View TV Sets or Rear-Screen Projectors

B) The distance between the left and right speakers should be equal to the distance from the seating position to the viewing screen. You may also experiment with placing the left and right speakers slightly forward of the center speaker.

Center Front Speaker

No more than 24"

Left Front

Speaker

Right Front Speaker

TV or Projection Screen

Left Front

Speaker

Center Front

Speaker

No more than 6 feet

when rear-mounted

speakers are used

Optional Rear-Wall Mounting

Right Front

Speaker

At least 6 inches from ceiling

At least 2 feet

17 SYSTEM CONFIGURATION

You are now ready to power up the AVR 120 to begin these final adjustments.

1. Plug the

Power Cord ° into an

unswitched AC outlet.

2. Press the

Main Power Switch 1 in until

it latches and the word “OFF” on the top of the switch disappears inside the front panel. Note that the

Power Indicator 3

will turn amber, indicating that the unit is in the Standby mode.

3. Remove the protective plastic film from the front-panel lens. If left in place, the film may affect the performance of your remote control.

4. Install the three supplied AAA batteries in the remote as shown. Be certain to follow the (+) and (–) polarity indicators that are on the bottom of the battery compartment.

5. Turn the AVR 120 on either by pressing the System Power Control 2 on the front panel, or via the remote by pressing the

AVR Selector f or any of the Input Selectors

eg on the remote. The

Power Indicator 3 will turn green to confirm that the unit is on, and the

Main

Information Display Û will also light up.

System Setup

The AVR 120 features an advanced memory system that enables you to establish different configurations for the bass management, digital input, surround mode, delay times and output levels for each input source.This flexibility enables you to custom-tailor the way in which you listen to each source and have the AVR 120 memorize those settings.This means, for example, that you may use different output levels or trims for different sources, or set different speaker configurations with the resultant changes to the bass management system. Once these settings are made, they will automatically be recalled whenever you select that input.

The factory default settings for the AVR 120 have all inputs configured for an analog source (except for the DVD input, which has the Coaxial Digital Input 1 e as the default), Stereo as the surround mode, all speaker positions set to “small,” and a subwoofer connected. Before using the unit, you will probably want to change the settings for most inputs so that they are properly configured to reflect the use of digital or analog inputs, the type of speakers installed and the surround mode specifics. Remember that since the AVR 120 memorizes the settings for each input individually, you will need to make these adjustments for each input used. However, once they are made, further adjustment is only required when system components are changed.

Once you have completed the settings for the first input, many settings may be duplicated for the remaining inputs. Remember that once the settings are entered for one input, they must be completed for all other input sources in your system.

Speaker Setup

These adjustments tell the AVR 120 which type of speakers are in use.This is important as it adjusts the settings that determine which speakers receive low-frequency (bass) information. For each of these settings use the LARGE setting if the speakers for a particular position are traditional full-range loudspeakers that are capable of reproducing sounds below 100Hz. Use the

SMALL setting for smaller, frequency-limited satellite speakers that do not reproduce sounds below 100Hz. Note that when “small” speakers are used, a subwoofer is required to reproduce low-frequency sounds. Remember that the “large” and “small” descriptions do not refer to the actual physical size of the speakers, but to their ability to reproduce low-frequency sounds. If you are in doubt as to which category describes your speakers, consult the specifications in the speakers’ owner’s manual, or ask your dealer.

With the AVR 120 turned on, follow these steps to configure the speakers:

1. Put the AVR 120 in the Dolby Pro Logic II

mode by pressing the

Surround Mode

Selector

7 on the front panel or by press-

ing the

Surround Mode Selector j on

the remote, until

PRO LOGIC II

appears in the Main Information Display F and the Pro Logic II Indicator D lights.

2. Press the

Speaker Select Button

on the remote or front panel. The words FNT SPEAKER will appear in the Main Information Display F.

3. Press the

Set Button o .

4. Press the

▲/▼ Buttons mq on the

remote or the

Selector Buttons 5 on the

front panel until either

LARGE or

SMALL appears, matching the type of

speakers you have at the left-front and rightfront positions, as described by the definitions shown in the preceding section.

When

SMALL is selected, low-frequency sounds will be sent to the subwoofer output only. Note that if you choose this option, and there is no subwoofer connected, you will not hear any low-frequency sounds from the front channels.

When

LARGE is selected, a full-range output will be sent to the front-left and frontright outputs, and NO low-frequency signals will be sent to the subwoofer output.

5. When you have completed your selection for the front channel, press the

Set Button

o , and then press the ▲/▼ Buttons mq on the remote or the Selector

Buttons

5 on the front panel to change

the display to

CEN SPEAKER.

6. Press the

Set Button o again, and

use the

▲/▼ Buttons mq on the

remote, or the

Selector Buttons 5 on the

front panel, to select the option that best describes your system based on the speaker definitions shown in the preceding section.

When

CEN SMALL is selected, low-frequency center-channel sounds will be sent to the subwoofer output only. Note that if you choose this option and there is no subwoofer connected, you will not hear any low-frequency sounds from the center-channel speaker.

When

CEN LARGE is selected, a fullrange output will be sent to the centerspeaker output, and NO center-channel signal will be sent to the subwoofer output.

System Configuration

18 SYSTEM CONFIGURATION

System Configuration

NOTE: If you choose Logic 7 as the sur-

round mode for the particular input source for which you are configuring your speakers, the AVR 120 will not make the LARGE option available for the center speaker. This is due to the requirements of Logic 7 processing, and does not indicate a problem with your receiver.

When

CEN NONE is selected, no signals

will be sent to the center-channel output.

7.When you have completed your selection for the center channel, press the

Set Button

o , and then press the ‹/› Buttons n on the remote or the Selector

Buttons

5 on the front panel to change

the display to

SUR SPEAKER.

8.Press the

Set Button o again, and

then use the

▲/▼ Buttons mq on the

remote or the

Selector Buttons 5 on the

front panel to select the option that best describes your system based on the speaker definitions shown in the preceding section.

When

SUR SMALL is selected, lowfrequency surround-channel sounds will be sent to the subwoofer output only. Note that if you choose this option and there is no subwoofer connected, you will not hear any low-frequency sounds from the surround speaker.

When

SUR LARGE is selected, a fullrange output will be sent to the surroundchannel outputs, and NO surround-channel signals will be sent to the subwoofer output.

When

SUR NONE is selected, surround sound information will be split between the front-left and front-right outputs. Note that for optimal performance when no surround speakers are in use, the Dolby 3 Stereo mode should be used instead of Dolby Pro Logic II.

9. When you have completed your selection for the surround channel, press the

Set Button

o , and then press ▲/▼ Buttons mq on the remote or the Selector

Buttons

5 on the front panel to change

the display to

S-W SPEAKER.

10. Press the

Set Button o , and then

press the

▲/▼ Buttons mq on the

remote or the

Selector Buttons 5 on the

front panel to select the option that best describes your system.

The choices available for the subwoofer position will depend on the settings for the other speakers, particularly the front left/right positions.

If the front left/right speakers are set to SMALL, the subwoofer will automatically be set to

SUB, which is the “on” position.

If the front left/right speakers are set to LARGE, three options are available:

• If no subwoofer is connected to the AVR 120, press the

▲/▼ Buttons mq

on the remote so that SUB NONE appears in the Main Information Display F. When this option is selected, all bass information will be routed to the front left/right “main” speakers.

• If a subwoofer is connected to the AVR 120, you have the option to have the front left/right “main” speakers reproduce bass frequencies at all times, and have the subwoofer operate only when the AVR 120 is being used with a digital source that contains a dedicated Low-Frequency Effects, or LFE, soundtrack.This allows you to use both your main and subwoofer speakers to take advantage of the special bass created for certain movies. Press

▲/▼ Buttons

mq on the remote so that SUB (LFE) appears in the Main Information

Display

• If a subwoofer is connected and you wish to use it for bass reproduction in conjunction with the main front left/right speakers, regardless of the type of program source or surround mode you are listening to, press the

▲/▼ Buttons mq on the remote

so that

SUB L/R+LFE appears in the

Main Information Display F. When this option is selected, a “complete” feed will be sent to the front left/right “main” speakers, and the subwoofer will receive bass frequencies below 100Hz.

11. When all speaker selections have been made, press the

Set Button o to

return to normal operation.

Output Level Adjustment

Output level adjustment is a key part of the configuration process for any surround sound product. It is particularly important for a Dolby Digital receiver such as the AVR 120, as correct output levels will ensure that you hear sound tracks in their proper place with the proper directionality and intensity.

IMPORTANT NOTE: Listeners are often confused about the operation of the surround channels.While some assume that sound should always be coming from each speaker, most of the time there will be little or no sound in the surround channels.This is because they are only used when a movie director or sound mixer specifically places sound there to create ambiance, a special effect or to continue action from the front of the room to the rear. When the output levels are properly set, it is normal for surround speakers to operate only occasionally.Artificially increasing the volume to the rear speakers may destroy the illusion of an enveloping sound field that duplicates the way you hear sound in a movie theater or concert hall.

Before beginning the adjustment process, make certain that all speaker connections have been properly made.The system volume should be set to the level that you will use during a typical listening session. Finally, make certain that the

Balance Control * is set to the center

“12 o’clock” position. To assist in making speaker configuration set-

tings, the icons in the

Speaker/Channel

Input Indicators

L change as the speaker type is selected at each position. When only the center icon box containing the abbreviation for the speaker position is lit, the speaker is set for “small.” When the inner box and the two outer boxes are lit, the speaker is set for “large.” When no indicator appears at a speaker location, that position is set for “none” or “no” speaker.

For example, in the following figure, the left front and right front speakers are set for “large,” the center, surround left (SL) and surround right (SR) speakers are set for small, and a subwoofer is set, as shown by the box with the abbreviation “LFE”, which stands for “low- frequency effects.”

19 SYSTEM CONFIGURATION

To adjust and calibrate the output levels, follow these steps. For accurate calibration, it is a good idea to make these adjustments while seated in your favorite listening position:

1.Put the AVR 120 in the Dolby Pro Logic II mode by pressing

Surround Mode

Selector

7 on the front panel, or by

pressing the

Surround Mode Selector

j on the remote, until PRO LOGIC II

scrolls across the Main Information

Display

F and the Pro Logic II

Indicators

D light.

2.Press the

Test Button h on the remote.

T-T FL 0dB will appear in the Main Information Display

F and the letters

FL will flash once each second.

3.The test noise will immediately begin to circulate among the speakers in a clockwise rotation, pausing at each position for three seconds.As the test noise rotates, the speaker position will be shown in the

Main Information Display F. NOTE: This is a good time to verify that

the speakers have been properly connected. As the test noise circulates, listen to make certain that the sound comes from the speaker position shown in the Main Information Display. If the sound from a speaker location does NOT match the position indicated in the display, turn the AVR 120 off using the

Main Power

Switch

1 and check the speaker wiring to make certain that each speaker is connected to the correct output terminal.

4.After checking for speaker placement, let the test noise circulate, and listen to see which channels sound louder than the others. Using the front left (FL in the display) speaker as a reference, press the

▲/▼

Buttons mq on the remote or the Selector Buttons 5 on the front panel

for each channel to begin to bring them to the same level. Note that when one of the buttons is pushed, the test noise circulation will pause on the channel being adjusted to give you time to make the adjustment. When you release the button, the circulation will resume after 15 seconds.

5.Continue to adjust the individual speakers until they all have the same volume. Note that adjustments should be made with the ▲/▼ Buttons mq on the remote or the

Selector Buttons 5 on the front

panel only, NOT the main volume controls. Then press the

Set Button o to

memorize the change. If you are using a sound pressure (SPL) meter for precise level adjustment, set the volume so that the meter reads 75dB, C-Weighting Slow.

NOTE: The subwoofer output level is not adjustable using the test tone.To change the subwoofer level, follow the steps for Output Level Trim Adjustment on page 26.

6.When you have adjusted the output so that all channels have the same level, press the

Test Button h on the remote

to complete the adjustment.

Delay Settings

Due to the different distances between the front-channel speakers and the listening position compared to the surround speakers and the listening position, the amount of time it takes for sound to reach your ears from the front or surround speakers may differ. You may compensate for this difference through the use of the delay settings to adjust the timing to tailor the specific speaker placement and acoustic conditions in your listening room or home theater.

The factory setting is appropriate for most rooms, but some installations create an uncommon distance between the front and surround speakers that may cause the arrival of frontchannel sounds to become disconnected from surround-channel sounds.

To resynchronize the front and surround channels, follow these steps:

1.Measure the distance from the listening/ viewing position to the front speakers.

2.Measure the distance from the listening/ viewing position to the surround speakers.

Subtract the distance to the surround speakers

from the distance to the front speakers.

a. When setting the delay time for the

Dolby Digital surround modes, the optimal delay time is the result of that subtraction. For example, if the front speakers are ten feet away and the surround speakers are five feet away, the optimal delay time is figured as 10–5=5. Thus, in this example, the delay time for Dolby Digital should be set at five milliseconds.

b.When setting the delay time for the

Pro Logic II mode, take the result of the subtraction and add 15 to obtain the optimal delay time. For example, if the front speakers are ten feet away and the surround speakers are five feet away, the optimal delay time is figured as 10–5+15=20. Thus, in this example, the Pro Logic delay should be set at twenty milliseconds.

NOTE: The Theater and Hall modes use a fixed, nonadjustable delay time.

The Dolby Digital mode also includes a separate setting for the center-channel delay mode, since the discrete nature of these signals makes the location of the center-channel speaker more critical. To calculate the delay for the center channel, measure the distance from the preferred listening position in the center of the room to both the center-channel speaker and either the left or right speaker.

If the distances are equal, no further adjustment is required and the center delay should be set to zero. If the distance to the front speakers is greater than the distance to the center speaker, you may wish to reposition the speakers by moving the front-left and front-right speakers closer to the listening position or the center speaker further away from the listening position.

If repositioning of the speakers is not possible, adjust the center delay time, adding one millisecond of center-channel delay for every foot closer to the listening position the center speaker is than the front speaker. For example, if the front-left and front-right speakers are each 10 feet from the listening position and the center-channel speaker is 8 feet away, the delay is figured as 10–8=2, suggesting an optimal center delay of 2 milliseconds.

System Configuration

SL SR

LFE

20 SYSTEM CONFIGURATION

System Configuration

To set the delay times, follow these steps:

1. Put the AVR 120 in the Dolby Pro Logic II mode by pressing the

Surround Mode

Selector

7 on the front panel or by

pressing the

Surround Mode Selector

j on the remote, until PRO LOGIC II appears in the Main Information Display F and the Pro Logic II Indicator D lights up.

2. Press the

Delay Button on

the remote or front panel. The words S DELAY TIME will appear in the Main Information Display F.

3. Press the

Set Button o

4. Adjust the delay time by pressing the ▲/▼

Buttons mq on the remote or the Selector Buttons 5 on the front panel

until the delay time figure calculated using the formula entered above appears in the display.

5. If only analog sources will be used, no adjustment is needed for the center-channel delay. In that case, press the

Set Button

o to enter the surround delay settings into the AVR 120’s memory. However, if you will be using digital sources and the calculations outlined above indicate that the center-channel delay requires an adjustment, continue with the following steps.

6. Before setting the center-channel delay time, make certain that a digital source has been selected.

7. Select the Dolby Digital mode by pressing either the

Surround Mode Selector 7 on the front panel or the Surround Mode Selector

j on the remote, until

DOLBY DIG appears in the Main Information Display

8. Press the

Delay Button on

the remote or front panel. The words S DELAY TIME will appear in the Main Information Display F.

9. Press the

Set Button o , and then

immediately press the

▲/▼ Buttons

mq on the remote or the Selector Buttons

5 on the front panel until the desired delay time for the surround channels is shown in the display.

10. Press the

Set Button o within three

seconds after the desired setting is shown.

11. Press the

▲/▼ Buttons mq on the

remote once so that

C DELAY TIME

appears in the Main Information Display F.

12. Press the the

Set Button o .

13. Press the

▲/▼ Buttons mq on the

remote or the

Selector Buttons 5 on the

front panel until the desired delay time for the center channel appears in the display.

14. Press the

Set Button o to enter the

setting into the AVR 120’s memory.

Additional Input Adjustments

In addition to the major adjustments described in the preceding pages, you may also wish to set the type of audio source type (analog or digital) to be used with an input at this time. Once a specific audio source type is associated with any of the inputs, it will remain in the memory until it is changed, even when another input is selected. To attach one of the digital inputs to a specific source, follow these steps:

1. Press the

Digital Button p .

2. Immediately press the

▲/▼ Buttons

mq or Selector Buttons 5 to scroll through the list of available digital inputs or the analog input.

3. When the desired input type is shown in both the

Main Information Display F and in the Analog S, Coaxial Digital Input

T or Optical Digital Input U

Indicators, press the Set Button o

to enter the setting into the unit's memory.

You may also “memorize” a specific surround mode so that it will always be used when an input is selected. The AVR 120 always remembers the last surround mode used with any input, but during the setup process you may wish to preset the modes for each source.To do that, follow these steps:

1. Select an input by pressing one of the

Input

Selectors

e! or the AM/FM Tuner

Select

2. Press the

Surround Mode Selector

j7, and immediately press the ▲/▼ Buttons mq or Surround Mode Selector

! to scroll through the list of available surround modes. Note that the name of each mode will scroll from right to left across the

Main Information Display

F. To avoid having the system “time out” and exit the select process, be sure to press the

▲/▼ Buttons mq or Surround

Mode Selector

! to select the next mode

at any time the mode name is displayed.

3. When the desired mode name appears in the

Main Information Display F and in the Surround Mode Indicators ,

simply pause for a few seconds to allow the unit to “time out.” Your selection will be memorized and will be activated each time the input is selected until another mode is selected.

4. Repeat the process for each of the inputs.

5. When the desired Surround mode has been entered for all inputs, press the

Set Button

Once the settings outlined on the previous pages have been made, the AVR 120 is ready for operation. While there are some additional settings to be made, these are best done after you have had an opportunity to listen to a variety of sources and different kinds of program material. These settings are described on pages 21 through 26 of this manual. In addition, any of the settings made in the initial configuration of the unit may be changed at any time.As you add new or different sources or speakers, or if you wish to change a setting to better reflect your listening taste, simply follow the instructions for changing the settings for that parameter, as shown in this section.

Having completed the setup and configuration process for your AVR 120, you are about to experience the finest in music and home theater listening. Enjoy!

21 OPERATION

Operation

Basic Operation

Once you have completed the setup and configuration of the AVR 120, it is simple to operate and enjoy.The following instructions will help you maximize the enjoyment of your new receiver:

Turning the AVR 120 On or Off

• When using the AVR 120 for the first time, you must press the

Main Power Switch1on the

front panel to turn the unit on. This places the unit in a Standby mode, as indicated by the amber color of the

Power Indicator3. Once

the unit is in Standby, you may begin a listening session by pressing the

System Power Control

on the front panel or the AVR Selector

f. Note that the Power Indicator3will turn green. This will turn the unit on and return it to the input source that was last used.The unit may also be turned on from Standby by pressing any of the

Input Selector Buttons ef

on the remote or the Input Source

Selector

on the front panel.

NOTE: After pressing one of the Input Selector Buttons

eg to turn the unit on, press the

AVR Selector f to set the remote control to the AVR 120’s functions.

To turn the unit off at the end of a listening session, simply press the

System Power

Control

2 on the front panel or the Power

Off Button

a on the remote. Power will be shut off to any equipment plugged into the rear panel

Switched AC Outlet ﬂ and the

Power Indicator 3 will turn amber.

When the remote is used to turn the unit “off” it is actually placing the system in a Standby mode, as indicated by the amber color of the Power Indicator 3.

• To program the AVR 120 for automatic turnoff, press the

Sleep Button i on the remote. Each press of the button will decrease the time before shut down in the following sequence:

The sleep time will be displayed in the

Preset

Number/Sleep Timer Indicator

J and it

will count down until the time has elapsed.

When the programmed sleep time has elapsed, the unit will automatically turn off. Note that the front panel display will dim to one half brightness when the Sleep function is programmed. To cancel the Sleep function, press and hold the

Sleep Buttoni until

the information display returns to normal brightness, the Sleep indicator numbers disappear and the words

SLEEP OFF

appear in the Main Information Display F.

When you will be away from home for an extended period of time it is always a good idea to completely turn the unit off with the front panel

Main Power Switch1.

NOTE: All preset memories are lost if the unit is

left turned off by using the

Main Power

Switch

for more than two weeks.

Source Selection

• To select a source, press any of the Source Selector Buttons

eg on the remote.

• The input source may also be changed by pressing the front-panel

Input Source

Selector

!. Each press of the button will move the input selection through the list of available inputs.

• As the input is changed, the AVR 120 will automatically switch to the digital input (if selected), surround mode, speaker configuration, output levels and night mode status that were entered during the configuration process for that source.

• The front-panel

Video 4 Inputs

may be used to connect a device such as a video game or camcorder to your home entertainment system on a temporary basis.

• As the input source is changed, the new input name will momentarily appear in the

Main

Information Display

F and a green LED will light next to the selected input’s name in the front panel

Input Indicators .

• When an audio source is selected, the last video input used remains routed to the

Video

1 Output

· and Video Monitor Output

¤. This allows you to listen to an audio input

such as the tuner while watching one of the video inputs.

• When a Video source is selected, the video signal for that input will be routed to the

Video

Monitor Output Jack

and will be viewable

on a TV monitor connected to the AVR 120.

Volume Control

• Adjust the volume to a comfortable level using the front-panel

Volume Control Ó or

remote

Volume Up/Down buttons.

• When listening in the Stereo mode with the surround circuits off, the

Balance Control *

may be used to adjust the relative sound output between the front left and right speakers.

• To temporarily silence all speaker outputs press the

Mute Button . This will inter-

rupt the output to all speakers and the headphone jack, but it will not affect any recording or dubbing that may be in progress. Press the Mute Button again or adjust the volume to return to normal operation.

• During a listening session you may wish to adjust the

Bass Control & and Treble

Control

( to suit your listening tastes or

room acoustics.

• To set the output of the AVR 120 so that the output is “flat,” with the tone controls de- activated, press the

Tone Mode Button 6

until the words Tone Out appear momentarily in the

Main Information Display F.

To return the tone controls to an active condition, press the

Tone Mode Button 6 until

the words

Tone In momentarily appear in

the

Main Information Display F.

• For private listening, plug the 1/4" stereo phone plug from a pair of stereo headphones into the front panel

Headphone Jack4.

Note that when the headphone’s plug is connected, the word

HEADPHONE will scroll

once across the

Main Information Display

F and all speakers will be silenced. When the headphone plug is removed, the audio feed to the speakers will be restored.

min80min70min60min50min

min20min10min

min

OFF

22 OPERATION

Operation

MODE FEATURES DELAY TIME RANGE

DOLBY DIGITAL Available only with digital input sources encoded with Dolby Digital data. It provides Center: 0 ms – 5 ms

up to five separate main audio channels and a special dedicated Low-Frequency Effects Initial Setting – 0 ms channel. Surround: 0 ms –15 ms

Initial Setting – 0 ms

DTS Available only with digital input sources encoded with DTS data. Available on special Delay time not adjustable

DVD, LD and audio-only discs, DTS provides up to five separate main audio channels and a special dedicated low-frequency channel.

DOLBY PRO LOGIC II Dolby Pro Logic II is the latest version of Dolby Laboratory’s benchmark surround technology 15 ms – 30 ms

MOVIE that decodes full-range, discrete left, center, right, right surround and left surround channels Initial Setting = 15 ms MUSIC from either matrix surround encoded programs or conventional stereo sources. EMULATION The Dolby Pro Logic II Movie mode is optimized for movie soundtracks, while the Pro Logic II

Music mode should be used with musical selections.The Pro Logic II Emulation mode creates compelling five-channel surround sound from conventional stereo recordings.

LOGIC 7 C Logic 7 is an advanced mode that extracts the maximum surround information from either Delay time not adjustable LOGIC 7 M surround-encoded programs or conventional stereo material. The Logic 7 C or Cinema mode

should be used with any source that contains Dolby Surround or similar matrix encoding. Logic 7 C delivers increased center-channel intelligibility, and more accurate placement of sounds with fades and pans that are much smoother and more realistic than with other decoding techniques.The Logic 7 M or Music mode should be used with analog or PCM stereo sources. Logic 7 M enhances the listening experience by presenting a wider front soundstage and greater rear ambience. Both Logic 7 modes also direct low-frequency information to the subwoofer (if installed and configured) to deliver maximum bass impact.

DOLBY 3 STEREO Uses the information contained in a surround-encoded or two-channel stereo program to No surround channels

create center-channel information. In addition, the information that is normally sent to the rear-channel surround speakers is carefully mixed in with the front-left and front-right channels for increased realism. Use this mode when you have a center-channel speaker but no surround speakers.

THEATER The THEATER mode creates a sound field that resembles the acoustic feeling of a Delay time not adjustable

standard live performance theater.

HALL 1 The two Hall modes create sound fields that resemble a small (HALL1) or Delay time not adjustable HALL 2 medium sized (HALL 2) concert hall.

VMAx Near When only the two front-channel loudspeakers are used, Harman’s patented VMAx mode No surround channels VMAx Far delivers a three-dimensional sound space with the illusion of “phantom speakers” at the

center and surround positions.The VMAx N, or “Near Field” mode should be selected when your listening position is less than five feet from the speakers.The VMAx F, or “Far Field” mode should be selected when your listening position is greater than five feet from the speakers. The VMAx modes are also available using the

Headphones Output 4. When headphones

are being used, the Far Field mode will appear to push the sound field away from your ears, reducing the “inside the head” sensation often experienced when using headphones.

5-Channel Stereo This mode takes advantage of multiple speakers to place a stereo signal at both the front and No delay is available for

back of a room. Ideal for playing music in situations such as a party, it places the same signal this mode at the front-left and surround-left, and front-right and surround-right speakers. The center channel is fed a summed mono mix of the in-phase material of the left and right channels.

SURROUND This mode turns off all surround processing and presents the pure left- and right- No surround channels OFF (STEREO) channel presentation of two-channel stereo programs.

Surround Mode Chart

23 OPERATION

Operation

Surround Mode Selection

One of the most important features of the AVR 120 is its ability to reproduce a full multichannel surround sound field from digital sources, analog matrix surround-encoded programs and standard stereo programs. In all, a total of fifteen listening modes are available on the AVR 120.

Selection of a surround mode is based on personal taste, as well as the type of program source material being used. For example, motion pictures or TV programs bearing the logo of one of the major surround-encoding processes, such as Dolby Surround, DTS Stereo or UltraStereo

may be played in either the Dolby Digital, Dolby Pro Logic II or Logic 7 Cinema surround modes depending on the source material.

NOTE: Once a program has been encoded with matrix surround information, it retains the surround information as long as the program is broadcast in stereo.Thus, movies with surround sound may be decoded via any of the analog surround modes such as Pro Logic II or Logic 7, when they are broadcast via conventional TV stations, cable, pay TV and satellite transmission. In addition, a growing number of made-fortelevision programs, sports broadcasts, radio dramas and music CDs are also recorded in surround sound. You may view a list of these programs at the Dolby Laboratories Web site at www.dolby.com.

Even when a program is not listed as carrying intentional surround information, you may find that the Pro Logic II, Logic 7,VMAx and the Hall or Theater modes often deliver enveloping surround presentations through the use of the natural information present in all stereo recordings. However, for stereo, but not surround programs, we suggest that you experiment with the other modes.

Surround modes are selected using either the front panel controls or the remote.To select a surround mode from the front panel, press the Surround Mode Selector 7 to scroll up or down through the list of available modes.To select a surround mode using the remote, press the

Surround Mode Selectorj and then

press the

⁄/¤

Buttons mq to change

the mode.As you press the buttons, the Surround mode name will appear in the

Main

Information Display

F, and an individual

mode indicator will also light up

BCDEG

. As the surround modes change, a green

LED will light next to the current mode in the

Surround Mode Indicators ˜ list on the front panel.

NOTE: The name of each Surround Mode will scroll across the

Main Information Display

F while the modes are being selected. To avoid exiting from the surround mode selection process, be certain to push the

▲

or ▼Button

mq while a mode name is still visible.

Note that the Dolby Digital and DTS modes may only be selected when a digital input is in use. In addition, when a digital source is present, the AVR 120 will automatically select and switch to the correct mode (Dolby Digital or DTS), regardless of the mode that has been previously selected. For more information on selecting digital sources, see the following section of this manual.

To listen to a program in traditional two-channel stereo, using the front-left and front-right speakers only (plus the subwoofer if installed and configured), follow the instructions shown above for using the remote until

SURR OFF

appears in the Main Information Display F.

Digital Audio Playback

Digital audio is a major advancement over older analog matrix surround systems. It delivers five discrete channels: left-front, center, right-front, left-surround and right-surround. Each channel reproduces full frequency range (20Hz to 20kHz) and offers dramatically improved dynamic range and significant improvements to signal-to-noise ratios. In addition, digital systems have the capability to deliver an additional channel that is specifically devoted to low-frequency information. This is the “.1” channel referred to when you see these systems described as “5.1”.The bass channel is separate from the other channels, but since it is intentionally bandwidth-limited, sound designers have given it that unique designation.

Dolby Digital

Dolby Digital (originally known as AC-3®) is a standard part of the DVD format, and is also part of the new digital broadcasting system and it is available with many satellite receivers and some digital cable boxes, as well as with specially encoded LD discs.

Note that an optional, external RF demodulator is required to use the AVR 120 to listen to the Dolby Digital sound tracks available on laser discs. Connect the RF output of the LD player to the demodulator and then connect the digital

output of the demodulator to the the

Optical

or Coaxial Inputs de#$ of the AVR

120. No demodulator is required for use with DVD players or DTS-encoded laser discs.

DTS

DTS is another digital audio system that is capable of delivering 5.1 audio.Although both DTS and Dolby Digital are digital, they use different methods of encoding the signals, and thus they require different decoding circuits to convert the digital signals back to analog.

DTS-encoded sound tracks are available on select DVD and LD discs, as well as on special audio-only DTS discs.You may use any LD or CD player equipped with a digital output to play DTS-encoded discs with the AVR 120. All that is required is to connect the player’s output to either the

Optical or Coaxial input on the

rear panel

de or front panel #$.

In order to listen to DVDs encoded with DTS sound tracks, the DVD player must be compatible with the DTS signal as indicated by a DTS logo on the player’s front panel. Note that early DVD players may not be able to play DTSencoded DVDs.This does not indicate a problem with the AVR 120, as some players cannot pass the DTS signal through to the digital outputs. If you are in doubt as to the capability of your DVD player to handle DTS discs, consult the player’s owner’s manual. Please note that some DVD players are shipped with their output set for Dolby Digital only.To insure that DTS data is being sent to the AVR, please check the setup menu system on your DVD player to make certain that DTS data output is enabled.

Selecting a Digital Source

To utilize either digital mode you must have properly connected a digital source to the AVR 120. Connect the digital outputs from DVD players, HDTV receivers, satellite systems or CD players to the

Optical or Coaxial Inputs

de#$. In order to provide a backup sig- nal and a source for analog stereo recording, the analog outputs provided on digital source equipment should also be connected to their appropriate inputs on the AVR 120 rear panel (e.g., connect the analog stereo audio output from a DVD to the

DVD Audio Inputs § on

the rear panel when you connect the source’s digital outputs).

When playing a digital source such as DVD, first select the input using the remote or front panel

24 OPERATION

Operation

controls as outlined in this manual. Next, select the digital source by pressing the

Digital

Input Selector Button

pÚ and then

using the

⁄/¤

Buttons mq on the

remote or the

Selector Buttons 5 on the

front panel to

choose any of the OPTICAL

or COAXIAL

inputs, as they appear in the

Main Information Display F, the Digital Input Indicators

TU. When the digital source is playing, the AVR 120 will automatically detect whether it is a multichannel Dolby Digital or DTS source, an MP3 signal or a conventional PCM signal, which is the standard output from CD players.A

Bitstream

Indicator

A will light in the Main

Information Display

Û to confirm that the

digital signal is Dolby Digital, DTS, PCM or MP3.

Digital Status Indicators

When a digital source is playing, the AVR 120 senses the type of bitstream data that is present. Using this information, the correct surround mode will automatically be selected. For example, DTS bitstreams will cause the unit to switch to DTS decoding, and Dolby Digital bitstreams will enable Dolby Digital decoding. When the unit senses PCM data from CDs or LDs, you may select any of the standard surround modes, such as Dolby Pro Logic II or Logic 7. Since the range of available surround modes is dependent on the type of digital data that is present, the AVR 120 uses a variety of indicators to let you know what type of signal is present. This will help you to understand the choice of modes.

When a digital source is playing, a

Bitstream

Indicator

A will light to show which type of

signal is playing:

: When the DOLBY D indicator lights, a Dolby Digital bitstream is being received. Depending on the settings on the source player and specific surround information and number of channels on the disc, a number of surround modes are possible. For discs with full 5.1 audio, only the Dolby Digital and VMAx modes are available.When the Dolby Digital signal is only two-channel, you may also select from the Logic 7 Cinema/Music, Hall 1/2,Theater, Dolby Pro Logic II Movie, Music or Emulation, or Dolby 3 Stereo Modes.When the AVR 120 senses a 2.0-channel Dolby Digital signal, the unit will automatically select Dolby Pro Logic II as the surround processing mode, and both the

Dolby Digital C and Dolby Pro Logic II D indicators will light in accordance with the

requirements of Dolby Laboratories.

DTS: When the DTS indicator lights, a DTS bitstream is being received. When the unit senses this type of data, only the DTS mode may be used.

PCM: When the PCM indicator lights, a standard Pulse Code Modulation, or PCM, signal is being received. This is the type of digital audio used by conventional compact disc and laser disc recordings.When a PCM bitstream is present, all modes except Dolby Digital and DTS are available.

MP3: When the MP3 indicator lights, a compatible MPEG 1/Layer 3 digital signal is being received. This is the popular audio format used by many computer programs for recording compressed audio files.When an MP3 bitstream is present, the sound will automatically be played in the stereo (surround off) mode.The surround modes are not available during MP3 playback.

In addition to the bitstream indicators, the AVR 120 features a set of unique channel-input indicators that tell you how many channels of digital information are being received and/or whether the digital signal is interrupted.

These indicators are the L/C/R/SL/SR/LFE letters that are inside the center boxes of the Speaker/Channel Input Indicators L in the front panel

Main Information Display

Û. When a standard analog signal is in use, only the “L” and “R” indicators will light, as analog signals have only left and right channels, respectively.

Digital signals, however, may have two, five or six separate channels, depending on the program material, the method of transmission and the way in which it was encoded.When a digital signal is playing, the letters in these indicators will light in response to the specific signal being received. It is important to note that although Dolby Digital, for example, is referred to as a “5.1” system, not all Dolby Digital DVDs or programs are encoded with 5.1 channels. Thus, it is sometimes normal for a DVD with a Dolby Digital soundtrack to trigger only the “L” and “R” indicators.

NOTE: Many DVD discs are recorded with both “5.1” and “2.0” versions of the same soundtrack. When playing a DVD, always be certain to check the type of material on the disc. Most discs show this information in the form of a listing or icon on the back of the disc jacket. When a disc does offer multiple sound track choices you may have to make some adjust-

ments to your DVD player (usually with the “Audio Select” button or in a menu screen on the disc) to send a full 5.1 feed to the AVR 120. It is also possible for the type of signal feed to change during the course of a DVD playback. In some cases the previews of special material will only be recorded in 2.0 audio, while the main feature is available in 5.1 audio. As long as your DVD player is set for 6-channel output, the AVR 120 will automatically sense changes to the bitstream and channel count and reflect them in these indicators.

The letters used by the

Speaker/Channel

Input Indicators

L also flash to indicate when a bitstream has been interrupted. This will happen when a digital input source is selected before the playback starts, or when a digital source such as a DVD is paused. The flashing indicators remind you that the playback has stopped due to the absence of a digital signal and not through any fault of the AVR 120.This is normal, and the digital playback will resume once the playback is started again.

Night Mode

A special feature of Dolby Digital is the Night mode, which enables Dolby Digital input sources to be played back with full dialogue intelligibility while reducing the minimum peak level by

/4 to 1/3. This prevents abruptly loud transitions from disturbing others, without reducing the impact of the digital source.The Night mode is available only when Dolby Digital signals with special data are being played.

The Night mode may be engaged when a Dolby Digital DVD is playing by pressing the

Night

Mode Button

k on the remote. Next, press

the

⁄/¤

Buttons mq to select either the

middle range or full-compression versions of the Night mode.To turn the Night mode off, press the

⁄/¤

Buttons mq until the mes-

sage in the

Main Information Display F

reads D-Range Off. When the Night mode is active, the

Night Mode Indicator K

will also light.

IMPORTANT NOTES ON DIGITAL PLAYBACK:

1. When the digital playback source is stopped,

or in a Pause, Fast Forward or Chapter Search mode, the digital audio data will momentarily stop, and the channel position letters inside the

Speaker/Channel Input

Indicators

L will flash. This is normal and does not indicate a problem with either the AVR 120 or the source machine. The AVR

25 OPERATION

Operation

120 will return to digital playback as soon as the data is available and when the machine is in a standard play mode.

2. Although the AVR 120 will decode virtually all DVD movies, CDs and HDTV sources, it is possible that some future digital sources may not be compatible with the AVR 120.

3. Note that not all digitally encoded programs contain full 5.1-channel audio. Consult the program guide that accompanies the DVD or laser disc to determine which type of audio has been recorded on the disc. The AVR 120 will automatically sense the type of digital surround encoding used and adjust to accommodate it.

4. When a digital source is playing, you may not be able to select some of the analog surround modes such as Dolby Pro Logic II, Dolby 3 Stereo, Hall,Theater or Logic 7.

5. When a Dolby Digital or DTS source is playing, it is not possible to make an analog recording using the

Tape ™ and Video 1

Audio Outputs

∞. However, the digital

signals will be passed through to the

Optical ª and Coaxial ‚ Digital Audio Outputs

PCM Audio Playback

PCM (Pulse Code Modulation) is the noncompressed digital audio system used for compact discs and laser discs.The digital circuits in the AVR 120 are capable of high-quality digital-to-analog decoding, and they may be connected directly to the digital audio output of your CD or LD player.

Connections may be made to either the rear panel

Optical or Coaxial Inputs de or the

front panel

Optical or Coaxial Digital Inputs

#$.

To listen to a PCM digital source,first select the input for the desired source (e.g., CD).Next, press the

Digital Input Selector Úp and

then use the

⁄/¤

Buttons mq on the

remote, or the

Selector Buttons 5 on the

front panel, until the desired choice appears in the

Main Information Display F.

When a PCM source is playing, the

PCM

Indicator A will light. During PCM playback, you may select any surround mode except Dolby Digital or DTS.

Playback from PCM sources may also benefit from the Logic 7 Mode.When playing back a surround-encoded PCM source, such as an LD or surround-encoded CD, use the Logic 7 C or Cinema mode.When playing true stereo recordings, use the Logic 7 M or Music mode for a wider soundstage and increased rearchannel ambience.

NOTE: When a Logic 7 mode is in use with a digital input source which has another mode for its default, that default mode, rather than Logic 7, will be used by the AVR after the digital bitstream is interrupted for any reason such as stopping or pausing the digital playback. Note, also, that Logic 7 is not available with digital playback unless a two-channel bitstream is in use.

MP3 Audio Playback

The AVR 120 is one of the few A/V receivers to provide on-board decoding for the MP3 audio format used by computers and portable audio devices. In addition, some new CD players are capable of playing back optical discs that are recorded with MP3, rather than standard CD audio information. By offering MP3 decoding, the AVR 120 is able to deliver more precise conversion of the digital signals to an analog output, along with the benefits of listening to the MP3 audio through the AVR 120’s highcurrent amplifier and the speakers from your surround system, rather than the smaller speakers and low-powered amplifiers typically used with computers.

To take advantage of the AVR 120’s MP3 capa- bilities, simply connect the PCM output of a computer’s sound card or the PCM output of a portable digital audio device to either the rear panel

Digital Inputs de or the front panel

Digital Inputs #$. As soon as the digital

signal is available, the

MP3 Bitstream

Indicator

A will light, and the audio will

begin playing.

NOTES:

• The AVR 120 only plays signals in the MP3 (MPEG 1/Layer 3) format. It is not compatible with other computer audio codecs.

• The digital audio input signal may be either optical or coaxial, but it must be PCM in the S/P-DIF format. Direct connection of USB or serial data outputs is not possible, even if the signals are in the MP3 format. If you have any questions about the data output format from your computer or a sound card, check with the device’s owner’s manual or contact its manufacturer.

Tuner Operation

The AVR 120’s tuner is capable of tuning AM, FM and FM Stereo broadcast stations. Stations may be tuned manually, or they may be stored as favorite station presets and recalled from a 30-position memory.

Station Selection

1. Press the AM/FM Tuner Select Button

g on the remote to select the tuner as an input. The tuner may be selected from the front panel by either pressing the

Input

Source Selector

! until the tuner is

active or by pressing the

Tuner Band

Selector

2. Press the

AM/FM Tuner Select Button

g or Tuner Band Selector 9 again to switch between AM and FM so that the desired frequency band is selected.

3. Press the

FM Mode Button@s to

select manual or automatic tuning.

When the

AUTO Indicator R is illuminated

in the

Main Information Display Û the

tuner will stop only at those stations that have a strong enough signal to be received with acceptable quality.

When the

AUTO Indicator R is not illumi-

nated, the tuner is in a manual mode and will stop at each frequency increment in the selected band.

4. To select stations, press the

Tuning

Selector Button

u. When the AUTO

Indicator

R is illuminated, press the button for two seconds and then release to cause the tuner to search for the next highest- or lowest-frequency station that has an acceptable signal. When tuning FM stations in the Auto mode, the tuner will select only stereo stations.To tune to the next station, press the button again. If the

STEREO

Indicator P is not illuminated, tap the Tuning Selector Button8u to

advance one frequency increment at a time, or press and hold it to locate a specific station. When the

TUNED Indicator Q

lights, the station is properly tuned and should be heard with clarity.

5. Stations may also be tuned directly by pressing the

Direct Button t, and then press-

26 OPERATION

Operation

ing the Numeric Keysrthat correspond to the station’s frequency. The desired station will automatically be tuned. If you press an incorrect button while entering a direct frequency, press the

Clear Button ` to start

over.

NOTE: When the FM reception of a station is weak, audio quality will be increased by switching to Mono mode by pressing the FM Mode Button@s until the

STEREO Indicator P goes out.

Preset Tuning

Using the remote, up to 30 stations may be stored in the AVR 120’s memory for easy recall using the front panel controls or the remote.

To enter a station into the memory, first tune the station using the steps outlined above. Then:

1. Press the

Memory Button on the

remote. Note that the

MEMORY Indicator

O will be illuminated and flash in the Main Information Display

Û.

2. Within five seconds, press the

Numeric

Keys

r corresponding to the location where you wish to store this station’s frequency. Once entered, the preset number will appear in the

Preset Number/Sleep Time

Display

3. Repeat the process after tuning any additional stations to be preset.

Recalling Preset Stations

• To manually select a station previously

entered in the preset memory, press the Numeric Keys r that correspond to the desired station’s memory location.

• To manually tune through the list of stored

preset stations one by one, press the

Preset

Stations Selector Buttons

)z on the

front panel or remote.

Tape Recording

In normal operation, the audio or video source selected for listening through the AVR 120 is sent to the record outputs.This means that any program you are watching or listening to may be recorded simply by placing machines connected to the outputs for

Tape Outputs ™ or

Video 1 Outputs ∞· in the Record mode.

When a digital audio recorder is connected to the

Optical ª or Coaxial ‚ Digital Audio

Outputs

, you are able to record the digital signal using a CD-R, MiniDisc or other digital recording system.

NOTES:

• The digital outputs are active only when a

digital signal is present, and they do not convert an analog input to a digital signal, or change the format of the digital signal. In addition, the digital recorder must be compatible with the output signal. For example, the PCM digital input from a CD player may be recorded on a CD-R or MiniDisc, but Dolby Digital or DTS signals may not.

• Please make certain that you are aware of

any copyright restrictions on any material you copy. Unauthorized duplication of copyrighted materials is prohibited by federal law.

Output Level Trim Adjustment

Normal output level adjustment for the AVR 120 is established using the test tone, as outlined on pages 18 and 19. In some cases, however, it may be desirable to adjust the output levels using program material such as a test disc, or a selection you are familiar with. Additionally, the output level for the subwoofer can only be adjusted using this procedure.

To adjust the output levels using program material, first set the reference volume for the front-left and front-right channels using the Volume Control Ó .

Once the reference level has been set, press the

Channel Select ButtonlÙ and note

that

FRONT L LEV will appear in the

Main Information Display F. To change the level, first press the

Set Button oÔ ,

and then use the

Selector Buttons 5 or the

⁄/¤

Buttons

to raise or lower the level. DO NOT use the volume control, as this will alter the reference setting.

Once the change has been made, press the

Set

Button

oÔ and then press the Selector

Buttons

5 or the

⁄/¤

Buttons

to select the next output channel location that you wish to adjust. To adjust the subwoofer level, press the

Selector Buttons 5 or the

⁄/¤

Buttons

until WOOFER LEV

appears in the Main Information Display F.

Press the

Set Button oÔ when the name

of the desired channel appears in the

Main

Information Display

F, and follow the

instructions shown earlier to adjust the level.

Repeat the procedure as needed until all channels requiring adjustment have been set. When all adjustments have been made and no further adjustments are made for five seconds, the AVR 120 will return to normal operation.

NOTE: The output levels may be separately trimmed for each digital and analog surround mode. If you wish to have different trim levels for a specific mode, select that mode and then follow the instructions in the steps shown earlier.

Display Brightness

The AVR 120’s Main Information Display

is set at a default brightness that is sufficient for viewing in a normally lit room. However, in some home theater installations, you may wish to occasionally lower the brightness of the display or turn it off completely.

To change the display brightness, press and hold the Set Button on the front panel

for three seconds until the message in the Main Information Display F reads VFD FULL. Within five seconds, press the Selector Buttons 5 on the front panel until the desired display brightness level is shown. At that point, press the

Set Button Ô again to

enter the setting. When

FULL appears in the Main

Information Display

F, the display is at its

normal brightness.When

HALF appears, the display is at half the normal brightness level. When OFF appears, all of the indicators in the Main Information Display F will go dark. Note, however, that the green LEDs for the

Input Indicators and the Surround Mode Indicators , as well as the Power Indicator

3 will always remain lit to remind

you that the AVR 120 is still turned on. Once the desired brightness level is selected, it

will remain in effect until it is changed again or until the unit is turned off.

27 PROGRAMMING THE REMOTE

Programming the Remote

The AVR 120 is equipped with a powerful remote control that will control not only the receiver’s functions, but also most popular brands of audio and video equipment, including CD players, cassette decks, TV sets, cable boxes, VCRs, satellite receivers and other home theater equipment. Once the AVR 120’s remote is programmed with the codes for the products you own, it is possible to eliminate most other remotes and replace them with the convenience of a single, universal remote control.

Programming the Remote

As shipped from the factory, the remote is fully programmed for all AVR 120 functions, as well as those of most Harman Kardon CD changers, DVD players, CD recorders, CD players and cassette decks. In addition,by following one of the methods below, you may program the remote to operate a wide range of devices from other manufacturers.

Direct Code Entry

This method is the easiest way to program your remote to work with different products.

1. Use the tables in the following pages to determine the three-digit code or codes that match both the product type (e.g.,VCR, TV), and the specific brand name. If there is more than one number for a brand, make note of the different choices.

2. Turn on the unit you wish to program into the AVR 120 remote.

3. Press and hold both the

Input Selector

e for the product you wish to control (e.g.,VCR, TV) and the

Mute Button at the same time.When the Program Indicator

c turns amber and begins flashing, release the buttons. It is important that you begin the next step within 20 seconds.

4. Point the AVR 120’s remote towards the unit to be programmed and enter the first threedigit code number using the

Numeric Keys

r. If the unit turns off, the correct code has been entered. Press the

Input Selector e

again, and note that the red light will flash three times before going dark to confirm the entry.

5. If the device to be programmed in does NOT turn off, continue to enter three-digit code numbers until the equipment turns off.At this point, the correct code has been entered. Press the

Input Selector e

again and note that the red light under the Input Selector e will flash three times before going dark to confirm the entry.

6. Try all of the functions on the remote to make certain that the product operates properly. Keep in mind that many manufacturers use a number of different combinations of codes, so it is a good idea to make certain that not only the power control, but the volume, channel and transport controls work as they should. If functions do not work properly, you may need to use a different remote code.

7. If a code cannot be entered to turn the unit off, if the code for your product does not appear in the tables in this manual, or if not all functions operate properly, try programming the remote with the Auto Search Method.

Auto Search Method

If the unit you wish to include in the AVR 120’s remote is not listed in the code tables in this manual or if the code does not seem to operate properly, you may wish to program the correct code using the Auto Search method that follows:

1. Turn on the unit that you wish to include in the AVR 120 remote.

2. Press the

Input Selector e for the type

of product to be entered (e.g.,VCR, TV) and the

Mute Button at the same time.

Hold both buttons until the red light under the

Input Selector e stays lit. Note that

the next step must take place while the red light is on, and it must begin within 20 seconds after the light appears.

3. Point the AVR 120 remote towards the unit to be programmed and press either the

⁄

or ¤Button mq. Each press will send out a series of codes from the remote’s built-in database.When the unit being programmed turns off, release the

⁄or¤

Button mq, as that is your indication that the correct code is in use.

4. Press the

Input Selector e, and note

that the red light under the Input Selector will flash three times before going dark to confirm the entry.

5. Try all of the functions on the remote to make certain that the product operates. Keep in mind that many manufacturers use a number of different combinations of codes, and it is a good idea to make certain

that not only the power control works, but also that the volume, channel and transport controls function properly. If all functions do not work properly, you may need to AutoSearch for a different code, or enter a code via the Direct Code Entry method.

Code Readout

When the code has been entered using the Auto Search method, it is always a good idea to find out the exact code so that it may be easily reentered if necessary.You may also read the codes to verify which device has been programmed to a specific Control Selector button.

1. Press and hold both the

Input Selector

e for the device for which you wish to find the code and the

Mute Button at the same time. Note that the Program Indicator

c will initally turn amber. Release the buttons and begin the next step within 20 seconds.

2. Press the

Set Button o. The Program

Indicator

c will then blink green in a sequence that corresponds to the three-digit code, with a one-second pause between digits. Count the number of blinks between pauses to determine the digit of the code. One blink is the number 1, two blinks is the number 2, and so forth.Ten blinks are used to indicate a “0.”

Example: One blink, followed by a one-second pause, followed by six blinks, followed by a one-second pause, followed by ten blinks indicates that the code has been set to 160.

For future reference, enter the Setup Codes for the equipment in your system here:

DVD ____________ CD ________________

VID1/VCR ________ VID2/TV __________

VID3/CBL/SAT ______________________

VID4 ____________ TAPE ____________

28 PROGRAMMING THE REMOTE

Programming the Remote

Macro Programming

Macros enable you to easily repeat frequently used combinations of commands with the press of a single button on the AVR 120 remote control. Once programmed, a macro will send out up to 19 different remote codes in a predetermined sequential order, enabling you to automate the process of turning on your system, changing devices, or other common tasks. The AVR 120 remote can store up to five separate macro command sequences: one that is associated with the

Power On Button d,

and four more that are accessed by pressing the Macro Buttons v.

1. Press the

Mute Button and the

Macro Button v to be programmed or

the

Power On Button d at the same

time. Note that the last

Input Selector

e pressed will light red, and the

Program Indicator c will flash amber.

2. Enter the steps for the macro sequence by pressing the button for the actual command step.Although the macro may contain up to 19 steps, each button press, including those used to change devices, counts as a step. The

Program Indicator c will flash

green to confirm each button press as you enter commands.

NOTE: While entering commands for Power On/Off of any device during a macro sequence, press the

Mute Button . DO NOT press the

actual Power Button.

3. When all the steps have been entered, press the

Sleep Button i to enter the

commands. The red light under the

Input

Selectors

ef will blink and then

turn off.

Example: To program the Macro 1 Button v so that it turns on the AVR 120,TV and a Cable Box, follow these steps:

• Press the

Macro 1 v and Mute

buttons at the same time and then release them.

• Note that the

Program Indicator c

will flash amber.

• Press the

AVR Selector f.

• Press the

Mute Button to store the

AVR 120’s Power On command.

• Press the

VID2 Input Selector Button

e to indicate the next command is to be transmitted to the TV.

• Press the

Mute Button to store the

TV Power On Command.

• Press the

VID3 Input Selector Button

e to indicate the next command is to be transmitted to the cable box.

• Press the

Mute Button to store the

Cable Power On command.

• Press the

Sleep Button i to complete

the process and store the macro sequence.

After following these steps, each time you press the

Macro 1 Button v, the

remote will send the Power On/Off command to the AVR 120, the television and the cable box with a single button press.

Erasing Macro Commands

To erase the commands that have been programmed into one of the Macro buttons, follow these steps:

1. Press the

Mute Button and the

Macro Button v that contains the

commands you wish to erase.

2. Note that the

Program Indicator c will

flash amber, and the LED under the

AVR

Selector

f will turn red.

3. Within ten seconds, press the

Surround Mode Selector/Channel Down Button

4. The red LED under the

AVR Selector f

will go out, and the Program Indicator

c will turn green and flash three times before it goes out.

5. When the

Program Indicator c goes

out, the Macro has been erased.

Programmed Device Functions

Once the AVR 120’s remote has been programmed for the codes of other devices, press the appropriate

Input Selector e to change

the remote from controlling the AVR 120 to controlling the additional product. When you press any one of the selectors, it will briefly flash in red to indicate that you have changed the device being controlled.

When operating a device other than the AVR 120, the controls may not correspond exactly to the function printed on the remote or button. Some commands, such as the Volume Control, are the same as they are with the AVR 120. Other buttons will change their function so that they correspond to a secondary label on the remote. For example, the Sleep and Surround mode selector buttons also function as the Channel Up and Channel Down

The diagram above shows the button numbers used in the Function List on pages 31 and 32.

29 PROGRAMMING THE REMOTE

Programming the Remote

buttons when operating most TV sets, VCRs or cable boxes.The Channel Up/Down indication is printed directly on the remote. For many standard CD players, cassette decks, VCRs and DVD functions, the standard function icons are printed on top of the buttons.

For some products, however, the function of a particular button does not follow the command printed on the remote. In order to see which function a button controls, consult the Function List tables on pages 31 and 32 To use those tables, first check the type of device being controlled (e.g.,TV, VCR). Next, look at the remote control diagram pictured at the left. Note that each button has a number on it.

To find out what function a particular button has for a specific device, find the button number on the Function List and then look in the column for the device you are controlling. For example, button number 50 is the Macro 1 button for the AVR 120, but it is the “Favorite” button for many cable television boxes and satellite receivers. Button number 29 is the Delay button for the AVR 120, but the Open/Close button for CD players.

NOTE: The numbers used to describe the button functions in the diagram on page 28 for the purposes of describing how a button operates are a different set of numbers than those used in the rest of this manual to describe the button functions for the AVR 120.

Notes on Using the AVR 120 Remote With Other Devices.

• Manufacturers may use different code sets within the same product category, such as TV sets or VCRs. They may also change codes for a certain category from one model year to the next. For that reason, it is important that you check to see whether the code set you have entered operates as many controls as possible. If it appears that only a few functions operate, check to see whether another code set will work with more buttons.

• When a button is pressed on the AVR 120 remote, the red light under the

Input

Selector

e for the product being operated should flash briefly. If the Device Control Selector flashes for some but not all buttons for a particular product, it does NOT indicate a problem with the remote but rather that no function is programmed for the button being pushed.

Punch-Through Programming

The AVR 120's remote may be programmed to control one device, such as a TV, while simultaneously directing only certain functions to another device, such as the transport controls of a DVD player, without having to switch back and forth between inputs.You may also use the remote to control the system volume on the AVR without the need to switch between different devices.This is called "Punch-Through," and this section will show you how to program the remote for these functions.

NOTE: All programming for the remote codes needed to operate specific devices, such as a TV, DVD, cable box, satellite receiver or VCR, should be completed before programming punch-through commands.

Volume Punch-Through

The AVR 120’s remote may be programmed to operate the

Volume Control and Mute

functions of either the TV or the AVR 120 in conjunction with any of the devices controlled by the remote. For example, since the AVR 120 will likely be used as the sound system for TV viewing, you may wish to have the AVR 120’s volume activated, although the remote is set to run the TV. Either the AVR 120 or TV volume control may be associated with any of the remote’s devices. To program the remote for Volume Punch-Through, follow these steps:

1. Press the

Input Selector e for the unit

you will be using (e.g.,TV) when you wish to have Volume Punch-Through to your audio system active and the

Mute Button at

the same time until the red light appears under the

Input Selector e and note that

the

Program Indicator c will flash

amber.

2. Press the

Volume Up Button and

note that the

Program Indicator c will

stop flashing and stay amber.

3. Press either the

AVR Selector f or the

Input Selector e, depending on which

system’s volume control you wish to have attached for the punch-through mode.The Program Indicator c will blink green three times and then go out to confirm the data entry.

Example: To have the AVR 220’s volume control activated even though the remote is set to control the TV, first press the

Video/TV Input Selector e and the Mute Button at the same time. Next,

press the

Volume Up Button , fol-

lowed by the

AVR Input Selector f.

NOTE: Should you wish to return the remote to

the original configuration after entering a Volume Punch-Through,you will need to repeat the steps shown above. However, press the same Input Selector in Steps 1 and 3.

Channel Control Punch-Through

The AVR 120’s remote may be programmed to operate so that the channel control function for either the TV, cable or satellite receiver used in your system may be used in conjunction with one of the other devices controlled by the remote. For example, while using and controlling the VCR, you may wish to change channels on a cable box or satellite receiver without having to change the device selected by the AVR 120 or the remote.To program the remote for Channel Control Punch-Through, follow these steps:

1. Press the

Input Selector Button e for the

device you will be using (e.g.,VCR) when you wish to have Channel Punch-Through active and the

Mute Button at the same time

until the red light appears under the

Input

Selector

e and the Program Indicator

c flashes amber.

2. Press the

Volume Down Button .The

Program Indicator c will stop flashing

and stay amber.

3. Press and release the

Input Selector Button

e for the device that will be used to change the channels.The

Program Indicator c

will blink green three times and then go out to confirm the data entry.

Example: To control the channels using your Cable Box or Satellite Receiver while the remote is set to control the VCR, first press the

VID1/VCR Input Selector Button e

and the Mute Button at the same time. Next, release them and press the

Volume

Down Button

, followed by the

VID2/TV Input Selector Button e.

30 PROGRAMMING THE REMOTE

Programming the Remote

NOTE: To remove the Channel Control Punch-

Through and return the remote to its original configuration, repeat the steps shown above. However, press the same button in Steps 1 and 3.

Transport Control Punch-Through

The AVR 120’s remote may be programmed to operate so that the

Transport Control

Functions

w (Play, Stop, Fast Forward, Rewind, Pause and Record) for a VCR, cassette deck, DVD or CD will operate in conjunction with one of the other devices controlled by the remote. For example, while using and controlling the TV, you may wish to start or stop your VCR or DVD without having to change the device selected by the AVR 120 or the remote. To program the remote for Transport Control Punch-Through, follow these steps:

1. Press the

Input Selector e for the device

you will be using (e.g.,TV) when you wish to have Transport Control Punch-Through active and the

Mute Button at the same time

until the red light appears under the

Input

Selector

e and the Program Indicator

c flashes amber.

2. Press the

Play Button w.The Program

Indicator c will stop flashing and stay amber.

3. Press and release the Input Selector Button

e for the device whose transport mechanism will be controlled (e.g., DVD, CD). The

Program

Indicator

c will blink green three times and

then go out to confirm the data entry.

Example: To control the transport of a DVD player while the remote is set to control the TV, first press the

VID2/TV Input Selector

Button

e and the Mute Button at

the same time. Next, release them and press the

Play Button w, followed by the DVD

Input Selector Button

NOTE: To remove the Channel Control PunchThrough and return the remote to its original configuration, repeat the steps shown above. However, press the same button in Steps 1 and 3.

Reassigning Device Control Selectors

Although each Input Selector e is normally assigned to the category of product shown on the remote, it is possible to reassign one of these buttons to operate a second device of another type. For example,if you have two VCRs but no satellite receiver, you may program the “SAT” button to operate a second VCR.Before following the normal programming steps for either Three-Digit entry or Auto Search code entry, you must first reassign the button with the following steps:

1. Press the

Input Selector e you wish to

reassign and the

Mute Button at the

same time until the red light appears under the

Input Selector e and the Program Indicator

c flashes amber.

2. Press the

Input Selector e for the device

type you wish to program into the reassigned button.

3. Enter the three-digit code for the specific model you wish the reassigned button to operate.

4. Press the same

Input Selector e pressed in

Step 1 once again to store the selection. The red LED under the reassigned Input Selector will flash three times and then go out.

Example: To use the CBL/SAT button to operate a second VCR, first press the

CBL/SAT

Input Selector

e and the Mute Button

at the same time until the red light glows

under the

CBL/SAT Button e. Press the

VCR Button e, followed by the three-digit

code for the specific model you wish to control. Finally, press the

CBL/SAT Button e again.

Resetting the Remote Memory

As you add components to your home theater system, occasionally you may wish to totally reprogram the remote control without the confusion of any commands, macros or ”Punch-Through“ pro- gramming that you may have done.To do this, it is possible to reset the remote to the original factory defaults and command codes by following these steps. Note, however, that once the remote is reset, all commands or codes that you have entered will be erased and will need to be reentered:

1. Press any of the

Input Selector Buttons e

and the ”O“ Button r at the same time until the

Program Indicator c begins to

flash amber.

2. Press the

”3“ Button r three times.

3. The red LED under the

Input Selector e will

go out and the

Program Indicator c will

stop flashing and turn green.

4. The

Program Indicator c will remain green

until the remote is reset. Note that this may take a while,depending on how many commands are in the memory and need to be erased.

5. When the

Program Indicator c goes out,

the remote has been reset to the factory settings.

31 FUNCTION LIST

No. Button Name AVR Function DVD CD/CD-R Tape VCR (VID1) TV (VID1) CBL (VID3) SAT (VID3)

1 Power Off Power Off Power Off Power Off Power Off Power Off Power Off Power Off Power Off 2 Power On Power On Power On Power On Power On Power On Power On Power On Power On 3 Mute Mute Mute Mute Mute Mute Mute Mute Mute 4 AVR AVR Select 5 DVD DVD Input Select DVD Select 6 CD CD Input Select CD Select 7 Tape Tape Input Select Tape Select 8 VID1 Video 1 Select VCR Select

9 VID2 Video 2 Select TV Select 10 VID3 Video 3 Select VID3 Select 11 VID4 Video 4 Select 12 AM/FM Tuner Select 13 Sleep Sleep Channel + Channel + Channel + 14 Test Test Tone Input Select 15

TV/DVD CDP Select TV/VCR TV/VCR TV/Cable TV/Sat

16 Volume Up Volume Up Input Level Up Volume Up Volume Up Volume Up Volume Up 17 Surround Select

Surround Mode Select

CDR Select Channel – Channel – Channel –

18 Night Night Mode Select 19 Spare 20 Volume Down Volume Down

Input Level Down

Volume Down Volume Down Volume Down

21 Channel/Guide Channel Trim Title Info/Guide Info/Guide 22 Speaker/Menu Speaker Adjust Menu Menu Menu Menu Menu 23

⁄

Move/Adjust Up Up Up Up Up Up

ﬁ

Move/Adjust Left Left Left Left Left Left

25 Set Set Enter Enter Enter Enter Enter 26

ﬂ

Right Right Right Right Right

Move/Adjust Down

Down Down Down Down Down

28 Digital/Exit

Digital Input Select

Subtitle Exit Exit Exit Exit

29 Delay/Prev. Ch. Delay Adjust Return Time Prev Channel Prev Channel Prev Channel 30 1 11 1 1 1 1 31 2 22 2 2 2 2 32 3 Iﬁﬁ

33 3 3 3 3

33 4

ﬂﬂ

44 4 4 4 4

34 5 55 5 5 5 5 35 6 66 6 6 6 6 36 7 77 7 7 7 7 37 8 88 8 8 8 8 38 Tun-M Tuner Mode 39 9 99 9 9 9 9 40 0 00 0 0 0 0 41 Memory Memory 42 Tune Up Tune Up Next Chapter 43 Direct Direct Tuner Entry Track Direct 44 Clear Clear Clear Clear Clear Clear Clear Clear

Function List

32 FUNCTION LIST

No. Button Name AVR Function DVD CD/CD-R Tape VCR (VID1) TV (VID1) CBL (VID3) SAT (VID3)

45 Preset Up Preset Tune Up Slow Forward 46 Tune Down Tune Down Prev Chapter

Track Increment

47 D. Skip Disc Skip Disc Skip Stop Stop 48 Preset Down

Preset Tune Down

Slow Rev Intro Scan

49 M1 Open/Close Open/Close Cancel Sleep PPV Cancel 50 M2

Subtitle On/Off

Repeat Fav Fav

51 M3 Audio Select Random Play Bypass Next 52 M4 Angle Select Music Alt 53 Rewind R. Search R. Search Rewind Rewind Day – Day – 54 Play Play Play Play Play 55 Fast Forward F. Search F. Search Fast Fwd Fast Fwd Day + Day + 56 Record Record Record Record 57 Stop Stop Stop Stop Stop 58 Pause Pause Pause Pause Pause 59 Skip Down Skip – Skip – Scan – Page – Page – 60 Skip Up Skip + Skip + Scan + Page + Page +

Function List (continued)

33 SETUP CODES

Manufacturer/Brand Setup Code Number

A MARK 103 132 ADMIRAL 192 AKAI 123 160 AMPRO 164 ANAM 045 103 106 109 112 122 AOC 103 123 128 BLAUPUNKT 084 BROKSONIC 205 206 CANDLE 123 128 CAPEHART 059 CENTURION 123 171 CENTRONIC 045 CITIZEN 045 123 128 132 CLASSIC 045 CONCERTO 128 CONTEC 045 CORANDO 172 CORONADO 132 CRAIG 045 157 158 159 CROWN 045 132 CURTIS MATHES 123 128 132 CXC 045 DAEWOO 045 087 102 105 106 108 111 114 116 119 127 128 132 DAYTRON 128 132 DIGI LINK 200 DYNASTY 045 DYNATECH 063 ELECTROHOME 115 132 EMERSON 045 123 128 132 139 157 158 159 162 205 FUNAI 045 FUTURETECH 045 GE 087 121 123 128 133 145 159 163 GOLDSTAR 101 103 110 128 132 GRUNDIG 193 HALL MARK 128 HARMAN KARDON 201 HITACHI 123 128 132 144 147 INFINITY 148 INKEL 120 JBL 148 JC PENNEY 115 123 128 132 145 JENSEN 019 JVC 079 087 134 KAWASHO 173 KEC 045 KENWOOD 123 204 KMC 132 KTV 045 123 132 162 LLOYTRON 172 173 LODGENET 069 LOGIK 069 LUXMAN 128 LXI 077 145 148 MAGNAVOX 123 128 132 145 148 MARANTZ 115 123 148 MATSUI 148 MEMOREX 069 128 METZ 084

Setup Code Table: TV

34 SETUP CODES

Manufacturer/Brand Setup Code Number

MGA 115 123 128 MINERVA 084 MITSUBISHI 077 115 123 128 160 167 168 MTC 175 176 NATIONAL 148 177 179 180 181 182 NEC 115 121 123 125 NIKEI 045 ONKING 045 ONWA 045 OPTONICA 077 ORION 207 208 209 210 211 PANASONIC 087 148 169 PHILCO 045 115 123 128 132 148 PHILIPS 123 128 132 145 148 PIONEER 024 123 128 213 214 PORTLAND 128 132 PROSCAN 133 PROTON 059 122 128 132 165 QUASAR 087 RADIO SHACK 045 128 132 180 196 197 RCA 115 123 128 133 145 161 163 REALISTIC 045 196 197 RUNCO 152 153 SAA 183 SAMPO 059 123 128 SAMSUNG 124 128 132 145 SANYO 054 SCOTT 045 128 132 SEARS 128 132 145 SHARP 077 128 132 SIEMENS 084 SIGNATURE 069 SONY 117 130 136 194 212 SOUNDESIGN 045 128 SPECTRICON 103 SSS 045 SYLVANIA 123 128 145 148 SYMPHONIC 184 TANDY 077 TATUNG 063 TECHNICS 080 TECHWOOD 128 TEKNIKA 045 069 115 123 128 132 TELERENT 069 TERA 156 THOMSON 190 191 TMK 128 TOSHIBA 063 129 202 TOTEVISION 132 VIDEO CONCEPTS 160 VIDTECH 128 WARDS 069 128 132 148 YAMAHA 123 128 YORK 128 YUPITERU 045 ZENITH 069 090 ZONDA 103

Setup Code Table: TV (continued)

35 SETUP CODES

Manufacturer/Brand Setup Code Number

AIWA 040 AKAI 048 108 109 126 AMPRO 076 ASA 134 AUDIO DYNAMICS 018 048 BROKSONIC 110 147 CANDLE 134 135 CANON 135 140 CAPEHART 094 CITIZEN 134 CRAIG 045 116 DAEWOO 017 094 104 DAYTRON 094 DBX 018 048 DYNATECH 040 EMERSON 013 040 042 110 112 FISHER 017 FUNAI 040 GE 076 095 124 GO VIDEO 113 GOLDSTAR 018 107 HARMAN KARDON 018 049 HITACHI 040 048 JC PENNEY 018 045 JENSEN 048 JVC 018 048 111 132 KENWOOD 020 048 LLOYD 040 LXI 020 040 MAGIN 045 MAGNAVOX 040 MARANTZ 018 MEMOREX 017 020 040 076 MGA 049 MITSUBISHI 049 131 MULTITECH 040 NAD 139 NATIONAL 140 NEC 018 048 NORDMENDE 048 OPTIMUS 159 ORION 147 PANASONIC 125 150 167 172 PHILCO 040 PHILIPS 040 075 PORTLAND 094 PULSAR 076 QUASAR 001 125 RADIO SHACK 134 140 142 158 159 RCA 095 124 125 157 172 REALISTIC 017 020 040 045 159

Setup Code Table: VCR

36 SETUP CODES

Manufacturer/Brand Setup Code Number

SALORA 020 SAMSUNG 045 095 105 109 SANSUI 048 116 147 SANYO 017 020 SCOTT 110 112 SEARS 017 020 SHARP 129 156 SONY 080 129 SOUNDESIGN 040 SYLVANIA 040 SYMPHONIC 040 TANDY 017 040 TASHICO 134 TATUNG 048 TEAC 040 048 TEKNIKA 040 THOMAS 040 TMK 013 TOSHIBA 112 155 TOTEVISION 045 UNITECH 045 VECTOR RESEARCH 018 VIDEO CONCEPTS 018 040 VIDEOSONIC 045 WARDS 040 045 112 YAMAHA 018 040 048 ZENITH 040 076 083

Setup Code Table: VCR (continued)

Setup Code Table: CD Setup Code Table: CD

Manufacturer/Brand Setup Code Number

ADCOM 063 069 AIWA 072 111 118 156 170 AKAI 050 177 184 AUDIO TECHNICA 053 AUDIOACCESS 125 AUDIOFILE 211 BSR 044 CALIFORNIA AUDIO 015 109 CAPETRONIC 070 CARRERA 087 CARVER 136 140 141 143 144 145 185 186 CASIO 117 122 166 CLARINETTE 122 166 DENON 187 188 213 EMERSON 052 093 108 FISHER 055 068 FRABA 117 FUNAI 126 GE 164

37 SETUP CODES

Manufacturer/Brand Setup Code Number

GENEXXA 108 GOLDSTAR 016 087 HAITAI 099 214 HARMAN KARDON 001 002 025 054 190 218 219 HITACHI 093 INKEL 216 JC PENNEY 098 147 JENSEN 153 JVC 176 195 196 KENWOOD 030 062 078 079 148 151 176 178 181 LOTTE 108 LUXMAN 077 102 LXI 164 MAGNAVOX 039 113 MARANTZ 058 084 191 192 193 MCINTOSH 194 MCS 080 098 MITSUMI 152 MODULAIRE 122 166 NAD 013 074 197 198 NAKAMICHI 199 200 201 NEC 069 NIKKO 053 055 ONKYO 037 038 045 046 171 175 202 203 OPTIMUS 065 089 091 092 099 104 212 PANASONIC 015 075 109 119 158 183 204 PHILIPS 039 138 149 209 PIONEER 071 094 100 112 123 131 161 162 215 PROTON 210 QUASAR 015 109 RADIO SHACK 122 126 213 RCA 024 081 093 150 RCX 169 REALISTIC 058 093 095 104 105 108 164 166 SANSUI 047 081 134 157 172 SANYO 033 068 082 095 168 SCOTT 108 SHARP 058 105 114 151 159 167 180 181 SHERWOOD 003 041 058 105 133 SONY 103 115 116 118 132 139 163 205 206 207 208 212 217 SOUNDSTREAM 124 SYMPHONIC 059 110 TAEKWANG 177 TEAC 011 058 085 086 106 107 110 121 137 146 154 THETA DIGITAL 039 TOSHIBA 013 074 097 151 155 173 VECTOR RESEARCH 087 VICTOR 120 130 WARDS 095 YAMAHA 019 031 053 061 135 169 YORK 122 166

Setup Code Table: CD Setup Code Table: CD (Continued)

38 SETUP CODES

Setup Code Table: Tape

Setup Code Table: DVD

Manufacturer/Brand Setup Code Number

APEX DIGITAL 061 DENON 019 051 GE 003 004 GOLDSTAR 005 HARMAN KARDON 001 JVC 006 LG 005 055 064 MAGNAVOX 056 MARANTZ 059 MITSUBISHI 023 NAD 062 ONKYO 009 048 PANASONIC 024 030 044 PHILIPS 056 PIONEER 041 065 PROCEED 060 PROSCAN 003 004 RCA 003 004 SAMSUNG 053 054 SHARP 028 SONY 043 045 THOMSON 003 004 TOSHIBA 009 058 YAMAHA 030 063 ZENITH 005 055 064

Manufacturer/Brand Setup Code Number

HARMAN KARDON 001

39 SETUP CODES

Setup Code Table: SAT

Manufacturer/Brand Setup Code Number

ALPHASTAR 472 ALPHASTAR DBS 450 ALPHASTAR DSR 442 BIRDVIEW 425 CHANNEL MASTER 320 321 322 325 361 CHAPARRAL 315 316 380 451 CITOH 360 DRAKE 313 317 318 413 481 DX ANTENNA 331 352 362 379 483 ECHOSTAR 395 397 452 453 463 477 478 484 485 ELECTRO HOME 392 FUJITSU 324 329 334 GENERAL INSTRUMENT 303 311 323 365 403 454 468 474 HITACHI DBS 455 HOUSTON TRACKER 463 HUGHES 437 JANIEL 366 JERROLD 454 468 484 KATHREIN 410 LEGEND 453 MACOM 317 365 369 370 371 MAGNAVOX 461 473 MEMOREX 453 NEXTWAVE 423 NORSAT 373 OPTIMUS 466 PANASONIC 366 469 PANASONIC DBS 457 PANSAT 420 PERSONAL CABLE 418 PHILIPS 375 PICO 407 PRESIDENT 381 404 PRIMESTAR 412 454 468 475 RCA 301 439 458 465 REALISTIC 349 480 SAMSUNG 442 SATELLITE SERVICE CO 335 388 SCIENTIFIC ATLANTA 339 SONY 405 STAR CHOICE DBS 459 STARCAST 347 SUPER GUIDE 327 423 TEECOM 330 333 390 391 393 409 TOSHIBA 302 426 460 461 462 470 UNIDEN 323 332 348 349 350 351 354 355 381 383 389 403 466 479 480 ZENITH 384 385 387 394 419

40 SETUP CODES

Setup Code Table: CBL

Manufacturer/Brand Setup Code Number

ABC 001 011 ALLEGRO 111 AMERICAST 212 ARCHER 112 BELCOR 113 CABLE STAR 033 113 CITIZEN 111 COLOUR VOICE 085 090 DIGI 114 EAGLE 186 EASTERN 066 070 ELECTRICORD 039 EMERSON 112 FOCUS 116 G.I. 001 011 017 096 097 GC ELECTRONICS 113 GEMINI 032 060 GENERAL 210 GENERAL INSTRUMENT 168 GOODMIND 112 HAMLIN 056 099 100 101 117 175 208 HITACHI 001 188 JASCO 111 JERROLD 001 002 011 017 073 096 097 162 168 188 210 LINDSAY 118 MACOM 191 MAGNAVOX 017 019 068 MOVIE TIME 035 039 NSC 035 190 OAK 197 PACE 179 PANASONIC 053 176 177 189 214 PANTHER 114 PHILIPS 013 019 020 085 090 PIONEER 001 041 119 171 209 POPULAR MECHANICS 116 PRELUDE 120 PRIMESTAR 162 RADIO SHACK 111 112 213 RCA 053 214 RECOTON 116 REGAL 056 099 100 101 208

41 SETUP CODES

Setup Code Table: CBL (continued)

Manufacturer/Brand Setup Code Number

REMBRANT 032 SAMSUNG 072 186 SCIENTIFIC ATLANTA 183 203 SEAM 121 SIGNATURE 001 188 SPRUCER 053 081 177 189 STARCOM 002 011 163 STARGATE 120 TANDY 024 TELECAPATION 028 TEXSCAN 036 TFC 122 TIMELESS 123 TOCOM 170 205 UNITED CABLE 011 UNIVERSAL 033 034 039 042 113 VIDEOWAY 124 211 VIEWSTAR 019 025 086 089 190 ZENITH 065 125 211 ZENTEK 116

42 TROUBLESHOOTING GUIDE

Troubleshooting Guide

SYMPTOM CAUSE SOLUTION

Unit does not function when Main • No AC Power • Make certain AC power cord is plugged into Power Switch is pushed a live outlet

• Check to see whether outlet is switch-controlled

Display lights, but no sound • Intermittent input connections • Make certain that all input and speaker connections or picture are secure

•

Mute is on • Press Mute button

• Volume control is down • Turn up volume control

Unit turns on, but front-panel • Display brightness is turned off • Follow the instructions in the Display Brightness section display does not light up on page 26 so that the display is set to VFD FULL

No sound from any speaker; • Amplifier is in protection mode • Check speaker wire connections for shorts at receiver and light around power switch is red due to possible short speaker ends

• Amplifier is in protection mode • Contact your local Harman Kardon service center, which you can due to internal problems locate by visiting our Web site at www.harmankardon.com

No sound from surround or • Incorrect surround mode • Select a mode other than Stereo or Dolby 3 Stereo center speakers • Input is monaural • There is no surround information from mono sources

• Incorrect configuration • Check speaker mode configuratioin

• Stereo or Mono program material • The surround decoder may not create center- or rear-channel

information from nonencoded programs

Unit does not respond to • Weak batteries in remote • Change remote batteries remote commands • Wrong device selected • Press the AVR selector

• Remote sensor is obscured • Make certain front-panel sensor is visible to remote

or connect remote sensor

Intermittent buzzing in tuner • Local interference • Move unit or antenna away from computers, fluorescent

lights, motors or other electrical appliances

Letters flash in the channel indicator • Digital audio feed paused • Resume play for DVD display and digital audio stops • Check that Digital Input is selected

Processor Reset

In the rare case where the unit’s operation or the displays seem abnormal, the cause may involve the erratic operation of the system’s memory or microprocessor.

To correct this problem, first unplug the unit from the AC wall outlet and wait at least three minutes. After the pause, reconnect the AC power cord and check the unit’s operation. If the system still malfunctions, a system “reset” may clear the problem.

To clear the AVR 120’s entire system memory including tuner presets, output level settings, delay times and speaker configuration data, first put the unit in Standby by pressing the

System Power Control Button 2. Next, simultaneously press and hold the

Tone Mode

6 and the FM Mode Selector @ buttons for three seconds.

The unit will turn on automatically and display the

RESET message in the Main

Information Display

F. Note that once you have cleared the memory in this manner, it is necessary to reestablish all system configuration settings and tuner presets.

NOTE:After a reset, the unit will be returned to the factory presets, and all settings for tuner memory and presets speaker configuration, delay times and surround mode memories must be reentered.

If the system is still operating incorrectly, there may have been an electronic discharge or severe AC line interference that has corrupted the memory or microprocessor.

If these steps do not solve the problem, consult an authorized Harman Kardon service center. You can locate the service center nearest to you by visiting our Web site at www.harmankardon.com.

Memory Backup

This product is equipped with a memory backup system that preserves the system configuration information and tuner presets if the unit is accidentally unplugged or subjected to a power outage.This memory will last for approximately two weeks, after which time all information must be reentered.

Your AVR 120 receiver has been designed to provide many years of trouble-free service. In the event that you are experiencing difficulties, please check the suggestions below for a possible solution to your problem. Additional information on the AVR 120, including updated information and user hints, is available from our Web site at www.harmankardon.com.

43 TECHNICAL SPECIFICATIONS

Technical Specifications

Audio Section

Stereo Mode Continuous Average Power (FTC)

50 Watts per channel, @ < 0.07% THD, 20Hz – 20kHz, both channels driven into 8 ohms

Five-Channel Surround Modes Power Per Individual Channel

Front L&R channels: 40 Watts per channel @ < 0.07% THD, 20Hz–20kHz into 8 ohms

Center channel: 40 Watts @ < 0.07% THD, 20Hz–20kHz into 8 ohms

Surround channels: 40 Watts per channel @ < 0.07% THD, 20Hz–20kHz into 8 ohms

Input Sensitivity/Impedance

Linear (High-Level) 200mV/47k ohms Signal-to-Noise Ratio (IHF-A) 95dB Surround System Adjacent Channel Separation

Pro Logic II 45dB

Dolby Digital (AC-3) 55dB

DTS 55dB

Frequency Response

@ 1W (+0dB, –3dB) 10Hz– 100kHz High Instantaneous

Current Capability (HCC) ±25 Amps Transient Intermodulation

Distortion (TIM) Unmeasurable Slew Rate 40V/µsec

FM Tuner Section

Frequency Range 87.5–108.0MHz Usable Sensitivity IHF 1.3µV/13.2dBf Signal-to-Noise Ratio Mono/Stereo 70dB/68dB Distortion Mono/Stereo 0.2%/0.3% Stereo Separation 40dB @ 1kHz Selectivity ±400kHz, 70dB Image Rejection 80dB IF Rejection 90dB

AM Tuner Section

Frequency Range 520–1710kHz Signal-to-Noise Ratio 45dB Usable Sensitivity Loop 500µV Distortion 1kHz, 50% Mod 0.8% Selectivity ±10kHz, 30dB

Video Section

Television Format NTSC Input Level/Impedance 1Vp-p /75 ohms Output Level/Impedance 1Vp-p/75 ohms Video Frequency

Response 10Hz–8MHz (–3dB)

General

Power Requirement AC 120V/60Hz Power Consumption 68W idle, 540W maximum

(2 channels driven)

Dimensions

Width 17.3 inches (440mm) Height 6.5 inches (165mm) Depth 17.1 inches (435mm)

Weight 31 lb (14.1kg)

Depth measurement includes knobs, buttons and terminal connections. Height measurement includes feet and chassis. All features and specifications are subject to change without notice.

Harman Kardon is a registered trademark, and Power for the Digital Revolution is a trademark, of Harman Kardon, Inc.

*Manufactured under license from Dolby Laboratories.

DTS and DTS Surround are registered trademarks of Digital Theater Systems, Inc.

UltraStereo is a trademark of UltraStereo Corp.

VMAx is a registered trademark of Harman International Industries, Inc., and is an implementation of Cooper Bauck Transaural Stereo under patent license.

Logic 7 is a registered trademark of Lexicon, Inc., a Harman International Company.

Crystal is a registered trademark of Cirrus Logic Corp.

Harman-Kardon AVR 120 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
