PRIMERGY RXI300
System configurator and order-information guide
February 2008
Contents
Instructions
Configuration diagram
Configurator
0 Software Configurator
I Basic unit
II Processor
III Memory
IV Hard disk drives
V SCSI / Fibre Channel Controller
VI Disk Array
VII Communication / Network
VIII System Management Products
IX Country specific power cord
Change Report
PRIMERGY Server
System Configurator and Order-Information Guide
PRIMERGY RXI300 Status 2008-01-29
Instructions
This document contains basic product and configuration information that will enable
you to configure your system via PC-/RACK-Architect.
Only these tools will ensure a fast and proper configuration of your PRIMERGY server
or your complete PRIMERGY Rack system.
You can configure your individual PRIMERGY server in order to adjust your specific requirements.
The Order-Information Guide has been split up in 11 chapters that are identical with the current price list and PC-Architect.
Please follow the lines. If there is a junction, you can choose which way or component
you would like to take. Go through the configurator by following the lines from the top to the bottom.
Section
In one chapter you can only select as many components (here 4x) as the arrow indicates.
Please note that there are information symbols which indicate necessary information.
Further information in the internet see:
http://www.primergy.com
(internet)
http://extranet.fujitsu-siemens.com/primergy
(extranet)
Prices and availability see price list and PC-/ System-Architect.
Subject to change and errors excepted.
X times
III
S26361-XXX-XXX S26361-XXX-XXX
Memory XXX MB Memory XXX MB
max. X times per system max. X times per system
Memory, example
There are X memory slots which can be equipped with XXX MB.
It is permissible to make up to X passes through the memory upgrade options.
4x
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
2 of 10
System Configurator and Order-Information Guide
PRIMERGY RXI300 Status 2008-01-29
Configuration diagram PRIMERGY RXI300
TOP View
Extension slots
Disk Array / Fibre Channel ( V )
Communication/Network ( VI )
# 1
# 2
111
203
FRONT VIEW
Hard disk drives, hot-plug ( IV )
Accessible drives
SCSI-ID 0
SCSI-ID 1
Basic unit ( I )
Memory ( III )
Bank 2 (4 modules)
Bank 1 (4 modules)
Processor ( II )
Itanium2 Itanium2
Key:
Slot
PCI Bus
3.5"x1" 3.5"x1"
Power supply
Included in basic unit
Option
PCI Riser with 3 slots
PCI-X 64-Bit / 100MHz, 3.3V, long
PCI-X 64-Bit / 100MHz, 3.3V, long
PCI-X 64-Bit / 133MHz, 3.3V, long
5,25"x 0,5"DVD-ROM
Operating Panel
3. PSU 2. PSU 1. PSU
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
3 of 10
System Configurator and Order-Information Guide
Start "PRIMERGY RXI300"
PRIMERGY RXI300 Status 2008-01-29
http://vil.mch.fsc.net/vil/pc/vil/primergy/overview/prince/index_en.htm
for internal users:
http://vil.mch.fsc.net/vil/oec/special/primergy/index_en.htm
for partners:
http://vilpart.fujitsu-siemens.de/vil/oec/special/primergy/index_en.htm
SW Configurator
with OEM-Software
for PRIMERGY Server
For all SW products please refer to the corresponding software configurator accessible via
the Extranet under Configuration & Tools, -All configurations, -Software, URL see below.
Microsoft - Software: W **) Linux - Software: **)
- Windows Server 2003 R2, - SuSE Linux ES (OEM): LO
Enterprise x64 Edition - SuSE Linux ES (Support): LS
- Additional loose - Red Hat EL (OEM): LO
Client-Access-Lizenzen (CALs) - Red Hat EL (Support): LS
**) Pay attention to release and order information in PRINCE -> Operating System
You'll find single software configurators and release lists (OS-matrix / system management / security) under following addresses:
Continue with PRIMERGY
HW configurator
Enterprise Products - PRIMERGY Server
Fujitsu Siemens Computers
4 of 10
System Configurator and Order-Information Guide
Start PRIMERGY RXI300
PRIMERGY RXI300 Status 2008-01-29
Section
PRIMERGY RXI300
Rack unit 2U - 3 bays for 350W hot-plug power supply moduls,
Basic unit with: (PSU redundancy restricted to 240V operation),
- 1x Itanium 2 processor (max 2) 2 sep. AC inlets
4 GB main memory - Fan unit with 6x60mm hot swap, variable speed fans
1.6GHz / 3MB TLC (Madison) S26361-K963-V210 - I/O Riser board with 3 PCI-X slots
9015 (1.4GHz/12MB TLC) (Montecito) S26361-K963-V944 2xPCI-X long with 100MHz
PRIMERGY PRIMECENTER- Rack 1x RS-232 (serial, RJ45 connector) in back
SNP:SY-F1647E301-P This service is to be ordered once 2x LAN 10/100/1000 (RJ45) in back
Installation ex works for one per installable server/storage 1xVHDCI SCSI connector
server or subsystem. subsystem, in order to get the no PS/2 connection for KB / Mouse
Hereby the rack will be delivered server/storage subsystem (USB connectivity must be used instead)
completely pre-mounted and mounted into the PRIMERGY racks. IA64 Server Support CD, User Manual
all wired connections are tested. In case of the 46 U PRIMERGY rack,
With racks 12U, 24U, 38U: this service has to be ordered,
Systems and components to get the mounting kits and the ServerView:
will be delivered installed in the rack cables installed FSC IA64 Server Support CD
With racks 46U: for EFI service partition
Systems and components
will be delivered separately
To be ordered only together with
a PRIMERGY- Mounting kit for PRIMERGY RXI300 is part of the basic unit
PRIMECENTER rack - 1 pair of telescopic rails (647 - 810mm)
e.g.: - 1 bracket DC-PC-Rack
S26361-K826-V10x - 1 cable management for DC-PC-racks
refer configurator PC-Rack Mounting kit for mounting of servers in in FSC 19" DataCenter- and
max. 1x per System
I
S26113-F602-E350 one CPU installed according to the configurator
3rd power supply module (PSU) thermal blank in other socket if 2nd CPU not installed
for 2+1 redundancy (350W) - 2 memory banks with 4 DIMM memory slots each
max. 1x per system for up to 16GB PC2100 registered DDR RAM with ECC
Basic unit
Basic Unit including:
2U Chassis with
2 hot plug moduls installed, 3rd modul req. for redundancy
- 2xSCSI HD drive bays with hot swap backplane
1xPCI-X long with 133MHz
- 1x IDE CDROM/DVD-ROM Combodrive
- Front panel board and front bezel
* Rack- mounting kit (sliding rail´s)
- telescopic rails kit
- cable management arm
* Systemboard with
- 2 Itanium CPU sockets
one bank installed according to the configurator
- onboard dual channel Ultra 320 SCSI
first ch.for int. Drives (SCSI backplane), RAID 1 support
second ch. for ext. SCSI devices
- dual port LAN-Controller 10/100/1000TX
- VGA Controller (8MB RAM) on-board (ATI Rage XL)
- External Interfaces:
2x VGA ports, 1 in front, 1 in back
"Rack-mounting ex factory" 4x USB 1.1, 2 in front, 2 in back
PRIMECENTER- racks and all server racks conforming to EIA standard
EIA-310-D for 19" racks.
Therefore the mounting kit is variable in depth from 647 - 810mm
A
- Connetion for KVM switch / Rack console
- RC22 can be directly connected (both USB and PS/2 connections)
- KVM S2 series needs the KVM S2 adapter USB-VGA
- For PS/2 KVM "S1" series as well as for standard PS/2 KB / Mouse
an additional USB to PS/2 adapter must be bought additionally and
connected to the RXI600. The adapter offers 2 x PS/2 ports.
Adaper order number, to purchase via PRIMEPOWER, is
D:GP70P-KA01 Adapter for PS/2<->USB
- Appropriate FSC USB keyboard is S26381-K340-V1*
This keyboard also needs USB cable T26139-Y3812-V1
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
5 of 10
System Configurator and Order-Information Guide
A
PRIMERGY RXI300 Status 2008-01-29
1.6 GHz
1.4GHz
3 MB
12 MB
up to
Section
up to
1x heat sink and "Easy retention" heat sink and "Easy retention"
Section
up to
1x
II
S26361-F3071-E263 S26361-F3071-E412
Itanium 2
with
(Intel Codename "Fanwood")
occupies 2nd CPU socket occupies 2nd CPU socket
max. 1x per system max. 1x per system
III
S26361-F3070-E400 S26361-F3070-E800
Main memory 4 GB Main memory 8 GB
PC2100 registered DDR RAM PC2100 registered DDR RAM
consisting of 4 modules consisting of 4 modules
with 1 GB each with 2 GB each
occupies one bank occupies one bank
max. 1x per system max. 1x per system
Processor
A two-way-processor system requires a multi-processor operating system.
Later upgrading to a two-way-processor system is also possible.
For a CPU extension the further CPUs must be of identical TLC (third level cache) and clock rate.
TLC on Chip, with
Memory
There are 8 memory slots available (2 banks, 4 modules each).
They can optionally be equipped with 1GB or 2GB registered DDR-RAM modules (PC2100).
The maximal extension is 16GB with 2GB modules!
Any mix of modules within one memory bank is not allowed.
One memory bank is allready occupied
Itanium 2 9015
TLC on Chip,
2x
Section
IV
S26361-F3066-E173 S26361-F3066-E114
Hard disk 73GB / 10K Hard disk 146GB / 10K
10000rpm,<5.5ms, min. 8MB Cache 10000rpm,<5.5ms, min. 8MB Cache
Ultra 320 SCSI (320MB/s) Ultra 320 SCSI (320MB/s)
Interface: Wide SCA (80-pin) Interface: Wide SCA (80-pin)
hot plug/hot replace tray hot plug/hot replace tray
occupies one 1" bay occupies one 1" bay
onb. SCCI or RAID Controller onb. SCCI or RAID Controller
max. 2x per system max. 2x per system
S26361-F3066-E130 S26361-F3066-E573
Hard disk 300GB / 10K Hard disk 73GB / 15K
10000rpm,<5.5ms, min. 8MB Cache 15000rpm,<4ms, min. 8MB Cache
Ultra 320 SCSI (320MB/s) Ultra 320 SCSI (320MB/s)
Interface: Wide SCA (80-pin) Interface: Wide SCA (80-pin)
hot plug/hot replace tray hot plug/hot replace tray
occupies one 1" bay occupies one 1" bay
onb. SCCI or RAID Controller onb. SCCI or RAID Controller
max. 2x per system max. 2x per system
Hard disk drives
Standard PRIMERGY harddisks must be ordered for upgrade.
To use these harddisks in the RXI300 a simple frame change must be carried out.
Upgrade harddisks are always delivered with standard PRIMERGY harddisk frames.
Unused harddisk positions in the PRIMERGY RXI300 are always equipped with fully
functional empty harddisk frames. Therefore, after the standard frame is removed, the
harddisk has to be mounted in the RXI300 specific empty frame.
The following harddisks are technically released for usage in the PRIMERGY RXI300:
S26361-F3121-L173 HDD U320 10k 73GB hot plug 1"
S26361-F3121-L114 HDD U320 10k 146GB hot plug 1"
S26361-F3121-L130 HDD U320 10k 300GB hot plug 1"
S26361-F3121-L573 HDD U320 15k 73GB hot plug 1"
B
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
6 of 10
System Configurator and Order-Information Guide
B
PRIMERGY RXI300 Status 2008-01-29
Section
included in the basic unit The system is equipped with a onboard dual channel Ultra 320 SCSI controller.
onboard 2 ch.SCSI Controller U320
connectivity
1) for int. Drives, RAID 1 on-board controller with hot swap support.
2) ext. VHDCI
Section
V
Fibre Channel controller for subsystems and SAN
S26361-F3141-E10
2GBit/s FC Controller
Emulex
LP1050, full height bracket
1 channel 2GBit/sec FC controller
LC Interface for 50um Fiber
PCI-X 64Bit / 133MHz, 170mm
3.3V / 5V tolerant signaling
max. 2x per system
VI
Additional RAID Controllers for connection of external Disk Arrays in Subsystem SX31
S26361-F3006-E128
2-channel RAID Controller U320
LSI
320-2
128MB SDRAM ECC Cache
RAID 0, 1, 10, 5 & 50
default with TBBU
plug: internal 1x HD68;
external: 1x VHDCI
without cable
incl. SW and description (Ger/US)
64/66 PCI controller, 180mm
3.3V and 5V tolerant signaling
max. 2x per system
SCSI / Fibre Channel Controller
one channel can be connected to internal devices via the SCSI blackplane.
The two int. HDD's can be mirrored if they are connected to the
The other SCSI channel can be used by external SCSI devices.
Disk Array
The cables of the connection from the
subsystems (SX30) to the Raid
Controllers, see configurator SX30
All Controllers for the connection of external storage systems are delivered without cables.
For the configuration of external cabling see the configurator for external storage systems.
C
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
7 of 10
System Configurator and Order-Information Guide
C
PRIMERGY RXI300 Status 2008-01-29
3x
Section
VII
on-board LAN Controller
dual Gb Ethernet Contr. on-board Teaming: Failover, Load Balancing
ext: 2 x RJ 45 connector
Single Port LAN Adapter
S26361-F3054-E1 S26361-F3053-E1
Gigabit Ethernet Contr. 1000SX Gigabit Ethernet Contr. 1000TX
Eth.Ctrl 1x1Gbit PCI-X Pro/1000MF LC Eth.Ctrl 1x1Gbit PCI-X Pro/1000MT Cu
Intel PRO/1000 MF Server Adapter Intel PRO/1000 MT Server Adapter
Adapter Teaming Support Adapter Teaming Support
PCI-X (PCI64/133), min 165 mm PCI-X (PCI64/133), min 165 mm
ext:LC-connector ext: for RJ45-connector, Cat 5
SW: VLAN, Fast & Gbit Etherchannel SW: VLAN, Fast & Gbit Etherchannel
max. 2x per system max. 2x per system
Dual Port LAN Adapter
S26361-F3011-E1
Gigabit Ethernet Contr dual 1000TX
Eth.Ctrl 2x1Gbit PCI-X PRO/1000MT Cu
Intel Pro/1000MT dual Server Adapter
Adapter Teaming Support
PCI-X (PCI64/66), min 163 mm
ext: for RJ45-plug, Cat 5
connection with Cat 5 cabling
SW: VLAN, Fast & Gbit Etherchannel
max. 2x per system
Communication / Network
All released Intel PCI LAN Controllers can be used with the
on-board controller in Teaming Mode.
connection with Cat 5 cabling
D
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
8 of 10
System Configurator and Order-Information Guide
D
PRIMERGY RXI300 Status 2008-01-29
Section
Section
VIII
IX
System Management Products
FSC IA64 Server Support CD
The CD contains tools for installing of the system,
for update and for system diagnose.
The tools works in the EFI system partition.
Included in the basic unit.
Country specific power cord
Country specific power cords are not required for rack versions, except for USA&Canada.
Power cords are shipped in a rack version with inlet connector for non-heating apparatus.
Description in englisch. Both included in basic unit.
T26139-Y1742-L10 USA, Canada
For shipments to USA&Canada, you have to order
two power cords (1,8m, grey). For phase redundancy
2 Power Cords and 3 PSU's per system are needed.
End PRIMERGY RXI300
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
9 of 10
System Configurator and Order-Information Guide
Date
order number
changes
PRIMERGY RXI300 Status 2008-01-29
Change Report
2006-11-02 S26361-F3071-E269 Processor Itanium2 1.6GHz / 9MB TLC - no longer available
2006-11-02 S26361-K963-V212 Rack mountable server 19" (2U) 1.6GHz / 9MB TLC / 4GB Memory - no longer available
2006-11-02 S26361-K963-V213 Rack mountable server 19" (2U) 1.6GHz / 9MB TLC / 8GB Memory - no longer available
2006-08-24 S26361-F3071-E412 Processor Itanium2 9015 1.6GHz / 12MB TLC 400MHz FSB - now available
2006-08-25
2006-08-25
2005-12-20
2005-09-23
2005-06-02 S26361-F3066-E136 Hard disk 36GB / 10K - no longer available
2005-04-20 S26361-F3066-E130 Hard disk 146GB / 10K - now available
2005-04-07
2005-01-21
2004-12-17
2004-12-17
2004-11-05
2004-11-05
2004-11-05
2004-11-05
2004-11-05
2004-11-05
2004-05-12
S26361-K963-V948
S26361-K963-V944
S26361-F2843-E1 2GBit/s FC Controller Emulex LP9802, PCI - no longer available
S26361-F3141-E10 2GBit/s FC controller Emulex LP1050 - now available
Section IV Basic unit without HDDs - now available
S26361-F3066-E173 Hard disk 73GB / 10K - now available
S26361-F3071-E1xx 2. Processor Itanium 2 (Madison) - no longer available
S26361-K963-V20x Basic units with Itanium 2 (Madison) processor - no longer available
S26361-F3071-E263 Processor Itanium2 1.6GHz / 3MB TLC Fanwood - now available
S26361-F3071-E269 Processor Itanium2 1.6GHz / 9MB TLC - now available
S26361-K963-V210 Rack mountable server 19" (2U) 1.6GHz / 3MB TLC Fanwood / 4GB Memory - now available
S26361-K963-V211 Rack mountable server 19" (2U) 1.6GHz / 3MB TLC Fanwood / 8GB Memory - now available
S26361-K963-V212 Rack mountable server 19" (2U) 1.6GHz / 9MB TLC / 4GB Memory - now available
S26361-K963-V213 Rack mountable server 19" (2U) 1.6GHz / 9MB TLC / 8GB Memory - now available
Rack mountable server 19" (2U) Itanium 2 9015 dual core processor; 8 GB Memory - now available
Rack mountable server 19" (2U) Itanium 2 9015 dual core processor; 4 GB Memory - now available
First draft
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
10 of 10
Loading...
