USB Data Card Programmer
user’s
manual
and
installation
guide
© Copyright 2001-2002 Garmin Ltd. or its subsidiaries
Garmin International, Inc.
1200 E 151st Street, Olathe, Kansas 66062 U.S.A.
Tel. 913/397.8200 or 800/800.1020 Fax. 913/397.8282
Garmin (Europe) Ltd.
Unit 5, The Quadrangle, Abbey Park Industrial Estate, Romsey, SO51 9DL U.K.
Tel. 44/1794.519944 Fax.44/1794.519222
Garmin Corporation
No. 68, Jangshu 2nd Road, Shijr, Taipei County, Taiwan
Tel. 886/2.2642.9199 Fax. 886/2.2642.9099
All rights reserved. Except as expressly provided herein, no part of this manual may be reproduced, copied, transmitted, disseminated, downloaded or stored in any storage medium, for any purpose without prior written consent of Garmin. Garmin hereby grants
permission to download a single copy of this manual onto a hard drive or other electronic storage medium to be viewed for personal use,
provided that such electronic or printed copy of this manual contains the complete text of this copyright notice and provided further
that any unauthorized commercial distribution of this manual is strictly prohibited.
Information in this manual is subject to change without notice. Garmin reserves the right to change or improve its products and
to make changes in the content without obligation to notify any person or organization of such changes. Visit the Garmin web site
(www.garmin.com) for current updates and supplemental information concerning the use and operation of this and other Garmin
products.
Garmin® and StreetPilot® are registered trademarks, MapSourceTM is a trademark of Garmin Ltd. or its subsidiaries and may not be
used without the express permission of Garmin. Windows 95, Windows NT, Windows 98, Windows ME, Windows 2000, and Windows
XP are registered trademarks of Microsoft Corporation.
December 2002 Part Number 190-00201-00 Rev. C Printed in Taiwan
FCC Compliance
FCC Compliance
This device complies with Part 15 of the FCC interference limits for Class
B digital devices FOR HOME OR OFFICE USE (“home or offi ce” interference
requirements are more stringent than “outdoor” requirements). Operation of
this device is subject to the following conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
The USB Data Card Programmer does not contain any user-serviceable
parts. Repairs should only be made by an authorized Garmin service center.
Unauthorized repairs or modifi cations could result in permanent damage to
the equipment, and void your warranty and your authority to operate this
device under Part 15 regulations.
Thank you for choosing the Garmin® USB Data Card Programmer
or the Garmin StreetPilot® III with Mini-USB Data Card Programmer.
To get successful results from your new USB Data Card Programmer,
take time to read through this user’s manual in order to fully understand all of the operating procedures.
This manual is organized into three sections:
The Introduction section provides licensing agreement information and a description of the programmer.
The Installation section introduces you to basic features and
procedures for programmer setup.
The Trouble Shooting section contains information for fi nding
solutions to installation and operating problems.
Standard Package Contents (USB Data Card Programmer)
• USB Data Card Programmer
• CD-ROM with USB Device Drivers for Windows 98/ME,
2000, and Garmin MapSourceTM Upgrade Software including
USB Support. (The USB drivers are also on the MapSource
City Navigator CD-ROM or MapSource Setup CD-ROM, if
applicable.)
• User’s Manual
• MapSource User’s Manual Addendum for the USB Data Card
Programmer
Introduction
About This Manual
Minimum System Requirements
IBM-Compatible PC with Pentium processor, 16
Megabytes RAM, CD-ROM drive, Mouse or other
pointing device, 256-color display adapter (24-bit
color recommended) and monitor with 640 x 480
resolution or higher, and up to 20 Megabytes free
hard drive space. A 32 bit operating system such
as Windows 98/ME, Windows 2000, or Windows
XP. Universal Serial Bus port (USB). The USB Data
Card Programmer is not designed to operate with
Windows 95 or Windows NT.
Software Requirements
Existing installation of Garmin MapSource
upgraded to Version 3.04 or later.
i
Introduction
Software License Agreement
THIS SOFTWARE IS OWNED BY GARMIN CORPORATION (“GARMIN”) AND IS PROTECTED UNDER COPYRIGHT LAWS AND INTERNATIONAL
COPYRIGHT TREATIES. THIS SOFTWARE IS LICENSED, NOT SOLD. THIS SOFTWARE IS PROVIDED UNDER THE FOLLOWING LICENSE
WHICH DEFINES WHAT YOU MAY DO WITH THE PRODUCT AND CONTAINS LIMITATIONS ON WARRANTIES AND/OR REMEDIES.
IMPORTANT: CAREFULLY READ THIS LICENSE BEFORE USING THIS PRODUCT. INSTALLING, COPYING, OR OTHERWISE USING THIS PRODUCT INDICATES YOUR ACKNOWLEDGMENT THAT YOU HAVE READ THIS LICENSE AND AGREE TO ITS TERMS. IF YOU DO NOT AGREE,
RETURN THE COMPLETE PRODUCT TO Garmin INTERNATIONAL, INC. CUSTOMER SERVICE, 1200 EAST 151st STREET, OLATHE, KS 66062
WITHIN 10 DAYS OF THE DATE YOU ACQUIRED IT FOR A FULL REFUND.
1. LICENSE: Garmin (“we” or “us”) provides you with storage media containing computer software (the “Program”) which may also include digital cartographic data and ”on-line” or electronic documentation, and printed materials together called (the “Product”) and grants you a limited non-exclusive
license to use the Product in accordance with the terms of this license agreement. The copyright and all other rights to the Product shall remain with us.
You must reproduce any copyright or other notice marked on the Product on all copies you make.
2. YOU MAY: a) install and use one copy of the Product on a single computer or network. This copy is to be used by only a single user at a time. If you
wish to use the Product for more users, you will need an additional license for each user.
b) make one copy of the Product for archival or backup purposes.
c) use a copy of the Product on a home or portable computer if that copy is never loaded at the same time it is loaded on your primary computer.
d) transfer the Product to someone else only if you assign all of your rights under this License, cease all use of the Product, erase or destroy any copy
(including the hard disk copy) made in support of your use of the Product, and ensure that the other person agrees to the terms of this License.
3. YOU MUST NOT: a) make copies of the Product except as expressly permitted in Section 2 of this License.
b) translate, reverse engineer, decompile, or disassemble the Product except to the extent the foregoing restriction is expressly prohibited by applicable
law.
c) rent, lease, loan, sub-license, distribute, assign, or transfer the Product except as set out in Section 2 (d) above.
d) modify the Product or merge all or any part of the Product with another program.
ii
Introduction
Software License Agreement
4. TERM: This License shall continue for as long as you use the Product. However, this License will terminate automatically without notice from Garmin
if you fail to comply with any of its terms or conditions. You must agree, upon terminations, to destroy all copies of the Product. The Limitations of Warranties and Liability set out below shall continue in force even after any termination.
5. LIMITATION OF WARRANTIES AND LIABILITY: THE PRODUCT IS PROVIDED ON AN “AS IS” BASIS WITHOUT ANY WARRANTIES OR
CONDITIONS, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABLE QUALITY, MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE, OR THOSE ARISING BY LAW, STATUTE, USAGE OR TRADE, OR COURSE OF DEALING. THE ENTIRE
RISK AS TO THE RESULTS AND PERFORMANCE OF THE PRODUCT IS ASSUMED BY YOU. NEITHER WE NOR OUR DEALERS OR SUPPLIERS
SHALL HAVE ANY LIABILITY TO YOU OR ANY OTHER PERSON OR, ENTITY FOR ANY INDIRECT, INCIDENTAL, SPECIAL, OR CONSEQUENTIAL
DAMAGES WHATSOEVER, INCLUDING, BUT NOT LIMITED TO, LOSS OF REVENUE OR PROFIT, LOST OR DAMAGED DATA OR OTHER COMMERCIAL OR ECONOMIC LOSS, EVEN IF WE HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, OR THEY ARE FORESEEABLE.
WE ARE ALSO NOT RESPONSIBLE FOR CLAIMS BY A THIRD PARTY. OUR MAXIMUM AGGREGATE LIABILITY SHALL NOT EXCEED THE
AMOUNT PAID BY YOU FOR THE PRODUCT. THE LIMITATIONS IN THIS SECTION SHALL APPLY WHETHER OR NOT THE ALLEGED BREACH
OR DEFAULT IS A BREACH OF FUNDAMENTAL CONDITION OR TERM OF A FUNDAMENTAL BREACH. SOME STATES/COUNTRIES DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, SO THE ABOVE LIMITATION
MAY NOT APPLY TO YOU.
6. RESTRICTED RIGHTS: If this Product is acquired by or for the U.S. Government, then it is provided with Restricted Rights. Use, duplication, or disclosure by the U.S. Government is subject to restrictions as set forth in subparagraphs (c)(1)(ii) of The Rights in Technical Data and Computer Software
clause at DFARS 252.227-7013, or subparagraphs (c)(1) and (2) of the Commercial Computer Software - Restricted Rights at 48 CFR 52.227-19, or
clause 18-52-227-86 (d) of the NASA Supplement to the FAR, as applicable. The contractor/manufacturer is Garmin International, Inc. 1200 E. 151st
Street, Olathe, KS 66062, USA.
7.) EXPORT CONTROLS: You agree not to export or re-export the Product to any country in violation of the export control laws of the United
States of America.
8. GENERAL: This License is the entire agreement between us, superseding any other agreement or discussions, oral or written, and may not be changed
except by a signed agreement. This License shall be governed by and construed in accordance with the laws of the State of Kansas, United States of
America. If any provision of this License is declared by a court of competent jurisdiction to be invalid, illegal, or unenforceable, such a provision shall be
severed from the License and the other provisions shall remain in full force and effect.
iii
Introduction
Features
Garmin Data Cards
The USB Data Card Programmer utilizes
Garmin Data Cards. Available in fi ve sizes:
8 MB Data Card
16 MB Data Card
32 MB Data Card
64 MB Data Card
128 MB Data Card
Check the Garmin web site or see your Garmin dealer for
availability of these data cards.
USB Connector
6 Ft. USB Data Cable
Mini Data Card
Programmer
Data Card Slot
(accepts only Garmin
Data Cards)
Data Card
Programmer
iv
Installation of the USB Programmer and Device Drivers
1. Insert either the USB Data Card Programmer CD-ROM, MapSource
City Navigator CD-ROM, or MapSource Setup CD into your
computer’s CD-ROM drive. It is important you insert the CD
before you plug the USB Programmer into the PC! If the
MapSource program is open, close the program.
2. Connect the USB connector on the end of the Programmer cable
to the USB port on the back of the computer. Most computers
have two USB Ports. Either port should work. The computer does
not need to be turned off when connecting or disconnecting the
Programmer. After connecting the Programmer to your computer
you will need to install the device drivers from the CD-ROM.
3. The computer will recognize the Programmer as a USB (or unknown)
device and open the Add New Hardware Wizard and search for the
device drivers. Click on “Next”. If, for some reason, the Wizard does
not run automatically, click the Start button and select “Settings”
and then “Control Panel”. Double click on the “Add New Hardware”
icon.
4. The next screen will ask you if you want it to search for the best
driver for your device or if you want to display a list to choose
from. Select “Search for the best driver for your device” and click
on “Next”.
5. The next screen will display a list of locations to search for the new
drivers. Select CD-ROM Drive from the list and click on “Next”.
Make certain all other boxes remain unchecked.
6. The Wizard will search for the driver and then display a window
to tell you it is ready to install. Click on “Next”. You may see a
“Copying Files...” screen which tells you the fi le cannot be found.
Choose Root Directory of the CD-ROM drive if not already there,
and to try copying again (example d:\). Click “OK” to continue.
Installation
Connecting the Programmer and
Installing the Device Drivers
USB Connector
Programmer Cable
USB Port
USB (Universal Serial Bus) Port
and USB Connector
,
Use care to insert the USB connector correctly. Do not
force the connection as this may damage the USB port
on your computer or the USB connector on the Programmer.
1
Installation
Installing the Device Drivers
,
The required driver fi les which the USB Data Card
Programmer needs to fi nd on either the USB Data
Card Programmer CD, the City Navigator CD, or the
MapSource Setup CD are:
grmn0200.inf
grmn0200.sys
grmn1200.sys
If these fi les cannot be seen in the root directory on the
CD using Windows Explorer, your View settings may
need to be adjusted.
2
7. When installation is complete a window will display that shows
the device name (Garmin USB Data Card Programmer) and states
the driver installation is fi nished. Click on “Finish”.
8. A fi nal window will appear telling you that operating software for
the Card Programmer is being installed.
9. To make sure the USB Programmer has been successfully installed:
From the Control Panel, click on “System”, then the “Device
Manager” tab, then click the + by “Universal serial bus controller”. You should see “Garmin USB Data Card Programmer” on the
list. Another method would be to open the MapSource program,
click the ‘Save To Device’ icon, then the ‘USB Port’ tab. You should
see “Card Programmer” listed in the “Save Maps To:” window.
If you see a yellow ‘!’ mark in front of the device name, (install)
appears at the end of the Programmer name or the Programmer
appears under “Other Devices” as an unknown device, follow these
alternate steps to install the Programmer:
1. Double-click the My Computer icon from your Desktop. For Windows 98, click “View”, “Folder Options”, then the “View” tab.
For Windows 2000/ME, click “Tools”, “Folder Options”, then the
“View” tab.
2. Make note of the following changes if you wish to change your
View settings back after installing the Programmer. Change the
Hidden Files selection to “Show All Files” or “Show hidden fi les
and folders” and uncheck the “Hide fi le extensions for known
fi le types” or “Hide protected operating system fi les”, then click
“OK”.
3. Be sure the driver CD is inserted and the USB Programmer is
plugged into the PC. Open the Control Panel. For Windows 98,
click on “System”, then the “Device Manager” tab. For Windows
2000/ME, click the “Hardware” tab, then click “Device Manager”.
4. Find and highlight the incorrect Programmer entry on the Device
Manager list, click on “Remove”, then click ‘OK’ to confi rm.
5. Click “Refresh”, then click “Next” to begin searching for the drivers. On the next screen, let Windows search by leaving the bullet
on the “Search for best driver..” option and click “Next”. On the
next screen, check ONLY the “CD-ROM drive” option and click
“Next”.
6. The Wizard will search for the driver and then display a window
to tell you it is ready to install. Click on “Next”. You may see a
“Copying Files...” screen which tells you the fi le cannot be found.
Choose Root Directory of the CD-ROM drive if not already there,
and to try copying again (example d:\). Click “OK” to continue.
7. When installation is complete a window should display that shows
the device name (Garmin USB Data Card Programmer) and states
the driver installation is fi nished. Click on “Finish”.
8. To make sure the USB Programmer has been successfully installed:
From the Control Panel, click on “System”, then the “Device Manager” tab, then click the + by “Universal serial bus controller”.
You should see “Garmin USB Data Card Programmer” on the list.
Another method would be to open the MapSource program, click
the ‘Save To Device’ icon, then the ‘USB Port’ tab. You should see
“Card Programmer” listed in the “Save Maps To:” window.
If the installation is still not successful, try shutting the computer
off for 1 minute, then trying the alternate steps again. A red ‘X’ over
the Programmer icon in Device Manager normally indicates a defective Programmer. If the USB Programmer still will not install, please
contact Garmin Product Support for further assistance.
Windows XP Users: During installation of the USB
Data Card Programmer you will see a message stating:
“The following device has not passed the Windows Logo
testing to verify its compatibility with Windows XP.
Continuing your installation of this software may
impair or destabilize the correct operation of your
system either immediately or in the future. Microsoft
strongly recommends that you stop this installation now
and contact the hardware vendor for software that has
passed Windows Logo testing.”
Garmin engineers have fully tested this product and it is compatible with Windows XP.
Press the ‘Continue Anyways’ button to fi nish
the installation.
Installation
Installing the Device Drivers
,
3
Installation
Installing the MapSource
Software Upgrade
If you are running an early version of MapSource (prior to 3.04),
you may upgrade your version of MapSource at this time using the
driver CD provided with the USB Data Card Programmer.
If you already have a version of MapSource newer than 3.05
(City Navigator, or the MapSource Setup CD), upgrading from the
driver CD is not necessary. You may also visit the Garmin web site to
download the most recent upgrade for MapSource.
To Install the MapSource Software Upgrade including
USB Data Card Programmer Support:
1. Insert the USB Data Card Programmer CD-ROM into your computer’s CD-ROM drive.
2. Click the Start button and select “Run...”
3. Then type in the drive letter of your CD-ROM drive followed by
the MapSource Update fi le name: MSUPDATE.EXE. (For example
d:\msupdate.exe)
4. Press ENTER and follow on-screen instructions.
5. Open MapSource and check the “About” box in the help fi le
to determine that you have successfully installed Version 3.04
or later.
4
To Install a Garmin Data Card:
1. Insert the Data Card (Label up and pin connector end fi rst) into the
card slot in the Programmer (standard USB Programmer pictured
to the right).
Installation
For the Mini-USB Programmer, make sure the Garmin
,
globe logo on the Programmer is facing UP for proper
orientation.
2. Be certain to install the Data Card completely into the slot to be
sure the pin connections have been made.
3. To remove the Data Card, pull directly away from the Programmer
using the extractor handle on the Data Card.
Use care not to remove the Data Card from the Program-
,
mer until data transfer has been completed to avoid possible loss of data.
Disconnecting the Programmer from Your Computer
After the USB Data Card Programmer has been successfully
installed (hardware and software), disconnecting and reconnecting the
Programmer can performed without additional installation steps.
1. Before disconnecting the Programmer, be certain that no data
transfer is in progress.
2. Unplug the USB connector from your computer. You do not need
to turn the computer off before removing or inserting the USB
connector.
Installing a Data Card in the
Programmer
Extractor Handle
Disconnecting the Programmer
from Your Computer
5
Trouble Shooting
Trouble Shooting Guide
Symptom Probable Cause Remedy
Windows does not recognize that the
Programmer has been connected to the
computer.
When preparing to transfer data, a
“No compatible device available.” message
appears.
When preparing to transfer data, a “There
is no data card in the Programmer.” message appears.
“An unrecognized data card is in the
programmer.” message appears when you
attempt to transfer data.
USB Connector is not properly inserted
into the USB port on the computer.
USB Port on your computer is not properly confi gured.
System operating software is not USB
compatible.
Programmer is not connected to USB port.
Card Programmer drivers are not installed.
No Data Card has been inserted in the
Programmer.
The Data Card is not fully inserted into the
Programmer.
The Data Card in the Programmer is
damaged.
MapSource must be updated to be
compatible with the card.
Be certain the Programmer has been
properly connected to your computer.
Consult your computer supplier.
Be certain the computer is operating on
Windows 98/ME/2000 software.
Reconnect the USB Connector to the
computer.
Install drivers.
Insert a Data Card into the Programmer.
Push the Data Card fully
the Programmer. When properly inserted,
the card will protrude approximately 1/2
inch from the slot.
Insert a different card and try again.
Update MapSource software from the
Garmin web site.
into the slot in
6
© Copyright 2001-2002 Garmin Ltd. or its subsidiaries
Garmin International, Inc.
1200 East 151st Street, Olathe, Kansas 66062, U.S.A
Garmin (Europe) Ltd.
Unit 5, The Quadrangle, Abbey Park Industrial Estate, Romsey, SO51 9DL, U.K.
Garmin Corporation
No 68, Jangshu 2nd Road, Shijr, Taipei County, Taiwan
www.garmin.com
Part Number 190-00201-00 Rev. C
Loading...
