GE CFE28USHSS, CFE28TSHSS, CYE22USHSS, CYE22TSHSS User Manual

Safety Instructions ............ 2-4

Operating Instructions

Features ..........................5, 6

Controls ..........................7-9

Dispenser ..........................10

Water Filter ........................11

Hot Water .........................12

Single Serve Keurig K-Cup Brewer ....13

Appliance Communication ..........14

Fresh Food Storage Options .....15,16

Climate Zone & Temperature

Controlled Drawer ...............17,18

Freezer ............................19

Automatic Ice maker ...............20

Care and Cleaning ................ 21

Replacing the Lights ................22

Bottom Freezer

Installation Instructions

Preparing to Install the

Refr igerato r ....................23, 24

Installing the Refrigerator .......25–35

Installing the Anti-Tip Bracket . . . 31, 32

Installing the Water Line ........36-38

Troubleshooting Tips ......40-42

Normal Operating Conditions .......39

Service - Truth or Myth .........42, 43

Consumer Support

Warranty ..........................44

RPWFE Water Filter Cartridge Limited

Warranty ........................45

Performance Data Sheet ...........46

Consumer Support .................48

Owner’s Manual and

Installation Instructions

GE Café™ models

Models that start with CFE are

Standard Depth Models (SD)

Models that start with CYE and CWE

are Counter Depth Models (CD)

Réfrigérateurs

Manuel d’utilisation

et instructions

d’installation

Modèles GE Café™

Les numéros de modèle commençant par

CFE sont des modèles de profondeur normale

(PN).

Les numéros de modèle commençant par

CYE et CWE sont des modèles de profondeur

de comptoir (PC).

Refrigeradores

Manual del Propietario

e Instrucciones de

Instalación

Modelos GE Café

Los modelos que comienzan con las letras

CFE son Modelos con Profundidad Estándar

(SD)

Los modelos que comienzan con las letras

CYE y CWE son Modelos con Profundidad de

Mesada (CD)

Write the model and serial numbers here:

Model # ____________________ Serial # ____________________

Find these numbers on a label on the left side, near the middle of the refrigerator compartment.

Refrigerators

239D3389P011 Pub No. 49-60741-3 04-16 GE

IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING.

SAFETY

GE Appliances website

For more information on your refrigerator’s operation, visit www.GEAppliances.com or

call 800.GECARES (800.432.2737). In Canada visit GEAppliances.ca or call 800.561.3344.

This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and the word “DANGER”, “WARNING”, or “CAUTION”. These words are defined as:

Indicates a hazardous situation which, if not avoided, will result in death or serious injury.

DANGER

Indicates a hazardous situation which, if not avoided, could result in death or serious injury.

WARNING

Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.

CAUTION

IMPORTANT SAFETY INSTRUCTIONS

WARNING

 This refrigerator must be properly installed and located in

accordance with the Installation Instructions before it is used.

 Unplug the refrigerator before making repairs, replacing a

light bulb, or cleaning. Note: Power to the refrigerator cannot be disconnected by any setting on the control panel. Note: Repairs must be performed by a qualified service professional.

 Replace all parts and panels before operating.  Do not store or use gasoline or other flammable vapors and

liquids in the vicinity of this or any other appliance.

To reduce the risk of fire, explosion, electric shock, or injury when using your

refrigerator follow these basic safety precautions:

 Because of potential safety hazards under certain

conditions, we strongly recommend against the use of an extension cord. However, if you must use an extension cord, it is absolutely necessary that it be a UL-listed (in the United States) or a CSA certified (in Canada), 3-wire grounding type appliance extension cord having a grounding type plug and outlet and that the electrical rating of the cord be 15 amperes (minimum) and 120 volts.

 To prevent suffocation and entrapment hazards to

children, remove the fresh food and freezer doors from any refrigerator before disposing of it or discontinuing its use.

 Do not allow children to climb, stand or hang on the door

handles or the shelves in the refrigerator. They could seriously injure themselves.

State of California Proposition 65 Warnings:

WARNING

CAUTION

 Do not clean glass shelves or covers with warm water

when they are cold. Glass shelves and covers may break if exposed to sudden temperature changes or impact, such as bumping or dropping. Tempered glass is designed to shatter into many small pieces if it breaks.

 Keep fingers out of the “pinch point” areas; clearances

between the doors and between the doors and cabinet are necessarily small. Be careful closing doors when children are in the area.

This product contains one or more chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

To reduce the risk of injury when using your refrigerator, follow these basic

safety precautions.

 Do not refreeze frozen foods which have thawed

completely.

 In refrigerators with automatic icemakers, avoid contact

with the moving parts of the ejector mechanism, or with the heating element that releases the cubes. Do not place fingers or hands on the automatic ice making mechanism while the refrigerator is plugged in.

IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. GEAppliances.com

SAFETY (CONT.)

INSTALLATION

WARNING

Explosion Hazard.

Keep flammable materials and vapors, such as gasoline, away from refrigerator. Failure to do so can result in fire, explosion, or death.

WARNING

Tip Over Hazard.

Built-in style models (model PYE, CYE, GYE, PWE, CWE, and ZWE) are top heavy, especially with any doors open. These models must be secured with the anti-tip floor bracket to prevent tipping forward, which could result in death or serious injury. Read and follow the entire installation instructions for installing the anti-tip floor bracket packed with your refrigerator.

CONNECTING ELECTRICITY

WARNING

Plug into a grounded 3-prong outlet Do not remove the ground prong Do not use an adapter Failure to follow these instructions can result in death, fire, or electrical shock.

Electrical Shock Hazard.

Do not, under any circumstances, cut or remove the third (ground) prong from the power cord. For personal safety, this appliance must be properly grounded.

The power cord of this appliance is equipped with a 3-prong (grounding) plug which mates with a standard 3-prong (grounding) wall outlet to minimize the possibility of electric shock hazard from this appliance.

Have the wall outlet and circuit checked by a qualified electrician to make sure the outlet is properly grounded.

Where a standard 2-prong wall outlet is encountered, it is your personal responsibility and obligation to have it replaced with a properly grounded 3-prong wall outlet. Do not use an adapter.

The refrigerator should always be plugged into its own individual electrical outlet which has a voltage rating that matches the rating plate.

A 115 Volt AC, 60 Hz, 15- or 20-amp fused, grounded electrical supply is required. This provides the best performance and also prevents overloading house wiring circuits which could cause a fire hazard from overheated wires.

Never unplug your refrigerator by pulling on the power cord. Always grip plug firmly and pull straight out from the outlet.

Repair or replace immediately all power cords that have become frayed or otherwise damaged. Do not use a cord that shows cracks or abrasion damage along its length or at either end.

When moving the refrigerator away from the wall, be careful not to roll over or damage the power cord.

IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING.

SAFETY (CONT.)

HOT WATER DISPENSER

WARNING

Scalding Hazard.

The hot water dispenser is capable of heating water to a temperature of approximately 185°F (85°C). Water temperatures above 125°F (52°C) can cause severe burns or death from scalding. Children, the disabled, and the elderly are at highest risk of being scalded.

Use this appliance only for its intended purpose as described in this Owner’s Manual. To reduce the risk of severe burns, scald injuries, or death when using your hot water dispenser, the instructions below must be followed:

 Do not permit children to use the hot water dispenser.  The hot water dispensing knob requires both twist and

push motions in order to reduce the risk of hot water being dispensed unintentionally or by small children. Do not tamper with or modify the hot water dispensing knob.

 The water coming from the dispenser is very hot. Use

extreme caution when dispensing and drinking water. Allow water to cool to a drinkable temperature before drinking.

 When dispensing water below 125ÛF, always test the

temperature of the water before drinking.

 When dispensing hot water, the container can become

very hot. Use a temperature insulating container, such as ceramic or foam. Using container materials such as paper or plastic may result in a burn while holding the cup. Do not use glass containers, as thermal shock can cause the container to break and may result in scalding or lacerations.

 Always follow the formula manufacturer’s instructions for

preparation of baby formula.

 Do not use with water that is microbiologically unsafe or of

unknown quality.

 Your container should be close to the dispensing point to

minimize the splashing of hot water.

 A newly installed water filter cartridge will cause water to

spurt from the dispenser. Run 2 gallons of water through the cold water dispenser (about 5 minutes) to remove air from the system. Until this air is removed from the system through the cold water dispenser, DO NOT use the hot water dispenser as it may result in spurting of hot water and lead to hot water scalding.

 The first time the hot water feature is used, confirm if

you live above 5000 feet (high altitude). This limits the temperature of the hot water system to avoid boiling. To access the high altitude selection, go to the settings menu.

 The hot water dispenser is designed to only dispense water.

Do not attempt to heat or dispense anything other than water. Do not attempt to disassemble or clean the tank.

 The hot water dispensing tank is a non-pressurized tank,

with a vent on the tank and a dispenser tube outlet. Do not modify the system, close or block the dispense tube, or connect any other type of device to the tank or dispense tube. Doing so may lead to rupture of the tank and hot water scalding.

PROPER DISPOSAL OF YOUR OLD REFRIGERATOR

WARNING

Remove fresh-food and freezer doors from the refrigerator, prior to disposal. Failure to do so can result in child entrapment which can lead to death or brain damage.

IMPORTANT:

Suffocation and child entrapment hazard.

Child entrapment and suffocation are not problems of the past. Junked or abandoned refrigerators are still dangerous even if they will sit for “just a few days.” If you are getting rid of your old refrigerator, please follow the instructions below to help prevent accidents.

Before You Throw Away Your Old Refrigerator or Freezer:

 Take off the fresh food and freezer doors.

 Leave the shelves in place so that children may

not easily climb inside.

Refrigerants

All refrigeration products contain refrigerants, which under federal law must be removed prior to product disposal. If you are getting rid of an old refrigeration product, check with the company handling the disposal about what to do.

READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.

SAVE THESE INSTRUCTIONS

About the features. GEAppliances.com

Space-saving ice maker*

Ice maker and bin are located on the door creating more usable storage space.

Showcase LED lighting

LED lighting is positioned throughout the interior to spotlight areas in the refrigerator. LEDs are located under the fresh food door to light the freezer when opened.

Drop-down tray*

Allows for extra door storage when you need it and tucks away when you don’t.

Full-width temperature controlled drawer

Adjustable temperature control bin that can accommodate larger items.

Dairy bin

Separate compartment for your items.

Ice bin/Ice maker*

Ice maker with ice storage bins.

QuickSpace™ shelf*

Functions as a normal full-sized shelf when needed and easily slides back to store tall items below.

Spillproof shelves

Designed to capture your spills for easier clean up.

Anti-slip Mat

Liner that captures spills, keeps containers from shifting when the door is opened and is easily removable for cleaning.

Removable door bin

Can be removed for those with a wall limiting the door opening.

Climate zone bin

Separate bins for produce storage.

Water filter

Filters water and ice.

* Select models only.

About the features .

Door ice bin*

1. Open left fresh food door.

2. Pull down latch to release bin door.

3. Using handhold lift ice bucket up and out to clear locators in bottom of bin.

4. To replace the ice bucket, set it on the guide brackets and push until the ice bucket seats properly.

5. If bucket cannot be replaced, rotate the Ice Bucket Fork 1/4 turn clockwise.

Drop down dairy bin*

1. Open right fresh food door.

2. Depress both buttons on lower sides and bin will drop down.

3. Reverse to reinstall.

Ice/water filter Remove filter/bypass plug

Push the indent on the cover and open filter door. Pull out on filter/ bypass plug and pull straight back to remove.

Installing the filter cartridge

Push the indent at the bottom of the cover and open. Lift door and align tabs on filter to filter/holder and push filter into place.

Latch

Ice bucket

Drop tray (tray open)

Push in and pull open

*Select Models Only

Swing

Push \ Pull

About the controls with temperature settings. GEAppliances.com

CYE/CFE Control Style CWE Control Style

Lock

Controls

Light

Temperature Express Modes Settings

Water

Water Crushed Cubed

Precise

Fill

Hot

Water

Changing the Temperature for Control Style CYE/CFE

To Change the Refrigerator Temperature: Access By: Temperature Button

Activate By: Below the word “Refrigerator”, use the arrows to select the desired temperature. Press DONE when finished to return to HOME screen. To Change the Freezer Temperature: Access By: Temperature Button Activate By: Below the word “Freezer”, use the arrows to select the desired

temperature. Press DONE when finished to return to HOME screen. To turn OFF cooling system, access SETTINGS from the HOME screen. Page over and tap COOLING SYSTEM ON. Press DONE to return to HOME screen. To turn ON cooling system, access SETTINGS from the HOME screen. Page over and tap COOLING SYSTEM OFF. Press DONE to return to HOME screen. Turning the cooling system off stops the cooling to refrigerator, but it does not shut off the electrical power.

Temperature

Refrigerator

Hold 3 Sec for °F/°C

Recommended: 37 °F

Actual Set

Energy Smart

Recommended: 0°F

Freezer

Energy Smart Override

Hold 3 Seconds

Door Alarm

Ice Maker

Lock Controls

Hold 3 Seconds

Reset Filter

Hold 3 Seconds

NOTE: For optimal temperature performance, we recommend to avoid placing food or other items directly at the air flow vents or the fresh food air tower, thus blocking the air flow.

Changing Temp. for Control Style CWE

Temperature Display is located on inside of left-hand refrigerator door. To change the temperature, press and release the REFRIGERATOR or FREEZER pad. The ACTUAL TEMP light will come on and the display will show the actual temperature. To change the temperature, tap either the REFRIGERATOR or FREEZER pad until the desired temperature is displayed. To turn OFF cooling system, press and hold the REFRIGERATOR and FREEZER pads simultaneously for 3 seconds. When the cooling system is OFF the display should read OFF. To turn ON cooling system, press either REFRIGERATOR or FREEZER pad. The display will show the preset temperature settings of 37°F for refrigerator and 0°F for freezer. Turning the cooling system off stops the cooling to refrigerator, but it does not shut off the electrical power.

About the controls features.

Control Style A, External Controls

Lock

Controls

Light

CFE/CYE Models

Temperature Express Modes Settings

Water

Water Crushed Cubed

Precise

Fill

Hot

Water

NOTE: The refrigerator is shipped with protective film covering the temperature controls. If this film was not removed during installation, remove it now.

The temperature controls are preset in the factory at 37°F for the refrigerator compartment and 0°F for the freezer compartment. Allow 24 hours for the temperature to stabilize to the preset recommended settings.

The temperature controls can display both the SET temperature as well as the actual temperature in the refrigerator and freezer. The actual temperature may vary slightly from the SET temperature based on usage and operating environment.

Hot Water

Dispenses up to 10 ounces of filtered hot water from user selected ranges of 90°F to 185°F.

Hot Water Knob

Illuminates to indicate hot water is ready. Dispenses with two motions: a counter-clockwise twist and then push to dispense.

Precise Fill

Precisely dispenses filtered water in accurate measurements in ounces, cups, quarts, or liters using paddle.

Refrigerator temp control

Adjust freezer compartment temperature.

Fresh food temp control

Adjust fresh food compartment temperature.

TurboFreeze™ setting

Activate TurboFreeze to quickly restore freezer temperatures after frequent door openings.

TurboCool™ setting

Activate TurboCool to quickly restore fresh food temperature after frequent door openings.

Humidity setting

Humidity setting can be normal or high.

Lock controls

Press and hold 3 seconds to lock out ice and water dispenser and all feature and temperature buttons.

LED dispenser light

LED lighting that can be turned on/off to light your dispenser.

Photo Upload

Insert USB memory stick to upload personal photos to the refrigerator LCD screen. LCD will provide on screen prompts to load and view slideshow. Make sure the photos are in the root directory in your USB.

Additional Settings

• Connected Home ready

• Slideshow

• Rese t filter

• Ice maker on/off

• Door alarm

• Sound control

• Cooling system On/Off

• Metric/English units

• Altitude Additional Modes

• Sabbath Mode Press and hold lock & light simultaneously for 3 seconds to enter/exit Sabbath mode. Activate Sabbath Mode to turn off interior lights, temperature control and advanced features. Compressor will run on a timed defrost when in Sabbath mode.

GEAppliances.com

Controls Style B, Internal Controls

Door Alarm

Sounds to alert when the freezer or fresh food doors have been left open.

Reset Filter

Hold for 3 seconds after replacing filter. Lock Controls

Press and hold 3 seconds to lock out ice and water dispenser and all feature and temperature buttons.

CWE Models

Refrigerator

Hold 3 Sec for °F/°C

Recommended: 37 °F

Actual Set

Energy Smart

Recommended: 0°F

Freezer

Energy Smart Override

Hold 3 Seconds

Door Alarm

Ice Maker

Lock Controls

Hold 3 Seconds

Reset Filter

Hold 3 Seconds

Freezer temp control

Adjust freezer compartment temperature

Refrigerator temp control

Adjust fresh food compartment temperature

Ice maker setting

Turn your ice makers on/off.

Sabbath Mode

Press and hold Door Alarm and Ice Maker simultaneously for 5 seconds to enter/exit Sabbath Mode.

About the dispenser. (CFE & CYE Models Only)

Water & Ice Dispenser

(See About the controls with temperature settings & About the control features)

Dispenser tray

WARNING

Laceration Hazard

 Never put fingers or any other object into ice crusher

discharge opening. Doing so can result in contacting the ice crushing blades and lead to serious injury or amputation

 Use a sturdy glass when dispensing ice. A delicate glass may

break and result in personal injury.

If no water is dispensed when the refrigerator is first installed, there may be air in the water line system. Press the dispenser paddle for at least five minutes to remove trapped air from the water line and to fill the water system. To flush out impurities in the water line, throw away the first six full glasses of water.

To remove Dispenser Tray



Pull Dispenser Tray out until it stops.



Locate tab in the center on the bottom and push up.



Pull Dispenser Tray assembly out.



Lift metal Dispenser Tray out at center notch to clean.

To reinstall Dispenser Tray



Place the Dispenser Tray cover on top of catch tray and

position under the two plastic retainers on either side.



Center Dispenser tray, and align with center guides.



Push in until is firmly in place.

Important Facts About Your Dispenser



Do not add ice from trays or bags to the door ice maker

bucket. It may not crush or dispense.



Avoid overfilling glass with ice and use of narrow glasses.

Backed-up ice can jam the chute or cause the door in the chute to freeze shut. If ice is blocking the chute remove the ice bucket, poke it through with a wooden spoon.



Beverages and foods should not be quick-chilled in the

door ice maker bin. Cans, bottles or food packages in the storage drawer may cause the ice maker or auger to jam.

To Use the Internal Water Dispenser (CWE Models Only)

The water dispenser is located on the left wall inside the refrigerator compartment.

To dispense water:

Hold the glass against the recess. Push the water dispenser button. Hold the glass underneath the

dispenser for 2–3 seconds after releasing the dispenser button. Water may continue to dispense after the button is released.



To keep dispensed ice from missing the glass, put the glass

close to, but not touching, the dispenser opening.



Some crushed ice may be dispensed even though you

selected CUBED ICE. This happens occasionally when a few cubes accidentally get directed to the crusher.



After crushed ice is dispensed, some water may drip from the

chute.



Sometimes a small mound of snow will form on the door in the ice chute. This condition is normal and usually occurs when you have dispensed crushed ice repeatedly. The snow will eventually evaporate.

If no water is dispensed when the refrigerator is first installed, there may be air in the water line system. Press the dispenser button for at least 5 minutes to remove trapped air from the water line and to fill the water system. During this process, the dispenser noise may be loud as the air is purged from the water line system. To flush out impurities in the water line, throw away the first 6 glassfuls of water.

NOTE: To avoid water deposits, the dispenser should be cleaned periodically by wiping with a clean cloth or sponge.

About the GE® RPWFE water filter cartridge.

Water Filter Cartridge

The water filter cartridge is located in the fresh food interior on the left side wall, near the top.

This product uses radio frequency identification (RFID) to detect leaks and monitor filter status. The RFID technology is certified by the FCC.

FCCID: ZKJ-EBX1532P001 ICID: 10229A-EBX1532P001

“This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.”

“This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.”

When to replace the filter cartridge

The filter cartridge should be replaced every six months or earlier if 170 gallons of water has been dispensed or the flow of water to the dispenser or icemaker decreases.

Touch Screen Models: A filter status message will appear on the screen when the water filter needs to be replaced. The filter status will automatically update when the filter is replaced.

Non-touch Screen Models: A filter indicator light will illuminate on the screen when the water filter needs to be replaced.

Removing the filter cartridge

To replace the filter, first remove the old cartridge by opening the filter door and pulling on the bottom of the cartridge to allow it to swing outward. When the cartridge can no longer swing, gently pull to unseat it from the cartridge holder. DO NOT TWIST CARTRIDGE. A small amount of water may drip out.

Installing the Filter Cartridge

1. Align top of filter cartridge with cartridge holder with the word “FRONT” facing outward then push the cartridge toward the rear of the unit until it is fully seated. DO NOT TWIST THE FILTER CARTRIDGE!

2. While continuing to ensure cartridge is fully seated in the holder, gently swing the filter inward until it is in position. If filter will not swing easily, check to ensure filter is properly aligned and fully seated within the cartridge holder. Close the filter door.

Swing

Push \ Pull

3. Run two gallons of water through the cold water dispenser (about 5 minutes) to remove air from the system. A newly

installed filter cartridge will cause water to spurt from the dispenser. Use a large pitcher or sports bottle to catch the

water spray. DO NOT use hands-free auto-fill (some models) until all air is removed from the system.

4. Reset Filter Status message (non-touch screen models).

WARNING

Use of the hot water dispenser prior to purging air from the system may result in spurting of hot water and lead to hot water scalding. Follow the instructions above to purge all air from the system through the cold water dispenser prior to using the hot water dispenser.

Note: It is normal for water to appear discolored during the initial system flush. Water color will return to normal after first few minutes of dispensing.

Filter Bypass Plug

To reduce the risk of property damage due to water leakage, you MUST use the filter bypass plug when a replacement filter cartridge is not available. Some models do not come equipped with the filter bypass plug. To obtain a free bypass plug, call 800-GECARES. In Canada, call 800.561.3344. The dispenser and icemaker will not operate without either the filter or bypass plug installed. The bypass plug is installed in the same way as a filter cartridge.

*Select Models Only

Scalding Hazard.*

WARNING

To reduce the risk associated with choking, do not allow children under 3 years of age to have access to small parts during the installation of this product. The disposable filter cartridge should be replaced every 6 months at the rated capacity,

or sooner if a noticeable reduction in flow rate occurs. For the maximum benefit of your filtration system, GE Appliances recommends the use of GE Appliances-branded filters only.

Using GE Appliances-branded filters in GE Appliances and Hotpoint® refrigerators provides optimal performance and reliability. GE Appliances filters meet rigorous industry NSF standards for safety and quality that are important for products that are filtering your water. GE Appliances has not qualified non-GE Appliances-branded filters for use in GE Appliances and Hotpoint refrigerators and there is no assurance that non-GE Appliances-branded filters meet GE Appliances standards for quality, performance and reliability.

If you have questions, or to order additional filter cartridges, visit our website at www.gewaterfilters.com or call GE Appliances Parts and Accessories, 877.959.8688.

Customers in Canada should consult the yellow pages for the nearest Camco Service Center.

About Hot Water. (CFE & CYE Models Only)

For GE Cafe™, Hot Water Only Models

To Use Hot Water Dispenser

• Press HOT WATER button.

• Select desired water temperature on the LCD screen (90, 150, 170, 185, or Custom).

• When hot water is ready (indicated on the screen and by a beeping sound) hold container with left hand centered in the recess under the spout.

• To dispense water, rotate the hot water knob counterclockwise and then push it in. The knob must be held in during dispense.

Lock

Controls

Light

Temperature Express Modes Settings

Water

Water Crushed Cubed

Precise

Fill

Hot

Water

Important Facts about HOT WATER

WARNING

Scalding Hazard.

• The water coming from the dispenser is very hot and can cause scalds or burns. Read all warnings on page 2

prior to use.

• Always use a container that is suitable for hot liquids (ceramic, foam, etc.)

• The maximum single hot water dispense amount is 10 oz. Additional hot water can be dispensed by restarting the hot water feature through the LCD screen.

• HOT WATER works best with household water pressure of 40 to 100 psi.

• HOT WATER will time out if unused and may require a short reheat time.

For GE Cafe™ with K-Cup Brewing System

Lock

Controls

Light

On GE Café refrigerators equipped with the K-Cup brewing system, ALL HOT WATER is dispensed from stainless steel dispense tube located under the right side of the control panel. The hot water is not dispensed from the center of the recess area.

To Use Hot Water Dispenser

• Press HOT WATER button.

• Select desired water temperature on the LCD screen (90, 150, 170, 185, or Custom).*

*If selecting “Keurig K-Cup Pod”, the hot water system will

change into K-Cup mode. See page 8 for K-Cup mode instructions.

•

When hot wa ter is ready (indicated on the screen and by a beeping sound) hold container with left hand centered in the recess under the spout.

•

To dispense water, rotate the hot water knob counterclockwise and then push it in. The knob must be held in during dispense.

Temperature Express Modes Settings

Water

Water Crushed Cubed

Precise

Fill

Hot

Water

Important Facts about HOT WATER

WARNING

Scalding Hazard

• See Hot Water Warning: Scalding Hazard above.

• Do no permit children to use the brewer.

• Always use a container that is suitable for hot liquids (ceramic, foam, etc.)

• Do not brew into a mug made of glass. Doing so may cause the glass to crack or break.

About Single Serve Keurig K-Cup Brewer

How to use the single serve dispenser

GEAppliances.com

Load Keurig K-Cup into brewer.

Push to

open

Drop K-Cup

into brewer and

press down

firmly.

Two ways to brew:

1. Press Hot Water. Select K-Cup Pod. OR

2. Slide the brewer into the rails.

Pick your size.

NOTICE: If using a powdered beverage, select the Cocoa setting.

Close brewer.

Lid will click

when secure.

CAUTION

Cut/Puncture Hazard.

• There are two sharp needles located inside the K-Cup brewer. To avoid risk of injury, do not put your fingers inside the brewer. Use caution when cleaning.

• Keep the K-Cup brewer out of the reach of children, as they may be injured in using the K-Cup brewer incorrectly.

Temperature Express Modes Settings

Cancel

Serving Size

Controls

Lock

Light

Coffee CocoaCoffee

Water

Water Crushed Cubed

Precise

Fill

Hot

Water

Rails for the brewer

Place your mug under the brewer (on the tray mug icon and under the red brew spout).

4 5

NOTICE: Make sure the mug being used is large enough for the size selected.

Red brew spout for mug alignment

Mug icon for placement

Rotate the hot water knob counterclockwise and push in to brew and dispense.

NOTICE: Press any button or dispenser paddle, or open either the left or right door to cancel dispense.

Lock

Controls

Light

Cleaning the brewer



The K-Cup brewer is dishwasher safe. To clean it, open the lid and place the K-Cup

brewer in the top rack of your dishwasher and run in a normal wash cycle.



To maximize performance of your brewer, it is recommended to rinse it thoroughly after

washing to remove all soap residue.



Periodic cleaning of dispenser recess area is recommended as staining may occur with

usage of the K-Cup brewer.

6oz

6oz Brew

Water Crushed Cubed

8oz

Precise

Water

10oz

Fill

Hot

Appliance Communication

(for customers in the United States and its t errit ories)

GE WiFi Connect GE WiFi Connect Enabled*

If your refrigerator has a Connected Appliance information label located on the inside as shown, your refrigerator can be connected to your WiFi network, allowing it to communicate with your smart phone for remote monitoring, control and notifications. Depending on the refrigerator model you have, you either have a WiFi communication card built into the product , or a port for an external W iFi ConnectPlus Module (sold separately). Please visit www.GEAppliances.com/connect to learn more about connected appliance features, and to learn what connected appliance apps will work with your Smart Phone.

WiFi Connectivity: For assistance with the appliance or the ConnectPlus network connectivity (for models that are WiFi enabled or WiFi optional), please call 1-800-220-6899.

REGULATORY INFORMATION FCC/IC Compliance Statement:

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/television technician for help. Labelling: Changes or modifications to this unit not expressly approved by the manufacturer could void the user’s

authority to operate the equipment.

*Select Models Only

About the fresh food storage options. GEAppliances.com

Rearranging the Shelves

Shelves in the refrigerator compartment are adjustable.

To remove:

Remove all items from the shelf. Tilt the shelf up at the front. Lift the shelf up at the back and bring the

shelf out.

To replace:

While tilting the shelf up, insert the top hook at the back of the shelf in a slot on the track.

Lower the front of the shelf until the bottom of the shelf locks into place.

Spillproof Shelves

Spillproof shelves have special edges to help prevent spills from dripping to lower shelves.

Quick Space Shelf *

This shelf splits in half and slides under itself for storage of tall items on the shelf below.

This shelf can be removed and replaced or relocated (just like spillproof shelves).

NOTE: The back half of the Quick Space Shelf is not adjustable.

*Select Models Only

About the fresh food storage options.

Non-Adjustable Dairy Bin*

To remove: Lift the dairy bin straight up,

then pull out.

Adjustable Bins on the Door

Adjustable bins can easily be carried from refrigerator to work area.

To remove: Lift bin straight up, then pull out. To replace or relocate: Slide in the bin just

above the molded door supports, and push down. The bin will lock in place (see page 33).

Non-Dispense Models (Left Hand Door)

To replace: Engage the bin in the molded door

supports and push down. The bin will lock in place. See page 33.

Drop down tray *

(tray open)

1. Open right fresh food door

2. Depress both buttons on lower sides of bin and bin will drop down.

3. Reverse to reinstall.

Non-Adjustable Bins on the Door (Dispenser Models - Left Hand Door)

To remove: Lift the bin straight up, then pull

out. To replace: Engage the bin in the molded

supports on the door and push down. It will lock in place.

The ice maker door bins are not interchangeable, note the location upon removal and replace the bin in its proper location.

*Select Models Only

About the climate zone and temperature controlled drawer. GEAppliances.com

ClimateZone

Keep fruits and vegetables organized in separate compartments for easy access.

Excess water that may accumulate in the bottom of the drawers or under the drawers should be wiped dry.

Temperature Controlled Drawer

The Temperature Controlled Drawer is a full-width drawer with adjustable temperature control. This drawer can be used for large miscellaneous items.

To change setting, press select button.

Note: Temperatures indicate the appropriate temperatures for the food and actual temperatures may vary based on normal operation and other factors such as door openings and fresh food set point.

Meat Beverage Deli

32° 34° 38°

CAUTION

Laceration Hazard.

Do not store glass bottles at this setting. If they are frozen, they can break and result in personal injury.

Select

About the climate zone and temperature controlled drawer.

How to Remove and Replace the Adjustable Deli/Produce Drawer

To remove:

Pull the drawer out to the stop position. Lift the front of the drawer up and out.

To replace:

Pull left and right slides until fully extended. Place drawer back in first and rotate drawer

front down to seat on slide. Push the drawer in to closed position.

How to Remove and Replace Drawer Divider*

To remove:

Pull the drawer out to the stop position. Slide pan divider to right to release it from

pan.

To replace:

Reverse steps 1 and 2 to replace drawer divider.

*Select Models Only

About the freezer. GEAppliances.com

Freezer Basket and Drawer

Basket. Drawer

Ice Bucket*

Non-Adjustable Bin in the Freezer

To remove: push in plastic tab on either left or

right side

To replace: slide bin into location until it locks into place.

Basket Removal

To remove, CFE only:

Open freezer door to the stop position. Remove freezer door bin by pushing

plastic tab on either left or right side to release bin hinge pin.

Remove freezer basket by lifting up the rear of the basket and moving basket rearward until the front of the basket can be rotated upward and out.

Lift it out to remove.

To remove, CYE and CWE only:

Open fresh food doors. Open freezer doorto the stop position.

Remove freezer basket by lifting up the rear of the basket and rotate it upward.

Lift it out to remove.

To replace:

Reverse step 1 thru 4 to replace.

*Select Models Only

About the automatic ice maker.

A newly installed refrigerator may take 12 to 24 hours to begin making ice.

Ice maker

Feeler Arm

Automatic Ice maker (on some models)

The ice maker will produce seven cubes per cycle approximately 100–130 cubes in a 24-hour period, depending on freezer compartment temperature, room temperature, number of door openings and other use conditions.

The ice maker will fill with water when it cools to 15°F (–10°C). A newly installed refrigerator may take 12 to 24 hours to begin making ice cubes.

If the refrigerator is operated before the water line connection is made to the unit or if the water supply to an operating refrigerator is turned off, make sure that the ice maker is turned off. Once the water has been connected to the refrigerator, the ice maker may be turned on. See the table below for details.

WARNING

You may hear a buzzing sound each time the ice maker fills with water.

Throw away the first few batches of ice to allow the water line to clear.

Be sure nothing interferes with the sweep of the feeler arm.

When the bin fills to the level of the feeler arm, the ice maker will stop producing ice. It is normal for several cubes to be joined together.

If ice is not used frequently, old ice cubes will become cloudy, taste stale and shrink.

NOTE: In homes with lower-than-average water pressure, you may hear the ice maker cycle multiple times when making one batch of ice.

To minimize the risk of personal injury, avoid contact with the moving parts of the ejector mechanism, or with the heating element that releases the cubes. Do not place fingers or hands on the automatic ice making mechanism while the refrigerator is plugged in.

How to Turn the Ice Maker On/Off

Display Type (See Page 7) Model # How to turn the ice maker on/off

Control Style A CYE/CFE Use the settings menu on the touchscreen Control Style B CWE Use the “ICE MAKER” button on the control

Lift and pull

Ice Box Door

Ice Bucket and Dispenser*

• Open the ice box door on inside of the left door.

• Pull up and out on the ice bucket in the left hand door to remove it from the compartment .

• To replace the ice bucket, set it on the guide brackets and push until the ice bucket seats properly.

• If bucket cannot be replaced, rotate the ice bucket fork 1/4 turn clockwise.

Freezer Ice Bucket*

The ice storage is in the freezer compartment drawer.

• Open the freezer drawer.

• The ice bucket is located on the left side of the upper basket.

• Pull the upper basket forward to remove the ice bucket.

Freezer Ice Bucket

Care and cleaning of the refrigerator. GEAppliances.com

Cleaning the Outside

The stainless steel panels, door handles and trim.

The stainless steel doors and door handles (on some models) can be cleaned with a commercially available stainless steel cleaner. Cleaners with oxalic acid such as Bar Keepers Friend Soft Cleanser™ will remove surface rust, tarnish and small blemishes. Use only a liquid cleanser free of grit and rub in the direction of the brush lines with a damp soft sponge. Do not use appliance wax or polish on the stainless steel.

Cleaning the Inside

Unplug the refrigerator before cleaning.

If this is not practical, wring excess moisture out of sponge or cloth when cleaning around switches, lights or controls. Use an appliance wax polish on the inside surface between the doors.

8VHZDUPZDWHUDQGEDNLQJVRGDVROXWLRQ³DERXWD

tablespoon (15 ml) of baking soda to a quart (1 liter) of water. This both cleans and neutralizes odors. Rinse and wipe dry.

Behind the Refrigerator

Be careful when moving the refrigerator away from the wall. All types of floor coverings can be damaged, particularly cushioned coverings and those with embossed surfaces.

Silver-accented plastic parts.

Wash parts with soap or other mild detergents. Wipe clean with a sponge, damp cloth or paper towel. Do not use scouring pads, powdered cleaners, bleach or cleaners containing bleach because these products can scratch and weaken the paint finish.

Should spill tray need cleaning use lime remover.

CAUTION

Do not clean glass shelves or covers

with warm water when they are cold. Glass shelves and covers may break if exposed to sudden temperature changes or impact such as bumping or dropping. Tempered glass is designed to shatter into many small pieces if it breaks.

Do not wash any plastic refrigerator parts in the dishwasher.

Pull the refrigerator straight out and return it to position by pushing it straight in. Moving the refrigerator in a side direction may result in damage to the floor covering or refrigerator.

Raise the leveling legs located at the bottom front of the refrigerator.

Preparing for Vacation

For long vacations or absences, remove food and unplug the refrigerator. Clean the interior with a baking soda solution of one tablespoon (15 ml) of baking soda to one quart (1 liter) of water. Leave the doors open.

LCD Models: turn refrigerator off at control (pg 7) . If the temperature can drop below freezing, have a qualified

service technician drain the water supply system to prevent serious property damage due to flooding.

1) Turn refrigerator off (pg. 7) or unplug the refrigerator.

2) Empty ice bucket

Preparing to Move

Secure all loose items such as shelves and drawers by taping them securely in place to prevent damage.

When using a hand truck to move the refrigerator, do not rest the front or back of the refrigerator against the hand truck. This could damage the refrigerator.

Lower the leveling legs until they touch the floor.

When pushing the refrigerator back, make sure you don’t roll over the power cord or water supply line.

3) Turn water supply off

If you cut the water supply off, turn off the ice maker (pg. 18).

Upon returning from vacation:

1) Replace the water filter.

2) Run 2 gallons of water through the cold water dispenser (about 5 minutes) to flush the system.

3) Dispense 185°F hot water 3 times (10 oz. each) to flush the system.

Handle only from the sides of the refrigerator.

Be sure the refrigerator stays in an upright position during moving.

Replacing the lights

Refrigerator Lights (LEDs)

There is LED lighting in fresh food compartment and on the bottom of the fresh food doors to light the freezer compartment.

An authorized technician will need to replace the LED light.

If this assembly needs to be replaced, call GE Appliances Service at 1.800.432.2737 in the United States or 1.800.561.3344 in Canada.

Installation

Refrigerator

Instructions

Questions? Call 800.GE.CARES (800.432.2737) or v isit our Website at: GEAppliances.com In Canada, call 1.800.561.3344 or visit our Website at: www.GEAppliances.ca

GE Café™ models

BEFORE YOU BEGIN

Read these instructions completely and carefully.

WARNING

•

IMPORTANT ³

and ordinances. Save these instructions for local inspector’s use.

• Note to Installer – Be sure to leave these instructions with the Consumer.

• Note to Consumer – Keep these instructions for future reference.

• Skill level – Installation of this appliance requires basic mechanical skills.

• Completion time –

Water Line Installation 30 minutes

• Proper installation is the responsibility of the installer.

• Product failure due to improper installation is not covered under the Warranty.

Tip Over Hazard.

Observe all governing codes

Refrigerator Installation can vary

TOOLS YOU MAY NEED

Adjustable Wrench

1/4” Outer Diameter

Compression Nut

and Ferrule (sleeve)

1/8”, 3/32”, 1/4” & 5/32”

Allen Wrenches

1/8” Drill Bit and Electric or Hand Drill

Pencil

Ȓµ Socket Ratchet/Driver

Phillips-Head Screwdriver

Flat-Head Screwdriver

Tape Measure

1/4” Nut Driver

PREPARATION

MOVING THE REFRIGERATOR INDOORS

If the refrigerator will not fit through a doorway, the refrigerator door and freezer drawer can be removed.

• To remove the refrigerator door, see the Installing the Refrigerator section.

• To remove the freezer drawer, see the Removing the Freezer Drawer section.

WATER SUPPLY TO THE ICE MAKER AND DISPENSER

If the refrigerator has an ice maker, it will have to be connected to a cold water line. A GE Appliances water supply kit (containing tubing, shutoff valve, fittings and instructions) is available at extra cost from your dealer, by visiting our website at GEAppliances.com (in Canada at www.GEAppliances.ca) or from Parts and Accessories,

888.959.8688 (in Canada 1.800.661.1616).

Pliers

Torx T20, T25

Level

Installation Instructions

DIMENSIONS

ø8

”

All measurements are given with leveling leg fully retracted.

CFE OnlyCYE, CWE Only

353ø4”353ø4”

ø8

”69

Case Depth w/o

CFE

”

ø8

CYE

”

ø8

Doors 29

23 1ø4” CFE 18 1ø4” CYE

Height from

floor to hinge

cover top 69

ø8”

69”69”

Additional Dimensions

361ø4”311ø4”

MOVING THE REFRIGERATOR

• Using the chart below determine if the width of your passageway can accommodate the depth of the refrigerator. Ensure you have clearance to prevent damage to the refrigerator before safely moving it to the final location.

• If passageways are large enough to accommodate the refrigerator without removing the handles skip to Step 6. Leave tape, film and all packaging on doors until the refrigerator is in the final location.

• NOTE: Use a padded hand truck or moving straps to move this refrigerator. Place the refrigerator on the hand truck

with a side against the truck. We strongly recommend that two people move and complete this installation.

If your model number starts with CFE

CFE CYE, CWE

ø8

Overall Height to Top of

Hinge Cover Height to Top of Cabinet Case Depth without Doors Overall Exterior Case Width Overall Exterior Depth

69” 69”

ø8

353ø4”353ø4”

36¼” 31¼”

Doors/Drawers with Handles

If your model number starts with CYE, CWE

”69

”24

ø8

”

ø8

36.25” 35.25” 29.375”

33.75” 30.25”

31.25”

30.25”

28.75”

25.25”

24.375”

Installation Instructions

INSTALLING THE REFRIGERATOR

REFRIGERATOR LOCATION

• Do not install the refrigerator where the temperature will go below 60°F (16°C) because it will not run often enough to maintain proper temperatures.

• Do not install the refrigerator where the temperature will go above 100°F (37°C) because it will not perform properly.

• Do not install the refrigerator in a location exposed to

water (rain, etc.) or direct sunlight.

• Install it on a floor strong enough to support it fully loaded.

CLEARANCES

Allow the following clearances for ease of installation, proper air circulation and plumbing and electrical connections.

REMOVE THE FRESH FOOD

DOOR HANDLE

Handle Design varies based on models, however Installation is same.

Stainless steel and plastic handles:

Loosen the set screws with the 1/8” Allen wrench and

remove the handle. NOTE: If the handle mounting fasteners need to be tightened or removed, use a 1/4” Allen wrench.

Mounting Fasteners

Sides 1/8” (3 mm) Top 1” (25 mm) Cabinet/Hinge Cover Back 2” (50 mm)

REMOVING THE REFRIGERATOR DOORS

• IMPORTANT NOTE: This refrigerator is 361/4” deep (311/4” for CYE models). Doors and passageways leading to the installation location must be at least 36 leave the doors and handles attached to the refrigerator while transporting it into the installation location. If passageways are less than 36

/4”, the refrigerator doors and handles can easily be scratched and damaged. The top cap and doors can be removed to allow the refrigerator to be safely moved indoors. If passageways are less than 31 start with Step 1.

• If it is not necessary to remove doors, skip to Step 11. Leave tape and all packaging on doors until the refrigerator is in the final location.

• NOTE: Use a padded hand truck to move this refrigerator. Place the refrigerator on the hand truck with a side against the truck. We strongly recommend that TWO PEOPLE move and complete this installation.

/4” wide in order to

/4”,

Leave film on until after installation

REMOV E T H E FREEZER DOOR HANDLE

Handle Design varies based on models, however Installation is same.

Stainless steel and plastic handles:

Loosen the set screws with the 1/8” Allen wrench and remove the

handle. NOTE: If the handle mounting fasteners need to be tightened or removed, use a 1/4” Allen wrench.

Mounting

Fasteners

Leave film on until after installation

Reinstall the handles using the same procedure as removing.

Installation Instructions

INSTALLING THE REFRIGERATOR (cont.)

REMOVE THE REFRIGERATOR DOORS

3 3

Securely tape the door shut with masking tape or have

a second person support the door.

Start with left-hand door first: Remove the hinge cover

on top of the left refrigerator door by removing all hex screws and pulling it up. Do the same for the right-hand door and the middle cover.

Hinge Cover

REMOVE THE REFRIGERATOR DOORS (cont)

Disconnect the water line from the back of the unit by

pressing down on the dark grey collar while pulling up on the water line.

Pull waterline through case conduit from the top to free the line for door removal. The water line is more than 4’ long and may need to be taped to Door for accessibility when reinstalling.

Disconnect both electrical connectors at the top cover.

Remove the 1/4” hex head screw to disconnect the ground wire from the hinge. Remove the 1/4” hex head screw to remove the strain relief from the water line.

Ground screw

Strain Relief

Using a 3/8” socket ratchet/driver, remove the screws

securing the top hinge to the cabinet,

then lift the hinge straight up to free the hinge pin

from the location in the top of the door.

CAUTION

Single person lift could cause injury. Use assistance when handling, moving or lifting the refrigerator doors.

Note: when removing door, to prevent damage to door and electronics, carefully place the door in a proper location. Note: The lower door hinge pin and hinge are keyed and must be matched correctly for the door to self close properly. Please follow the directions carefully.

Lifting Hazard.

Installation Instructions

INSTALLING THE REFRIGERATOR (cont.)

REMOVE THE REFRIGERATOR DOORS (cont)

Note: for proper installation later, please follow the next step carefully.

Fresh Food doors to be REMOVED and INSTALLED

opened at 90° with case front.

Lift up & off center hinge

Open Door to 90°

REMOVE OPPOSITE DOOR

Follow the same procedure on the opposite door. There are no wires or water lines on the opposite side

REINSTALLING THE REFRIGERATOR DOORS

Reverse steps 1 through 4 to reinstall refrigerator, follow details below for critical alignments.

Reinstall center hinge first and torque the screws to 65 in-lbs. With the LH door at 90º to the front of

the case, lower the refrigerator door onto the center hinge. Ensure that the door and hinge align correctly.

Rotate doors closed and make sure moveable center sealing portion of the door aligns with the striker. If the door will not

self-close after reinstalling, remove door, turn door upside down, check alignment mark and arrow; (there is an alignment mark on the door closure mechanism It corresponds to an alignment mark on the bottom end cap. Rotate door closure mechanism to align mark and arrow, reinstall door).

REMOVE CENTER HINGE (if necessary)

Remove the 3/8ļscrews securing the center hinge to the cabinet. Use T20 driver to remove outboard screw

Remove center screw

Loosen Outer screws

Underside of Fresh Food Door

align marks

If door cannot be installed at 90° follow steps below:

1. If space or model limits opening door to less than 180°, then: a) Remove door, carefully turn door upside down. b) Check alignment of door closure mechanism shaft on underside of door. The flats on the shaft should correspond to alignment tab on plastic ring or mark on bottom end cap. c) If shaft is not aligned to tab/mark, using 5/32” Allen wrench, rotate door closure mechanism shaft counterclockwise for right door and clockwise for left door. Then align flat with tab/mark. d) Install the door at 90°.

Securely tape the door shut with masking tape or have a second person support the door. Reinstall the top hinge and torque the screws to 65 in-lbs.

Be sure to reinstall the ground wire and strain relief to the top hinge.

Reinstall the hinge cover. Note: Ensure wires are not pinched or

under screw bosses before tightening screws.

Installation Instructions

INSTALLING THE REFRIGERATOR (cont.)

REMOVE THE FREEZER DOOR

Pull the freezer door open to full extension. Remove 3 attachment screws, located at the bottom

on each side of the freezer door using 3/8” hex socket driver.

A B

REPLACING THE FREEZER DOOR

Pull the slide Mechanism to full extension using both hands simultaneously.

Remove the basket resting on the slides.

CAUTION

Freezer door is heavy Use both hands to secure the door before lifting.

Lift the freezer door to disengage it from the slide

mechanism

Lifting Hazard

CAUTION

Freezer door is heavy Use both hands to secure the door before lifting.

Lift the freezer door and place it on the slide mechanism

Lifting Hazard

Align and insert tab on freezer door bracket into slot on freezer slide bracket.

The door can safely rest on the bottom. Do not rest the door on any other surfaces to avoid scratches.

Push the slide mechanism back completely until it self retracts.

Replace the attachment screws and torque the screws

to 65 in-lb For adjusting freezer door gaps, follow the instructions

on pg 27. Replace the basket

Installation Instructions

INSTALLING THE REFRIGERATOR (cont.)

Instructions for adjusting freezer door gaps:

IMPORTANT! The 6 mounting screws (3 on each side) are NOT interchangeable with the center or top hinge screws. Drawer screws have flat washer heads, and other screws have lines/ribs on washer heads.

After installation of the freezer door, check for uniform gaps (top and bottom of right and left hand side) with the template provided.

In the event of excessive gaps use the following steps to adjust the freezer door.

Step 1 - Loosen the 3 screws on each side (right and left) of the freezer door.

Step 2 - Adjust set screw clockwise if gap at the top is too big (see template). Turn the set screw using 3/32” hex

key clockwise by quarter to half a rotation Step 3 - Adjust set screw counter-clockwise if gap at the bottom is too big (see template). Turn the set screw

using 3/32” hex key counter-clockwise by quarter to half a rotation

Step 4 - Tighten the 3 screws on each side (right and left). Step 5 - Re-check the gaps using the template and repeat steps 1 to 4 if required and complete with step 5.

Fold here for using template

0.600”

Template for checking gaps.

Gap should be 0.6” or below.

Gabarit pour vérifier les

écarts. L’écart doit être de

0,6 po (1,5 cm) ou moins.

Plantilla para el control de

espacios. El espacio debería

ser de 0.6” o inferior.

Plier ici pour utiliser le gabarit Dóblelo aquí para usar la plantilla

Step 1 Étape 1 Paso 1

Step 4 Étape 4 Paso 4

Set Screw Vis d’ajustement Tornillo del Set

Step 2 Étape 2 Paso 2

Step 3 Étape 3 Paso 3

Installation Instructions

INSTALLING THE REFRIGERATOR (cont.)

LEVEL THE FREEZER DOOR

LEVEL THE FREEZER DOOR (cont.)

Lift the door on the side requiring adjustment, rotate the cam to required position.

0 - Initial position 1 - Lift by 0.050”

-1 - Lower by 0.050”

-2 - Lower by 0.100

-3 - Lower by 0.150”

Locate the height adjuster cam in the freezer

door. Slightly loosen the three door attachment screws on both sides using a 3/8” hex socket driver.

Locate and loosen the cam screw using the

T-27 screw driver.

After adjustment tighten the 3 attachment

screws using to 65 in-lb.

REMOVE PACKAGING

A) Remove all tape, foam and protective

packing from shelves and drawers.

+ 114 hidden pages
