GRASS VALLEY K2 DYNO PA - V1.5, K2 Dyno PA User Manual

K2 Dyno PA
LIVE EVENT MANAGEMENT SYSTEM
User Manual
Software Version 1.5
071-8762-01
October 2010
A
K2 Dyno PA
LIVE EVENT MANAGEMENT SYSTEM
User Manual
Software Version 1.5
071-8762-01
October 2010
Copyright Copyright © Grass Valley, Inc. All rights reserved. Printed in the United States of America.
Portions of software © 2000 – 2009, Microsoft Corporation. All rights reserved. This document may not be copied in whole or in part, or otherwise reproduced except as specifically permitted under U.S. copyright law, without the prior written consent of Grass Valley, Inc., P.O. Box 59900, Nevada City, California 95959-7900. This product may be covered by one or more U.S. and foreign patents.
Disclaimer Product options and specifications subject to change without notice. The information in this
manual is furnished for informational use only, is subject to change without notice, and should not be construed as a commitment by Grass Valley, Inc. Grass Valley, Inc. assumes no responsibility or liability for any errors or inacc uracies that may appear in this publication.
U.S. Government Restricted Rights Legend
Trademarks and Logos
Use, duplication, or disclosure by the United States Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.277-7013 or in subparagraph c(1) and (2) of the Commercial Computer Software Restricted Rights clause at FAR 52.227-19, as applicable. Manufacturer is Grass Valley, Inc., P.O. Box 59900, Nevada City, California 95959-7900 U.S.A.
Grass Valley, K2, Aurora, Summit, Dyno, Solo, Infinity, Turbo, Profile, Profile XP, NetCentral, NewsBrowse, NewsEdit, NewsQ, NewsShare, Ne wsQ Pro, and Media Manager are either registered trademarks or trademarks of Grass Valley, Inc. in the United States and/or other countries. Grass Valley, Inc. products are covered by U.S. and foreign patents, issued and pending. Additional information regarding Grass Valley, Inc. trademarks and other proprietary rights may be found at www.grassvalley.com.
Other trademarks and logos used in this document are either registered trademarks or trademarks of the manufacturers or vendors of the associated products, such as Microsoft® Windows® operating system, Windows Media® play er, Internet Explorer® internet browser, and SQL Server™. QuickTime and the QuickTime logo are trademarks or registered trademarks of Apple Computer, Inc., used under license therefrom.
4 K2 Dyno PA Use r Manual October 15, 2010
Contents
Grass Valley Product Support..................................................................................................7
About the K2 Dyno PA User Manual .......................................................................................9
Chapter 1: About K2 Dyno Production Assistant...................................................11
About K2 Dyno Production Assistant....................................................................................12
Using K2 Dyno PA ................................................................................................................13
About bins.............................................................................................................................14
About repositories.................................................................................................................14
About K2 Dyno PA User Interface.........................................................................................14
Customizing the K2 Dyno PA user interface..........................................................................17
About user layouts and preferences......................................................................................19
Sharing assets and information between multiple K2 Dyno PA clients..................................20
Chapter 2: Star ting Dyno PA....................................................................................23
Starting the K2 Dyno PA application......................................................................................24
Contents
Chapter 3: Logging and keywords...........................................................................25
About K2 Dyno PA metadata and logging keywords.............................................................26
Creating a K2 Dyno PA keyword ..........................................................................................26
Renaming a K2 Dyno PA keyword ........................................................................................26
Deleting a K2 Dyno PA keyword ...........................................................................................27
Applying (logging) a keyword in K2 Dyno PA........................................................................27
Applying (logging) a keyframe in K2 Dyno PA.......................................................................28
Cueing a keyframe in an asset..............................................................................................28
Deleting a keyframe...............................................................................................................28
Creating a keyword category ................................................................................................29
Renaming a keyword category..............................................................................................29
Deleting a keyword category.................................................................................................29
Exporting K2 Dyno PA keywords to a K2 Dyno Controller.....................................................30
Exporting K2 Dyno PA keywords to another Dyno PA ..........................................................30
Importing K2 Dyno PA keywords ..........................................................................................30
Chapter 4: Searching assets....................................................................................31
Creating a search query in K2 Dyno PA................................................................................32
Editing a search in K2 Dyno PA.............................................................................................32
Deleting a search in K2 Dyno PA .........................................................................................33
Chapter 5: Working with assets, bins, and folders ................................................35
Creating a clip.......................................................................................................................36
Creating a subclip..................................................................................................................36
Copying assets......................................................................................................................37
Copying an asset to a repository...........................................................................................37
Playing an asset or playlist....................................................................................................38
15 October 2010 Dyno Production Assistant User Manual 5
Contents
Renaming an asset ..............................................................................................................38
Deleting an asset ..................................................................................................................39
Adding a repository...............................................................................................................39
Adding a bin..........................................................................................................................40
Editing a repository ...............................................................................................................41
Deleting a repository or bin...................................................................................................41
Chapter 6: Transferring Assets with K2 Dyno PA...................................................43
Transferring assets automatically with rules..........................................................................44
Editing a rule .....................................................................................................................45
Deleting a rule....................................................................................................................46
Checking an asset for rules ..............................................................................................46
Canceling an active transfer .............................................................................................46
Transferring scheduled assets ..............................................................................................46
Transferring assets manually.................................................................................................48
Chapter 7: Playlists...................................................................................................49
Creating a playlist..................................................................................................................50
Editing a playlist.....................................................................................................................51
Deleting a playlist..................................................................................................................52
Renaming a playlist ..............................................................................................................52
Copying a playlist .................................................................................................................52
6 Dyno Production Assistant User Manual 15 October 2010
Grass Valley Product Support
T o get technical assistance, check on the status of a question, or to report a ne w issue, contact Grass Valley Product Support via e-mail, the Web, or by phone or fax.
Web Technical Support
To access support information on the Web, visit the product support Web page on the Grass Valley Web site. You can download software or nd solutions to problems.
World Wide Web: http://www.grassvalley.com/support/ Technical Support E-mail Address: gvgtechsupport@grassvalley.com
Telephone Support
Use the following information to contact Product Support by phone.
International Support Centers
Our international support centers are available 24 hours a day, 7 days a week.
Authorized Local Support Representative
A local support representative may be available in your country. To locate a support center during normal local business hours, refer to the following list. This list is regularly updated on the website for Grass Valley Product Support
(http://www.grassvalley.com/support/contact/phone/) After–hours local phone support is also available for warranty and contract customers.
Macau
In countryToll freeSupport Center
+33 1 48 25 20 20+800 80 80 20 20France +1 530 478 4148+1 800 547 8949United States
TelephoneCountryRegion
+86 10 5883 7575ChinaAsia +852 2531 3058Hong Kong, Taiwan, Korea,
+81 3 6848 5561Japan
15 October 2010 Dyno Production Assistant User Manual 7
+603 7492 3303Southeast Asia - Malaysia +65 6379 1313Southeast Asia - Singapore
Grass Valley Product Support
South America
TelephoneCountryRegion
+91 22 676 10324India 1 300 721 495AustraliaPacic 0800 846 676New Zealand +61 3 8540 3650For callers outside Australia
or New Zealand
+55 11 5509 3440AllCentral America,
North America
Africa
North America, Mexico, Caribbean
France
Eastern Europe
Tadzhikistan, Ukraine, Uzbekistan
Near East and Africa
+1 800 547 8949; +1 530 478 4148
+44 1189 230 499UK, Ireland, IsraelEurope +31 (0) 35 62 38 421Benelux – Netherlands +32 (0) 2 334 90 30Benelux – Belgium +800 80 80 20 20;
+33 1 48 25 20 20 +49 6150 104 444Germany, Austria,
+7 495 258 09 20Belarus, Russia,
+45 404 72 237Northern Europe +39 06 87 20 35 28Southern Europe – Italy +34 91 512 03 50Southern Europe – Spain +971 4 299 64 40Middle EastMiddle East, Near East, +800 80 80 20 20;
+33 1 48 25 20 20
8 Dyno Production Assistant User Manual 15 October 2010
About the K2 Dyno PA User Manual
This manual is intended for users of the K2 Dyno Production Assistant™ (Dyno PA) application; it describes concepts and tasks that pertain to operating Dyno PA. For information on administrator tasks such as installing and conguring Dyno PA, see the K2 Dyno Production Assistant Conguration Manual.
15 October 2010 Dyno Production Assistant User Manual 9
Chapter 1
About K2 Dyno Production Assistant
This section contains the following topics:
About K2 Dyno Production Assistant
Using K2 Dyno PA
About bins
About repositories
About K2 Dyno PA User Interface
Customizing the K2 Dyno PA user interface
About user layouts and preferences
Sharing assets and information between multiple K2 Dyno PA clients
15 October 2010 Dyno Production Assistant User Manual 11
About K2 Dyno Production Assistant
About K2 Dyno Production Assistant
K2 Dyno Production Assistant (Dyno PA) is a software platform composed of the Dyno PA application and the Grass Valley platform service. The platform service allows users on various Dyno PA clients to access assets as well as share saved searches, keywords, and transfer rules.
NOTE: The Dyno PA application can be used with K2 Media Clients, K2 Summit Production Clients, and K2 Solo Media Servers. When a procedure can be applied to any of these, the term K2 system is used. A K2 Summit Production Client with internal storage is referred to as a standalone K2 Summit system. A K2 Summit Production Client with external storage (an FSM server and a RAID) is referred to as a K2 Summit SAN system. Where a procedure can be applied to a K2 Summit Production Client (in a standalone or SAN system) or a K2 Solo Media Server, the term K2 Summit system is used. The Dyno P A application runs on a machine referred to as the Dyno PA client.
Dyno PA can manage various K2 systems to perform several different tasks.
12 Dyno Production Assistant User Manual 15 October 2010
About K2 Dyno Production Assistant
Using K2 Dyno PA
This section describes three of the common workows for the K2 Dyno PA application.
Content Management/Controller workow
This workow describes a role that principally deals with assets. The user can be manually exporting or transferring assets about the network, creating playlists, loading assets onto managed channels, creating rules for automatic transfers/exports, creating searches, managing repositories, setting up scheduled transfers, and adding keywords to assets.
Logger workow
This workow is more about metadata enrichment of record trains from the K2 Dyno Replay Controller. Users load source clips into the Browse pane and then using the keyframe logging mode add keyframes (keywords with timecode context) to assets. Users can also add Dyno P A ke ywords to Dyno highlights or other assets in the system.
Judiciary/Review workow
This workow describes the use of the Browse pane to review footage from a live event from multiple angles, possibly as part of a formal judiciary process such as a video referee. The Browse, Recording Assets and K eyframe panes are used to quickly nd points within the record trains and then to switch between trains keeping the current timecode context.
15 October 2010 Dyno Production Assistant User Manual 13
About K2 Dyno Production Assistant
About bins
Bins are folders on a K2 system. You can create or delete a bin on a K2 system, but bins cannot be renamed from K2 Dyno PA.
About repositories
A K2 Dyno P A repository can be used to transfer , import or export assets. A repository acts as a shortcut to a location on the network that can be used to transfer assets from or to Dyno PA. If you delete a repository from Dyno PA, the shortcut is deleted; the assets in the repository itself are not affected.
In Dyno PA there are two types of repositories:
K2 system repository
K2 system repositories simply represent a bin on a K2 system in Dyno P A. Creating a K2 system repository allows you quick access to that bin. For example, if a bin is nested under several parent folders on a K2 system, creating a K2 system-based repository for this bin displays it under the top-level repository section in the Navigator pane, which makes it easy to locate. As a repository, you can also give the bin to a name more applicable to your particular workow.
File System repository
File system repositories import and export assets to and from K2 systems. Examples of le-system based repositories include: a USB drive mounted on a connected PC, a Network Attached Storage (NAS) driv e, or an Apple Macintosh-shared drive.
About K2 Dyno PA User Interface
The K2 Dyno PA user interface is composed of several panes that can be hidden or dragged to different areas of the screen. Highlighted items, such as bins, playlists, or managed channels, are displayed with a blue background.
14 Dyno Production Assistant User Manual 15 October 2010
About K2 Dyno Production Assistant
The Dyno PA panes are described below.
NOTE: If your Dyno PA system is not licensed to use a particular feature, that pane is not displayed in the Dyno PA application.
Navigator pane: Lists all the K2 systems that have been added as a serv er to the Dyno P A client, the current Dyno session, bins (folders on a K2 system), repositories (folders on a user-dened location), and any search queries that hav e been sa ved. The Refresh
and Filter buttons let you update the list or select which K2 systems you want to display. You can add, edit or delete servers, bins, repositories, and searches in this pane.
Server Information pane: If a K2 system in the Navigator pane is highlighted, the Server Information pane displays, showing the status and version information of that K2 system. When the K2 system is not highlighted, the Server Information pane is not accessible.
15 October 2010 Dyno Production Assistant User Manual 15
About K2 Dyno Production Assistant
Playlist pane: Displays the playlist currently being edited. In this pane, clicking the Locate button causes the Asset List pane to display the bin on the K2 system
where this playlist is located. Asset List pane: Lists, either in thumbnail or list view, all the assets on the bin,
repository, or Dyno session currently highlighted in the Navigator pane. The Filter button lets you view all the assets in a system or view assets from a specic camera angle. The Sort button lets you group assets by criteria such as name, creation
date, rating, and so on. Rules pane: Displays all the rules currently congured. In this pane, you can add,
edit, activate or delete rules that tell K2 Dyno PA when to transfer an asset and where to transfer it to. Clicking the Rules tab displays the Rules pane if it is covered by other panes.
Managed Channels pane: Displays all the currently congured record and play channels on K2 systems that can be controlled through the Dyno PA application. If you have administrator-level privileges on Dyno PA, you can add, edit, or delete channels in addition to playing, recording, stopping, fast-forwarding, rewinding, or ejecting assets or putting an asset in loop playback mode. Clicking the Managed Channels tab displays the Managed Channels pane if it is covered by other panes.
Recording Assets pane: Displays all the records currently in progress on the K2 systems. You can view the records in list or thumbnail view, browse a record or load it to one of the K2 systems. The tabs above the record trains let you choose whether to view record trains on one K2 system or all av ailable systems. Clicking the Recording Assets tab displays the Recording Assets pane if it is covered by other panes.
T ransfer Scheduler pane: Displays the scheduled transfers. You can add, edit, cancel or delete scheduled transfers in this pane. Clicking the Transfer Scheduler tab displays the Transfer Scheduler pane if it is covered by other panes.
Browse pane:Allows you to load assets from a K2 Summit system and view them in Dyno PA. You can create cue points, mark in or mark out points, create subclips, unload the asset or locate it in the Asset List, and toggle between Live mode and
Keyframe Logging mode. In this pane, clicking the Locate button causes the Asset List pane to display the bin on the K2 Summit system where the asset loaded in the Browse pane is located.
Info pane: Allows you to view the video and keyword information of a highlighted asset. Clicking the Info tab displays the Info pane if it is covered by other panes. In
this pane, clicking the Locate button causes the Asset List pane to display the bin on the K2 system where the asset loaded in the Info pane is located.
Active Transfer pane: Allows you to view transfers currently in progress as well as failed transfers, if any. Clicking the Active Transfer tab displays the Active Transfer pane if it is covered by other panes.
16 Dyno Production Assistant User Manual 15 October 2010
