Gateway ADC-320, WGM-240 Firmware Update Manual

Updating Your

Gateway

Connected DVD

Player Firmware

Before your Gateway Co nnected DVD Player can use your

802.11 g wirele ss network ing card, you must u pdate your
DVD player’ s firmwar e.

To update your DVD player’s firmware:

1 T urn on the te levisio n connec ted to your DVD player ,

then turn on your DVD player by pressing the power

button on the front of the player.
2Press the Open/Close button to open the DVD tray.
3Insert the Gateway Conne cted DVD Player Firmware

Upgrade CD, then close th e DVD tray. A menu appears

on your television.
4 Use the arrow keys on your remote control to

highlight

A screen displays the progress of the upgrade. After the

firmw are is up dated, th e DVD tray opens

automatically.
5 Remove the CD and close the DVD tray.
6 To finish the u pdate, tu rn off your D VD player b y

pressing the power button on the front of the player.

Your DVD player’s firmware has been updated, and i t

can now use the 802.11g wireless networking card for

communicat ing with your home ne twork.

Upgrade My Firmware, then press Enter .

1

Appendix : Updating Your Gateway Connected DVD Player Firmware

Regul atory compliance statements

Wireless Guidance

The WGM-240 wireless PCMCIA card is int ended to be use
exclusively with the Gateway Connected DVD player .

The WGM -240 802.1 1g wire less LAN (low po wer Radi o
Frequency, RF, transmitt ing device) o perates in t he
2400 - 2483.5 MHz band. The following section is a general
overview of considerations while operating the wireless LAN.

Limitations, cautions, and concerns are listed below and in the
specific country sections (or country group sections). This
wireless device is only qualified for use in the countries
identified by the Rad io Approval Marks on the device rating
label. If the country you will be using the wireless device in is
not listed , please contac t that countri es local Radio Approval
agency for requirements prior to operatio n. Wireless devices
are closely regulated and use may not be allowed.

The power output of the WGM-240 wireless LAN device is well
below the RF exposure limits as known at this time. Because
this wireless device emits less energy than is allowed in radio
frequency safety standards and recommendations, Gateway
believes thes e devices are saf e for use. Regardless of the power
levels, care should be taken to minimize human contact during
normal oper ation.

Measurements have been performed to show tha t the RF
exposure is below what is considered safe limits; however, care
should be taken to make sure that the user or bystanders keep
the trans mitter away from th eir bodies w hen the w ireless
device is transmitting. Measurements indicated compliance
with RF exposure limits at the antenna housing's surface.

As stated previously , this ca rd is only intended to be used in
the Gateway Connected DVD Pla yer where this separation
distance can be maintained.

This wireless device is intended to be used indoors. In some
areas, use of this device o utdoors is prohibited.

Some circumstances require restrictions on using wireless
devices. Examples of common restrictions are listed below:

2

Warning

Radio frequen cy wireless comm unication can inter fere
with equipment on commercial aircraft. Current
aviation regulations require wireless devices to be
turned off while trav el ing in an airplane. IEE E 802.11g
(also known as wireless Ethernet or Wifi)
communication devices are examples of devices that
provide wirel ess commun ication. See the user’s guide
for the device that this card will be installed into for
instructions on turning off the wireless functionality.

Warning

Warning

Warning

In enviro nments where the risk of inte rf erence to o ther
devices or services is harmful or perceived as
harmful, the option to use a wireless device may be
restricted or eliminated. Airports, hospitals, and
oxygen or flammable gas laden atmospheres are
limited examples where use of wireless devices may
be restricted or eliminated. When in environments
where you are uncertain of the sanction to use
wireless devices, ask the applicable authority for
authorization prior to use or turning on the wireless
device.

Every country has different restrictions on the use of
wireless devices. When traveling between countries,
check with th e local Radio Approval authorities prior to
any move or trip for any restrictions on the use of a
wireless device in the destination country.

Do not operate the wireless device unless all covers
and shields are in place and the device it is installed
into is fully assembled.

Warning

Warning

Wireless devices are not user serviceable. Do not
modify them in any way. Modification to a wireless
device will void the authorization to use it. Contact
Gateway for service.

Only use drivers approv ed f or the country in which the
device will be used. Insta ll the Gate way device driv ers
included with your product, or contact Gateway
Technical Support for additional information.

3

Appendix : Updating Your Gateway Connected DVD Player Firmware

United States of America

Federal Comm unications Co mmission (FCC)
Intentional emitter per FCC P art 15

The power output of the WGM-240 wireless LAN device is well
below the RF exposure limits as known at this time. Because
this wireless device emits less energy than is allowed in radio
frequency safety standards and recommendations, Gateway
believes thes e devices are saf e for use. Regardless of the power
levels, care should be taken to minimize human contact during
normal oper ation.

Measurements have been performed to show tha t the RF
exposure is below what is considered safe limits; however, care
should be taken to make sure the us er or bystanders keep the
transmitter away from their bodies when the wireless device is
transmitting. This equipment complies with FCC radiation
exposure limits for an uncontrolled environment, of a portable
transmitting device, under 47 CFR 2.1093 paragraph (d)(2).
Measurements indicated compliance with RF exposure limits at
the antenna housing's surface.

This wireless device is intended to be used indoors. In some
areas, use of this device o utdoors is prohibited.

As stated previously , this ca rd is only intended to be used in
the Gateway Connected DVD Pla yer where this separation
distance can be maintained. The Gateway WGM-240 is limited
to use o n channels o ne through eleven by s pecified firmw are
controlled in U.S.A. as a requirement of the FCC grant.

Operation of this device is subject to the following two
conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received,
including interference that may cause undesired operation of
the device.

Warning

Warning

In order to comply with FCC requirements this
transmitter must not be operated (or co-located) in
conjunction with any other transmitter or antenna.

Wireless devices are not user serviceable. Do not
modify them in any way. Modification to a wireless
device will void the authorization to use it. Contact
Gateway for service.

4

Unintentional em itter per FCC P art 15

This device has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio or television rec eption. However, there is
no guarantee that interference will not occur in a particular
installation. If this eq uipment does cause interferen ce to radio
and television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to
correct the interfer ence by one or more of the following
measures:

■ Reorient or relocate the receiving antenna

■ Increase the sep aration between the equipme nt and receiver

■ Connect the equipm ent into an outlet on a circuit different

from that to which the receiver is connected

■ Consult the dealer or an experienced radio/TV te chnician for

help.

Compliance Accessories: These accessories are re quired to be
used in order to ensure compliance with FCC rules: None.

5

Appendix : Updating Your Gateway Connected DVD Player Firmware

FCC declar ation of conformity

Responsi ble party:
Gateway Companies, Inc.

610 Gateway Drive, North Sioux City , SD 57049
[phone] Fax: [phone]

Product:

■ WGM-240

This device complies with Part 15 of the FCC Rules. Operation
of this product is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operat ion.

Warning

Changes or modifications not expressly approved by
Gateway could void the FCC compliance and negate
your authority to operate the product.

California Proposition 65 W arning

Warning

This product contains chemicals, including lead,
known to the State of California to cause cancer
and/or birth defects or reproductive harm.

6

Notices

Copyright © 2003 Gateway, Inc.
All Rights Reserved
14303 Gateway Place
Po way, CA 92064 USA

All Rights Reserved

This public ation is protec ted by cop yright and all rights are r eserved. No part of it may be
reproduced or tr ansmitted by an y means or in an y form, withou t prior consent in writing
from Gatew ay.

The inf ormation in this manu al has been carefull y checked a nd is belie ved to b e
accurate. H owe ver , changes ar e made periodically. These changes ar e incorporated in
newer publication editions. Gate wa y may impr ove an d/or change products descri bed in
this publication at an y time. Due to contin uing system improv ements, Gate wa y is not
responsib le for inaccur ate inf ormation which ma y appear in this ma nual. F or the latest
product updates , consult the Gate way W eb site at www.gateway.com. In no eve nt will
Gatew ay be liab le fo r direct, indirect , special, ex emplary, incidental, or consequenti al
damages resultin g from any def ect or omission i n this manual, e ven i f advised of the
possibility of such damages.

In the interest of con tinued product de velo pment, Gatew a y reserves the right to mak e
improv ements in this man ual and the products it des cribes at any time , without notices or
obligation.

T radem ark Acknowle dgments

1-800-GATE WA Y, Ac tiveCPR, ALR, AnyK e y, blac k- an d- whi t e spot desig n, CrystalS ca n,
Destination, DestiVu, EZ Pad, EZ Point, Field Mouse, Gateway 2000, Gateway Country,
gateway.net, Gateway stylized logo, Perfect Scholar, Solo, TelePath, Vivitron, stylized “G”
design, and “You’ve got a friend in the business” slogan are registered trademarks and
blac k -a nd- whi te spo tte d box logo , GATEWAY, Gateway Astro , Gat e way@Work, Gateway
Connect ed tou ch pa d, Gat e way Conn ect ed m usic play er, Gatewa y C ybe r:)Ware,
Gateway Education:)Ware, Gateway Flex Case, Gateway Gaming:)Ware, Gateway
GoBack, Gateway Gold, Gateway Learning:)Ware, Gateway Magazine, Gateway Micro
Server, Gateway Money:)Ware, Gateway Music:)Ware, Gateway Networking Solutions,
Gateway Online Netw ork (O.N.) solution, Gatew ay Photo:)Ware, Gateway Professional
PCs, Gate w ay Profile, Gat e w ay Solo, gre en sty liz ed GATEWAY, green stylized Gat e w ay
logo, Gateway Teacher:)Ware, Gateway Video:)Ware, HelpSpot, InforManager, Just click
it!, Learn@G atew a y, Kids Back P ac k, SERVE-TO-O RDER, S erver W a tchdog , the Spott ed
G Gate w ay Logo and the Spo tte d G Lo go, SpotShop , Sp ot sho p.com, and Your:)W ar e ar e
trademarks of Gateway, Inc. Intel, Intel Inside logo, and Pentium are registered
trademarks and MMX is a trademark of Intel Corporation. Microsoft, MS, MS-DOS, and
Windows are trademarks or registered trademarks of Microsoft Corporation. All other
product names mentioned herein are used for identification purposes only, and may be
the trademarks or registered trademarks of their respective companies.

7

Appendix : Updating Your Gateway Connected DVD Player Firmware

MAN CONNECT DVD FRMWARE UPD R012/03

8

8509634
