Fujitsu RX600 S6 User Manual

Operating Manual - English

PRIMERGY RX600 S6 Server

Operating Manual

July 2011

Comments… Suggestions… Corrections…

The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.

Feel free to send us your comments by e-mail to

E-Mail: [e-mail].

Certified documentation
according to DIN EN ISO 9001:2008

To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2008.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Copyright and Trademarks

Copyright © 2011 Fujitsu Technology Solutions GmbH.

All rights reserved.

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

– The contents of this manual may be revised without prior notice.

– Fujitsu assumes no liability for damages to third party copyrights or other rights arising from

the use of any information in this manual.

– No part of this manual may be reproduced in any form without the prior written permission

of Fujitsu.

Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of
Microsoft Corporation in the USA and other countries.

Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries
in the USA and other countries.

Before reading this manual

For your safety

This manual contains important information for safely and correctly using this
product.

Carefully read the manual before using this product. Pay particular attention to
the accompanying manual "Safety Notes and Regulations" and ensure these
safety notes are understood before using the product. Keep this manual and the
manual "Safety Notes and Regulations" in a safe place for easy reference while
using this product.

Radio interference

This product is a "Class A" ITE (Information Technology Equipment). In a
domestic environment this product may cause radio interference, in which case
the user may be required to take appropriate measures. VCCI-A

Aluminum electrolytic capacitors

The aluminum electrolytic capacitors used in the product's printed circuit board
assemblies and in the mouse and keyboard are limited-life components. Use of
these components beyond their operating life may result in electrolyte leakage
or depletion, potentially causing emission of foul odor or smoke.

As a guideline, in a normal office environment (25°C) operating life is not
expected to be reached within the maintenance support period (5 years).
However, operating life may be reached more quickly if, for example, the
product is used in a hot environment. The customer shall bear the cost of
replacing replaceable components which have exceeded their operating life.
Note that these are only guidelines, and do not constitute a guarantee of
trouble-free operation during the maintenance support period.

High safety use

This product has been designed and manufactured for general uses such as
general office use, personal use, domestic use and normal industrial use. It has
not been designed or manufactured for uses which demand an extremely high
level of safety and carry a direct and serious risk to life or body if such safety
cannot be ensured.

RX600 S6 Operating Manual

These uses include control of nuclear reactions in nuclear power plants,
automatic airplane flight control, air traffic control, traffic control in mass
transport systems, medical devices for life support, and missile guidance
control in weapons systems (hereafter, "high safety use"). Customers should
not use this product for high safety use unless measures are in place for
ensuring the level of safety demanded of such use. Please consult the sales
staff of Fujitsu if intending to use this product for high safety use.

Measures against momentary voltage drop

This product may be affected by a momentary voltage drop in the power supply
caused by lightning. To prevent a momentary voltage drop, use of an AC
uninterruptible power supply is recommended.

(This notice follows the guidelines of Voltage Dip Immunity of Personal
Computer issued by JEITA, the Japan Electronics and Information Technology
Industries Association.)

Technology controlled by the Foreign Exchange and Foreign Trade
Control Law of Japan

Documents produced by Fujitsu may contain technology controlled by the
Foreign Exchange and Foreign Trade Control Law of Japan. Documents which
contain such technology should not be exported from Japan or transferred to
non-residents of Japan without first obtaining authorization in accordance with
the above law.

Harmonic Current Standards

This product conforms to harmonic current standard JIS C 61000-3-2.

Only for the Japanese market: About SATA hard disk drives

The SATA version of this server supports hard disk drives with SATA / BC-SATA
storage interfaces. Please note that the usage and operation conditions differ
depending on the type of hard disk drive used.

Please refer to the following internet address for further information on the
usage and operation conditions of each available type of hard disk drive:

http://primeserver.fujitsu.com/primergy/harddisk/

Operating Manual RX600 S6

Only for the Japanese market:

I Although described in this manual, some sections do not apply to the

Japanese market. These options and routines include:

– CSS (Customer Self Service)

– Replacing the lithium battery

RX600 S6 Operating Manual

Operating Manual RX600 S6

Contents

1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

1.1 Concept and target groups for this manual . . . . . . . . . 11

1.2 Documentation overview . . . . . . . . . . . . . . . . . . . 12

1.3 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . 22

1.5 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . 22

2 Overview of the installation steps . . . . . . . . . . . . . . . 25

3 Important information . . . . . . . . . . . . . . . . . . . . . 27

3.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 27

3.2 ENERGY STAR . . . . . . . . . . . . . . . . . . . . . . . . . 35

3.3 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 35

3.4 FCC Class A Compliance Statement . . . . . . . . . . . . . 36

3.5 Transporting the server . . . . . . . . . . . . . . . . . . . . 37

3.6 Notes on installing the server in the rack . . . . . . . . . . . 38

3.7 Environmental protection . . . . . . . . . . . . . . . . . . . 39

4 Hardware installation . . . . . . . . . . . . . . . . . . . . . . 41

4.1 Unpacking the server . . . . . . . . . . . . . . . . . . . . . 42

4.2 Rack installation/removal of server . . . . . . . . . . . . . . 43

4.2.1 Rack system requirements . . . . . . . . . . . . . . . . . . . 43

4.2.2 Mounting the server into the rack . . . . . . . . . . . . . . . . 46

4.3 Connecting devices to the server . . . . . . . . . . . . . . . 47

4.4 Connecting the server to the mains . . . . . . . . . . . . . . 49

4.4.1 Installation requirements . . . . . . . . . . . . . . . . . . . . . 49

4.4.2 Connecting the power cord . . . . . . . . . . . . . . . . . . . 54

RX600 S6 Operating Manual

Contents

4.5 Notes on connecting/disconnecting cables . . . . . . . . . . 55

5 Starting up and operation . . . . . . . . . . . . . . . . . . . . 57

5.1 Control elements and indicators . . . . . . . . . . . . . . . . 57

5.1.1 Front of server . . . . . . . . . . . . . . . . . . . . . . . . . . 57

5.1.1.1 Control elements . . . . . . . . . . . . . . . . . . . . . . . 59

5.1.1.2 Indicators on the control panel . . . . . . . . . . . . . . . . 60

5.1.1.3 Indicators on the accessible drives/components . . . . . . . 61

5.1.1.4 Indicators on the hot-plug HDD/SSD modules . . . . . . . . 62

5.1.2 Rear of server . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

5.1.2.1 Global Error indicator and CSS indicator . . . . . . . . . . . 63

5.1.2.2 ID indicator and button . . . . . . . . . . . . . . . . . . . . 65

5.1.2.3 Indicators on the connector panel (LAN indicators) . . . . . . 66

5.1.2.4 Indicators on the hot-plug power supply units . . . . . . . . . 67

5.2 Switching the server on and off . . . . . . . . . . . . . . . . 69

5.3 Configuring the server . . . . . . . . . . . . . . . . . . . . . 72

5.3.1 Configuring the SAS/SATA RAID controller card . . . . . . . . . 72

5.3.2 Configuring the server and installing the operating system

with the ServerView Installation Manager . . . . . . . . . . . . . 73

5.3.3 Configuring the server and installing the operating system

without the ServerView Installation Manager . . . . . . . . . . . 74

5.4 Cleaning the server . . . . . . . . . . . . . . . . . . . . . . . 75

6 Property and data protection . . . . . . . . . . . . . . . . . . 77

6.1 Mechanical access protection . . . . . . . . . . . . . . . . . 77

6.2 BIOS Setup security functions . . . . . . . . . . . . . . . . . 77

7 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 79

7.1 Power-on indicator remains unlit . . . . . . . . . . . . . . . . 79

7.2 Server switches itself off . . . . . . . . . . . . . . . . . . . . 79

7.3 Screen remains blank . . . . . . . . . . . . . . . . . . . . . . 80

7.4 Flickering stripes on monitor screen . . . . . . . . . . . . . 81

7.5 No screen display or display drifts . . . . . . . . . . . . . . . 81

Operating Manual RX600 S6

Contents

7.6 Incorrect date and time . . . . . . . . . . . . . . . . . . . . 82

7.7 Drives reported as "dead" when starting system . . . . . . 82

7.8 Added drive reported as defective . . . . . . . . . . . . . . 82

7.9 Error message on screen . . . . . . . . . . . . . . . . . . . 83

8 CSS components . . . . . . . . . . . . . . . . . . . . . . . . 85

8.1 Hot-plug components . . . . . . . . . . . . . . . . . . . . . 87

8.1.1 Hot-plug power supply units . . . . . . . . . . . . . . . . . . 87

8.1.1.1 Replacing a hot-plug power supply unit . . . . . . . . . . . 88

8.1.1.2 Adding a hot-plug power supply unit . . . . . . . . . . . . . 89

8.1.2 Hot-plug fans . . . . . . . . . . . . . . . . . . . . . . . . . . 91

8.1.2.1 Replacing a defective fan . . . . . . . . . . . . . . . . . . 92

8.1.2.2 Adding new fans . . . . . . . . . . . . . . . . . . . . . . . 93

8.1.3 Hot-plug HDD/SSD modules . . . . . . . . . . . . . . . . . . 94

8.1.3.1 HDD/SSD module and dummy module . . . . . . . . . . . 96

8.1.3.2 Removing/installing the dummy module . . . . . . . . . . . 97

8.1.3.3 Installing the HDD/SSD module . . . . . . . . . . . . . . . 98

8.1.3.4 Removing the HDD/SSD module . . . . . . . . . . . . . . 99

8.1.4 Hot-plug expansion cards . . . . . . . . . . . . . . . . . . . . 101

8.1.4.1 Identifying the defective CSS component . . . . . . . . . . 103

8.1.4.2 Removing a hot-plug expansion card . . . . . . . . . . . . 103

8.1.4.3 Removing a dummy module . . . . . . . . . . . . . . . . . 106

8.1.4.4 Installing a hot-plug expansion card . . . . . . . . . . . . . 107

8.1.5 Hot-plug memory boards . . . . . . . . . . . . . . . . . . . . 109

8.1.5.1 Identifying the defective memory . . . . . . . . . . . . . . . 110

8.1.5.2 Removing the memory board in question . . . . . . . . . . 111

8.1.5.3 Removing a defective memory module . . . . . . . . . . . 111

8.1.5.4 Installing a new memory module . . . . . . . . . . . . . . . 113

8.1.5.5 Reinstalling the memory board in question . . . . . . . . . 113

8.1.5.6 Adding a memory board . . . . . . . . . . . . . . . . . . . 114

8.2 Non-hot-plug components . . . . . . . . . . . . . . . . . . . 116

8.2.1 Identifying the defective CSS component . . . . . . . . . . . . 117

8.2.2 Replacing a non-hot-plug expansion card . . . . . . . . . . . . 117

8.2.2.1 Removing a non-hot-plug expansion card . . . . . . . . . . 117

8.2.2.2 Installing a non-hot-plug expansion card . . . . . . . . . . . 118

8.2.3 Replacing SFP+ transceiver modules . . . . . . . . . . . . . . 119

8.2.3.1 Removing an SFP+ transceiver module . . . . . . . . . . . 119

8.2.3.2 Installing SFP+ transceiver modules . . . . . . . . . . . . 121

RX600 S6 Operating Manual

Contents

8.3 Opening/Closing the server . . . . . . . . . . . . . . . . . . 125

8.3.1 Opening the server . . . . . . . . . . . . . . . . . . . . . . . 125

8.3.2 Closing the server . . . . . . . . . . . . . . . . . . . . . . . . 127

9 Appendix: server specification . . . . . . . . . . . . . . . . 129

Operating Manual RX600 S6

1 Preface

The scalable PRIMERGY RX600 S6 server is an Intel-based rack server for
critical company scenarios, e.g. as database management system for medium
or large-sized databases or as a consolidation basis to run an immensely large
number of different applications using virtualization technologies.

Thanks to its highly developed hardware and software components, the server
offers a high level of data security and availability. These include hot-plug
HDD/SSD modules, hot-plug system fans, and also hot-plug power supply
units, the Server Management ServerView Suite, Prefailure Detection and
Analysis (PDA) and Automatic Server Reconfiguration and Restart (ASR&R).

Security functions in the BIOS Setup and on the system board protect the data
on the server against manipulation. Additional security is provided by the
lockable rack door.

The server occupies 4 height units (HU) in the rack.

1.1 Concept and target groups for this manual

This operating manual describes how to install, set up and operate your server.

This operating manual is intended for those responsible for installing the
hardware and ensuring that the system runs smoothly. It contains all the
information you need to put your PRIMERGY RX600 S6 into operation.

To understand the various expansion options, you will need to be familiar with
the fields of hardware and data transmission and you will require a basic
knowledge of the underlying operating system.

RX600 S6 Operating Manual 11

Preface

1.2 Documentation overview

More information on your PRIMERGY RX600 S6 can be found in the following
documents:

– "Quick Start Hardware - PRIMERGY RX600 S6" leaflet

" はじめにお読みください -PRIMERGY RX600 S6" for the Japanese market
(only included as a printed copy)

– "Quick Start Software - Quick Installation Guide" DVD booklet

(only included with the ServerView Suite as a printed copy)

– "Safety Notes and Regulations" manual

" 安全上のご注意 " for the Japanese market

– "Warranty" manual

" 保証書 " for the Japanese market

– "ServerView Suite Local Service Concept - LSC" manual

– "Returning used devices" manual and "Service Desk" leaflet

" サポート＆サービス " for the Japanese market

– "PRIMERGY RX600 S6 Server Operating Manual"

– "PRIMERGY RX600 S6 Server Options Guide"

– "System Board D3141 for PRIMERGY RX600 S6 Technical Manual"

– "System Board D3141 BIOS Setup Utility for PRIMERGY RX600 S6"

manual

12 Operating Manual RX600 S6

I PRIMERGY manuals are available in PDF format on the

ServerView Suite DVD 2. The ServerView Suite DVD 2 is part of the
ServerView Suite supplied with every server.

If you no longer have the ServerView Suite DVDs, you can obtain the
relevant current versions using the order number U15000-C289 (the
order number for the Japanese market: please refer to the configurator
of the server http://primeserver.fujitsu.com/primergy/system/).

The PDF files of the manuals can also be downloaded free of charge
from the Internet. The overview page showing the online documentation
available on the Internet can be found using the URL (for EMEA market):

http://manuals.ts.fujitsu.com. The PRIMERGY server documentation can

be accessed using the Industry standard servers navigation option.

For the Japanese market:

Please refer to the following URL for the latest product manuals:

http://primeserver.fujitsu.com/primergy/manual/

Before using the product, please check for additional information that
may be available under the following URL:

http://primeserver.fujitsu.com/primergy/products/note/

Further sources of information:

Preface

– ServerView Suite Glossary on the ServerView Suite DVD 2
– Manual for the monitor
– Documentation for the boards and drives
– Operating system documentation
– Information files in your operating system

RX600 S6 Operating Manual 13

Preface

1.3 Features

Customer Self Service (CSS)

The PRIMERGY Customer Self Service (CSS) concept enables you to identify
and replace the affected component yourself in the case of certain error
scenarios.

In the CSS concept, you can replace the following components yourself in the
event of an error:

– Hot-plug hard disk drives and solid state disks

– Hot-plug power supply units

– Hot-plug Memory modules

– Hot-plug System fans

– Expansion cards (as soon as released)

For information on replacing these components, see chapter "CSS

components" on page 85.

CSS indicators on the control panel and on the back of the PRIMERGY server
provide you with information if a CSS event arises (for more information on the
behavior of these indicators, see chapter "Starting up and operation" on

page 57 and the "ServerView Suite Local Service Concept - LSC" manual on

the ServerView Suite DVD 2).

Your server is equipped with a ServerView Local Service Display, which enables
you to identify the type of component affected by the error directly on the server
(for more information, see the "ServerView Suite Local Service Concept - LSC"
manual on the ServerView Suite DVD 2).

In addition, CSS errors are displayed in the ServerView Operations Manager,
the server management software from Fujitsu.

In the event of errors, the ServerView Operations Manager refers you directly
to the affected component and its order information in the Illustrated Spares
catalog of the server in question. (This feature is not available for the Japanese
market.)

14 Operating Manual RX600 S6

Preface

System board

The features of the system board are described in the "System Board D3141 for
PRIMERGY RX600 S6 Technical Manual" for the hardware and in the "System
Board D3141 BIOS Setup Utility for PRIMERGY RX600 S6" manual for the
firmware.

Hot-plug PCI slots

The server has ten PCI-Express slots, where two of them are hot-plug slots.
These hot-plug PCI-Express slots allow installation and removal of boards
during operation when the operating system supports this function (for further
details see section "Hot-plug expansion cards" on page 101).

Hard disk drives

The server can be equipped with up to 8 HDD/SSD modules. Each HDD/SSD
module can accommodate an HDD/SSD drive with a 2.5-inch format. The
modules are connected to the SAS/SATA backplane wirelessly. This allows
HDD/SSD modules to be plugged in or pulled out easily.

The hard disk system is designed for SAS/SATA with one channel for each hard
disk drive.

If the server has the corresponding RAID configuration, HDD/SSD modules can
also be replaced during operation.

SAS/SATA controller card (optionally with RAID controller)

The SAS/SATA controller card for operating up to eight SAS/SATA hard disk
drives can be alternately without or with RAID functionality. In case of RAID
functionality the levels 0, 1, 1E, 5, 6, 10, 50 and 60 are supported.

Battery Backup Units

Up to two intelligent Battery Backup Units (iBBUs) back up the memory contents
of their corresponding RAID controllers in the event of power failure (option).

Accessible drives/components

A number of mounting locations are available:

– An installation slot for a ServerView Local Service Display (standard)
– An installation slot for a slimline DVD/BD drive (option)
– A 5.25-inch bay for a magnetic tape drive (option)

RX600 S6 Operating Manual 15

Preface

The accessible drives/components integrated in these locations cannot be
replaced during operation.

Power supply

The server has up to four hot-plug power supply units that automatically switch
to a mains voltage of 100 - 127 V / 200 - 240 V. This ensures redundant power
supply. If one power supply unit is defective, the other(s) then guarantee(s)
unimpaired operation. The faulty power supply unit can be replaced during
operation (for further details see "Hot-plug power supply units" on page 87).

Cooling

Each processor has a heat sink. Further cooling for the installed processors is
provided by hot-plug fans (optionally in a redundant configuration).

Temperature sensors variably adjust the fans. If a temperature sensor fails or is
removed, the fans affected run at maximum speed so as to provide the greatest
possible protection for the hardware.

If a fan fails, unimpaired further operation is ensured. A defective fan module
can be replaced during operation (for further details see "Hot-plug fans" on

page 91).

High level of availability and data security

When memory data is accessed, 1-bit errors in the main memory are identified
and automatically corrected with the ECC (Error Correcting Code) method. The
patented memory scrubbing function regularly starts up the EDC mechanism
(Error Detection Code) and thus ensures continuous data integrity.

The memory modules used support SDDC technology (Chipkill™), which
further increases the effectiveness of memory error monitoring and correction.

Support is likewise provided for hot-spare memory technology, in which a
memory module is used like a replacement module. If a memory module fails,
the module with the defective memory is automatically deactivated and the
replacement module is activated (provided it has been configured for
appropriately in the BIOS). The deactivated memory module is no longer used
and the faulty memory module can be replaced at the next opportunity. In order
to be able to use the hot-spare memory function, all occupied DIMM slots must
have an identical memory configuration.

Memory modules can be protected against failure through mirroring (memory
mirroring, requires two or four memory modules).

16 Operating Manual RX600 S6

Preface

ASR&R (Automatic Server Reconfiguration and Restart) restarts the system in
the event of an error and automatically "hides" the defective system
components.

The PDA (Prefailure Detection and Analysis) technology from Fujitsu analyzes
and monitors all components that are critical for system reliability.

The SAS/SATA controller card supports the RAID levels 0, 1, 1E, 5, 6, 10, 50
and 60 thus increasing system availability and reliability.

Additional reliability is provided by the hot-plug HDD/SSD modules, fans and
power supply units.

RX600 S6 Operating Manual 17

Preface

iRMC S2 with integrated management LAN connector

I The features of the iRMC S2 Advanced Video Redirection and Remote

Storage are available as an option.

The iRMC S2 (integrated Remote Management Controller) is a BMC with
integrated management LAN connector and expanded functionality that was
previously only available with additional plug-in cards. In this way, the iRMC S2
enables complete control of PRIMERGY servers, regardless of system status,
and thus particularly the control of PRIMERGY servers that are in the "out-of­band" system status.

Major functions supported by the iRMC S2 include the following:

● Browser access via iRMC S2-s own Web server

● Secure communication (SSH, SSL)

● Power Management for the managed server (depending on its system

status)

● Power Consumption Management

● Connecting virtual drives as remote storage

● Text-based and graphic console bypass (Advanced Video Redirection)

● Command Line Interface (CLI)

● Simple, interactive or script-based iRMC S2 configuration

● Customer Self Service (CSS)

● iRMC S2-s own user management

● Multi-computer, global iRMC S2 user administration using an LDAP

Directory Service

● Automatic network configuration via DNS / DHCP

● Power supply of the iRMC S2 via the system standby supply

● Full-coverage alarm management

● System Event Log (SEL) reading and processing

More information about the iRMC S2 can be found in the "iRMC S2 - integrated
Remote Management Controller" user’s guide (on the ServerView Suite DVD 2
under Industry Standard Servers - Software - ServerView Suite - Out-Of-Band
Management).

18 Operating Manual RX600 S6

Preface

Server management

Server management is implemented using the ServerView Operations Manager
supplied and the PDA (Prefailure Detection and Analysis) technology from
Fujitsu. PDA reports the threat of a system error or overload at an early stage,
allowing preventive measures to be taken.

The ServerView Operations Manager enables the management of all
PRIMERGY servers in the network via a central console. The ServerView
Operations Manager supports the following functions:

● Round-the-clock monitoring, regardless of server status

● High-performance, graphical console bypass (AVR) protected by

HTTPS/SSL (128 bit)

● Remote storage via USB

● Remote power on

● Temperature monitoring of the CPU and the surrounding area

● Detailed status and error reports for processors and main memory

● Watchdog timer for Automatic Server Reconfiguration and Restart (ASR&R)

in the event of failure of memory modules or processors

● Power monitoring

● End-of-life monitoring of fans with prompt notification before failure

● Watchdog timer for monitoring the operating system with ASR&R

Further information on the ServerView Operations Manager is provided in the
associated documentation.

RX600 S6 Operating Manual 19

Preface

ServerView Installation Manager

You can configure the PRIMERGY server quickly and precisely with the
ServerView Installation Manager software provided. User-guided menus are
available for installing the server operating system (for further details see
section "Configuring the server" on page 72).

Service and support

PRIMERGY servers are service-friendly and modular, enabling quick and easy
maintenance.

For easier and immediate recognition, handles and locks (touch points) are
color coded. Green touch points are for components that can be replaced
without tools as well as for hot-plug components that can be replaced or
inserted during operation without the need for tools (see also "CSS

components" on page 85).

You can use the ServerView Local Service Display on the front panel of the
server to check the status of the key system components at any time without
opening the housing. Further information on ServerView Local Service Display
is provided in the associated documentation.

For further information, please refer to the diagnosis LEDs on the hot-plug
components (power supply units, fans, expansion cards, HDD/SSD modules).

The ServerView Update Manager supplied with the Fujitsu utilities supports a
fast remote BIOS update via the LAN interface; the BIOS can also be updated
locally via USB. The optional ServerView Remote Management remote testing
and diagnostic system enables you to remotely maintain your server.

20 Operating Manual RX600 S6

Preface

ServerView Remote Management

ServerView Remote Management is the remote management solution from
Fujitsu for PRIMERGY servers. ServerView Remote Management and the
relevant hardware components integrated on the system board allow remote
monitoring and maintenance as well as fast restoration of operation in the event
of errors.

Remote monitoring and maintenance avoids time-consuming and costly on-site
repairs and reduces service costs. This leads to a reduction in the total cost of
ownership and an excellent return on investment for the remote management
solution.

The administrator can access all system information and information from the
sensors such as fan speeds or voltages via the iRMC S3's Web interface (see
section "iRMC S2 with integrated management LAN connector" on page 18).
You can also start the text-based or graphic console bypass (Advanced Video
Redirection, AVR) and connect virtual drives as remote storage.

I More information about the iRMC S3 can be found in the "iRMC S2/3 -

integrated Remote Management Controller" user guide (on the
ServerView Suite DVD 2 under Industry Standard Servers - Software -
ServerView Suite - Out-Of-Band Management).

RX600 S6 Operating Manual 21

Preface

1.4 Notational conventions

The following notational conventions are used in this manual:

Text in italics indicates commands or menu items.

"Quotation marks" indicate names of chapters and terms that are being

emphasized.

Ê describes activities that must be performed in the order

shown.

V CAUTION! pay particular attention to texts marked with this symbol.

Failure to observe this warning may endanger your life,
destroy the system or lead to the loss of data.

I indicates additional information, notes and tips.

1.5 Technical data

Electrical data (hot-plug power supply unit)

Rated voltage range 100 - 127 V / 200 - 240 V

Frequency 50 Hz - 60 Hz

Rated current (basic configuration) 3.1 A (240 V)

Max. rated current 11 A (240 V)

Active power min. (typical configuration) 750 W

Active power max. (typical configuration) 1800 W

Rated active power max. 2640 W (11 A x 240 V)

Apparent power (typical configuration) 1830 VA

Heat dissipation 750 W/h = 2559 btu/h

1950 W/h = 6654 btu/h
3360 W/h = 11465 btu/h

Main power fuse 16 A

Protection class I

22 Operating Manual RX600 S6

Compliance with regulations and standards

Preface

Product safety and
ergonomics

IEC 60950-1/2 / EN 60950-1/2, UL/CSA 60950­1/2, CNS 14336 / GB 4943 / EN 50371

Electromagnetic
compatibility

Interference emissions EN 55022 class A; FCC class A; CNS 13438 class

A; VCCI class A; AS/NZS CISPR 22 class A;
GB 9254 class A; GB 17625; ETSI EN 300 386
V1.3.1

Interference immunity EN 55024, EN 300386

Harmonic current EN 61000-3-2

Flicker EN 61000-3-3

CE marking to EU
directives

Low Voltage Directive 2006/95/EC (product safety)
Electromagnetic compatibility 2004/108/EC

Environmental conditions ETSI 300 019-2-3 Class 3.1 (T3.1)

Noise emission ETSI 300 753 Class 3.1

RX600 S6 Operating Manual 23

Preface

Dimensions / Weight

Rack (W x D x H) 482.6 mm (Bezel) / 444.8 mm (Body) x 765.0 mm x

176.0 mm

Mounting depth rack 728 mm

Height unit rack 4 U

19" rackmount Yes

Mounting cable depth

100 mm (1000 mm rack recommended)

rack

Weight minimum 32 kg; maximum 46 kg (actual weight may

vary depending on configuration)

Rack integration kit rack integration kit as option

Ventilation clearance

At least 200 mm on the front and rear.

Ambient conditions

Environment class 3K2
Environment class 2K2

EN 60721 / IEC 721 Part 3-3
EN 60721 / IEC 721 Part 3-2

Temperature:

Operation (3K2) 10°C - 35°C

Transport (2K2) -25°C - 60°C

Humidity 10% - 85% (non condensing)

Condensation during operation must be avoided!

Noise level

Sound power level L

(ISO 9296) < 6.5 B (standby)

WAd

< 6.6 B (operation)

Sound pressure level at bystander position L
(ISO 9296) (at < 23 °C)

pAm

< 50 dB(A) (standby)
< 50 dB(A) (operation)

24 Operating Manual RX600 S6

2 Overview of the installation steps

This chapter contains an overview of the steps necessary to install your server.
Links guide you to sections where you can find more detailed information on the
individual steps:

Ê At first, please take notice of the safety instructions in chapter "Important

information" on page 27 and following.

Ê Transport the server to the place where you want to install it.

Ê Unpack all parts, check the contents of the package for visible transport

damage and check whether the items delivered match the details on the
delivery note (see section "Unpacking the server" on page 42).

Ê Make sure that all necessary manuals (see "Documentation overview" on

page 12) are available; print out the PDF files if required.

Ê Fit the server in the rack (see section "Rack installation/removal of server"

on page 43).

Ê Wire the server. Follow the instructions in the sections "Connecting devices

to the server" on page 47 and "Notes on connecting/disconnecting cables"
on page 55.

Ê Connect the server to the mains (see section "Connecting the server to the

mains" on page 49).

Ê Familiarize yourself with the controls and indicators on the front and rear of

the server (see section "Control elements and indicators" on page 57).

Ê Configure the server and install the desired operating system and

applications. Here you can choose from two possibilities:

– Remote installation with the ServerView Installation Manager:

With the ServerView Suite DVD 1 provided, you can configure the server
and install the operating system in a convenient manner.

Details on how to operate the ServerView Installation Manager, as well
as some additional information, are included in the "ServerView Suite
Installation Manager" user’s guide (on ServerView Suite DVD 2 under

Industry Standard Servers - Software - ServerView Suite - Server Installation
and Deployment).

RX600 S6 Operating Manual 25

Overview of the installation steps

Configuration information can also be found in section "Configuring the

server and installing the operating system with the ServerView
Installation Manager" on page 73.

– Local configuration and installation with or without ServerStart (see

section "Configuring the server and installing the operating system with

the ServerView Installation Manager" on page 73 or section "Configuring
the server and installing the operating system without the ServerView
Installation Manager" on page 74).

I You will find more information on installing the server remotely or

locally in the "ServerView Suite Installation Manager" user’s guide
(on the ServerView Suite DVD 2 under Industry Standard Servers -
Software - ServerView Suite - Server Installation and Deployment).

26 Operating Manual RX600 S6

3 Important information

In this chapter you will find essential information regarding safety when working
on your server.

3.1 Safety instructions

I The following safety instructions are also provided in the manual "Safety

Notes and Regulations" or " 安全上のご注意 ".

This device meets the relevant safety regulations for IT equipment. If you have
any questions about whether you can install the server in the intended
environment, please contact your sales outlet or our customer service team.

V CAUTION!

● The actions described in this manual shall be performed by technical

specialists. A technical specialist is a person who is trained to install
the server including hardware and software.

● Repairs to the device that do not relate to CSS failures shall be

performed by service personnel. Please note that unauthorized
interference with the system will void the warranty and exempt the
manufacturer from all liability.

● Any failure to observe the guidelines in this manual, and any improper

repairs could expose the user to risks (electric shock, energy
hazards, fire hazards) or damage the equipment.

● Before installing/removing internal options to/from the server, turn off

the server, all peripheral devices, and any other connected devices.
Also unplug all power cords from the power outlet. Failure to do so
can cause electric shock.

RX600 S6 Operating Manual 27

Important information

Before starting up

V CAUTION!

● During installation and before operating the device, observe the

instructions on environmental conditions for your device (see

"Ambient conditions" on page 24).

● If the server has been moved from a cold environment, condensation

may form both inside and on the outside of the machine.

Wait until the server has acclimatized to room temperature and is
absolutely dry before starting it up. Material damage may be caused
to the server if this requirement is not met.

● Only transport the server in the original packaging or in packaging

that protects it from impacts and jolts.

Installation and operation

V CAUTION!

● This unit should not be operated in ambient temperatures above

35 °C.

● If the unit is integrated into an installation that draws power from an

industrial power supply network with an IEC309 connector, the power
supply's fuse protection must comply with the requirements for non­industrial power supply networks for type A connectors.

● The unit automatically adjusts itself to a mains voltage in a range of

100 - 127 V / 200 - 240 V. Ensure that the local mains voltage lies
within these limits.

● This device must only be connected to properly grounded power

outlets or insulated sockets of the rack's internal power supply with
tested and approved power cords.

● Ensure that the device is connected to a properly grounded power

outlet close to the device.

28 Operating Manual RX600 S6

Important information

V CAUTION!

● Ensure that the power sockets on the device and the properly

grounded power outlets are freely accessible.

● The On/Off button or the main power switch (if present) does not

isolate the device from the mains power supply. To disconnect it
completely from the mains power supply, unplug all network power
plugs from the properly grounded power outlets.

● Always connect the server and the attached peripherals to the same

power circuit. Otherwise you run the risk of losing data if, for example,
the server is still running but a peripheral device (e.g. memory
subsystem) fails during a power outage.

● Data cables must be adequately shielded.

● Ethernet cabling has to comply with EN 50173 and EN 50174-1/2

standards or ISO/IEC 11801 standard respectively. The minimum
requirement is a Category 5 shielded cable for 10/100 Ethernet, or a
Category 5e cable for Gigabit Ethernet.

● Route the cables in such a way that they do not create a potential

hazard (make sure no-one can trip over them) and that they cannot
be damaged. When connecting the server, refer to the relevant
instructions in this manual.

● Never connect or disconnect data transmission lines during a storm

(risk of lightning hazard).

● Make sure that no objects (e.g. jewelry, paperclips etc.) or liquids can

get inside the server (risk of electric shock, short circuit).

● In emergencies (e.g. damaged casing, controls or cables, penetration

of liquids or foreign bodies), switch off the server immediately,
remove all power plugs and contact your sales outlet or customer
service team.

RX600 S6 Operating Manual 29

Important information

V CAUTION!

● Proper operation of the system (in accordance with IEC 60950-1/2

resp. EN 60950-1/2) is only ensured if the casing is completely
assembled and the rear covers for the installation slots have been
fitted (electric shock, cooling, fire protection, interference
suppression).

● Only install system expansions that satisfy the requirements and

rules governing safety and electromagnetic compatibility and those
relating to telecommunication terminals. If you install other
expansions, they may damage the system or violate the safety
regulations. Information on which system expansions are approved
for installation can be obtained from our customer service center or
your sales outlet.

● The components marked with a warning notice (e.g. lightning symbol)

may only be opened, removed or exchanged by authorized, qualified
personnel. Exception: CSS components can be replaced.

● The warranty is void if the server is damaged during installation or

replacement of system expansions.

● Only set screen resolutions and refresh rates that are specified in the

operating manual for the monitor. Otherwise, you may damage your
monitor. If you are in any doubt, contact your sales outlet or customer
service center.

● Before installing/removing internal options to/from the server, turn off

the server, all peripheral devices, and any other connected devices.
Also unplug all power cords from the outlet. Failure to do so can
cause electric shock.

● Do not damage or modify internal cables or devices. Doing so may

cause a device failure, fire, or electric shock.

● Devices inside the server remain hot after shutdown. Wait for a while

after shutdown before installing or removing internal options.

● The circuit boards and soldered parts of internal options are exposed

and can be damaged by static electricity. Before handling them, first
touch a metal part of the server to discharge static electricity from
your body.

● Do not touch the circuitry on boards or soldered parts. Hold the

metallic areas or the edges of the circuit boards.

30 Operating Manual RX600 S6

Important information

V CAUTION!

● Install the screw removed during installation/detaching Internal

Options in former device/position. To use a screw of the different kind
causes a breakdown of equipment.

● The installation indicated on this note is sometimes changed to the

kind of possible options without notice.

Batteries

V CAUTION!

● Incorrect replacement of batteries may lead to a risk of explosion. The

batteries may only be replaced with identical batteries or with a type
recommended by the manufacturer (see the technical manual for the
system board).

● Do not throw batteries into the trash can.

● Batteries must be disposed of in accordance with local regulations

concerning special waste.

● Replace the lithium battery on the system board in accordance with

the instructions in the technical manual for the system board.

● All batteries containing pollutants are marked with a symbol (a

crossed-out garbage can). In addition, the marking is provided with
the chemical symbol of the heavy metal decisive for the classification
as a pollutant:

Cd Cadmium
Hg Mercury
Pb Lead

RX600 S6 Operating Manual 31

Important information

Working with CDs/DVDs/BDs and optical drives

When working with devices with optical drives, these instructions must be
followed.

V CAUTION!

● Only use CDs/DVDs/BDs that are in perfect condition, in order to

prevent data loss, equipment damage and injury.

● Check each CD/DVD/BD for damage, cracks, breakages etc. before

inserting it in the drive.

Note that any additional labels applied may change the mechanical
properties of a CD/DVD/BD and cause imbalance.

Damaged and imbalanced CDs/DVDs/BDs can break at high drive
speeds (data loss).

Under certain circumstances, sharp CD/DVD/BD fragments can
pierce the cover of the optical drive (equipment damage) and can fly
out of the device (danger of injury, particularly to uncovered body
parts such as the face or neck).

● High humidity and airborne dust levels are to be avoided. Electric

shocks and/or server failures may be caused by liquids such as
water, or metallic items, such as paper clips, entering a drive.

● Shocks and vibrations are also to be avoided.

● Do not insert any objects other than the specified CDs/DVDs/BDs.

● Do not pull on, press hard, or otherwise handle the CD/DVD/BD tray

roughly.

● Do not disassemble the optical drive.

● Before use, clean the optical disk tray using a soft, dry cloth.

● As a precaution, remove disks from the optical drive when the drive

is not to be used for a long time. Keep the optical disk tray closed to
prevent foreign matter, such as dust, from entering the optical drive.

● Hold CDs/DVDs/BDs by their edges to avoid contact with the disk

surface.

32 Operating Manual RX600 S6

Important information

● Do not contaminate the CD/DVD/BD surface with fingerprints, oil,

dust, etc. If dirty, clean with a soft, dry cloth, wiping from the center to
the edge. Do not use benzene, thinners, water, record sprays,
antistatic agents, or silicone-impregnated cloth.

● Be careful not to damage the CD/DVD/BD surface.

● Keep the CDs/DVDs/BDs away from heat sources.

● Do not bend or place heavy objects on CDs/DVDs/BDs.

● Do not write with ballpoint pen or pencil on the label (printed) side.

● Do not attach stickers or similar to the label side. Doing so may cause

rotational eccentricity and abnormal vibrations.

● When a CD/DVD/BD is moved from a cold place to a warm place,

moisture condensation on the CD/DVD/BD surface can cause data
read errors. In this case, wipe the CD/DVD/BD with a soft, dry cloth
then let it air dry. Do not dry the CD/DVD/BD using devices such as a
hair dryer.

● To avoid dust, damage, and deformation, keep the CD/DVD/BD in its

case whenever it is not in use.

● Do not store CDs/DVDs/BDs at high temperatures. Areas exposed to

prolonged direct sunlight or near heating appliances are to be
avoided.

I You can prevent damage from the optical drive and the CDs/DVDs/BDs,

as well as premature wear of the disks, by observing the following
suggestions:

– Only insert disks in the drive when needed and remove them after

use.
– Store the disks in suitable sleeves.
– Protect the disks from exposure to heat and direct sunlight.

Laser information

The optical drive complies with IEC 60825-1 laser class 1.

V CAUTION!

The optical drive contains a light-emitting diode (LED), which under
certain circumstances produces a laser beam stronger than laser
class 1. Looking directly at this beam is dangerous.

Never remove parts of the optical drive casing!

RX600 S6 Operating Manual 33

Important information

Modules with Electrostatic-Sensitive Devices

Modules with electrostatic-sensitive devices are identified by the following
sticker:

Figure 1: ESD label

When you handle components fitted with ESDs, you must always observe the
following points:

● Switch off the system and remove the power plugs from the power outlets

before installing or removing components with ESDs.

● You must always discharge static build-up (e.g. by touching a grounded

object) before working with such components.

● Any devices or tools that are used must be free of electrostatic charge.

● Wear a suitable grounding cable that connects you to the external chassis

of the system unit.

● Always hold components with ESDs at the edges or at the points marked

green (touch points).

● Do not touch any connectors or conduction paths on an ESD.

● Place all the components on a pad which is free of electrostatic charge.

I For a detailed description of how to handle ESD components, see the

relevant European or international standards (EN 61340-5-1,
ANSI/ESD S20.20).

34 Operating Manual RX600 S6

Important information

Other important information:

● During cleaning, observe the instructions in section "Cleaning the server" on

page 75.

● Keep this operating manual and the other documentation (such as the

technical manual, documentation DVD) close to the device. All
documentation must be included if the equipment is passed on to a third
party.

3.2 ENERGY STAR

Products that have been certified compliant with ENERGY STAR
and identified as such are in full compliance with the specification
at shipping. Note that energy consumption can be affected by
software that is installed or any changes that are made to the
hardware configuration or BIOS or energy options subsequently.
In such cases, the properties guaranteed by ENERGY STAR can
no longer be assured.

The "ServerView Operations Manager" user guide contains
instructions for reading out measurement values, including those
relating to current energy consumption and air temperatures.
Either the Performance Monitor or the Task Manager can be
used to read out CPU utilization levels.

3.3 CE conformity

The system complies with the requirements of the EC directives
2004/108/EC regarding "Electromagnetic Compatibility" and
2006/95/EC "Low Voltage Directive". This is indicated by the CE
marking (CE = Communauté Européenne).

RX600 S6 Operating Manual 35

Important information

3.4 FCC Class A Compliance Statement

If there is an FCC statement on the device, it applies to the products covered in
this manual, unless otherwise specified herein. The statement for other
products will appear in the accompanying documentation.

NOTE:

This equipment has been tested and found to comply with the limits for a
"Class A" digital device, pursuant to Part 15 of the FCC rules and meets all
requirements of the Canadian Interference-Causing Equipment Standard
ICES-003 for digital apparatus. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in strict accordance with the instructions, may cause harmful
interference to radio communications. However, there is no warranty that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:

● Reorient or relocate the receiving antenna.

● Increase the separation between equipment and the receiver.

● Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

● Consult the dealer or an experienced radio/TV technician for help.

Fujitsu is not responsible for any radio or television interference caused by
unauthorized modifications of this equipment or the substitution or attachment
of connecting cables and equipment other than those specified by Fujitsu. The
correction of interferences caused by such unauthorized modification,
substitution or attachment will be the responsibility of the user.

The use of shielded I/O cables is required when connecting this equipment to
any and all optional peripheral or host devices. Failure to do so may violate FCC
and ICES rules.

WARNING:

This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.

36 Operating Manual RX600 S6

Important information

3.5 Transporting the server

V CAUTION!

Only transport the server in its original packaging or in packaging that
protects it from impacts and jolts. Do not unpack the server until it is at its
installation location.

If you need to lift or transport the server, ask other people to help you.

Never lift or carry the device by the handles on the front panel.

RX600 S6 Operating Manual 37

Important information

3.6 Notes on installing the server in the rack

V CAUTION!

● For safety reasons, at least two people are required to install the

server in the rack because of its weight and size.

(For the Japanese market, please refer to " 安全上のご注意 ".)

● Never lift the server into the rack using the QRLs (Quick Release

Levers) on the front panel.

● When connecting and disconnecting cables, observe the relevant

instructions in the "Important Information" chapter of the technical
manual for the corresponding rack. The technical manual is supplied
with the corresponding rack.

● When installing the rack, make sure that the anti-tilt mechanism is

correctly fitted.

● For safety reasons, no more than one unit may be removed from the

rack at any one time during installation and maintenance work.

● If several units are simultaneously removed from the rack, there is a

risk that the rack could tip over.

● The rack must be connected to the power supply by an authorized

specialist (electrician).

● If the server is integrated into an installation that draws power from an

industrial power supply network with an IEC309 type connector, the
power supply's fuse protection must comply with the requirements for
non-industrial power supply networks for the type A connector.

38 Operating Manual RX600 S6

Important information

3.7 Environmental protection

Environmentally-friendly product design and development

This product has been designed in accordance with the Fujitsu standard for
"environmentally friendly product design and development". This means that
key factors such as durability, selection and labeling of materials, emissions,
packaging, ease of dismantling and recycling have been taken into account.

This saves resources and thus reduces the harm done to the environment.
Further information can be found at:

– http://ts.fujitsu.com/products/standard_servers/index.html (for the EMEA market)
– http://primeserver.fujitsu.com/primergy/concept/ (for the Japanese market)

Energy-saving information

Devices that do not need to be constantly switched on should be switched off
until they are needed as well as during long breaks and after completion of work.

Packaging information

This packaging information doesn’t apply to the Japanese market.

Do not throw away the packaging. You may need it later for transporting the
system. If possible, the equipment should only be transported in its original
packaging.

Information on handling consumables

Please dispose of printer consumables and batteries in accordance with the
applicable national regulations.

In accordance with EU directives, batteries must not be disposed of with
unsorted domestic waste. They can be returned free of charge to the
manufacturer, dealer or an authorized agent for recycling or disposal.

All batteries containing pollutants are marked with a symbol (a crossed-out
garbage can). They are also marked with the chemical symbol for the heavy
metal that causes them to be categorized as containing pollutants:

Cd Cadmium
Hg Mercury
Pb Lead

RX600 S6 Operating Manual 39

Important information

Labels on plastic casing parts

Please avoid sticking your own labels on plastic parts wherever possible, since
this makes it difficult to recycle them.

Returns, recycling and disposal

Please handle returns, recycling and disposal in accordance with local
regulations.

The device must not be disposed of with domestic waste. This
device is labeled in compliance with European directive
2002/96/EC on waste electrical and electronic equipment (WEEE).

This directive sets the framework for returning and recycling used
equipment and is valid across the EU. When returning your used
device, please use the return and collection systems available to
you. Further information can be found at

http://ts.fujitsu.com/recycling.

Details regarding the return and recycling of devices and consumables within
Europe can also be found in the "Returning used devices" manual, via your local
Fujitsu branch or from our recycling center in Paderborn:

Fujitsu Technology Solutions
Recycling Center
D-33106 Paderborn

Tel. [phone]
Fax [phone]

40 Operating Manual RX600 S6

4 Hardware installation

V CAUTION!

● Follow the safety instructions in the chapter "Important information"

on page 27.

● Do not expose the server to extreme environmental conditions (see

"Ambient conditions" on page 24). Protect the server from dust,

humidity and heat.

● Make sure that the server is acclimatized for the time indicated in this

table before putting it into operation.

Temperature difference (°C) Minimum acclimatization time

(hours)

53

10 5

15 7

20 8

25 9

30 10

Table 1: Acclimatization time

In the table "Acclimatization time", the temperature difference refers

to the difference between the operating environment temperature and

the temperature to which the server was exposed previously (outside,

transport or storage temperature).

RX600 S6 Operating Manual 41

Hardware installation

4.1 Unpacking the server

V CAUTION!

Follow the safety instructions in "Important information" on page 27.

The server must always be lifted or carried by at least two people.
(For the Japanese market, please refer to " 安全上のご注意 ".)

Do not unpack the server until it is at its installation location.

Ê Transport the server to the place where you want to set it up.

Ê Unpack all individual parts.

Keep the original packaging in case you want to transport the server again
(applies only to EMEA market).

Ê Check the delivery for any damage during transport.

Ê Check whether the items delivered match the details on the delivery note.

The product name and serial number of the product can be found on the ID card
(see section "ID card" on page 58).

Ê Notify your supplier immediately should you discover that the items

delivered do not correspond to the delivery note.

42 Operating Manual RX600 S6

Hardware installation

4.2 Rack installation/removal of server

V CAUTION!

● Please observe the safety information and notes on rack mounting in

chapter "Important information" on page 27.

● At least two people are needed to install / remove the server in the

rack. (For the Japanese market, please refer to " 安全上のご注意 ".)

● The rack may tip over if more than one unit is removed at the same

time.

● The server may not occupy the top height units of the rack

(38HU/42HU PRIMECENTER Rack, DataCenter Rack, 19-inch

standard rack (for the Japanese market)), as otherwise boards

cannot be replaced.

4.2.1 Rack system requirements

The rack systems from Fujitsu PRIMECENTER Rack, DataCenter Rack and
19-inch standard rack (for the Japanese market) support the installation of
PRIMERGY servers. Installation in most current rack systems from other
manufacturers (3rd party racks) is also supported.

To accommodate the ventilation concept and ensure proper ventilation, any
unused areas in the rack must be sealed using dummy covers.

The power is supplied via the multiple socket outlets fitted in the rack.

Fujitsu rack systems

The main features of PRIMECENTER Rack, DataCenter Rack and 19-inch
standard rack (for the Japanese market) are as follows:

– support systems that can be mounted without tools

– support systems having a linear alignment feature to ensure that they can

be adjusted to different rack depths

PRIMECENTER Rack and DataCenter Rack provide an enhanced cable
management in the lateral rack area.

RX600 S6 Operating Manual 43

Hardware installation

I For PRIMECENTER Racks and DataCenter Racks:

The mounting of the rails in the different racks is described in the next
sections. Installation of the cable management is described in detail in
the Technical Manual for the respective rack.

I For 19-inch standard rack (for the Japanese market):

For information on mounting of the rails in the 19-inch standard rack (for
the Japanese market) please refer to the "Rack system structure guide"
(refer to http://primeserver.fujitsu.com/primergy/peripheral/rack/).

3rd party racks

Certain general conditions must be met:

– Installation dimensions (see the dimensions shown in figure 2 on page 45):

1 Front of rack

2 Rear of rack

A Rack depth (comparison PRIMECENTER Rack 940/1000/1100 mm)

B Rack width (comparison PRIMECENTER rack 700 mm)

C Clearance for 19" installation level

C1 Front 19" installation level

C2 Rear 19" installation level

D Cable routing area (cable area depth) and ventilation

E Space for front panel and ventilation

F Space for right and left support systems

P PRIMERGY rack installation depth

a1 Front left support upright

a2 Front right support upright

b1 Rear left support upright

b2 Rear right support upright

44 Operating Manual RX600 S6

100 mm

Hardware installation

735 - 770 mm

+/- 1,6mm

Figure 2: Mechanical requirements

RX600 S6 Operating Manual 45

Hardware installation

– You must ensure that the safety mechanisms on the server, e.g. stoppers or

retaining systems, are functioning correctly.

– The shape of the rack support uprights must ensure that the support

systems can be bolted to the front.

The support systems have a linear alignment feature to ensure that they can
be adjusted to different rack depths.

– No cable management support (delivered with the mounting kit).

– Climatic conditions:An unobstructed air intake in the rack front and air

discharge in the rear cover of the rack are essential for ventilation of the
installed server.

In general, the ventilation concept ensures that the necessary cooling is
achieved by the horizontal self-ventilation of the installed devices (air flow
from the front to the rear).

– Power supply: For installation in third party racks, you must ensure that the

appropriate socket strips are present.

4.2.2 Mounting the server into the rack

I For information on mounting the server in the rack please refer to the

mounting instructions provided with the Rack Mounting Kit. Further
information you can find in the manual of your rack system.

46 Operating Manual RX600 S6

Hardware installation

4.3 Connecting devices to the server

The connectors for external devices are on the front and rear of the server. The
additional connectors available on your server depend on the expansion cards
installed (e.g. optional SAS connector).

I Some of the devices that can be connected may require special

software, e.g. drivers (see the documentation for the connected device).

/

Figure 3: Connectors on the front

On the front of the server are a video connector (1) and three USB
connectors (2).

0

I The two video connectors on the front and rear (see figure 4 on page 48)

can only be used alternatively; the connector not used is automatically
deactivated.

RX600 S6 Operating Manual 47

Hardware installation

The standard connectors on the rear are marked with symbols, and one is color­coded:

3

2

/

0

1

Figure 4: Connectors on the rear

1 4x LAN connector 4 Video connector (blue)

2 Serial connector COM1 5 Management LAN connector

3 2 x USB connector

Ê Connect the data cables to the server and peripherals.

I Connect keyboard and mouse via USB. There are no separate PS/2

connectors for them.

Connecting the monitor

Ê Plug the data cable for the monitor into the video connector on the server.

Alternatively, the video connector at the front or the rear of the server can be
used.

Ê Connect the power cord of the monitor to a grounded mains outlet of the in-

house mains and/or into the mains socket strip of the rack.

48 Operating Manual RX600 S6

Hardware installation

4.4 Connecting the server to the mains

V CAUTION!

The server is automatically set to a mains voltage in the range 100 - 127
V / 200 - 240 V. You may only operate the server if its rated voltage range
corresponds to the local mains voltage.

4.4.1 Installation requirements

The power subsystem consists of:

– Power supply modules (PSU)

– A power distribution board (PDB)

The power supply subsystem can support up to 4 PSUs which all connect to the
PDB. The total system is rated 100 - 127 V / 200 - 240 V, 50/60 Hz, 28/14 A.The
minimum system configuration requires installation of at least two PSUs. The
PSU is considered hot-swappable(see "Hot-plug power supply units" on

page 87). The system can be configured to support *True AC redundancy or

non-AC redundancy.

I *True AC redundancy is recommended for systems used for critical

business applications. This will result in the system to continue operation
during a power failure as the redundant part of the subsystem is plugged
into a separate AC source (e.g. uninterruptable power supply (UPS)).

I Refer to tables below for maximum DC loading for both AC redundant

and AC non redundant configurations.

Installation requirements for AC redundant configurations

The AC redundant configuration is with two PSU plugged into a main AC source
and two other PSUs plugged into a separate AC source (e.g. UPS).

PSU Configuration Max. DC Loading DC Redundancy

1+1 (2 PSUs) 830W Yes

2+2 (4 PSUs) 1580W Yes

Table 2: Maximum DC Loading Requirements

RX600 S6 Operating Manual 49

Hardware installation

Installation requirements for AC non redundant configurations

For systems not requiring AC redundancy, the power supply subsystem can be
installed with up to 4 PSUs. The PSUs can be connected to a single or multiple
AC sources.

PSU Configuration Max. DC Loading DC Redundancy

1+1 (2 PSUs) 830W Yes

2+1 (3 PSUs) 1580W Yes

3+1 (4 PSUs) 2320W Yes

Table 3: Maximum DC Loading Requirements

Three power supply modules are capable of handling the maximum power
requirements for a fully configured PRIMERGY RX600 S6 server system, which
include the following:

● Four processors

● 1024 GB of memory

● Eleven PCIe add-in cards (including the SAS/SATA RAID controller card)

● Eight hard disk drives and/or solid state disks

● One optical drive

● One tape drive

The hot swap feature allows the user to replace a failed power supply module
without affecting the system functionality.

50 Operating Manual RX600 S6

Hardware installation

AC source related power supply configuration and system load limits

The system configuration and load is limited by the number of AC mains power
sources available as indicated in the following table.

Number
of power
supply
modules
installed

2 830W 2 PSUs

AC redundant systems
(requires 2 AC sources)

Max. DC
loading to

Installation

requirements
support AC
redundancy

connected to

mains (1+1)

AC non-redundant systems
(connected to 1 AC source)

Max. DC
loading for AC

Installation

requirements
non-redundant
systems

1580W 2 PSUs

connected to

mains (1+1)

3 N/A N/A 2320W 3 PSUs

connected to

mains (2+1)

4 1580W 2 PSUs

connected to
mains2 PSUs

2320W 4 PSUs

connected to

mains (3+1)

connected to
an isolated AC
source
e.g. UPS (2+2)

Table 4: System power supply configuration and system load limits

Installation in PRIMECENTER/Datacenter rack

Please follow the installation requirements for connection to the mains
described in the rack manuals.

RX600 S6 Operating Manual 51

Hardware installation

Installation in 3rd party racks without main connection according to
IEC309 or outside of racks

I 1. These additional installation requirements ONLY apply when 4 PSUs

are connected to a high line voltages (220V or higher).

2. These requirements DO NOT apply when PSUs are connected to low
line voltages (100-127V and 200V) OR if at least one PSU is
connected into a separate AC source (e.g. UPS).

V CAUTION!

These additional installation requirements are REQUIRED to avoid risk
of high leakage current which may result in electric shock.

1. Systems REQUIRE being installed in a location having equipotential
bonding (such as a telecommunication center, a dedicated computer room
or a *RESTRICTED ACCESS LOCATION.

* Definition of RESTRICTED ACCESS LOCATION is a location for
equipment where both of the following apply:

– Access can only be gained by SERVICE PERSONS or by USERS who

have been instructed about the reasons for the restrictions applied to the
location and about any precautions that shall be taken; and

– Access is through the use of a TOOL or lock and key, or other means of

security, and is controlled by the authority responsible for the location.

2. The building installation shall provide means for connection to protective
earth as follows: Connection to protective earth can be provided by the
socket-outlet that provides power to the PSU. A service person requires
checking the socket-outlet to make sure it has a protective earth. If the
socket-outlet does not have a protective earth, then the service person
requires arranging:

– Installation of a protective earth conductor from the system to the

building installation. The grounding bolt is located on the chassis rear left
side wall designated by the symbol.

52 Operating Manual RX600 S6

photo shows installation of a protective earth conductor

1

2

Figure 5: Installing a protective earth conductor

Ê Loosen the first nut and remove it (1).

Ê Plug the protective earth conductor onto the bolt (2).

Hardware installation

3

Ê Replace the nut and tighten it (3).

RX600 S6 Operating Manual 53

Hardware installation

4.4.2 Connecting the power cord

Ê Connect the power cord to the server power supply unit.

Ê Connect the mains plug to a grounded mains outlet in the in-house power

supply network or a power outlet of the socket strip in the rack (see Technical
Manual for the rack).

Ê Secure the power cords in the cable clamps so the insulated connectors

cannot be disconnected from the server accidentally.

Figure 6: Cable clamps to secure the power cords

Ê Thread the cable through the cable clamp as shown in figure 6.

Ê Pull the cable clamp tight to secure the power cord.

Now the insulated connector cannot be disconnected from the server
accidentally.

I You can loosen the cable clamp by opening the small locking lever.

54 Operating Manual RX600 S6

Hardware installation

4.5 Notes on connecting/disconnecting cables

V CAUTION!

Always read the documentation supplied with the device you wish to
connect.

Never connect, or disconnect cables during a thunderstorm.

Never pull on a cable when disconnecting it. Always take hold of the
cable by the plug.

Follow the sequence described below to connect or disconnect external
devices to or from the server:

Be sure to wait for 10 seconds or more after shutdown before turning the
server on.

Connecting cables

Ê Turn off all power and equipment switches.

Ê Disconnect all power plugs from the properly grounded power outlets.

Ê Connect all cables to the server and peripherals.

Ê Plug all data communication cables into the utility sockets.

Ê Plug all power cords into the properly grounded power outlets.

Disconnecting cables

Ê Turn off all power and equipment switches.

Ê Disconnect all power plugs from the properly grounded power outlets.

Ê Unplug all data communication cables from the utility sockets.

Ê Disconnect the relevant cables from the server and all the peripherals.

I For connecting or disconnecting LAN cables, the server needs not to be

powered off. To avoid loss of data teaming/bonding function has to be
enabled.

RX600 S6 Operating Manual 55

Hardware installation

56 Operating Manual RX600 S6

5 Starting up and operation

V CAUTION!

Follow the safety instructions in chapter "Important information" on

page 27.

5.1 Control elements and indicators

5.1.1 Front of server

0 1

/

#7

#6

6

Figure 7: Front - overall view

1 ID card 5 Video connector

2 ServerView Local Service

Display

3 Optical drive activity indicator 7 HDD/SSD indicators

4 Control panel (for details see

page 58)

5

6 3x USB connector

8 Tape drive dummy cover

(optional place for a tape drive)

2

#5

#4

#3

3 4

#2

#1

#0

RX600 S6 Operating Manual 57

Starting up and operation

The white numbers in figure 7 show the HDD/SSD slot assignment.

/012 34

567

Figure 8: Front - detailed view: control panel

1 ID indicator 6 Reset button

2 CSS indicator 7 NMI button

3 Global Error indicator 8 On/Off button

4 HDD/SSD activity indicator 9 ID button

5 Power-on indicator

ID card

You can pull out the ID card (see figure 7 on page 57) as far as it will go and
push it back in again.

The ID card contains various system information, such as the product name,
serial number, order number, MAC addresses and DNS name (in the Japanese
market, only the product name and the serial number).

58 Operating Manual RX600 S6

5.1.1.1 Control elements

ID ID button

ID LED lights up (blue) on the front and on the rear of the server
when the ID button is pressed. Both ID indicators are
synchronized.

On/Off button

When the system is switched off, it can be switched on again by
pressing the On/Off button.

When the system is operating, pressing the On/Off button will
switch off the system.

V CAUTION!

Risk of loss of data!

I The On/Off button does not disconnect the server from the

mains voltage. To disconnect from the mains completely,
remove the power plug(s).

RST Reset button

Starting up and operation

Pressing the reset button reboots the system.

V CAUTION!

Risk of loss of data!

NMI NMI button

V CAUTION!

Do not press! Risk of loss of data! The NMI button may only
be used by service.

RX600 S6 Operating Manual 59

Starting up and operation

5.1.1.2 Indicators on the control panel

ID ID indicator (blue)

Lights up blue when the system has been selected by pressing
the ID button. To deactivate, press the button again.

The ID indicator can also be activated via the ServerView
Operations Manager and the iRMC S2 Web interface and its
status reported to the ServerView Operations Manager and the
iRMC S2.

Power-on indicator (green/orange/yellow)

Lights up green – and also lights up orange for less than one
second – when the server is switched ON.

Lights up orange when the server is in shutdown mode (operating
system shutdown) or is switched off.

Lights up yellow during power on delay.

CSS CSS indicator (yellow)

– Lights up yellow if a prefailure event was detected for a CSS

component that you can fix yourself (for reasons of precaution)
with the CSS concept.

– Flashes yellow if an error was detected that you can fix

yourself with the CSS concept.

– Does not light up when the system is OK.

If the event is still acute after a power failure, the indicator is
activated after the restart.

The indicator also lights up in standby mode.

For more information on the CSS concept, see "Customer Self

Service (CSS)" on page 14.

HDD/SSD activity indicator (green)

Lights up green when an internal hard disk drive or solid state
drive is accessed.

60 Operating Manual RX600 S6

Starting up and operation

Global Error indicator (orange)

!

– Lights up orange if a prefailure event has been detected that

requires (precautionary) service intervention.

– Flashes orange if an error was detected that requires service

intervention.

– Does not light up if there is no critical event.

If the event is still acute after a power failure, the indicator is
activated after the restart.

The indicator also lights up in standby mode.

You can find more details on the indicated errors in the System
Event Log (SEL), on the ServerView Local Service Display, in the
ServerView Operations Manager or via the iRMC S2's Web
interface.

5.1.1.3 Indicators on the accessible drives/components

Optical drive activity indicator

Lights up green when the storage medium is being accessed.

ServerView Local Service Display

You can use the slot mechanism to pull out the ServerView Local Service
Display from the server housing and read the information. Press the front of the
module to release the lock.

You can also pivot the ServerView Local Service Display down by an angle of
120° from its normal position. This makes reading easier when the server is
located very high in the rack.

Further information on using the ServerView Local Service Display is provided
in the "Customer Self Service (CSS)" manual.

RX600 S6 Operating Manual 61

Starting up and operation

5.1.1.4 Indicators on the hot-plug HDD/SSD modules

1 2

Figure 9: Indicators on a hot-plug HDD/SSDmodule

1 HDD/SSD BUSY (green)

– Lights up: HDD/SSD in active phase (drive active, drive being

accessed)

– Does not light: HDD/SSD inactive (drive inactive)

2 HDD/SSD FAULT (orange)

– Does not light: no HDD/SSD error
– Lights up: HDD/SSD Faulty or Rebuild Stopped (drive defective/needs

replacing, a rebuild process was stopped or the HDD/SSD module is
not correctly inserted)

– Slow flashing: HDD/SSD Rebuild (the data is being restored after

changing a drive)

If a hard disk drive continuously indicates an error, the drive should be replaced
as soon as possible. This can be done during operation (see "Hot-plug

HDD/SSD modules" on page 94).

62 Operating Manual RX600 S6

Starting up and operation

5.1.2 Rear of server

5.1.2.1 Global Error indicator and CSS indicator

0/

Figure 10: Global Error indicator and CSS indicator

1 CSS indicator (yellow)

– Lights up yellow if a prefailure event was detected for a CSS

component that you can fix yourself (for reasons of precaution) with
the CSS concept.

– Flashes yellow if an error was detected that you can fix yourself with

the CSS concept.

– Does not light up when the system is OK.

If the event is still acute after a power failure, the indicator is activated
after the restart.

The indicator also lights up in standby mode.

For more information on the CSS concept, see "Hot-plug HDD/SSD

modules" on page 94.

RX600 S6 Operating Manual 63

Starting up and operation

2 Global Error indicator (orange)

– Lights up orange if a prefailure event has been detected that

requires (precautionary) service intervention.

– Flashes orange if an error was detected that requires service

intervention.

– Does not light up if there is no critical event.

If the event is still acute after a power failure, the indicator is activated
after the restart.

The indicator also lights up in standby mode.

You can find more details on the indicated errors in the System Event
Log (SEL), on the ServerView Local Service Display, in the ServerView
Operations Manager or via the iRMC S2's Web interface.

64 Operating Manual RX600 S6

5.1.2.2 ID indicator and button

Starting up and operation

/

Figure 11: ID indicator

1 ID indicator (blue)

Lights up blue when the system has been selected by pressing the ID
button. To deactivate, press the ID button again.

The ID indicator can also be activated via the ServerView Operations
Manager and the iRMC S2 Web interface and its status reported to the
ServerView Operations Manager and the iRMC S2.

2 ID button

RX600 S6 Operating Manual 65

0

Starting up and operation

5.1.2.3 Indicators on the connector panel (LAN indicators)

0

/

2
1

0

/

0

0
/

Figure 12: LAN indicators

1 LAN speed

(system LAN/
shared LAN)

2LAN

link/transfer
(system LAN/
shared LAN)

3 LAN speed

(management
LAN)

/

Steady yellow signal in the event of a LAN transfer rate
of 1 Gbit/s.

Steady green signal in the event of a LAN transfer rate
of 100 Mbit/s.

Remains dark in the event of a LAN transfer rate of
10 Mbit/s.

Steady green signal when a LAN connection exists.

Remains dark when no LAN connection exists.

Flashes green when LAN transfer takes place.

Steady green signal in the event of a LAN transfer rate

of 100 Mbit/s.

Remains dark in the event of a LAN transfer rate of
10 Mbit/s.

66 Operating Manual RX600 S6

Starting up and operation

4LAN

link/transfer
(management
LAN)

5.1.2.4 Indicators on the hot-plug power supply units

Steady green signal when a LAN connection exists.

Remains dark when no LAN connection exists.

Flashes green when LAN transfer takes place.

/

0

1

Figure 13: Indicators on the power supply units

1 DC power

redundancy
indicator

2 PSU failure

and warnings
indicator

3 AC power

supply input
status
indicator

RX600 S6 Operating Manual 67

Lights up green when PSU is running.

Flashes green when PSU is in cold redundancy mode.

Lights up amber in case of a critical event (PSU

shutdown).

Flashes amber in case of a warning event (operation
continue).

Lights up green if AC power is present.

Flashes green if AC power is not present.

Starting up and operation

In normal server operation, LED 1 and 3 light up permanently, LED 2 does not
light up. As soon as LED 2 indicates a fault by lighting up, the affected power
supply unit should be replaced as soon as possible. This can be done during
operation (see "Hot-plug power supply units" on page 87).

68 Operating Manual RX600 S6

Starting up and operation

5.2 Switching the server on and off

V CAUTION!

● If nothing appears on the screen but flickering stripes after switching

on the server, switch the server off immediately (see chapter

"Troubleshooting and tips" on page 79).

● The On/Off button does not disconnect the server from the mains

voltage. To completely disconnect it from the mains voltage, remove
the power plug(s) from the socket(s).

● Do not move, strike, or shake the server when it is turned on. This can

damage the hard disk in the server and cause data loss.

● Turn the server on when the temperature is in its operating

environment range (10 – 35°C). For details on the operating
environment, refer to "Safety Precautions". When operating the
device outside of this operating environment, the server may operate
improperly, damage data etc. Furthermore, Fujitsu cannot be held
responsible for any related damage, malfunction, or loss of data, etc.

● Be sure to wait for 10 seconds or more after shutdown before turning

the server on.

● After connecting the power cords, press the On/Off button after it

passes for more than 10 seconds.

Switching the server on

The power-on indicator (see figure 8 on page 58) lights up orange (standby
mode) when the server is connected to the mains.

– Starting up for the first time:

For the Japanese market, please refer to " はじめにお読みください ".

Ê Press the On/Off button (see figure 8 on page 58).

Ê Insert ServerView Suite DVD 1 in the DVD drive.

Ê Follow the on-screen instructions (see also section "Configuring the

server and installing the operating system with the ServerView
Installation Manager" on page 73 or section "Configuring the server and
installing the operating system without the ServerView Installation
Manager" on page 74).

RX600 S6 Operating Manual 69

Starting up and operation

– System already installed:

Ê Press the On/Off button (see figure 8 on page 58).

The server is switched on, performs a system test and boots the
operating system.

Switching the server off

The power-on indicator lights up green (item 5 in figure 8 on page 58).

Ê Shut down the operating system properly.

The server is switched off automatically and goes into standby mode. The
power-on indicator lights up orange.

I If the operating system does not switch the server off automatically, press

the On/Off button for at least four seconds and/or send a corresponding
control signal.

Other On/Off options

Besides the On/Off button, the server can be switched ON and OFF in the
following ways:

– Timer-controlled switch-on/off

Using the ServerView Operations Manager or iRMC S2, you can configure
that the server is switched on/off controlled by timer.

– Ring indicator

The server is switched on by an internal or external modem.

– Wake up On LAN (WOL)

The server is switched on by a command via the LAN (Magic Packet

– After power failure

The server automatically reboots following a power failure (depending on the
settings in the BIOS or in iRMC S2).

– Power button override

The system can be switched off by pressing and holding down the On/Off
button (for approximately 4 - 5 seconds).

70 Operating Manual RX600 S6

TM

).

Starting up and operation

V CAUTION!

There is a risk that data may be lost.

– iRMC S2

iRMC S2 offers various options for switching the server on and off, e.g. via
the Power On Off page of the iRMC S2 Web interface.

V CAUTION when turning the power off (Windows Server 2008)!

The operation of the power switch can be specified as "Do Nothing",
"Stand by", "Hibernate", and "Shutdown" depending on the OS settings.
The default is "Shutdown".

On this server, functions corresponding to "Stand by" and "Hibernate" are
supported as BIOS and hardware functions. However, some drivers and
software installed in the server do not support these functions. For this
reason, functions corresponding to "Stand by" and "Hibernate" are
unavailable on this server. When the operating mode is set to "Stand by"
or "Hibernate", the system may operate improperly or hard disk data may
be corrupted.

For details about operating mode settings, refer to the manual supplied
with the OS.

RX600 S6 Operating Manual 71

Starting up and operation

5.3 Configuring the server

This section contains information about configuring the server and installing the
operating system.

I Make sure that the energy saving functions are disabled in the BIOS

Setup during server operation.

5.3.1 Configuring the SAS/SATA RAID controller card

The server comes with a SAS/SATA RAID controller with "MegaRAID
functionality". You can configure the SAS/SATA RAID controller either before or
during installation with the ServerView Installation Manager. Using the
ServerView Installation Manager is recommended.

I A separate utility is available to the controller for MegaRAID

configuration. For further information, refer to the "SAS Software User’s
Guide" (on the ServerView Suite DVD 2 under Industry Standard Servers -
Expansion Cards - Storage Adapters - LSI Configuration Software).

Further information on modular RAID controllers is provided in the
"Modular RAID Controller Installation Guide" (on the ServerView Suite
DVD 2 under Industry Standard Servers - Expansion Cards - Storage Adapters

- LSI RAID / SCSI Controllers).

I Descriptions of operating systems not covered in the controller manual

are provided in the corresponding readme files on the driver CDs.

72 Operating Manual RX600 S6

Starting up and operation

5.3.2 Configuring the server and installing the operating system with the ServerView Installation Manager

Using the ServerView Installation Manager on the ServerView Suite DVD 1
provided, you can conveniently configure the server and install the operating
system. This includes configuring the server-specific settings using the
ServerView Configuration Manager and configuring the RAID controller using
the ServerView RAID Manager.

Advantages of the ServerView Installation Manager

– Wizard assisted configuration of your server hardware and disk arrays

– Wizard assisted installation of all leading server operating systems

– Wizard-assisted creation of configuration files for unattended installation of

several PRIMERGY servers with identical hardware configurations.

– Installation of drivers and additional software.

I The software that can be installed depends on your server’s hardware

configuration. This configuration is detected automatically.

I Descriptions of operating systems not covered in the RAID controller

manual are provided in the corresponding readme files on the driver
CDs.

To find out how to operate the ServerView Installation Manager and for further
information, refer to the associated manual.

If you are using the ServerView Installation Manager, you can skip the following
section on how to configure the server and install the operating system.
Continue from section "Cleaning the server" on page 75.

RX600 S6 Operating Manual 73

Starting up and operation

5.3.3 Configuring the server and installing the operating system without the ServerView Installation Manager

Installing the operating system

Ê Insert the CD/DVD/BD for the operating system you want to install.

Ê Reboot the server.

Ê Follow the instructions on screen and in the manual for the operating

system.

74 Operating Manual RX600 S6

Starting up and operation

5.4 Cleaning the server

V CAUTION!

Switch the server off and disconnect the power plugs from the properly
grounded power outlets.

Do not clean any interior parts yourself; leave this job to a service
technician.

Do not use any cleaning agents that contain abrasives or may corrode
plastic.

Ensure that no liquid enters the system. Ensure that the ventilation areas
of the server and the monitor are clear.

Do not use any cleaning sprays (including flammable types). It may
cause a device failure or a fire.

Clean the keyboard and the mouse with a disinfecting cloth.

Wipe the server and monitor casing with a dry cloth. If particularly dirty, use a
cloth that has been moistened in a mild domestic detergent and then carefully
wrung out.

RX600 S6 Operating Manual 75

Starting up and operation

76 Operating Manual RX600 S6

6 Property and data protection

6.1 Mechanical access protection

The lockable rack door protects the server against unauthorized access.

6.2 BIOS Setup security functions

The Security menu in BIOS Setup offers various options for protecting your data
from unauthorized access. For example, you can assign passwords for users
and administrators. By combining these options you can achieve optimum
protection for your system.

I A detailed description of the Security menu and how to assign passwords

can be found in the BIOS Setup documentation on the ServerView Suite
DVD 2.

RX600 S6 Operating Manual 77

Property and data protection

78 Operating Manual RX600 S6

7 Troubleshooting and tips

V CAUTION!

Follow the safety instructions in the "Safety notes and regulations"
manual or " 安全上のご注意 " and in chapter "Important information" on

page 27.

If a fault occurs, attempt to resolve it using the measures described:

– in this chapter,
– in the documentation for the connected devices,
– in the help systems of the software used.

If you fail to correct the problem, proceed as follows:

Ê Make a list of the steps performed and the circumstances that led to the fault.

Also make a list of any error messages that were displayed.

Ê Switch off the server.

Ê Contact our customer service team.

7.1 Power-on indicator remains unlit

The power-on indicator remains dark after the server has been connected to
mains.

Power cable incorrectly connected

Ê Make sure that the power cable(s) is/are correctly connected to the server

and the grounded power outlet(s).

7.2 Server switches itself off

Server Management has detected an error

Ê Check the error list of System Event Log in ServerView Operations Manager

or in the iRMC S2 web interface, and attempt to eliminate the error.

RX600 S6 Operating Manual 79

Troubleshooting and tips

7.3 Screen remains blank

Monitor is switched off

Ê Switch on your monitor.

Screen has gone blank

Ê Press any key on the keyboard.

or

Ê Deactivate screen saver. Enter the appropriate password.

Brightness control is set to dark

Ê Set the brightness control on the monitor to light. For detailed information,

refer to the operating manual supplied with your monitor.

Power cable or monitor cable not connected

Ê Switch off the monitor and the server.

Ê Check whether the power cable is properly connected to the monitor and to

the grounded power outlet.

Ê Check whether the monitor cable is properly connected to the server and

monitor (if it is plugged in with a connector). If a separate graphics card is
installed in the server, then the monitor cable must be connected to the
graphics card.

Ê Switch on the monitor and the server.

80 Operating Manual RX600 S6

Troubleshooting and tips

7.4 Flickering stripes on monitor screen

V CAUTION!

Switch off the server immediately. Risk of damaging the server.

Monitor does not support the set horizontal frequency

Ê Find out which horizontal frequency your monitor screen supports. You will

find the horizontal frequency (also known as line frequency or horizontal
deflection frequency) in the documentation for your monitor.

Ê Refer to the documentation for your operating system or the software for the

screen controller for details of how to set the correct horizontal frequency for
your monitor, and follow the procedure accordingly.

7.5 No screen display or display drifts

The wrong horizontal frequency or resolution has been selected for the
monitor or for the application program.

Ê Find out which horizontal frequency your monitor screen supports. You will

find the horizontal frequency (also known as line frequency or horizontal
deflection frequency) in the documentation for your monitor.

Ê Refer to the documentation for your operating system or the software for the

screen controller for details of how to set the correct horizontal frequency for
your monitor, and follow the procedure accordingly.

RX600 S6 Operating Manual 81

Troubleshooting and tips

7.6 Incorrect date and time

Ê Set the date and time in the operating system or in the BIOS Setup under

the Main menu, using System Date and System Time respectively.

I Note that the operating system may affect the system time. For example,

the operating system time may deviate from the system time under
Linux, and would overwrite the system time in the default setting on
shutdown.

If the date and time are still wrong after the server has been switched off and
back on again, replace the lithium battery (for a description refer to the "System
Board D3141 for PRIMERGY RX600 S6 Technical Manual") or contact our
customer service team.

7.7 Drives reported as "dead" when starting system

RAID controller configuration incorrect

Ê Check and correct the settings for the drives using the RAID controller utility.

Further information is provided in the manual for the RAID controller.

7.8 Added drive reported as defective

RAID controller is not configured for this drive

The drive was probably installed when the system was switched off.

Ê Reconfigure the RAID controller for the drive using the corresponding utility.

Information is provided in the documentation for the RAID controller.

or

Ê Remove and reinstall the drive while the system is switched ON.

If the drive continues to be shown as defective, then replace it (see "Hot-plug

HDD/SSD modules" on page 94).

82 Operating Manual RX600 S6

Troubleshooting and tips

7.9 Error message on screen

The meaning of the error message is explained in the documentation for the
relevant components and programs on the ServerView Suite DVD 2.

RX600 S6 Operating Manual 83

Troubleshooting and tips

84 Operating Manual RX600 S6

8 CSS components

This chapter describes how to handle CSS components and how to identify
defective CSS components and replace them yourself.

I Further information on the CSS concept is provided in the "ServerView

Suite Local Service Concept - LSC" manual on the ServerView Suite
DVD 2.

For the latest information on optional products provided for the RX600 S6
see the configurator of the server:

http://ts.fujitsu.com/products/standard_servers/index.htm

(for the EMEA market)

http://primeserver.fujitsu.com/primergy/system/

(for the Japanese market)

V CAUTION!

● Do not disassemble the power supply unit. Doing so may cause

electric shock.

● Do not damage or modify internal cables or devices. Doing so may

cause a device failure, fire, or electric shock.

● Devices inside the server remain hot after shutdown. Wait for a while

after shutdown before installing or removing internal options.

● The circuit boards and soldered parts of internal options are exposed

and can be damaged by static electricity. Before handling them, first
touch a metal part of the server to discharge static electricity from
your body.

● Do not touch the circuitry on boards or soldered parts. Hold the

metallic areas or the edges of the circuit boards.

● If devices are installed or disassembled using methods other than

those outlined in this chapter, the warranty will be invalidated.

● The installation indicated on this note is sometimes changed to the

kind of possible options without notice.

● Follow the safety instructions in the chapter "Important information"

on page 27.

In the PRIMERGY RX600 S6 server, the following components are considered
to be CSS components:

RX600 S6 Operating Manual 85

CSS components

● Hot-plug components

– Hot-plug power supply units (see page 87)
– Hot-plug fans (see page 91)
– Hot-plug HDD/SSD modules (see page 94)
– Hot-plug memory boards (see page 109)
– Expansion cards in hot-plug PCIe slots (slots 6 & 7 only, see page 101)

You can expand or replace the hot-plug components during operation.

● Non-hot-plug components

– Expansion cards in non-hot-plug slots (see page 117)

These components can be changed by you in the event of an error.
Expansions and upgrades may only be carried out by authorized specialist
personnel.

86 Operating Manual RX600 S6

CSS components

8.1 Hot-plug components

This section describes how to handle hot-plug components and how to modify
your server hardware (e.g. adding/replacing hot-plug power supply units).

The hot-plug procedure increases the availability of system operation and
guarantees a high degree of data integrity and failsafe performance.

8.1.1 Hot-plug power supply units

The server must have at least two hot-plug power supply units (PSUs) to ensure
redundant power supply. If one power supply unit fails, the other unit ensures
that the operation can continue uninterrupted. The defective power supply unit
can be replaced during operation (hot-plug).

V CAUTION!

● Areas around the power supply unit may remain extremely hot after

shutdown. Wait for a while after shutdown before removing the power
supply unit.

● When installing the power supply unit, be sure to confirm that the

connector of the PSU is not damaged or bent.

● Do not insert your hands in the power supply unit slot when removing

the power supply unit. Doing so may cause electric shock.

● If the power supply unit is hard to remove, do not pull out it by force.

● The power supply unit is heavy, so handle it carefully. If you drop it by

mistake, injuries may result.

RX600 S6 Operating Manual 87

CSS components

8.1.1.1 Replacing a hot-plug power supply unit

0

Figure 14: Unlocking and removing the power supply unit

/

V CAUTION!

When replacing a non-defective hot-plug power supply unit in a non­redundant configuration, the server must be switched off first.

Ê Remove the power cord from the cable clamp. You can losen the cable

clamp by opening the small locking lever.

Ê Remove the power cord from the installed power supply unit.

Ê Press the green release lever (1) and pull out the power supply unit in the

direction of the arrow (2). Grip the handle while pulling the power supply.

V CAUTION!

Release your hands from lever (1) as soon as the power supply unit
has been pulled out a few centimeters.

Ê Completely remove the defective power supply unit from the slot.

V CAUTION!

Never leave the slot for the power supply unit empty for more than
two minutes during operation. Otherwise, excessive temperatures
could damage system components.

88 Operating Manual RX600 S6

CSS components

Ê Slide the new power supply unit into the empty slot until it clicks into place.

I Make sure that the new power supply unit engages correctly in the

mounting location and is locked in position. This is the only way to
prevent the power supply unit from sliding out of its mountings and
being damaged during transportation.

Ê Thread the cable through the cable clamp (see figure 6 on page 54).

Ê Pull the cable clamp tight to secure the power cord.

Ê Connect the newly installed power supply unit to the mains.

If everything is functioning correctly, the green LEDs 1 and 3 (see "Indicators

on the hot-plug power supply units" on page 67) at the rear of the power

supply unit will now light up.

8.1.1.2 Adding a hot-plug power supply unit

//

Figure 15: Removing a PSU dummy module

Ê Remove the PSU dummy module as follows:

1. Press the two metal clips together (see arrows (1) in figure above).

2. Pull the PSU dummy module out of its slot (see arrow (2) in figure above).

Ê Slide the new power supply unit into the empty slot until it clicks into place.

0

I Make sure that the new power supply unit engages correctly in the

mounting location and is locked in position.This is the only way to prevent
the power supply unit from sliding out of its mountings and being
damaged during transportation.

RX600 S6 Operating Manual 89

CSS components

Ê Thread the cable through the cable clamp (see figure 6 on page 54).

Ê Pull the cable clamp tight to secure the power cord.

Ê Connect the newly installed power supply unit to the mains.

If everything is functioning correctly, the green LEDs 1 and 3 (see "Indicators

on the hot-plug power supply units" on page 67) at the rear of the power

supply unit will now light up.

90 Operating Manual RX600 S6

CSS components

8.1.2 Hot-plug fans

The server comes with eight hot-plug fans. Each fan is mounted in a fan module
that is accessible from the top when opening the server.

A possible fan failure is reported by the CSS indicator lighting up on the front
and rear of the server as well as by the indicator on the fan module in question.

The fan failure is also displayed on the ServerView Local Service Display (see
the "Customer Self Service (CSS)" manual on the ServerView Suite DVD 2).

Identifying the defective CSS component

Ê Open the server (see "Opening/Closing the server" on page 125).

The defective fan is identified from the indicator on each fan (see figure 16

on page 91).

Figure 16: Indicator on a hot-plug fan

RX600 S6 Operating Manual 91

CSS components

8.1.2.1 Replacing a defective fan

Figure 17: Unlocking a fan module and removing it

Ê Press the two green handles and lift the fan module out of the housing (see

figure 17).

V CAUTION!

Never leave the fan module slot empty for more than two minutes
during operation. Otherwise, excessive temperatures could damage
system components.

Ê Insert the new fan module in the empty slot until it clicks into place. To make

sure the fan has engaged press again.

The new fan module is tested by Server Management. The LED then either
does not light at all (fan is ok) or lights up (fan is not ok).

Ê Close the server (see "Opening/Closing the server" on page 125).

92 Operating Manual RX600 S6

CSS components

8.1.2.2 Adding new fans

Ê Open the server (see "Opening/Closing the server" on page 125).

Ê Insert the new fan modules in the empty slots until they engage. To make

sure the fan has engaged press again.

The new fan module is tested by Server Management. The LED then either
does not light at all (fan is OK) or lights up (fan is not ok).

Ê Close the server (see "Opening/Closing the server" on page 125).

RX600 S6 Operating Manual 93

CSS components

8.1.3 Hot-plug HDD/SSD modules

The hard disk drives or solid state disks which can be ordered for the
PRIMERGY RX600 S6 are supplied already mounted in an installation frame so
that defective hard disk drives or solid state disks can be replaced and new
hard disk drives or solid state disks can be added during operation. The hard
disk drive or solid state disk and the installation frame together make up the
HDD/SSD module.

V CAUTION!

● The hard disk drive or solid state disk must not be removed from the

installation frame by anyone except a service technician.

● The HDD/SSD modules (drives) must all be marked clearly so that

they can be put back in their original places after an upgrade. If this
is not done, existing data can be lost.

● The hot-plug function is only possible in conjunction with a

corresponding RAID configuration.

Further information about the RAID configuration or RAID level can
be found in the RAID controller documentation.

● Do not touch the circuitry on boards or soldered parts. Hold the

metallic areas or the edges of the circuit boards.

● Before removing the unit, wait for about 30 seconds until the disk

stops spinning completely.

● When the hard disk unit is starting up, you may hear a resonant noise

for a while, but this does not mean a failure.

● Depending on the OS, you can configure the write cache settings for

the hard disk drives or solid state disks. If a power failure should occur
while the write cache is enabled, cached data may be lost.

● When disposing of, transferring, or returning a hard disk unit, wipe out

the data on the drive for your own security.

● Rough handling of hard disk units can damage the stored data. To

cope with any unexpected problems, always back up important data.
When backing up data to another hard disk drive, you should make
backups on a file or partition basis.

● Be careful not to hit the hard disk unit or bring it into contact with

metallic objects.

94 Operating Manual RX600 S6

CSS components

● Use the device on a shock and vibration free surface.

● Do not use the unit in extremely hot or cold locations, or locations with

extreme temperature changes.

● Never attempt to disassemble the hard disk unit.

Handling drives and HDD/SSD modules

Drives incorporated in the HDD/SSD modules are highly sensitive
electromagnetic devices and must be handled with great care. Incorrect
handling can cause partial or total failure of the drives. These failures can result
in data errors and to a loss of data or to total corruption of the drive.

Observe the following rules to prevent such problems occurring:

● Only store and transport HDD/SSD modules within the limits stipulated in the

specification.

● When transporting HDD/SSD modules (even over short distances), always

use the original packaging (ESD label).

● Never expose HDD/SSD modules to a temperature shock. Avoid the

formation of condensation inside and on the outside of the drive.

V CAUTION!

The HDD/SSD module must be acclimatized in its operating
environment for an acclimatization time before it is started up for the
first time.

Temperature difference (°C)

(operating environment/

Minimum acclimatization time

(hours)

outside)

53

10 5

15 7

20 8

25 9

30 10

Table 5: Acclimatization times for HDD/SSD modules

RX600 S6 Operating Manual 95

CSS components

● Always set the HDD/SSD module down carefully, with the large surface

facing downwards to prevent it from tipping over.

8.1.3.1 HDD/SSD module and dummy module

/0 1 2345

Figure 18: 2.5-inch HDD module and dummy module

0

1 Dummy module

2 Tabs for unlocking the dummy module

3 HDD/SSD module (installation frame with hard disk drive or solid state

disk installed)

4 Indicators:

HDD/SSD Busy (LED green)
HDD/SSD Fault (LED orange)
For description see section "Indicators on the hot-plug HDD/SSD

modules" on page 62.

5 Handle for locking and unlocking the HDD/SSD module

6 Button for locking and unlocking the handle

7 Ridge for applying a sticker with the current drive name and drive size

96 Operating Manual RX600 S6

CSS components

8.1.3.2 Removing/installing the dummy module

Free slots are provided with dummy modules. Remove the dummy module
before installing an additional HDD/SSD module.

0

0

1

Figure 19: Removing/installing the 2.5-inch dummy module

Ê Press both tabs on the dummy module together until the locking mechanism

disengages (1).

Ê Pull the dummy module out of the bay (2).

To install a dummy module, follow the same procedure in reverse order.

V CAUTION!

Store the dummy module in a safe place. If you have removed an
HDD/SSD module and do not install a new one in its place, put the
dummy module back in its place for cooling, to comply with EMC
regulations (regulations regarding electromagnetic compatibility), and for
protection against fire. Ensure that the dummy module engages correctly
in the bay.

RX600 S6 Operating Manual 97

CSS components

8.1.3.3 Installing the HDD/SSD module

/

/

Figure 20: Unlocking the 2.5-inch HDD/SSD module

Ê Release the locking mechanism as follows:

1. Press the two green tabs of the locking lever together (1).

0

2. Push the handle of the HDD/SSD module fully in the direction of the
arrow (2). The HDD/SSD module is now unlocked.

98 Operating Manual RX600 S6

CSS components

/

0

Figure 21: Installing the 2.5-inch HDD/SSD module

Ê Carefully push the HDD/SSD module into the empty slot (1) until it stops.

Ê Push the handle completely (2) in the direction of the arrow until the locking

mechanism engages.

8.1.3.4 Removing the HDD/SSD module

V CAUTION!

● Only remove an HDD/SSD module during operation if the drive is not

currently being accessed. Observe the control LEDs for the
corresponding HDD/SSD modules (see "Indicators on the hot-plug

HDD/SSD modules" on page 62).

● Under no circumstances should you remove an HDD/SSD module

while the system is in operation if you are not sure that the hard disk
drive or solid state disk is operated by a RAID controller and belongs
to a disk array that is operating in RAID level 1, 1E, 10, 5, 50, 6 or 60.

An HDD/SSD module can only be replaced during operation in
conjunction with a corresponding RAID configuration.

● All HDD/SSD modules (drives) must be uniquely identified so that

they can be reinstalled in their original mounting locations later. If this
is not done, existing data can be lost.

RX600 S6 Operating Manual 99

CSS components

If you want to remove an HDD/SSD module during operation, proceed as
follows:

Ê If you want to remove an HDD/SSD module that is not defective, the drive

must be first set to "Offline" via the software (RAID controller configuration
software).

Ê Unlock the HDD/SSD module as described in section "Installing the

HDD/SSD module" on page 98.

Ê Pull the HDD/SSD module out a few centimeters.

Ê Wait for at least 60 seconds.

I This period is necessary for the RAID controller to recognize that an

HDD/SSD module has been removed and for the hard disk drive to
come to a stop.

Ê Pull the HDD/SSD module out completely.

Ê Install the new HDD/SSD module, as described in "Installing the HDD/SSD

module" on page 98.

V CAUTION!

If you have removed an HDD/SSD module and do not install a new
one in its place, put the dummy module back in its place for cooling,
to comply with EMC regulations (regulations regarding
electromagnetic compatibility), and for protection against fire. Ensure
that the dummy module engages correctly in the bay.

100 Operating Manual RX600 S6
