22'' SCROLL SAW
MODEL G1060
INSTRUCTION MANUAL
COPYRIGHT © 1992 BY GRIZZLY IMPORTS, INC. REG.# TX 3 300 229
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY IMPORTS, INC.
REVISED JULY 1997 PRINTED IN TAIWAN
G1060 22'' Scroll Saw -1-
Table Of Contents
PAGE
1. SAFETY ....................................................................................................................2
SAFETY RULES FOR ALL TOOLS ....................................................................2
ADDITIONAL SAFETY INSTRUCTIONS FOR SCROLL SAWS ........................3
2. CIRCUIT REQUIREMENTS...................................................................................... 4
110V OPERATION ..............................................................................................4
GROUNDING ......................................................................................................4
3. GENERAL INFORMATION ...................................................................................... 5
UNPACKING ........................................................................................................6
PIECE INVENTORY ............................................................................................6
CLEAN UP............................................................................................................7
SITE CONSIDERATIONS ....................................................................................7
4. ASSEMBLY .............................................................................................................. 8
SAFETY SHIELD..................................................................................................8
5. ADJUSTMENTS ........................................................................................................9
BLADE INSTALLATION ......................................................................................9
BLADE TENSION ..............................................................................................10
TABLE TILT ..................................................................................................10-11
SAFETY SHIELD................................................................................................11
6. OPERATIONS..........................................................................................................12
TEST RUN..........................................................................................................12
STRAIGHT CUTS ..............................................................................................12
CURVED CUTS..................................................................................................13
BEVEL CUTS ....................................................................................................13
INSIDE CUTS ....................................................................................................14
7. MAINTENANCE ......................................................................................................15
GENERAL ..........................................................................................................15
WORKING TABLE..............................................................................................15
LUBRICATION ..................................................................................................15
8. CLOSURE................................................................................................................16
MACHINE DATA ................................................................................................17
PARTS BREAKDOWN AND PARTS LISTS ................................................18-19
WARRANTY AND RETURNS............................................................................20
-2- G1060 22'' Scroll Saw
WARNING: For Your Own Safety, Read
Instruction Manual Before Operating Scroll Saw
Safety Instructions For Power Tools
These safety rules cannot cover every situation in a work shop. Consider your conditions when setting up
or operating your scroll saw.
SECTION 1: SAFETY
a) Always wear eye protection.
b) Always keep guards in place and in proper
operating condition.
c) Do not cut pieces too small to hold by hand.
d) Make sure the blade teeth point downward
toward the table.
7. DON’T FORCE TOOL. It will do the job bet-
ter and safer at the rate for which it was
designed.
8. USE RIGHT TOOL. Don’t force tool or
attachment to do a job for which it was not
designed.
9. USE PROPER EXTENSION CORD. Make
sure your extension cord is in good condition. When using an extension cord, be sure
it is rated Hard Service (grade S) or better.
Conductor size must be 16 A.W.G. for cords
up to 100 feet in length. An undersized cord
will cause a drop in line voltage resulting in
loss of power and overheating. Your extension cord must also contain a ground wire
and plug pin. Always repair or replace
extension cords if they become damaged.
Minimum gage for extension cord:
16 A.W.G. 50ft
16 A.W.G. 100ft
14 A.W.G. 200ft
12 A.W.G. 300ft
1. KEEP GUARDS IN PLACE and in working
order.
2. REMOVE ADJUSTING KEYS AND
WRENCHES. Form habit of checking to see
that keys and adjusting wrenches are
removed from tool before turning on.
3. KEEP WORK AREA CLEAN. Cluttered
areas and benches invite accidents.
4. DON’T USE IN DANGEROUS ENVIRONMENT. Don’t use power tools in damp or
wet locations, or expose them to rain. Keep
work area well lighted.
5. KEEP CHILDREN AND VISITORS AWAY.
All children and visitors should be kept a
safe distance from work area.
6. MAKE WORK SHOP CHILD PROOF with
padlocks, master switches, or by removing
starter keys.
G1060 22'' Scroll Saw -3-
Additional Safety Instructions For Scroll Saws
16. REDUCE THE RISK OF UNINTENTIONAL
STARTING. Make sure switch is in off posi-
tion before plugging in.
17. USE RECOMMENDED ACCESSORIES.
Consult the owner’s manual for recommended accessories. The use of improper accessories may cause risk of injury.
18. CHECK DAMAGED PARTS. Before further
use of the tool, a guard or other part that is
damaged should be carefully checked to
determine that it will operate properly and
perform its intended function-check for alignment of moving parts, binding of moving
parts, breakage of parts, mounting, and any
other conditions that may affect its operation.
A guard or other part that is damaged should
be properly repaired or replaced.
19. DIRECTION OF FEED. Feed work into a
blade or cutter against the direction of rotation of the blade or cutter only.
20. NEVER LEAVE TOOL RUNNING UNAT-
TENDED. TURN POWER OFF. Don’t leave
tool until it comes to a complete stop.
6. Feed stock into the blade using a slow,
steady, even pressure.
7. Keep workpiece firmly against the table.
8. Wait until all motion is stopped before clear-
ing cutoff pieces away from the blade.
9. Habits are hard to break, good and bad.
Develop good habits and safety will become
second nature to you.
1. Make sure saw teeth are pointed down
toward the table.
2. Maintain proper blade tension.
3. When making adjustments, keep power off
and the power cord unplugged.
4. To test adjustments, rotate the Rocker Arm
slowly by hand. Never assume an adjustment is correct and then turn the power on.
5. Adjust Hold-down Foot so it barely touches
your workpiece.
10. WEAR PROPER APPAREL Do not wear
loose clothing, gloves, neckties, rings,
bracelets, or other jewelry which may get
caught in moving parts. Non-slip footwear is
recommended. Wear protective hair covering
to contain long hair.
11. ALWAYS USE SAFETY GLASSES. Also
use face or dust mask if cutting operation is
dusty. Everyday eyeglasses only have
impact resistant lenses, they are NOT safety
glasses.
12. SECURE WORK. Use clamps or a vise to
hold work when practical. It’s safer than
using your hand and frees both hands to
operate tool.
13. DON’T OVERREACH. Keep proper footing
and balance at all times.
14. MAINTAIN TOOLS WITH CARE. Keep tools
sharp and clean for best and safest performance. Follow instructions for lubricating and
changing accessories.
15. DISCONNECT TOOLS before servicing and
changing accessories, such as blades, bits,
cutters, and the like.
Figure 1.
Improper connections of the electrical-grounding
conductor can result in risk of electric shock. The
conductor with green or green and yellow striped
insulation is the electrical-grounding conductor. If
repair or replacement of the electric cord or plug
is necessary, do not connect the equipment
grounding conductor to a live terminal.
Under no circumstances should the grounding
pin from any three-pronged plug be removed. If it
will not fit the outlet, have the proper outlet
installed by a qualified electrician.
Check with a qualified electrician or one of our
service personnel if the grounding instructions
are not completely understood, or if in doubt as to
whether the tool is properly grounded. Use only
3-wire extension cords that have 3-prong grounding type plugs and 3-hole receptacles that accept
the tool’s plug. FIgure 1.
Repair or replace damaged or worn cord immediately.
-4- G1060 22'' Scroll Saw
110V Operation
Your G1060 22'' Scroll Saw is prewired for 110
volt, single phase operation. The
1
⁄8'' H.P. motor
draws approximately 2.2 amps. We strongly recommend fusing your Scroll Saw at 15 amps.
Fusing higher will not adequately protect the
motor.
Although the G1060 22'' Scroll Saw does not
draw a large load, if you’re using a circuit that is
already close to capacity, it might blow a fuse or
trip a circuit breaker. If an unusual load does not
exist and power failure still occurs, have the circuit inspected by a qualified electrician.
CAUTION: Be sure that your particular electrical
configuration complies with local and state codes.
The best way to ensure compliance is to check
with your local municipality or licensed electrician.
Grounding
CAUTION: THIS TOOL MUST BE GROUNDED
WHILE IN USE TO PROTECT THE OPERATOR
FROM ELECTRIC SHOCK.
In the event of a malfunction or breakdown,
grounding provides a path of least resistance for
electric current to reduce the risk of electric
shock. This tool is equipped with an electric cord
having an equipment-grounding conductor and a
grounding plug. The plug must be plugged into a
matching outlet that is properly installed and
grounded in accordance with all local codes and
ordinances.
SECTION 2: CIRCUIT REQUIREMENTS
Grounded Outlet Box
Current
Carrying
Prongs
Grounding Blade Is
Longest Of the Three Blades
G1060 22'' Scroll Saw -5-
Grizzly Imports, Inc. is proud to offer the Model
G1060 22'' Scroll Saw. The G1060 is part of
Grizzly’s growing family of fine woodworking and
metalworking machinery. When used according
to the guidelines stated in this manual, you can
expect years of trouble-free, enjoyable operation.
The Model G1060 is capable of a wide variety of
operations. The 22'' throat capacity enables you
to maneuver large workpieces for a variety of
intricate operations. The G1060 comes complete
with base, motor and electrical package. It also
features a safety shield and an an air pump to
keep the cutting line visible during operation.
We are also pleased to provide this manual with
the Model G1060. It was written to guide you
through assembly, review safety considerations,
and cover general operating procedures. It represents our latest effort to produce the best documentation possible. If you have any criticisms that
you feel we should address in our next printing,
please write to us at the Bellingham, WA address
at the end of this section.
SECTION 3: GENERAL INFORMATION
Most important, we stand behind our machines.
We have an excellent service department at your
disposal should the need arise. If you have any
service questions or parts requests, please call or
write to us at the location listed below.
Grizzly Industrial, Inc.
1203 Lycoming Mall Circle
Muncy, PA 17756
Phone:(570) 546-9663
Fax:(800) 438-5901
E-Mail: techsupport@grizzly.com
Web Site: http://www.grizzly.com
To comment on this manual write to:
Grizzly Industrial, Inc.
C
⁄
O
Technical Documentation
P.O. Box 2069
Bellingham, WA 98227
To operate this, or any other power tool safely
and efficiently, it is essential to become as familiar with it as possible. The time you invest before
you begin to use your Model G1060 Scroll Saw
will be time well spent. DO NOT operate this
machine until you are completely familiar with the
contents of this manual.
-6- G1060 22'' Scroll Saw
Unpacking
The Model G1060 22'' Scroll Saw is shipped from
the manufacturer in a carefully packed carton. If
you discover the machine is damaged after
you’ve signed for delivery, please call Customer
Service immediately for advice.
Save the containers and all packing materials for
possible inspection by the carrier or its agent.
Otherwise filing a freight claim can be difficult.
Caution: The G1060 weighs 56 lbs. DO NOT
over-exert yourself while unpacking or moving
your machine – get assistance.
When you are completely satisfied with the condition of your shipment, you should inventory its
parts.
Piece Inventory
After all the parts have been removed from the
carton, you should have:
• Scroll Saw Assembly
• Hardware
Hardware Qty
Mounting Rod 1
1
⁄4" - 20 Wing Nut 1
1
⁄4" Washer 1
Support Post 1
Safety Shield 1
Mounting Clip 1
In the event that any non-proprietary parts are
missing (e.g. a nut or a washer), we would be
glad to replace them, or, for the sake of expediency, replacements can be obtained at your local
hardware store.
G1060 22'' Scroll Saw -7-
Clean up
The working table for the G1060 is coated with a
waxy oil that protects them from corrosion during
shipment. Remove the protective coating with
mineral spirits and paper towels. Do not use
gasoline or other petroleum based solvents
because of their extremely low flash points. Do
not use chlorine-based solvents – if you happen
to splash some onto a painted surface, you’ll ruin
the finish.
WARNING!
Follow the safety rules listed below when
working with solvents:
1. Read and follow all directions and warnings
on the solvent label.
2. Work only in a well ventilated area.
3. Do not work near any type of open flame
(e.g., pilot lights, kerosene heaters, and so
on).
4. DO NOT smoke while working with flamma-
ble material.
5. Paper towels from the cleaning process are
extremely combustible. Dispose of waste
towels so they do not create a fire hazard.
Site Considerations
1. Working Clearances: Consider existing and
anticipated needs, size of material to be
processed through the machine, and space
for auxiliary stands, work tables or other
machinery when establishing a location for
your scroll saw.
2. Lighting and Outlets: Lighting should be
bright enough to eliminate shadow and prevent eye strain. Electrical circuits should be
dedicated or large enough to handle amperage requirements. Outlets should be located
near each machine so power or extension
cords are clear of high-traffic areas. Observe
local electrical codes for proper installation
of new lighting, outlets, or circuits.
-8- G1060 22'' Scroll Saw
SECTION 4: ASSEMBLY
Safety Shield
The only real assembly required for your scroll
saw is to attach the safety shield to the support
post.
1. Slide the mounting clip over the threaded
end of the mounting rod and secure with
wing nut provided.
2. Mount the shield assembly to the support
post by sliding the mounting clip onto the
support post and securing in the desired
position. Figure 2.
Figure 2.
G1060 22'' Scroll Saw -9-
Changing Blades
SECTION 5: ADJUSTMENTS
1. Remove Safety Shield assembly.
2. Remove Table Insert and flip open Chuck
Guards. Figure 3.
3. Mount Blade in Chucks. This can be done
with the help of the Chuck Holder, located on
the right edge of the table. Figure 4.
4. Mount Chucks between Upper and Lower
Arms (Blade teeth should be pointing down
toward the table) and close Chuck Guard.
Don’t replace the Safety Shield or Table
Insert just yet - wait until after you’ve adjusted blade tension.
Figure 3.
Figure 4.
-10- G1060 22'' Scroll Saw
Blade Tension
1. Turn the Blade Tension Adjustment Knob
clockwise to tighten, counterclockwise to
loosen. Figure 5. Proper tension is difficult to
quantify, but as you turn the knob clockwise,
you will notice when the blade initially begins
to tighten. The moment you feel the blade
tighten, give the knob about another
1
⁄4
turn
and then stop. Getting the blade any tighter
than this could snap it or cause unnecessary
strain on the chucks.
2. Once you have achieved proper blade ten-
sion, replace the table insert and safety
shield assembly.
Figure 5.
Table Tilt
Your Scroll Saw can handle any sort of bevel cut
between 0 and 30˚. Before you try this, however,
make sure the blade is perpendicular to the table.
Recalibration of this setting is easy.
1. Find a small block of wood that is known to
be square.
2. Loosen Tilt Adjustment Knob located direct-
ly under the table.
3. Place block against Blade. If there is any
space between the block and the blade, the
table is not at 90˚. Adjust the table to close
this space. Figure 6.
Figure 6.
G1060 22'' Scroll Saw -11-
Safety Shield
Always wear safety glasses. The Safety Shield
included with your Scroll Saw should be used as
additional protection for your face and eyes
should the blade snap or material be ejected from
the blade area toward your head. To adjust the
safety shields:
1. Loosen the Wing Nut on the Support Clip.
Figure 8.
2. Swivel Shield into desired position.
3. Tighten Wing Nut.
4. Once you are sure the Table is at 90˚, tighten
the Tilt Adjustment Knob. It will also be necessary to loosen the pointer and reset it.
Now that the table is perpendicular to the blade,
any angle you set between 0 and 30˚ will be
accurate. To do this:
1. Facing the Saw, turn the Table Insert 90˚ to
the right as shown in Figure 7.
Figure 7.
Figure 8.
2. Under the Table and to the left, locate the Tilt
Adjustment Knob. Turn the knob counterclockwise and lift the right edge of the table.
When the table reaches the desired angle,
tighten the Tilt Adjustment Knob.
-12- G1060 22'' Scroll Saw
SECTION 6: OPERATIONS
Once assembly is complete and adjustments are
done to your satisfaction, you are ready to test
the machine.
Turn on the power supply at the main panel.
Press the START button. Make sure that your finger is poised on the STOP button, just in case
there’s a problem. The scroll saw should run
smoothly, with little or no vibration or rubbing
noises. Strange or unnatural noises should be
investigated and corrected before operating the
machine further.
WARNING: DO NOT attempt to investigate or
adjust the machine while it is running. Wait until
the machine is turned off, unplugged and all
working parts have come to a rest before you do
anything!
If you cannot easily locate the source of an
unusual noise or vibration, feel free to contact our
service department for help.
Your scroll saw can perform a variety of intricate
cuts: straight, curved, bevel, inside, and so on.
The kind of work you produce with it is limited
only by your imagination.
In this section we’ll cover the four basic types of
cuts from which all others are variations. Please
keep in mind that these are standard guidelines;
they are by no means the only correct ways to
use your Scroll Saw. NOTE: Safety Shield is
removed for photographic clarity in this section.
Test Run
Straight Cuts
1. Scribe a straight line on your workpiece with
a sharp pencil or scratch awl.
2. Adjust Hold-down Foot so it barely touches
the workpiece.
3. Turn power on. Allow motor to get up to
speed and push workpiece slowly and
steadily into the blade, keeping your hands
to either side of the cutting line. Make sure
the blade is cutting to the waste side of the
line. Figure 9.
Figure 9.
G1060 22'' Scroll Saw -13-
Curved Cuts
1. Scribe a curved line on your workpiece with
a sharp pencil or scratch awl.
2. Adjust Hold-down Foot as for straight cut-
ting.
3. Maintaining a slow, even pressure, feed the
workpiece into the blade. Approaching a
tight radius, slow down your feed rate, but
don’t stop. The blade must do the cutting;
don’t force the piece into the blade faster
than the machine can handle, especially on
a curve. This will cause the blade to twist,
which increases the risk of breakage. At all
times, keep the workpiece flat against the
table, and keep an eye on the blade to make
sure it doesn’t twist.
4. If your cut produces waste in the curve’s
interior, turn the power off and wait until all
motion stops before removing the waste
against the blade. Figure 10.
Figure 10.
Bevel Cuts
1. Scribe your workpiece as described in the
previous two sections.
2. Adjust table to desired angle.
3. Adjust the Hold-down Foot to the same angle
as the table. Its adjustment bolt is shown in
Figure 11. As with the other cuts, make it
touch, not clamp your workpiece.
4. Using the same principles as in the previous
sections, feed the work slowly and evenly
into the blade, remembering not to force the
workpiece.
5. Wait until all motion has stopped before
removing waste close to the blade.
Figure 11.
-14- G1060 22'' Scroll Saw
Inside Cuts
Inside cuts such as circles or the insides of closed
letters can be easily cut with your Scroll Saw by
threading the blade through the workpiece’s
closed loop from the bottom and remounting the
blade in the chucks. This procedure is described
below.
1. Remove Table Insert.
2. Flip open Chuck Guard and loosen Upper
Arm Chuck.
3. Remove blade from the Upper Chuck using
Chuck Holder.
4. Drill a hole in the waste portion of the work-
piece.
5. Thread the Blade through the workpiece and
let the workpiece rest on the table. Remount
Blade in Chuck, carefully aligning the ridge
on the bottom of the Chuck to the V-groove
in the Upper Arm. Figure 12.
Figure 12.
Figure 13.
6. Secure the Blade in the Chuck. This will
require an Allen wrench and a pair of pliers.
Figure 13.
7. Replace Table Insert.
8. Make cuts.
9. Remove blade from the chuck to release the
workpiece.
G1060 22'' Scroll Saw -15-
SECTION 7: MAINTENANCE
Lubrication
Lubricate the upper and lower guide arm bushings once a month. Light machine oil will be adequate. Damage to the motor may result if the
bushings are allowed to run dry.
Regular periodic maintenance on your Model
G1060 Scroll Saw will ensure its optimum performance. Make a habit of inspecting your scroll saw
each time you use it. Check for the following conditions and repair or replace when necessary.
Caution: Always perform any maintenance with
the power off and the machine unplugged.
1. Loose bolts.
2. Worn switch.
3. Worn or damaged cords and plugs.
4. Any other condition that could hamper the
safe operation of this machine.
General
Working Table
The working table can be kept slippery and rustfree with regular applications of talcum powder.
Rub the powder into the table tops with either a
felt brick (i.e.-common chalk board eraser) or a
chamois cloth.
We do not recommend wax or paraffin; eventually, the buildup will impede the smooth movement
of your lumber over the table surfaces.
Figure 14.
-16- G1060 22'' Scroll Saw
The following pages contain general machine
data, parts diagrams/lists, troubleshooting guide
and warranty/return information for your Model
G1060 22'' Scroll Saw.
If you need parts or help in assembling your
machine, or if you need operational information,
we encourage you to call our Service
Department. Our trained service technicians will
be glad to help you.
If you have comments dealing specifically with
this manual, please write to our Bellingham,
Washington location using the address in the
general information. The specifications, drawings, and photographs illustrated in this manual
represent the Model G1060 as supplied when this
manual was prepared. However, due to Grizzly’s
policy of continuous improvement, changes may
be made at any time with no obligation on the part
of Grizzly. Whenever possible, though, we send
manual updates to all owners of a particular tool
or machine. Should you receive one, add the new
information to this manual and keep it for reference.
We have included some important safety measures that are essential to this machine’s operation. While most safety measures are generally
universal, Grizzly reminds you that each workshop is different and safety rules should be con-
sidered as they apply to your specific situation.
We recommend you keep a copy of our current
catalog for complete information regarding
Grizzly's warranty and return policy. If you need
additional technical information relating to this
machine, or if you need general assistance or
replacement parts, please contact the Service
Department listed in General Information.
Additional information sources are necessary to
realize the full potential of this machine. Trade
journals, woodworking magazines, and your local
library are good places to start.
WARNING!
As with all power tools, there is danger associated with the Model G1060 22'' Scroll Saw. Use the
tool with respect and caution to lessen the possibility of mechanical damage or operator injury. If
normal safety precautions are overlooked or
ignored, injury to the operator or others in the
area is likely.
The Model G1060 was specifically designed for
sawing operations. DO NOT MODIFY AND/OR
USE THIS SCROLL SAW FOR ANY OTHER
PURPOSE. Modifications or improper use of
this tool will void the warranty. If you are con-
fused about any aspect of this machine, DO NOT
use it until you have answered all your questions.
SECTION 8: CLOSURE
G1060 22'' Scroll Saw -17-
MACHINE DATA
GRIZZLY MODEL G1060 22" SCROLL SAW
Design Type ........................................................................................................................ Bench Model
Capacities:
Maximum Cutting Width..........................................................................................................22"
Maximum Cutting Height........................................................................................................1
7
⁄8"
Table Tilt ..............................................................................................................................0-30
o
Overall Dimensions:
Base ..........................................................................................................................20
1
⁄2" x 83⁄4"
Table ........................................................................................................................17
3
⁄8" x 83⁄4"
Height......................................................................................................................................15"
Width ......................................................................................................................................29"
Depth ......................................................................................................................................11"
Blade to Frame ....................................................................................................................21
1
⁄2"
Container Dimensions ......................................................................................10" x 19
1
⁄
2" x 21"
Shipping Weight ................................................................................................................62 lbs.
Net Weight......................................................................................................................56
1
⁄
2 lbs.
Blade and Movement:
Standard, Plain-end Blade........................................................................................................5"
Cuts per minute ..................................................................................................................1720
Stroke ......................................................................................................................................
3
⁄4"
Construction:
Base ..............................................................................................................................Cast Iron
Table ................................................................................................................Ground Cast Iron
Arms and Pillar..............................................................................................Die Cast Aluminum
Motor:
Horsepower ........................................................................................................................
1
⁄8 HP
Amps ......................................................................................................................................2.2
Phase Type/ Voltage ..................................................................................Single Phase / 110V
Cycle/ RPM ................................................................................................60 Hertz/ 1720 RPM
Switch ....................................................................On/ Off Toggle with Removable Plastic Key
Power Transfer ............................................................................Balanced Eccentric Fly Wheel
Bearings ..............................................................................Shielded & Permanently Lubricated
Specifications, while accurate, are subject to change without notice.
32
-18- G1060 22'' Scroll Saw
75
25
2
67
67
64
37
66
65
14
24
70
25
44
45
13
11
38
26
16
16
20
69
31
15
33
29
39
69
52
77
18
21
52
48
73
6
54
53
73
48
29
35
26
3
36
36A
23
12
9
10
34
3
22
74
19
68
11
74
17
7
50
49
4
46
30
31
51
63
6
47
41
43
58
56
57
59
8
72
76
25
2
25
2
42
41
28
1
67
27
25
2
28
67
78
40
5
60
G1060 22'' Scroll Saw -19-
REF PART # DESCRIPTION REF PART # DESCRIPTION
01 P1060001 BASE
02 PSB07M CAP SCREW M8-1.25 X 24MM
03 PLW04M LOCK WASHER 8MM
04 P1060004 MOTOR
05 P1060005 ROCKER ARM
06 PSS02M SETSCREW M6-1.0 X 6MM
07 P1060007 FRONT STRUT
08 P1060008 REAR STRUT
09 P1060009 BELLOWS
10 P1060010 ANCHOR PLATE
11 PS12M PHLP HD SCR M3-0.5 X 6MM
12 P1060012 PRESSURE PLATE
13 PS21M PHLP HD SCR M4-0.7 X 15MM
14 P1060014 PILLAR
15 P1060015 CONNECTING LINK
16 P625 BEARING 625-ZZ
17 PSB15M CAP SCREW M5-0.8 X 20MM
18 P1060018 SPACER
19 PN06M HEX NUT M5-0.8MM
20 P1060020 SPACER
21 PSB38M CAP SCREW M5-0.8 X 25MM
22 P1060022 LOWER ARM
23 P106023 BUSHING
24 P1060024 FULCRUM BOLT
25 PW01M WASHER 8MM
26 PLN04M LOCKNUT M8-1.25
27 P1060027 TABLE TILT GAUGE
28 PS05M PHLP HD SCR M5-0.8 X 8MM
29 PLW03M LOCK WASHER 6MM
30 P1060030 TABLE
31 PSB06M CAP SCREW M6-1.0 X 25MM
32 P1060032 PLUG
33 P1060033 UPPER ARM
34 P1060034 BUSHING
35 P1060035 FULCRUM BOLT
36 P1060036 ADJUSTMENT KNOB
36A PN02M HEX NUT M10-1.5
37 P1060037 SUPPORT ARM
38 P1060038 AIR HOSE
39 P1060039 HOSE CLAMP
*replacement chucks supplied with setscrews.
40 P1060040 ADJUSTMENT KNOB
41 P1060041 STAR WASHER 5MM
42 P1060042 POINTER
43 PS09M CAP SCREW M5-0.8 X 10MM
44 P1060044 ROCKER GUARD
45 PSB03M CAP SCREW M5-0.8 X 8MM
46 P1060046 REGULATOR
47 P1060047 HOLD-DOWN FOOT
48 PN07M HEX NUT M3-0.5
49 P1060049 AIR NOZZLE
50 P1060050 SUPPORT POST
51 P1060051 ADJUSTMENT KNOB
52 P1060052 CHUCK GUARD
53* P1060053 CHUCK
54 G1138 BLADE (SEE CATALOG)
56 P1060056 TABLE INSERT
57 P1060057 ANCHOR PLATE
58 PSB28M CAP SCREW M6-1.0 X15MM
58A PAW05M ALLEN WRENCH 5MM
59 PSW07 SWITCH
60 P1060060 POWER CORD
61 P1060061 STRAIN RELIEF
62 PAW03M ALLEN WRENCH 3MM
63 P1060063 SAFETY SHIELD
64 P1060064 MOUNTING ROD
65 P1060065 MOUNTING CLIP
66 PWN02 WING NUT
1
⁄4
''-20
67 PW06 WASHER
1
⁄
4''
68 P1060068 CONNECTING LINK PLATE
69 PS13M SCREW M3-0.5 X 20MM
70 P1060070 LOGO PLATE
71 P1060071 RIVET
72 PSB06M CAP SCREW M6-1.0 X 25MM
73 P1060073 FIBER WASHER
74 PLW01M LOCK WASHER 5MM
75 PS02M PHLP HD SCR M4-0.7 X 12MM
76 P1060076 RUBBER FOOT
77 PSS26M SETSCREW M5-0.8 X 6MM
78 PSS01M SETSCREW M6-1.0 X 10MM
-20- G1060 22'' Scroll Saw
Grizzly Imports, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the
date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance. This is Grizzly’s sole written warranty and
any and all warranties that may be implied by law, including any merchantability or fitness, for any particular purpose, are hereby limited to the duration of this written warranty. We do not warrant or represent that
the merchandise complies with the provisions of any law or acts unless the manufacturer so warrants. In
no event shall Grizzly’s liability under this warranty exceed the purchase price paid for the product and any
legal actions brought against Grizzly shall be tried in the State of Washington, County of Whatcom.
We shall in no event be liable for death, injuries to persons or property or for incidental, contingent, special, or consequential damages arising from the use of our products.
To take advantage of this warranty, contact us by mail or phone and give us all the details. We will then
issue you a “Return Number’’, which must be clearly posted on the outside as well as the inside of the carton. We will not accept any item back without this number. Proof of purchase must accompany the merchandise.
The manufacturers reserve the right to change specifications at any time because they constantly strive to
achieve better quality equipment. We make every effort to ensure that our products meet high quality and
durability standards and we hope you never need to use this warranty.
Please feel free to write or call us if you have any questions about the machine or the manual.
Thank you again for your business and continued support. We hope to serve you again soon.
WARRANTY AND RETURNS
Loading...
