IMPORTANT SAFETY NOTICE
o
Proper service and repair is important to the safe, reliable operation of all
Funai Equipment. The service procedures recommended by Funai and
described in this service manual are effective methods of performing
service operations. Some of these service special tools should be used
when and as recommended.
It is important to note that this service manual contains various CAUTIONS
and NOTICES which should be carefully read in order to minimize the risk
of personal injury to service personnel. The possibility exists that improper
service methods may damage the equipment. It also is important to
understand that these CAUTIONS and NOTICES ARE NOT EXHAUSTIVE.
Funai could not possibly know, evaluate and advice the service trade of all
conceivable ways in which service might be done or of the possible
hazardous consequences of each way. Consequently, Funai has not
undertaken any such broad evaluation. Accordingly, a servicer who uses a
service procedure or tool which is not recommended by Funai must first
use all precautions thoroughly so that neither his safety nor the safe
operation of the equipment will be jeopardized by the service method
selected.
The LCD panel is manufactured to provide many years of useful life.
Occasionally a few non active pixels may appear as a tiny spec of col
This is not to be considered a defect in the LCD screen.
Prior to shipment from the factory, our products are strictly inspected for recognized product safety and electrical
codes of the countries in which they are to be sold. However, in order to maintain such compliance, it is equally
important to implement the following precautions when a set is being serviced.
Safety Precautions for LCD TV
Circuit
1. Before returning an instrument to the
customer, always make a safety check of the
entire instrument, including, but not limited to, the
following items:
a. Be sure that no built-in protective devices are
defective and have been defeated during
servicing. (1) Protective shields are provided
on this chassis to protect both the technician
and the customer. Correctly replace all missing
protective shields, including any removed for
servicing convenience. (2) When reinstalling
the chassis and/or other assembly in the
cabinet, be sure to put back in place all
protective devices, including but not limited to,
nonmetallic control knobs, insulating
fishpapers, adjustment and compartment
covers/shields, and isolation resistor/capacitor
networks. Do not operate this instrument or
permit it to be operated without all
protective devices correctly installed and
functioning. Servicers who defeat safety
features or fail to perform safety checks
may be liable for any resulting damage.
b. Be sure that there are no cabinet openings
through which an adult or child might be able to
insert their fingers and contact a hazardous
voltage. Such openings include, but are not
limited to, (1) spacing between the Liquid
Crystal Panel and the cabinet mask, (2)
excessively wide cabinet ventilation slots, and
(3) an improperly fitted and/or incorrectly
secured cabinet back cover.
c. Antenna Cold Check - With the instrument AC
plug removed from any AC source, connect an
electrical jumper across the two AC plug
prongs. Place the instrument AC switch in the
on position. Connect one lead of an ohmmeter
to the AC plug prongs tied together and touch
the other ohmmeter lead in turn to each tuner
antenna input exposed terminal screw and, if
applicable, to the coaxial connector. If the
measured resistance is less than 1.0 megohm
or greater than 5.2 megohm, an abnormality
exists that must be corrected before the
instrument is returned to the customer. Repeat
this test with the instrument AC switch in the off
position.
d. Leakage Current Hot Check - With the
instrument completely reassembled, plug the
AC line cord directly into a 120 V AC outlet. (Do
not use an isolation transformer during this
test.) Use a leakage current tester or a
metering system that complies with American
National Standards Institute (ANSI) C101.1
Leakage Current for Appliances and
Underwriters Laboratories (UL) 1410, (50.7).
With the instrument AC switch first in the on
position and then in the off position, measure
from a known earth ground (metal water pipe,
conduit, etc.) to all exposed metal parts of the
instrument (antennas, handle brackets, metal
cabinet, screw heads, metallic overlays, control
shafts, etc.), especially any exposed metal
parts that offer an electrical return path to the
chassis. Any current measured must not
exceed 0.5 milli-ampere. Reverse the
instrument power cord plug in the outlet and
repeat the test.
READING SHOULD
NOT BE ABOVE 0.5 mA
LEAKAGE
DEVICE
BEING
TESTED
TEST ALL EXPOSED
METAL SURFACES
ALSO TEST WITH
PLUG REVERSED
USING AC
ADAPTER PLUG
AS REQUIRED
ANY MEASUREMENTS NOT WITHIN THE
LIMITS SPECIFIED HEREIN INDICATE A
POTENTIAL SHOCK HAZARD THAT MUST
BE ELIMINATED BEFORE RETURNING THE
INSTRUMENT TO THE CUSTOMER OR
BEFORE CONNECTING THE ANTENNA OR
ACCESSORIES.
2. Read and comply with all caution and safety-
related notes on or inside the receiver cabinet, on
the receiver chassis, or on the Liquid Crystal
Panel.
CURRENT
TESTER
+
EARTH
GROUND
_
2-1LTVN_ISP
Page 6
3. Design Alteration Warning - Do not alter or add
to the mechanical or electrical design of this TV
receiver. Design alterations and additions,
including, but not limited to circuit modifications
and the addition of items such as auxiliary audio
and/or video output connections, might alter the
safety characteristics of this receiver and create a
hazard to the user. Any design alterations or
additions will void the manufacturer's warranty and
may make you, the servicer, responsible for
personal injury or property damage resulting
therefrom.
4. Hot Chassis Warning a. Some TV receiver chassis are electrically
connected directly to one conductor of the AC
power cord and maybe safety-serviced without
an isolation transformer only if the AC power
plug is inserted so that the chassis is
connected to the ground side of the AC power
source. To confirm that the AC power plug is
inserted correctly, with an AC voltmeter,
measure between the chassis and a known
earth ground. If a voltage reading in excess of
1.0 V is obtained, remove and reinsert the AC
power plug in the opposite polarity and again
measure the voltage potential between the
chassis and a known earth ground.
b. Some TV receiver chassis normally have 85V
AC(RMS) between chassis and earth ground
regardless of the AC plug polarity. This chassis
can be safety-serviced only with an isolation
transformer inserted in the power line between
the receiver and the AC power source, for both
personnel and test equipment protection.
c. Some TV receiver chassis have a secondary
ground system in addition to the main chassis
ground. This secondary ground system is not
isolated from the AC power line. The two
ground systems are electrically separated by
insulation material that must not be defeated or
altered.
5. Observe original lead dress. Take extra care to
assure correct lead dress in the following areas: a.
near sharp edges, b. near thermally hot parts-be
sure that leads and components do not touch
thermally hot parts, c. the AC supply, d. high
voltage, and, e. antenna wiring. Always inspect in
all areas for pinched, out of place, or frayed wiring.
Check AC power cord for damage.
6. Components, parts, and/or wiring that appear to
have overheated or are otherwise damaged
should be replaced with components, parts, or
wiring that meet original specifications.
Additionally, determine the cause of overheating
and/or damage and, if necessary, take corrective
action to remove any potential safety hazard.
7. Product Safety Notice - Some electrical and
mechanical parts have special safety-related
characteristics which are often not evident from
visual inspection, nor can the protection they give
necessarily be obtained by replacing them with
components rated for higher voltage, wattage, etc.
Parts that have special safety characteristics are
identified by a # on schematics and in parts lists.
Use of a substitute replacement that does not
have the same safety characteristics as the
recommended replacement part might create
shock, fire, and/or other hazards. The product's
safety is under review continuously and new
instructions are issued whenever appropriate.
Prior to shipment from the factory, our products
are strictly inspected to confirm they comply with
the recognized product safety and electrical codes
of the countries in which they are to be sold.
However, in order to maintain such compliance, it
is equally important to implement the following
precautions when a set is being serviced.
2-2LTVN_ISP
Page 7
Precautions during Servicing
A. Parts identified by the # symbol are critical for
safety.
Replace only with part number specified.
B. In addition to safety, other parts and assemblies
are specified for conformance with regulations
applying to spurious radiation. These must also be
replaced only with specified replacements.
Examples: RF converters, RF cables, noise
blocking capacitors, and noise blocking filters, etc.
C. Use specified internal wiring. Note especially:
1) Wires covered with PVC tubing
2) Double insulated wires
3) High voltage leads
D. Use specified insulating materials for hazardous
live parts. Note especially:
1) Insulation Tape
2) PVC tubing
3) Spacers
4) Insulators for transistors.
E. When replacing AC primary side components
(transformers, power cord, etc.), wrap ends of
wires securely about the terminals before
soldering.
F.Observe that the wires do not contact heat
producing parts (heat sinks, oxide metal film
resistors, fusible resistors, etc.)
G. Check that replaced wires do not contact sharp
edged or pointed parts.
H. When a power cord has been replaced, check that
5~6 kg of force in any direction will not loosen it.
I.Also check areas surrounding repaired locations.
J. Use care that foreign objects (screws, solder
droplets, etc.) do not remain inside the set.
K. When connecting or disconnecting the internal
connectors, first, disconnect the AC plug from the
AC supply outlet.
L. When installing parts or assembling the cabinet
parts, be sure to use the proper screws and
tighten certainly.
2-3LTVN_ISP
Page 8
Safety Check after Servicing
Examine the area surrounding the repaired location for damage or deterioration. Observe that screws, parts and
wires have been returned to original positions. Afterwards, perform the following tests and confirm the specified
values in order to verify compliance with safety standards.
1. Clearance Distance
When replacing primary circuit components, confirm
specified clearance distance (d) and (d') between
soldered terminals, and between terminals and
surrounding metallic parts. (See Fig. 1)
Table 1: Ratings for selected area
Chassis or Secondary Conductor
Primary Circuit
AC Line VoltageRegion
110 to 130 V
Note: This table is unofficial and for reference only. Be
sure to confirm the precise values.
U.S.A. or
Canada
Clearance
Distance (d), (d’)
≥ 3.2 mm
(0.126 inches)
2. Leakage Current Test
Confirm the specified (or lower) leakage current
between B (earth ground, power cord plug prongs) and
externally exposed accessible parts (RF terminals,
antenna terminals, video and audio input and output
terminals, microphone jacks, earphone jacks, etc.) is
lower than or equal to the specified value in the table
below.
Measuring Method: (Power ON)
Insert load Z between B (earth ground, power cord plug
prongs) and exposed accessible parts. Use an AC
voltmeter to measure across both terminals of load Z.
See Fig. 2 and following table.
d'd
Fig. 1
Exposed Accessible Part
Z
AC Voltmeter
(High Impedance)
Earth Ground
B
Power Cord Plug Prongs
Table 2: Leakage current ratings for selected areas
AC Line VoltageRegionLoad ZLeakage Current (i)Earth Ground (B) to:
110 to 130 V
Note: This table is unofficial and for reference only. Be sure to confirm the precise values.
U.S.A. or
Canada
0.15 µF CAP. & 1.5 kΩ
RES. Connected in parallel
2-4LTVN_ISP
i ≤ 0.5 mA rms
Fig. 2
Exposed accessible
parts
Page 9
STANDARD NOTES FOR SERVICING
Circuit Board Indications
1. The output pin of the 3 pin Regulator ICs is
indicated as shown.
Top View
Out
2. For other ICs, pin 1 and every fifth pin are
indicated as shown.
Pin 1
3. The 1st pin of every male connector is indicated as
shown.
Pin 1
Input
In
Bottom View
5
10
Pb (Lead) Free Solder
Pb free mark will be found on PCBs which use Pb
free solder. (Refer to figure.) For PCBs with Pb free
mark, be sure to use Pb free solder. For PCBs
without Pb free mark, use standard solder.
Pb free mark
How to Remove / Install Flat Pack-IC
1. Removal
With Hot-Air Flat Pack-IC Desoldering Machine:
1. Prepare the hot-air flat pack-IC desoldering
machine, then apply hot air to the Flat Pack-IC
(about 5 to 6 seconds). (Fig. S-1-1)
Fig. S-1-1
2. Remove the flat pack-IC with tweezers while
applying the hot air.
3. Bottom of the flat pack-IC is fixed with glue to the
CBA; when removing entire flat pack-IC, first apply
soldering iron to center of the flat pack-IC and heat
up. Then remove (glue will be melted). (Fig. S-1-6)
4. Release the flat pack-IC from the CBA using
tweezers. (Fig. S-1-6)
CAUTION:
1. The Flat Pack-IC shape may differ by models. Use
an appropriate hot-air flat pack-IC desoldering
machine, whose shape matches that of the Flat
Pack-IC.
2. Do not supply hot air to the chip parts around the
flat pack-IC for over 6 seconds because damage
to the chip parts may occur. Put masking tape
around the flat pack-IC to protect other parts from
damage. (Fig. S-1-2)
3-1TVN_SN
Page 10
3. The flat pack-IC on the CBA is affixed with glue, so
be careful not to break or damage the foil of each
pin or the solder lands under the IC when
removing it.
With Soldering Iron:
1. Using desoldering braid, remove the solder from
all pins of the flat pack-IC. When you use solder
flux which is applied to all pins of the flat pack-IC,
you can remove it easily. (Fig. S-1-3)
CBA
Masking
Tape
Tweezers
Hot-air
Flat Pack-IC
Desoldering
Machine
Flat Pack-IC
Fig. S-1-2
Flat Pack-IC
Desoldering Braid
Soldering Iron
Fig. S-1-3
2. Lift each lead of the flat pack-IC upward one by
one, using a sharp pin or wire to which solder will
not adhere (iron wire). When heating the pins, use
a fine tip soldering iron or a hot air desoldering
machine. (Fig. S-1-4)
Sharp
Pin
Fine Tip
Soldering Iron
Fig. S-1-4
3. Bottom of the flat pack-IC is fixed with glue to the
CBA; when removing entire flat pack-IC, first apply
soldering iron to center of the flat pack-IC and heat
up. Then remove (glue will be melted). (Fig. S-1-6)
4. Release the flat pack-IC from the CBA using
tweezers. (Fig. S-1-6)
3-2TVN_SN
Page 11
With Iron Wire:
1. Using desoldering braid, remove the solder from
all pins of the flat pack-IC. When you use solder
flux which is applied to all pins of the flat pack-IC,
you can remove it easily. (Fig. S-1-3)
2. Affix the wire to a workbench or solid mounting
point, as shown in Fig. S-1-5.
3. While heating the pins using a fine tip soldering
iron or hot air blower, pull up the wire as the solder
melts so as to lift the IC leads from the CBA
contact pads as shown in Fig. S-1-5.
4. Bottom of the flat pack-IC is fixed with glue to the
CBA; when removing entire flat pack-IC, first apply
soldering iron to center of the flat pack-IC and heat
up. Then remove (glue will be melted). (Fig. S-1-6)
5. Release the flat pack-IC from the CBA using
tweezers. (Fig. S-1-6)
Note: When using a soldering iron, care must be
taken to ensure that the flat pack-IC is not
being held by glue. When the flat pack-IC is
removed from the CBA, handle it gently
because it may be damaged if force is applied.
Hot Air Blower
2. Installation
1. Using desoldering braid, remove the solder from
the foil of each pin of the flat pack-IC on the CBA
so you can install a replacement flat pack-IC more
easily.
2. The “●” mark on the flat pack-IC indicates pin 1.
(See Fig. S-1-7.) Be sure this mark matches the
pin 1 on the PCB when positioning for installation.
Then presolder the four corners of the flat pack-IC.
(See Fig. S-1-8.)
3. Solder all pins of the flat pack-IC. Be sure that
none of the pins have solder bridges.
Example :
Pin 1 of the Flat Pack-IC
is indicated by a " " mark.
Fig. S-1-7
To Solid
Mounting Point
CBA
Tweezers
Iron Wire
Soldering Iron
Fig. S-1-5
Fine Tip
Soldering Iron
Flat Pack-IC
or
Presolder
Flat Pack-IC
CBA
Fig. S-1-8
Fig. S-1-6
3-3TVN_SN
Page 12
Instructions for Handling Semiconductors
Electrostatic breakdown of the semi-conductors may
occur due to a potential difference caused by
electrostatic charge during unpacking or repair work.
1. Ground for Human Body
Be sure to wear a grounding band (1 MΩ) that is
properly grounded to remove any static electricity that
may be charged on the body.
2. Ground for Workbench
Be sure to place a conductive sheet or copper plate
with proper grounding (1 MΩ) on the workbench or
other surface, where the semi-conductors are to be
placed. Because the static electricity charge on
clothing will not escape through the body grounding
band, be careful to avoid contacting semi-conductors
with your clothing.
<Incorrect>
<Correct>
1MΩ
CBA
Grounding Band
1MΩ
CBA
Conductive Sheet or
Copper Plate
3-4TVN_SN
Page 13
CABINET DISASSEMBLY INSTRUCTIONS
[LC427SSX (Serial No. : DS1A**********),
42MF439B/F7 (Serial No. : DS1A**********)]
1. Disassembly Flowchart
This flowchart indicates the disassembly steps for the
cabinet parts, and the CBA in order to gain access to
item(s) to be serviced. When reassembling, follow the
steps in reverse order. Bend, route and dress the
cables as they were.
(1) Order of steps in procedure. When reassembling,
follow the steps in reverse order. These numbers
are also used as the Identification (location) No. of
parts in figures.
4-1A91H1DC
Page 14
(2) Parts to be removed or installed.
(3) Fig. No. showing procedure of part location
(4) Identification of parts to be removed, unhooked,
unlocked, released, unplugged, unclamped, or
desoldered.
P = Spring, L = Locking Tab, S = Screw,
H = Hex Screw, CN = Connector
* = Unhook, Unlock, Release, Unplug, or Desolder
e.g. 2(S-2) = two Screws (S-2),
2(L-2) = two Locking Tabs (L-2)
(5) Refer to the following "Reference Notes in the
Ta bl e ."
(S-2)
[2] Rear Cabinet
(S-2)
[1] Stand Assembly
(S-1)
(S-3)
(S-2)
(S-5)
(S-4)
(S-2)
Fig. D1
4-2A91H1DC
Page 15
[6] Jack Power CBA
[7] Inverter
Power CBA
(S-11)
(S-10)
(S-11)
(S-8)
(S-10)
(S-9)
[5] Jack Holder(A)
[4] Digital Main
CBA Unit
Shield Box
[3] Jack Holder(D)
(S-6)
(S-7)
Fig. D2
4-3A91H1DC
Page 16
[11] Stand Bracket
(S-15)
(S-17)
[9] PCB Holder
[8] Wall Mount Bracket
(S-15)
(S-12)
(S-18)
(S-16)
(S-18)
(S-16)
(S-17)
[10] AC Inlet Holder
(S-13)
(S-14)
Fig. D3
4-4A91H1DC
Page 17
[17] Front Cabinet
[15] Function CBA
[16] IR Sensor
CBA
(S-21)
Speaker Box [F]
(S-21)
[14] Junction
CBA
[13] Speaker
(S-20)
[13] Speaker
Speaker Box [F]
(S-20)
(S-19)
[12] LCD Module
Assembly
(S-19)
Fig. D4
4-5A91H1DC
Page 18
TV Cable Wiring Diagram
Inverter Power CBA
CN1803
CN1804
To LCD Module
Assembly
Jack Power CBA
Function
CBA
CN1601
To AC Inlet
CN1801
CN1501
To Speaker
CN901
CN601
CN801
CN802
CN203CN202 CN201
CN3702 CN3701
CN3901
WH1301B
IR Sensor CBA
Digital Main CBA Unit
To LCD Module
Assembly
Junction
CBA
WH1302BWH1301ACN1302WH1302A
Fig. D5
4-6A91H1DC
Page 19
CABINET DISASSEMBLY INSTRUCTIONS
[LC427SSX (Serial No. : YA2A**********),
42MF439B/F7 (Serial No. : YA2A**********)]
1. Disassembly Flowchart
This flowchart indicates the disassembly steps for the
cabinet parts, and the CBA in order to gain access to
item(s) to be serviced. When reassembling, follow the
steps in reverse order. Bend, route and dress the
cables as they were.
(1) Order of steps in procedure. When reassembling,
follow the steps in reverse order. These numbers
are also used as the Identification (location) No. of
parts in figures.
(2) Parts to be removed or installed.
(3) Fig. No. showing procedure of part location
(4) Identification of parts to be removed, unhooked,
unlocked, released, unplugged, unclamped, or
desoldered.
P = Spring, L = Locking Tab, S = Screw,
H = Hex Screw, CN = Connector
* = Unhook, Unlock, Release, Unplug, or Desolder
e.g. 2(S-2) = two Screws (S-2),
2(L-2) = two Locking Tabs (L-2)
(5) Refer to the following "Reference Notes in the
Ta bl e ."
(S-3)
[4] Rear Cabinet
Assembly
(S-3)
[1] Stand Base Assembly
(S-5)
(S-4)
(S-3)
(S-2a)
[2] Stand Hinge
[3] Stand Sub Cover
(S-2b)
(S-3)
(S-1)
Fig. D1
4-8A91H6DC
Page 21
[8] Jack Power CBA
[9] Inverter
Power CBA
(S-11)
(S-10)
(S-11)
(S-8)
(S-10)
(S-9)
[7] Jack Holder(A)
[6] Digital Main
CBA Unit
Shield Box
[5] Jack Holder(D)
(S-6)
(S-7)
Fig. D2
4-9A91H6DC
Page 22
[13] Stand Bracket
(S-15)
(S-17)
[11] PCB Holder
[10] Wall Mount Bracket
(S-15)
(S-12)
(S-18)
(S-16)
(S-18)
(S-16)
(S-17)
[12] AC Inlet Holder
(S-13)
(S-14)
Fig. D3
4-10A91H6DC
Page 23
[19] Front Cabinet Assembly
[17] Function CBA
[18] IR Sensor
CBA
(S-21)
Speaker Box [F]
(S-21)
[16] Junction
CBA
[15] Speaker
(S-20)
[15] Speaker
Speaker Box [F]
(S-20)
(S-19)
[14] LCD Module
Assembly
(S-19)
Fig. D4
4-11A91H6DC
Page 24
TV Cable Wiring Diagram
Inverter Power CBA
CN1803
CN1804
To LCD Module
Assembly
Jack Power CBA
Function
CBA
CN1601
To AC Inlet
CN1801
CN1501
To Speaker
CN901
CN601
CN801
CN802
CN203CN202 CN201
CN3702 CN3701
CN3901
WH1301B
IR Sensor CBA
Digital Main CBA Unit
To LCD Module
Assembly
Junction
CBA
WH1302BWH1301ACN1302WH1302A
Fig. D5
4-12A91H6DC
Page 25
ELECTRICAL ADJUSTMENT INSTRUCTIONS
General Note: “CBA” is abbreviation for
“Circuit Board Assembly.”
Note: Electrical adjustments are required after
replacing circuit components and certain
mechanical parts. It is important to perform
these adjustments only after all repairs and
replacements have been completed.
Also, do not attempt these adjustments unless
the proper equipment is available.
Test Equipment Required
1. NTSC Pattern Generator (Color Bar W/White
Window, Red Color, Dot Pattern, Gray Scale,
Monoscope, Multi-Burst)
2. Remote control unit
3. Color Analyzer
How to make the Service remote
control unit:
[ LC427SSX ]
Cut “A” portion of the attached remote control unit as
shown in Fig. 1.
How to set up the service mode:
Service mode:
1. Use the service remote control unit.
2. Turn the power on.
3. Press the service button on the service remote
control unit. The following screen appears.
"*" differs depending on the models.
Code :
***********-***
Pic code :
**-***-**-*****-***
MIPS :
Push 0key
Tuner :
****-*****-****
safety_Non
Safety :
service button
A
Fig. 1
[ 42MF439B/F7 ]
Cut “A” portion of the attached remote control unit as
shown in Fig. 2.
service button
(There is a button under the plastic housing.)
A
Fig. 2
5-1FL9.2EA
Page 26
1. Purity Check Mode
2. VCOM Adjustment
This mode cycles through full-screen displays of red,
green, blue, and white to check for non-active pixels.
1. Enter the Service mode.
2. Each time pressing [7] button on the service
remote control unit, the display changes as
follows.
Purity Check Mode
White mode
[7] button
[7] button
Black mode
[7] button
Red mode
[7] button
Green mode
[7] button
Blue mode
Test PointAdj. Point
Screen
[CHANNEL UP/DOWN ]
buttons
M. EQ.Spec.
Color analyzerSee below
Figure
To avoid interference from ambinent
light, this adjustment should be
performed in a dark room.
Perpendicularity
L = 3 cm
Color Analyzer
1. Operate the unit for more than 20 minutes.
2. Set the color analyzer and bring the optical
receptor to the center on the LCD-Panel surface
after zero point calibration as shown above.
Note: The optical receptor must be set
perpendicularly to the LCD Panel surface.
3. Enter the Service mode.
4. Press [3] button on the service remote control unit.
5. Press [CHANNEL UP/DOWN] buttons on the
service remote control unit so that the color
analyzer value becomes minimum.
[7] button
White 20% mode
Note:
When entering this mode, the default setting is White mode.
5-2LC7NEA
Page 27
The white balance adjustment should be
performed when replacing the LCD Panel
or Digital CBA.
3. White Balance Adjustment
Purpose: To mix red, green and blue beams correctly
for pure white.
Symptom of Misadjustment: White becomes bluish
or reddish.
Test Point
Screen
Adj. PointModeInput
[VOLUME
DOWN]
button
[VIDEO1]
C/D
M. EQ.Spec.
White Raster
(APL 70%)
or
(APL 40%)
5. [CUTOFF]
Press [1] button to select “COR” for Red Cutoff
adjustment. Press [3] button to select “COB” for
Blue Cutoff adjustment.
[DRIVE]
Press [4] button to select “DR” for Red Drive
adjustment. Press [6] button to select “DB” for Blue
Drive adjustment.
6. In each color mode, press [CHANNEL UP/DOWN]
buttons to adjust the values of color.
7. Adjust Cutoff and Drive so that the color
temperature becomes 12000°K (x
=
0.272 / y
=
0.278 ±0.005).
Pattern Generator,
Color analyzer
x= 0.272 ± 0.005
y= 0.278 ± 0.005
Figure
To avoid interference from ambinent
light, this adjustment should be
performed in a dark room.
Perpendicularity
L = 3 cm
INPUT: WHITE 70%, 40%
Color Analyzer
1. Operate the unit for more than 20 minutes.
2. Input the White Raster(70%=70IRE, 40%=40IRE).
INPUT SIGNAL
0IRE0IRE
Low
Hight
Light
Light
100IRE
40%=40IRE
70%=70IRE
3. Set the color analyzer to the CHROMA mode and
bring the optical receptor to the center on the
LCD-Panel surface after zero point calibration as
shown above.
Note: The optical receptor must be set
perpendicularly to the LCD Panel surface.
4. Enter the Service mode. Press [VOLUME DOWN]
button on the service remote control unit and select
“C/D” mode.
100IRE
5-3LC7NEA
Page 28
HOW TO INITIALIZE THE LCD TV
The purpose of initialization is to place the set in a new out of box condition. The customer will be prompted to
select a language and program channels after the set has been initialized.
To put the program back at the factory-default, initialize the LCD TV using the following procedure.
1. Turn the power on.
2. To enter the service mode, press the service
button on the service remote control unit.
- To cancel the service mode, press [POWER]
button on the service remote control unit.
3. Press [INFO] button on the service remote control
unit to initialize the LCD television.
4. "INITIALIZED" will appear in the upper right of the
screen. "INITIALIZED" color will change to green
from red when initializing is complete.
6-1A91F3INT
Page 29
FIRMWARE RENEWAL MODE
Equipment Required
a. USB memory
b. Remote Control Unit
Firmware Update Procedure
Note: There are two states (the User Upgrade and
the Factory Upgrade) in firmware update.
User UpgradeUpgrade the firmware only.
The setting values are not
initialized.
Factory upgradeUpgrade the firmware and
initialize the setting values.
The identification of User Upgrade and Factory
Upgrade are done by the filename.
1. Turn the power off and unplug the AC Cord.
2. Insert the USB memory to the USB port as shown
below.
USB port
USB Memory
The appearance shown in *1 is described as follows.
AppearanceState
Downloading...
Writing...
Downloading the firmware from
the USB memory.
Writing the downloaded firmware
in flash memory.
Checking...Checking the new firmware.
5. When the firmware update is completed, the
following will appear on the screen.
Software Upgrade
The software upgrade is completed.
Remove USB storage device, unplug and replug power code.
Unplug the AC cord and kindly remove the USB
memory from the USB port. Plug the AC cord in
the wall outlet again and turn the power on.
Note:
When the Factory Upgrade is used, after
restarting TV, shift to initial screen menu in service
mode. "INITIALIZED" will appear on the upper
right of the screen. "INITIALIZED" color will
change to green from red when initializing is
complete.
Rear Cabinet
3. Plug the AC cord in the wall outlet and turn the
power on.
4. The update will start and the following will appear
on the screen.
Software Upgrade
Software upgrade in progress. Please wait.
Do not remove the USB device or turn the TV off
while upgrade is in progress.
*1
Downloading...
0%
Note: If the above screen isn’t displayed, repeat from
step 1.
7-1A91H1FW
Page 30
[ Power Supply Section ]
( Inverter Power CBA )
FLOW CHART NO.1
The power cannot be turned on.
TROUBLESHOOTING
Is the fuse (F1601) normal?
Ye s
Is normal state restored when once un
power cord is plugged again several seconds?
Ye s
Is the AL+5V line voltage normal?
Ye s
Is the PANEL+24V line voltage normal?
Ye s
Check each rectifying circuit of the secondary
circuit and service it if defective.
FLOW CHART NO.2
The fuse blows out.
Check the presence that the primary component
is leaking or shorted and service it if defective.
plugged
No
No
No
No
See FLOW CHART No.2 <The fuse blows out.>
Check if there is any leak or short-circuiting on the
primary circuit component, and service it if defective.
(D1205, D1206, D1207, D1208, Q1203, Q1204,
T1201)
Check if there is any leak or short-circuiting on the
primary circuit component, and service it if defective.
(D1601, IC1401, IC1702, Q1601, Q1602, Q1701,
Q1702, T1701)
Check the presence that the rectifying diode or circuit
is shorted in each rectifying circuit of secondar
and service it if defective.
y side,
After servicing, replace the fuse.
FLOW CHART NO.3
When the output voltage fluctuates.
Does the photocoupler circuit on the
secondary side operate normally?
Ye s
Check D1210, IC1202, IC1702, IC1704 and their
periphery, circuit and service it if defective.
FLOW CHART NO.4
When buzz sound can be heard in the vicinity of power circuit.
Check if there is any short-circuit on the rectifying diode and the circ
and service it if defective. (D1101, D1714, D1715, Q1101)
No
Check D1213, D1720, IC1202, IC1704 and their
periphery circuit, and service it if defective.
uit in each rectifying circuit of the secondary side,
8-1A91H1TR
Page 31
FLOW CHART NO.5
AL+5V is not output.
Is approximately +5V voltage supplied to the
cathode of D1101?
Ye s
Check if there is any leak or short-circuit on the loaded
circuit, and service it if defective.
FLOW CHART NO.6
AL+3.3V is not output.
Is approximately +5V voltage supplied to the collector
of Q1101?
Ye s
Is approximately +4V voltage supplied to the base
of Q1101?
Ye s
Replace Q1101.
( Jack Power CBA )
FLOW CHART NO.7
When the output voltage fluctuates.
No
No
No
Check C1103, D1101, D1102 and their periphery
circuit, and service it if defective.
Check C1103, D1101, D1102 and their periphery
circuit, and service it if defective.
Check D1109 and their periphery circuit, and
service it if defective.
Does the photocoupler circuit on the
secondary side operate normally?
Ye s
Check D607, IC601 and their per
service it if defective.
FLOW CHART NO.8
When buzz sound can be heard in the vicinity of power circuit.
Check if there is any short-circuit on the rectifying diode and the circuit
and service it if defective. (D613, D615, D617, D618, D620, D621, D622, D623, D624, IC602, Q603, Q604, Q605)
FLOW CHART NO.9
TUNER+31V is not output.
Is approximately +40V voltage supplied to the
cathode of D618?
Check D632, R640 and their periphery circuit, and
service it if defective.
iphery, circuit and
Ye s
No
No
Check D616, D637, IC601 and their periphery
circuit, and service it if defective.
in each rectifying circuit of the secondary side,
Check C617, D618, D619 and their periphery
circuit, and service it if defective.
8-2A91H1TR
Page 32
FLOW CHART NO.10
P-ON+8.2V is not output.
Is approximately +16.5V voltage supplied to the
collector of Q603?
Ye s
Is approximately +9V voltage supplied to the
base of Q603?
Ye s
Replace Q603.
FLOW CHART NO.11
P-ON+5V is not output.
Is approximately +6V voltage supplied to the
collector of Q604?
Ye s
Is approximately +6V voltage supplied to the
base of Q604?
Ye s
Replace Q604.
No
No
No
No
Check C622, C624, D617, D624 and their periphery
circuit, and service it if defective.
Check D627, D628 and their periphery circuit, and
service it if defective.
Check C619, D620 and their per
iphery circuit,
and service it if defective.
Check D638 and their periphery circuit, and service
it if defective.
FLOW CHART NO.12
P-ON+3.3V is not output.
Is approximately +5V voltage supplied to the
collector of Q605?
Ye s
Is approximately +4V voltage supplied to the
base of Q605?
Ye s
Replace Q605.
No
No
Check C621, D623 and their periphery circuit, and
service it if defective.
Check D631 and their periphery circuit, and service
it if defective.
8-3A91H1TR
Page 33
[ Video Signal Section ]
FLOW CHART NO.1
The key operation is not functioning.
Are the contact point and installation state of the key
switches (SW1351~SW1355, SW1357) nor
Ye s
When pressing each switches (SW1351~SW1355,
SW1357) do the voltage of Pin(3) of CN202 increase?
Ye s
Replace Digital Main CBA Unit.
FLOW CHART NO.2
No operation is possible from the remote control unit.
Operation is possible from the remote control unit.
Is 3.3V voltage supplied to Pin(2) terminal of the
remote control receiver (RS1301)?
Ye s
Is the "L" pulse sent out Pin(1) terminal of remote
control receiver (RS1301) when the infrared remote
control is activated?
Ye s
Is the "L" pulse supplied to Pin(1) of CN202?
Ye s
Replace Digital Main CBA Unit.
mal?
No
No
No
No
No
Re-install the switches (SW1351~SW1355, SW1357)
correctly or replace the poor switch.
Check the switches (SW1351~SW1355, SW1357)
and their periphery, and service it if defective.
Check AL+3.3V line and service it if defective.
Replace the remote control receiver(RS1301)
or the remote control unit.
Check the line between Pin(1) terminal of remote
control receiver(RS1301) and Pin(1) of CN202,
and service it if defective.
8-4A91H1TR
Page 34
FLOW CHART NO.3
Picture does not appear normally. (EXT. input)
Are the video signals inputted to each pin of IC401?Check the line between video input terminal and
Check SP801,SP802 and their periphery circuit,
and service it if defective.
Are the audio(L/R) signals outputted to Pin(4, 6) of
CN202?
Ye s
Are the audio(L/R) signals inputted to Pin(3, 5)
of IC803?
Ye s
Are the audio(L/R) signals outputted to Pin(1, 7)
of IC803?
Ye s
Check the line between Pin(1, 7) of IC803 and audio
output terminal(JK722, JK723) and service it if defective.
No
No
No
Replace Digital Main CBA Unit or LCD Module
Assembly.
Check the line between Pin(4, 6) of CN202 and
Pin(3, 5) of IC803, and service it if defective.
Replace IC803
8-6A91H1TR
Page 36
FLOW CHART NO.2
Picture does not appear normally. (Tuner input)
Are the DIF signal inputted to Pin(3, 4) of CN201?
Yes
(Output to audio
Ye s
(Output to speakers)
output terminal)
Are the audio(L/R) signals outputted to Pin(8, 10) of
CN202?
Ye s
Are the audio(L/R) signals inputted to Pin(1, 44)
of IC801?
Ye s
Are the audio(L/R) signals outputted to CN801 and
CN802?
Ye s
Check SP801,SP802 and their periphery circuit,
and service it if defective.
No
Check the line between Pin(3, 4) of CN201 and
Pin(12, 13) of TU101, and service it if defective.
No
Replace Digital Main CBA Unit or LCD Module
Assembly.
Check the line between Pin(8, 10) of CN202 and
No
Pin(1, 44) of IC801, and service it if defective.
No
Check IC801 and their periphery circuit, and
service it if defective.
Are the audio(L/R) signals outputted to Pin(4, 6) of
CN202?
Ye s
Are the audio(L/R) signals inputted to Pin(3, 5)
of IC803?
Ye s
Are the audio(L/R) signals outputted to Pin(1, 7)
of IC803?
Ye s
Check the line between Pin(1, 7) of IC803 and audio
output terminal(JK722, JK723) and service it if defective.
Replace Digital Main CBA Unit or LCD Module
No
Assembly.
No
Check the line between Pin(4, 6) of CN202 and
Pin(3, 5) of IC803, and service it if defective.
No
Replace IC803
8-7A91H1TR
Page 37
BLOCK DIAGRAMS
System Control Block Diagram
AL+3.3V
POWER
D1302
WH1301A
KEY-IN166
LED144
KEY-IN133
IR SENSOR CBAFUNCTION CBA
REMOTE
RS1301
STANDBY
D1301
SENSOR
WH1302B
REMOTE22
P-ON-H155
TO
P-ON-H2
P-ON-H1
CN1801
POWER
SUPPLY 1
PROTECT3
BLOCK
BACKLIGHT-SW
3
DIAGRAM
BACKLIGHT-ADJ
4
INVERTER POWER CBA
5
WH1302A
JUNCTION
CBA
CN1302
REMOTE27
P-ON-H154
KEY-IN163
CN203
WH1301B
KEY SWITCH
LED145
CN202CN3702
LED122
REMOTE11
KEY-IN133
TO
PROTECT1
P-ON-H139
P-ON-H248
PROTECT3
BACKLIGHT-SW
BACKLIGHT-ADJ
9
7
8
CN901
POWER SUPPLY 2
BLOCK DIAGRAM
CN201CN3701
7
10
PROTECT1
P-ON-H266
10
25
23
P-ON-H188
PROTECT3
BACKLIGHT-SW
BACKLIGHT-ADJ
7
25
23
SCL
SDA
TU101 (TUNER UNIT)
9
8
28
27
SCL
SDA
28
27
CN3702CN202
JACK POWER CBA
F1
R22
AC5
LED1
KEY-IN1
REMOTE
IC3301
(MAIN MICRO CONTROLLER)
AUDIO-MUTE
AB9
AUDIO-MUTE
TO AUDIO
BLOCK
DIAGRAM
PROTECT1 AD5
R23
AB13
P-ON-H2
P-ON-H1
9-1
AE5
AB16
PROTECT3
BACKLIGHT-SW
AB23
BACKLIGHT-ADJ
AC18
SCL
AC19
SDA
SCK
SIN
SOUTCSWP
AB24
SI
E11
AC25
AC24
1
3
CS
SO
WP
AB25
652
SCK
IC3101 (MEMORY)
X3102
CLKOUT
CLKIN
N1
N2
25MHz
OSC
DIGITAL MAIN CBA UNIT
A91H1BLS
Page 38
Video Block Diagram
TO DIGITAL
SIGNAL
PROCESS
BLOCK
AUDIO SIGNAL
DIAGRAM
TO DIGITAL
SIGNAL
PROCESS
BLOCK
DIAGRAM
VIDEO SIGNAL
DIGITAL MAIN CBA UNIT
Pb-IN
CVBS/Y/S-Y-IN
CVBS/Y/S-Y-IN1818
CN202CN3702
383634
Pr/S-C-IN
Pb-IN2020
Pr/S-C-IN2222
WF1WF2WF3
IF-AGC
DIF-OUT1
DIF-OUT2
IF-AGC11
DIF-OUT244
DIF-OUT133
CN201CN3701
IC401
(INPUT SELECTOR)
JACK POWER CBA
VIDEO
SELECTOR
3
1
5
7
9
11414345475052
JK703
VIDEO-IN1
CY
JK702
S-VIDEO
-IN1
JK707
VIDEO-IN2
CY
JK706
S-VIDEO
-IN2
S-VIDEO-SW1
S-VIDEO-SW2
51
49
WITH TWO COMPONENT INPUT
JK714
JK715
COMPONENT
-Y-IN1
JK716
COMPONENT
-Pb-IN1
COMPONENT
-Pr-IN1
JK717
JK718
COMPONENT
-Y-IN2
JK719
COMPONENT
-Pb-IN2
COMPONENT
-Pr-IN2
12
DIF-OUT1
TU101
(TUNER UNIT)
13
14
IF-AGC
DIF-OUT2
9-2A91H1BLV
Page 39
Audio Block Diagram
TO
DIGITAL
SIGNAL
PROCESS
BLOCK
DIAGRAM
TO
SYSTEM
CONTROL
BLOCK
DIAGRAM
TO
DIGITAL
SIGNAL
PROCESS
BLOCK
DIAGRAM
AUDIO SIGNAL
DIGITAL MAIN CBA UNIT
WF4
AUDIO(L)
CN3702CN202
AUDIO(L)2424
AUDIO(R)
AUDIO(R)2626
AUDIO-MUTE
IC3501
(AUDIO DSP)
IC3503
(AUDIO D/A CONVERTER)
BCLK
LRCLK
35
8
(L-CH)
CN202CN3702
ACLK
ADATA0
ADATA1
4402
39
DSP
373433
36
567
D/A
CONVERTER
(R-CH)
15
14
44
66
88
AUDIO(L)-OUT
AUDIO(R)-OUT
AMP(L)-OUT
3
8
IC3502
(AUDIO D/A CONVERTER)
1010
AMP(R)-OUT
D/A
(L-CH)
(R-CH)
15
567
CONVERTER
14
1313
SPDIF
CN202CN3702
SPDIF
1111
AUDIO-MUTE
(INPUT SELECTOR)
IC401
JACK POWER CBA
JK704
14
AUDIO(L)-IN1
JK705
16
18
AUDIO(R)-IN1
20
24
JK708
28
AUDIO
AUDIO(L)-IN2
JK709
SELECTOR
151719
AUDIO(R)-IN2
27
21
COMPONENT
AUDIO(L)-IN1
JK710
JK711
25
WITH TWO COMPONENT INPUT
COMPONENT
AUDIO(R)-IN1
COMPONENT
JK712
AUDIO(L)-IN2
COMPONENT
JK713
AUDIO(R)-IN2
JK720
HDMI
AUDIO(L)-IN
JK721
HDMI
IC803
(OP AMP)
AUDIO(R)-IN
5
7
JK722
AUDIO(L)-OUT
3
1
MUTE
Q703
JK723
AUDIO(R)-OUT
DRIVE
Q802,Q804
MUTE
Q704
JK701
DIGITAL
BUFFER
Q702
AUDIO-OUT
(COAXIAL)
1
DRIVE1PWM1
IC801 (AUDIO POWER AMP)
9,10
13,14
CN801
CL801
1
2
SP(L)-
SP(L)+
SP801
SPEAKER
L-CH
44
DRIVE2PWM2
35,36
31,32
Q801
20
MUTE CONTROL
1
2
CN802
SP(R)-
SP(R)+
CL802
SP802
SPEAKER
R-CH
9-3
A91H1BLA
Page 40
Digital Signal Process Block Diagram
LCD MODULE
ASSEMBLY
AUDIO SIGNAL
VIDEO SIGNAL
IC3301 (DIGITAL SIGNAL PROCESS)
LVDS-D0E(+)23
LVDS-D1E(+)21
LVDS-D1E(-)22
LVDS-D0E(-)24
LVDS-D2E(+)19
LVDS-D2E(-)20
LVDS-D3E(+)13
LVDS-D3E(-)14
LVDS-D0O(+)39
LVDS-D0O(-)40
LVDS-D1O(+)37
LVDS-CE(-)17
AE24
LVD S
M2
AF18
TX
AD9
AE18
AD12
AD17
AUDIO I/F
AD10
LVDS-D1O(-)38
AD18
AD11
LVDS-CE(+)16
CN3901
AF23
AE23
AD23
AD24
A/D
CONVERTER
DEMODULATOR
V3
/MPEG DECODER
AF2
AE2
SW
V1
V2
AA3
U2
U1
U3
AF22
IF-AGC
AF7
AE22
AD21
AD22
AF24
M1
LVDS-D2O(+)35
AE17
AC10
LVDS-D2O(-)36
AF17
AD14
LVDS-D3O(+)29
AF16
LVDS-D3O(-)30
AE16
LVDS-CO(+)32
AE19
LVDS-CO(-)33
AF19
AUDIO
DECODER
D1
DIGITAL
D2
SIGNAL
PROCESS
C1
C2
HDMI
IC3201
DATA(0-15)
H1,H3,H7,H9
B1,B9,C2,C8,
F1,F9,G2,G8,
M2,M3,M7,M8,
D1,D3,D7,D9,
A13-15,A18,
A21-23,B13-15,
B17,B19-23
C15,C17-19,
ADDESS(0-12)
N2,N3,N7,N8,
P2,P3,P7,P8,R2
C23,C24,D14,
D15,D17-19,
D22,D23
(DDR2 SDRAM)
VIDEO
DECODER
I/F
B1
B2
A1
A2
Pr/S-C-IN
TO VIDEO
BLOCK DIAGRAM
DIF-OUT1
CVBS/Y/S-Y-IN
Pb-IN
DIGITAL MAIN CBA UNIT
DIF-OUT2
IF-AGC
AUDIO(R)
AUDIO(L)
ACLK
BCLK
LRCLK
TO AUDIO
BLOCK DIAGRAM
IC3801 (HDMI SW)
222124232625201943
DATA0(+)
DATA0(-)
DATA1(+)
DATA1(-)
DATA2(+)
79461
JK3803
SPDIF
CLOCK(+)
DATA2(-)
3
101216
HDMI-IN1
ADATA1
ADATA0
CLOCK(-)
HDMI-DATA
9-4
44
DATA0(+)
HDMI-CLOCK
15
56575859606162
HDMI
SW
14131615181712
DATA0(-)
DATA1(+)
DATA1(-)
DATA2(+)
DATA2(-)
79461
3
HDMI-IN2
JK3801
CLOCK(+)
113940
HDMI-DATA
CLOCK(-)
101216
63
HDMI-CLOCK
15
DATA0(+)
686770697271666529
DATA0(-)
DATA1(+)
DATA1(-)
DATA2(+)
DATA2(-)
HDMI-DATA
CLOCK(+)
79461
3
HDMI-IN3
JK3802
CLOCK(-)
101216
30
HDMI-CLOCK
15
A91H1BLD
Page 41
Power Supply 1 Block Diagram
AL+3.3V
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
+3.3V REG.
Q1101
Q1202
Q1201
LCD MODULE
ASSEMBLY
PANEL+24V
1-5
CN1804
PANEL+24V
1-5
CN1803
PROTECT311BACKLIGHT-ADJ13BACKLIGHT-SW
14
BACKLIGHT-SW
BACKLIGHT-ADJ
TO SYSTEM CONTROL
BLOCK DIAGRAM
P-ON-H1
PROTECT3
P-ON-H2
9
8
10
T1201
4
For continued protection against risk of fire,
replace only with same type 4 A, 125V fuse.
CAUTION ! :
ATTENTION : Utiliser un fusible de rechange de même type de 4A, 125V.
BRIDGE
RECTIFIER
4A/125V
D1205-D1208
7
6
Q1203
INVERTER POWER CBA
1
2
SWITCHING
IC1202
(FEED BACK)
11
L1604
2
14
32
SWITCHING
Q1204
8
5
SWITCHING
Q1602
14
14
IC1705
(ISOLATOR)
COLD
Q1705
32
Q1404
Q1708
32
3
14
IC1705
(ISOLATOR)
Q1703
14
Q1707
32
Q1704
RL1201
CONTROL
8
11
L1603
2
5
SWITCHING
Q1601
11
1091112131415
T1701
8
7
SWITCHING
Q1701
9
534
8
SWITCHING
Q1702
12
2
5
16
1
IC1704
14
(FEED BACK)
4
13
LINE
FILTER
L1601
BRIDGE
RECTIFIER
F1601
8A/250V
HOT CIRCUIT. BE CAREFUL.
CN1601
HOT-GND2
ACL1
AC
INLET
CAUTION !
Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F1601) is blown , check to see that all components in the power supply
circuit are not defective before you connect the AC plug to the AC power supply.
Otherwise it may cause some components in the power supply circuit to fail.
AC601
AC CORD
D1601
L1602
LINE
FILTER
SWITCHING
CONTROL
IC1401
(SWITCHING CONTROL)
7
11612
IC1702
(HIGH-VOLTAGE
RESONANT CONTROL)
VCC
8
CN1501
+354V 1
HOT+22V 4
TO POWER
SUPPLY 2
BLOCK
DIAGRAM
CN601
HIGH-
VOLTAGE
RESONANT
CONTROL
HOT
Q1402
Q1401
9- 5A91H1BLP1
Q1403
Page 42
Power Supply 2 Block Diagram
AL+13V
P-ON+8.2V
P-ON+11V
TUNER+31V
P-ON+5V
P-ON+3.3V
LCD+12V
P-ON+3V
P-ON+7V
P-ON+5V
P-ON+3.3V
TO SYSTEM
CONTROL
BLOCK
DIAGRAM
Q603
SW+8.2V
DIGITAL MAIN CBA UNIT
CN201CN3701
15,16P-ON+3V15,16
27-29
LCD+12V27-29
18
P-ON+7V18
14
P-ON+5V14
SW+5V
Q604
21,22
P-ON+3.3V21,22
PROTECT1
SW+3.3V
Q605
9
10
2
T601
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
HOT CIRCUIT. BE CAREFUL.
3
16
CN601
TO
POWER
+345V1
SUPPLY 1
BLOCK
HOT-GND2
DIAGRAM
11
HOT+22V3
CN1501
14
15
13
128
14
(FEED BACK)
4
6
7
IC601
32
HOTCOLD
CONTROL
Q602
SWITCHING
JACK POWER CBA
SWITCHING
Q601
9-6
A91H1BLP2
Page 43
SCHEMATIC DIAGRAMS / CBA AND TEST POINTS
Standard Notes
WARNING
Many electrical and mechanical parts in this chassis
have special characteristics. These characteristics
often pass unnoticed and the protection afforded by
them cannot necessarily be obtained by using
replacement components rated for higher voltage,
wattage, etc. Replacement parts that have these
special safety characteristics are identified in this
manual and its supplements; electrical components
having such features are identified by the mark “#” in
the schematic diagram and the parts list. Before
replacing any of these components, read the parts list
in this manual carefully. The use of substitute
replacement parts that do not have the same safety
characteristics as specified in the parts list may create
shock, fire, or other hazards.
Notes:
1. Do not use the part number shown on these
drawings for ordering. The correct part number is
shown in the parts list, and may be slightly
different or amended since these drawings were
prepared.
2. All resistance values are indicated in ohms
(K = 10
3. Resistor wattages are 1/4W or 1/6W unless
otherwise specified.
4. All capacitance values are indicated in µF
(P = 10
5. All voltages are DC voltages unless otherwise
specified.
6. This schematic diagrams are masterized version
that should cover the entire FL9.2 chassis models.
Thus some parts in detail illustrated on this
schematic diagrams may vary depend on the
model within the FL9.2 chassis.
Please refer to the parts lists for each models.
7. The Circuit Board layout illustrated on this service
manual is the latest version for this chassis at the
moment of making this service manual.
Depend on the mass production date of each
model, the actual layout of each Board may differ
slightly from this version.
3
, M = 106).
-6
µF).
10-1FL9_2SC
Page 44
LIST OF CAUTION, NOTES, AND SYMBOLS USED IN THE SCHEMATIC DIAGRAMS ON
r
THE FOLLOWING PAGES:
1. CAUTION:
CAUTION: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH SAME
TYPE_A,_V FUSE.
ATTENTION: UTILISER UN FUSIBLE DE RECHANGE DE MÊME TYPE DE_A,_V.
2. CAUTION:
Fixed Voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F1601) is blown, first check to see that all components in the power supply circuit are not
defective before you connect the AC plug to the AC power supply. Otherwise it may cause some components
in the power supply circuit to fail.
3. Note:
1. Do not use the part number shown on the drawings for ordering. The correct part number is shown in the
parts list, and may be slightly different or amended since the drawings were prepared.
2. To maintain original function and reliability of repaired units, use only original replacement parts which are
listed with their part numbers in the parts list section of the service manual.
4. Voltage indications on the schematics are as shown below:
Plug the TV power cord into a standard AC outlet.:
2
(Unit: Volt)
1
5.05.0
3
Power on mode
5. How to read converged lines
1-D3
Distinction Area
Line Number
(1 to 3 digits)
Examples:
1. "1-D3" means that line number "1" goes to the line numbe
"1" of the area "D3".
2. "1-B1" means that line number "1" goes to the line number
"1" of the area "B1".
6. Test Point Information
: Indicates a test point with a jumper wire across a hole in the PCB.
: Used to indicate a test point with a component lead on foil side.
: Used to indicate a test point with no test pin.
: Used to indicate a test point with a test pin.
Voltage
Indicates that the voltage
is not consistent here.
3
2
1
AREA D3
1-B1
AREA B1
1-D3
ABCD
10-2FL9_2SC
Page 45
10-3
A91H1SCJP1
Jack Power 1/3 Schematic Diagram
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
Page 46
10-4
A91H1SCJP2
Jack Power 2/3 Schematic Diagram
Page 47
10-5
A91H1SCJP3
Jack Power 3/3 Schematic Diagram
Page 48
10-6
A91H1SCIP1
Inverter Power 1/3 Schematic Diagram
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
CAUTION !
Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F1601) is blown , check to see that all components in the power supply
circuit are not defective before you connect the AC plug to the AC power supply.
Otherwise it may cause some components in the power supply circuit to fail.
For continued protection against risk of fire,
replace only with same type 8A, 250V fuse.
CAUTION ! :
ATTENTION : Utiliser un fusible de rechange de même type de 8A, 250V.
8A 250V
Page 49
10-7
A91H1SCIP2
Inverter Power 2/3 Schematic Diagram
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
Page 50
10-8
A91H1SCIP3
Inverter Power 3/3 Schematic Diagram
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
Page 51
10-9
A91H1SCIR
IR Sensor & Junction Schematic Diagram
Page 52
10-10
A91H1SCF
Function Schematic Diagram
Page 53
10-11
A91H1SCD1
Digital Main 1/5 Schematic Diagram
The order of pins shown in this diagram is different from that of actual IC3301.
IC3301 is divided into five and shown as IC3301 (1/5) ~ IC3301 (5/5) in this Digital Main Schematic Diagram Section.
1 NOTE:
Page 54
10-12
A91H1SCD2
Digital Main 2/5 Schematic Diagram
The order of pins shown in this diagram is different from that of actual IC3301.
IC3301 is divided into five and shown as IC3301 (1/5) ~ IC3301 (5/5) in this Digital Main Schematic Diagram Section.
1 NOTE:
Page 55
10-13
Digital Main 3/5 Schematic Diagram
A91H1SCD3
The order of pins shown in this diagram is different from that of actual IC3301.
IC3301 is divided into five and shown as IC3301 (1/5) ~ IC3301 (5/5) in this Digital Main Schematic Diagram Section.
1 NOTE:
Page 56
10-14
Digital Main 4/5 Schematic Diagram
A91H1SCD4
The order of pins shown in this diagram is different from that of actual IC3301.
IC3301 is divided into five and shown as IC3301 (1/5) ~ IC3301 (5/5) in this Digital Main Schematic Diagram Section.
1 NOTE:
Page 57
10-15
Digital Main 5/5 Schematic Diagram
A91H1SCD5
The order of pins shown in this diagram is different from that of actual IC3301.
IC3301 is divided into five and shown as IC3301 (1/5) ~ IC3301 (5/5) in this Digital Main Schematic Diagram Section.
1 NOTE:
Page 58
10-16
BA94H0F01012-A
Jack Power CBA Top View
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
Because a hot chassis ground is present in the power
supply circuit, an isolation transformer must be used.
Also, in order to have the ability to increase the input
slowly,when troubleshooting this type power supply
circuit, a variable isolation transformer is required.
Page 59
10-17
PIN 24 OF
CN202
WF4
PIN 22 OF
CN202
WF3
PIN 20 OF
CN202
WF2
PIN 18 OF
CN202
WF1
BA94H0F01012-A
Jack Power CBA Bottom View
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
Because a hot chassis ground is present in the power
supply circuit, an isolation transformer must be used.
Also, in order to have the ability to increase the input
slowly,when troubleshooting this type power supply
circuit, a variable isolation transformer is required.
Page 60
10-18
BA94H0F01032-A
Inverter Power CBA Top View
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
Because a hot chassis ground is present in the power
supply circuit, an isolation transformer must be used.
Also, in order to have the ability to increase the input
slowly,when troubleshooting this type power supply
circuit, a variable isolation transformer is required.
CAUTION !
Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F1601) is blown , check to see that all components in the power supply
circuit are not defective before you connect the AC plug to the AC power supply.
Otherwise it may cause some components in the power supply circuit to fail.
For continued protection against risk of fire,
replace only with same type 8A, 250V fuse.
CAUTION ! :
ATTENTION : Utiliser un fusible de rechange de même type de 8A, 250V.
8A 250V
Page 61
10-19
BA94H0F01032-A
Inverter Power CBA Bottom View
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
Because a hot chassis ground is present in the power
supply circuit, an isolation transformer must be used.
Also, in order to have the ability to increase the input
slowly,when troubleshooting this type power supply
circuit, a variable isolation transformer is required.
CAUTION !
Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F1601) is blown , check to see that all components in the power supply
circuit are not defective before you connect the AC plug to the AC power supply.
Otherwise it may cause some components in the power supply circuit to fail.
For continued protection against risk of fire,
replace only with same type 8A, 250V fuse.
CAUTION ! :
ATTENTION : Utiliser un fusible de rechange de même type de 8A, 250V.
8A 250V
Page 62
10-20
BA94H0F01032-BBA94H0F01012-D
Function CBA Top View
Function CBA Bottom View
Junction CBA
Top View
Junction CBA
Bottom View
BA94H0F01032-C
IR Sensor CBA Top View
IR Sensor CBA Bottom View
Page 63
WAVEFORMS
CVBS
0.2V
S-VIDEO-Y
0.2V
S-VIDEO-C
0.2V
AUDIO
1V
0.5m
COMPONENT-Pr
0.2V
ms
COMPONENT-Pb
0.2V
COMPONENT-Y
0.2V
WF1 ~ WF4 = Waveforms to be observed at
Waveform check points.
(Shown in Schematic Diagram.)
Input: NTSC Color Bar Signal (with 1kHz Audio Signal)
26 NU
27 NU
28 NU
29 LVDS-D30(+)
30 LVDS-D30(-)
31 GND
32 LVDS-C0(+)
33 LVDS-C0(-)
34 GND
35 LVDS-D20(+)
36 LVDS-D20(-)
37 LVDS-D10(+)
38 LVDS-D10(-)
39 LVDS-D00(+)
40 LVDS-D00(-)
41 NU
42 NU
43 GND
44 P-ON+3.3V
45 NU
46 NU
47 NU
48 NU
49 NU
50 NU
51 NU
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
S2STYROFOAM TOP A94H0UH1EM023865
S3STYROFOAM BOTTOM A94H0UH1EM023866
S4SET BAG A91H2UH1EM325897
S5SERIAL NO. LABEL TD812HC---------S6STAND BAG A91H2UH1EM428517
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
S2STYROFOAM TOP A94H0UH1EM023865
S3STYROFOAM BOTTOM A94H0UH1EM023866
S4SET BAG A91H2UH1EM325897
S5SERIAL NO. LABEL TD812HC---------S6STAND BAG A91H2UH1EM428517
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
C108CHIP CERAMIC CAP.(1608) CH J 47pF/50VCHD1JJ3CH470
C109CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C110ELECTROLYTIC CAP. 1000µF/6.3V MCE0KMASDL102
C111CHIP CERAMIC CAP. CH J 220pF/50VCHD1JJ3CH221
C201CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C202CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C203CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C204CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C205CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C206ELECTROLYTIC CAP. 220µF/6.3V MCE0KMASDL221
C401CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C402ELECTROLYTIC CAP. 47µF/25V MCE1EMASDL470
C403ELECTROLYTIC CAP. 10µF/50V M H7CE1JMAVSL100
C404CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C405CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C406CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C407CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C410CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C411CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C412ELECTROLYTIC CAP. 100µF/16V MCE1CMASDL101
C413ELECTROLYTIC CAP. 100µF/10V MCE1AMASDL101
C503CHIP CERAMIC CAP. F Z 0.01µF/50VCHD1JZ30F103
C601METALIZED FILM CAP. 0.0033µF/1.6KV JCT3C332F7004
C602CAP ELECTROLYTIC 100µF/400V/M/22/25CA2H101DYG17
A91H0MJC-001
Ref. No.DescriptionPart No.
C603POLYESTER FILM CAP. (PB FREE) 0.047µF/
C604CERAMIC CAP. RB 100pF/2KVCA3D101TE006
C605POLYESTER FILM CAP. (PB FREE) 0.001µF/
C606POLYESTER FILM CAP. (PB FREE) 0.1µF/100V JCA2A104DT018
C607POLYESTER FILM CAP. (PB FREE) 0.0022µF/
C610#SAFTY CAP. 2200pF/250V KXCA2E222MR101
C612POLYESTER FILM CAP. (PB FREE) 0.0022µF/
C614ELECTROLYTIC CAP 3300µF/25V MCE1EMZNDL332
C615ELECTROLYTIC CAP 3300µF/25V MCE1EMZNDL332
C617ELECTROLYTIC CAP. 220µF/50V MCE1JMASDL221
C618ELECTROLYTIC CAP. 4700µF/10V M P=7.5CE1AMZNDL472
C619ELECTROLYTIC CAP. 1000µF/10V MCE1AMASDL102
C620CAP ALUMINUM ELECTOLYTIC 2200µF/6.3V MCE0KMZNDL222
C621ELECTROLYTIC CAP. 1000µF/10V MCE1AMASDL102
C622ELECTROLYTIC CAP. 470µF/25V MCE1EMASDL471
C623CAP CERAMIC (AX) 0.01µF/50V/B/KCA1J103TU061
C624ELECTROLYTIC CAP. 470µF/25V MCE1EMASDL471
C625ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C626ELECTROLYTIC CAP. 100µF/16V MCE1CMASDL101
C628ELECTROLYTIC CAP. 1000µF/10V MCE1AMASDL102
C629ELECTROLYTIC CAP 3300µF/6.3V MCE0KMZNDL332
C630CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C631ELECTROLYTIC CAP. 1µF/50V MCE1JMASDL1R0
C633ELECTROLYTIC CAP. 330µF/50V MCE1JMZNDL331
C634CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C635ELECTROLYTIC CAP. 100µF/10V MCE1AMASDL101
C636CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C637CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C638CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C639CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C640CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C641CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C642CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C643CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C644CHIP CERAMIC CAP.(1608) B K 5600pF/50VCHD1JK30B562
C645CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C646CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C648CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C701CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C703CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C704ELECTROLYTIC CAP. 10µF/50V M H7CE1JMAVSL100
C705CHIP CERAMIC CAP.(1608) B K 0.01µF/50VCHD1JK30B103
C706CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C707CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C708CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C709CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C711CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C713CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C714CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C715CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C716CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C717CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C721CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C722CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C723CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C731CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C733CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C740CHIP CERAMIC CAP. CH J 39pF/50VCHD1JJ3CH390
C741CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C742CHIP CERAMIC CAP. CH J 39pF/50VCHD1JJ3CH390
C743CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C744CHIP CERAMIC CAP. CH J 39pF/50VCHD1JJ3CH390
C745CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C746CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C747CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C750CHIP CERAMIC CAP.(1608) B K 3300pF/50VCHD1JK30B332
C751CHIP CERAMIC CAP.(1608) B K 3300pF/50VCHD1JK30B332
C752CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C801CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C802CHIP CERAMIC CAP.(1608) B K 0.01µF/50VCHD1JK30B103
C803CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C804CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C805CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C806CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C807CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C808CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C809CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C810CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C811CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C812CHIP CERAMIC CAP.(1608) B K 0.47µF/16VCHD1CK30B474
C813ELECTROLYTIC CAP. 470µF/25V MCE1EMASDL471
C816CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C817ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C818CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C819CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C820ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C821CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C822CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C823CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C824ELECTROLYTIC CAP. 470µF/25V MCE1EMASDL471
C825CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C826CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C830CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C832CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C833CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C835CHIP CERAMIC CAP.(1608) CH J 270pF/50VCHD1JJ3CH271
C836ELECTROLYTIC CAP. 100µF/16V M H7CE1CMAVSL101
C837CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C839ELECTROLYTIC CAP. 4.7µF/50V M H7CE1JMAVSL4R7
C840ELECTROLYTIC CAP. 4.7µF/50V M H7CE1JMAVSL4R7
C841CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C843ELECTROLYTIC CAP. 100µF/25V MCE1EMASDL101
C847CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C848CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C849CHIP CERAMIC CAP.(1608) B K 0.47µF/16VCHD1CK30B474
C851ELECTROLYTIC CAP. 3.3µF/50V MCE1JMASDL3R3
C852CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C853CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C854CHIP CERAMIC CAP. B K 470pF/50VCHD1JK30B471
C855CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
Ref. No.DescriptionPart No.
C856CHIP CERAMIC CAP. B K 470pF/50VCHD1JK30B471
C863ELECTROLYTIC CAP. 47µF/25V MCE1EMASDL470
C864ELECTROLYTIC CAP. 47µF/25V MCE1EMASDL470
C865CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C866CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C867CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C868CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C869CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
R401CHIP RES.(1608) 1/10W 0 ΩRRXAZR5Z0000
R402CHIP RES.(1608) 1/10W 0 ΩRRXAZR5Z0000
R403CHIP RES. 1/10W J 100 ΩRRXAJR5Z0101
R404CHIP RES. 1/10W J 100 ΩRRXAJR5Z0101
R405RES CARBON FILM T 1/4W J 33k ΩRCX4333T1001
R406CHIP RES. 1/10W J 33k ΩRRXAJR5Z0333
R407RES CARBON FILM T 1/4W J 33k ΩRCX4333T1001
R503CHIP RES.(1608) 1/10W 0 ΩRRXAZR5Z0000
R504RES CARBON FILM T 1/4W J 10k ΩRCX4103T1001
R505CHIP RES. 1/10W J 1k ΩRRXAJR5Z0102
R506CHIP RES.(1608) 1/10W 0 ΩRRXAZR5Z0000
R507CHIP RES. 1/10W J 2.2k ΩRRXAJR5Z0222
R508CHIP RES. 1/10W J 3.3k ΩRRXAJR5Z0332
R511CHIP RES. 1/10W J 33k ΩRRXAJR5Z0333
R512CHIP RES. 1/10W J 3.3k ΩRRXAJR5Z0332
R513CHIP RES.(1608) 1/10W 0 ΩRRXAZR5Z0000
R601METAL OXIDE FILM RES. 2W J 100k ΩRN02104ZU001
R602METAL OXIDE FILM RES. 2W J 100k ΩRN02104ZU001
R603RES CARBON FILM T 1/4W J 470k ΩRCX4474T1001
R604RES CARBON FILM T 1/4W J 470k ΩRCX4474T1001
R605RES CARBON FILM T 1/4W J 470k ΩRCX4474T1001
R606RES CARBON FILM T 1/4W J 470k ΩRCX4474T1001
R607RES CARBON FILM T 1/4W J 120 ΩRCX4121T1001
R608RES CARBON FILM T 1/4W J 120 ΩRCX4121T1001
R610WIRE COPPER 6111-06003-0120XZ40C0SHG002
R611RES CARBON FILM T 1/4W J 2.2k ΩRCX4222T1001
R612RES CARBON FILM T 1/4W J 1.2k ΩRCX4122T1001
R613RES CARBON FILM T 1/4W J 390 ΩRCX4391T1001
R614METAL OXIDE FILM RES. 2W J 1 ΩRN021R0ZU001
R615RES CARBON FILM T 1/4W J 150 ΩRCX4151T1001
R617WIRE COPPER 6111-06003-0120XZ40C0SHG002
R618RES CARBON FILM T 1/4W J 330 ΩRCX4331T1001
R619RES CARBON FILM T 1/4W G 1.2k ΩRCX4122T1002
R620RES CARBON FILM T 1/4W G 10k ΩRCX4103T1002
R621RES CARBON FILM T 1/4W J 4.7k ΩRCX4472T1001
R622RES CARBON FILM T 1/4W G 2.7k ΩRCX4272T1002
R624RES CARBON FILM T 1/4W J 220 ΩRCX4221T1001
R625WIRE COPPER 6111-06003-0120XZ40C0SHG002
R626RES CARBON FILM T 1/4W J 1.2k ΩRCX4122T1001
R627RES CARBON FILM T 1/4W J 220 ΩRCX4221T1001
R628METAL OXIDE FILM RES. 2W J 0.27 ΩRN02R27ZU001
R630RES CARBON FILM T 1/4W J 22 ΩRCX4220T1001
R631METAL RESISTER. 2W J 0.56 ΩRN02R56ZU001
R632CHIP RES. 1/10W F 10k ΩRRXAFR5H1002
R633RES CARBON FILM T 1/4W J 68 ΩRCX4680T1001
R634RES CARBON FILM T 1/4W J 10 ΩRCX4100T1001
R635CHIP RES. 1/10W F 3.6k ΩRRXAFR5H3601
R636METAL RESISTER. 2W J 0.56 ΩRN02R56ZU001
R638WIRE COPPER 6111-06003-0120XZ40C0SHG002
R639WIRE COPPER 6111-06003-0120XZ40C0SHG002
R640RES. CARBON FILM J 1/2W J 820 ΩRCX2821T1003
R641RES CARBON FILM T 1/4W J 4.7k ΩRCX4472T1001
R642RES CARBON FILM T 1/4W J 220 ΩRCX4221T1001
R643RES CARBON FILM T 1/4W J 220 ΩRCX4221T1001
R644RES CHIP.(1608) 1/10W D 10k ΩRRXADR5H1002
R645RES CHIP.(1608) 1/10W D 10k ΩRRXADR5H1002
R646RES CHIP.(1608) 1/10W D 1.1k ΩRRXADR5H1101
R647RES CARBON FILM T 1/4W J 390 ΩRCX4391T1001
R648CHIP RES. 1/10W J 8.2k ΩRRXAJR5Z0822
R649RES CARBON FILM T 1/4W G 15k ΩRCX4153T1002
R650CHIP RES. 1/10W F 5.1k ΩRRXAFR5H5101
R651METAL OXIDE FILM RES 2W J 330 ΩRN02331ZU001
R652METAL OXIDE FILM RES 2W J 330 ΩRN02331ZU001
2009030515-3A91H1EL
Page 76
Ref. No.DescriptionPart No.
R653METAL OXIDE FILM RES 2W J 330 ΩRN02331ZU001
R654RES CARBON FILM T 1/4W J 560 ΩRCX4561T1001
R655CHIP RES. 1/10W J 10 ΩRRXAJR5Z0100
R656CHIP RES. 1/10W J 10 ΩRRXAJR5Z0100
R657METAL OXIDE FILM RES 2W J 330 ΩRN02331ZU001
R658CHIP RES. 1/10W F 270 ΩRRXAFR5H2700
R701CHIP RES. 1/10W J 10k ΩRRXAJR5Z0103
R702CHIP RES. 1/10W J 10k ΩRRXAJR5Z0103
R704CHIP RES. 1/10W J 220 ΩRRXAJR5Z0221
R705CHIP RES. 1/10W J 110 ΩRRXAJR5Z0111
C1416CAP CERAMIC (AX) CH 22pF/50VCA1J220TU059
C1601# CAP METALIZED FILM 0.22µF/300V K 3.5MM CT2F224DC004
C1602# CAP METALIZED FILM 1.0µF/300V K 3.5MMCT2F105DC004
C1603# SAFTY CAP. 1000pF/250V KXCA2E102MR101
C1604# SAFTY CAP. 1000pF/250V KXCA2E102MR101
C1607CAP METALIZED FILM J1.0µF/630V/J/MPEFCA2K105DT048
C1610# CAP METALIZED FILM 0.22µF/300V K 3.5MM CT2F224DC004
R1103RES CARBON FILM T 1/4W J 10 ΩRCX4100T1001
R1104CHIP RES. 1/10W J 270 ΩRRXAJR5Z0271
R1105RES CARBON FILM T 1/4W G 6.8k ΩRCX4682T1002
R1106RES CARBON FILM T 1/4W G 27k ΩRCX4273T1002
R1107CHIP RES. 1/10W F 3.3k ΩRRXAFR5H3301
R1108CHIP RES. 1/10W F 10k ΩRRXAFR5H1002
Ref. No.DescriptionPart No.
R1109RES CARBON FILM T 1/4W J 22 ΩRCX4220T1001
R1206CHIP RES. 1/10W J 470 ΩRRXAJR5Z0471
R1207CHIP RES. 1/10W J 3.3k ΩRRXAJR5Z0332
R1208RES CARBON FILM T 1/4W J 560 ΩRCX4561T1001
R1209RES CARBON FILM T 1/4W J 33k ΩRCX4333T1001
R1210CHIP RES. 1/10W J 220k ΩRRXAJR5Z0224
R1211CHIP RES. 1/10W F 1.0k ΩRRXAFR5H1001
R1212CHIP RES. 1/10W F 4.3k ΩRRXAFR5H4301
R1213CHIP RES. 1/10W F 4.7k ΩRRXAFR5H4701
R1214WIRE COPPER 6111-06003-0120XZ40C0SHG002
R1215RES CARBON FILM T 1/4W J 100 ΩRCX4101T1001
R1216RES CARBON FILM T 1/4W J 1.0k ΩRCX4102T1001
R1217RES CARBON FILM T 1/4W J 820k ΩRCX4824T1001
R1218RES CARBON FILM T 1/4W J 820k ΩRCX4824T1001
R1219RES CARBON FILM T 1/4W J 820k ΩRCX4824T1001
R1220RES CARBON FILM T 1/4W J 330 ΩRCX4331T1001
R1221RES CARBON FILM T 1/4W J 470k ΩRCX4474T1001
R1222RES CARBON FILM T 1/4W J 1.8k ΩRCX4182T1001
R1223RES CARBON FILM T 1/4W J 1.0k ΩRCX4102T1001
R1224RES. CARBON FILM J 1/2W J 3.9 ΩRCX23R9T1003
R1225RES CARBON FILM T 1/4W J 18k ΩRCX4183T1001
R1226RES CARBON FILM T 1/4W J 4.7k ΩRCX4472T1001
R1227RES CARBON FILM T 1/4W J 10k ΩRCX4103T1001
R1228METAL OXIDE FILM RES. 2W J 1 ΩRN021R0ZU001
R1229METAL OXIDE FILM RES. 2W J 56 ΩRN02560ZU001
R1401RES MATALIZED FILM 1/4W F 825k ΩRDC8253HH001
R1402RES MATALIZED FILM 1/4W F 825k ΩRDC8253HH001
R1403RES MATALIZED FILM 1/4W F 619k ΩRDC6193HH001
R1404RES MATALIZED FILM 1/4W F 619k ΩRDC6193HH001
R1405RES METALIZED FILM T 1/4W F 51.1k ΩRDC5112HH003
R1406METAL FILM RES. 1/4W F 121k ΩRDC1213HH001
R1407RES METALIZED FILM T 1/4W F 2.74k ΩRDC2741HH003
R1409RES METALIZED FILM T 1/4W F 5.62k ΩRDC5621HH003
R1410RES CARBON FILM T 1/4W J 470 ΩRCX4471T1001
R1411RES CARBON FILM T 1/4W J 3.3k ΩRCX4332T1001
R1412RES CARBON FILM T 1/4W J 10k ΩRCX4103T1001
R1413RES CARBON FILM T 1/4W J 4.7k ΩRCX4472T1001
R1415RES CARBON FILM T 1/4W J 4.7k ΩRCX4472T1001
R1416RES CARBON FILM T 1/4W J 39k ΩRCX4393T1001
R1417METAL FILM RES. 1/4W F 100k ΩRDC1003HH001
R1418METAL FILM RES. 1/4W F 100k ΩRDC1003HH001
R1419METAL FILM RES. 1/4W F 100k ΩRDC1003HH001
R1420RES METALIZED FILM T 1/4W F 26.7k ΩRDC2672HH003
R1421WIRE COPPER 6111-06003-0120XZ40C0SHG002
R1422METAL FILM RES. 1/4W F 100k ΩRDC1003HH001
R1423RES CARBON FILM T 1/4W J 220k ΩRCX4224T1001
R1424RES CARBON FILM T 1/4W J 100 ΩRCX4101T1001
R1425RES MATALIZED FILM 1/4W F 825k ΩRDC8253HH001
R1426RES MATALIZED FILM 1/4W F 825k ΩRDC8253HH001
R1427RES MATALIZED FILM 1/4W F 619k ΩRDC6193HH001
R1428RES MATALIZED FILM 1/4W F 619k ΩRDC6193HH001
R1429RES METALIZED FILM T 1/4W F 21.0k ΩRDC2102HH003
R1430RES METALIZED FILM T 1/4W F 21.0k ΩRDC2102HH003
R1431RES MATALIZED FILM 1/4W F 825k ΩRDC8253HH001
R1432RES MATALIZED FILM 1/4W F 825k ΩRDC8253HH001
R1433RES MATALIZED FILM 1/4W F 619k ΩRDC6193HH001
R1434RES MATALIZED FILM 1/4W F 619k ΩRDC6193HH001
R1435RES METALIZED FILM T 1/4W F 33.2k ΩRDC3322HH003
R1436RES CARBON FILM T 1/4W J 4.7k ΩRCX4472T1001
R1437RES CARBON FILM T 1/4W J 470 ΩRCX4471T1001
R1438RES CARBON FILM T 1/4W J 3.3k ΩRCX4332T1001
R1439RES CARBON FILM T 1/4W J 2.2k ΩRCX4222T1001
R1440WIRE COPPER 6111-06003-0120XZ40C0SHG002
2009030515-6A91H1EL
Page 79
Ref. No.DescriptionPart No.
R1441WIRE COPPER 6111-06003-0120XZ40C0SHG002
R1601# GLASS GLAZE RES. 1/2W J 1M ΩRXX2JZLZ0105
R1602# GLASS GLAZE RES. 1/2W J 8.2M ΩRXX2JZLZ0825
R1603RES CARBON FILM T 1/4W J 20k ΩRCX4203T1001
R1604RES CEMENT 5W J 0.015 ΩRW05L15PAK24
R1605RES CARBON FILM T 1/4W J 4.7 ΩRCX44R7T1001
R1606RES CARBON FILM T 1/4W J 4.7 ΩRCX44R7T1001
R1607RES CARBON FILM T 1/4W J 20k ΩRCX4203T1001
R1608GLASS GLAZE RES. 1/2W J 1M ΩRXX2JZLZ0105
R1701RES CARBON FILM T 1/4W J 10 ΩRCX4100T1001
R1702RES CARBON FILM T 1/4W J 10 ΩRCX4100T1001
R1703RES CARBON FILM T 1/4W J 10k ΩRCX4103T1001
R1704RES CARBON FILM T 1/4W J 3.3k ΩRCX4332T1001
R1705RES CARBON FILM T 1/4W J 39k ΩRCX4393T1001
R1706RES CARBON FILM T 1/4W J 470 ΩRCX4471T1001
R1707RES CARBON FILM T 1/4W J 1.0k ΩRCX4102T1001
R1708RES CARBON FILM T 1/4W J 68k ΩRCX4683T1001
R1709RES CARBON FILM T 1/4W J 1.0k ΩRCX4102T1001
R1710RES CARBON FILM T 1/4W J 10k ΩRCX4103T1001
R1711RES CARBON FILM T 1/4W J 33k ΩRCX4333T1001
R1712RES CARBON FILM T 1/4W J 68k ΩRCX4683T1001
R1713RES CARBON FILM T 1/4W J 47 ΩRCX4470T1001
R1714RES CARBON FILM T 1/4W J 10k ΩRCX4103T1001
R1715RES CARBON FILM T 1/4W J 22k ΩRCX4223T1001
R1716RES CARBON FILM T 1/4W J 47k ΩRCX4473T1001
R1717RES CARBON FILM T 1/4W J 2.2k ΩRCX4222T1001
R1718RES CARBON FILM T 1/4W J 47 ΩRCX4470T1001
R1719RES CEMENT 5W J 0.18 ΩRW05R18PAK24
R1720RES CEMENT 5W J 0.18 ΩRW05R18PAK24
R1722RES CARBON FILM T 1/4W J 10k ΩRCX4103T1001
R1724RES CARBON FILM T 1/4W J 10k ΩRCX4103T1001
R1725CHIP RES. 1/10W J 22k ΩRRXAJR5Z0223
R1726CHIP RES. 1/10W J 47k ΩRRXAJR5Z0473
R1727CHIP RES. 1/10W J 5.1k ΩRRXAJR5Z0512
R1728CHIP RES. 1/10W J 4.7k ΩRRXAJR5Z0472
R1729CHIP RES. 1/10W J 220 ΩRRXAJR5Z0221
R1730RES CARBON FILM T 1/4W J 2.2k ΩRCX4222T1001
R1731CHIP RES. 1/10W J 2.7k ΩRRXAJR5Z0272
R1732RES CARBON FILM T 1/4W J 3.9k ΩRCX4392T1001
R1733WIRE COPPER 6111-06003-0120XZ40C0SHG002
R1734CHIP RES. 1/10W F 4.3k ΩRRXAFR5H4301
R1735RES CARBON FILM T 1/4W G 6.8k ΩRCX4682T1002
R1736RES CARBON FILM T 1/4W G 8.2k ΩRCX4822T1002
R1737CHIP RES. 1/10W F 2.2k ΩRRXAFR5H2201
R1738CHIP RES. 1/10W J 2.7k ΩRRXAJR5Z0272
R1739CHIP RES. 1/10W J 390 ΩRRXAJR5Z0391
R1740RES CARBON FILM T 1/4W J 22k ΩRCX4223T1001
R1741CHIP RES. 1/10W J 47k ΩRRXAJR5Z0473
R1742CHIP RES. 1/10W J 3.3k ΩRRXAJR5Z0332
R1743CHIP RES. 1/10W J 10k ΩRRXAJR5Z0103
R1744RES CARBON FILM T 1/4W J 2.2k ΩRCX4222T1001
R1745RES CARBON FILM T 1/4W J 2.2k ΩRCX4222T1001
R1801CHIP RES. 1/10W J 470 ΩRRXAJR5Z0471
R1802CHIP RES. 1/10W F 33.0k ΩRRXAFR5H3302
R1803CHIP RES. 1/10W F 6.8k ΩRRXAFR5H6801
R1804CHIP RES. 1/10W J 1k ΩRRXAJR5Z0102
R1805CHIP RES. 1/10W J 10k ΩRRXAJR5Z0103
R1351RES CARBON FILM T 1/4W G 18k ΩRCX4183T1002
R1352RES CARBON FILM T 1/4W G 8.2k ΩRCX4822T1002
R1353RES CARBON FILM T 1/4W G 4.7k ΩRCX4472T1002
R1354RES CARBON FILM T 1/4W G 2.7k ΩRCX4272T1002
R1355RES CARBON FILM T 1/4W G 4.7k ΩRCX4472T1002
R1356WIRE COPPER 6111-06003-0120XZ40C0SHG002
SWTICHES
SW1351TACT SWITCH SKQSABSST0101AL038
SW1352TACT SWITCH SKQSABSST0101AL038
SW1353TACT SWITCH SKQSABSST0101AL038
SW1354TACT SWITCH SKQSABSST0101AL038
SW1355TACT SWITCH SKQSABSST0101AL038
SW1357TACT SWITCH SKQSABSST0101AL038
IR SENSOR CBA
Ref. No.DescriptionPart No.
IR SENSOR CBA
Consists of the following:
CAPACITORS
C1301ELECTROLYTIC CAP. 47µF/16V M H7CE1CMAVSL470
C1302CHIP CERAMIC CAP.(1608) CH J 270pF/50VCHD1JJ3CH271
C1303CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C1304CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C1305CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C1307CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
CN1302242 SERIES CONNECTOR TUC-P08X-B1 WHT STJCTUB08TG002
----------
2009030515-8A91H1EL
Page 81
ELECTRICAL PARTS LIST
[LC427SSX (Serial No. : YA2A**********)]
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
C.....±0.25%D.....±0.5%F.....±1%
G.....±2%J......±5%K.....±10%
M.....±20%N.....±30%Z.....+80/-20%
DIGITAL MAIN CBA UNIT
Ref. No.DescriptionPart No.
DIGITAL MAIN CBA UNITA91H7MMA-001
JACK POWER CBA
Ref. No.DescriptionPart No.
JACK POWER CBA
Consists of the following:
CAPACITORS
C101CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C104CHIP CERAMIC CAP.(1608) CH J 47pF/50VCHD1JJ3CH470
C105ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C106CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C107CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C108CHIP CERAMIC CAP.(1608) CH J 47pF/50VCHD1JJ3CH470
C109CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C110ELECTROLYTIC CAP. 1000µF/6.3V MCE0KMASDL102
C111CHIP CERAMIC CAP. CH J 220pF/50VCHD1JJ3CH221
C201CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C202CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C203CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C204CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C205CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C206ELECTROLYTIC CAP. 220µF/6.3V MCE0KMASDL221
C401CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C402ELECTROLYTIC CAP. 47µF/25V MCE1EMASDL470
C403ELECTROLYTIC CAP. 10µF/50V M H7CE1JMAVSL100
C404CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C405CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C406CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C407CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C410CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C411CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C412ELECTROLYTIC CAP. 330µF/16V MCE1CMASDL331
C413ELECTROLYTIC CAP. 330µF/10V MCE1AMASDL331
C503CHIP CERAMIC CAP. F Z 0.01µF/50VCHD1JZ30F103
C601METALIZED FILM CAP. 0.0033µF/1.6KV JCT3C332F7004
C602CAP ELECTROLYTIC 100µF/400V/M/22/25CA2H101DYG17
A91H6MJC-001
Ref. No.DescriptionPart No.
C603POLYESTER FILM CAP. (PB FREE) 0.047µF/
C604CERAMIC CAP. RB 100pF/2KVCA3D101TE006
C605POLYESTER FILM CAP. (PB FREE) 0.001µF/
C606POLYESTER FILM CAP. (PB FREE) 0.1µF/100V JCA2A104DT018
C607POLYESTER FILM CAP. (PB FREE) 0.0022µF/
C610#SAFTY CAP. 2200pF/250V KXCA2E222MR101
C612POLYESTER FILM CAP. (PB FREE) 0.0022µF/
C621ELECTROLYTIC CAP. 1000µF/10V MCE1AMASDL102
C622ELECTROLYTIC CAP. 470µF/25V MCE1EMASDL471
C623CAP CERAMIC AXIAL 52 10000pF/50V/B/KCA1J103TU097
C624ELECTROLYTIC CAP. 470µF/25V MCE1EMASDL471
C625ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C626ELECTROLYTIC CAP. 100µF/16V MCE1CMASDL101
C628ELECTROLYTIC CAP. 1000µF/10V MCE1AMASDL102
C629ELECTROLYTIC CAP 3300µF/6.3V MCE0KMZNDL332
C630CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C631ELECTROLYTIC CAP. 1µF/50V MCE1JMASDL1R0
C633ELECTROLYTIC CAP. 330µF/50V MCE1JMZNDL331
C634CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C635ELECTROLYTIC CAP. 100µF/10V MCE1AMASDL101
C636CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C637CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C638CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C639CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C640CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C641CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C642CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C643CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C644CHIP CERAMIC CAP.(1608) B K 5600pF/50VCHD1JK30B562
C645CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C646CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C647CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C648CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C701CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C703CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C704ELECTROLYTIC CAP. 10µF/50V M H7CE1JMAVSL100
C705CHIP CERAMIC CAP.(1608) B K 0.01µF/50VCHD1JK30B103
C706CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C707CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C708CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C709CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C711CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C713CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C714CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C715CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C716CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C717CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C719CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
100V J
100V J
100V J
100V J
CA2A473DT018
CA2A102DT018
CA2A222DT018
CA2A222DT018
2009072815-9A91H7EL
Page 82
Ref. No.DescriptionPart No.
C720CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C721CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C722CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C723CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C731CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C733CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C740CHIP CERAMIC CAP. CH J 39pF/50VCHD1JJ3CH390
C741CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C742CHIP CERAMIC CAP. CH J 39pF/50VCHD1JJ3CH390
C743CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C744CHIP CERAMIC CAP. CH J 39pF/50VCHD1JJ3CH390
C745CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C746CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C747CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C750CHIP CERAMIC CAP.(1608) B K 3300pF/50VCHD1JK30B332
C751CHIP CERAMIC CAP.(1608) B K 3300pF/50VCHD1JK30B332
C752CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C801CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C802CHIP CERAMIC CAP.(1608) B K 0.01µF/50VCHD1JK30B103
C803CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C804CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C805CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C806CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C807CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C808CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C809CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C810CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C811CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C812CHIP CERAMIC CAP.(1608) B K 0.47µF/16VCHD1CK30B474
C813ELECTROLYTIC CAP. 470µF/25V MCE1EMASDL471
C816CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C817ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C818CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C819CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C820ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C821CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C822CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C823CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C824ELECTROLYTIC CAP. 470µF/25V MCE1EMASDL471
C825CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C826CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C827CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C828CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C829CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C830CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C832CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C833CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C834CHIP CERAMIC CAP.(1608) CH J 270pF/50VCHD1JJ3CH271
C835CHIP CERAMIC CAP.(1608) CH J 270pF/50VCHD1JJ3CH271
C836ELECTROLYTIC CAP. 100µF/16V M H7CE1CMAVSL101
C837CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C839ELECTROLYTIC CAP. 4.7µF/50V M H7CE1JMAVSL4R7
C840ELECTROLYTIC CAP. 4.7µF/50V M H7CE1JMAVSL4R7
C841CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C843ELECTROLYTIC CAP. 100µF/25V MCE1EMASDL101
C847CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C848CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C849CHIP CERAMIC CAP.(1608) B K 0.47µF/16VCHD1CK30B474
C851ELECTROLYTIC CAP. 3.3µF/50V MCE1JMASDL3R3
C852CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C853CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C854CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C855CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
Ref. No.DescriptionPart No.
C856CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C863ELECTROLYTIC CAP. 47µF/25V MCE1EMASDL470
C864ELECTROLYTIC CAP. 47µF/25V MCE1EMASDL470
C865CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C866CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C867CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C868CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C869CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
CONNECTORS
CN201FFC CONNECTOR IMSA-9615S-29A-PP-AJC96J29ER007
CN202FFC CONNECTOR IMSA-9615S-29A-PP-AJC96J29ER007
CN203242 SERIES CONNECTOR 224202108W1J322C08TG001
CN601WIRE ASSEMBLY 3PIN 3PIN/120MMWX1A94H0-213
CN801PH CONNECTOR TOP 2P B2B-PH-K-S
B21POW HEAT SINK A7120UH1EM423993
B24HEAT SINK PLT ASSEMBLY L0700UZ1EM423290
BC601WIRE COPPER 6111-06003-0120XZ40C0SHG002
BC603WIRE COPPER 6111-06003-0120XZ40C0SHG002
BC701WIRE COPPER 6111-06003-0120XZ40C0SHG002
BC702BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
BC801BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
BC804BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
BC805BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
BC806BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
BC807BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
JK701JACK RCA PCB S ORANGE 01/RCA-101H(OR) JXRJ010YUQ06
JK702JACK SW DIN PCB S 04/DIN-417HA-01JYEJ040YUQ03
JK703JACK RCA PCB S YELLOW 01/RCA-101H(YL) JXRJ010YUQ05
JK704JACK RCA PCB S WHITE 01/RCA-101H(WH)JXRJ010YUQ02
JK705JACK SW RCA PCB S RED RCA-102H(RD)JYRJ010YUQ03
JK706JACK SW DIN PCB L DIN-435C(777D)JYEL040YUQ03
JK707JACK RCA PCB L RCA-101S(1)-03JXRL010YUQ12
JK708JACK RCA PCB L RCA-101S(1)-04JXRL010YUQ13
JK709JACK SW RCA PCB L RCA-102F(RD)JYRL010YUQ05
JK712JACK RCA PCB S WHITE 01/RCA-101H(WH)JXRJ010YUQ02
JK713JACK SW RCA PCB S RED RCA-102H(RD)JYRJ010YUQ03
JK717JACK RCA PCB S GREEN 01/RCA-101H(GN) JXRJ010YUQ03
JK718JACK RCA PCB S BLUE 01/RCA-101H(BL)JXRJ010YUQ04
JK719JACK RCA PCB S RED 01/RCA-101H(RD)JXRJ010YUQ01
JK720JACK RCA PCB S WHITE 01/RCA-101H(WH)JXRJ010YUQ02
JK721JACK RCA PCB S RED 01/RCA-101H(RD)JXRJ010YUQ01
JK722JACK RCA PCB S WHITE 01/RCA-101H(WH)JXRJ010YUQ02
JK723JACK RCA PCB S RED 01/RCA-101H(RD)JXRJ010YUQ01
JS201WIRE COPPER 6111-06003-0120XZ40C0SHG002
JS801WIRE COPPER 6111-06003-0120XZ40C0SHG002
L8SCREW B-TIGHT D3X8 BIND HEAD+GBJB3080
T601#TRANS POWER 9706LTT3PC0KT056
TU101TUNER UNIT ATSC/NTSC/QAM UC020AFUTUNNTUSP035
2009072815-12A91H7EL
Page 85
INVERTER ASSEMBLY
Ref. No.DescriptionPart No.
INVERTER ASSEMBLY
Consists of the following:
INVERTER POWER CBA
--------------------------------------------------------------------FUNCTION CBA
IR SENSOR CBA
JUNCTION CBA
C1414CAP CERAMIC AXIAL 52 1200pF/50V/B/KCA1J122TU097
C1415CAP CERAMIC AXIAL 52 22pF/50VCH/JCA1J220TU095
C1416CAP CERAMIC AXIAL 52 22pF/50VCH/JCA1J220TU095
C1601# CAP METALIZED FILM 0.22µF/300V K 3.5MM CT2F224DC004
C1602# CAP METALIZED FILM 1.0µF/300V K 3.5MMCT2F105DC004
C1603# SAFTY CAP. 1000pF/250V KXCA2E102MR101
C1604# SAFTY CAP. 1000pF/250V KXCA2E102MR101
C1607CAP METALIZED FILM J1.0µF/630V/J/MPEFCA2K105DT048
C1610# CAP METALIZED FILM 0.22µF/300V K 3.5MM CT2F224DC004
C1611# SAFTY CAP. 1000pF/250V KXCA2E102MR101
C1612CAP ELECTROLYTIC 150µF/400V/M/25/30CA2H151DYG18
C1613CERAMIC CAP. RB 330pF/2KVCA3D331TE006
C1614CERAMIC CAP. RB 330pF/2KVCA3D331TE006
C1701CAP CERAMIC AXIAL 52 100000pF/50V/F/ZCA1J104TU098
C1702CERAMIC CAP. RB 330pF/2KVCA3D331TE006
C1703CERAMIC CAP. RB 330pF/2KVCA3D331TE006
C1704ELECTROLYTIC CAP. 100µF/25V MCE1EMASDL101
C1705CAP CERAMIC AXIAL 52 4700pF/50V/B/KCA1J472TU097
100V J
100V J
100V J
100V J
100V J
100V J
A91H6M1V-001
A91H6M1V-001-IV
---------------------------A91H6M1V-001-FNIRJN
----------
CA2A473DT018
CA2A182DT018
CA2A103DT018
CA2A102DT018
CA2A122DT018
CA2A102DT018
Ref. No.DescriptionPart No.
C1706CERAMIC CAP. B K 100pF/1KVCCD3AKD0B101
C1707ELECTROLYTIC CAP. 22µF/50V MCE1JMASDL220
C1708CAP CERAMIC AXIAL 52 100000pF/50V/F/ZCA1J104TU098
C1709CAP CERAMIC AXIAL 52 330pF/50V/B/KCA1J331TU097
C1710CAP CERAMIC AXIAL 52 100000pF/50V/F/ZCA1J104TU098
C1711METALIZED POLYESTER FILM CAP. 0.47µF/
C1712CAP CERAMIC AXIAL 52 100000pF/50V/F/ZCA1J104TU098
C1713ELECTROLYTIC CAP. 47µF/25V MCE1EMASDL470
C1714CAP METALIZED FILM J0.039µF/630V/J/MPEF CA2K393DT045
C1715CAP CERAMIC AXIAL 52 4700pF/50V/B/KCA1J472TU097
C1716ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C1717CHIP CERAMIC CAP. F Z 0.01µF/50VCHD1JZ30F103
C1718CHIP CERAMIC CAP. F Z 0.01µF/50VCHD1JZ30F103
C1720POLYESTER FILM CAP. (PB FREE) 0.047µF/
C1722CHIP CERAMIC CAP. F Z 0.01µF/50VCHD1JZ30F103
C1723CHIP CERAMIC CAP. F Z 0.01µF/50VCHD1JZ30F103
C1724CAP ELE STD-85 4700µF/35V SLCE1GMZNDL472
C1725CAP ELE STD-85 4700µF/35V SLCE1GMZNDL472
C1726CAP CERAMIC AXIAL 52 100000pF/50V/F/ZCA1J104TU098
C1727CAP ELE STD-85 4700µF/35V SLCE1GMZNDL472
C1731CAP CERAMIC AXIAL 52 10000pF/50V/F/ZCA1J103TU098
C1801ELECTROLYTIC CAP. 2200µF/35V MCE1GMZNDL222
C1806ELECTROLYTIC CAP. 2200µF/35V MCE1GMZNDL222
C1807ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C1811ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C1812CAP CERAMIC AXIAL 52 1000pF/50V/B/KCA1J102TU097
50V J
100V J
CT1J474DT040
CA2A473DT018
CONNECTORS
CN1501CONNECTOR PRINT OSU 3 S B3P4-VH-LJ3VH030JG015
CN1601CONNECTOR B2P3-VH(LF)(SN)J3VH020JG001
CN1801FFC CONNECTOR IMSA-9615S-11A-PP-AJC96J11ER007
CN1803CONNECTOR PRINT OSU B14B-PH-K-
When you repair any of the below Coils that are being used for this
CBA, please replace every Coils with same parts number.
Do not intermingle Coils with different parts numbers.
L1603#COIL EF 9702LLEE0Z0KT001
L1604#COIL EF 9702LLEE0Z0KT001
or
L1603#COIL EF JLC2518LLEE0Z0XB007
L1604#COIL EF JLC2518LLEE0Z0XB007
TRANSISTORS
Q1101TRANSISTOR KTC3199-GR-AT/PNQS4KTC3199P
Q1201TRANSISTOR KTC3199-GR-AT/PNQS4KTC3199P
Q1202TRANSISTOR 2SA950-O (TE2 F T)QQS002SA950F
Q1203# FET 2SK3757(Q)QFWZ02SK3757
Q1204# TRANSISTOR 2SC2120-O(TE2 F T)QQS02SC2120F
Q1401TRANSISTOR 2SC2120-O(TE2 F T)QQS02SC2120F
Q1402TRANSISTOR 2SA950-O (TE2 F T)QQS002SA950F
Q1403TRANSISTOR KTC3199-GR-AT/PNQS4KTC3199P
Q1404TRANSISTOR KTC3199-GR-AT/PNQS4KTC3199P
Q1601# FET MOS 2SK3561(Q) IDSS100UAQFWZ2SK3561Q
Q1602# FET MOS 2SK3561(Q) IDSS100UAQFWZ2SK3561Q
Q1701# FET MOS 2SK3561(Q) IDSS100UAQFWZ2SK3561Q
Q1702# FET MOS 2SK3561(Q) IDSS100UAQFWZ2SK3561Q
Q1703TRANSISTOR 2SA950-O (TE2 F T)QQS002SA950F
Q1704TRANSISTOR KTC3199-GR-AT/PNQS4KTC3199P
Q1705TRANSISTOR KTC3199-GR-AT/PNQS4KTC3199P
Q1706TRANSISTOR KTA1267-GR-AT/PNQS1KTA1267P
Q1707TRANSISTOR KTC3199-GR-AT/PNQS4KTC3199P
Q1708TRANSISTOR KTC3199-GR-AT/PNQS4KTC3199P
R1351RES CARBON FILM J 52 1/4W G 12k ΩRCX4123T1005
R1352RES CARBON FILM J 52 1/4W G 8.2k ΩRCX4822T1005
R1353RES CARBON FILM J 52 1/4W G 4.7k ΩRCX4472T1005
R1354RES CARBON FILM J 52 1/4W G 2.7k ΩRCX4272T1005
R1355RES CARBON FILM J 52 1/4W G 4.7k ΩRCX4472T1005
R1356WIRE COPPER 6111-06003-0120XZ40C0SHG002
C1301ELECTROLYTIC CAP. 47µF/16V M H7CE1CMAVSL470
C1302CHIP CERAMIC CAP.(1608) CH J 270pF/50VCHD1JJ3CH271
C1303CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C1304CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C1305CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C1307CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
DIODES
----------
2009072815-15A91H7EL
Page 88
Ref. No.DescriptionPart No.
D1301LED L-53HTNP4Z000L53HT
D1302LED GREEN 333GT/E(FNA)NPWZ33GTEFNA
CN1302242 SERIES CONNECTOR TUC-P08X-B1 WHT STJCTUB08TG002
----------
2009072815-16A91H7EL
Page 89
ELECTRICAL PARTS LIST
[42MF439B/F7 (Serial No. : DS1A**********)]
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
C.....±0.25%D.....±0.5%F.....±1%
G.....±2%J......±5%K.....±10%
M.....±20%N.....±30%Z.....+80/-20%
DIGITAL MAIN CBA UNIT
Ref. No.DescriptionPart No.
DIGITAL MAIN CBA UNITA91H0MMA-001
JACK POWER CBA
Ref. No.DescriptionPart No.
JACK POWER CBA
Consists of the following:
CAPACITORS
C101CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C104CHIP CERAMIC CAP.(1608) CH J 47pF/50VCHD1JJ3CH470
C105ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C106CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C107CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C108CHIP CERAMIC CAP.(1608) CH J 47pF/50VCHD1JJ3CH470
C109CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C110ELECTROLYTIC CAP. 1000µF/6.3V MCE0KMASDL102
C111CHIP CERAMIC CAP. CH J 220pF/50VCHD1JJ3CH221
C201CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C202CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C203CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C204CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C205CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C206ELECTROLYTIC CAP. 220µF/6.3V MCE0KMASDL221
C401CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C402ELECTROLYTIC CAP. 47µF/25V MCE1EMASDL470
C403ELECTROLYTIC CAP. 10µF/50V M H7CE1JMAVSL100
C404CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C405CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C406CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C407CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C410CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C411CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C412ELECTROLYTIC CAP. 100µF/16V MCE1CMASDL101
C413ELECTROLYTIC CAP. 100µF/10V MCE1AMASDL101
C503CHIP CERAMIC CAP. F Z 0.01µF/50VCHD1JZ30F103
C601METALIZED FILM CAP. 0.0033µF/1.6KV JCT3C332F7004
C602CAP ELECTROLYTIC 100µF/400V/M/22/25CA2H101DYG17
A91H0MJC-001
Ref. No.DescriptionPart No.
C603POLYESTER FILM CAP. (PB FREE) 0.047µF/
C604CERAMIC CAP. RB 100pF/2KVCA3D101TE006
C605POLYESTER FILM CAP. (PB FREE) 0.001µF/
C606POLYESTER FILM CAP. (PB FREE) 0.1µF/100V JCA2A104DT018
C607POLYESTER FILM CAP. (PB FREE) 0.0022µF/
C610#SAFTY CAP. 2200pF/250V KXCA2E222MR101
C612POLYESTER FILM CAP. (PB FREE) 0.0022µF/
C614ELECTROLYTIC CAP 3300µF/25V MCE1EMZNDL332
C615ELECTROLYTIC CAP 3300µF/25V MCE1EMZNDL332
C617ELECTROLYTIC CAP. 220µF/50V MCE1JMASDL221
C618ELECTROLYTIC CAP. 4700µF/10V M P=7.5CE1AMZNDL472
C619ELECTROLYTIC CAP. 1000µF/10V MCE1AMASDL102
C620CAP ALUMINUM ELECTOLYTIC 2200µF/6.3V MCE0KMZNDL222
C621ELECTROLYTIC CAP. 1000µF/10V MCE1AMASDL102
C622ELECTROLYTIC CAP. 470µF/25V MCE1EMASDL471
C623CAP CERAMIC (AX) 0.01µF/50V/B/KCA1J103TU061
C624ELECTROLYTIC CAP. 470µF/25V MCE1EMASDL471
C625ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C626ELECTROLYTIC CAP. 100µF/16V MCE1CMASDL101
C628ELECTROLYTIC CAP. 1000µF/10V MCE1AMASDL102
C629ELECTROLYTIC CAP 3300µF/6.3V MCE0KMZNDL332
C630CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C631ELECTROLYTIC CAP. 1µF/50V MCE1JMASDL1R0
C633ELECTROLYTIC CAP. 330µF/50V MCE1JMZNDL331
C634CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C635ELECTROLYTIC CAP. 100µF/10V MCE1AMASDL101
C636CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C637CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C638CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C639CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C640CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C641CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C642CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C643CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C644CHIP CERAMIC CAP.(1608) B K 5600pF/50VCHD1JK30B562
C645CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C646CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C647CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C648CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C701CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C703CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C704ELECTROLYTIC CAP. 10µF/50V M H7CE1JMAVSL100
C705CHIP CERAMIC CAP.(1608) B K 0.01µF/50VCHD1JK30B103
C706CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C707CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C708CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C709CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C711CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C713CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C714CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C715CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C716CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C717CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C719CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
100V J
100V J
100V J
100V J
CA2A473DT018
CA2A102DT018
CA2A222DT018
CA2A222DT018
2009030515-17A91H0EL
Page 90
Ref. No.DescriptionPart No.
C720CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C721CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C722CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C723CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C731CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C733CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C740CHIP CERAMIC CAP. CH J 39pF/50VCHD1JJ3CH390
C741CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C742CHIP CERAMIC CAP. CH J 39pF/50VCHD1JJ3CH390
C743CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C744CHIP CERAMIC CAP. CH J 39pF/50VCHD1JJ3CH390
C745CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C746CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C747CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C750CHIP CERAMIC CAP.(1608) B K 3300pF/50VCHD1JK30B332
C751CHIP CERAMIC CAP.(1608) B K 3300pF/50VCHD1JK30B332
C752CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C801CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C802CHIP CERAMIC CAP.(1608) B K 0.01µF/50VCHD1JK30B103
C803CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C804CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C805CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C806CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C807CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C808CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C809CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C810CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C811CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C812CHIP CERAMIC CAP.(1608) B K 0.47µF/16VCHD1CK30B474
C813ELECTROLYTIC CAP. 470µF/25V MCE1EMASDL471
C816CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C817ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C818CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C819CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C820ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C821CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C822CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C823CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C824ELECTROLYTIC CAP. 470µF/25V MCE1EMASDL471
C825CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C826CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C827CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C828CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C829CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C830CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C832CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C833CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C834CHIP CERAMIC CAP.(1608) CH J 270pF/50VCHD1JJ3CH271
C835CHIP CERAMIC CAP.(1608) CH J 270pF/50VCHD1JJ3CH271
C836ELECTROLYTIC CAP. 100µF/16V M H7CE1CMAVSL101
C837CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C839ELECTROLYTIC CAP. 4.7µF/50V M H7CE1JMAVSL4R7
C840ELECTROLYTIC CAP. 4.7µF/50V M H7CE1JMAVSL4R7
C841CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C843ELECTROLYTIC CAP. 100µF/25V MCE1EMASDL101
C847CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C848CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C849CHIP CERAMIC CAP.(1608) B K 0.47µF/16VCHD1CK30B474
C851ELECTROLYTIC CAP. 3.3µF/50V MCE1JMASDL3R3
C852CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C853CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C854CHIP CERAMIC CAP. B K 470pF/50VCHD1JK30B471
C855CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
Ref. No.DescriptionPart No.
C856CHIP CERAMIC CAP. B K 470pF/50VCHD1JK30B471
C863ELECTROLYTIC CAP. 47µF/25V MCE1EMASDL470
C864ELECTROLYTIC CAP. 47µF/25V MCE1EMASDL470
C865CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C866CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C867CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C868CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C869CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
CONNECTORS
CN201FFC CONNECTOR IMSA-9615S-29A-PP-AJC96J29ER007
CN202FFC CONNECTOR IMSA-9615S-29A-PP-AJC96J29ER007
CN203242 SERIES CONNECTOR 224202108W1J322C08TG001
CN601WIRE ASSEMBLY 3PIN 3PIN 120MMWX1A94H0-203
CN801PH CONNECTOR TOP 2P B2B-PH-K-S
B21POW HEAT SINK A7120UH1EM423993
B24HEAT SINK PLT ASSEMBLY L0700UZ1EM423290
BC601WIRE COPPER 6111-06003-0120XZ40C0SHG002
BC603WIRE COPPER 6111-06003-0120XZ40C0SHG002
BC701WIRE COPPER 6111-06003-0120XZ40C0SHG002
BC702BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
BC801BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
BC804BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
BC805BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
BC806BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
BC807BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
JK701JACK RCA PCB S ORANGE 01/RCA-101H(OR) JXRJ010YUQ06
JK702JACK SW DIN PCB S 04/DIN-417HA-01JYEJ040YUQ03
JK703JACK RCA PCB S YELLOW 01/RCA-101H(YL) JXRJ010YUQ05
JK704JACK RCA PCB S WHITE 01/RCA-101H(WH)JXRJ010YUQ02
JK705JACK SW RCA PCB S RED RCA-102H(RD)JYRJ010YUQ03
JK706JACK SW DIN PCB L DIN-435C(777D)JYEL040YUQ03
JK707JACK RCA PCB L RCA-101S(1)-03JXRL010YUQ12
JK708JACK RCA PCB L RCA-101S(1)-04JXRL010YUQ13
JK709JACK SW RCA PCB L RCA-102F(RD)JYRL010YUQ05
JK712JACK RCA PCB S WHITE 01/RCA-101H(WH)JXRJ010YUQ02
JK713JACK SW RCA PCB S RED RCA-102H(RD)JYRJ010YUQ03
JK717JACK RCA PCB S GREEN 01/RCA-101H(GN) JXRJ010YUQ03
JK718JACK RCA PCB S BLUE 01/RCA-101H(BL)JXRJ010YUQ04
JK719JACK RCA PCB S RED 01/RCA-101H(RD)JXRJ010YUQ01
JK720JACK RCA PCB S WHITE 01/RCA-101H(WH)JXRJ010YUQ02
JK721JACK RCA PCB S RED 01/RCA-101H(RD)JXRJ010YUQ01
JK722JACK RCA PCB S WHITE 01/RCA-101H(WH)JXRJ010YUQ02
JK723JACK RCA PCB S RED 01/RCA-101H(RD)JXRJ010YUQ01
JS201WIRE COPPER 6111-06003-0120XZ40C0SHG002
JS801WIRE COPPER 6111-06003-0120XZ40C0SHG002
L8SCREW B-TIGHT D3X8 BIND HEAD+GBJB3080
T601#TRANS POWER 9706LTT3PC0KT056
TU101TUNER UNIT ATSC/NTSC/QAM UC020AFUTUNNTUSP035
2009030515-20A91H0EL
Page 93
INVERTER ASSEMBLY
Ref. No.DescriptionPart No.
INVERTER ASSEMBLY
Consists of the following:
INVERTER POWER CBA
--------------------------------------------------------------------FUNCTION CBA
IR SENSOR CBA
JUNCTION CBA
C1712CAP CERAMIC (AX) 0.1µF/50V/F/ZCA1J104TU062
C1713ELECTROLYTIC CAP. 47µF/25V MCE1EMASDL470
C1714CAP METALIZED FILM J0.039µF/630V/J/MPEF CA2K393DT045
C1715CAP CERAMIC (AX) 4700pF/50V/B/KCA1J472TU061
C1716ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C1717CHIP CERAMIC CAP. F Z 0.01µF/50VCHD1JZ30F103
C1718CHIP CERAMIC CAP. F Z 0.01µF/50VCHD1JZ30F103
C1720POLYESTER FILM CAP. (PB FREE) 0.047µF/
C1722CHIP CERAMIC CAP. F Z 0.01µF/50VCHD1JZ30F103
C1723CHIP CERAMIC CAP. F Z 0.01µF/50VCHD1JZ30F103
C1724CAP ELE STD-85 4700µF/35V SLCE1GMZNDL472
C1725CAP ELE STD-85 4700µF/35V SLCE1GMZNDL472
C1726CAP CERAMIC (AX) 0.1µF/50V/F/ZCA1J104TU062
C1727CAP ELE STD-85 4700µF/35V SLCE1GMZNDL472
C1731CAP CERAMIC (AX) 0.01µF/50V/F/ZCA1J103TU062
C1801ELECTROLYTIC CAP. 2200µF/35V MCE1GMZNDL222
C1806ELECTROLYTIC CAP. 2200µF/35V MCE1GMZNDL222
C1807ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C1811ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C1812CAP CERAMIC (AX) 1000pF/50V/B/KCA1J102TU061
50V J
100V J
CT1J474DT040
CA2A473DT018
CONNECTORS
CN1501CONNECTOR PRINT OSU 3 S B3P4-VH-LJ3VH030JG015
CN1601CONNECTOR B2P3-VH(LF)(SN)J3VH020JG001
CN1801FFC CONNECTOR IMSA-9615S-11A-PP-AJC96J11ER007
CN1803CONNECTOR PRINT OSU B14B-PH-K-
L1101CHOKE COIL 22µH-KLLBD00PKV021
L1601#FILTER LLBG00ZY2015LLBG00ZY2015
L1602#FILTER LLBG00ZY2015LLBG00ZY2015
L1603#COIL EF 9702LLEE0Z0KT001
L1604#COIL EF 9702LLEE0Z0KT001
TRANSISTORS
Q1101TRANSISTOR KTC3199-GR-AT/PNQS4KTC3199P
Q1201TRANSISTOR KTC3199-GR-AT/PNQS4KTC3199P
Q1202TRANSISTOR 2SA950-O (TE2 F T)QQS002SA950F
Q1203# FET 2SK3757(Q)QFWZ02SK3757
Q1204# TRANSISTOR KTC3199-GR-AT/PNQS4KTC3199P
Q1401TRANSISTOR 2SC2120-O(TE2 F T)QQS02SC2120F
Q1402TRANSISTOR 2SA950-O (TE2 F T)QQS002SA950F
Q1403TRANSISTOR KTC3199-GR-AT/PNQS4KTC3199P
Q1404TRANSISTOR KTC3199-GR-AT/PNQS4KTC3199P
Q1601# FET MOS 2SK3561(Q) IDSS100UAQFWZ2SK3561Q
Q1602# FET MOS 2SK3561(Q) IDSS100UAQFWZ2SK3561Q
Q1701# FET MOS 2SK3561(Q) IDSS100UAQFWZ2SK3561Q
Q1702# FET MOS 2SK3561(Q) IDSS100UAQFWZ2SK3561Q
Q1703TRANSISTOR 2SA950-O (TE2 F T)QQS002SA950F
Q1704TRANSISTOR KTC3199-GR-AT/PNQS4KTC3199P
Q1705TRANSISTOR KTC3199-GR-AT/PNQS4KTC3199P
Q1706TRANSISTOR KTA1267-GR-AT/PNQS1KTA1267P
Q1707TRANSISTOR KTC3199-GR-AT/PNQS4KTC3199P
Q1708TRANSISTOR KTC3199-GR-AT/PNQS4KTC3199P
RESISTORS
R1103RES CARBON FILM T 1/4W J 10 ΩRCX4100T1001
R1104CHIP RES. 1/10W J 270 ΩRRXAJR5Z0271
R1105RES CARBON FILM T 1/4W G 6.8k ΩRCX4682T1002
R1106RES CARBON FILM T 1/4W G 27k ΩRCX4273T1002
R1107CHIP RES. 1/10W F 3.3k ΩRRXAFR5H3301
R1108CHIP RES. 1/10W F 10k ΩRRXAFR5H1002
Ref. No.DescriptionPart No.
R1109RES CARBON FILM T 1/4W J 22 ΩRCX4220T1001
R1206CHIP RES. 1/10W J 470 ΩRRXAJR5Z0471
R1207CHIP RES. 1/10W J 3.3k ΩRRXAJR5Z0332
R1208RES CARBON FILM T 1/4W J 560 ΩRCX4561T1001
R1209RES CARBON FILM T 1/4W J 33k ΩRCX4333T1001
R1210CHIP RES. 1/10W J 220k ΩRRXAJR5Z0224
R1211CHIP RES. 1/10W F 1.0k ΩRRXAFR5H1001
R1212CHIP RES. 1/10W F 4.3k ΩRRXAFR5H4301
R1213CHIP RES. 1/10W F 4.7k ΩRRXAFR5H4701
R1214WIRE COPPER 6111-06003-0120XZ40C0SHG002
R1215RES CARBON FILM T 1/4W J 100 ΩRCX4101T1001
R1216RES CARBON FILM T 1/4W J 1.0k ΩRCX4102T1001
R1217RES CARBON FILM T 1/4W J 820k ΩRCX4824T1001
R1218RES CARBON FILM T 1/4W J 820k ΩRCX4824T1001
R1219RES CARBON FILM T 1/4W J 820k ΩRCX4824T1001
R1220RES CARBON FILM T 1/4W J 330 ΩRCX4331T1001
R1221RES CARBON FILM T 1/4W J 470k ΩRCX4474T1001
R1222RES CARBON FILM T 1/4W J 1.8k ΩRCX4182T1001
R1223RES CARBON FILM T 1/4W J 1.0k ΩRCX4102T1001
R1224RES. CARBON FILM J 1/2W J 3.9 ΩRCX23R9T1003
R1225RES CARBON FILM T 1/4W J 18k ΩRCX4183T1001
R1226RES CARBON FILM T 1/4W J 4.7k ΩRCX4472T1001
R1227RES CARBON FILM T 1/4W J 10k ΩRCX4103T1001
R1228METAL OXIDE FILM RES. 2W J 1 ΩRN021R0ZU001
R1229METAL OXIDE FILM RES. 2W J 56 ΩRN02560ZU001
R1401RES MATALIZED FILM 1/4W F 825k ΩRDC8253HH001
R1402RES MATALIZED FILM 1/4W F 825k ΩRDC8253HH001
R1403RES MATALIZED FILM 1/4W F 619k ΩRDC6193HH001
R1404RES MATALIZED FILM 1/4W F 619k ΩRDC6193HH001
R1405RES METALIZED FILM T 1/4W F 51.1k ΩRDC5112HH003
R1406METAL FILM RES. 1/4W F 121k ΩRDC1213HH001
R1407RES METALIZED FILM T 1/4W F 2.74k ΩRDC2741HH003
R1409RES METALIZED FILM T 1/4W F 5.62k ΩRDC5621HH003
R1410RES CARBON FILM T 1/4W J 470 ΩRCX4471T1001
R1411RES CARBON FILM T 1/4W J 3.3k ΩRCX4332T1001
R1412RES CARBON FILM T 1/4W J 10k ΩRCX4103T1001
R1413RES CARBON FILM T 1/4W J 4.7k ΩRCX4472T1001
R1415RES CARBON FILM T 1/4W J 4.7k ΩRCX4472T1001
R1416RES CARBON FILM T 1/4W J 39k ΩRCX4393T1001
R1417METAL FILM RES. 1/4W F 100k ΩRDC1003HH001
R1418METAL FILM RES. 1/4W F 100k ΩRDC1003HH001
R1419METAL FILM RES. 1/4W F 100k ΩRDC1003HH001
R1420RES METALIZED FILM T 1/4W F 26.7k ΩRDC2672HH003
R1421WIRE COPPER 6111-06003-0120XZ40C0SHG002
R1422METAL FILM RES. 1/4W F 100k ΩRDC1003HH001
R1423RES CARBON FILM T 1/4W J 220k ΩRCX4224T1001
R1424RES CARBON FILM T 1/4W J 100 ΩRCX4101T1001
R1425RES MATALIZED FILM 1/4W F 825k ΩRDC8253HH001
R1426RES MATALIZED FILM 1/4W F 825k ΩRDC8253HH001
R1427RES MATALIZED FILM 1/4W F 619k ΩRDC6193HH001
R1428RES MATALIZED FILM 1/4W F 619k ΩRDC6193HH001
R1429RES METALIZED FILM T 1/4W F 21.0k ΩRDC2102HH003
R1430RES METALIZED FILM T 1/4W F 21.0k ΩRDC2102HH003
R1431RES MATALIZED FILM 1/4W F 825k ΩRDC8253HH001
R1432RES MATALIZED FILM 1/4W F 825k ΩRDC8253HH001
R1433RES MATALIZED FILM 1/4W F 619k ΩRDC6193HH001
R1434RES MATALIZED FILM 1/4W F 619k ΩRDC6193HH001
R1435RES METALIZED FILM T 1/4W F 33.2k ΩRDC3322HH003
R1436RES CARBON FILM T 1/4W J 4.7k ΩRCX4472T1001
R1437RES CARBON FILM T 1/4W J 470 ΩRCX4471T1001
R1438RES CARBON FILM T 1/4W J 3.3k ΩRCX4332T1001
R1439RES CARBON FILM T 1/4W J 2.2k ΩRCX4222T1001
R1440WIRE COPPER 6111-06003-0120XZ40C0SHG002
2009030515-22A91H0EL
Page 95
Ref. No.DescriptionPart No.
R1441WIRE COPPER 6111-06003-0120XZ40C0SHG002
R1601# GLASS GLAZE RES. 1/2W J 1M ΩRXX2JZLZ0105
R1602# GLASS GLAZE RES. 1/2W J 8.2M ΩRXX2JZLZ0825
R1603RES CARBON FILM T 1/4W J 20k ΩRCX4203T1001
R1604RES CEMENT 5W J 0.015 ΩRW05L15PAK24
R1605RES CARBON FILM T 1/4W J 4.7 ΩRCX44R7T1001
R1606RES CARBON FILM T 1/4W J 4.7 ΩRCX44R7T1001
R1607RES CARBON FILM T 1/4W J 20k ΩRCX4203T1001
R1608GLASS GLAZE RES. 1/2W J 1M ΩRXX2JZLZ0105
R1701RES CARBON FILM T 1/4W J 10 ΩRCX4100T1001
R1702RES CARBON FILM T 1/4W J 10 ΩRCX4100T1001
R1703RES CARBON FILM T 1/4W J 10k ΩRCX4103T1001
R1704RES CARBON FILM T 1/4W J 3.3k ΩRCX4332T1001
R1705RES CARBON FILM T 1/4W J 39k ΩRCX4393T1001
R1706RES CARBON FILM T 1/4W J 470 ΩRCX4471T1001
R1707RES CARBON FILM T 1/4W J 1.0k ΩRCX4102T1001
R1708RES CARBON FILM T 1/4W J 68k ΩRCX4683T1001
R1709RES CARBON FILM T 1/4W J 1.0k ΩRCX4102T1001
R1710RES CARBON FILM T 1/4W J 10k ΩRCX4103T1001
R1711RES CARBON FILM T 1/4W J 33k ΩRCX4333T1001
R1712RES CARBON FILM T 1/4W J 68k ΩRCX4683T1001
R1713RES CARBON FILM T 1/4W J 47 ΩRCX4470T1001
R1714RES CARBON FILM T 1/4W J 10k ΩRCX4103T1001
R1715RES CARBON FILM T 1/4W J 22k ΩRCX4223T1001
R1716RES CARBON FILM T 1/4W J 47k ΩRCX4473T1001
R1717RES CARBON FILM T 1/4W J 2.2k ΩRCX4222T1001
R1718RES CARBON FILM T 1/4W J 47 ΩRCX4470T1001
R1719RES CEMENT 5W J 0.18 ΩRW05R18PAK24
R1720RES CEMENT 5W J 0.18 ΩRW05R18PAK24
R1722RES CARBON FILM T 1/4W J 10k ΩRCX4103T1001
R1724RES CARBON FILM T 1/4W J 10k ΩRCX4103T1001
R1725CHIP RES. 1/10W J 22k ΩRRXAJR5Z0223
R1726CHIP RES. 1/10W J 47k ΩRRXAJR5Z0473
R1727CHIP RES. 1/10W J 5.1k ΩRRXAJR5Z0512
R1728CHIP RES. 1/10W J 4.7k ΩRRXAJR5Z0472
R1729CHIP RES. 1/10W J 220 ΩRRXAJR5Z0221
R1730RES CARBON FILM T 1/4W J 2.2k ΩRCX4222T1001
R1731CHIP RES. 1/10W J 2.7k ΩRRXAJR5Z0272
R1732RES CARBON FILM T 1/4W J 3.9k ΩRCX4392T1001
R1733WIRE COPPER 6111-06003-0120XZ40C0SHG002
R1734CHIP RES. 1/10W F 4.3k ΩRRXAFR5H4301
R1735RES CARBON FILM T 1/4W G 6.8k ΩRCX4682T1002
R1736RES CARBON FILM T 1/4W G 8.2k ΩRCX4822T1002
R1737CHIP RES. 1/10W F 2.2k ΩRRXAFR5H2201
R1738CHIP RES. 1/10W J 2.7k ΩRRXAJR5Z0272
R1739CHIP RES. 1/10W J 390 ΩRRXAJR5Z0391
R1740RES CARBON FILM T 1/4W J 22k ΩRCX4223T1001
R1741CHIP RES. 1/10W J 47k ΩRRXAJR5Z0473
R1742CHIP RES. 1/10W J 3.3k ΩRRXAJR5Z0332
R1743CHIP RES. 1/10W J 10k ΩRRXAJR5Z0103
R1744RES CARBON FILM T 1/4W J 2.2k ΩRCX4222T1001
R1745RES CARBON FILM T 1/4W J 2.2k ΩRCX4222T1001
R1801CHIP RES. 1/10W J 470 ΩRRXAJR5Z0471
R1802CHIP RES. 1/10W F 33.0k ΩRRXAFR5H3302
R1803CHIP RES. 1/10W F 6.8k ΩRRXAFR5H6801
R1804CHIP RES. 1/10W J 1k ΩRRXAJR5Z0102
R1805CHIP RES. 1/10W J 10k ΩRRXAJR5Z0103
R1351RES CARBON FILM T 1/4W G 18k ΩRCX4183T1002
R1352RES CARBON FILM T 1/4W G 8.2k ΩRCX4822T1002
R1353RES CARBON FILM T 1/4W G 4.7k ΩRCX4472T1002
R1354RES CARBON FILM T 1/4W G 2.7k ΩRCX4272T1002
R1355RES CARBON FILM T 1/4W G 4.7k ΩRCX4472T1002
R1356WIRE COPPER 6111-06003-0120XZ40C0SHG002
C1301ELECTROLYTIC CAP. 47µF/16V M H7CE1CMAVSL470
C1302CHIP CERAMIC CAP.(1608) CH J 270pF/50VCHD1JJ3CH271
C1303CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C1304CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C1305CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C1307CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
DIODES
D1301LED L-53HTNP4Z000L53HT
D1302LED GREEN 333GT/E(FNA)NPWZ33GTEFNA
CN1302242 SERIES CONNECTOR TUC-P08X-B1 WHT STJCTUB08TG002
----------
2009030515-24A91H0EL
Page 97
ELECTRICAL PARTS LIST
[42MF439B/F7 (Serial No. : YA2A**********)]
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
C.....±0.25%D.....±0.5%F.....±1%
G.....±2%J......±5%K.....±10%
M.....±20%N.....±30%Z.....+80/-20%
DIGITAL MAIN CBA UNIT
Ref. No.DescriptionPart No.
DIGITAL MAIN CBA UNITA91H6MMA-001
JACK POWER CBA
Ref. No.DescriptionPart No.
JACK POWER CBA
Consists of the following:
CAPACITORS
C101CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C104CHIP CERAMIC CAP.(1608) CH J 47pF/50VCHD1JJ3CH470
C105ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C106CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C107CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C108CHIP CERAMIC CAP.(1608) CH J 47pF/50VCHD1JJ3CH470
C109CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C110ELECTROLYTIC CAP. 1000µF/6.3V MCE0KMASDL102
C111CHIP CERAMIC CAP. CH J 220pF/50VCHD1JJ3CH221
C201CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C202CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C203CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C204CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C205CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C206ELECTROLYTIC CAP. 220µF/6.3V MCE0KMASDL221
C401CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C402ELECTROLYTIC CAP. 47µF/25V MCE1EMASDL470
C403ELECTROLYTIC CAP. 10µF/50V M H7CE1JMAVSL100
C404CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C405CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C406CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C407CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C410CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C411CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C412ELECTROLYTIC CAP. 330µF/16V MCE1CMASDL331
C413ELECTROLYTIC CAP. 330µF/10V MCE1AMASDL331
C503CHIP CERAMIC CAP. F Z 0.01µF/50VCHD1JZ30F103
C601METALIZED FILM CAP. 0.0033µF/1.6KV JCT3C332F7004
C602CAP ELECTROLYTIC 100µF/400V/M/22/25CA2H101DYG17
A91H6MJC-001
Ref. No.DescriptionPart No.
C603POLYESTER FILM CAP. (PB FREE) 0.047µF/
C604CERAMIC CAP. RB 100pF/2KVCA3D101TE006
C605POLYESTER FILM CAP. (PB FREE) 0.001µF/
C606POLYESTER FILM CAP. (PB FREE) 0.1µF/100V JCA2A104DT018
C607POLYESTER FILM CAP. (PB FREE) 0.0022µF/
C610#SAFTY CAP. 2200pF/250V KXCA2E222MR101
C612POLYESTER FILM CAP. (PB FREE) 0.0022µF/
C621ELECTROLYTIC CAP. 1000µF/10V MCE1AMASDL102
C622ELECTROLYTIC CAP. 470µF/25V MCE1EMASDL471
C623CAP CERAMIC AXIAL 52 10000pF/50V/B/KCA1J103TU097
C624ELECTROLYTIC CAP. 470µF/25V MCE1EMASDL471
C625ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C626ELECTROLYTIC CAP. 100µF/16V MCE1CMASDL101
C628ELECTROLYTIC CAP. 1000µF/10V MCE1AMASDL102
C629ELECTROLYTIC CAP 3300µF/6.3V MCE0KMZNDL332
C630CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C631ELECTROLYTIC CAP. 1µF/50V MCE1JMASDL1R0
C633ELECTROLYTIC CAP. 330µF/50V MCE1JMZNDL331
C634CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C635ELECTROLYTIC CAP. 100µF/10V MCE1AMASDL101
C636CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C637CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C638CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C639CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C640CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C641CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C642CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C643CHIP CERAMIC CAP.(1608) F Z 0.1µF/25VCHD1EZ30F104
C644CHIP CERAMIC CAP.(1608) B K 5600pF/50VCHD1JK30B562
C645CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C646CHIP CERAMIC CAP.(2125) F Z 10µF/10VCHE1AZ30F106
C647CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C648CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C701CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C703CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C704ELECTROLYTIC CAP. 10µF/50V M H7CE1JMAVSL100
C705CHIP CERAMIC CAP.(1608) B K 0.01µF/50VCHD1JK30B103
C706CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C707CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C708CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C709CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C711CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C713CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C714CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C715CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C716CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C717CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C719CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
100V J
100V J
100V J
100V J
CA2A473DT018
CA2A102DT018
CA2A222DT018
CA2A222DT018
2009072815-25A91H6EL
Page 98
Ref. No.DescriptionPart No.
C720CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C721CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C722CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C723CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C731CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C733CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C740CHIP CERAMIC CAP. CH J 39pF/50VCHD1JJ3CH390
C741CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C742CHIP CERAMIC CAP. CH J 39pF/50VCHD1JJ3CH390
C743CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C744CHIP CERAMIC CAP. CH J 39pF/50VCHD1JJ3CH390
C745CHIP CERAMIC CAP. F Z 0.47µF/16VCHD1CZ30F474
C746CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C747CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C750CHIP CERAMIC CAP.(1608) B K 3300pF/50VCHD1JK30B332
C751CHIP CERAMIC CAP.(1608) B K 3300pF/50VCHD1JK30B332
C752CHIP CERAMIC CAP.(1608) CH J 100pF/50VCHD1JJ3CH101
C801CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C802CHIP CERAMIC CAP.(1608) B K 0.01µF/50VCHD1JK30B103
C803CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C804CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C805CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C806CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C807CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C808CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C809CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C810CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C811CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C812CHIP CERAMIC CAP.(1608) B K 0.47µF/16VCHD1CK30B474
C813ELECTROLYTIC CAP. 470µF/25V MCE1EMASDL471
C816CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C817ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C818CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C819CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C820ELECTROLYTIC CAP. 10µF/50V MCE1JMASDL100
C821CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C822CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C823CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C824ELECTROLYTIC CAP. 470µF/25V MCE1EMASDL471
C825CHIP CERAMIC CAP.(1608) B K 1µF/25VCHD1EK30B105
C826CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C827CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C828CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C829CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C830CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C832CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C833CHIP CERAMIC CAP.(1608) B K 2.2µF/10VCHD1AK30B225
C834CHIP CERAMIC CAP.(1608) CH J 270pF/50VCHD1JJ3CH271
C835CHIP CERAMIC CAP.(1608) CH J 270pF/50VCHD1JJ3CH271
C836ELECTROLYTIC CAP. 100µF/16V M H7CE1CMAVSL101
C837CHIP CERAMIC CAP.(1608) F Z 0.1µF/50VCHD1JZ30F104
C839ELECTROLYTIC CAP. 4.7µF/50V M H7CE1JMAVSL4R7
C840ELECTROLYTIC CAP. 4.7µF/50V M H7CE1JMAVSL4R7
C841CHIP CERAMIC CAP.(1608) CH J 1000pF/50VCHD1JJ3CH102
C843ELECTROLYTIC CAP. 100µF/25V MCE1EMASDL101
C847CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C848CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C849CHIP CERAMIC CAP.(1608) B K 0.47µF/16VCHD1CK30B474
C851ELECTROLYTIC CAP. 3.3µF/50V MCE1JMASDL3R3
C852CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
C853CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
C854CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C855CHIP CERAMIC CAP. F Z 1µF/10VCHD1AZ30F105
Ref. No.DescriptionPart No.
C856CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C863ELECTROLYTIC CAP. 47µF/25V MCE1EMASDL470
C864ELECTROLYTIC CAP. 47µF/25V MCE1EMASDL470
C865CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C866CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C867CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C868CHIP CERAMIC CAP. B K 2200pF/50VCHD1JK30B222
C869CHIP CERAMIC CAP.(1608) B K 0.1µF/25VCHD1EK30B104
CONNECTORS
CN201FFC CONNECTOR IMSA-9615S-29A-PP-AJC96J29ER007
CN202FFC CONNECTOR IMSA-9615S-29A-PP-AJC96J29ER007
CN203242 SERIES CONNECTOR 224202108W1J322C08TG001
CN601WIRE ASSEMBLY 3PIN 3PIN/120MMWX1A94H0-213
CN801PH CONNECTOR TOP 2P B2B-PH-K-S
B21POW HEAT SINK A7120UH1EM423993
B24HEAT SINK PLT ASSEMBLY L0700UZ1EM423290
BC601WIRE COPPER 6111-06003-0120XZ40C0SHG002
BC603WIRE COPPER 6111-06003-0120XZ40C0SHG002
BC701WIRE COPPER 6111-06003-0120XZ40C0SHG002
BC702BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
BC801BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
BC804BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
BC805BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
BC806BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
BC807BEADS INDUCTOR FBR07HA121SB-00LLBF00STU030
JK701JACK RCA PCB S ORANGE 01/RCA-101H(OR) JXRJ010YUQ06
JK702JACK SW DIN PCB S 04/DIN-417HA-01JYEJ040YUQ03
JK703JACK RCA PCB S YELLOW 01/RCA-101H(YL) JXRJ010YUQ05
JK704JACK RCA PCB S WHITE 01/RCA-101H(WH)JXRJ010YUQ02
JK705JACK SW RCA PCB S RED RCA-102H(RD)JYRJ010YUQ03
JK706JACK SW DIN PCB L DIN-435C(777D)JYEL040YUQ03
JK707JACK RCA PCB L RCA-101S(1)-03JXRL010YUQ12
JK708JACK RCA PCB L RCA-101S(1)-04JXRL010YUQ13
JK709JACK SW RCA PCB L RCA-102F(RD)JYRL010YUQ05
JK712JACK RCA PCB S WHITE 01/RCA-101H(WH)JXRJ010YUQ02
JK713JACK SW RCA PCB S RED RCA-102H(RD)JYRJ010YUQ03
JK717JACK RCA PCB S GREEN 01/RCA-101H(GN) JXRJ010YUQ03
JK718JACK RCA PCB S BLUE 01/RCA-101H(BL)JXRJ010YUQ04
JK719JACK RCA PCB S RED 01/RCA-101H(RD)JXRJ010YUQ01
JK720JACK RCA PCB S WHITE 01/RCA-101H(WH)JXRJ010YUQ02
JK721JACK RCA PCB S RED 01/RCA-101H(RD)JXRJ010YUQ01
JK722JACK RCA PCB S WHITE 01/RCA-101H(WH)JXRJ010YUQ02
JK723JACK RCA PCB S RED 01/RCA-101H(RD)JXRJ010YUQ01
JS201WIRE COPPER 6111-06003-0120XZ40C0SHG002
JS801WIRE COPPER 6111-06003-0120XZ40C0SHG002
L8SCREW B-TIGHT D3X8 BIND HEAD+GBJB3080
T601#TRANS POWER 9706LTT3PC0KT056
TU101TUNER UNIT ATSC/NTSC/QAM UC020AFUTUNNTUSP035
2009072815-28A91H6EL
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
