Haier HW70-1401B-U, HW801401B, HW70-1401S-U, HW60-1401-U, HW60-1401B-U User Manual
...
AutomAtic Drum WAshing mAchine
USER MANUAL
hW80-1401B-u hW70-1401B-u
hW70-1401s-u hW70-1401-u
hW70-1201B-u hW70-1201s-u
hW70-1201-u hW60-1401B-u
hW60-1401s-u hW60-1401-u
hW60-1201B-u hW60-1201s-u
hW60-1201-u
tABle of contents
03 - 09
10 - 15
16- 20
Before use using the AppliAnce MAINTENANCE
COMPONENTS> ............................... 03
PREPARATION> ................................04
SAFETY INSTRUCTIONS> ................... 05
INSTALLATION> ................................ 06
CONTROL PANEL> ............................ 08
LEGEND
Yes
No
Optional
For your safety, any instructions in this manual with this "Warning" sign must be followed strictly.
IMPORTANT DISPOSAL INSTRUCTIONS
As a responsible retailer we care about the environment. As such we urge you to follow the correct
disposal procedure for your product and packaging materials.
PROGRAM SELECTION> ..................... 10
CONSUMPTION AND TECHNICAL DATA> ..
WASHING METHODS> ...................... 12
CLEANING & CARE> .......................... 16
DISPLAY CODES> ............................. 18
TROUBLESHOOTING> ........................ 19
11
IMPORTANT SAFETY INFORMATION...20
>
This will help conserve natural recourses and ensure that it is recycled in a manner that protects health
and the environment.
You must dispose of this product and its packaging according to local laws and regulations. Because
this product contains electronic components, the product and its accessories must be disposed of separately from household
waste when the product reaches its end of life.
Contact your local authority to learn about disposal and recycling. The product and packaging should be taken to your local
collection point for recycling. Some collection points accept products free of charge.
We apologise for any inconvenience caused by minor inconsistencies in these instructions, which may occur as a resultof
product improvement and development.
KESA ELECTRICALS U.K HU1 3AU 05/12/2010
03
Before use
Delay
components
THANKS FOR PURCHASING A HAIER PRODUCT
Please read these instructions carefully before using this appliance. The instructions contain important information which will help you
get the best out of the appliance and ensure safe and proper installation, use and maintenance.
Keep this manual in a convenient place so you can always refer to it for the safe and proper use of the appliance.
If you sell the appliance, give it away, or leave it behind when you move house, make sure you also pass on this manual so that the
new owner can become familiar with the appliance and safety warnings.
ACCESSORIES
Check the accessories and literature
in accordance with this list:
1x Inlet hose assembly
1x User manual
HW80-1401 HW80-1201 HW80-1001
HW80-1401S HW80-1201S HW80-1001S
HW80-1401B HW80-1201B HW80-1001B
HW70-1401 HW70-1201 HW70-1001
HW70-1401S HW70-1201S HW70-1001S
HW70-1401B HW70-1201B HW70-1001B
1x Drain hose bracket
4x Blanking plugs
04
Before use
T1
T2
T3
S1
S2
S4
S3
T4
prepArAtion
PREPARING THE MACHINE
Remove all the packing materials to prevent unsteadiness, including the polystyrene base. Upon
opening the package, water drops may be seen on the plastic bag and the porthole. This is normal
phenomenon resulting from water tests in the factory.
DESCRIPTION
This diagram may be slightly different from the layout of the washing machine you have just
purchased due to technical improvements.
Control panel
Door handle
Work top
Washer door
Start/Pause
Detergent distribution drawer
Filter cover
Drain hose
Water inlet valve
Power cord
Back cover screws
Back cover
Transportation bolts
05
Before use
sAfety instructions
BEFORE SWITCHING THE APPLIANCE ON FOR THE FIRST TIME
DO ...
... Make sure that the transport bolt are removed.
... Use a separate earthed socket for the power supply.
... Make sure that the plug is accessible.
... Hold the plug and not the electric cable when
unplugging the power supply.
... Make sure that the fuses in the power circuit are rated
for 15A.
... Keep away from heat sources and direct sun light to
prevent plastic and rubber components from aging.
... Make sure that the power cord is not caught under or
in the appliance and avoid damage to the power cable.
... Check that hose joints and connections are firm and no
water can leak. If joints are loose or there is leakage, turn off the
water supply and refix. Do not use the washing machine until the
hoses are properly fixed.
DURING DAILY USE OF THE APPLIANCE
DO ...
... Pull up zips and fix loose threads to prevent the items
from being entangled. If necessary, put small items into a net bag
or pillow.
... Turn off the machine after each wash program and
switch it off at the mains to save electricity and for safety. Wipe
clean the lower part of the porthole.
... Keep the door slightly open when the washing machine
is not in use to prevent formation of odours.
... Let the power cord be replaced by the manufacturer, his
service agent or other accordingly qualified persons, in case it is
damaged.
... Ensure that the appliance is not used by persons
with reduced physical, sensory or mental capabilities, lack of
experience and knowledge without supervision or instruction by a
person responsible for their safety.
... Supervise children to ensure that they do not play with
the appliance.
DO NOT ...
... Touch or use the appliance when barefoot or with wet
or damp hands or feet.
... Use flammable detergent or dry cleaning agent.
... Use any flammable sprays in close vicinity to the
appliance.
... Remove or insert the plug in the presence of flammable
gas.
... Allow children or infirm persons to play with the appliance
or packing materials.
... Install the appliance outdoors in a damp place, or in an
area which may be prone to water leaks such as under or near a
sink unit. In the event of a water leak allow the machine to dry
naturally.
... Place the washing machine directly on a carpet, or close
to a wall or furniture.
DO NOT ...
... Touch the washer door during the washing process - it
gets hot!
...Place heavy objects or sources of heat or damp on top
of the appliance.
... Hot wash foam rubber or sponge-like materials.
... Open the detergent distribution drawer during the wash
cycle.
... Force the washer door open. The door is fitted with a
self-lock device and will open shortly after the washing procedure
is ended.
... Open the washer door if the water level is visibly
over the porthole.
... Cover the washing machine with plastic cover so that
inside dampness cannot be kept in.
06
Before use
3.
1.
2.
4.
instAllAtion
DISMANTLE THE TRANSPORTATION BOLTS
The transportation bolts are designed for clamping anti-vibration components
inside of the washing machine during the transportation process.
Remove the back cover.1.
Remove the four bolts on the rear side and take out the synthetic 2.
stabilisers from within the machine.
Replace the back cover.3.
Fill the holes left by the bolts with blanking plugs.4.
Note:
1.When you replace the back cover,the convexity must face
to outside, and you have to insert the back cover from the
two gaps as shown in fig.5.
2.Keep the transportation bolts and synthetic stabilisers
in a safe place for later use.
ADJUSTING THE WASHING MACHINE
There are adjustable feet under the bottom of the washing machine. Before use, they should be
adjusted so that the machine is level. This will minimise vibrations and thus noise during use. It will also
reduce wear and tear. We recommend using a spirit level to level the appliance.The floor should be as
stable and flat as possible.
5.
