Funai DRA-2631, DRA-2677, DRB-2737 Service manual

SERVICE MANUAL

DVD RECORDER

DR-A2677

DR-A2631

DR-B2737

TABLE OF CONTENTS

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1-1

Laser Beam Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2-1

Important Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3-1

Standard Notes for Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4-1

Cabinet Disassembly Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5-1

How to Initialize the DVD Recorder. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6-1

Firmware Renewal Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7-1

Function Indicator Symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8-1

Block Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9-1

Schematic Diagrams / CBA’s and Test Points. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10-1

Waveforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11-1

Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12-1

IC Pin Function Descriptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13-1

Lead Identifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14-1

Exploded Views. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15-1

Mechanical Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16-1

Electrical Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-17-1

Manufactured under license from Dolby Laboratories.
"Dolby" and the double-D symbol are trademarks of Dolby Laboratories.

SPECIFICATIONS

Item Conditions Unit Nominal Limit

1. VIDEO

1-1. Video Output 75 Ω load Vp-p 1.0

1-2. S-Video Output

Y (Luminance) 75 Ω load Vp-p 1.0

C (Chrominance) 75 Ω load Vp-p 0.3

2. AUDIO

2-1. Output Level Vrms 2.0

2-2. Frequency Response

DVD-VIDEO LPCM fs = 96 kHz Hz 20 - 44 k

fs = 48 kHz Hz 20 - 20 k

Audio CD fs = 44.1 kHz Hz 20 - 20 k

2-3. Signal/Noise Ratio

DVD-VIDEO LPCM dB 85

CD dB 85

REC & Playback Input: 2 Vrms, Rec Speed: SP dB 85

2-4. THD+N 1 kHz, 0 dB

DVD-VIDEO LPCM % 0.01

CD % 0.01

REC & Playback Input: 2 Vrms, Rec Speed: SP % 0.01

3. TUNER

3-1. Video Output 75 Ω load Vp-p 1.0

3-2. Video S/N dB 42

3-3. Audio Output dBv -12

3-4. Audio S/N dB 46

Notes:

1. All Items are measured without pre-emphasis unless otherwise specified.

2. Power supply: 220 - 240 V ~ 50 Hz

3. Load imp.: 100 kΩ

4. Room ambient : 5 °C ~ 40 °C

1-1-1 E6820SP

LASER BEAM SAFETY PRECAUTIONS

This DVD player uses a pickup that emits a laser beam.

Do not look directly at the laser beam coming
from the pickup or allow it to strike against your
skin.

The laser beam is emitted from the location shown in the figure. When checking the laser diode, be sure to keep
your eyes at least 30 cm away from the pickup lens when the diode is turned on. Do not look directly at the laser
beam.

CAUTION: Use of controls and adjustments, or doing procedures other than those specified herein, may result in
hazardous radiation exposure.

Drive Mechanism Assembly

Laser Beam Radiation

Laser Pickup

Turntable

Location: Top of DVD mechanism.

1-2-1 R2P_LASER

IMPORTANT SAFETY PRECAUTIONS

Product Safety Notice

Some electrical and mechanical parts have special
safety-related characteristics which are often not evi­dent from visual inspection, nor can the protection
they give necessarily be obtained by replacing them
with components rated for higher voltage, wattage,
etc. Parts that have special safety characteristics are
identified by a ! on schematics and in parts lists. Use
of a substitute replacement that does not have the
same safety characteristics as the recommended
replacement part might create shock, fire, and/or other
hazards. The Product’s Safety is under review continu­ously and new instructions are issued whenever
appropriate. Prior to shipment from the factory, our
products are carefully inspected to confirm with the
recognized product safety and electrical codes of the
countries in which they are to be sold. However, in
order to maintain such compliance, it is equally impor­tant to implement the following precautions when a set
is being serviced.

Precautions during Servicing

A. Parts identified by the ! symbol are critical for

safety. Replace only with part number specified.

B. In addition to safety, other parts and assemblies

are specified for conformance with regulations
applying to spurious radiation. These must also be
replaced only with specified replacements.
Examples: RF converters, RF cables, noise block­ing capacitors, and noise blocking filters, etc.

C. Use specified internal wiring. Note especially:

1)Wires covered with PVC tubing

2)Double insulated wires

3)High voltage leads

D. Use specified insulating materials for hazardous

live parts. Note especially:

1)Insulation tape

2)PVC tubing

3)Spacers

4)Insulators for transistors

E. When replacing AC primary side components

(transformers, power cord, etc.), wrap ends of
wires securely about the terminals before solder­ing.

F. Observe that the wires do not contact heat produc-

ing parts (heatsinks, oxide metal film resistors, fus­ible resistors, etc.).

G. Check that replaced wires do not contact sharp

edges or pointed parts.

H. When a power cord has been replaced, check that

5 - 6 kg of force in any direction will not loosen it.

I. Also check areas surrounding repaired locations.

J. Be careful that foreign objects (screws, solder

droplets, etc.) do not remain inside the set.

K. Crimp type wire connector

The power transformer uses crimp type connectors
which connect the power cord and the primary side
of the transformer. When replacing the transformer,
follow these steps carefully and precisely to pre­vent shock hazards.
Replacement procedure

1)Remove the old connector by cutting the wires at a
point close to the connector.

Important: Do not re-use a connector. (Discard it.)

2)Strip about 15 mm of the insulation from the ends
of the wires. If the wires are stranded, twist the
strands to avoid frayed conductors.

3)Align the lengths of the wires to be connected.
Insert the wires fully into the connector.

4)Use a crimping tool to crimp the metal sleeve at its
center. Be sure to crimp fully to the complete clo­sure of the tool.

L. When connecting or disconnecting the internal

connectors, first, disconnect the AC plug from the
AC outlet.

1-3-1 DVD_SFNP

Safety Check after Servicing

Examine the area surrounding the repaired location
for damage or deterioration. Observe that screws,
parts, and wires have been returned to their original
positions. Afterwards, do the following tests and con­firm the specified values to verify compliance with
safety standards.

1. Clearance Distance

When replacing primary circuit components, confirm
specified clearance distance (d) and (d’) between sol­dered terminals, and between terminals and surround­ing metallic parts. (See Fig. 1)

Table 1 : Ratings for selected area

AC Line Voltage Clearance Distance (d), (d’)

Chassis or Secondary Conductor

Primary Circuit Terminals

dd'

220 to 240 V

Note: This table is unofficial and for reference only.

Be sure to confirm the precise values.

≥ 3 mm(d)

≥ 6 mm(d’)

2. Leakage Current Test

Confirm the specified (or lower) leakage current
between B (earth ground, power cord plug prongs)
and externally exposed accessible parts (RF termi­nals, antenna terminals, video and audio input and
output terminals, microphone jacks, earphone jacks,
etc.) is lower than or equal to the specified value in the
table below.

Measuring Method (Power ON) :

Insert load Z between B (earth ground, power cord
plug prongs) and exposed accessible parts. Use an
AC voltmeter to measure across the terminals of load
Z. See Fig. 2 and the following table.

Exposed Accessible Part

Z

One side of

B

Power Cord Plug Prongs

Fig. 1

AC Voltmeter
(High Impedance)

Fig. 2

Table 2: Leakage current ratings for selected areas

AC Line Voltage Load Z Leakage Current (i)

2kΩ RES.

Connected in

220 to 240 V

Note: This table is unofficial and for reference only. Be sure to confirm the precise values.

parallel

50kΩ RES.

Connected in

parallel

i≤0.7mA AC Peak

i≤2mA DC

i≤0.7mA AC Peak

i≤2mA DC

1-3-2 DVD_SFNP

One side of power cord plug

prongs (B) to:

RF or

Antenna terminals

A/V Input, Output

STANDARD NOTES FOR SERVICING

Circuit Board Indications

1. The output pin of the 3 pin Regulator ICs is indi­cated as shown.

Top View

Input

Out

2. For other ICs, pin 1 and every fifth pin are indicated
as shown.

In

Pin 1

3. The 1st pin of every male connector is indicated as
shown.

Bottom View

5

10

Pb (Lead) Free Solder

When soldering, be sure to use the Pb free solder.

How to Remove / Install Flat Pack-IC

1. Removal

With Hot-Air Flat Pack-IC Desoldering Machine:.

(1) Prepare the hot-air flat pack-IC desoldering

machine, then apply hot air to the Flat Pack-IC
(about 5 to 6 seconds). (Fig. S-1-1)

Fig. S-1-1

Pin 1

Instructions for Connectors

1. When you connect or disconnect the FFC (Flexible
Foil Connector) cable, be sure to first disconnect
the AC cord.

2. FFC (Flexible Foil Connector) cable should be
inserted parallel into the connector, not at an angle.

FFC Cable

Connector

CBA

(2) Remove the flat pack-IC with tweezers while apply-

ing the hot air.

(3) Bottom of the flat pack-IC is fixed with glue to the

CBA; when removing entire flat pack-IC, first apply
soldering iron to center of the flat pack-IC and heat
up. Then remove (glue will be melted). (Fig. S-1-6)

(4) Release the flat pack-IC from the CBA using twee-

zers. (Fig. S-1-6)

Caution:

1. The Flat Pack-IC shape may differ by models. Use
an appropriate hot-air flat pack-IC desoldering
machine, whose shape matches that of the Flat
Pack-IC.

2. Do not supply hot air to the chip parts around the
flat pack-IC for over 6 seconds because damage to
the chip parts may occur. Put masking tape around
the flat pack-IC to protect other parts from damage.
(Fig. S-1-2)

* Be careful to avoid a short circuit.

1-4-1 DVD_NOTE

3. The flat pack-IC on the CBA is affixed with glue, so
be careful not to break or damage the foil of each
pin or the solder lands under the IC when removing
it.

Hot-air
Flat Pack-IC
Desoldering
Machine

CBA

With Soldering Iron:

(1) Using desoldering braid, remove the solder from all

pins of the flat pack-IC. When you use solder flux
which is applied to all pins of the flat pack-IC, you
can remove it easily. (Fig. S-1-3)

Flat Pack-IC

Desoldering Braid

Masking
Tape

Tweezers

Flat Pack-IC

Fig. S-1-2

Soldering Iron

Fig. S-1-3

(2) Lift each lead of the flat pack-IC upward one by

one, using a sharp pin or wire to which solder will
not adhere (iron wire). When heating the pins, use
a fine tip soldering iron or a hot air desoldering
machine. (Fig. S-1-4)

Sharp
Pin

Fine Tip
Soldering Iron

Fig. S-1-4

(3) Bottom of the flat pack-IC is fixed with glue to the

CBA; when removing entire flat pack-IC, first apply
soldering iron to center of the flat pack-IC and heat
up. Then remove (glue will be melted). (Fig. S-1-6)

(4) Release the flat pack-IC from the CBA using twee-

zers. (Fig. S-1-6)

With Iron Wire:

(1) Using desoldering braid, remove the solder from all

pins of the flat pack-IC. When you use solder flux
which is applied to all pins of the flat pack-IC, you
can remove it easily. (Fig. S-1-3)

(2) Affix the wire to a workbench or solid mounting

point, as shown in Fig. S-1-5.

(3) While heating the pins using a fine tip soldering

iron or hot air blower, pull up the wire as the solder
melts so as to lift the IC leads from the CBA con­tact pads as shown in Fig. S-1-5

1-4-2 DVD_NOTE

(4) Bottom of the flat pack-IC is fixed with glue to the

CBA; when removing entire flat pack-IC, first apply
soldering iron to center of the flat pack-IC and heat
up. Then remove (glue will be melted). (Fig. S-1-6)

(5) Release the flat pack-IC from the CBA using twee-

zers. (Fig. S-1-6)

Note:

When using a soldering iron, care must be taken
to ensure that the flat pack-IC is not being held by
glue. When the flat pack-IC is removed from the
CBA, handle it gently because it may be damaged
if force is applied.

2. Installation

(1) Using desoldering braid, remove the solder from

the foil of each pin of the flat pack-IC on the CBA
so you can install a replacement flat pack-IC more
easily.

(2) The “I” mark on the flat pack-IC indicates pin 1.

(See Fig. S-1-7.) Be sure this mark matches the 1
on the PCB when positioning for installation. Then
presolder the four corners of the flat pack-IC. (See
Fig. S-1-8.)

(3) Solder all pins of the flat pack-IC. Be sure that none

of the pins have solder bridges.

To Solid
Mounting Point

CBA

Hot Air Blower

Iron Wire

Soldering Iron

Fig. S-1-5

Fine Tip
Soldering Iron

Example :

or

Pin 1 of the Flat Pack-IC
is indicated by a " " mark.

Fig. S-1-7

Presolder

Flat Pack-IC

CBA

Fig. S-1-8

Tweezers

Flat Pack-IC

Fig. S-1-6

1-4-3 DVD_NOTE

Instructions for Handling
Semi-conductors

Electrostatic breakdown of the semi-conductors may
occur due to a potential difference caused by electro­static charge during unpacking or repair work.

1. Ground for Human Body

Be sure to wear a grounding band (1MΩ) that is prop­erly grounded to remove any static electricity that may
be charged on the body.

2. Ground for Workbench

(1) Be sure to place a conductive sheet or copper plate

with proper grounding (1MΩ) on the workbench or
other surface, where the semi-conductors are to be
placed. Because the static electricity charge on
clothing will not escape through the body ground­ing band, be careful to avoid contacting semi-con­ductors with your clothing.

< Incorrect >

< Correct >

1MΩ

CBA

Grounding Band

1MΩ

CBA

Conductive Sheet or
Copper Plate

1-4-4 DVD_NOTE

CABINET DISASSEMBLY INSTRUCTIONS

1. Disassembly Flowchart

This flowchart indicates the disassembly steps to gain
access to item(s) to be serviced. When reassembling,
follow the steps in reverse order. Bend, route, and
dress the cables as they were originally.

[9] Fan

[8] Fan Cover

[1] Top Cover

[2] Front Assembly

[3] DVD Mechanism & DVD Main CBA Assembly

[4] SW CBA

[5] PCB Holder

[10] Rear Panel

[11] AV CBA

[12] Jack CBA [13] AFV CBA

[6] Power Supply CBA

[7] Power Holder

2. Disassembly Method

ID/

Loc.

No.

[1] Top Cover D1 7(S-1) ---

[2]

[3]

[4] SW CBA D4 (S-3), Desolder ---

[5] PCB Holder D4 2(S-4) ---

[6]

[7] Power Holder D4 (S-6) ---

[8] Fan Cover D5 2(S-7) ---

[9] Fan D5 Fan Earth, *CN1202 ---

[10] Rear Panel D5

Part

Front
Assembly

DVD
Mechanism &
DVD Main CBA
Assembly

Power Supply
CBA

Fig.

No.

D2 *6(L-1), *3(L-2) 1

D3

D4 3(S-5), *CN1201 ---

Removal

Remove/*Unhook/

Unlock/Release/

Unplug/Desolder

4(S-2), *CN501,
*CN601

(S-8),
7(S-9)---[DR-A2631]
8(S-9)---[DR-A2677/
DR-B2737]

Note

---

---

[11] AV CBA D6 3(S-10) ---

[12] Jack CBA D6 Desolder ---

[13] AFV CBA D6 Desolder ---

↓

(1)

Note:

(1) Identification (location) No. of parts in the figures

(2) Name of the part

(3) Figure Number for reference

(4) Identification of parts to be removed, unhooked,

unlocked, released, unplugged, unclamped, or
desoldered.
P = Spring, L = Locking Tab, S = Screw,
CN = Connector
* = Unhook, Unlock, Release, Unplug, or Desolder
e.g. 2(S-2) = two Screws (S-2),
2(L-2) = two Locking Tabs (L-2)

(5) Refer to “Reference Notes.”

↓

(2)

↓

(3)

↓

(4)

(5)

Reference Notes

1. CAUTION 1: Locking Tabs (L-1) and (L-2) are
fragile. Be careful not to break them.

↓

1-5-1 E68C4DC

[1] Top Cover

(S-1)

(S-1)

(S-1)

Fig. D1

(S-6)

[7] Power
Holder

(S-5)

[6] Power Supply CBA

(S-5)

[4] SW CBA

Desolder

(S-3)

[8] Fan Cover

Fan Earth

CN1201

(S-4)

[5] PCB
Holder

Fig. D4

(S-7)

[2] Front
Assembly

(L-1)

(L-2)

(S-2)

(L-1)

(S-2)

(L-1)

Fig. D2

[3] DVD Mechanism
& DVD Main
CBA Assembly

CN501

CN601

[10] Rear Panel

CN1202

(S-10)

[9] Fan

[DR-A2677/

DR-B2737]

(S-9)

[13] AFV CBA

[12] Jack CBA

(S-10)

(S-9)

(S-8)

Fig. D5

Fig. D3

[11] AV CBA

Desolder

Fig. D6

1-5-2 E68C4DC

3. How to Eject Manually

< Method 1 >

Note: When servicing, do not touch white resin part as shown below.

When rotating the gear, be careful not to damage the gear.

1. Remove the Top Cover.

2. Rotate the gear in the direction of the arrow manually as shown below.

View for A

Do not touch!

Rotate this gear in
the direction of the arrow

A

1-5-3 E68C4DC

< Method 2 >

Note: When servicing, do not touch white resin part

as shown below.

1. Remove the Top Cover, the Front Assembly and
the DVD Mechanism & DVD Main CBA Assembly.
Then, remove the DVD Mechanism Unit.

2. Remove two screws, and remove the Insulating
Plate.

Screw

Insulating Plate

4. Release the other side of two Locking Tabs, and
remove the Clamper Assembly.

Clamper Assembly

Locking Tabs

5. Remove the disc.

Disc

Do not touch!

3. Release two Locking Tabs, and lift up one side of
the Clamper Assembly.

Clamper Assembly

Locking Tabs

1-5-4 E68C4DC

HOW TO INITIALIZE THE DVD RECORDER

To put the program back at the factory-default,
initialize the DVD recorder as the following procedure.

1. Turn the DVD recorder on.

2. Confirm that no disc is loaded or that the disc tray
is open. To put the DVD recorder into the Version
display mode, press [CM SKIP], [1], [2], and [3]
buttons on the remote control in that order.
Fig. a appears on the screen.

*1: "
*2: Firmware Version differs depending on the
models, and this indication is one example.

Fig. a Version Display Mode Screen

" differs depending on the models.

*******

F/W VERSION

Model Name :

Firmware Version
BE :
FE :
API :
TT :

DEFAULT SETTING : ENTER
EXIT : RETURN

*******

R2E3030S2S
R20_048_000
Ver 1.08
T20191FSP

3. Press [ENTER] button, then the DVD recorder
starts initializing. When the initializing is
completed, the DVD recorder exits the Version
display mode and turns off the power
automatically.

* To move into the Normal mode from the

Version display mode, press [RETURN] button
on the remote control instead of [ENTER]
button.

* When [STANDBY-ON] button is pressed

before [ENTER] button is pressed, the DVD
recorder exits the Version display mode, then
the power turns off.

1-6-1 E6820INT

FIRMWARE RENEWAL MODE

1. Turn the power on and remove the disc on the tray.

2. To put the DVD recorder into version up mode,
press [CM SKIP], [6], [5], and [4] buttons on the
remote control unit in that order. Then the tray will
open automatically.
Fig. a appears on the screen and Fig. b appears
on the VFD.

* Firmware Version differs depending on the
models, and this indication is one example.

Firm Update Mode

Please insert a disc.

Fig. a Version Up Mode Screen

Fig. b VFD in Version Up Mode

ver. R2E3030S2S

Current
F/W version
is displayed.

4. Select the firmware version pressing arrow
buttons, then press [ENTER].
Fig. d appears on the screen and Fig. e appears
on the VFD. The DVD recorder starts updating.

About VFD indication of Fig. e:

1) When Fig. d is displayed on the screen, “F-UP”

is displayed on the VFD.

2) When “Firmware Updating... XX% Complete.”

is displayed on the screen, “XX”% is displayed
on the VFD.

* Firmware Version differs depending on the
models, and this indication is one example.

Selected
F/W version
is displayed.

Firm Update Mode

R2E3030S2S

File Loading...
(*1)

Fig. d Programming Mode Screen

ver.

R2E3030S2S

3. Load the disc for version up.
Fig. c appears on the screen. The file on the top is
highlighted as the default.
When there is only one file to exist, Step 4 will
start automatically.

* Firmware Version differs depending on the
models, and this indication is one example.

Firm Update Mode ver. R2E3030S2S

Disc name
is displayed.

VOL_200408250934

1 R2E3030S2S
2 R2E3031S2S
3 R2E3032S2S
4 R2E3033S2S

Fig. c Update Disc Screen

1 / 1

Files included
in the disc are
displayed.

Fig. e VFD in Programming Mode (Example)

The appearance shown in (*1) of Fig. d is
described as follows.

No. Appearance State

1 File Loading... Sending files into the memory

Firmware

2

Updating...

Writing new version data

XX% Complete.

Firmware

--­Update Failure

Failed in updating

1-7-1 E6820FW

5. After updating is finished, the tray opens
automatically.
Fig. f appears on the screen and Fig. g appears on
the VFD.

* Firmware Version differs depending on the
models, and this indication is one example.

Firm Update Mode ver. R2E3030S2S

R2E3030S2S

B/E Firmware

Update End

Fig. f Completed Program Mode Screen

Fig. g VFD in Completed Program Mode

At this time, no button is available.

6. Press [STANDBY-ON] button to turn the power off.
Then press it again.

1-7-2 E6820FW

FUNCTION INDICATOR SYMBOLS

Note: If an error occurs, a message with the error number appears on the screen.

Recording Error

Message Solution

Can not record on this disc.

This program is not allowed to
be recorded.

This program is not recordable
in Video mode.

This program is not allowed to
be recorded on this disc.

You cannot record on this disc as
Power Calibration Area is full.

Insert the recordable disc, and
ensure the disc status satisfies
the recording requirements.

You cannot record copy
prohibited programs.

Set “DVD-RW Recording
Format” to “VR mode”.

Insert a ver.1.1 CPRM
compatible DVD-RW disc.

Error message

E35

Error

No.

1 An error occurs during data reading. -

2

3

4 An error occurs with OPC. -

5 During recovery in a record. -

6

7 An error occurs in a format. -

8 It cannot start an encode. -

9

10

11

12

13 It is a reply that “ATAPI is not readable.” -

14

15

16 An error occurs in Finalize Close. -

17 An error occurs in Rec Stop Close. -

18 An error occurs in PCA Full (DVD_R). -

19 Safety Stop occurs during editing. -

20 High Speed Disc. 2

21 The disc which is not formatted. 5

22 The disc that Disc Error occurred. 3

23 The -R Disc of VR Mode. 6

24

25 During the Macrovision picture input. 11

26 During the CGMS picture input. 12

27

28

Error No.

Error Description Priority

There is no reply for 15 seconds in Test
Unit Ready.

Cannot write the data after trying to write
three times.

An error occurs even if it do recovery of a
record three times.

There is not NV_PCK/RDI_PCK in data
doing an encode.

Encode Pause condition continued for 10
minutes.

Encode Pause condition continued by
normal REC condition for 10 minutes.

Differ in an address and do not get
StreamID of RDI/VIDEO.

Cannot write the data after recovering
SMALL VMGI.

Cannot write the data after DVD-R
Reverse Track.

The disc except DVD-R/RW or DVD-R
finalized disc

During the CGMS picture (possible a
record once) input. (Video Format Disc)

During the CGMS picture (possible a
record once) input. (Disc which there is
not for the correspondence to VR Format
CPRM)

-

-

-

-

-

-

-

-

-

1

12

12

1-8-1 E68C4FIS

Message Solution

This disc is protected and not
recordable.

Disc is full.
(No area for new recording)

You cannot record more than
99 titles on one disc.
(The maximum is 99.)

You cannot record more than
999 chapters on one disc.
(The maximum is 999.)

You cannot record on this disc
as Control Information is full.

You cannot record on the disc
as Power Calibration Area is
full.

This disc is already finalized.

Can not record on this disc. Repeat the same operation.

Release the disc protect
setting in the Disc Setting
menu.

Insert the recordable disc with
enough recording space.

Delete unnecessary titles.

Delete unnecessary chapter
markers.

Delete unnecessary titles. 34

Insert a new disc. 35 PCA Full. (in REC start) 4

Release the finalizing for this
disc.

Error

No.

Error Description Priority

29 Disc Protected Disc. 7

30 There is no it in a space field. 5

It is recorded a 99 title. (Video Format

31

Disc)

32 It is recorded a 99 title. (VR Format Disc) 8

There is 999 number of total chapter. (VR

33

Format Disc)

There is not a space to a record field of
control information.

36 It is done Finalize. (Video Format Disc) 6

37 Access to Memory Area range outside. -

38 Sector Address is wrong. -

39 BUP writing error of chapter editing. -

7

9

10

If an error occurs during the timer recording, one of the following error numbers (40 to 42) or the above error
messages (error number: 1 to 39) is displayed on the recording menu after timer recording.
(Once the screen of the program line is exited, the program line for the error will be cleared.)
(No Error Message is displayed for the error No. 40 ~ 42.)

Example: DR-A2631

Timer Programming

Date Start End CH Speed

A program with the error number is grayed out and asterisked on the timer programming list.

Message Solution

Error message is not
displayed.

01/01 12:00 13:00 P01 E40

*

2. ---

3. ---

4. ---

5. ---

6. ---

7. ---

8. ---

Error

No.

- Set the timer programming
correctly.

- Set the timer programming
before the start time.

- Insert a recordable videotape
with a record tab.

Turn the power on and set the
clock correctly then set timer
programming again.

Insert the recordable disc. 42 No disc when recording -

- Some portion has not been recorded

40

because of program overlapping.

- Recording did not start at the start time.

41 Power failed -

The speed mode changes
to the error number.

Error Description Priority

-

1-8-2 E68C4FIS

BLOCK DIAGRAMS

System Control Block Diagram

A

B

C

Model Mark

DR-A2677

Q1222

IC1206

DR-A2631

EV+3.3V

RESET

1 2

14

RESET

Comparison Chart of

Models & Marks

DR-B2737

30

P-DOWN

EV+5V

Q1224

C1231

7

VCC

(BACKUP CAPACITOR)

VFD

FL1203

GRID

~

23

17

~

7G

1G

(VFD DRIVER)

CLK

DIN

IC1205

1

28

485049

FL-DIN

FL-CLK

STB

2

27

FL-STB

REMOTE

7

a

~

~

RM1201

SEGMENT

16

14

i

h

SENSOR

REMOTE

FAN

FAN+12V2GND

1

CN1202

FAN CONTROL

Q1205,Q1206

55

FAN-CONT2

FAN-AL+12V

TO VIDEO INPUT SELECT

BLOCK DIAGRAM

TO AUDIO

BLOCK DIAGRAM

SCL

SDA

SDA

AUDIO-MUTE

38

AUDIO-MUTE

SCL

TU1201(TUNER UNIT)

6

5

IC1215

(5V<-->3.3V LEVEL CONVERTER)

3

2

33

34

SUB-SCL

SUB-SDA

SCL

11

SDA

12

TO AUDIO

BLOCK DIAGRAM

RGB THROUGH

17

RGB THROUGH

SELECT BLOCK DIAGRAM

TO VIDEO INPUT SELECT

BLOCK DIAGRAM

DAVN-L

RGB THROUGH TO VIDEO OUTPUT

24

DAVN-L

A,C

IC1207

(SUB MICRO CONTROLLER)

REG-CONT

52

J908

J906

REG-CONT

PWSW

TO POWER SUPPLY

BLOCK DIAGRAM

VIDEO-SW1

41

42 VIDEO-SW2

43 VIDEO-SW3

VIDEO-SW1

VIDEO-SW2

VIDEO-SW3

TO VIDEO INPUT/OUTPUT

SELECT BLOCK DIAGRAM

OSC2

8

X1202

8MHz

OSC1

9

RESONATOR

X OUT

12

32.768KHz

X1201

X IN

11

X'TAL

IC601

(MAIN MICRO CONTROLLER)

SUB-RXD

SYS-RESET

2219182029

CN1204

30 30SYS-RESET

29 29SUB-RXD

CN601

V7A2Y2

SUB-RXD

SYS-RESET

SUB-TXD

SUB-SCLK

RDY

27 27SUB-TXD

25 25SUB-SCLK

28 28RDY

H2

U8

RDY

SUB-TXD

SUB-SCLK

X802

27MHz

X'TAL

M1

CLK 27 IN

N1

CLK 27 OUT

EV+2.4VP-ON+1.5V

+1.5V

IC1501

REGULATOR

REG-CONT2

26

26 26REG-CONT2

CN601 CN1204

KEY-1

KEY-2

1

2

AV CBA

1

2

CN1205

KEY-1

KEY-2

1

2

CN3001

KEY SWITCH

SW CBA

KEY SWITCH

DVD MAIN CBA

1-9-1

E68C4BLS

Digital Signal Process Block Diagram

TO VIDEO

OUTPUT

SELECT

BLOCK

DIAGRAM

BCK

VIDEO-Y

VIDEO-G

VIDEO-C

VIDEO-B

VIDEO-R

VIDEO-C

VIDEO-Y/CVBS

SPDIF

DATA

LRCK

MD

MC

TO AUDIO

INPUT/

MS

OUTPUT

BLOCK

DIAGRAM

SCK

LRCK

BCK

DATA

SYSCLK

REC VIDEO SIGNAL PB VIDEO SIGNAL REC AUDIO SIGNAL PB AUDIO SIGNAL

IC601 (MPEG2 AV CODEC)IC201

J18

D/A

H18

D/A

K18

D/A

VIDEO

ENCODER

VIDEO

I/F

H19

D/A

G19

D/A

V15

W17

VIDEO

DECODER

BACK-END

DIGITAL

SIGNAL

FRONT-END

E20

PROCESS

DIGITAL

SIGNAL

T20

N19

PROCESS

M19

V4W4V3

AUDIO

H20

G20

F20

FLASH MEMORY

IC604 (FLASH MEMORY)

DDR SDRAM

IC602,IC603 (DDR SDRAM)

P19

U20

I/F

SDRAM

IC204

IC101

DVD MECHANISM

RF/

ERROR AMP

IC102

CN101

LPC

TILT

PICK

IC402

TRACKING

-UP

FOCUS

MOTOR

DRIVER

CN1003

1-9-2

FE

ENCODER

IC410

ENCODER CBA

OP AMP

CN401

CN1001

TRAY OPEN

IC202

+3.3V

FLASH

MEMORY

LOADER CBA

IC401

SLED

MOTOR

M

MOTOR

DRIVER

CN1002

SPINDLE

MOTOR

DVD MAIN CBA

RELAY CBA

M

E68C4BLD

Video Input Select Block Diagram

JK1211

S-VIDEO

IN3

(REAR)

C

REC VIDEO SIGNAL

TO VIDEO

OUTPUT SELECT

BLOCK DIAGRAM

VIDEO-OUT2

VIDEO-OUT1

2

1

3 4

Y

JK1212

C

3 4

Y

S-VIDEO

IN4

(FRONT)

2

1

VIDEO-IN4

JK1201

(FRONT)

30

31

DRIVER

BUFFER

6dB

AMP

IC1219 (VIDEO INPUT SELECT)

TU1201 (TUNER UNIT)

28

24

VIDEO OUT

1

29

DRIVER

6dB

AMP

3

5

DVD-VIDEO

TO VIDEO

OUTPUT SELECT

BLOCK DIAGRAM

CONTROL

33

LOGIC

32

(VIDEO INPUT SELECT)IC1209

13

Y1

LPF

BUFFER

19

BUFFER

Q1232

15

MUTE

Y2

10

12

TU/LINE

VIDEO4

20

MUTE

2214

C1

Q1231

MUTE

C2

BUFFER LPF

BUFFER

CONTROL

LOGIC

22 23 24

TO SYSTEM CONTROL

VIDEO-SW2

VIDEO-SW1

VIDEO-SW3

BLOCK DIAGRAM

SDA

DAVN-L

DAVN-L

6147

SDA

SCL

SCL

AV CBA

16

VPS-V

A

B

Model Mark

DR-A2677

Comparison Chart of

Models & Marks

DR-A2631

JK1206

C

DR-B2737

20

VIDEO IN

CN2001 CN1210

JK2001

10

VIDEO-IN2

10

20

VIDEO2 IN

IC1220 (VPS)

CN1204

VIDEO-Y/CVBS

21 21

23 23VIDEO-C

CN601

A,C

JACK CBA

VIDEO-Y/CVBS

VIDEO-C

DVD MAIN CBA

TO DIGITAL

SIGNAL

PROCESS

BLOCK

DIAGRAM

1-9-3

E68C4BLVIS

Video Output Select Block Diagram

JK1213

S-VIDEO

OUT

2

1

3 4

YC

REC VIDEO SIGNAL PB VIDEO SIGNAL

C1407

VIDEO-OUT1

19

JK1206

VIDEO-G OUT

VIDEO-B OUT

VIDEO-R OUT

RGB-SW

7

11

15

16

TO SYSTEM CONTROL

BLOCK DIAGRAM

RGB-THROUGH

5

6

DRIVER

2dB

AMP

8dB

-6dB

LPF DRIVER

4dB

AMP

IC1223 (VIDEO DRIVER)

3

AMP

7

2dB

AMP

LPF DRIVER

4dB

AMP

1

WF3

DVD-VIDEO

VIDEO-OUT2

VIDEO-OUT1

TO VIDEO INPUT SELECT

BLOCK DIAGRAM

11

2dB

AMP

2dB

LPF DRIVER

4dB

4dB

AMP

IC1226 (VIDEO DRIVER)

6

15

IC1221 (SW)

1

2

3

15

AMP

LPF DRIVER

AMP

1

4

5

10

2dB

AMP

LPF DRIVER

4dB

AMP

8

14

13

12

SW

AV CBA

Q1254

9 10 11

CONTROL

P-ON+3.3V

WF1

WF4

CN1204

11VIDEO-Y

CN601

VIDEO-G

VIDEO-Y

TO DIGITAL

7

VIDEO-G
7

99VIDEO-C

VIDEO-C

VIDEO-B

SIGNAL

PROCESS

BLOCK

5

3

VIDEO-B

VIDEO-R

5

3

VIDEO-R

DIAGRAM

WF6

WF2

WF5

1-9-4

Q1240

8

CN1210

13

VIDEO-G-IN

VIDEO-OUT2
8

13

CN2001

12

11

VIDEO-B-IN

VIDEO-R-IN14 14

RGB-SW

12

11

Q1246

Q1252

JACK CBA

JK2001

7

111915

16

DVD MAIN CBA

RGB-SW

VIDEO-B IN

VIDEO-R IN

VIDEO-G IN

VIDEO OUT2

E68C4BLVOS

Audio Block Diagram

AUDIO(R)-IN2

AUDIO(L)-OUT2

AUDIO(R)-OUT2

AUDIO(L)-IN26

2

1

3

JK2001

AUDIO(L)-IN16

JK1206

JACK CBA

REC AUDIO SIGNAL PB AUDIO SIGNAL

CN2001

AUDIO(L)-IN2

AUDIO(R)-IN2

AUDIO(L)-OUT2

AUDIO(R)-OUT2

66

55

11

33

MUTE-ON

Q2002

MUTE-ON

Q2001

2

AUDIO-MUTE
2

AUDIO(R)-IN1

AUDIO(L)-OUT1

AUDIO(R)-OUT1

2

1

3

Q1258

Q1257

AFV CBA

MUTE-ON

MUTE-ON

IF SIGNAL

PROCESS

CN1

SIF

TU-AUDIO(R)

TU-AUDIO(L)

22

55

44

CN1209

SIF OUT

TU1201 (TUNER UNIT)

22

Q1244

JK1210

AUDIO(L)

-OUT

MUTE-ONDRIVE

Q1255

Q1245

AUDIO(R)

-OUT

MUTE-ON

Q1256

JK1204

TO SYSTEM

CONTROL

BLOCK DIAGRAM

AUDIO-MUTE

RGB-THROUGH

AUDIO(L)

-IN3

AUDIO(R)

-IN3

JK1202

AUDIO(L)

-IN4

AUDIO(R)

JK1203

-IN4

CN1210

8

10

24

BUFFER

IC1219 (INPUT/OUTPUT SELECT)

27

DIGITAL

AUDIO OUT

(COAX1AL)

JK1209

6

AMP

AMP

DIGITAL

AUDIO OUT

(OPTICAL)

FIBER OPTIC

TRANS MODULE

JK1207

26

25

DRIVER

DRIVER

A,C

14

BUFFER

23

162012

AMP

LOGIC

333213

SCL

AV CBADVD MAIN CBA

22

21

425

1

7

AMP

DRIVER

DRIVER

CONTROL

15

SDA

(OP AMP)IC1222

WF7

OP AMP

2

OP AMP

6

IN3

TU/IN1/2

(L-CH)

(AUDIO INPUT SELECT)

IC1208

)

OP AMP

(

IC1216

3

6

OP

7

AMP

IN4

TU/IN1/2

(R-CH)

111121514

IN3

13

2

OP

AMP

1

IN4

SW CTL

9

10

Q1247

A

B

Model Mark

DR-A2677

Comparison Chart of

DR-A2631

Models & Marks

BUFFER

C

DR-B2737

CN1203

11SPDIF

CN501

SPDIF

WF8

TO SYSTEM CONTROL

BLOCK DIAGRAM

IC901

(AUDIO D/A CONVERTER)

1-9-5

768

BCK

DATA

AUDIO(L)-OUT

AUDIO(R)-OUT

17 17

15 15

CN601 CN1204

151416

L-CH

R-CH

MUTE

AUDIO D/A

LRCKMDMC

AUDIO(L)-IN

AUDIO(R)-IN

DVD-AUDIO-MUTE
19 19

13 13

11 11

CONVERTER

4

3

SCK2ML

5

TO DIGITAL

SIGNAL

PROCESS

BLOCK

DIAGRAM

IC902

(AUDIO A/D CONVERTER)

1

R-CH

L-CH

101112

BCK

LRCK

2

AUDIO A/D

CONVERTER

15

DATA

SYSCLK

E68C4BLA

Power Supply Block Diagram

CAUTION !

Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.

If Main Fuse (F1001) is blown , check to see that all components in the power supply

circuit are not defective before you connect the AC plug to the AC power supply.

Otherwise it may cause some components in the power supply circuit to fail.

TO

SYSTEM

CONTROL

BLOCK

DIAGRAM

PWSW

EV+32V

MAIN CBA

AL+12V

FAN-AL+12V

131211

131211

CN1106

SW+10V P-ON+10V

Q1228

Q1215,Q1217

10

10

P-ON+12V

SW+12V

9

9

EV+5V

Q1221

EV+3.3V

SW+3.3V

REG.

IC1211

P-ON+5V

SW+5V

Q1218

VIDEO+5V

Q1214

P-ON+3.3V

P-ON+5V

SW+5V

TO DVD MAIN

CBA CN501

CN1203

IC1212

CN1201

7 7

CN1106

21 P-ON+2.5V

22 P-ON+2.5V

20 P-ON+2.5V

IC1213

+2.5V REG.

5 5

2 2

3 3

25 P-ON+3.3V

26 P-ON+3.3V

27 P-ON+3.3V

+3.3V REG.

1 1

11 P-ON+5V

12 P-ON+5V

Q1213

4 EV+10.5V

5 EV+10.5V

13 P-ON+5V

6 EV+10.5V

14 EV+2.4V

TO SYSTEM CONTROL

BLOCK DIAGRAM

REG-CONT

15 EV+2.4V

16 EV+2.4V

17 EV+2.4V

F2

AL-30V

EV-5V

F1

2

1

AL+5V

3 AL+12V31

12

RECTIFIER

AL+5V

5 AL+44V54 FAN-AL+12V42

CN1103 CN1105 CN1201

NOTE:

The voltage for parts in hot circuit is measured using

hot GND as a common terminal.

11

T1001

3

BRIDGE

D1001 - D1004

JUNCTION

7

7 EV+3V

CN1102 CN1104

5 AL+4V 5

3

3 AL-30V

2F2 2

1

F1

1

CBA

COLD

Q1101

13

14

15

16

17

18

19

20

5

Q1003

Q1002

7

8

IC1001

ERROR

VOLTAGE DET

1

4

23

POWER SUPPLY CBA

LINE

FILTER

L1004

CAUTION !

For continued protection against fire hazard,

replace only with the same type fuse.

F1001

HOT CIRCUIT. BE CAREFUL.

T1.6A L 250V

AC1001

1-9-6

Q1001

HOT

E68C4BLP

SCHEMATIC DIAGRAMS / CBA’S AND TEST POINTS

Standard Notes

WARNING

Many electrical and mechanical parts in this chassis
have special characteristics. These characteristics
often pass unnoticed and the protection afforded by
them cannot necessarily be obtained by using
replacement components rated for higher voltage,
wattage, etc. Replacement parts that have these
special safety characteristics are identified in this
manual and its supplements; electrical components
having such features are identified by the mark " ! "
in the schematic diagram and the parts list. Before
replacing any of these components, read the parts list
in this manual carefully. The use of substitute
replacement parts that do not have the same safety
characteristics as specified in the parts list may create
shock, fire, or other hazards.

Notes:

1. Do not use the part number shown on these
drawings for ordering. The correct part number is
shown in the parts list, and may be slightly different
or amended since these drawings were prepared.

2. All resistance values are indicated in ohms

3

(K=10

3. Resistor wattages are 1/4W or 1/6W unless
otherwise specified.

4. All capacitance values are indicated in µF
(P=10

5. All voltages are DC voltages unless otherwise
specified.

6. Electrical parts such as capacitors, connectors,
diodes, IC’s, transistors, resistors, switches, and
fuses are identified by four digits. The first two
digits are not shown for each component. In each
block of the diagram, there is a note such as shown
below to indicate these abbreviated two digits.

, M=106).

-6

µF).

1-10-1 R2P_SC

LIST OF CAUTION, NOTES, AND SYMBOLS USED IN THE SCHEMATIC DIAGRAMS ON
THE FOLLOWING PAGES:

1. CAUTION:

FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE FUSE.

2. CAUTION:

Fixed Voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F1001) is blown, first check to see that all components in the power supply circuit are not
defective before you connect the AC plug to the AC power supply. Otherwise it may cause some components
in the power supply circuit to fail.

3. Note:

1. Do not use the part number shown on the drawings for ordering. The correct part number is shown in the

parts list, and may be slightly different or amended since the drawings were prepared.

2. To maintain original function and reliability of repaired units, use only original replacement parts which are

listed with their part numbers in the parts list section of the service manual.

4. Voltage indications for PLAY and REC mode on the schematics are as shown below:

2

1

(Unit: Volt)

The same voltage for
both PLAY & REC modes

5.0

3

5.0
(2.5)

Indicates that the voltage
is not consistent here.

PLAY mode
REC mode

5. How to read converged lines

1-D3

Distinction Area

Line Number
(1 to 3 digits)

Examples:

1. "1-D3" means that line number "1" goes to the line number
"1" of the area "D3".

2. "1-B1" means that line number "1" goes to the line number
"1" of the area "B1".

6. Test Point Information

: Indicates a test point with a jumper wire across a hole in the PCB.

: Used to indicate a test point with a component lead on foil side.

: Used to indicate a test point with no test pin.

: Used to indicate a test point with a test pin.

3

AREA D3

2

1

AREA B1

1-D3

ABCD

1-B1

1-10-2 R2P_SC

DVD Main 1/6 Schematic Diagram

1-10-3

E68C4SCD1

DVD Main 2/6 Schematic Diagram

1-10-4

E68C4SCD2

DVD Main 3/6 Schematic Diagram

1-10-5

E68C4SCD3

DVD Main 4/6 Schematic Diagram

NOTE:

1. The order of pins shown in this diagram is different from that of actual IC601.

2. IC601 is divided into six and shown as IC601 (1/6) ~ IC601 (6/6) in this DVD Main Schematic Diagram Section.

1-10-6

E68C4SCD4

DVD Main 5/6 Schematic Diagram

NOTE:

1. The order of pins shown in this diagram is different from that of actual IC601.

2. IC601 is divided into six and shown as IC601 (1/6) ~ IC601 (6/6) in this DVD Main Schematic Diagram Section.

1-10-7

E68C4SCD5

DVD Main 6/6 Schematic Diagram

NOTE:

1. The order of pins shown in this diagram is different from that of actual IC601.

2. IC601 is divided into six and shown as IC601 (1/6) ~ IC601 (6/6) in this DVD Main Schematic Diagram Section.

1-10-8

E68C4SCD6

AV 1/6 Schematic Diagram

*1 NOTE

IC1206

BU4219G-TR

PST3619NR

Group A Group B

C1225 0.015 0.1

These components (IC1206, C1225)
can be used in any models.
However, you cannot mix components under
Group A with the ones under Group B.
You can choose either Group. The difference
between Group A and Group B is shown below.

Comparison Chart of
Models and Marks

MODEL MARK

DR-A2677 A
DR-A2631 B
DR-B2737 C

1-10-9

E68C4SCAV1

AV 2/6 Schematic Diagram

5G 4G 3G 2G 1G

7G

6G

a

d

g

h

h

g

c

b

ef

REPEAT

PM

REC

VCD VCR

DVD

R

XP SP
LP EP

SLP

P.SCAN

SEP

W

CD

T C

7G 6G 5G 4G 3G 2G 1G

a

b

c

d

e

f

g

c

d

e

f

gg

c

d

e

f

g

c

d

e

f

g

c

d

e

f

g

c

d

e

f

g

hh

i

ababababa

b

FL1203 MATRIX CHART

REPEAT

PM

REC

VCD VCR DVD

R

XP
SP
LP
EP

SLP

P.SCAN

SEP

W

CD

T

C

1-10-10

E68C4SCAV2

AV 3/6 Schematic Diagram

Comparison Chart of
Models and Marks

MODEL MARK

DR-A2677 A
DR-A2631 B
DR-B2737 C

1-10-11

E68C4SCAV3

AV 4/6 Schematic Diagram

1-10-12

E68C4SCAV4

AV 5/6 Schematic Diagram

Comparison Chart of
Models and Marks

MODEL MARK

DR-A2677 A
DR-A2631 B
DR-B2737 C

1-10-13

E68C4SCAV5

AV 6/6 Schematic Diagram

1-10-14

E68C4SCAV6

Power supply & Junction Schematic Diagram

CAUTION !

Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F1001) is blown , check to see that all components in the power supply
circuit are not defective before you connect the AC plug to the AC power supply.
Otherwise it may cause some components in the power supply circuit to fail.

CAUTION !

For continued protection against fire hazard,
replace only with the same type fuse.

NOTE:

The voltage for parts in hot circuit is measured using
hot GND as a common terminal.

1-10-15

E68C4SCP

AFV Schematic Diagram

Comparison Chart of
Models and Marks

MODEL MARK

DR-A2677 A
DR-A2631 B
DR-B2737 C

1-10-16

E68C4SCAFV

Jack Schematic Diagram

SW Schematic Diagram

E68C4SCJ E68C4SCSW

1-10-17

AV CBA Top View

1-10-18 BE6800F01011A

AV CBA Bottom View

WF3

C1407
PLUS LEAD

WF8

PIN 1 OF
CN1203

WF1

PIN 1 OF
CN1204

WF6

PIN 3 OF
CN1204

WF5

PIN 5 OF
CN1204

WF4

PIN 7 OF
CN1204

WF2

PIN 9 OF
CN1204

WF7

PIN 17 OF
CN1204

1-10-19

BE6800F01011A

Power supply CBA Top View

Because a hot chassis ground is present in the power
supply circut, an isolation transformer must be used.
Also, in order to have the ability to increase the input
slowly, when troubleshooting this type power supply
circuit, a variable isolation transformer is required.

CAUTION !

For continued protection against fire hazard,
replace only with the same type fuse.

NOTE:

The voltage for parts in hot circuit is measured using
hot GND as a common terminal.

CAUTION !

Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F1001) is blown , check to see that all components in the power supply
circuit are not defective before you connect the AC plug to the AC power supply.
Otherwise it may cause some components in the power supply circuit to fail.

1-10-20

BE6800F01021A

Power supply CBA Bottom View

Because a hot chassis ground is present in the power
supply circut, an isolation transformer must be used.
Also, in order to have the ability to increase the input
slowly, when troubleshooting this type power supply
circuit, a variable isolation transformer is required.

CAUTION !

For continued protection against fire hazard,
replace only with the same type fuse.

NOTE:

The voltage for parts in hot circuit is measured using
hot GND as a common terminal.

CAUTION !

Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F1001) is blown , check to see that all components in the power supply
circuit are not defective before you connect the AC plug to the AC power supply.
Otherwise it may cause some components in the power supply circuit to fail.

1-10-21

BE6800F01021A

SW CBA Bottom ViewSW CBA Top View

BE6800F01011B

Jack CBA Top View Jack CBA Bottom View

Junction CBA

Top View

Junction CBA

Bottom View

1-10-22

BE6800F01021C

BE6800F01021B

AFV CBA Top View

AFV CBA Bottom View

1-10-23

BE6800F01091

WF1

Pin 1 of CN1204

WAVEFORMS

NOTE:

Input: COLOR BAR SIGNAL
(WITH 1KHz AUDIO SIGNAL)

WF5

Pin 5 of CN1204

VIDEO-Y 0.2V 20µsec

WF2

Pin 9 of CN1204

VIDEO-C 0.2V 20

WF3

C1407 PLUS LEAD

VIDEO-B

WF6

Pin 3 of CN1204

µ

sec

VIDEO-R

WF7

Pin 17 of CN1204

0.2V 20µsec

0.2V 20µsec

VIDEO-CVBS 0.5V 20

WF4

Pin 7 of CN1204

VIDEO-G

0.2V 20µsec

µ

sec

1-11-1

AUDIO(L)-OUT

WF8

Pin 1 of CN1203

SPDIF 1V 0.1

1V 0.1µsec

µ

sec

E6820WF

AC CORD

A

Model Mark

DR-A2677

Comparison Chart of

Models & Marks

VIDEO

IN4

AUDIO(R)

IN4

FRONT

AUDIO(L)

IN4

S-VIDEO

IN4

DIGITAL

AUDIO OUT

(COAXIAL)

DIGITAL

AUDIO OUT

(OPTICAL)

AUDIO(R)

OUT

AUDIO(L)

OUT

REAR

AUDIO(R)

IN3

AUDIO(L)

IN3

S-VIDEO

OUT

S-VIDEO

IN3

B

C

DR-A2631

DR-B2737

A,C

20

18

16

14

12

10

8

6

4

2

1234567

1234567

F1 11

CN1201 CN1106 CN1102CN1104

21

19

17

15

13

11

9

7

5

3

1

JK1206

AL-30V 33

F2 22

FAN

21

20

19

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

JK2001

POWER

SUPPLY

JUNCTION

CBA

AL+4V 55

GND 66

GND 44

AFV CBA

SW CBA

JACK CBA

WIRING DIAGRAM

CBA

8

1234567

CN1103CN1105

8

1234567

1515

AL+5V 99

AL+12V 1111

FAN-AL+12V 1212

AL+44V 1313

GND 1414

1
2

11
22
33

GND

CN1204

CN1202

CN1205 CN1209

CN1203

CN1210

JW002
VIDEO-Y 11
GND 22
VIDEO-R 33
GND 44
VIDEO-B 55
GND 66
VIDEO-G 77
GND 88
VIDEO-C 99
GND 1010
AUDIO(R)-IN 1111
GND 1212
AUDIO(L)-IN 1313
GND 1414
AUDIO(R)-OUT
GND 1616
AUDIO(L)-OUT
GND 1818
DVD-AUDIO-MUTE
AUDIO+5V 2020
VIDEO-Y/CVBS
GND 2222
VIDEO-C 2323
GND 2424
SUB-SCLK 2525
REG-CONT2 2626
SUB-TXD
RDY 2828
SUB-RXD
SYS-RESET 3030

JW001
SPDIF 11
GND 22
GND 33
EV+10.5V 44
EV+10.5V 55
EV+10.5V 66
GND 77
GND 88
GND 99
GND 1010
P-ON+5V 1111
P-ON+5V 1212
P-ON+5V 1313
EV+2.4V 1414
EV+2.4V 1515
EV+2.4V 1616
EV+2.4V 1717
GND 1818
GND 1919
P-ON+2.5V 2020
P-ON+2.5V 2121
P-ON+2.5V 2222
GND 2323
GND 2424
P-ON+3.3V 2525
P-ON+3.3V 2626
P-ON+3.3V 2727
GND 2828
GND 2929
GND 3030

AL+3V 77

GND 88

AV CBA

FAN+12V
GND

NU 11
SIF 22
GND 33
TU-AUDIO(R) 44
TU-AUDIO(L) 55

CN1CN2001

P-ON+5V 66
P-ON+5V 77
IIC-BUS-SCL 88
IIC-BUS-SDA 99

KEY-1 11
KEY-2 22
GND 33

CN3001

AUDIO(R)-OUT2
AUDIO2-MUTE
AUDIO(L)-OUT2
GND 44
AUDIO(R)-IN2 55
AUDIO(L)-IN2 66
SC2-IN 77
VIDEO-OUT2 88
GND 99
VIDEO-IN2 1010
RGB-SW 1111
VIDEO-B-IN 1212
VIDEO-G-IN 1313
VIDEO-R-IN 1414

AL+5V 1010

JW010

JW2001,
JW2002

1515

CN601

1717

1919

2121

2727

2929

CN501

FCS(+)

TRK(+)

TRK(-)

GND

THERMO

GND

FPD

10

FPD-SW

11

VC-FPD

12

VCC1

13

VC-PD

14

H

15

D

16

C

17

F

18

NU

SW

RF(+)

RF(-)

GND

VCC2

IIN3
IIN2
IIN1

GND

XOUTEN3

GND

XOUTEN2

GND

OSCEN

LDEN2
LDEN1

CN1001

19

NU

20
21
22
23

E

24

B

25

A

26

G

27
28
29
30
31
32
33
34
35
36
37
38
39
40

RELAY CBA

CN101

DVD MAIN CBA

NU

18 1

SW1

17 2

SL-

16 3

SL+

15 4

GND

14 5

T-SCN2

13 6

T-SCN3

12 7

W

11 8
10 9

V

910

U

CN401

VCC

811

HU+

712

HU-

613

HV+

514

HV-

415

HW+

316

HW-

217
118

VH-

1
2FCS(-)
3
4
5TILT(+)
6TILT(-)
7
8
9

CN1002

10
11

CN1003

FOCUS
ACTUATOR

TRACKING
ACTUATOR

TILT
ACTUATOR

FPDICCD-LDDVD-LD

PICKUP

PDIC

DVD/CD LASER DIODE DRIVE

M

SLED

MOTOR

1
2
3
4
5
6
7
8
9

M

SPINDLE

DVD MECHANISM & DVD MAIN CBA ASSEMBLY

DVD MECHANISM

MOTOR

TRAY OPEN

1
2
3

SLED

SENSOR

ENCODER CBA LOADER CBA

1-12-1

E68C4WI

IC PIN FUNCTION DESCRIPTIONS

Comparison Chart of Models and Marks

Model Mark

DR-A2677 A

DR-A2631 B

DR-B2737 C

IC1207 (Sub Micon)

Pin
No.

1 IN KEY-1 Key Data Input 1

2 IN KEY-2 Key Data Input 2

3INPOW-SAF

4INAFT

5 - N.U. Not Used

6 IN EV+3.3V +3.3V Power Supply

7 IN BUP+3.3V +3.3V Power Supply

8 OUT OSC2 Main Clock Output

9 IN OSC1 Main Clock Input

10 - VSS Ground

11 IN XIN Sub Clock Input

12 OUT XOUT Sub Clock Output

13 - GND Ground

14 IN RESET

15 OUT 8POUT-1

16 OUT 8POUT-2

17 OUT

18 OUT SUB-TXD

19 IN SUB-RXD

20 OUT SUB-SCLK

21 - N.U. Not Used

22 OUT

23 - N.U. Not Used

24

25 - N.U. Not Used

Mark

IN/

OUT

Signal

Name

Abnormal Voltage
Detection

Tuner Voltage Input
Signal

Sub Micro Controller
Reset Signal

Control SCART 1 8Pin
Level by using 8POUT­1 and 8POUT-2

Control SCART 1 8Pin
Level by using 8POUT­1 and 8POUT-2

RGB­THROUGH

SCART 2 RGB
Through Control Signal

Transmission Data to
Main Micro Controller

Reception Data from
Main Micro Controller

Communication Clock
with Main Micro
Controller

SYS­RESET

A,C IN DAVN-L

System Reset Signal

VPS/PDC Data
Receive = “L”

B - N.U. Not Used

Function

Pin
No.

26 OUT

Mark

IN/

OUT

Signal

Name

REG­CONT2

Function

Power Regulator
Control Signal

27 IN REMOTE Remote Signal Input

28 - N.U. Not Used

Ready/Busy

29 IN RDY

communication Control
with Main Micro
Controller

30 IN P-DOWN

Power Voltage Down
Detector Signal

31 - N.U. Not Used

32 - N.U. Not Used

33

IN/

SUB-SDA Serial Data

OUT

34 OUT SUB-SCL Serial Clock

35 - N.U. Not Used

36 - N.U. Not Used

37 - N.U. Not Used

38 OUT

AUDIO­MUTE

Audio Mute Control
Signal

39 - N.U. Not Used

40 - N.U. Not Used

41 OUT

42 OUT

43 OUT

VIDEO­SW1

VIDEO­SW2

VIDEO­SW3

Video Input Select
Signal

Video Input Select
Signal

Video Input Select
Signal

44 - N.U. Not Used

45 - N.U. Not Used

46 - N.U. Not Used

47 - N.U. Not Used

48 OUT FL-DIN Serial Data

49 OUT FL-STB Serial Interface Strobe

50 OUT FL-CLK Serial Clock

51 - N.U. Not Used

52 OUT

REG­CONT

Power Regulator
Control Signal

53 - N.U. Not Used

54 - N.U. Not Used

55 OUT

FAN­CONT2

Fan Motor Control
Signal

56 - N.U. Not Used

57 - N.U. Not Used

58 - N.U. Not Used

59 - N.U. Not Used

60 - N.U. Not Used

1-13-1 E68C4PIN

Mark

IN/

OUT

Pin
No.

61 - AVss AVSS (GND)

62 IN FAN-LOCK

63 IN AGC

64 IN SC2-IN

Signal

Name

Function

Fan Motor Lock
Detection

IF AGC Comparator
Signal

Input Signal from Pin 8
of SCART2

IC1205 (VFD DRIVER)

Pin

IN/

No.

OUT

1 IN CLK Serial Clock

2 IN STB Serial Interface Strobe

3 - N.U. Not Used

4 - N.U. Not Used

5 - VSS GND

6 - VDD Power Supply

7

8 b

9 c

10 d

OUT

11 e

12 f

13 g

14 h

15 - VEE Pull Down Level

16 OUT i Segment Output

17

18 6G

19 5G

OUT

20 4G

21 3G

22 2G

23 1G

24 - VDD Power Supply

25 - VSS GND

26 IN OSC Oscillator Input

27 - N.U. Not Used

28 IN DIN Serial Data Input

Signal

a

7G

Name

Function

Segment Output

Grid Output

1-13-2 E68C4PIN

E C B

LEAD IDENTIFICATIONS

2SA1175(F,H,J)
2SC2785(F,H,J)
BA1F4M-T
KRC103M
KTA1266(GR)
KTA-1266-GR-AT/P
KTA1267(GR,Y)
KTC3199(BL,GR,Y)
KTA1267-GR-AT/P
KTA1267Y-AT/P
KTC3199-(BL,GR,Y)-AT/P
KTC3193(Y)
KTC3193-Y-AT/P
KTA1273(Y)

E C B

2SA1015-GR(TPE2)
2SA1015-GR(TE2 F T)
2SA1015-Y(TE2 F T)
2SA1015-Y(TPE2)
2SC1815-BL(TPE2)
2SC1815-GR(TPE2)
2SC1815-BL(TE2 F T)
2SC1815-GR(TE2 F T)
2SC1815-Y(TE2 F T)
2SC1815-Y(TPE2)
2SC2120-Y(TPE2)
2SC2120-Y(TE2 F T)

2SC3266-(GR,Y)(TPE2 F)
2SC3266-(GR,Y)(TPE2)
KTC3266-GR-AT/P
KTC3266-Y-AT/P
KTC3203(Y)
KTC3203-Y-AT/P
2SA966(Y)
2SA966-Y(TE6 F M)

KIA4558P/P
RC4580IP
TC7WBD125AFK

8 5

1 4

MM1637XVBE

16

1

PT6313-S-TP(L)
SC16313G

28

15

FA1F4M-T1B
KRC103S RTK
KTC3875Y-RTK
KTC3879Y-RTK

C

BE

CD4052BPWR

EL817A
EL817B
PS2561A-1(Q,W)
LTV-817B-F

1

2

4

3

LC74793JM-TRM

1: A
2: K
3: E
4: C

MM1697AJBE

16

9

24

9

PQ070XF01SZ
PQ070XF01SZH

1234

13

2SK3566

GDS

BU4219G-TR

R3112N191A-TR-(FA,FB)
IC-PST3619NR

54

1

8

CD4053BCSJX
CD4053BNSR
TC4053BF(N)
TC4053BF(N)

16

8

1

MM1636XWRE

8

5

9

12

KIA431-AT/P

123

NC7WZU04P6X

5

64

44

34

1

MSP3407G-QG-B8-V3
MSP3417G-QG-B8-V3

33

1

14

23

11

1: R

1

1

8

MM1443XJBE

34

22

18

4

123

MN101C77A FD1

48

49

2: A
3: K

33

32

123

Note:

A: Anode
K: Cathode
E: Emitter
C: Collector
B: Base

17

R: Reference
S: Source
G: Gate

12

1

17

64

1

16

D: Drain

1-14-1 E68C4LE

Cabinet

EXPLODED VIEWS

A6

2L031

2L021

See Electrical Parts List
for parts with this mark.

Some Ref. Numbers are
not in sequence.

2B8

2L031

2L031

DVD Mechanism &
DVD Main CBA
Assembly

2L021

2L021

Power Supply CBA

2B9

A16

A2

2L021

[ A ]

2B11

2B15

A3

2L011

Junction CBA

SW CBA

2L019

2L011

2L081

2L012

2L081

[ A,C ]

2L012

2B1

2L081

2L021

2L021

2L081

Jack CBA

2B12

2L081

A1X

A14

A5

2B2

2B5

A26

2B3

AV CBA

A5

A4

2B4

2B13

Comparison Chart of
Models and Marks

Model Mark

DR-A2677
DR-A2631
DR-B2737

AFV CBA

A
B
C

1-15-1 E68C4CEX

Packing

S2

X7

X2

X4

S2

X1

[B,C] [A]

X6

X5

S4

X6A
X6B

X27

[B]

X26

[C]

[B,C]

X10

Comparison Chart of
Models and Marks

X10A
X10B

Model Mark

DR-A2677
DR-A2631
DR-B2737

[A]

S3

Unit

A
B
C

S1

A13

Some Ref. Numbers
are not in sequence.

1-15-2 E68C4PEX

MECHANICAL PARTS LIST

PRODUCT SAFETY NOTE: Products marked with a

! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.

NOTE: Parts that are not assigned part numbers
(---------) are not available.

Comparison Chart of Models and Marks

Model Mark

DR-A2677 A

DR-A2631 B

DR-B2737 C

Ref. No. Mark Description Part No.

A1X A FRONT ASSEMBLY E68C4ED 1VM220429

A1X B FRONT ASSEMBLY E68C7ED 1VM220428

A1X C FRONT ASSEMBLY E68C5BD 1VM220430

A2 TOP COVER E6700UD 1VM120049

A3 A REAR PANEL E68C4ED 1VM220414

A3 B REAR PANEL E68C7ED 1VM220417

A3 C REAR PANEL E68C5BD 1VM220415

A4 CHASSIS E6700ED 1VM120045

A5 FOOT K7010UA 0VM403657A

A6 FAN COVER E6800ED 1VM220260

A13 LABEL SERIAL NO. HE240ED ----------

A13 A LABEL BAR CODE E68C4ED ----------

A13 B LABEL BAR CODE E68C7ED ----------

A13 C LABEL BAR CODE E68C5BD ----------

A14 LABEL(C) E6700UD ----------

A16 A LABEL SHOW VIEW H6745EP ----------

A26 LABEL SERIAL BAR CODE E57A0ED ----------

2B1 PCB HOLDER E6700UD 1VM220245

2B2 CABLE COVER E6700UD 1VM420969

2B4 LOCKING CARD SPACER KGLS-12S XP0U024WD004

2B5 POWER EARTH PLATE E6800ED 1VM420990

2B8! CAUTION LABEL(PAL) E6800ED ----------

2B9 POWER HOLDER E6800ED 1VM320541

2B13 PLATE GROUND(RCA) E6800ED 1VM320610

2B14 A GEMSTAR LABEL E6710JD ----------

2B15 FAN EARTH E6800ED 1VM320812

2L011 SCREW P-TIGHT M3X6 BIND HEAD+ GBMP3060

2L012 SCREW B-TIGHT M3X8 BIND HEAD + GBKB3080

2L021 SCREW S-TIGHT M3X6 BIND CROM GBCS3060

2L031 SCREW S-TIGHT M3X10 BIND HEAD+ GBMS3100

2L081 SCREW S-TIGHT M3X6 BIND HEAD+ GBMS3060

PACKING

S1 A GIFT BOX CARTON E68C4ED 1VM320913

S1 B GIFT BOX CARTON E68C7ED 1VM320915

S1 C GIFT BOX CARTON E68C5BD 1VM320914

S2 STYROFORM(UK) E6821BD 1VM220397C

S3 UNIT BAG E5500UD 0VM411683

S4 C AC PAD HC461BD 0VM413331

ACCESSORIES

X1 A REMOTE CONTROL UNIT E6824ED NB018ED

X1 B,C REMOTE CONTROL UNIT E6820ED NB011ED

X2 DRY BATTERY R6P/2S or XB0M451T0001

DRY BATTERY ES-GR6M-C XB0M571GLP01

X4 RF CORD PAL 1.2M or WPZ0122LG001

RF CABLE CC1001020012010 WPZ0122LW001

X5 ACCESSORY BAG E5700UD 0VM415576

Ref. No. Mark Description Part No.

X6A A QUICK GUIDE(GER) E68C4ED 1VMN20508

X6B A QUICK GUIDE(ENG) E68C4ED 1VMN20509

X6 B QUICK GUIDE(GRE) E68C7ED 1VMN20521

X6 C QUICK GUIDE(ENG) E68C5BD 1VMN20511

X7 21P CABLE(BYR SUPPLY) H9300ED 0VMN03276

X10! B OWNERS MANUAL(GRE) E68C7ED 1VMN20520

X10! C OWNERS MANUAL(ENG) E68C5BD 1VMN20510

X10A! A OWNERS MANUAL(GER) E68C4ED 1VMN20506

X10B! A OWNERS MANUAL(ENG) E68C4ED 1VMN20507

X26 B WARRANTY CARD E68C7ED 1VMN20827

X27 B LABEL SERIAL NO. H9500ED ----------

20050419 1-16-1 E68C4CA

ELECTRICAL PARTS LIST

PRODUCT SAFETY NOTE: Products marked with a

! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.

NOTES:

1. Parts that are not assigned part numbers (---------)
are not available.

2. Tolerance of Capacitors and Resistors are noted
with the following symbols.

C.....±0.25% D.....±0.5% F.....±1%

G.....±2% J......±5% K.....±10%

M.....±20% N.....±30% Z.....+80/-20%

Comparison Chart of Models and Marks

Model Mark

DR-A2677 A

DR-A2631 B

DR-B2737 C

DVD MECHANISM & DVD MAIN CBA
ASSEMBLY

Ref. No. Mark Description Part No.

DVD MECHANISM & DVD MAIN CBA

A

ASSEMBLY
DVD MECHANISM & DVD MAIN CBA

B

ASSEMBLY
DVD MECHANISM & DVD MAIN CBA

C

ASSEMBLY

N78G8BEN

N78G7BEN

N78G9BBN

AV CBA + SW CBA

Ref. No. Mark Description Part No.

A

AV CBA + SW CBA

B

AV CBA + SW CBA

C

AV CBA + SW CBA
Consists of the following:

AV CBA (SUB-A)
SW CBA (SUB-B)

AV CBA

Ref. No. Mark Description Part No.

AV CBA (SUB-A)
Consists of the following:

CAPACITORS

C1205 ELECTROLYTIC CAP. 3.3µF/50V M or CE1JMASDL3R3

ELECTROLYTIC CAP. 3.3µF/50V M CE1JMASTL3R3

C1208 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222

C1209 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222

C1210 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222

C1211 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1212 ELECTROLYTIC CAP. 3.3µF/50V M or CE1JMASDL3R3

ELECTROLYTIC CAP. 3.3µF/50V M CE1JMASTL3R3

C1214 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100

ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100

C1215 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100

ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100

C1216 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100

ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100

C1217 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100

1VSA11390
1VSA11305
1VSA11520

----------

----------

----------

Ref. No. Mark Description Part No.

ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100

C1218 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1219 CHIP CERAMIC CAP. CH J 18pF/50V or CHD1JJ3CH180

C1220 CHIP CERAMIC CAP.(1608) CH J 22pF/

C1222 ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221

C1223 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

If C1225 is 0.015µF, then IC1206 is BU4219G-TR, R3112N191A-TR-FA or
R3112N191A-TR-FB.

C1225 CHIP CERAMIC CAP.(1608) B K 0.015µF/

IC1206 RESET IC BU4219G-TR or QSZBA0TRM090

If C1225 is 0.1µF, then IC1206 is IC-PST3619NR.

C1225 CHIP CERAMIC CAP.(1608) B K 0.1µF/

IC1206 SYSTEM RESET IC IC-PST3619NR QSZBA0TMM151
C1228 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1229 CERAMIC CAP.(AX) F Z 0.1µF/25V CCA1JZTFZ104
C1230 CERAMIC CAP.(AX) F Z 0.1µF/25V CCA1JZTFZ104
C1231 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471

C1235 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101

C1238 CERAMIC CAP.(AX) F Z 0.1µF/25V CCA1JZTFZ104
C1239 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1241 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1242 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1244 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1245 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1246 CHIP CERAMIC CAP.(1608) B K 0.01µF/

C1247 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

CHIP CERAMIC CAP. CG J 18pF/50V CHD1JJ3CG180

50V or

CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220

ELECTROLYTIC CAP. 220µF/16V M CE1CMASTL221

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V

VOLTAGE DETECT R3112N191A-TR-FA orQSZBA0TRC021

VOLTAGE DETECT R3112N191A-TR-FB QSZBA0TRC022

50V

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471

ELECTROLYTIC CAP. 100µF/16V M CE1CMASTL101

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or

CHD1JZ30F104

CHD1EZ30F104

CHD1JJ3CH220

CHD1JZ30F104

CHD1EZ30F104

CHD1JK30B153

CHD1JK30B104

CHD1JZ30F104

CHD1EZ30F104

CHD1JZ30F104

CHD1EZ30F104

CHD1JZ30F104

CHD1EZ30F104

CHD1JZ30F104

CHD1EZ30F104

CHD1JZ30F104

CHD1EZ30F104

CHD1JZ30F104

CHD1EZ30F104

CHD1JK30B103

CHD1JZ30F104

CHD1EZ30F104

20050419 1-17-1 E68C4EL

Ref. No. Mark Description Part No.

CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

C1248 ELECTROLYTIC CAP. 22µF/16V M or CE1CMASDL220

ELECTROLYTIC CAP. 22µF/16V M CE1CMASTL220

C1250 ELECTROLYTIC CAP. 3.3µF/50V M or CE1JMASDL3R3

ELECTROLYTIC CAP. 3.3µF/50V M CE1JMASTL3R3

C1251 CHIP CERAMIC CAP.(1608) CH J 100pF/

C1252 CHIP CERAMIC CAP.(1608) B K 0.01µF/

C1256 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101

C1259 CERAMIC CAP.(AX) F Z 0.1µF/25V CCA1JZTFZ104
C1260 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1261 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101

C1262 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101

C1263 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1264 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1267 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1270 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101

C1271 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1273 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100

C1274 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100

C1275 ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221

C1276 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1277 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1279 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1281 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1286 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470

C1287 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

50V or

CHIP CERAMIC CAP.(1608) CG J 100pF/
50V

50V

ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTL101

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTL101

ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTL101

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTL101

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100

ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100

ELECTROLYTIC CAP. 220µF/16V M CE1CMASTL221

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

ELECTROLYTIC CAP. 47µF/16V M CE1CMASTL470

50V or

CHD1JJ3CH101

CHD1JJ3CG101

CHD1JK30B103

CHD1JZ30F104

CHD1EZ30F104

CHD1JZ30F104

CHD1EZ30F104

CHD1JZ30F104

CHD1EZ30F104

CHD1JZ30F104

CHD1EZ30F104

CHD1JZ30F104

CHD1EZ30F104

CHD1JZ30F104

CHD1EZ30F104

CHD1JZ30F104

CHD1EZ30F104

CHD1JZ30F104

CHD1EZ30F104

CHD1JZ30F104

CHD1EZ30F104

CHD1JZ30F104

Ref. No. Mark Description Part No.

CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or

CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

C1288 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101

ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTL101

C1289 CHIP CERAMIC CAP.(1608) CH J 100pF/

C1295 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1296 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471

C1297 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101

C1298 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101

C1299 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100

C1300 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100

C1301 CERAMIC CAP.(AX) F Z 0.1µF/25V CCA1JZTFZ104
C1313 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0

C1314 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0

C1315 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470

C1316 CHIP CERAMIC CAP.(1608) B K 0.1µF/

C1323 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100

C1324 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100

C1326 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101

C1328 CERAMIC CAP.(AX) B K 0.1µF/25V CCA1EKT0B104

C1334 A,C CHIP CERAMIC CAP.(1608) B K 1000pF/

C1335 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471

C1338 A,C CHIP CERAMIC CAP.(1608) B K 1000pF/

C1340 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0

C1342 A,C CHIP CERAMIC CAP. CH J 18pF/50V or CHD1JJ3CH180

C1343 A,C ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7

C1344 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100

C1345 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100

C1346 A,C CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1347 A,C CHIP CERAMIC CAP. CH J 15pF/50V or CHD1JJ3CH150

C1348 A,C SEMICONDUCTOR CAP. SR K 0.018µF/

C1349 CHIP CERAMIC CAP.(1608) CH J 270pF/

C1350 CHIP CERAMIC CAP.(1608) CH J 270pF/

C1355 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101

50V or

CHIP CERAMIC CAP.(1608) CG J 100pF/
50V

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471

ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTL101

ELECTROLYTIC CAP. 100µF/16V M CE1CMASTL101

ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100

ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100

ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0

ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0

ELECTROLYTIC CAP. 47µF/16V M CE1CMASTL470

50V

ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100

ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100

ELECTROLYTIC CAP. 100µF/16V M CE1CMASTL101

50V

ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471

50V

ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0

A,C CHIP CERAMIC CAP. CG J 18pF/50V CHD1JJ3CG180

A,C ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASTL4R7

ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100

ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100

50V or

A,C CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or

A,C CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

A,C CHIP CERAMIC CAP. CG J 15pF/50V CHD1JJ3CG150

25V

50V or

CHIP CERAMIC CAP. A J 270pF/50V CHD1JJ3CG271

50V or

CHIP CERAMIC CAP. A J 270pF/50V CHD1JJ3CG271

CHD1EZ30F104

CHD1JJ3CH101

CHD1JJ3CG101

CHD1JZ30F104

CHD1EZ30F104

CHD1JK30B104

CHD1JK30B102

CHD1JK30B102

CHD1JZ30F104

CHD1EZ30F104

CDA1EKS0X183

CHD1JJ3CH271

CHD1JJ3CH271

20050419 1-17-2 E68C4EL

Ref. No. Mark Description Part No.

ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTL101

C1357 CHIP CERAMIC CAP.(1608) B K 0.01µF/

C1358 CHIP CERAMIC CAP.(1608) CH J 47pF/

C1359 CHIP CERAMIC CAP.(1608) CH J 47pF/

C1361 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1362 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0

C1363 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7

C1364 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7

C1365 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7

C1366 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7

C1367 CHIP CERAMIC CAP.(1608) B K 0.01µF/

C1371 CHIP CERAMIC CAP.(1608) CH J 47pF/

C1372 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100

C1373 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471

C1374 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471

C1375 CHIP CERAMIC CAP.(1608) B K 0.1µF/

C1376 ELECTROLYTIC CAP. 22µF/25V M or CE1EMASDL220

C1378 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1379 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7

C1380 ELECTROLYTIC CAP. 4.7µF/25V M or CE1EMASDL4R7

C1382 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100

C1383 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100

C1385 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0

C1386 CHIP CERAMIC CAP.(1608) CH J 47pF/

C1387 A,C ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C1388 CERAMIC CAP.(AX) B K 0.1µF/25V CCA1EKT0B104
C1389 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0

C1390 A,C ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0

C1391 B CHIP CERAMIC CAP. CH J 39pF/50V or CHD1JJBCH390

C1392 A,C CHIP CERAMIC CAP.(1608) B K 0.01µF/

C1393 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0

C1394 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0

50V

50V or

CHIP CERAMIC CAP. CG J 47pF/50V CHD1JJ3CG470

50V or

CHIP CERAMIC CAP. CG J 47pF/50V CHD1JJ3CG470

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0

ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASTL4R7

ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASTL4R7

ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASTL4R7

ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASTL4R7

50V

50V or

CHIP CERAMIC CAP. CG J 47pF/50V CHD1JJ3CG470

ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100

ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471

ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471

50V

ELECTROLYTIC CAP. 22µF/25V M CE1EMASTL220

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASTL4R7

ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASTL4R7

ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100

ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100

ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0

50V or

CHIP CERAMIC CAP. CG J 47pF/50V CHD1JJ3CG470

ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0

A,C ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0

B CHIP CERAMIC CAP. CG J 39pF/50V CHD1JJ3CG390

50V

ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0

ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0

CHD1JK30B103

CHD1JJ3CH470

CHD1JJ3CH470

CHD1JZ30F104

CHD1EZ30F104

CHD1JK30B103

CHD1JJ3CH470

CHD1JK30B104

CHD1JZ30F104

CHD1EZ30F104

CHD1JJ3CH470

CHD1JK30B103

Ref. No. Mark Description Part No.

C1396 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1398 A,C ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470

C1399 B CHIP CERAMIC CAP.(1608) CH J 22pF/

C1400 B CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1406 CHIP CERAMIC CAP.(1608) B K 0.1µF/

C1407 PCB JUMPER D0.6-P5.0 JW5.0T
C1408 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471

C1409 CHIP CERAMIC CAP.(1608) B K 0.01µF/

C1410 CHIP CERAMIC CAP. CH J 56pF/50V or CHD1JJ3CH560

C1411 ELECTROLYTIC CAP. 22µF/25V M or CE1EMASDL220

C1412 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1413 CHIP CERAMIC CAP.(1608) B K 0.01µF/

C1415 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101

C1416 CHIP CERAMIC CAP. CH J 39pF/50V or CHD1JJBCH390

C1418 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0

C1419 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0

C1420 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0

C1424 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1425 CHIP CERAMIC CAP. F Z 0.22µF/16V or CHD1CZ30F224

C1426 CHIP CERAMIC CAP. F Z 0.22µF/16V or CHD1CZ30F224

C1427 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1428 CHIP CERAMIC CAP.(1608) B K 0.01µF/

C1429 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1430 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222

C1433 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222

C1434 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222

C1436 CHIP CERAMIC CAP.(1608) B K 1000pF/

C1439 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470

C1440 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1442 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0

C1443 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V or

B CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220

50V or

B CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or

B CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V

ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471

50V

CHIP CERAMIC CAP. CG J 56pF/50V CHD1JJ3CG560

ELECTROLYTIC CAP. 22µF/25V M CE1EMASTL220

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V

ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTL101

CHIP CERAMIC CAP. CG J 39pF/50V CHD1JJ3CG390

ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0

ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0

ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0

CHIP CERAMIC CAP. FZ Z 0.22µF/25V CHD1EZ3FZ224

CHIP CERAMIC CAP. FZ Z 0.22µF/25V CHD1EZ3FZ224

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V

ELECTROLYTIC CAP. 47µF/16V M CE1CMASTL470

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0

CHD1JZ30F104

CHD1EZ30F104

CHD1JJ3CH220

CHD1JZ30F104

CHD1EZ30F104

CHD1JK30B104

CHD1JK30B103

CHD1JZ30F104

CHD1EZ30F104

CHD1JK30B103

CHD1JZ30F104

CHD1EZ30F104

CHD1JK30B103

CHD1JZ30F104

CHD1EZ30F104

CHD1JK30B102

CHD1JZ30F104

CHD1EZ30F104

20050419 1-17-3 E68C4EL

Ref. No. Mark Description Part No.

ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471

C1444 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471

ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471

C1445 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471

ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471

C1446 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1451 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222

C1452 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1456 A,C CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1458 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0

C1459 CHIP CERAMIC CAP.(1608) B K 1000pF/

C1460 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0

C1461 CHIP CERAMIC CAP.(1608) B K 1000pF/

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V or

A,C CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or

A,C CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0

50V

50V

CHD1JZ30F104

CHD1EZ30F104

CHD1JZ30F104

CHD1EZ30F104

CHD1JK30B102

CHD1JK30B102

CONNECTORS

CN1201 242 SERIES CONNECTOR

CN1202 PH CONNECTOR (WHITE) TOP 2P B2B-

CN1209 A,B AFV PCB ASSEMBLY E6820ED E6820AFV

CN1209 C AFV PCB ASSEMBLY E6821BD E6821AFV

224202115W1 or

CONNECTOR BASE 15P TUC-P15P-B1 J3TUA15TG001

PH-K-S(LF) or

PH CONNECTOR TOP 2P B2B-PH-K-S J3PHC02JG001

J322C15TG001

J3PHC02JG017

DIODES

D1201 DIODE 1N5397-B NDLZ001N5397

D1204 SWITCHING DIODE 1N4148M or NDTZ01N4148M

SWITCHING DIODE 1SS133(T-77) QDTZ001SS133

D1205 DIODE 1N5397-B NDLZ001N5397

D1206 SWITCHING DIODE 1N4148M or NDTZ01N4148M

SWITCHING DIODE 1SS133(T-77) QDTZ001SS133

D1207 ZENER DIODE DZ-7.5BSAT265 or NDTA0DZ7R5BS

ZENER DIODE MTZJT-777.5A QDTA0MTZJ7R5

D1210 PCB JUMPER D0.6-P5.0 JW5.0T

D1211 SWITCHING DIODE 1N4148M or NDTZ01N4148M

SWITCHING DIODE 1SS133(T-77) QDTZ001SS133

D1212 SWITCHING DIODE 1N4148M or NDTZ01N4148M

SWITCHING DIODE 1SS133(T-77) QDTZ001SS133

D1213 SWITCHING DIODE 1N4148M or NDTZ01N4148M

SWITCHING DIODE 1SS133(T-77) QDTZ001SS133

D1219 SWITCHING DIODE 1N4148M or NDTZ01N4148M

SWITCHING DIODE 1SS133(T-77) QDTZ001SS133

D1220 SWITCHING DIODE 1N4148M or NDTZ01N4148M

SWITCHING DIODE 1SS133(T-77) QDTZ001SS133

D1223 ZENER DIODE MTZJT-774.3C QDTC0MTZJ4R3

D1224 ZENER DIODE DZ-11BSBT265 or NDTB00DZ11BS

ZENER DIODE MTZJT-7711B QDTB00MTZJ11

D1226 SWITCHING DIODE 1N4148M or NDTZ01N4148M

SWITCHING DIODE 1SS133(T-77) QDTZ001SS133

D1228 ZENER DIODE DZ-5.6BSBT265 or NDTB0DZ5R6BS

ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6

D1237 ZENER DIODE DZ-33BSDT265 or NDTD00DZ33BS

ZENER DIODE MTZJT-7733D QDTD00MTZJ33

D1238 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

D1239 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

D1241 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

D1243 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

Ref. No. Mark Description Part No.

D1244 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

D1245 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

D1247 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

D1248 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

D1249 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

D1250 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

ICS

IC1205 VFD DRIVER IC SC16313G or NSZBA0T0S005

VFD DRIVER/CONTROLLER IC PT6313­S-TP(L)

If IC1206 is BU4219G-TR, R3112N191A-TR-FA or R3112N191A-TR-FB, then
C1225 is 0.015µF.

IC1206 RESET IC BU4219G-TR or QSZBA0TRM090

VOLTAGE DETECT R3112N191A-TR-FA orQSZBA0TRC021

VOLTAGE DETECT R3112N191A-TR-FB QSZBA0TRC022

C1225 CHIP CERAMIC CAP.(1608) B K 0.015µF/

If IC1206 is IC-PST3619NR, then C1225 is 0.1µF.

IC1206 SYSTEM RESET IC IC-PST3619NR QSZBA0TMM151
C1225 CHIP CERAMIC CAP.(1608) B K 0.1µF/

IC1207 SUB MICON MN101C77A FD1 QSZAB0RMS035

IC1208 IC(ANALOG SW) CD4052BPWR NSZBA0TTY142

IC1209 VIDEO SWITCH MM1697AJBE QSZBA0TMM150

IC1211 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036

IC1212 VOLTAGE REGULATOR PQ070XF01SZH orQSZBA0SSH054

IC1213 VOLTAGE REGULATOR PQ070XF01SZH orQSZBA0SSH054

IC1215 BUS SWITCH IC TC7WBD125AFK QSZBA0TTS150

IC1216 IC OP AMP RC4580IP NSZBA0STY173

IC1219 AV SWITCH MM1443XJBE QSZBA0TMM152

IC1220 A,C IC VPS/PDC SLICER LC74793JM-TRM QSZBA0TSY018

IC1221 IC SWITCH TC4053BF(EL N F) or QSZBA0TTS163

IC1222 IC OP AMP KIA4558P/P or NSZBA0SJY035

IC1223 DRIVER FOR DVD MM1636XWRE QSZBA0TMM108

IC1225 B LOGIC IC NC7WZU04P6X NSZBA0TF3109

IC1226 DRIVER FOR DVD MM1637XVBE QSZBA0TMM102

50V

50V

VOLTAGE REGULATOR PQ070XF01SZ QSZBA0SSH026

VOLTAGE REGULATOR PQ070XF01SZ QSZBA0SSH026

IC ANALOG MULTIPLEXER
CD4053BNSR or

IC ANALOG MULTIPLEXERS
CD4053BCSJX or

IC SWITCH TC4053BF(N) QSMBA0STS002

IC OP AMP RC4580IP NSZBA0STY173

NSZBA0TG2007

CHD1JK30B153

CHD1JK30B104

NSZBA0TTY093

NSZBA0TF3071

COILS

L1201 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1209 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101

L1210 PCB JUMPER D0.6-P5.0 JW5.0T

L1211 PCB JUMPER D0.6-P5.0 JW5.0T

L1217 PCB JUMPER D0.6-P5.0 JW5.0T
L1218 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101

L1221 PCB JUMPER D0.6-P5.0 JW5.0T
L1224 INDUCTOR(0.47µH K) LAP02TAR47K LLAXKATTUR47

L1226 BEAD CORE ASSEMBLY E6820ED 1VSA11351

TRANSISTORS

Q1205 TRANSISTOR KTA1267Y-AT/P or NQSYKTA1267P

TRANSISTOR KTA1267-GR-AT/P or NQS1KTA1267P

TRANSISTOR 2SA1175(J) or QQSJ02SA1175

TRANSISTOR 2SA1175(H) or QQSH02SA1175

TRANSISTOR 2SA1175(F) or QQSF02SA1175

TRANSISTOR KTA1267(Y) or NQSY0KTA1267

20050419 1-17-4 E68C4EL

Ref. No. Mark Description Part No.

TRANSISTOR KTA1267(GR) NQS10KTA1267

Q1206 RES. BUILT-IN TRANSISTOR KRC103M orNQSZ0KRC103M

RES. BUILT-IN TRANSISTOR BA1F4M-T QQSZ00BA1F4M

Q1207 TRANSISTOR KTC3199-BL-AT/P or NQS5KTC3199P

TRANSISTOR 2SC1815-BL(TE2 F T) or QQS22SC1815F

TRANSISTOR KTC3199(BL) or NQS50KTC3199

TRANSISTOR 2SC1815-BL(TPE2) QQS202SC1815

Q1208 RES. BUILT-IN TRANSISTOR KRC103M orNQSZ0KRC103M

RES. BUILT-IN TRANSISTOR BA1F4M-T QQSZ00BA1F4M

Q1210 RES. BUILT-IN TRANSISTOR KRC103M orNQSZ0KRC103M

RES. BUILT-IN TRANSISTOR BA1F4M-T QQSZ00BA1F4M

Q1213 RES. BUILT-IN TRANSISTOR KRC103M orNQSZ0KRC103M

RES. BUILT-IN TRANSISTOR BA1F4M-T QQSZ00BA1F4M

Q1214 TRANSISTOR 2SC3266-GR(TPE2 F) or QQS12SC3266F

TRANSISTOR 2SC3266-Y(TPE2 F) or QQSY2SC3266F

TRANSISTOR KTC3266-GR-AT/P or NQS4KTC3266P

TRANSISTOR KTC3266-Y-AT/P or NQSYKTC3266P

TRANSISTOR 2SC3266-GR(TPE2) or QQS102SC3266

TRANSISTOR 2SC3266-Y(TPE2) QQSY02SC3266

Q1215 TRANSISTOR 2SA966-Y(TE6 F M) or QQSY02SA966F

TRANSISTOR KTA1273(Y) or NQSY0KTA1273

TRANSISTOR 2SA966(Y) QQSY002SA966

Q1217 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P

TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P

TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F

TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F

TRANSISTOR 2SC2785(J) or QQSJ02SC2785

TRANSISTOR 2SC2785(H) or QQSH02SC2785

TRANSISTOR 2SC2785(F) or QQSF02SC2785

TRANSISTOR KTC3199(Y) or NQSY0KTC3199

TRANSISTOR KTC3199(GR) or NQS10KTC3199

TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815

TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815

Q1218 TRANSISTOR KTC3203-Y-AT/P or NQSYKTC3203P

TRANSISTOR 2SC2120-Y(TE2 F T) or QQSY2SC2120F

TRANSISTOR KTC3203(Y) or NQSY0KTC3203

TRANSISTOR 2SC2120-Y(TPE2) QQSY02SC2120

Q1221 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P

TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P

TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F

TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F

TRANSISTOR 2SC2785(J) or QQSJ02SC2785

TRANSISTOR 2SC2785(H) or QQSH02SC2785

TRANSISTOR 2SC2785(F) or QQSF02SC2785

TRANSISTOR KTC3199(Y) or NQSY0KTC3199

TRANSISTOR KTC3199(GR) or NQS10KTC3199

TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815

TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815

Q1222 TRANSISTOR KTA1267Y-AT/P or NQSYKTA1267P

TRANSISTOR KTA1267-GR-AT/P or NQS1KTA1267P

TRANSISTOR 2SA1175(J) or QQSJ02SA1175

TRANSISTOR 2SA1175(H) or QQSH02SA1175

TRANSISTOR 2SA1175(F) or QQSF02SA1175

TRANSISTOR KTA1267(Y) or NQSY0KTA1267

TRANSISTOR KTA1267(GR) NQS10KTA1267

Q1224 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P

TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P

TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F

TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F

TRANSISTOR 2SC2785(J) or QQSJ02SC2785

TRANSISTOR 2SC2785(H) or QQSH02SC2785

TRANSISTOR 2SC2785(F) or QQSF02SC2785

TRANSISTOR KTC3199(Y) or NQSY0KTC3199

TRANSISTOR KTC3199(GR) or NQS10KTC3199

TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815

Ref. No. Mark Description Part No.

TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815

Q1228 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P

TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P

TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F

TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F

TRANSISTOR 2SC2785(J) or QQSJ02SC2785

TRANSISTOR 2SC2785(H) or QQSH02SC2785

TRANSISTOR 2SC2785(F) or QQSF02SC2785

TRANSISTOR KTC3199(Y) or NQSY0KTC3199

TRANSISTOR KTC3199(GR) or NQS10KTC3199

TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815

TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815

Q1231 TRANSISTOR KTC3193-Y-AT/P or NQSYKTC3193P

TRANSISTOR KTC3193(Y) NQSY0KTC3193

Q1232 TRANSISTOR KTC3193-Y-AT/P or NQSYKTC3193P

TRANSISTOR KTC3193(Y) NQSY0KTC3193

Q1238 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P

TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P

TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F

TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F

TRANSISTOR 2SC2785(J) or QQSJ02SC2785

TRANSISTOR 2SC2785(H) or QQSH02SC2785

TRANSISTOR 2SC2785(F) or QQSF02SC2785

TRANSISTOR KTC3199(Y) or NQSY0KTC3199

TRANSISTOR KTC3199(GR) or NQS10KTC3199

TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815

TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815

Q1240 CHIP TRANSISTOR KTC3875Y-RTK NQ1Y0KTC3875

Q1243 A,C TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P

A,C TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P

A,C TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F

A,C TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F

A,C TRANSISTOR 2SC2785(J) or QQSJ02SC2785

A,C TRANSISTOR 2SC2785(H) or QQSH02SC2785

A,C TRANSISTOR 2SC2785(F) or QQSF02SC2785

A,C TRANSISTOR KTC3199(Y) or NQSY0KTC3199

A,C TRANSISTOR KTC3199(GR) or NQS10KTC3199

A,C TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815

A,C TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815

Q1244 TRANSISTOR KTA1267Y-AT/P or NQSYKTA1267P

TRANSISTOR KTA1267-GR-AT/P or NQS1KTA1267P

TRANSISTOR 2SA1175(J) or QQSJ02SA1175

TRANSISTOR 2SA1175(H) or QQSH02SA1175

TRANSISTOR 2SA1175(F) or QQSF02SA1175

TRANSISTOR KTA1267(Y) or NQSY0KTA1267

TRANSISTOR KTA1267(GR) NQS10KTA1267

Q1245 TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P

TRANSISTOR 2SA1015-GR(TE2 F T) or QQS12SA1015F

TRANSISTOR KTA1266(GR) or NQS40KTA1266

TRANSISTOR 2SA1015-GR(TPE2) QQS102SA1015

Q1246 CHIP TRANSISTOR KTC3879Y-RTK NQ1Y0KTC3879

Q1247 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P

TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P

TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F

TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F

TRANSISTOR 2SC2785(J) or QQSJ02SC2785

TRANSISTOR 2SC2785(H) or QQSH02SC2785

TRANSISTOR 2SC2785(F) or QQSF02SC2785

TRANSISTOR KTC3199(Y) or NQSY0KTC3199

TRANSISTOR KTC3199(GR) or NQS10KTC3199

TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815

TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815

Q1252 CHIP TRANSISTOR KRC103S RTK or NQ1Z0KRC103S

CHIP TRANSISTOR FA1F4M-T1B QQ8Z00FA1F4M

Q1254 CHIP TRANSISTOR KRC103S RTK or NQ1Z0KRC103S

CHIP TRANSISTOR FA1F4M-T1B QQ8Z00FA1F4M

Q1255 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P

20050419 1-17-5 E68C4EL

Ref. No. Mark Description Part No.

TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P

TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F

TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F

TRANSISTOR 2SC2785(J) or QQSJ02SC2785

TRANSISTOR 2SC2785(H) or QQSH02SC2785

TRANSISTOR 2SC2785(F) or QQSF02SC2785

TRANSISTOR KTC3199(Y) or NQSY0KTC3199

TRANSISTOR KTC3199(GR) or NQS10KTC3199

TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815

TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815

Q1256 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P

TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P

TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F

TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F

TRANSISTOR 2SC2785(J) or QQSJ02SC2785

TRANSISTOR 2SC2785(H) or QQSH02SC2785

TRANSISTOR 2SC2785(F) or QQSF02SC2785

TRANSISTOR KTC3199(Y) or NQSY0KTC3199

TRANSISTOR KTC3199(GR) or NQS10KTC3199

TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815

TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815

Q1257 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P

TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P

TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F

TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F

TRANSISTOR 2SC2785(J) or QQSJ02SC2785

TRANSISTOR 2SC2785(H) or QQSH02SC2785

TRANSISTOR 2SC2785(F) or QQSF02SC2785

TRANSISTOR KTC3199(Y) or NQSY0KTC3199

TRANSISTOR KTC3199(GR) or NQS10KTC3199

TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815

TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815

Q1258 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P

TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P

TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F

TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F

TRANSISTOR 2SC2785(J) or QQSJ02SC2785

TRANSISTOR 2SC2785(H) or QQSH02SC2785

TRANSISTOR 2SC2785(F) or QQSF02SC2785

TRANSISTOR KTC3199(Y) or NQSY0KTC3199

TRANSISTOR KTC3199(GR) or NQS10KTC3199

TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815

TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815

RESISTORS

R1201 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R1202 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R1204 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1205 CHIP RES.(1608) 1/10W J 47k Ω RRXAJR5Z0473
R1206 CARBON RES. 1/4W J 8.2 Ω RCX4JATZ08R2
R1207 CARBON RES. 1/4W J 5.6 Ω RCX4JATZ05R6
R1208 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R1211 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R1212 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R1215 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1216 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221
R1217 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221
R1218 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1221 CARBON RES. 1/6W J 1k Ω or RCX6JATZ0102

CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1224 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221
R1225 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221
R1229 CARBON RES. 1/4W J 82 Ω RCX4JATZ0820
R1231 CHIP RES.(1608) 1/10W J 5.6k Ω RRXAJR5Z0562
R1232 CHIP RES.(1608) 1/10W J 47k Ω RRXAJR5Z0473
R1233 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R1234 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1235 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103

Ref. No. Mark Description Part No.

R1236 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1237 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1238 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R1239 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R1240 CHIP RES.(1608) 1/10W J 47k Ω RRXAJR5Z0473
R1242 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1243 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R1244 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R1247 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R1250 CHIP RES.(1608) 1/10W J 47k Ω RRXAJR5Z0473
R1251 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1252 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1253 CHIP RES.(1608) 1/10W J 3.3k Ω RRXAJR5Z0332
R1254 CHIP RES.(1608) 1/10W J 39k Ω RRXAJR5Z0393
R1255 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
R1256 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1257 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1260 CHIP RES.(1608) 1/10W J 3.3k Ω RRXAJR5Z0332
R1262 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1263 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R1264 CHIP RES.(1608) 1/10W J 82k Ω RRXAJR5Z0823
R1267 CHIP RES.(1608) 1/10W J 68k Ω RRXAJR5Z0683
R1268 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1269 CHIP RES.(1608) 1/10W J 47k Ω RRXAJR5Z0473
R1272 CARBON RES. 1/4W J 680 Ω RCX4JATZ0681
R1273 CARBON RES. 1/4W J 680 Ω RCX4JATZ0681
R1278 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1282 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1286 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1295 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1299 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1300 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
R1301 CARBON RES. 1/6W J 390 Ω or RCX6JATZ0391

CARBON RES. 1/4W J 390 Ω RCX4JATZ0391
R1303 A,C CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1304 A,C CHIP RES.(1608) 1/10W J 22k Ω RRXAJR5Z0223
R1310 CHIP RES.(1608) 1/10W J 330 Ω RRXAJR5Z0331
R1312 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103

R1313 PCB JUMPER D0.6-P5.0 JW5.0T
R1316 CHIP RES.(1608) 1/10W J 22k Ω RRXAJR5Z0223
R1318 CHIP RES.(1608) 1/10W F 4.7k Ω or RRXAFR5H0472

CHIP RES.(1608) 1/10W F 4.7k Ω RRXAFR5Z0472
R1320 CARBON RES. 1/6W J 100 Ω or RCX6JATZ0101

CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R1321 CHIP RES.(1608) 1/10W F 1.5k Ω or RRXAFR5H0152

CHIP RES.(1608) 1/10W F 1.5k Ω RRXAFR5Z0152
R1322 CHIP RES.(1608) 1/10W J 47k Ω RRXAJR5Z0473
R1323 CHIP RES.(1608) 1/10W F 100 Ω or RRXAFR5H0101

CHIP RES. 1/10W F 100 Ω RRXAFR5Z0101
R1324 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1325 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1327 CHIP RES.(1608) 1/10W F 10k Ω or RRXAFR5H0103

CHIP RES.(1608) 1/10W F 10k Ω RRXAFR5Z0103
R1328 CHIP RES.(1608) 1/10W F 10k Ω or RRXAFR5H0103

CHIP RES.(1608) 1/10W F 10k Ω RRXAFR5Z0103
R1329 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1330 CHIP RES. 1/10W F 15k Ω or RRXAFR5H0153

CHIP RES.(1608) 1/10W F 15k Ω RRXAFR5Z0153
R1331 CHIP RES.(1608) 1/10W F 10k Ω or RRXAFR5H0103

CHIP RES.(1608) 1/10W F 10k Ω RRXAFR5Z0103
R1332 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1334 CHIP RES.(1608) 1/10W J 2.7k Ω RRXAJR5Z0272
R1335 CHIP RES. 1/10W F 120 Ω or RRXAFR5H1200

CHIP RES. 1/10W F 120 Ω RRXAFR5Z1200
R1336 CHIP RES.(1608) 1/10W F 1.5k Ω or RRXAFR5H0152

CHIP RES.(1608) 1/10W F 1.5k Ω RRXAFR5Z0152
R1337 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222

20050419 1-17-6 E68C4EL

Ref. No. Mark Description Part No.

R1338 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1339 CHIP RES.(1608) 1/10W J 22k Ω RRXAJR5Z0223
R1350 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R1351 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R1358 CHIP RES.(1608) 1/10W J 47k Ω RRXAJR5Z0473
R1360 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R1362 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1365 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1366 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R1367 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1372 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1373 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
R1374 CHIP RES.(1608) 1/10W J 5.6k Ω RRXAJR5Z0562
R1375 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
R1376 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
R1377 CHIP RES.(1608) 1/10W J 6.8k Ω RRXAJR5Z0682
R1378 CARBON RES. 1/4W J 330 Ω RCX4JATZ0331
R1379 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1380 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1382 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1384 CHIP RES.(1608) 1/10W J 150 Ω RRXAJR5Z0151
R1385 CHIP RES.(1608) 1/10W J 150 Ω RRXAJR5Z0151
R1386 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1387 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1390 CHIP RES.(1608) 1/10W J 6.8k Ω RRXAJR5Z0682
R1391 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1392 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471

R1395 PCB JUMPER D0.6-P5.0 JW5.0T

R1396 PCB JUMPER D0.6-P5.0 JW5.0T
R1399 CARBON RES. 1/6W J 27k Ω or RCX6JATZ0273

CARBON RES. 1/4W J 27k Ω RCX4JATZ0273

R1400 CARBON RES. 1/6W J 6.8k Ω or RCX6JATZ0682

CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682
R1401 CHIP RES.(1608) 1/10W J 6.8k Ω RRXAJR5Z0682
R1402 CHIP RES.(1608) 1/10W J 1.5k Ω RRXAJR5Z0152
R1403 CHIP RES.(1608) 1/10W J 12k Ω RRXAJR5Z0123
R1404 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1405 CARBON RES. 1/6W J 180 Ω or RCX6JATZ0181

CARBON RES. 1/4W J 180 Ω RCX4JATZ0181
R1414 CHIP RES.(1608) 1/10W F 200 Ω or RRXAFR5H0201

CHIP RES.(1608) 1/10W F 200 Ω RRXAFR5Z0201
R1421 CHIP RES.(1608) 1/10W F 200 Ω or RRXAFR5H0201

CHIP RES.(1608) 1/10W F 200 Ω RRXAFR5Z0201
R1423 CARBON RES. 1/6W J 150 Ω or RCX6JATZ0151

CARBON RES. 1/4W J 150 Ω RCX4JATZ0151
R1424 CHIP RES.(1608) 1/10W J 150 Ω RRXAJR5Z0151
R1425 CHIP RES.(1608) 1/10W F 200 Ω or RRXAFR5H0201

CHIP RES.(1608) 1/10W F 200 Ω RRXAFR5Z0201
R1426 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
R1430 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
R1431 CHIP RES.(1608) 1/10W F 200 Ω or RRXAFR5H0201

CHIP RES.(1608) 1/10W F 200 Ω RRXAFR5Z0201
R1435 A,C CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1436 A,C CHIP RES.(1608) 1/10W J 220k Ω RRXAJR5Z0224
R1441 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1447 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1448 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1450 CARBON RES. 1/6W J 75 Ω or RCX6JATZ0750

CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R1455 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1456 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1461 A,C CHIP RES.(1608) 1/10W J 6.8k Ω RRXAJR5Z0682
R1462 CHIP RES.(1608) 1/10W F 8.2k Ω or RRXAFR5H0822

CHIP RES.(1608) 1/10W F 8.2k Ω RRXAFR5Z0822
R1463 CHIP RES.(1608) 1/10W F 8.2k Ω or RRXAFR5H0822

CHIP RES.(1608) 1/10W F 8.2k Ω RRXAFR5Z0822
R1464 A,C CHIP RES.(1608) 1/10W J 2.7k Ω RRXAJR5Z0272

Ref. No. Mark Description Part No.

R1465 A,C CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1466 A,C CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1467 A,C CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1468 A,C CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1469 CHIP RES.(1608) 1/10W F 13k Ω or RRXAFR5H0133

CHIP RES.(1608) 1/10W F 13k Ω RRXAFR5Z0133
R1470 CHIP RES.(1608) 1/10W J 13k Ω RRXAJR5Z0133
R1471 CHIP RES.(1608) 1/10W F 13k Ω or RRXAFR5H0133

CHIP RES.(1608) 1/10W F 13k Ω RRXAFR5Z0133
R1472 CHIP RES.(1608) 1/10W J 13k Ω RRXAJR5Z0133
R1476 CHIP RES.(1608) 1/10W F 200 Ω or RRXAFR5H0201

CHIP RES.(1608) 1/10W F 200 Ω RRXAFR5Z0201
R1484 CARBON RES. 1/6W J 100 Ω or RCX6JATZ0101

CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R1488 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1489 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1494 A,C CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1496 A,C CHIP RES.(1608) 1/10W J 5.6k Ω RRXAJR5Z0562
R1497 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
R1498 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
R1499 CHIP RES.(1608) 1/10W J 22k Ω RRXAJR5Z0223
R1500 CHIP RES.(1608) 1/10W J 22k Ω RRXAJR5Z0223
R1502 A,C CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1508 CARBON RES. 1/6W J 100 Ω or RCX6JATZ0101

CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R1511 B CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1512 B CHIP RES.(1608) 1/10W J 1M Ω RRXAJR5Z0105
R1513 A,C CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1516 B CHIP RES.(1608) 1/10W J 3.3k Ω RRXAJR5Z0332
R1517 B CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1518 CHIP RES.(1608) 1/10W J 6.8k Ω RRXAJR5Z0682
R1519 B CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1521 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1523 CARBON RES. 1/6W J 3.3k Ω or RCX6JATZ0332

CARBON RES. 1/4W J 3.3k Ω RCX4JATZ0332
R1527 CHIP RES.(1608) 1/10W J 1.8k Ω RRXAJR5Z0182
R1529 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1530 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1531 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1532 CARBON RES. 1/6W J 1.8k Ω or RCX6JATZ0182

CARBON RES. 1/4W J 1.8k Ω RCX4JATZ0182
R1533 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1534 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1535 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1538 CARBON RES. 1/6W J 30k Ω or RCX6JATZ0303

CARBON RES. 1/4W J 30k Ω RCX4JATZ0303
R1539 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221
R1540 CARBON RES. 1/6W J 75 Ω or RCX6JATZ0750

CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R1541 CARBON RES. 1/6W J 68 Ω or RCX6JATZ0680

CARBON RES. 1/4W J 68 Ω RCX4JATZ0680
R1545 CARBON RES. 1/6W J 220 Ω or RCX6JATZ0221

CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R1546 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R1547 A,C CHIP RES.(1608) 1/10W J 390 Ω RRXAJR5Z0391
R1550 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R1551 CARBON RES. 1/6W J 220 Ω or RCX6JATZ0221

CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R1552 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R1553 CARBON RES. 1/4W J 470 Ω RCX4JATZ0471
R1554 CARBON RES. 1/4W J 470 Ω RCX4JATZ0471
R1555 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1556 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R1557 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R1558 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R1559 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221
R1560 CHIP RES.(1608) 1/10W J 220 Ω RRXAJR5Z0221

20050419 1-17-7 E68C4EL

Ref. No. Mark Description Part No.

R1563 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1565 CARBON RES. 1/6W J 10k Ω or RCX6JATZ0103

CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R1567 CHIP RES.(1608) 1/10W J 330 Ω RRXAJR5Z0331
R1568 CHIP RES.(1608) 1/10W J 330 Ω RRXAJR5Z0331
R1569 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1570 CHIP RES.(1608) 1/10W J 12k Ω RRXAJR5Z0123
R1571 CHIP RES.(1608) 1/10W J 47k Ω RRXAJR5Z0473
R1572 CHIP RES.(1608) 1/10W J 330 Ω RRXAJR5Z0331
R1573 CHIP RES.(1608) 1/10W J 330 Ω RRXAJR5Z0331
R1574 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1575 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1576 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1577 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1578 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1587 CARBON RES. 1/6W J 470 Ω or RCX6JATZ0471

CARBON RES. 1/4W J 470 Ω RCX4JATZ0471
R1588 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1589 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1590 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1591 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1592 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1593 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1594 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1595 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1596 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1597 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1598 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1599 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103

MISCELLANEOUS

2B3 FL HOLDER E6700UD 1VM320515

FL1203 VACUUM FLUORESCENT DISPLAY 7-

JK1201 RCA JACK(YELLOW) MTJ-032-05B-20 JXRL010LY038

JK1202 RCA JACK(WHITE) MTJ-032-05B-22 JXRL010LY039

JK1203 RCA JACK(RED) MTJ-032-05A-21 JYRL010LY010

JK1204 PIN JACK 2P MSD-242V-01 NI FE LF JXRL020LY123

JK1206 RGB CONNECTOR MRC-021V-05 JXGL210LY004

JK1207 A,C FIBER OPTIC TRANS.MODULE 0C-

JK1209 RCA JACK(BLACK) MSP-251V-01 NI or JXRL010LY070

JK1210 PIN JACK 2P MSD-242V-01 NI FE LF JXRL020LY123

JK1211 S TYPE JACK MDC-050V-2.4 JXEL040LY001

JK1212 S TYPE JACK DMD1-3411PP003 JXEL040RP002

JK1213 S TYPE JACK MDC-050V-2.4 JXEL040LY001

JW001 FFC CABLE 30P FFC/P1.00/160 WX1E6820-001

JW002 FFC CABLE 30P FFC/P1.00/70 WX1E6820-002

JW010 FLAT CABLE 3P AWG26#2651/P2.0/100 WX1E6820-006

RM1201 REMOTE RECEIVER MIM-93M6DKF or USESJRSUNT01

TU1201 TUNER UNIT TMDG9-861A UTUNPLGAL015

X1201 XTAL 32.768kHz(20PPM) or FXC323LQUA01

X1202 CERAMIC RESONETOR

X1203 A,C Xtal 1K*044335DA FXC445LDS003

X1204 B Xtal 1K*044335DA FXC445LDS003

BT-301N

0805T*002 or

A,C FIBER OPTIC TRANS.MODULE

GP1FA513TZ0F or

A,C OPTICAL TRANSMITTING MODULE

JST1162

RCA JACK(BLACK) AV1-28A-1 JXRL010RP024

REMOTE RECEIVER PIC-37042LU USESJRSKK033

XTAL 32.768kHz(20PPM) FXC323LDS002

CSTLS8M00G56-B0 or

CERAMIC RESONATOR ZTT8.00MT47 FY0805PLN004

TVFD1C0FT048

JWHHA00JD002

JWHHA00SH006

JWHHA00SLT01

FY0805PMR002

SW CBA

Ref. No. Mark Description Part No.

SW CBA (SUB-B)
Consists of the following:

---------

RESISTORS

R3003 CHIP RES.(1608) 1/10W J 300 Ω RRXAJR5Z0301
R3004 CHIP RES.(1608) 1/10W J 620 Ω RRXAJR5Z0621
R3005 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R3006 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R3007 CHIP RES.(1608) 1/10W J 6.8k Ω RRXAJR5Z0682
R3010 CHIP RES.(1608) 1/10W J 300 Ω RRXAJR5Z0301
R3011 CHIP RES.(1608) 1/10W J 620 Ω RRXAJR5Z0621
R3012 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R3013 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R3014 CHIP RES.(1608) 1/10W J 6.8k Ω RRXAJR5Z0682

SWITCHES

SW3001 TACT SWITCH KSM0612B or SST0101HH003

TACT SWITCH SKQSAB SST0101AL038

SW3002 TACT SWITCH KSM0612B or SST0101HH003

TACT SWITCH SKQSAB SST0101AL038

SW3003 TACT SWITCH KSM0612B or SST0101HH003

TACT SWITCH SKQSAB SST0101AL038

SW3004 TACT SWITCH KSM0612B or SST0101HH003

TACT SWITCH SKQSAB SST0101AL038

SW3005 TACT SWITCH KSM0612B or SST0101HH003

TACT SWITCH SKQSAB SST0101AL038

SW3006 TACT SWITCH KSM0612B or SST0101HH003

TACT SWITCH SKQSAB SST0101AL038

SW3007 TACT SWITCH KSM0612B or SST0101HH003

TACT SWITCH SKQSAB SST0101AL038

SW3008 TACT SWITCH KSM0612B or SST0101HH003

TACT SWITCH SKQSAB SST0101AL038

SW3009 TACT SWITCH KSM0612B or SST0101HH003

TACT SWITCH SKQSAB SST0101AL038

SW3010 TACT SWITCH KSM0612B or SST0101HH003

TACT SWITCH SKQSAB SST0101AL038

PSV CBA

Ref. No. Mark Description Part No.

A,BCPSV CBA

PSV CBA
Consists of the following:

POWER SUPPLY CBA (PSV-A)
JUNCTION CBA (PSV-B)
JACK CBA (PSV-C)

POWER SUPPLY CBA

Ref. No. Mark Description Part No.

POWER SUPPLY CBA (PSV-A)
Consists of the following:

CAPACITORS

C1001! METALLIZED FILM CAP. 0.068µF/250V K orCT2E683DC011

! METALLIZED FILM CAP. 0.068µF/250V K orCT2E683DC014

! METALLIZED FILM CAP. 0.068µF/250V M CT2E683MS037
C1002! ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
! ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100

C1003 CERAMIC CAP. YV Z 0.022µF/50V CCD1JZSYV223

C1004! SAFTY CAP. 2200pF/250V or CCN2EMA0E222

! SAFETY CAP. 2200pF/250V CA2E222MR049
C1005 ELECTROLYTIC CAP. 100µF/400V M CA2H101S6016

C1006 CERAMIC CAP.(AX) X K 1800pF/16V CCA1CKT0X182

C1008 CERAMIC CAP.(AX) B K 1000pF/50V CCA1JKT0B102

C1009 CERAMIC CAP. SL K 56pF/1KV or CCD3AKPSL560

CERAMIC CAP. SL J 56pF/1KV CCD3AJPSL560

C1010 CERAMIC CAP. B K 0.01µF/500V CCD2JKP0B103

C1101 CERAMIC CAP. B K 470pF/500V CCD2JKP0B471

1VSA11293
1VSA11454

---------

---------

---------

---------

20050419 1-17-8 E68C4EL

Ref. No. Mark Description Part No.

C1104 CHIP CERAMIC CAP.(1608) B K 0.01µF/

C1106 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101

C1107 ELECTROLYTIC CAP. 22µF/50V M or CE1JMASDL220

C1108 CHIP CERAMIC CAP.(1608) B K 0.01µF/

C1109 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C1110 ELECTROLYTIC CAP. 1000µF/6.3V M or CE0KMASDL102

C1111 ELECTROLYTIC CAP. 3300µF/6.3V SL or CE0KMZADL332

C1112 ELECTROLYTIC CAP. 1000µF/16V M or CE1CMASDL102

C1113 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C1114 ELECTROLYTIC CAP. 4700µF/6.3V SL or CE0KMZADL472

C1115 CHIP CERAMIC CAP.(1608) B K 0.01µF/

C1116 ELECTROLYTIC CAP. 1000µF/6.3V M or CE0KMASDL102

C1117 ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471

C1120 ELECTROLYTIC CAP. 1000µF/6.3V M or CE0KMASDL102

50V

ELECTROLYTIC CAP. 100µF/16V M CE1CMASTL101

ELECTROLYTIC CAP. 22µF/50V M CE1JMASTL220

50V

50V or

CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or

CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASTL102

ELECTROLYTIC CAP. 3300µF/6.3V M CE0KMZPTL332

ELECTROLYTIC CAP. 1000µF/16V M CE1CMASTL102

ELECTROLYTIC CAP. 4700µF/6.3V M CE0KMZPTL472

50V

ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASTL102

ELECTROLYTIC CAP. 470µF/16V M CE1CMASTL471

ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASTL102

CHD1JK30B103

CHD1JK30B103

CHD1JZ30F104

CHD1EZ30F104

CHD1JK30B103

DIODES

D1001 DIODE 1N5397-B NDLZ001N5397

D1002 DIODE 1N5397-B NDLZ001N5397

D1003 DIODE 1N5397-B NDLZ001N5397

D1004 DIODE 1N5397-B NDLZ001N5397

D1005 SWITCHING DIODE 1N4148M or NDTZ01N4148M

SWITCHING DIODE 1SS133(T-77) QDTZ001SS133

D1006 SWITCHING DIODE 1N4148M or NDTZ01N4148M

SWITCHING DIODE 1SS133(T-77) QDTZ001SS133

D1007 SWITCHING DIODE 1N4148M or NDTZ01N4148M

SWITCHING DIODE 1SS133(T-77) QDTZ001SS133

D1008 SWITCHING DIODE 1N4148M or NDTZ01N4148M

SWITCHING DIODE 1SS133(T-77) QDTZ001SS133

D1009 SWITCHING DIODE 1N4148M or NDTZ01N4148M

SWITCHING DIODE 1SS133(T-77) QDTZ001SS133

D1010 SWITCHING DIODE 1N4148M or NDTZ01N4148M

SWITCHING DIODE 1SS133(T-77) QDTZ001SS133

D1011 RECTIFIER DIODE BA159 or NDQZ000BA159

RECTIFIER DIODE BA159 NDWZ000BA159

D1101 RECTIFIER DIODE BA157 or NDQZ000BA157

RECTIFIER DIODE BA157 NDWZ000BA157

D1102 SCHOTTKY BARRIER DIODE SB380 NDQZ000SB380

D1103 RECTIFIER DIODE BA157 or NDQZ000BA157

RECTIFIER DIODE BA157 NDWZ000BA157

D1104 RECTIFIER DIODE BA157 or NDQZ000BA157

RECTIFIER DIODE BA157 NDWZ000BA157

D1105 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140

SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140

D1107 SCHOTTKY BARRIER DIODE SB240-B/PNDWZ000SB240

D1108 SCHOTTKY BARRIER DIODE SB340 NDQZ000SB340

D1111 ZENER DIODE DZ-6.8BSBT265 or NDTB0DZ6R8BS

ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8

D1112 ZENER DIODE DZ-20BSAT265 or NDTA00DZ20BS

ZENER DIODE MTZJT-7720A QDTA00MTZJ20

D1113 ZENER DIODE DZ-15BSBT265 or NDTB00DZ15BS

ZENER DIODE MTZJT-7715B QDTB00MTZJ15

Ref. No. Mark Description Part No.

ICS

IC1001

!

! PHOTOCOUPLER EL817B or NPEB000EL817

! PHOTOCOUPLER LTV-817B-F or NPEB0LTV817F

! PHOTOCOUPLER PS2561A-1(Q) or QPEQPS2561A1

! PHOTOCOUPLER PS2561A-1(W) QPEWPS2561A1

PHOTOCOUPLER EL817A or NPEA000EL817

COILS

L1001! BEAD CORE ASSEMBLY E6820ED 1VSA11355

L1002 BEAD CORE ASSEMBLY E6820ED 1VSA11355

L1003 BEAD CORE ASSEMBLY E6820ED 1VSA11355

L1004! LINE FILTER 56MH TLF14CB5630R2 or LLBG00ZTU022

! LINE FILTER 50MH LF-4D-E503(PB

L1005 BEAD CORE B16 RH 3.5X10X1.3 XL03010XM001
L1101 INDUCTOR(15µH) CWKB-150K or LLC150KKV005

L1102 INDUCTOR(18µH) CWKB-180K or LLC180KKV005

L1105 CHOKE COIL 47µH or LLBD00PKV022

FREE)

CHOKE COIL(15µH) LHL10NB150K LLARKGQTU150

CHOKE COIL(18µH) LHL10NB180K LLARKGQTU180

RADIAL TYPE CHOKE COIL CW68­470K-841040NP or

CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K or LLBD00PKV005
CHOKE COIL 47µH-K or LLBD00PKT001

FIXED INDUCTORS LGB0810T-470K LLBD00PU6007

LLBG00ZKQ014

LLBD00PKV023

TRANSISTORS

Q1001 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P

TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P

TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F

TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F

TRANSISTOR 2SC2785(J) or QQSJ02SC2785

TRANSISTOR 2SC2785(H) or QQSH02SC2785

TRANSISTOR 2SC2785(F) or QQSF02SC2785

TRANSISTOR KTC3199(Y) or NQSY0KTC3199

TRANSISTOR KTC3199(GR) or NQS10KTC3199

TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815

TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815

Q1002! TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F

! TRANSISTOR 2SC1815-Y(TPE2) QQSY02SC1815

Q1003 FET 2SK3566 QFWZ02SK3566

Q1101 TRANSISTOR KTA1267Y-AT/P or NQSYKTA1267P

TRANSISTOR KTA1267-GR-AT/P or NQS1KTA1267P

TRANSISTOR 2SA1175(J) or QQSJ02SA1175

TRANSISTOR 2SA1175(H) or QQSH02SA1175

TRANSISTOR 2SA1175(F) or QQSF02SA1175

TRANSISTOR KTA1267(Y) or NQSY0KTA1267

TRANSISTOR KTA1267(GR) NQS10KTA1267

RESISTORS

R1002 CARBON RES. 1/4W J 560k Ω RCX4JATZ0564
R1003 CARBON RES. 1/4W J 560k Ω RCX4JATZ0564
R1004 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104

CARBON RES. 1/4W J 100k Ω RCX4JATZ0104

R1005 CARBON RES. 1/6W J 10k Ω or RCX6JATZ0103

CARBON RES. 1/4W J 10k Ω RCX4JATZ0103

R1006 CARBON RES. 1/6W J 470k Ω or RCX6JATZ0474

CARBON RES. 1/4W J 470k Ω RCX4JATZ0474

R1007 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104

CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1009 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1010 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1011 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1012 CARBON RES. 1/6W J 1k Ω or RCX6JATZ0102

CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1013 CARBON RES. 1/4W G 820 Ω RCX4GATZ0821
R1014 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104

CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1016 METAL OXIDE FILM RES. 1W J 2.7 Ω or RN01JZLZ02R7

20050419 1-17-9 E68C4EL

Ref. No. Mark Description Part No.

METAL OXIDE FILM RES. 1W J 2.7 Ω or RN01JZQZ02R7
METAL FILM RES. 1W J 2.7 Ω RN01JZPZ02R7

R1017 CARBON RES. 1/6W J 5.6k Ω or RCX6JATZ0562

CARBON RES. 1/4W J 5.6k Ω RCX4JATZ0562

R1018 CARBON RES. 1/6W J 1k Ω or RCX6JATZ0102

CARBON RES. 1/4W J 1k Ω RCX4JATZ0102

R1019 METAL OXIDE FILM RES. 2W J 82k Ω or RN02JZLZ0823

METAL OXIDE FILM RES. 2W J 82k Ω or RN02JZQZ0823

METAL OXIDE FILM RES. 2W J 82k Ω RN02JZPZ0823
R1020 METAL OXIDE FILM RES. 1W J 1.8 Ω RN011R8ZU001
R1101 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1102 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1103 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R1104 CHIP RES.(1608) 1/10W J 1.8k Ω RRXAJR5Z0182
R1105 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1106 CHIP RES.(1608) 1/10W F 2.2k Ω or RRXAFR5H0222

CHIP RES.(1608) 1/10W F 2.2k Ω RRXAFR5Z0222
R1108 CHIP RES. 1/10W F 5.6k Ω or RRXAFR5H0562

CHIP RES. 1/10W F 5.6k Ω RRXAFR5Z0562
R1109 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102

MISCELLANEOUS

2L019 SCREW S-TIGHT M3X8 BIND HEAD+ GBMS3080

2B11 HEAT SINK E6800ED 1VM420987

AC1001!A,B AC CORD PE8G2CG9G0AB05 WAE0172LW011

AC1001!C AC CORD PE8G2X91H0AA061 WAB0182LW016

F1001! FUSE T1.6AL/250V or PAGC20BW3162

! FUSE 50T016H 1.6A/250V PAGH20BHV162

FH1001 FUSE HOLDER MSF-015 or XH01Z00LY001

FUSE HOLDER DFH-001 XH01Z00RP001

FH1002 FUSE HOLDER MSF-015 or XH01Z00LY001

FUSE HOLDER DFH-001 XH01Z00RP001

T1001! SWITCHING TRANSFORMER BCK-28-

! PULSE TRANS CGS-SW0046J-NP LTT00EPSA181

0575 or

LTT00EPXB020

JUNCTION CBA

Ref. No. Mark Description Part No.

JUNCTION CBA (PSV-B)

Consists of the following:

---------

CONNECTORS

CN1106 242 SERIES CONNECTOR TUC-P15X-

B1 WHT ST or

CONNECTOR 15P TUC-P15X-B1 JCTUS15TG001

JCTUB15TG002

COIL

L2001 BEAD CORE ASSEMBLY E6820ED 1VSA11351

MISCELLANEOUS

2B12 PLATE GROUND(21PIN) H9500ED 0VM415201A

JK2001 RGB CONNECTOR MRC-021V-03 JXGL210LY003

JW1001 FLAT CABLE 8P AWG26#2651/P2.0/70 WX1E6820-005

JW1002 FLAT CABLE 7P AWG26#2651/P2.0/70 WX1E6820-007

JW2001 FLAT CABLE 4P AWG26#2651/P2.0/70 WX3804S6FF07

JW2002 FLAT CABLE 10P AWG26#2651/P2.0/70 WX3810S6FF07

JACK CBA

Ref. No. Mark Description Part No.

JACK CBA (PSV-C)

Consists of the following:

CAPACITORS

C2002 CERAMIC CAP.(AX) X K 2200pF/16V CCA1CKT0X222

C2004 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222

C2005 CHIP CERAMIC CAP.(1608) CH J 470pF/

C2006 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222

C2007 CHIP CERAMIC CAP.(1608) CH J 470pF/

50V or

CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471

50V or

---------

CHD1JJ3CH471

CHD1JJ3CH471

Ref. No. Mark Description Part No.

CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471

C2008 CERAMIC CAP.(AX) B K 1000pF/50V CCA1JKT0B102
C2009 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0

ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0

C2010 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0

ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0

C2011 CHIP CERAMIC CAP.(1608) B K 1000pF/

50V

CHD1JK30B102

DIODES

D2001 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

D2002 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

D2003 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

D2004 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

D2005 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

D2006 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

D2007 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

D2008 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

D2009 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

D2010 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS

ZENER DIODE MTZJT-7711A QDTA00MTZJ11

TRANSISTORS

Q2001 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P

TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P

TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F

TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F

TRANSISTOR 2SC2785(J) or QQSJ02SC2785

TRANSISTOR 2SC2785(H) or QQSH02SC2785

TRANSISTOR 2SC2785(F) or QQSF02SC2785

TRANSISTOR KTC3199(Y) or NQSY0KTC3199

TRANSISTOR KTC3199(GR) or NQS10KTC3199

TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815

TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815

Q2002 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P

TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P

TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F

TRANSISTOR 2SC1815-GR(TE2 F T) or QQS12SC1815F

TRANSISTOR 2SC2785(J) or QQSJ02SC2785

TRANSISTOR 2SC2785(H) or QQSH02SC2785

TRANSISTOR 2SC2785(F) or QQSF02SC2785

TRANSISTOR KTC3199(Y) or NQSY0KTC3199

TRANSISTOR KTC3199(GR) or NQS10KTC3199

TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815

TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815

RESISTORS

R2002 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R2003 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R2005 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R2006 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472

CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R2007 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R2008 CARBON RES. 1/6W J 4.7k Ω or RCX6JATZ0472

CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R2009 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R2010 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R2011 CHIP RES.(1608) 1/10W J 75 Ω RRXAJR5Z0750
R2012 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R2013 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102

20050419 1-17-10 E68C4EL

AFV CBA

Ref. No. Mark Description Part No.

A,BCAFV CBA

AFV CBA
Consists of the following:

CAPACITORS

C1 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C4 CHIP CERAMIC CAP. CH J 56pF/50V or CHD1JJ3CH560

C5 CHIP CERAMIC CAP.(1608) CH J 22pF/

C6 CHIP CERAMIC CAP. CH J 56pF/50V or CHD1JJ3CH560

C7 CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0

C8 CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0

C11 CHIP CERAMIC CAP.(1608) B K 0.01µF/

C12 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C13 CHIP CERAMIC CAP.(1608) B K 0.01µF/

C14 CHIP CERAMIC CAP.(1608) B K 0.01µF/

C15 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C16 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C17 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C19 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C20 ELECTROLYTIC CAP. 3.3µF/50V M H7 CE1JMASSL3R3
C21 CHIP CERAMIC CAP.(1608) F Z 0.1µF/

C22 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C24 ELECTROLYTIC CAP. 0.22µF/50V M H7 CE1JMASSLR22
C27 CERAMIC CAP.(AX) F Z 0.1µF/25V CCA1JZTFZ104

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

CHIP CERAMIC CAP. CG J 56pF/50V CHD1JJ3CG560

50V or

CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220

CHIP CERAMIC CAP. CG J 56pF/50V CHD1JJ3CG560

CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0

CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0

CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0

CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0

50V

50V

50V

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

50V or
CHIP CERAMIC CAP.(1608) F Z 0.1µF/

25V or
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104

CONNECTORS

CN1 ANGLE PIN HEADER 9P IMSA-6029B-1-

09Z003-

DIODES

D2 SWITCHING DIODE 1N4148M or NDTZ01N4148M

SWITCHING DIODE 1SS133(T-77) QDTZ001SS133

ICS

IC1 A,B IC AUDIO PROCESSOR MSP3407G-

IC1 C IC AUDIO PROCESSOR MSP3417G-

QG-B8-V3

QG-B8-V3

COILS

L1 INDUCTOR 10µH-K-26T LLAXKATTU100

L2 PCB JUMPER D0.6-P5.0 JW5.0T
L3 INDUCTOR 18µH-K-26T LLAXKATTU180
L4 INDUCTOR 10µH-K-26T LLAXKATTU100

RESISTORS

R1 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R4 CHIP RES.(1608) 1/10W J 120k Ω RRXAJR5Z0124
R5 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R6 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000

1VSA11126
1VSA11463

CHD1JZ30F104

CHD1EZ30F104

CHD1JJ3CH220

CHD1JK30B103

CHD1JK30B103

CHD1JK30B103

CHD1JZ30F104

CHD1EZ30F104

CHD1JZ30F104

CHD1EZ30F104

CHD1JZ30F104

CHD1EZ30F104

JTED009ER045

NSZBA0SP3004

NSZBA0SP3005

Ref. No. Mark Description Part No.

MISCELLANEOUS

X1 XTAL 18.432MHz FXD186LLN001

20050419 1-17-11 E68C4EL

DR-A2677/DR-A2631/DR-B2737

E68C4/E68C7ED/E68C5BD

2005-05-19
