Gold's Gym XR 5.9, GGBE4869.11 User Manual
www.workoutwarehouse.com
Model No. GGBE4869.11
Serial No.
Write the serial number in the
space above for reference.
Serial Number Decal (under seat)
ACTIVATE YOUR
WARRANTY
To register your product and
activate your warranty today, go
to www.workoutwarehouse.com/
registration.
USER’S MANUAL
CUSTOMER CARE
For service at any time, go to
www.workoutwarehouse.com.
Or call 1-877-776-4777
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
TABLE OF CONTENTS
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT PRECAUTIONS ..................................................................3
BEFORE YOU BEGIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
PART IDENTIFICATION CHART. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
ADJUSTMENT ............................................................................11
EXERCISE GUIDELINES ....................................................................12
PART LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
EXPLODED DRAWING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
ORDERING REPLACEMENT PARTS .................................................. Back Cover
LIMITED WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
WARNING DECAL PLACEMENT
This drawing shows the location(s) of the warning
decal(s). If a decal is missing or illegible, see
the front cover of this manual and request a
free replacement decal. Apply the decal in the
location shown. Note: The decal(s) may not be
shown at actual size.
GOLD’S GYM is a registered trademark of Gold’s Gym International, Inc.
This product is manufactured and distributed under license from Gold’s Gym International, Inc.
2
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your weight bench before using your weight bench.
ICON assumes no responsibility for personal injury or property damage sustained by or through the
use of this product.
1. It is the responsibility of the owner to
ensure that all users of the weight bench are
adequately informed of all precautions.
2. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or persons with pre-existing health problems.
3. The weight bench is not intended for use by
persons with reduced physical, sensory, or
mental capabilities or lack of experience and
knowledge, unless they are given supervision or instruction about use of the weight
bench by someone responsible for their
safety.
4. Read all instructions in this manual and all
warnings on the weight bench before using
the weight bench.
5. The weight bench is intended for home use
only. Do not use the weight bench in a commercial, rental, or institutional setting.
carpet. Make sure that there is enough clearance around the weight bench to mount,
dismount, and use the weight bench.
8. Inspect and properly tighten all parts each
time the weight bench is used. Replace any
worn parts immediately.
9. Keep children under age 13 and pets away
from the weight bench at all times.
10. The weight bench is designed to support a
maximum user weight of 300 lbs. (136 kg)
and a maximum total weight of 410 lbs. (186
kg). Do not use more than 110 lbs. (50 kg)
of weight with the weight bench. Note: The
weight bench does not include weights.
11. Always wear athletic shoes for foot
protection while using the weight bench.
12. Always make sure that the locking pin is fully
inserted into the frame and into the pivot
bracket before you use the weight bench.
6. Keep the weight bench indoors, away from
moisture and dust. Do not put the weight
bench in a garage or covered patio, or near
water.
7. Place the weight bench on a level surface,
with a mat beneath it to protect the floor or
13. Over exercising may result in serious injury
or death. If you feel faint, if you become short
of breath, or if you experience pain while
exercising, stop immediately and cool down.
3
STANDARD SERVICE PLANS
all
4
BEFORE YOU BEGIN
Thank you for selecting the versatile GOLD’S GYM®
XR 5.9 weight bench. The XR 5.9 weight bench is
designed to help develop the major muscle groups
of the upper body. Whether your goal is to tone your
body, build dramatic muscle size and strength, or
improve your cardiovascular system, the weight bench
will help you to achieve the specific results you want.
For your benefit, read this manual carefully before
using the weight bench. If you have questions after
Backrest
reading this manual, please see the front cover of this
manual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
Before reading further, please look at the drawing
below and familiarize yourself with the parts that are
labeled.
Length: 4 ft. 6 in. (137 cm)
Width: 1 ft. 6 in. (46 cm)
Seat
Locking Pin
Pivot Bracket
Front Leg
Foam Pad
5
