Grandstream Networks, Inc.
GWN7610/GWN7600/GWN7600LR
Wireless Access Points
User Manual
GWN7610
Enterprise 802.11ac
WiFi Access Point
GWN7600
Mid-Tier 802.11ac Wave-2
WiFi Access Point
GWN7600LR
Outdoor Long Range 802.11ac
Wave-2 WiFi Access point
P a g e | 2
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
COPYRIGHT
©2018 Grandstream Networks, Inc. http://www.grandstream.com
All rights reserved. Information in this document is subject to change without notice. Reproduction or
transmittal of the entire or any part, in any form or by any means, electronic or print, for any purpose
without the express written permission of Grandstream Networks, Inc. is not permitted.
The latest electronic version of this guide is available for download here:
http://www.grandstream.com/support
Grandstream is a registered trademark and Grandstream logo is trademark of Grandstream Networks, Inc.
in the United States, Europe and other countries.
CAUTION
Changes or modifications to this product not expressly approved by Grandstream, or operation of this
product in any way other than as detailed by this guide, could void your manufacturer warranty.
WARNING
Please do not use a different power adaptor with devices as it may cause damage to the products and
void the manufacturer warranty.
P a g e | 3
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
FCC Caution
Any Changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
P a g e | 4
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
GNU GPL INFORMATION
GWN7610/GWN7600/GWN7600LR firmware contains third-party software licensed under the GNU
General Public License (GPL). Grandstream uses software under the specific terms of the GPL. Please
see the GNU General Public License (GPL) for the exact terms and conditions of the license.
Grandstream GNU GPL related source code can be downloaded from Grandstream web site:
http://www.grandstream.com/support/faq/gnu-general-public-license
P a g e | 5
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Table of Contents
DOCUMENT PURPOSE .............................................................................................. 12
CHANGE LOG ............................................................................................................. 13
Firmware Version 1.0.7.13 ..................................................................................................................13
Firmware Version 1.0.6.43 ..................................................................................................................13
Firmware Version 1.0.6.41 ..................................................................................................................14
Firmware Version 1.0.5.15 ..................................................................................................................14
Firmware Version 1.0.5.13 ..................................................................................................................14
Firmware Version 1.0.4.22 ..................................................................................................................15
Firmware Version 1.0.4.20 ..................................................................................................................15
Firmware Version 1.0.4.12 ..................................................................................................................15
Firmware Version 1.0.3.25 ..................................................................................................................15
Firmware Version 1.0.3.21 ..................................................................................................................15
Firmware Version 1.0.3.19 ..................................................................................................................16
Firmware Version 1.0.2.108 ................................................................................................................16
Firmware Version 1.0.2.15 ..................................................................................................................16
Firmware Version 1.0.1.31 ..................................................................................................................17
Firmware Version 1.0.1.27 ..................................................................................................................17
WELCOME .................................................................................................................. 18
PRODUCT OVERVIEW ............................................................................................... 20
Technical Specifications ......................................................................................................................20
INSTALLATION ........................................................................................................... 26
Equipment Packaging .........................................................................................................................26
GWN7610/GWN7600/GWN7600LR Access Point Ports ....................................................................28
Power and Connect GWN7610/GWN7600/GWN7600LR Access Point ............................................29
Warranty ..............................................................................................................................................30
P a g e | 6
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Wall and Ceiling Mount Installation for GWN7610/GWN7600 ............................................................30
Wall Mount ...................................................................................................................................30
Ceiling Mount ...............................................................................................................................31
Mounting Instructions for GWN7600LR .......................................................................................32
GETTING STARTED .................................................................................................... 33
LED Patterns .......................................................................................................................................33
Discover the GWN7610/GWN7600/GWN7600LR ..............................................................................34
Method1: Discover the GWN7610/GWN7600/GWN7600LR using its MAC address .................34
Method 2: Discover the GWN7610/GWN7600/GWN7600LR using GWN Discovery Tool .........35
Use the Web GUI ................................................................................................................................35
Access Web GUI .........................................................................................................................36
WEB GUI Languages ..................................................................................................................37
Overview Page ............................................................................................................................38
Save and Apply Changes ............................................................................................................39
GWN.CLOUD ............................................................................................................... 40
USING GWN76XX AS STANDALONE ACCESS POINT ............................................ 41
Connect to GWN76xx Default Wi-Fi Network .....................................................................................41
USING GWN76XX AS MASTER ACCESS POINT CONTROLLER ............................ 42
Login Page ..........................................................................................................................................43
Discover and Pair Other GWN76xx Access Point ..............................................................................43
AP Location .........................................................................................................................................47
Transfer AP – Transfer Network Group ..............................................................................................47
Failover Master ...................................................................................................................................47
Failover Mode ..............................................................................................................................48
Client Bridge .......................................................................................................................................49
SSID ............................................................................................................................. 50
CLIENTS CONFIGURATION ....................................................................................... 57
P a g e | 7
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Clients .................................................................................................................................................57
Clients Access .....................................................................................................................................58
Time Policy ..........................................................................................................................................60
Banned Clients ....................................................................................................................................61
CAPTIVE PORTAL ...................................................................................................... 62
Guest...................................................................................................................................................62
Policy List ............................................................................................................................................63
Internal Splash Page ...................................................................................................................64
External Splash Page ..................................................................................................................67
Splash Page ........................................................................................................................................68
Vouchers .............................................................................................................................................69
Voucher Feature Description .......................................................................................................69
Voucher Configuration .................................................................................................................70
Using Voucher with GWN Captive Portal ....................................................................................73
MESH NETWORK ....................................................................................................... 75
BANDWIDTH RULES .................................................................................................. 78
SYSTEM SETTINGS .................................................................................................... 80
Maintenance .......................................................................................................................................80
Basic ............................................................................................................................................80
Upgrade .......................................................................................................................................80
Access .........................................................................................................................................82
Syslog ..........................................................................................................................................82
Logserver .....................................................................................................................................83
Debug .................................................................................................................................................84
Capture (GWN7610/GWN7600 Only) .........................................................................................84
Core Files ....................................................................................................................................87
Ping/Traceroute ...........................................................................................................................87
Syslog ..........................................................................................................................................88
P a g e | 8
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Email/Notification ................................................................................................................................89
DHCP Sever .......................................................................................................................................91
Static DHCP ........................................................................................................................................92
SCHEDULE ................................................................................................................. 94
LED SCHEDULE ......................................................................................................... 96
UPGRADING AND PROVISIONING ........................................................................... 97
Upgrading Firmware ...........................................................................................................................97
Upgrading via Web GUI ...............................................................................................................97
Upgrading Slave Access Points ..........................................................................................................98
Sequential Upgrade .....................................................................................................................99
Provisioning and Backup ..................................................................................................................100
Download Configuration ............................................................................................................100
Upload Configuration .................................................................................................................100
Configuration Server ..................................................................................................................101
Reset and reboot ..............................................................................................................................101
Syslog ...............................................................................................................................................101
EXPERIENCING THE GWN76XX WIRELESS ACCESS POINTS ............................ 102
P a g e | 9
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Table of Tables
Table 1: GWN7610 Technical Specifications ............................................................................................ 20
Table 2: GWN7600 Technical Specifications ............................................................................................ 21
Table 3: GWN7600LR Technical Specifications ........................................................................................ 23
Table 4: GWN7610/GWN7600 Equipment Packaging .............................................................................. 26
Table 5: GWN7600LR Equipment Packaging ........................................................................................... 27
Table 6: GWN7610/GWN7600 Ports Description ..................................................................................... 28
Table 7: GWN7600LR Ports Description ................................................................................................... 28
Table 8: LED Patterns ............................................................................................................................... 33
Table 9: Overview ...................................................................................................................................... 38
Table 10: Device Configuration ................................................................................................................. 45
Table 11: Wi-Fi........................................................................................................................................... 51
Table 12: Time Policy Parameters ............................................................................................................ 60
Table 13: Captive Portal – Policy List – Splash Page is “Internal” ............................................................ 64
Table 14: Captive Portal – Policy List – Splash Page is “External” ........................................................... 67
Table 15: Voucher Parameters .................................................................................................................. 72
Table 16: Mesh configuration .................................................................................................................... 77
Table 17: Bandwidth Rules........................................................................................................................ 78
Table 18: Basic .......................................................................................................................................... 80
Table 19: Upgrade ..................................................................................................................................... 81
Table 20: Access ....................................................................................................................................... 82
Table 21: Syslog Parameters .................................................................................................................... 83
Table 22: Logserver Parameters ............................................................................................................... 83
Table 23: Debug ........................................................................................................................................ 85
Table 24: Email Setting ............................................................................................................................. 89
Table 25: Email Events .............................................................................................................................. 90
Table 26: DHCP Server Parameters ......................................................................................................... 91
Table 27: LEDs .......................................................................................................................................... 96
Table 28: Network Upgrade Configuration ................................................................................................ 97
P a g e | 10
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Table of Figures
Figure 1: GWN7610 or GWN7600 Equipment Package ........................................................................... 26
Figure 2: GWN7600LR Equipment Package ............................................................................................ 27
Figure 3: GWN7610/GWN7600 & GWN7600LR Ports ............................................................................. 28
Figure 4: Connecting GWN AP - GWN7600 as example .......................................................................... 29
Figure 5: Wall Mount – Steps 1 & 2 .......................................................................................................... 30
Figure 6: Wall Mount – Steps 3 & 4 .......................................................................................................... 30
Figure 7: Wall Mount – Steps 5 & 6 .......................................................................................................... 30
Figure 8: Ceiling Mount – Steps 1 & 2 ...................................................................................................... 31
Figure 9: Ceiling Mount – Step 3 .............................................................................................................. 31
Figure 10: Ceiling Mount – Step 4 ............................................................................................................ 31
Figure 11: Ceiling Mount – Steps 5 & 6 .................................................................................................... 31
Figure 12: GWN7600LR Vertical Mounting ............................................................................................... 32
Figure 13: GWN7600LR Horizontal Mounting .......................................................................................... 32
Figure 14: Discover the GWN7610/GWN7600/GWN7600LR using its MAC Address ............................. 34
Figure 15: GWN Discovery Tool ................................................................................................................ 35
Figure 16: GWN7610/GWN7600/GWN7600LR Web GUI Login Page ..................................................... 36
Figure 17: Change Password on First Boot .............................................................................................. 37
Figure 18: GWN7610/GWN7600/GWN7600LR Web GUI Language (Login page) ................................. 37
Figure 19: GWN7610/GWN7600/GWN7600LR Web GUI Language (Web Interface) ............................. 37
Figure 20: GWN76xx Dashboard (GWN7600 as example) ...................................................................... 38
Figure 21: Apply Changes ......................................................................................................................... 39
Figure 22: GWN.Cloud Login Page .......................................................................................................... 40
Figure 23: MAC Tag Label ........................................................................................................................ 41
Figure 24: Login Page ............................................................................................................................... 42
Figure 25: Setup Wizard ........................................................................................................................... 43
Figure 26: Discover and Pair GWN7610/GWN7600/GWN7600LR .......................................................... 44
Figure 27: Discovered Devices ................................................................................................................. 44
Figure 28: GWN7610/GWN7600/GWN7600LR Online ............................................................................ 45
Figure 29: Failover Master ........................................................................................................................ 48
Figure 30: Failover Mode GUI ................................................................................................................... 49
Figure 31: Client Bridge ............................................................................................................................ 49
Figure 32: SSID ......................................................................................................................................... 50
Figure 33: Add a new SSID ....................................................................................................................... 50
Figure 34: Device Membership ................................................................................................................. 56
Figure 35: Clients ...................................................................................................................................... 57
Figure 36: Clients - Select Items ............................................................................................................... 58
Figure 37: Global Blacklist ........................................................................................................................ 58
P a g e | 11
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 38: Managing the Global Blacklist ................................................................................................. 59
Figure 39: Adding Client Access List ......................................................................................................... 59
Figure 40: Adding New Access List ........................................................................................................... 59
Figure 41: Blacklist Access List ................................................................................................................. 60
Figure 42: Ban/Unban Client ..................................................................................................................... 61
Figure 43: Captive Portal – Guest Page ................................................................................................... 62
Figure 44: Captive Portal - Guest Page - Select Items ............................................................................. 62
Figure 45: Captive Portal - Policy List ....................................................................................................... 63
Figure 46: Add a New Policy ..................................................................................................................... 64
Figure 47: Authentication rules ................................................................................................................. 68
Figure 48: Captive Portal – Splash Page .................................................................................................. 69
Figure 49: Add Voucher Sample ............................................................................................................... 71
Figure 50: Vouchers List ........................................................................................................................... 72
Figure 51: Captive Portal with Voucher authentication ............................................................................. 74
Figure 52: Access Points Status ............................................................................................................... 76
Figure 53: Mesh settings ........................................................................................................................... 76
Figure 54: MAC Address Bandwidth Rule ................................................................................................. 79
Figure 55: Bandwidth Rules ...................................................................................................................... 79
Figure 56: Capture Page ........................................................................................................................... 85
Figure 57: Capture Files ............................................................................................................................ 86
Figure 58: IP Ping ..................................................................................................................................... 87
Figure 59: IP Traceroute ........................................................................................................................... 88
Figure 60: Syslog ...................................................................................................................................... 88
Figure 61: Email ........................................................................................................................................ 89
Figure 62: Notification ............................................................................................................................... 90
Figure 63: DHCP Binding .......................................................................................................................... 92
Figure 64: Static DHCP Devices List ........................................................................................................ 93
Figure 65: Create New Schedule .............................................................................................................. 94
Figure 66: Schedules List .......................................................................................................................... 95
Figure 67: LED Scheduling Sample .......................................................................................................... 96
Figure 68: Access Points ........................................................................................................................... 99
Figure 69: Choosing multiple devices ....................................................................................................... 99
Figure 70: All-at-Once and Sequential Upgrade ..................................................................................... 100
P a g e | 12
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
DOCUMENT PURPOSE
This document describes how to configure the GWN7610/GWN7600/GWN7600LR via Web GUI in
standalone mode, with other GWN76XX Access Points as Master/Slave architecture and more. The
intended audiences of this document are network administrators. Please visit
http://www.grandstream.com/support to download the latest “GWN7610/GWN7600/GWN7600LR User
Manual”.
This guide covers following topics:
• Product Overview
• Installation
• Getting Started
• GWN.Cloud
• Using GWN7610/GWN7600/GWN7600LR as Standalone Access Point
• Using GWN7610/GWN7600/GWN7600LR as Master Access Point Controller
• Failover Master
• Client Bridge
• SSIDs
• Clients Configuration
• System Settings
• LED Schedule
• Captive Portal
• Vouchers
• Mesh Network
• Bandwidth Rules
• DHCP Server
• Schedule
• LED Schedule
• Maintenance
• Upgrading and Provisioning
• Experiencing the GWN76xx Wireless Access Point
P a g e | 13
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
CHANGE LOG
This section documents significant changes from previous versions of the
GWN7610/GWN7600/GWN7600LR user manuals. Only major new features or major document updates
are listed here. Minor updates for corrections or editing are not documented here.
Firmware Version 1.0.7.13
Product Name: GWN7610 / GWN7600 / GWN7600LR
• Added support of Radio Resource Management (RRM). [Dynamic Channel Assignment] [Transmit
Power Control] [Coverage Hole Detection]
• Added Mesh for GWN7610. [MESH NETWORK]
• Added External Captive Portal support. [External Splash Page]
• Added AP Scheduling Reboot. [Reboot Schedule]
• Enhanced WiFi Service by adding configurable options of [Beacon Interval], [DTIM Period], and
[Multicast to Unicast].
• Enhanced Client Information. [Clients]
• Enhanced Captive Portal features. [Failsafe Mode] [Byte Limit] [Enable Daily Limit] [Force to
Follow]
• Added Static DHCP feature [Static DHCP]
Firmware Version 1.0.6.43
Product Name: GWN7610
• Added date time display on Overview Page. [Overview Page]
• Added new feature scheduling module. [SCHEDULE]
• Added possibility to print/delete multiple vouchers. [Vouchers]
• Added expiration period to vouchers. [Vouchers]
• Added DHCP Server. [DHCP Sever]
• Added support for GWN.Cloud. [GWN.CLOUD]
• Added support for Transfer AP and Transfer Network Group. [Transfer AP – Transfer Network
Group]
P a g e | 14
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Firmware Version 1.0.6.41
Product Name: GWN7600 / GWN7600LR
• Added date time display on Overview Page. [Overview Page]
• Added new feature scheduling module. [SCHEDULE]
• Added possibility to print/delete multiple vouchers. [Vouchers]
• Added expiration period to vouchers. [Vouchers]
• Added DHCP Server. [DHCP Sever]
• Added support for GWN.Cloud [GWN.CLOUD]
• Added support for Transfer AP and Transfer Network Group. [Transfer AP – Transfer Network
Group]
• Added support for Outdoor/Indoor Scene WiFi channel configuration (Applicable for GWN7600LR
Only). [Scene]
Firmware Version 1.0.5.15
Product Name: GWN7610
• Added support for New Firmware Reminder on Master Web [New Firmware Notification]
• Added support for Sequential Upgrade [Sequential Upgrade]
• Added support for Feature Scheduling [SCHEDULE]
• Added support for Master Direction. [Master Direction]
• Added support for Master Transfer [Transfer to Master]
• Added support for Airtime Fairness [Airtime Fairness]
• Added support for Social login/Voucher [Vouchers]
Firmware Version 1.0.5.13
Product Name: GWN7600 / GWN7600LR
• Added support for New Firmware Reminder on Master Web [New Firmware Notification]
• Added support for Sequential Upgrade [Sequential Upgrade]
• Added support for Feature Scheduling [SCHEDULE]
• Added support for Master Transfer [Transfer to Master]
• Added support for Master Direction. [Master Direction]
• Added support for Airtime Fairness [Airtime Fairness]
• Added support for Social login/Voucher [Vouchers]
• Added support for Mesh Network [MESH NETWORK]
P a g e | 15
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Firmware Version 1.0.4.22
Product Name: GWN7610
• Included patch for WPA2 4-way handshake vulnerability [VU#228519]
Firmware Version 1.0.4.20
Product Name: GWN7610
• Added support for Timed Client Disconnect and Enhanced Client Blocking [CLIENTS
CONFIGURATION]
• Added support for Client Bridge [Client Bridge]
• Added support for Syslog server [Syslog]
• Added support for Configurable Web UI access port [Web HTTP Access]
• Added support for E-mail notifications [Email/Notification]
Firmware Version 1.0.4.12
Product Name: GWN7600 / GWN7600LR
• Added support for Timed Client Disconnect and Enhanced Client Blocking [CLIENTS
CONFIGURATION]
• Added support for Client Bridge [Client Bridge]
• Added support for Syslog server [Syslog]
• Added support for Configurable Web UI access port [Web HTTP Access]
• Added support for E-mail notifications [Email/Notification]
• Included patch for WPA2 4-way handshake vulnerability [VU#228519]
Firmware Version 1.0.3.25
Product Name: GWN7600 / GWN7600LR
• No major changes.
Firmware Version 1.0.3.21
Product Name: GWN7610
• No major changes.
P a g e | 16
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Firmware Version 1.0.3.19
Product Name: GWN7610 / GWN7600 / GWN7600LR
• Added support for captive portal [CAPTIVE PORTAL]
• Added support for 802.11k/r/v [Enable Voice Enterprise]
• Added support for failover master [Failover Master]
• Added support for VLAN assignment via RADIUS [Enable Dynamic VLAN]
• Added support for Select SSID Band [SSID Band]
• Added support for Exact Radio Power Configuration in dBm [Custom Wireless Power]
• Added support for AP Location [AP Location]
• Added support for Per-Client/Per-SSID bandwidth rules [BANDWIDTH RULES]
• Added option to limit clients count per SSID [Wireless Client Limit]
• Added support for WiFi Schedule [SCHEDULE]
• Added support for LED control [LED SCHEDULE]
• Added option to enable/disable DHCP option 66 & 43 override [Allow DHCP options 66 and 43
override]
Firmware Version 1.0.2.108
Product Name: GWN7610
• Added Controller protocol security enhancement. [Controller Protocol Security Enhancement]
• Added support for LED control. [LED SCHEDULE]
• Added support for Captive Portal. [CAPTIVE PORTAL]
• Added support for Wi-Fi schedule. [SCHEDULE]
• Added Client Isolation enhancement. [Client Isolation]
• Added support to store Syslog locally on the unit and display it on Web GUI. [Syslog]
Firmware Version 1.0.2.15
Product Name: GWN7610
• Added New Overview Page.
• Added Web UI enhancement.
• Added support for Password change on first boot. [Figure 17: Change Password on First Boot]
• Added Country code selection into setup wizard.
P a g e | 17
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Firmware Version 1.0.1.31
Product Name: GWN7600 / GWN7600LR
• This is the initial version.
Firmware Version 1.0.1.27
Product Name: GWN7610
• This is the initial version.
P a g e | 18
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
WELCOME
Thank you for purchasing Grandstream GWN7610/GWN7600/GWN7600LR Enterprise Wireless Access
Point.
The GWN7610 is a high-performance 802.11ac wireless access point for small to medium sized
businesses, multiple floor offices, commercial locations and branch offices. It offers dual-band 3x3:3 MIMO
technology and a sophisticated antenna design for maximum network throughput and expanded Wi-Fi
coverage range. To ensure easy installation and management, the GWN7610 uses a controller-less
distributed network management design in which the controller is embedded within the product’s Web user
interface. This allows each access point to manage a network of up to 50 GWN76XX independently without
needing seperate controller hardware/software and without a single point-of-failure.
The GWN7600 is a mid-tier Wave-2 802.11ac WiFi access point for small to medium sized businesses,
multiple floor offices, commercial locations and branch offices. The GWN7600LR Outdoor Long-range
802.11ac Wave-2 Wi-Fi Access Point is designed to provide extended coverage support. Ideal for outdoor
Wi-Fi solutions thanks to its waterproof casing and heat resistant technology. The GWN7600/GWN7600LR
come equiped with dual-band, 2x2:2 MU-MIMO with beam-forming technology and a sophisticated
antenna design for maximum network throughput and expanded Wi-Fi coverage range for both Indoor
(GWN7600) and Outdoor deployement (GWN7600LR).
To ensure easy installation and management, the GWN7600/GWN7600LR uses a controller-less
distributed network management design in which the controller is embedded within the product’s web user
interface. This allows each access point to manage a network of up to 30 GWN76XX series APs
independently without needing separate controller hardware/software and without a single point-of-failure.
This wireless access point can be paired with any third party routers as well as Grandstream GWN series
routers. With support for advanced QoS, low-latency real-time applications, 450+ concurrent client devices
per AP and dual Gigabit network ports with PoE, the GWN7600/GWN7600LR is an ideal WiFi access point
for medium wireless network deployments with medium-to-high user density.
P a g e | 19
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Caution:
Changes or modifications to this product not expressly approved by Grandstream, or operation of this
product in any way other than as detailed by this User Manual, could void your manufacturer warranty.
Note (VU#228519): “Out of the box” Grandstream Access Points are not affected by this issue. APs with
old firmware are only affected after changing into client-bridge mode. Please refer to our white paper of
“WPA Security Vulnerability” here.
P a g e | 20
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
PRODUCT OVERVIEW
Technical Specifications
Table 1: GWN7610 Technical Specifications
Wi-Fi Standards
IEEE 802.11 a/b/g/n/ac
Antennas
3x 2.4 GHz, gain 3 dBi, internal antenna
3x 5 GHz, gain 3 dBi, internal antenna
Wi-Fi Data Rates
IEEE 802.11ac: 6.5 Mbps to 1300 Mbps
IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
IEEE 802.11n: 6.5 Mbps to 450 Mbps
IEEE 802.11b: 1, 2, 5.5, 11 Mbps
IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
*Actual throughput may vary depending on many factors including environmental conditions,
distance between devices, radio interference in the operating environment and mix of
devices in the network
Frequency Bands
2.4GHz radio: 2.400 - 2.4835 GHz
5GHz radio: 5.150 - 5.250 GHz, 5.725 - 5.850 GHz (FCC, IC, RCM)
Channel Bandwidth
2.4G: 20 and 40 MHz
5G: 20,40 and 80 MHz
Wi-Fi and System
Security
WEP, WPA/WPA2‐PSK, WPA/WPA2‐Enterprise (TKIP/AES), anti-hacking secure
boot and critical data/control lockdown via digital signatures, unique security
certificate and random default password per device
MIMO
3x3:3 2.4GHz, 3x3:3 5GHz
Coverage Range
575ft. (175 meters)
*coverage range can vary based on environment
Maximum TX Power
5G: 26dBm (FCC) / 20dBm (CE)
2.4G: 26dBm (FCC) / 17dBm (CE)
*Maximum power varies by country, frequency band and MCS rate
Receiver Sensitivity
2.4G
802.11b:-92dBm@11Mbps; 802.11g:-76dBm@54Mbps; 802.11n 20MHz:
-73dBm@MCS7; 802.11n 40MHz:-70dBm@MCS7
5G
802.11a:-94dBm@6Mbps; 801.11a:-77dBm@54Mbps; 802.11ac 20MHz:
P a g e | 21
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
-69dBm@MCS8; 802.11ac HT40:-65dBm@MCS9; 802.11ac 80MHz:
1dBm@MCS9
* Receiver sensitivity varies by frequency band, channel width and MCS rate
SSIDs
16 SSIDs per access point
Concurrent Clients
250+
Network Interfaces
2x autosensing 10/100/1000 Base-T Ethernet Ports
Auxiliary Ports
1x USB 2.0 port, 1x Reset Pinhole, 1x Kensington lock
Mounting
Indoor wall mount or ceiling mount, kits included
LEDs
3 multi-color LEDs for device tracking and status indication
Network Protocols
IPv4, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
QoS
802.11e/WMM, VLAN, TOS
Network
Management
Embedded controller in GWN7610 allows it to auto-discover, auto-provision and
manage up to 50 GWN7610s in a network
Auto Power Saving
Self-power adaptation upon auto detection of PoE or PoE+
Power and Green
Energy Efficiency
DC Input: 24VDC/1A
Power over Ethernet 802.3af/802.3at compliant
Maximum Power Consumption: 13.8W
Environmental
Operation: 0°C to 50°C
Storage: -10°C to 60°C
Humidity: 10％ to 90% Non-condensing
Physical
Unit Dimension: 205.3 x 205.3 x 45.9mm; Unit Weight: 540g
Unit + Mounting Kits Dimension: 205.3 x 205.3 x 50.9mm; Unit + Mounting Kits
Weight: 600g
Entire Package Dimension: 258 x 247 x 86mm; Entire Package Weight: 900g
Package Content
GWN7610 802.11ac Wireless AP, Mounting Kits, Quick Start Guide
Compliance
FCC, CE, RCM, IC
Table 2: GWN7600 Technical Specifications
Wi-Fi Standards
IEEE 802.11 a/b/g/n/ac (Wave-2)
Antennas
2x 2.4 GHz, gain 3 dBi, internal antenna
2x 5 GHz, gain 3 dBi, internal antenna
Wi-Fi Data Rates
IEEE 802.11ac: 6.5 Mbps to 877 Mbps
IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
IEEE 802.11n: 6.5 Mbps to 300 Mbps; 400 Mbps with 256-QAM on 2.4GHz
P a g e | 22
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
IEEE 802.11b: 1, 2, 5.5, 11 Mbps
IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
*Actual throughput may vary depending on many factors including environmental
conditions, distance between devices, radio interference in the operating
environment and mix of devices in the network.
Frequency Bands
2.4GHz radio : 2.400 - 2.4835 GHz
5GHz radio: 5.150 - 5.250 GHz, 5.725 - 5.850 GHz
Channel Bandwidth
2.4G: 20 and 40 MHz
5G: 20,40 and 80 MHz
Wi-Fi and System
Security
WEP, WPA/WPA2‐PSK, WPA/WPA2‐Enterprise (TKIP/AES), anti-hacking secure
boot and critical data/control lockdown via digital signatures, unique security
certificate and random default password per device.
MIMO
2x2:2 2.4GHz, 2x2:2 5GHz
Coverage Range
Up to 541ft. (165 meters) for GWN7600.
*Coverage range can vary based on environment
Maximum TX Power
5G: 22dBm
2.4G: 22dBm
*Maximum power varies by country, frequency band and MCS rate.
Receiver Sensitivity
2.4G
802.11b:-99dBm @1Mbps,-91dBm @11Mbps;802.11g:-93dBm @6Mbps,-
75dBm @54Mbps; 80.11n 20MHz:-72dBm @MCS7;802.11n 40MHz:-69dBm
@MCS7
5G
802.11a:-91dBm @6Mbps,-74dBm @54Mbps;802.11ac 20MHz:-67dBm
@MCS8;802.11ac HT40:-63dBm @MCS9;802.11ac 80MHz:-60dBm @MCS9
BSSID
16 SSIDs per radio
Concurrent Clients
450+
Network Interfaces
2x autosensing 10/100/1000 Base-T Ethernet Ports
Auxiliary Ports
1x USB 2.0 port, 1x Reset Pinhole, 1x Kensington lock
Mounting
Indoor wall mount or ceiling mount, kits included
LEDs
multi-color LEDs for device tracking and status indication
Network Protocols
IPv4, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
QoS
802.11e/WMM, VLAN, TOS
P a g e | 23
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Network
Management
Embedded controller in GWN7600 allows it to auto-discover, auto-provision and
manage up to 30 GWN76XX in a network
Power and Green
Energy Efficiency
DC Input: 24VDC/1A
Power over Ethernet (802.3af) compliant
Maximum Power Consumption: 13.8W
Temperature
& Humidity
Operation: 0°C to 40°C
Storage: -10°C to 60°C
Humidity: 10％ to 90% Non-condensing
Physical
Unit Dimension: 205.3 x 205.3 x 45.9mm; Unit Weight: 526g
Unit + Mounting Kits Dimension: 205.3 x 205.3 x 53.9mm; Unit + Mounting Kits
Weight : 610g
Entire Package Dimension: 228.5*220*79mm; Entire Package Weight: 854g
Package Content
GWN7600 Wave-2 802.11ac Wireless AP, Mounting Kits, Quick Installation Guide
Compliance
FCC, CE, RCM, IC
Table 3: GWN7600LR Technical Specifications
Wi-Fi Standards
IEEE 802.11 a/b/g/n/ac (Wave-2)
Antennas
2x 2.4 GHz, gain 4 dBi, internal antenna
2x 5 GHz, gain 5 dBi, internal antenna
Wi-Fi Data Rates
IEEE 802.11ac: 6.5 Mbps to 867 Mbps
IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
IEEE 802.11n: 6.5 Mbps to 300 Mbps; 400Mbps with 256-QAM on 2.4GHz
IEEE 802.11b: 1, 2, 5.5, 11 Mbps
IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
*Actual throughput may vary depending on many factors including environmental conditions, distance
between devices, radio interference in the operating environment and mix of devices in the network
Frequency Bands
2.4GHz radio: 2.400 - 2.4835 GHz
5GHz radio: 5.150 - 5.250 GHz, 5.725 - 5.850 GHz
Channel Bandwidth
2.4G: 20 and 40 MHz
5G: 20,40 and 80 MHz
Wi-Fi and System
Security
WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES), anti-hacking secure
boot and critical data/control lockdown via digital signatures, unique security
certificate and random default password per device
MIMO
2x2:2 2.4GHz (MIMO), 2x2:2 5GHz (MU-MIMO)
P a g e | 24
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Coverage Range
Up to 984ft. (300 meters)
*Coverage range can vary based on environment
Maximum TX
Power
5G: 22dBm (FCC) / 20dBm (CE)
2.4G: 22dBm (FCC) / 17dBm (CE)
*Maximum power varies by country, frequency band and MCS rate
Receiver
Sensitivity
2.4G
802.11b: -99dBm@1Mbps, -91dBm@11Mbps; 802.11g:-93dBm@6Mbps,
-75dBm@54Mbps; 802.11n 20MHz: -72dBm@MCS7; 802.11n 40MHz:
-69dBm @MCS7
5G
802.11a: -91dBm@6Mbps, -74dBm@54Mbps; 802.11ac 20MHz: -67dBm@MCS8;
802.11ac; HT40: -63dBm@MCS9; 802.11ac 80MHz: -60dBm@MCS9
SSIDs
16 SSIDs per access point
Concurrent Clients
450+
Network Interfaces
2x autosensing 10/100/1000 Base-T Ethernet Ports
Auxiliary Ports
1x Reset Pinhole
Mounting
Outdoor base bracket and cover bracket included
LEDs
multicolor LED for device tracking and status indication
Network Protocols
IPv4, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
QoS
802.11e/WMM, VLAN, TOS
Network
Management
Embedded controller in GWN7600LR allows it to auto-discover, auto-provision and
manage up to 30 GWN76XXs in a network
Power and Green
Energy Efficiency
Power over Ethernet 802.3af and 802.3at compliant
Maximum Power Consumption:
▪ 12.9 W (PoE supply)
▪ 23.0 W (PoE+ supply)
Temperature
& Humidity
Operation: -30°C to 60°C
Storage: -30°C to 70°C
Humidity: 5% to 95% Non-condensing
Physical
Unit Dimension: 290×150×35mm; Unit Weight: 708g
Unit + Mounting Kits Dimension: 290×150×56mm;
Unit + Mounting Kits Weight: 1528.2g
Entire Package Dimension: 423×187×97mm;
Entire Package Weight: 1844g
P a g e | 25
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Package Content
Enterprise 802.11ac Wave-2 Outdoor Long Range WiFi Access Point, Mounting
Kits, Quick Installation Guide
Waterproof Grade
IP66-level weatherproof capability when installed vertically
Compliance
FCC, CE, RCM, IC
P a g e | 26
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
INSTALLATION
Before deploying and configuring the GWN7610/GWN7600/GWN7600LR, the device needs to be properly
powered up and connected to the network. This section describes detailed information on installation,
connection and warranty policy of the GWN7610/GWN7600/GWN7600LR.
Equipment Packaging
Table 4: GWN7610/GWN7600 Equipment Packaging
Main Case (GWN7610 or GWN7600)
Yes (1)
Mounting Bracket
Yes (1)
Ceiling Mounting Bracket
Yes (1)
Plastic Expansion Bolt
Yes (3)
M3 NUT
Yes (3)
Screw (PM 3 x 50)
Yes (3)
Screw (PM 3.5 x 20)
Yes (3)
Quick Installation Guide
Yes (1)
GPL License
Yes (1)
Figure 1: GWN7610 or GWN7600 Equipment Package
GWN7610 or GWN7600
P a g e | 27
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Below is the equipment packaging for GWN7600LR model.
Table 5: GWN7600LR Equipment Packaging
Main Case
Yes (1)
Cover Interface
Yes (1)
Base Bracket
Yes (1)
Cover Bracket
Yes (1)
Assembled Screw
Yes (4)
Locknut
Yes (4)
Anchors + Screws
Yes (4)
Screw (PM8 x 115)
Yes (4)
Quick Installation Guide
Yes (1)
GPL License
Yes (1)
Figure 2: GWN7600LR Equipment Package
P a g e | 28
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
GWN7610/GWN7600/GWN7600LR Access Point Ports
Figure 3: GWN7610/GWN7600 & GWN7600LR Ports
Table 6: GWN7610/GWN7600 Ports Description
Port
Description
Power
Power adapter connector (24V, 1A)
NET/PoE
Ethernet RJ45 port (10/100/1000Mbps) supporting PoE (802.3af).
NET
Ethernet RJ45 port (10/100/1000Mbps) to your router or another
GWN76xx series
USB 2.0 port (for future IOT & location-based applications)
RESET
Factory reset button. Press for 7 seconds to reset factory default settings.
Table 7: GWN7600LR Ports Description
Port
Description
NET/PoE
Ethernet RJ45 port (10/100/1000Mbps) supporting PoE.
NET
Ethernet RJ45 port (10/100/1000Mbps) to your router or another
GWN76xx series.
RESET
Factory reset button. Press for 7 seconds to reset factory default settings.
P a g e | 29
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Power and Connect GWN7610/GWN7600/GWN7600LR Access Point
Step 1:
Connect one end of a RJ-45 Ethernet cable into the NET or PoE/NET port of the GWN7610/GWN7600;
PoE/NET port of the GWN7600LR.
Step 2:
Connect the other end of the Ethernet cable(s) into a LAN port to your Network. (Use PoE switch for
GWN7600LR).
Step 3:
For GWN7610/GWN7600 only, connect the 24V DC power adapter into the power jack on the back of the
access point. Insert the main plug of the power adapter into a surge-protected power outlet. Otherwise,
PoE can be used if the switchport does provide PoE power.
Notes:
• GWN7610/GWN7600LR can be powered using PoE(802.3af)/PoE+(802.3at) switch via PoE/NET
port while GWN7600 can be powered using PoE (802.3af) switch via PoE/NET port. In this case,
both power and network connectivity will be provided over the PoE/NET port.
• GWN7610 has a PoE detection daemon that will monitor the status and update maximum
allowable power for USB ports in real time.
Step 4:
Wait for the GWN7610/GWN7600/GWN7600LR to boot up and acquire an IP address from the DHCP
Server.
Figure 4: Connecting GWN AP - GWN7600 as example
P a g e | 30
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Warranty
If the GWN7610/GWN7600/GWN7600LR Wireless Access Point was purchased from a reseller, please
contact the company where the device was purchased for replacement, repair or refund. If the device was
purchased directly from Grandstream, contact our Technical Support Team for a RMA (Return Materials
Authorization) number before the product is returned. Grandstream reserves the right to remedy warranty
policy without prior notification.
Wall and Ceiling Mount Installation for GWN7610/GWN7600
GWN7610/GWN7600 can be mounted on the wall or ceiling, please refer to the following steps for the
appropriate installation.
Wall Mount
Step1:
Position the mounting bracket at the desired location on the wall
with the arrow pointing up.
Step 2:
Use a pencil to mark the four mounting holes (screw holes DIA
5.5mm, reticle hole DIA 25mm).
Step 3:
Insert screw anchors into the 5.5 mm holes. Attach the mounting
bracket to the wall by inserting the screws into the anchors.
Step 4:
Connect the power cable and the Ethernet cable (RJ45) to the
correct ports of your GWN7610/GWN7600.
Step 5:
Align the arrow on the GWN7610/GWN7600 AP with the arrow on
the locking tab of the mounting bracket and ensure that your GWN
is firmly seated on the mounting bracket.
Step 6:
Turn the GWN clockwise until it locks into place and fits the locking tab.
Figure 5: Wall Mount – Steps 1 & 2
Figure 7: Wall Mount – Steps 5 & 6
PA3.5 x 20 screw
Plastic Expansion Bolt
Figure 6: Wall Mount – Steps 3 & 4
P a g e | 31
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Ceiling Mount
Step 1:
Remove the ceiling tile.
Step 2:
Place the ceiling backing plate in the center of the ceiling tile and
mark the mounting screw holes (screw holes DIA 5.5mm, reticle
hole DIA 25mm).
Step 3:
Insert the screws through the mounting bracket.
Step 4:
Connect the power cable and the Ethernet cable (RJ45) to the
correct ports of your GWN7600.
Step 5:
Align the arrow on the GWN7600 AP with the arrow on the locking
tab of the mounting bracket and ensure that your GWN is firmly
seated on the mounting bracket and connect the network and
power cables.
Step 6:
Turn the GWN clockwise until it locks into place and fits the locking
tab.
Note:
Ceiling mounting is recommended for optimal coverage performance.
Figure 11: Ceiling Mount – Steps 5 & 6
Ceiling Mounting Bracket
M3 nut
M3.0x50 screw
Figure 10: Ceiling Mount – Step 4
Figure 9: Ceiling Mount – Step 3
Figure 8: Ceiling Mount – Steps 1 & 2
P a g e | 32
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Mounting Instructions for GWN7600LR
Please refer to the following steps for the mounting your GWN7600LR correctly.
1. Prepare the Cover Bracket by inserting the 4 screws (PM8) into corresponding holes.
2. Attach the Cover Bracket with screws on the vertical/horizontal Mounting Bolt were GWN7600LR
will be installed.
3. Assemble the Base Bracket with the Cover Bracket using provided locknuts and screws (PM8).
4. Connect the Ethernet cable (RJ45) to the correct ports of your GWN7600LR.
5. Align the GWN7600LR with the Base Bracket and pull it down to the right position.
6. Install the 2x Assembled screws to fix GWN7600LR on the Mounting Bolt.
Figure 12: GWN7600LR Vertical Mounting
Figure 13: GWN7600LR Horizontal Mounting
P a g e | 33
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
GETTING STARTED
The GWN7610/GWN7600/GWN7600LR Wireless Access Point provides an intuitive web GUI
configuration interface for easy management to give users access to all the configurations and options for
the GWN7610/GWN7600/GWN7600LR’s setup.
This section provides step-by-step instructions on how to read LED patterns, discover the
GWN7610/GWN7600/GWN7600LR and use its Web GUI interface.
LED Patterns
The panel of the GWN7610/GWN7600/GWN7600LR has different LED patterns for different activities, to
help users read the status of the GWN7610/GWN7600/GWN7600LR whether it’s powered up correctly,
provisioned, in upgrading process and more, for more details please refer to the below table.
Table 8: LED Patterns
LED Status
Indication
OFF
Unit is powered off or abnormal power supply.
Blinking green
Firmware update in progress.
Solid green
Firmware update successful.
Blinking red
Delete paired slave - Factory reset initiated.
Solid red
Firmware update failed.
Blinking purple
Unit not provisioned.
Solid purple
Unit not paired
Blinking blue
Unit provisioning in progress.
Solid blue
Unit is provisioned successfully.
Blinking White
Used for Access Point location feature
P a g e | 34
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Discover the GWN7610/GWN7600/GWN7600LR
Once the GWN7610/GWN7600/GWN7600LR is powered up and connected to the Network correctly,
users can discover the GWN7610/GWN7600/GWN7600LR using one of the below methods:
Method1: Discover the GWN7610/GWN7600/GWN7600LR using its MAC address
1. Locate the MAC address on the MAC tag of the unit, which is on the underside of the device, or
on the package.
2. From a computer connected to same Network as the GWN7610/GWN7600/GWN7600LR, type in
the following address using the GWN7610/GWN7600/GWN7600LR’s MAC address on your
browser https://gwn_<mac>.local
For example, if a GWN7610/GWN7600/GWN7600LR has the MAC address 00:0B:82:8B:58:30,
this unit can be accessed by typing https://gwn_000b828b5830.local/ on the browser.
Figure 14: Discover the GWN7610/GWN7600/GWN7600LR using its MAC Address
P a g e | 35
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Method 2: Discover the GWN7610/GWN7600/GWN7600LR using GWN Discovery Tool
1. Download and install GWN Discovery Tool from the following link:
http://www.grandstream.com/support/tools
2. Open the GWNDiscoveryTool, click on Select to define the network interface, then click on
Scan.
3. The tool will discover all GWN7610/GWN7600/GWN7600LR Access Points connected on the
network showing their MAC, IP addresses and firmware version.
4. Click on Manage Device to be redirected directly to the GWN7610/GWN7600/GWN7600LR's
configuration interface, or type in manually the displayed IP address on your browser.
Figure 15: GWN Discovery Tool
Use the Web GUI
Users can access then the GWN7610/GWN7600/GWN7600LR using its WebGUI, the following sections
will explain how to access and use the Web Interface.
P a g e | 36
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Access Web GUI
The GWN7610/GWN7600/GWN7600LR embedded Web server responds to HTTPS GET/POST requests.
Embedded HTML pages allow users to configure the device through a Web browser such as Microsoft IE,
Mozilla Firefox, Google Chrome and etc.
Figure 16: GWN7610/GWN7600/GWN7600LR Web GUI Login Page
To access the Web GUI:
1. Make sure to use a computer connected to the same local Network as the
GWN7610/GWN7600/GWN7600LR.
2. Ensure the device is properly powered up.
3. Open a Web browser on the computer and type in the URL using the MAC address as shown in
[Discover the GWN7610/GWN7600/GWN7600LR] or the IP address using the following format:
https://IP_Address
4. Enter the administrator’s login and password to access the Web Configuration Menu. The default
administrator's username and password are "admin" and "admin".
Note: At first boot or after factory reset, users will be asked to change the default administrator password
before accessing GWN7610/GWN7600/GWN7600LR Web interface.
The new password field is case sensitive with a maximum length of 32 characters. Using strong password
including letters, digits and special characters is recommended for better security.
P a g e | 37
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 17: Change Password on First Boot
WEB GUI Languages
Currently the GWN7610/GWN7600/GWN7600LR series web GUI supports English and Simplified
Chinese.
Users can select the displayed language at the upper right of the web GUI either before or after login.
Figure 18: GWN7610/GWN7600/GWN7600LR Web GUI Language (Login page)
Figure 19: GWN7610/GWN7600/GWN7600LR Web GUI Language (Web Interface)
P a g e | 38
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Overview Page
Overview is the first page shown after successful login to the GWN7610/GWN7600/GWN7600LR’s Web
Interface. Overview page provides an overall view of the GWN7610/GWN7600/GWN7600LR’s information
presented in a Dashboard style for easy monitoring along with firmware version and date-time information
at the top.
Figure 20: GWN76xx Dashboard (GWN7600 as example)
Users can quickly see the status of the GWN7610/GWN7600/GWN7600LR for different items, please refer
to the following table:
Table 9: Overview
AP
Shows the number of Access Point that are Discovered, Paired (Online)
and Offline. Users may click on to go to Access Points page for
basic and advanced configuration options for the APs
P a g e | 39
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Clients
Shows the total number of connected clients, and a count for clients
connected to each Channel. Users may click on to go to Clients
page for more options.
AP Channel Distribution
Shows the Channel used for all APs that are paired with this Access Point.
Top AP
Shows the Top APs list, users may assort the list by number of clients
connected to each AP or data usage combining upload and download.
Users may click on to go to Access Points page for basic and
advanced configuration options for the APs.
Top SSID
Shows the Top SSIDs list, users may assort the list by number of clients
connected to each SSID or data usage combining upload and download.
Users may click on to go to SSID page for more options.
Top Clients
Shows the Top Clients list, users may assort the list of clients by their
upload or download. Users may click on to go to Clients page for
more options.
Alert/Notification
Shows 3 types of Alert/Notifications: Critical, Major and Normal. Users can
click to pop up the list of Alert and Notifications.
Note that Overview page in addition to other tabs can be updated each 15s, 1min ,2min and 5min or Never
by clicking in the upper bar menu (Default is 15s).
New Firmware Notification: Starting from firmware version 1.0.5.13/1.0.5.14, and once a different
OFFICIAL firmware is released on Grandstream Networks website, the master AP will popup reminder
notification to the administrator in order to upgrade the device. You can click on New button in order to be
redirected to the release note of the new firmware version, for upgrading steps please refer to section
[UPGRADING AND PROVISIONING].
Save and Apply Changes
When clicking on "Save" button after configuring or changing any option on the web GUI pages. A message
mentioning the number of changes will appear on the upper menu. Click button to apply changes.
Figure 21: Apply Changes
P a g e | 40
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
GWN.CLOUD
Starting from firmware 1.0.6.41/1.0.6.43, the GWN7610/GWN7600/GWN7600LR can be managed by your
GWN.Cloud account, GWN.Cloud web interface now can be accessed at https://www.gwn.cloud. Please
refer to GWN.Cloud User Guide for how to add your GWN AP to GWN.Cloud.
Figure 22: GWN.Cloud Login Page
P a g e | 41
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
USING GWN76XX AS STANDALONE ACCESS POINT
The GWN7610/GWN7600/GWN7600LR can be used in Standalone mode, where it can act as Master
Access Point Controller or in Slave mode and managed by another GWN76xx Master.
This section will describe how to use and configure the GWN7610/GWN7600/GWN7600LR in standalone
mode.
Connect to GWN76xx Default Wi-Fi Network
GWN7610/GWN7600/GWN7600LR can be used as standalone access point out of box, or after factory
reset with Wi-Fi enabled by default.
After powering the GWN7610/GWN7600/GWN7600LR and connecting it to the network,
GWN7610/GWN7600/GWN7600LR will broadcast a default SSID based on its MAC address GWN
[MAC’s last 6 digits] and a random password.
Note that GWN7610/GWN7600/GWN7600LR’s default SSID and password information are printed on the
MAC tag of the unit as shown on the below figure.
Figure 23: MAC Tag Label
P a g e | 42
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
USING GWN76XX AS MASTER ACCESS POINT CONTROLLER
Master Mode allows a GWN7610/GWN7600/GWN7600LR to act as an Access Point Controller managing
other GWN76XX access points. This will allow users adding other access points under one controller and
managing them in an easy and a centralized way.
Master/Slave mode is helpful with large installations that needs more coverage area zones with the same
controller.
Figure 24: Login Page
Warning:
“Set unit as Master” option will forbid the GWN7610/GWN7600/GWN7600LR Access Point from being
paired by other Master GWN76XX and can only act as a Master Access point controller.
Users will need to perform a factory reset to the GWN7610/GWN7600/GWN7600LR, or unpair it from the
initial GWN76XX to make it open to Master Access Point mode again.
P a g e | 43
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Login Page
After login, users can use the Setup Wizard tool to go through the configuration setup or exit and
configure it manually. Setup Wizard can be accessed anytime by clicking on while on the web
interface.
Figure 25: Setup Wizard
Discover and Pair Other GWN76xx Access Point
First, note that by default the GWN controller access point will automatically discover all APs connected
to the same LAN (broadcast domain), but starting from firmware 1.0.5.13/1.0.514 a new possibility has
been added in order to pair and provision remote APs using DHCP option 43 with master direction
explained below.
Master Direction
To pair and manage access points located on remote networks, the admin needs to configure the IP
address of master AP on DHCP option 43 which will be send to the slave access point during booting
stage and allow the save/master connection to be established remotely. GWN7610 accepts option 224
encapsulated in option 43, and the syntax is in TLV format. A simple example of DHCP 43 configuration
would be:
224(Type)12(Length)10.157.0.234(Value) translated into Hex as e00c31302e3135372e302e323334
P a g e | 44
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Scenario example: a company has two offices connected via VPN (master AP located on network
192.168.1.0/24 and slave AP located on remote network 192.168.2.0/2). On remote network the admin
can set DHCP option 43 using GWN7000 router as following value:
encap:43,224,”192.168.1.100”.
After that the slave AP will be listed on the master AP discovered devices and ready for paring and
provisioning process which is described on the next steps.
To Pair a GWN76XX access point connected to the same Network as the
GWN7610/GWN7600/GWN7600LR follows the below steps:
1. Connect to the GWN7610/GWN7600/GWN7600LR Web GUI as Master and go to Access
Points.
Figure 26: Discover and Pair GWN7610/GWN7600/GWN7600LR
2. Click on to discover access points within GWN76xx Network, the following page
will appear.
Figure 27: Discovered Devices
3. Click on Pair under Actions, to pair the discovered access point as slave with the
GWN7610/GWN7600/GWN7600LR acting as Master.
4. The paired GWN7610/GWN7600/GWN7600LR will appear Online, users can click on to
P a g e | 45
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
unpair it.
Figure 28: GWN7610/GWN7600/GWN7600LR Online
5. Users can click on next to Master or paired access point to check device configuration for
its status, users connected to it and configuration. Refer to below table for Device Configuration
tabs.
6. Now an easier way to transfer your master authority from one unit to another available unit is
available on Access Point management page. By clicking the “Transfer to Master” button
the designated slave unit will be upgraded to master and current master will be downgraded to
slave accordingly.
Table 10: Device Configuration
Field
Description
Status
Shows the device’s status information such as MAC, Product Model, Part
Number, Boot Version, Firmware version, IP Address, Link Speed,
Uptime, and Users count via different Radio channels.
Clients
Shows the connected users to the GWN76xx access point.
Configuration
• Device Name: Set GWN7610/GWN7600/GWN7600LR’s name to
be shown next to MAC address.
• Fixed IP: Set a static IP for the GWN76xx, default is unchecked.
• Airtime Fairness: Allow faster clients to have more airtime than
slower clients.
• Band Steering: When Frequency is set to Dual-Band, users can
check this option to enable Band Steering on the Access Point,
this will help redirecting clients to a radio band accordingly for
efficient use and to benefit from the maximum throughput
supported by the client.
• Mode: Choose the mode for the frequency band, 802.11n/g/b for
2.4 GHz and 802.11ac for 5GHz.
• Channel Width: Choose the Channel Width, note that wide
channel will give better speed/throughput, and narrow channel
will have less interference. 20Mhz is suggested in very high-
density environment.
P a g e | 46
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
• 40MHz Channel Location: Configure the 40MHz channel
location when using 20MHz/40MHz in Channel Width, users can
set it to be Secondary below Primary, Primary below Secondary
or Auto.
• Channel: Select Auto, or a specified channel, default is Auto. Note
that the proposed channels depend on Country Settings under
System Settings→Maintenance.
• Enable Short Guard Interval: Check to activate this option to
increase throughput.
• Active Spatial Streams: Choose active spatial stream if Auto, 1
or 2 streams.
• Radio Power: Set the Radio Power, it can be Low, Medium or
High.
• Custom Wireless Power(dBm): allows users to set a custom
wireless power for both 5GHz/2.4GHz band, the value of this field
must be between 1 and 31.
• Allow Legacy Devices(802.11b): Check to support 802.11b
devices to connect the AP in 802.11n/g mode.
• Dynamic Channel Assignment: Once enabled, AP will try to
allocate and move the best channel during operation, unlike Auto
Channel Selection (ACS) which scan and assign channel when
WiFi interface goes up for one time. This feature is not supported
on GWN7610.
• Transmit Power Control: TPC algorithm runs every 10 minutes.
AP acquires the RSSI information of the neighbor by wireless
scanning and establishes the neighbor table. The algorithm
requires that there must be at least 3 neighbor APs with RSSI
larger than -70dbm. Otherwise, power will not be adjusted.
• Coverage Hole Detection: CHD enables AP to decide whether to
increase the AP power by the current SNR and SNR threshold of
the connected clients.
P a g e | 47
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Note
If a GWN7610/GWN7600/GWN7600LR is not being discovered or the pair icon is grey color, make sure
that it is not being paired with another GWN76XX Access Point acting as Master Controller, if yes users
will need to unpair it first, or reset it to factory default settings in order to make it available for pairing by
other GWN76XX Access Point Controller
AP Location
GWN supports a handy feature which allows users to locate other Access points by blinking LED. To use
the feature, navigate on the master web GUI under “Access Points” page and click on the icon near
the desired AP, and it corresponding unit will start blinking the LEDs.
Transfer AP – Transfer Network Group
Users can easily transfer the AP from local master to the GWN.CLOUD account by clicking on
. When you already have Network/WIFI configurations on your cloud account, using this
feature will let you choose existing Network/SSID to adopt your local AP.
Note: Local configurations will not be transferred.
feature will allow you to transfer your local configurations to your cloud account.
For more details, please refer to GWN.Cloud User Guide.
Failover Master
In a Master-Slave architecture, having a backup Master is critical for redundancy and failover function,
thus, and in order to avoid a single point of failure in your wireless network, you can specify a slave AP as
failover master. Whenever it detects the master is down, it will promote itself as failover master within a
time frame of around 20~30 minutes by entering failover mode. After then, if the master AP comes back,
failover master will automatically go back to slave mode, or if the master doesn’t come back to alive,
Administrator can login using “failover” account to turn the failover master as true master and take over all
controls.
P a g e | 48
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 29: Failover Master
Users could select the failover Master by following below steps:
• Log into web GUI of the master GWN.
• Go to Access Points page.
• Press
• Select from the available paired Slave Aps the candidate to become a failover Master.
• Save and Apply the settings.
Failover Mode
Once failover slave has been selected, the primary master will send the configuration of the network to the
failover slave and the slave will start monitoring the status of the primary master to detect any failure for
any reason (network connection loss, power outage).
In case of failure, the failover slave will promote itself to a temporary backup master while waiting for the
primary master to come back.
During the failover mode users could access the web GUI of the failover slave using a special failover
account with same admin password.
• Username = failover
• Password = admin password
P a g e | 49
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 30: Failover Mode GUI
The failover mode has only read permission on the configuration and very limited options, users still can
reboot other slave Access points in case it is needed.
Users also can press on « Switch to master » button in order to set the failover slave as the new primary
master of the wireless network, once this is done they have full write permission control over the web GUI
option as usual.
Client Bridge
The Client Bridge feature allows an access point to be configured as a client for bridging wired only clients
wirelessly to the network. When an access point is configured in this way, it will share the WiFi connection
to the LAN ports transparently. This is not to be confused with a mesh setup. The client will not accept
wireless clients in this mode.
Once a SSID has the Client Bridge Support enabled, the AP adopted in this SSID can be turned in to
Bridge Client mode by click the Bridge button .
Please be noted that once an AP it turned into Client Bridge mode, it cannot be controlled by a Master
anymore, and a factory reset is required to turn it back into normal AP mode.
Figure 31: Client Bridge
Important Notes :
• The access point that will be operating on bridge mode, must be set with a fixed IP address before
activating the bridge mode on the access point.
• Users must enable client bridge support option under SSID or SSID WiFi settings in order to have
it fully functional. See [Client Bridge Support]
P a g e | 50
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
SSID
When using GWN7610/GWN7600/GWN7600LR as Master Access Point, users can create different SSIDs
and assign GWN76xx Slave Access Points to them.
Log in as Master to the GWN7610/GWN7600/GWN7600LR WebGUI and go to SSIDs.
Figure 32: SSID
GWN7610/GWN7600/GWN7600LR can support up to 16 SSIDs, click on to add a new SSID.
Figure 33: Add a new SSID
P a g e | 51
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
When editing or adding a new SSID, users will have two tabs to configure:
• Wi-Fi: Please refer to the below table for Wi-Fi tab options
Table 11: Wi-Fi
Field
Description
Enable SSID
Check to enable Wi-Fi for the SSID.
SSID
Set or modify the SSID name.
SSID Band
Select the Wi-Fi band the GWN will use, three options are available:
• Dual-Band
• 2.4GHz
• 5Ghz
SSID Hidden
Select to hide SSID. SSID will not be visible when scanning for Wi-Fi, to
connect a device to hidden SSID, users need to specify SSID name and
authentication password manually.
VLAN
Enter the VLAN ID corresponding to the SSID.
Wireless Client Limit
Configure the limit for wireless client. If there’s an SSID per-radio on a
SSID, each SSID will have the same limit. So, setting a limit of 50 will limit
each SSID to 50 users independently. If set to 0 the limit is disabled.
Enable Captive Portal
Click on the checkbox to enable the captive portal feature.
Captive Portal Policy
Select the captive portal policy already created on the “CAPTIVE
PORTAL” web page to be used in the created SSID.
Enable Schedule
Check the box and choose a schedule to apply for the selected SSID.
Security Mode
Set the security mode for encryption, 5 options are available:
• WEP 64-bit: Using a static WEP key. The characters can only be
0-9 or A-F with a length of 10, or printable ASCII characters with a
length of 5.
• WEP 128-bit: Using a static WEP key. The characters can only be
0-9 or A-F with a length of 26, or printable ASCII characters with a
length of 13.
• WPA/WPA2: Using “PSK” or “802.1x” as WPA Key Mode, with
“AES” or “AES/TKIP” Encryption Type.
• WPA2: Using “PSK” or “802.1x” as WPA Key Mode, with “AES” or
“AES/TKIP” Encryption Type. Recommended configuration for
authentication.
• Open: No password is required. Users will be connected without
authentication. Not recommended for security reasons.
P a g e | 52
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
WEP Key
Enter the password key for WEP protection mode.
This field is available only when “Security Mode” is set to “WEP 64-bit” or
“WEP 128-bit”.
WPA Key Mode
Two modes are available:
• PSK: Use a pre-shared key to authenticate to the Wi-Fi.
• 802.1X: Use a RADIUS server to authenticate to the Wi-Fi.
This field is available only when “Security Mode” is set to “WPA/WPA2” or
“WPA2”.
WPA Encryption Type
Two modes are available:
• AES: This method changes dynamically the encryption keys
making them nearly impossible to circumvent.
• AES/TKIP: use both Temporal Key Integrity Protocol and
Advanced Encryption Standard for encryption, this provides the
most reliable security.
This field is available only when “Security Mode” is set to “WPA/WPA2” or
“WPA2”.
WPA Pre-Shared Key
Set the access key for the clients, and the input range should be: 8-63
ASCII characters or 8-64 hex characters.
This field is available only when “Security Mode” is set to “WPA/WPA2” or
“WPA2”.
RADIUS Sever Address
Configures RADIUS authentication server address.
This field is available only when “WPA Key Mode” is set to “802.1x”.
RADIUS Server Port
Configures RADIUS Server Listening port (default is: 1812).
This field is available only when “WPA Key Mode” is set to “802.1x”.
RADIUS Server Secret
Enter the secret password for client authentication with RADIUS server.
This field is available only when “WPA Key Mode” is set to “802.1x”.
RADIUS Accounting Server
Configures the address for the RADIUS accounting server.
This field is available only when “WPA Key Mode” is set to “802.1x”.
RADIUS Accounting Server
Port
Configures RADIUS accounting server listening port (defaults to 1813).
This field is available only when “WPA Key Mode” is set to “802.1x”.
RADIUS Accounting Server
Secret
Enter the secret password for client authentication with RADIUS
accounting server.
This field is available only when “WPA Key Mode” is set to “802.1x”.
RADIUS NAS ID
Enter the RADIUS NAS ID.
This field is available only when “WPA Key Mode” is set to “802.1x”.
P a g e | 53
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Enable Dynamic VLAN
When enabled, clients will be assigned IP address from corresponding
VLAN configured on the RADIUS user profile.
This field is available only when “WPA Key Mode” is set to “802.1x”.
Client Bridge Support
Configures the client bridge support to allow the access point to be
configured as a client for bridging wired only clients wirelessly to the
network. When an access point is configured in this way, it will share the
WiFi connection to the LAN ports transparently. Once a SSID has a Client
Bridge Support enabled, the AP adopted in this SSID can be turned in to
Bridge Client mode by click the Bridge button.
Client Time Policy
Select a time policy to be applied to all clients connected to this SSID.
Use MAC Filtering
Choose Blacklist/Whitelist to specify MAC addresses to be
excluded/included from connecting to the zone’s Wi-Fi.
Default is Disabled.
Client Isolation
Client isolation feature blocks any TCP/IP connection between connected
clients to GWN7610/GWN7600/GWN7600LR’s Wi-Fi access point. Client
isolation can be helpful to increase security for Guest networks/Public
WiFi.
Three modes are available:
• Radio Mode: Wireless clients can access to the internet services,
GWN7xxx router and the access points
GWN7610/GWN7600/GWN7600LR but they cannot communicate
with each other.
• Internet Mode: Wireless clients will be allowed to access only the
internet services and they cannot access any of the management
services, either on the router nor the access points
GWN7610/GWN7600/GWN7600LR.
• Gateway MAC Mode: Wireless clients can only communicate with
the gateway, the communication between clients is blocked and
they cannot access any of the management services on the
GWN7610/GWN7600/GWN7600LR access points.
Gateway MAC Address
This field is required when using Client Isolation, so users will not lose
access to the Network (usually Internet). Type in the default LAN
Gateway’s MAC address (router’s MAC address for instance) in
hexadecimal separated by “:”. Example: 00:0B:82:8B:4D:D8
P a g e | 54
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
RSSI Enabled
Check to enable RSSI function, this will lead the AP to disconnect users
below the configured threshold in Minimum RSSI (dBm).
Minimum RSSI (dBm)
Enter the minimum RSSI value in dBm. If the signal value is lower than the
configured minimum value, the client will be disconnected. The input range
is from “-94” or “-1”.
Beacon Interval
Configures interval between beacon transmissions/broadcasts.
The Beacon signals help to keep the network synchronized and provide
main information about the network such as SSID, Timestamp…
• Using High Beacon Interval: AP will be sending beacon
broadcast less frequently. This will help to get better throughput,
thus better speed/performance. It also helps to save WiFi clients
energy consumption.
• Using Low Beacon Interval: AP will be sending beacon
broadcast more frequently. This can help in environments with
weak signal areas; sending more frequently beacons will increase
chances to be received by WiFi clients with weak signal.
Notes:
1. When AP enables several SSIDs with different interval values,
the max value will take effect.
2. When AP enables less than 3 SSIDs, the interval value which
will be effective are the values from 40 to 500.
3. When AP enables more than 2 but less than 9 SSIDs, the
interval value which will be effective are the values from 100 to
500.
4. When AP enables more than 8 SSIDs, the interval value which
will be effective are the values from 200 to 500.
5. Mesh feature will take up a share when it is enabled.
Default value is 100ms. Valid range: 40 – 500 ms.
DTIM Period
Configures the frequency of DTIM (Delivery Traffic Indication Message)
transmission per each beacon broadcast. Clients will check the AP for
buffered data at every configured DTIM Period. You may set a high value
for power saving consideration.
P a g e | 55
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Default value is 1, meaning that AP will have DTIM broadcast every
beacon. If set to 10, AP will have DTIM broadcast every 10 beacons.
Valid range: 1 – 10.
Multicast to Unicast
Once selected, AP will convert multicast streams into unicast streams over
the wireless link. Which helps to enhance the quality and reliability of
video/audio stream and preserve the bandwidth available to the non-
video/audio clients.
Enable Voice Enterprise
Check to enable/disable Voice Enterprise. The roaming time will be
reduced once enable voice enterprise.
• The 802.11k standard helps clients to speed up the search for
nearby APs that are available as roaming targets by creating an
optimized list of channels. When the signal strength of the current
AP weakens, your device will scan for target APs from this list.
• When your client device roams from one AP to another on the
same network, 802.11r uses a feature called Fast Basic Service
Set Transition (FT) to authenticate more quickly. FT works with
both pre-shared key (PSK) and 802.1X authentication methods.
• 802.11v allows client devices to exchange information about the
network topology, including information about the RF
environment, making each client network aware, facilitating
overall improvement of the wireless network.
Note: 11R is required for enterprise audio feature, 11V and 11K are
optional.
This field is available only when “Security Mode” is set to “WPA/WPA2” or
“WPA2”.
Enable 11R
Check to enable 802.11r
This field is available only when “Security Mode” is set to “WPA/WPA2” or
“WPA2”.
Enable 11K
Check to enable 802.11k
Enable 11V
Check to enable 802.11v
Upstream Rate
Set the maximum upstream rate
Downstream Rate
Set the maximum downstream rate
P a g e | 56
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
• Device Membership: Used to add or remove paired access points to the SSID.
Figure 34: Device Membership
Click on to add the GWN7610/GWN7600/GWN7600LR to the SSID or click on to remove it.
P a g e | 57
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
CLIENTS CONFIGURATION
Users can configure clients’ parameters, time policy and also check the list of the clients that has been
banned after time disconnect policy has been enabled. Below we discuss each section of this menu:
Clients
Users can access clients list connected to GWN7610/GWN7600/GWN7600LR from Web GUI → Clients
→ Clients to perform different actions to wireless clients.
Figure 35: Clients
• Click on under Actions to check client’s status and modify basic settings such Device’s Name.
• Click on to block a client’s MAC address from connecting to the zone’s SSID.
• Click on to release WiFi offline client IP lease.
Users can press button to customize items to display on the page. Following items are supported:
P a g e | 58
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 36: Clients - Select Items
Clients Access
From this menu, users can manage in global way the blacklist of clients that will be blocked from accessing
the WiFi network, click on to add or remove MAC addresses of client from global
blacklist.
Figure 37: Global Blacklist
P a g e | 59
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 38: Managing the Global Blacklist
A second option is to add custom access lists that will be used as matching mechanism for MAC address
filtering option under SSIDs to allow (whitelist) or disallow (blacklist) clients access to the WiFi network.
Click on in order to create new access list, then fill it with all MAC addresses to be matched.
Figure 39: Adding Client Access List
Users can check « Enable Schedule » to assign a schedule for the list when it will take effect.
Figure 40: Adding New Access List
Once this is done, this access list can be used under SSID WiFi settings to filter clients either using whitelist
or blacklist mode.
P a g e | 60
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 41: Blacklist Access List
Time Policy
The timed client disconnect feature allows the system administrator to set a fixed time for which clients
should be allowed to connect to the access point, after which the client will no longer be allowed to connect
for a user configurable cool-down period.
The configuration is based on a policy where the administrator can set the amount of time for which clients
are allowed to connect to the WiFi and reconnect type and value after which they will be allowed to connect
back after they have been disconnected.
To create a new policy, go under Clients→Time Policy and add new one., then set the following
parameters:
Table 12: Time Policy Parameters
Option
Description
Name
Enter the name of the policy
Enabled
Check the box to enable the policy
Limit Client Connection Time
Sets amount of time a client may be connected.
P a g e | 61
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Client Reconnect Timeout Type
Select the method with which we will reset a client’s connection timer
so they may reconnect again. Options are:
• Reset Daily.
• Reset Weekly.
• Reset Hourly.
• Timed Reset.
Client Reconnect Timeout
If “Timed Reset” is selected, this is the period for which the client will
have to wait before reconnecting.
Day of the Week
If “Reset Weekly” is selected, this is the day when the reset will be
applied.
Hour of the Day
If “Reset Weekly” or “Reset Daily” is selected, this is the hour and day
when the reset will be applied.
Note: Time tracking shall be accounted for on a per-policy basis, such that a client connected to any SSID
assigned the time tracking policy will accrue a common counter, regardless of which SSID they are
connected to (as long as those SSIDs all share the same time tracking policy).
Banned Clients
Click on menu to view the list of the clients that have been banned after time
disconnect feature has taken effect, these clients will not be allowed to connect back until timeout reset or
you can unblock a client by clicking on the icon .
Figure 42: Ban/Unban Client
P a g e | 62
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
CAPTIVE PORTAL
Captive Portal feature on GWN7610/GWN7600/GWN7600LR AP helps to define a Landing Page (Web
page) that will be displayed on Wi-Fi clients’ browsers when attempting to access Internet. Once connected
to a GWN7610/GWN7600/GWN7600LR AP, Wi-Fi clients will be forced to view and interact with that
landing page before Internet access is granted.
The Captive Portal feature can be configured from the GWN7610/GWN7600/GWN7600LR Web page
under “Captive Portal”.
The page contains following sub-menus: Guest, Policy List, Splash Page and Vouchers.
Guest
This section lists the clients connected or trying to connect to Wi-Fi via Captive Portal.
Figure 43: Captive Portal – Guest Page
Users can press button to customize items to display on the page. Following items are supported:
Figure 44: Captive Portal - Guest Page - Select Items
P a g e | 63
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Policy List
Users can customize a portal policy in this page.
Figure 45: Captive Portal - Policy List
• Click on to edit the policy.
• Click on to delete the policy.
• Click on to add a policy.
The policy configuration page allows adding multiple captive portal policies which will be applied to SSIDs
and contains options for different authentication types a splash page that can be easily configured as
shown on the next section.
Administrator can use an internal or external splash page.
P a g e | 64
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 46: Add a New Policy
Internal Splash Page
Below table lists the items policy add page configures.
Table 13: Captive Portal – Policy List – Splash Page is “Internal”
Field
Description
Name
Enter the name of the Captive Portal policy
Splash Page
Select Splash Page type, Internal or External.
P a g e | 65
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Authentication Type
Following types of authentication are available:
• Login for free: when choosing this option, the landing page feature will not
provide any type of authentication, instead it will prompt users to accept the
license agreement to gain access to internet.
• RADIUS Server: Choosing this option will allow users to set a RADIUS
server to authenticate connecting clients.
• Social Login Authentication: Choosing this option will allow users to
enable authentication Facebook or Twitter or WeChat.
• Vouchers: Choose this page when using authentication via Vouchers.
• Login with Password: Choose this page when using authentication via a
password.
Expiration
Configures the period of validity, after the valid period, the client will be re-
authenticated again.
If Authentication Type is set to “RADIUS Authentication”
RADIUS Server
Address
Fill in the IP address of the RADIUS server.
RADIUS Server Port
Set the RADIUS server port, the default value is 1812.
RADIUS Server Secret
Fill in the key of the RADIUS server.
RADIUS Authentication
Method
Select the RADIUS authentication method, 3 methods are available: PAP, CHAP
and MS-CHAP.
If Authentication Type is set to “Social Login Authentication”
WeChat
Check to enable/disable WeChat Authentication
Shop ID
Fill in the Shop ID that offers WeChat Authentication.
APP ID
Fill in the APP ID provided by the WeChat in its web registration page
Secret Key
Set the key for the portal, once clients want to connect to the WiFi, they should
enter this key.
Facebook
Check to enable/disable Facebook Authentication
Facebook App ID
Fill in the Facebook App ID.
Facebook APP Key
Set the key for the portal, once clients want to connect to the WiFi, they should
enter this key.
Twitter
Check this box to enable Twitter Authentication.
Force to Follow
If checked, users need to Follow owner before been authenticated.
P a g e | 66
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Owner
Enter the app Owner to use Twitter Login API.
This field appears only when Force to Follow is checked.
Consumer Key
Enter the app Key to use Twitter Login API.
Consumer Secret
Enter the app secret to use Twitter Login API.
For all Authentication Types
Use Default Portal
Page
If checked, the users will be redirected to the default portal page once connected
to the GWN.
If unchecked, users can manually select which Portal Page to use from Portal
Page Customization drop-down list.
Portal Page
Customization
Select the customized portal page (if “Use Default Portal Page” is unchecked).
• /facebook.html
• /password_auth.html
• /portal_default.html
• /portal_pass.html
• /portal_tip.html
• /social_auth.html
• /status.html
• /twitter.html
• /twitter_website.html
• /vouchers_auth.html
• /wechat.html
Landing Page
Choose the landing page, 2 options are available:
• Redirect to the Original URL.
• Redirect to External Page.
Redirect External Page
URL Address
Once the landing page is set to redirect to external page, user should set the
URL address for redirecting.
This field appears only when Landing Page is set to “Redirect to an External
Page”.
Enable Daily Limit
If enabled, captive portal will limit user connection by times of one day.
Failsafe Mode
If checked, AP will grant access to STA if AP can’t reach to external authentication
server.
This option is available only when Authentication Type is set to “RADIUS
Server” or “Vouchers”.
Enable HTTPS
Check to enable/disable HTTPS service.
P a g e | 67
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Notes:
1. If Facebook authentication is configured, you will need to log in your Facebook account of
https://developers.facebook.com/apps , and set the OAuth redirect to :
https://cwp.gwn.cloud:8443/GsUserAuth.cgi?GsUserAuthMethod=3
2. If Twitter authentication is configured, you will need to log in your Twitter account of
https://apps.twitter.com/app, and set the callback URLs to:
http://cwp.gwn.cloud:8080/GsUserAuth.cgi?GsUserAuthMethod=5
External Splash Page
Table 14: Captive Portal – Policy List – Splash Page is “External”
Field
Description
Name
Enter the name of the Captive Portal policy
Splash Page
Select to either use Internal or External Splash Page.
Platform
Select which external captive portal platform to use:
• Linkyfi Platform (https://www.avsystem.com/products/linkyfi)
• Purple Platform (https://purple.ai/)
External Splash Page
URL
Enter the External Splash Page URL, and make sure to enter the pre-
authentication rules request by the external portal platform in the pre-
authentication configuration option.
RADIUS Server
Address
Fill in the IP address of the RADIUS server.
RADIUS Server Port
Set the RADIUS server port, the default value is 1812.
RADIUS Server Secret
Fill in the key of the RADIUS server.
RADIUS Accounting
Server Address
Configures the address for the RADIUS accounting server.
RADIUS Accounting
Server Port
Configures RADIUS accounting server listening port (default is 1813).
RADIUS Accounting
Server Secret
Enter the secret password for client authentication with RADIUS accounting
server.
Accounting Update
Interval
Enter Update Interval for RADIUS Accounting Server. The interval unit can be
set by seconds, minutes, hours or days.
RADIUS NAS ID
Enter RADIUS NAS ID.
This field appears only when Platform is set to “Linkyfi Platform”.
Redirect URL
Specify URL where to redirect clients after authentication.
P a g e | 68
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
In case social media authentication is used, the user needs to allow some traffic between the AP and social
medial platforms (Facebook API as example) to send authentication credentials and receive reply, this
traffic can be allowed using the Authentication rules which are explained below.
Figure 47: Authentication rules
Pre-Authentication Rules
Using this option, users can set rules to match traffic that will be allowed for connected WiFi users before
authentication process. This can be needed for example to setup Facebook authentication where some
traffic should be allowed to Facebook server(s) to process the user’s authentication. Or simply to be used
to allow some type of traffic for unauthenticated users.
Post-Authentication Rules
On the other hand, post authentication rules are used to match traffic that will be banned for WiFi clients
after authentication. As an example, if you want to disallow connected WiFi clients to issue Telnet or SSH
traffic after authentication then you can set post authentication rules to match that traffic and once a
connected client passes the authentication process they will be banned from issuing telnet and SSH
connections.
Splash Page
Files configuration page allows users to view and upload HTML pages and related files (images…).
P a g e | 69
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 48: Captive Portal – Splash Page
User can add folder in corresponding folder by selecting the folder and click on .
• Click on to upload a file from local device.
• Click on to download the files in Captive Portal folder.
• Click on to edit the corresponding file, in another word, to replace the file with a new one.
• Click on to delete the file.
Vouchers
Voucher Feature Description
Voucher feature will allow clients to have internet access for a limited duration using a code that is randomly
generated from GWN controller.
As an example, a coffee shop could offer internet access to customers via WiFi using voucher codes that
can be delivered on each command. Once the voucher expires the client can no longer connect to the
internet.
P a g e | 70
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Note that multiple users can use a single voucher for connection with expiration duration of the voucher
that starts counting after first successful connection from one of the users that are allowed.
Another interesting feature is that the admin can set data bandwidth limitation on each created voucher
depending on the current load on the network, users’ profile (VIP customers get more speed than regular
ones...etc) and the internet connection available (fiber, DSL or cable…etc) to avoid connection congestion
and slowness of the service.
Each created voucher can be printed and served to the customers for usage, and the limit is 1000 vouchers.
The usage of voucher feature needs to be combined with captive portal that is explained after this section,
in order to have the portal page requesting clients to enter voucher code for authentication.
Voucher Configuration
To configure/create vouchers for clients to use, follow below steps:
1. On controller web GUI, navigate under “Captive Portal → Vouchers”
2. Click on button in order to add a new voucher.
3. Enter voucher details which are explained on the next table.
4. Press save to create the voucher(s).
Notes:
• Users can specify how many vouchers to generate which have the same profile, this way the GWN
will generate as many vouchers as needed which do have the same settings avoiding creating
them one by one.
• The admin can verify the status of each vocoder on the list (In use, not used, expired …etc).
• Press to print the voucher, to delete it or to renew the voucher.
P a g e | 71
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 49: Add Voucher Sample
The below figure shows the status of the vouchers after GWN randomly generates the code for each one.
P a g e | 72
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 50: Vouchers List
Users can click on buttons and to delete and print multiple vouchers.
Also, users can use the drop-down list filter to filter the vouchers that where
created at specific date-time.
The following table summarizes description for voucher configuration parameters:
Table 15: Voucher Parameters
Field
Description
Create Number One Time
Specify how many vouchers to generate which will have same
profile/settings (duration, bandwidth and number of users).
Valid range: 1 – 1000.
Device Quota
Specify how many users can use same voucher.
Valid range: 1 – 5.
P a g e | 73
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Byte Limit
Specify download byte limit for the voucher. The unit can be either M
(Megabyte) or G (Gibabyte).
Valid range: 10 – 1048576 (M)
1 – 1024 (G)
Duration
Specify the duration after which the voucher will expire, and clients
will be disconnected from internet.
Note: in case or multiple users, the duration will start counting after
first user starts using the voucher.
Expiration
Set the validity period of credentials, limited to 1-365 integer. The unit
is day.
Downstream
Set the downstream bandwidth speed limit (in Kbps or Mbps).
Upstream
Set the upstream bandwidth speed limit (in Kbps or Mbps).
Notes
Notes for the admin when checking the list of vouchers.
Using Voucher with GWN Captive Portal
In order to successfully use the voucher feature, users will need to create a captive portal in order to
request voucher authentication codes from users before allowing them access to internet. More details
about captive portal will be covered on next section but for voucher configuration please follow below steps.
1. Go under “Captive Portal → Captive portal” menu.
2. Press in order to add new captive portal policy.
3. Set the following parameters as shown on the screenshot for basic setup then save and apply.
P a g e | 74
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 51: Captive Portal with Voucher authentication
Then go under your SSID configuration page and enable the generated captive portal under WiFi settings
tab.
P a g e | 75
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
MESH NETWORK
In Mesh Network, wireless connection is established between multiple Aps, which is used to passthrough
data traffic rather than client association. Each AP will evaluate the performance of wireless channel based
on several factors and choose one or multiple appropriate APs to setup connection.
In a mesh network, access points are categorized to two types:
• CAP (Central Access Point): this is an access point that has an uplink connection to the wired
network.
• RE (Range Extender): This is an access point that participate on the mesh network topology and
has a wireless uplink connection to the central network.
In order to deploy mesh access points (RE), users/installers can follow below steps:
1. Make sure to have the master and CAP access points already deployed (sometimes the CAP
access points can be the master controller of the network).
2. Next, we need to pair the RE access points to the master. This can be done in two ways:
A. Connect all REs to the same wired LAN as the master then perform the normal process of
discovery/pairing process, and after successfully pairing the APs they can be deployed on the
field.
B. REs can also be discovered wirelessly when powered via PSU or PoE Injector, and admin
can configure them after discovery. This requires that the REs must be within the range of the
Master or CAP Slave’s signals coverage.
Note: If there are other GWN APs broadcasting in the same field with different subnet, RE may be
wirelessly connected to those networks and cannot be discovered and paired by your Master.
Therefore, it is recommended to use the first method of wired pairing and then deploy those REs.
3. After that all slave access points have been deployed and paired to the master, you can directly
manage them to operate the mesh network. Mesh service configuration is the same as transitional
GWN WLAN.
4. Log into the master page, and under Access Points page you can see the information, for example
the AP in the “Online Wireless” state is the RE (Range Extender) with a wireless uplink to the
CAP. The APs showing “Online” state are either a wired master or CAP.
P a g e | 76
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 52: Access Points Status
For Global mesh network settings, navigate to the menu “System Settings → Mesh” for setting up the
following parameters described below:
Figure 53: Mesh settings
P a g e | 77
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
The following table describes the Mesh configuration settings.
Table 16: Mesh configuration
For more detailed information about GWN Mesh network feature, you may refer to the following technical
document: Mesh Network Guide.
Filed
Description
Scan Interval
Interval in seconds to scan for available Mesh neighbors.
Mesh Enabled on 2.4G
Radio Interface
If checked, Mesh will work on 2.4GHz band.
Mesh Enabled on 5G
If checked, Mesh will work on 5GHz band.
Wireless cascades
Define how many AP can be cascaded wirelessly with the AP. The minimum
value is 1 and maximum value is 4.
P a g e | 78
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
BANDWIDTH RULES
The bandwidth rule is a GWN7610/GWN7600/GWN7600LR feature that allows users to limit bandwidth
utilization per SSID or client (MAC address or IP address).
This option can be configured from the GWN7610/GWN7600/GWN7600LR WebGUI under “Bandwidth
Rules”.
Click to add a new rule, the following table provides an explanation about different options
for bandwidth rules.
Table 17: Bandwidth Rules
Field
Description
Enable
Enable/Disable the Bandwidth rule.
SSID
Select which SSID will be affected by the bandwidth rule limitation.
Range Constraint
Choose the type of rule to be applied on bandwidth utilization from the
dropdown list, three options are available:
• All: Set a bandwidth limitation on the SSID level.
• MAC: Set a bandwidth limitation per MAC address.
• IP Address: Set a bandwidth limitation per IP address.
MAC
Enter the MAC address of the device to which the limitation will be
applied, this option appears only when MAC type is selected.
IP address
Enter the IP address of the device to which the limitation will be applied,
this option appears only when IP Address type is selected.
Enable Schedule
Enable this option to assign a schedule for the bandwidth rule.
Upstream Rate
Specify the limit for the upload bandwidth using Kbps or Mbps.
Downstream Rate
Specify the limit for the download bandwidth using Kbps or Mbps.
The following figure shows an example of MAC address rule limitation.
P a g e | 79
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 54: MAC Address Bandwidth Rule
The following figure shows examples of bandwidth rules:
Figure 55: Bandwidth Rules
Note:
The same settings for bandwidth management are available from the following menus:
Per-SSID
Navigate on the web GUI under “SSID→Add /Edit→WiFi” and you can set the Upstream and Downstream
rate in Mbps.
Per-Client
Navigate on the web GUI under “Clients→Edit→Bandwidth Rules” where you can set the Upstream and
Downstream rate in Mbps.
P a g e | 80
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
SYSTEM SETTINGS
Maintenance
Users can access Maintenance page from GWN7610/GWN7600/GWN7600LR WebGUI→System
Settings→ Maintenance.
Basic
Basic page allows Country and Time configuration.
Table 18: Basic
Field
Description
Web HTTP Access
Enables Web HTTP Access. By default, it’s disabled.
Web HTTPS Port
Specifies HTTPS port. By default, is 443.
Country
Select the country from the drop-down list. This can affect the number of
channels depending on the country standards.
Scene
Configure whether to enable/disable 5.150-5.350GHz (channels 36-64) for
outdoor usage in order to follow some countries regulations.
Note:
This option is only available for certain countries and only effective for
outdoor type of access points (GWN7600LR only).
Time Zone
Configure time zone for the GWN7610/GWN7600/GWN7600LR.
Make sure to reboot the device to take effect.
NTP Server
Configure the IP address or URL of the NTP server. The device will obtain
the date and time from the configured server.
Date Display Format
Change the Date Display Format, three options are possible YYYY/MM/DD,
MM/DD/YYYY and DD/MM/YYYY.
Reboot Schedule
Select the time schedule when AP will be rebooted.
Refer to [SCHEDULE] to define time.
Upgrade
The Upgrade Web page allows upgrade related configuration.
P a g e | 81
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Table 19: Upgrade
Field
Description
Authenticate Config File
Authenticates configuration file before acceptance. The default
setting is No.
XML Config File Password
The password for encrypting the XML configuration file using
OpenSSL. The password is to decrypt the XML configuration file is
it is encrypted via OpenSSL
Upgrade Via
Allow users to choose the method to load the firmware and config:
TFTP, HTTP or HTTPS.
Firmware Server
Define the IP address or URL for the firmware upgrade server.
Make sure all files relevant to the firmware are updated completely
Config Server
Configure the IP address of URL for the file server.
Check/Download New Firmware
and Config at Boot
Configure whether to enable/disable automatic upgrade and
provisioning when reboot.
Allow DHCP options 66 and 43
override
Enable/Disable DHCP options 66 and 43 to override the upgrade
and provisioning settings
Automatic Upgrade
Set automatic upgrade every intervals/day/week. The device will
request to upgrade automatically according to the setup time. The
default setting is Disabled
X Hours
Select the time period to check for firmware upgrade.
This field is available when select “Check every X Hours” in
“Automatic Upgrade”
Hour of Day (0-23)
Defines the hour of the day (0-23) to check the HTTP/TFTP server
for firmware upgrade or configuration file changes.
This field is available when select “Check at Hour of Day” and
“Check at Day of Week” in “Automatic Upgrade”
Day of Week
Defines the day of the week to check the HTTP/TFTP server for
firmware upgrade or configuration file changes.
This field is available when select “Check at Day of Week” in
“Automatic Upgrade”
Upgrade Now
Click on button to begin the upgrade. Note that the
device will reboot after downloading the firmware.
P a g e | 82
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Download Configuration
Click on button to download the device
configuration file to PC.
Upload Configuration
Click on to select a compressed config file to restore
the config; after succeeding, the device will reboot automatically.
Reboot
Click on button to reboot device.
Factory Reset
Click on to restore the device and all online APs to
factory default settings.
Access
The Access Web page provide configuration for admin and user password.
Table 20: Access
Field
Description
Current Administrator
Password
Enter the current administrator password
New Administrator
Password
Change the current password. This field is case sensitive with a maximum
length of 32 characters.
Confirm New
Administrator Password
Enter the new administrator password one more time to confirm.
New User Password
Configure the password for user-level Web GUI access. This field is case
sensitive with a maximum length of 32 characters.
Confirm New User
Password
Enter the new User password again to confirm.
Syslog
The syslog Web page provides configuration settings for syslog.
P a g e | 83
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Table 21: Syslog Parameters
Field
Description
Syslog Server
Enter the IP address or URL of Syslog server.
Syslog Level
Select the level of Syslog, 5 levels are available: None, Debug, Info,
Warning and Error.
Log DNS Queries
Check to log DNS Queries.
Logserver
The logserver page allows the user to configure syslog server on GWN7610/GWN7600/GWN7600LR in
order to save log messages on connected external USB drive.
First connect a USB drive to the Access point, then configure the parameters and make sure to start the
server in order to collect messages from devices sending syslog to GWN.
Following table gives description for configuration parameters of GWN Logserver:
Table 22: Logserver Parameters
Option
Description
Logrotate File Size
Select the size of file to trigger rotation, if left empty, then the router will use
only the Logrotate frequency rules to trigger rotation.
Default is 5 M. Units can be M (Megabytes) or K (Kilobytes).
Logrotate File Count
Select the Maximum number of rotates files to keep. Default is 56 files.
Logrotate Mode
Choose the time rotation frequency mode (default every 3 hours).
• Every X Minutes (0-59).
• Every X hours (0-23)
• X hour of day (0-23).
• X day of week (Sunday-Saturday) + X hour of day (0-23).
Hours
Enter the number of hours period after which trigger file rotation.
Minutes
Enter the number of Minutes period after which trigger file rotation.
Hour of the day
Enter the hour of day at which trigger file rotation.
Day of the week
Enter Day of the week + hour of day, at which trigger file rotation.
Devices
Select the path (a USB partition) to store collected logs. Required.
Enable Logserver
Enables the logserver.
P a g e | 84
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
After setting up the logserver and saving the settings, users need to connect an USB external storage and
press Start button to start collecting logs.
All log messages from all devices will be put on one single file, and the router will keep rotating and creating
new files based on the configured rotation policy.
• Under Syslog File List, users can select a device and press List button to list all saved logs on
this device.
• Press Download button to download a saved log.
• Press Clear button to remove logs.
Debug
GWN7610/GWN7600/GWN7600LR offers many features for managing and monitoring connected clients
to SSIDs, as well as debugging and troubleshooting.
Capture (GWN7610/GWN7600 Only)
This section is used to generate packet trace captures from SSIDs interfaces which will help to sniff
packets within the SSID for troubleshooting purpose or monitoring. Users will need to plug a USB device
to the USB port on the back of the GWN7610/GWN7600.
P a g e | 85
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
To access Capture page, go to System Settings→Debug→Capture.
Figure 56: Capture Page
The below table will show different fields used on debug page:
Table 23: Debug
Required Options
File Name
Enter the name of the capture file that will be generated.
Interface
Choose a SSID as Interface on which the traffic will be captured.
Device
Choose a device plugged to USB port to save the capture once started.
Advanced Options
File Size
Set a File size that the capture will not exceed.
Rotate Count
Set a value for rotating captures.
Direction
Choose if you want to get all traffic or only outgoing or incoming to the chosen
interface.
P a g e | 86
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Filtering Options
Source Port
Set the Source Port to filter capture traffic coming from the defined source port.
Destination Port
Set the Destination Port to filter capture traffic coming from the defined port.
Source IP
Set the Source IP to filter capture traffic coming from the defined source IP.
Destination IP
Set Destination IP to filter capture traffic coming from the defined destination IP.
Protocol
Choose ALL or a specific protocol to capture (IP, ARP, RARP, TCP, UDP, ICMP,
IPv6)
• Click on to start capturing on a certain device plugged to the USB port.
• Click on to stop the capture.
Click on to show the captured files on a chosen device, users could check the capture
files details.
• Click on to delete all files.
• Click on next to a capture file to download it on a local folder.
• Click on to delete the corresponding capture file.
Figure 57: Capture Files
P a g e | 87
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Core Files
The Core Files Web page displays core dumps generated when the GWN7610/GWN7600/GWN7600LR
crashes. This is helpful for troubleshooting purposes, if any core dump found on this page please help to
contact our support team for further investigation using following link:
https://partnerconnect.grandstream.com/
Ping/Traceroute
Ping and Traceroute are useful debugging tools to verify reachability with other clients across the network.
The GWN7610/GWN7600/GWN7600LR offers both Ping and Traceroute tools for IPv4 and IPv6 protocols.
To use these tools, go to GWN7610/GWN7600/GWN7600LR WebGUI → System Settings → Debug →
Ping/Traceroute.
Figure 58: IP Ping
• Next to Tool choose from the dropdown menu: - IPv4 Ping for an IPv4 Ping test to Target
- IPv6 Ping for an IPv6 Ping test to Target
- IPv4 Traceroute for an IPv4 Traceroute to Target
- IPv6 Traceroute for an IPv6 Traceroute to Target
• Type in the destination’s IP address in Target field.
• Click on Run.
P a g e | 88
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 59: IP Traceroute
Syslog
The syslog Web page displays logs generated by the GWN7610/GWN7600/GWN7600LR for
troubleshooting purpose as shown in figure below.
Syslog messages are also displayed in real time under Web GUI→System Settings→Debug→Syslog.
Figure 60: Syslog
P a g e | 89
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Email/Notification
The Email/Notification page allows the administrator to select a predefined set of system events and to
send notifications upon the change of the set events.
Note:
A reboot is required in order to activate email notification feature.
Figure 61: Email
Table 24: Email Setting
Filed
Description
Host
Configures the SMTP Email Server IP or Domain Name.
Port
Specifies the Port number used by server to send email.
Username
Specifies sender’s User ID or account ID in the email system used.
Password
Specifies sender’s password of the email account.
Email Address
Specifies the email address of the administer where to receive notifications.
Skip Certificate
Validation
Check this box to skip the certificate validation
P a g e | 90
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 62: Notification
The following table describes the notifications configuration settings.
Table 25: Email Events
Filed
Description
Enabled
Enable/disable the notification. By default, it’s disabled
Memory Usage
Configures whether to send notification if memory usage is greater than the
configured threshold. By default, it’s disabled.
Memory Usage
Threshold (%)
Specifies the Memory Usage Threshold (%). Must be integer between 1 and 100.
CPU Usage
Configures whether to send notification if CPU usage is greater than the configured
threshold. By default, it’s disabled.
P a g e | 91
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
CPU Usage
Threshold (%)
Specifies the CPU Usage Threshold (%). Must be integer between 1 and 100.
Firmware upgrade
Configures whether to send notification on firmware upgrade. Default is disabled.
SSID
Configures whether to send notification if any SSID is enabled. Default is disabled.
Time Zone Change
Configures whether to send notification on time zone change. Default is disabled.
Administrator
Password Change
Configures whether to send notification on admin password change. Default is
disabled.
AP Offline
Configures whether to send notification when AP going offline. Default is disabled.
DHCP Sever
By default, GWN has DHCP relay, but users could create and manage multiple DHCP server pools which
will be mapped to the SSID using VLAN tag, for example when creating a DHCP pool under “System
Settings → DHCP Server” users need to set a VLAN ID and same one should be set under SSID to map
the configured DHCP pool with the SSID. This way users could configure multiple SSIDs mapped to
multiple VLANs on the network in which case they are isolated by layer 2 switching.
The table below summarizes the configuration parameters for DHCP server.
Table 26: DHCP Server Parameters
Field
Description
Name
Set the name of the DHCP Pool.
Enable
Enable/Disable the DHCP pool.
VLAN ID
Set a VLAN ID, same one should be set on SSID settings to map it with the
DHCP pool.
DHCP Server Static Address
Configure the static address of the DHCP server (through which GWN
Master AP will be accessible).
DHCP Server Subnet Mask
Sets the subnet mask for the DHCP Pool.
DHCP Start Address
Set the start address for DHCP
DHCP End Address
Set the end address for DHCP
DHCP Lease Time
Set the DHCP lease time for the clients (default 12h).
P a g e | 92
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
DHCP Options
Add the Option items for DHCP, detailed option contents can be found via:
https://wiki.openwrt.org/doc/howto/dhcp.dnsmasq
DHCP Gateway
Set the gateway for DHCP, and it is better to set the gateway, should be
different that the static IP of the access point and on the same subnet.
DHCP Preferred DNS
Set the preferred DNS for DHCP
DHCP Alternated DNS
Set the alternated DNS for DHCP
Static DHCP
Users can use the feature in order to set static DHCP binding to certain clients, to whom you do not want
the IP address to change.
To configure Static DHCP, please follow below steps:
1. Go under the menu “System Settings ➔ DHCP Server ➔ Static DHCP”.
2. Click button to create a new entry.
3. Enter the name of the device, along with its MAC address and IP address
Figure 63: DHCP Binding
4. Press Save and Apply to submit the changes.
P a g e | 93
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 64: Static DHCP Devices List
P a g e | 94
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
SCHEDULE
Users can use the schedule configuration menu to set specific schedule for GWN features while giving the
flexibility to specify the date and time to turn ON/OFF the selected feature.
The Schedule can be used for settings up specific time for Wi-Fi where the service will be active or for
LED schedule or bandwidth rules …etc.
To configure a new schedule, follow below steps:
1. Go under “Schedule” and click on Create New Schedule.
Figure 65: Create New Schedule
2. Select the periods on each day that will be included on the schedule and enter a name for the
schedule (ex: office hours).
3. Users can choose to set weekly schedule or absolute schedule (for specific days for example),
and if both weekly schedule and absolute schedules are configured on the same day then the
absolute schedule will take effect and the weekly program will be cancelled for that specific date.
4. Once the schedule periods are selected, click on Save to save the schedule.
P a g e | 95
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
The list of created schedules will be displayed as shown on the figure below. With the possibility to edit or
delete each schedule:
Figure 66: Schedules List
P a g e | 96
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
LED SCHEDULE
GWN7610/GWN7600/GWN7600LR Access Points series support also the LED schedule feature. This
feature is used to set the timing when the LEDs are ON and when they will go OFF at customer’s
convenience.
This can be useful for example when the LEDs become disturbing during some periods of the day, this
way with the LED scheduler, you can set the timing so that the LEDs are off at night after specific hours
and maintain the Wi-Fi service for other clients without shutting down the AP.
To configure LED schedule, on the GWN7610/GWN7600/GWN7600LR WebGUI navigate to “System
Settings→LEDs”.
Following options are available:
Table 27: LEDs
Field
Description
LEDs Always Off
Configure whether to disable the AP LED dictator
Schedule
Please choose a schedule to assign to LEDs, users can configure
schedules under the menu SCHEDULE
Following example on the next page sets the LEDs to be turned on from 8am till 8pm every day.
Figure 67: LED Scheduling Sample
P a g e | 97
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
UPGRADING AND PROVISIONING
Upgrading Firmware
The GWN7610/GWN7600/GWN7600LR can be upgraded to a new firmware version remotely or locally.
This section describes how to upgrade your GWN7610/GWN7600/GWN7600LR.
Upgrading via Web GUI
The GWN7610/GWN7600/GWN7600LR can be upgraded via TFTP/HTTP/HTTPS by configuring the
URL/IP Address for the TFTP/HTTP/HTTPS server and selecting a download method. Configure a valid
URL for TFTP, HTTP or HTTPS; the server name can be FQDN or IP address.
Examples of valid URLs:
firmware.grandstream.com/BETA
192.168.5.87
The upgrading configuration can be accessed via Web GUI→System
Settings→Maintenance➔Upgrade
Table 28: Network Upgrade Configuration
Field
Description
Authenticate Config File
Authenticates configuration file before acceptance. The default
setting is No.
XML Config File Password
The password for encrypting the XML configuration file using
OpenSSL. The password is to decrypt the XML configuration file is
it is encrypted via OpenSSL
Upgrade Via
Allow users to choose the method to load the firmware and config:
TFTP, HTTP or HTTPS.
Firmware Server
Define the IP address or URL for the firmware upgrade server.
Make sure all files relevant to the firmware are updated completely
Config Server
Configure the IP address of URL for the file server.
Check/Download New Firmware
and Config at Boot
Configure whether to enable/disable automatic upgrade and
provisioning when reboot.
Allow DHCP options 66 and 43
override
Enable/Disable DHCP options 66 and 43 to override the upgrade
and provisioning settings
P a g e | 98
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Automatic Upgrade
Set automatic upgrade every intervals/day/week. The device will
request to upgrade automatically according to the setup time. The
default setting is Disabled
X Hours
Select the time period to check for firmware upgrade.
This field is available when select “Check every X Hours” in
“Automatic Upgrade”
Hour of Day (0-23)
Defines the hour of the day (0-23) to check the HTTP/TFTP server
for firmware upgrade or configuration file changes.
This field is available when select “Check at Hour of Day” and
“Check at Day of Week” in “Automatic Upgrade”
Day of Week
Defines the day of the week to check the HTTP/TFTP server for
firmware upgrade or configuration file changes.
This field is available when select “Check at Day of Week” in
“Automatic Upgrade”
Upgrade Now
Click on button to begin the upgrade. Note that the
device will reboot after downloading the firmware.
Note: Please save and apply your configuration first if there are any
configuration modification.
Download Configuration
Click on button to download the device
configuration file to PC.
Upload Configuration
Click on to select a compressed config file to restore
the config; after succeeding, the device will reboot automatically.
Reboot
Click on button to reboot device.
Factory Reset
Click on to restore the device and all online APs to
factory default settings.
Upgrading Slave Access Points
When the GWN7610/GWN7600/GWN7600LR is being paired as slave using another
GWN7610/GWN7600/GWN7600LR Access Point acting as Controller, users can upgrade their paired
P a g e | 99
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
access points from the GWN7610/GWN7600/GWN7600LR Master Controller.
To upgrade a slave access point, log in to the GWN7610/GWN7600/GWN7600LR acting as Master
Controller and go to Access Points.
Figure 68: Access Points
Make sure that firmware server path is set correctly under Maintenance, check the desired APs to upgrade,
and click on to upgrade the selected paired access points.
Sequential Upgrade
If you choose multiple slave devices to upgrade their firmware, two options are available: “All-at-Once”
and “Sequential”. “All-at-Once” will use the default method, all checked slaves will upgrade their firmware
at the same time, while using “Sequential” upgrade method, the slaves will upgrade their firmware one by
one in order to:
• Avoid entire Wi-Fi service interruption by full system firmware upgrade.
• Reduce network bandwidth consumption caused by firmware downloading.
Figure 69: Choosing multiple devices
P a g e | 100
GWN7610/GWN7600/GWN7600LR User Manual
Version 1.0.7.13
Figure 70: All-at-Once and Sequential Upgrade
Once you choose sequential upgrade, the following icon will update you about
the number of upgraded slaves out of the selected slaves.
Provisioning and Backup
The GWN7610/GWN7600/GWN7600LR configuration can be backed up locally or via network. The
backup file will be used to restore the configuration on GWN7610/GWN7600/GWN7600LR when
necessary.
Download Configuration
Users can download the GWN7610/GWN7600/GWN7600LR configuration for restore purpose under Web
GUI→System Settings→Maintenance→Upgrade.
Click on to download locally the configuration file.
Upload Configuration
Users can upload configuration file to the GWN7610/GWN7600/GWN7600LR under Web GUI→System
Settings→Maintenance→Upgrade.
Click on to browse for the configuration to upload.
Please note that the GWN7610/GWN7600/GWN7600LR will reboot after the configuration file is restored
successfully.
