Haier LE32M600 User Manual

LED LCD TV

OWNER' S MANUAL

MOD EL: L E 3 2 M 6 0 0

Please RE AD this manual carefully
before op erating your TV, and retain
it for futu re reference

Contents

1、 Safety an d warnings. .. ....... .. ....... .. ....... .. ....... .. ......... ......... ......... .. ....... .. ....... .. ....... .. ....... .. ..2-3

2、 Introdu ction.... .. ....... .. ....... .. ....... .. ....... .. ......... ......... ......... ......... .. ....... .. ....... .. ....... .. ......... .4

3、 Install ation.... .. ....... .. ....... .. ....... .. ....... .. ......... ......... ......... ......... .. ....... .. ....... .. ....... .. ......... .. 5-8

4、 Remote Co ntroller.. ......... ......... ......... ......... .. ....... .. ....... .. ....... .. ......... ......... ......... ......... .. .. 9

5、 TV Op eration .. ....... .. ....... .. ....... .. ......... ......... ......... ......... .. ....... .. ....... .. ....... .. ....... .. ......... ..10-13

6、 Trouble sh ooting... ......... ......... .. ....... .. ....... .. ....... .. ....... .. ......... ......... ......... .. ....... .. ....... .. ... 14

-1-

IMPORTANT SAFETY INSTRUCTION

1) Read the se instruct ions.

2) Keep the se instruct ions.

3) Heed all w arnings.

4) Follow a ll instruct ions.

5) Do not use t his apparat us n ear water.

6) Clean on ly with dry clo th.

7) Do not blo ck any ventil ation openi ng s, instal l
in accord ance with the i nstructio ns .

8) Do not ins tall near any h eat sources s uc h as
radiati ons, heat reg isters, sto ve s, or other
apparat us (includi ng amplifie rs ) that prod uc e
heat.

9) Do not def eat the safet y purpose of th e
polariz ed plug. If the p rovided plu g do es not fit
into your o utlet, cons ult an electr ician for
replace ment of the obs olete outle t.

10) Prote cted the powe r cord from bei ng w alked
on or pinch ed particul arly at plugs , co nvenien ce
recepta cles, and the p oint where th ey exit from
the appar atus.

11) Only use att achments/ ac cessori es s pecifie d
by the manu facturer.

12) Unplu g this appara tu s during li gh ting
storms or w hen unused fo r lo ng period s of t ime.

13) Refer a ll servicin g to qualifie d se rvice
personn el. Servici ng i s require d wh en the
apparat us has been dam aged in any way, such as
power-supply c or d or plug is da ma ged, liqu id
has been sp illed or obje cts have fall en into the
apparat us, the appar atus has been e xp osed to
rain or moi sture, does n ot o perate no rm ally, or
has been dr opped.

14) Mains p lug is used as th e di sconnec t de vice,
the disco nnect devic e shall remai n readily
operabl e.

15) The v entilat io n should not be i mpeded by
coverin g the ventila tion openin gs w ith items ,
such as new spapers, ta bl e-cloth , cu rtains, e tc .

16) No nake d flame sourc es , such as lig ht ed
candles , should be pla ced on the appa ra tus.

17) Atte nt ion should be d rawn to the
environ mental aspe cts of batter y di sposal.

18) The u se of appar at us in moderat e climate.

19) The a pparatu s sh all not be ex po sed to
drippin g or splashin g an d that no obj ec ts filled
with liqu ids, such as va se s, shall be p la ced on
the appar atus.

SA FE TY AND WARNINGS

CAUT ION

RISK OF ELECTRIC SHOCK

DO NOT OPEN!

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK).NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.

The symbol indicates that dangerous
voltages constituting a risk of electric shock
are present within this unit.

The symbol indicates that there are
important operating and maintenance
instructions in the literaturaccompanying this
unit.

WARNING :

To red uc e the risk of f ir e or electr ic s hock, do
not expos e this appara tus to rain or mo is ture.

WARNING:

The batte ries shall no t be exposed to
excessi ve heat such as s un shine, fi re o r the
like.

This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user accessible
parts. When servicing use only
identical replacement parts.

This mark ing indicat es that this pr od uct shoul d
not be disp osed with oth er h ousehol d wa stes
through out the EU. To preven t possible ha rm t o
the envir onment or hum an health fro m
uncontr olled waste d is posal, re cy cle it
respons ibly to promo te t he sustai na ble reuse o f
materia l resources . To ret urn your used d ev ice,
please us e the return an d collectio n sy stems or
contact t he retailer w here the prod uct was
purchas ed. The y ca n take this p ro duct for
environ mental safe r ecycling.

CAUTI ON

-2-

High voltages are used in the operation of this television
receiver. Do not remove the cabinet back from your set.
Refer servicing to qualified service personnel.

SA FE TY AND WARN IN GS

Never stand on, lean on, or suddenly push the television or
its stand. You should pay special attention to children.
Serious injury may result if it falls.

To prevent fire or electrical shock hazard, do not expose
the television receiver to rain or moisture.

Do not drop or push objects into the television cabinet
slots or openings. Never spill any kind of liquid on the
television receiver.

Do not block the ventilation holes in the back cover.
Adequate ventilation is essential to prevent failure of
electrical components.

Do not place your television on an unstable cart, stand,
shelf or table. Serious injury to an individual , and damage
to the television, may result if it falls.

When th e tel ev isi on rece iver is n ot us ed f or an
exten ded p er iod o f time, i t is advi sab le t o dis conne ct
the AC pow er co rd from t he AC outl et.

Avoid exposing the television receiver to direct sunlight
and other sources of heat. Do not stand the television
receiver directly on other products which give off heat,
e.g. video cassette players and audio amplifiers. Do not
place naked flame sources, such as lighted candles on
the television.

Do not trap the power supply cord under the television
receiver.

If the television is to be built into a compartment or similar
enclosure, the minimum distances must be maintained. Heat
build-up can reduce the service life of your television, and
can also be dangerous.

-3-

INTRODUCTION

Main features

① Used as Television, display terminal, PC display；

② High luminance, wide viewing angle；

③ Can store 200 TV programs；

④ HDMI interface；

5 Multi-Media player (USB);

Main parameter

Viewing Picture Size (Diagonal)

Resolution
Aspect Ratio

TV System

Video Signal System

Receiving Channel

Input Power Voltage

Power consumption

Audio Output Power

Signal Input/Output

Horizon

tal definition（TV line）

（THD 7% ）

80 cm

1366x768
16 : 9

PAL/BG,PAL/I,PAL/DK,SECAM/BG,SECAM/DK

PAL/NTSC/SECAM

1-200

AC 100-240V 50/60Hz

50W

2x8W

Analog RGB(VGA) x 1

High-Definition Multimedia Interface (HDMI) x 1
MHL x 1

Composite Video Input x 1
Composite Video output x1

Audio Input x 2
Headphone x 1

YCb (Pb )Cr (P r) x 1
USB x 1
RF x 1

Composite Video input >=350

Y Cb(Pb ) Cr(Pr) >=400

Accessories

Infra red R em ote C ontro ller.. ... ..... ..

Batte ry( AA A). ..... ..... ..... ... ..... ..... ..2

User’s M anua l.. .. ... ..... ..... ..... ... ..... .1

1

-4-
