1 Preface
The PRIMERGY RX600 S4 server is an Intel-based server for mid-size and
large companies. The server is suitable for use as a file server and also as an
application, information or Internet server. It is used as a rack model.
Thanks to its highly developed hardware and software components, the server
offers a high level of data security and availability. These include hot-plug HDD
modules, hot-plug system fans and power supply units, and also hot-plug PCI
slots, the Server Management Software ServerView, "Prefailure Detection and
Analysis" (PDA) and "Automatic Server Reconfiguration and Restart" (ASR&R).
Security functions in the BIOS-Setup and on the system board protect the data
on the server against manipulation. Additional security is provided by the
lockable rack door.
The server occupies 4 height units (HU) in the rack.
1.1 Concept and target groups for this manual
This operating manual describes how to install, set up and operate your server.
This operating manual is intended for those responsible for installing the
hardware and ensuring that the system runs smoothly. It contains all the information you need to put your PRIMERGY RX600 S4 into operation.
To understand the various expansion options, you will need to be familiar with
the fields of hardware and data transmission and you will require a basic
knowledge of the underlying operating system.
RX600 S4 Operating manual 7
Documentation overview Preface
1.2 Documentation overview
More information on your PRIMERGY RX600 S4 can be found in the following
documents:
– “Quick Start Hardware - PRIMERGY RX600 S4” leaflet (only included as a
printed copy)
– “Quick Start Software - Quick Installation Guide” leaflet (only included as a
printed copy)
– “Safety notes and other important information” manual
– “Warranty” manual
– “Customer Self Service (CSS)” manual
– “Ergonomics” manual
– “Returning used devices” manual
– “Helpdesk” leaflet
– Technical manual for the system board D2244
– “PRIMERGY RX600 S4 Server Operating Manual”
– “PRIMERGY RX600 S4 Server Options Guide”
– “Fujitsu Siemens Computers Phoenix Trusted Core
TM
BIOS” manual
– "Integrated RAID for SAS User’s Guide"
– “ServerView RAID User's Guide”
– “Integrated Mirroring User’s Guide”
I PRIMERGY manuals are available in PDF format on the ServerBooks
DVD. The ServerBooks DVD is part of the ServerView Suite supplied with
every server.
The PDF files of the manuals can also be downloaded free of charge
from the Internet. The overview page showing the online documentation
available on the Internet can be found using the URL:
http://manuals.fujitsu-siemens.com. The PRIMERGY server documentation
can be accessed using the Industry standard servers navigation option.
If you need a replacement copy of the ServerBooks DVD, send the
details of your server to the following e-mail address: Reklamat-PC-
LOG@fujitsu-siemens.com
8 Operating manual RX600 S4
Preface Features
Further sources of information:
– Manual for the monitor
– Documentation for boards and drives
– Documentation for your operating system
– Information files on your operating system
1.3 Features
Customer Self Service (CSS)
The Fujitsu Siemens Computers Customer Self Service (CSS) concept enables
you to identify and replace the affected component yourself in the case of
certain error scenarios.
In the CSS concept, you can replace the following components yourself in the
event of an error:
– Hot-plug hard disk drives
– Hot-plug power supply units
– Memory modules
– System fans
– Expansion cards
For information on replacing these components, see chapter “CSS compo-
nents” on page 81.
CSS indicators on the control panel and on the back of the PRIMERGY server
provide you with information if a CSS event arises (for more information on the
behavior of these indicators, see chapter “Starting up and operation” on
page 55 and the "Customer Self Service (CSS)" manual on the ServerBooks
DVD).
You can also fit your server with a ServerView Local Service Panel, which
enables you to identify the type of component affected by the error directly on
the server (for more information, see the "Customer Self Service (CSS)" manual
on the ServerBooks DVD).
In addition, CSS errors are displayed in ServerView S2, the server
management software from Fujitsu Siemens Computers.
RX600 S4 Operating manual 9
Features Preface
In the event of errors, ServerView S2 refers you directly to the affected
component and its order information in the Illustrated Spares catalog of the
server in question.
System board
The features of the system board are described in the technical manual for the
system board D2244 for the hardware and in the “BIOS Setup” for the firmware.
Hot-plug PCI slots
The server has three standard PCI slots and four hot-plug PCI slots. These hotplug PCI slots allow installation and removal of boards during operation when
the operating system supports this function (for further details see section “Hot-
plug expansion cards” on page 97).
Hard disk drives
The server is equipped with a drive bay in which up to 8 SAS HDD modules can
be inserted. Each HDD module can accommodate an SAS hard disk drive with
a 2.5-inch format. The modules are connected to the SAS backplane wirelessly.
This allows HDD modules to be plugged in or pulled out easily.
The hard disk system is designed for SAS with one channel for each hard disk
drive.
If the server has the corresponding RAID configuration, HDD modules can also
be replaced during operation.
An external SCSI interface is also offered optionally to allow external storage
subsystems to be connected. You will find further information in the Options
Guide.
Onboard SAS RAID controller
There is an onboard SAS RAID controller for operating eight SAS hard disk
drives. RAID levels 0, 1, 5, 10 and 50 are supported.
A BBU backs up the memory contents also in the event of power failure (option).
10 Operating manual RX600 S4
Preface Features
Accessible drives/components
A number of mounting locations are available:
– An installation slot for a ServerView Local Service Display (standard)
– An installation slot for a slimline CD/DVD drive (option)
– A 5.25-inch bay for a magnetic tape drive (option)
The accessible drives/components integrated in this locations cannot be
replaced during operation.
Power supply
The server has two hot-plug power supply units that automatically switch to a
mains voltage of 110 V - 240 V. This ensures redundant power supply. If one
power supply unit is defective, the other then guarantees unimpaired operation.
The faulty power supply unit can be replaced during operation (for further details
see section “Replacing the hot-plug power supply unit” on page 82).
Cooling
Each processor has a heat sink. Further cooling for the installed processors is
provided by four hot-plug CPU fans (redundant configuration). Two CPU fans
are mounted in each fan module.
Temperature sensors variably adjust the fans. If a temperature sensor fails or is
removed, the CPU fans affected run at maximum speed so as to provide the
greatest possible protection for the hardware. When the housing is open, all the
CPU fans run at maximum speed.
If a CPU fan fails, unimpaired further operation is ensured. A defective fan
module can be replaced during operation (for further details see “Replacing hot-
plug CPU fans” on page 84).
The main memory is cooled by two fan units. Each fan unit consists of two
separate hot-plug fans. If one fan in a redundant unit fails, the system is able to
continue operating without limitations. If a fan fails, it can be replaced while the
system is running (for further details see section “Replacing hot-plug main
memory fans” on page 86).
RX600 S4 Operating manual 11
Features Preface
High level of availability and data security
When memory data is accessed, 1-bit errors in the main memory are identified
and automatically corrected with the ECC (Error Correcting Code) method. The
patented memory scrubbing function regularly starts up the EDC mechanism
(Error Detection Code) and thus ensures continuous data integrity.
The memory modules used support SDDC technology (Chipkill™), which
further increases the effectiveness of memory error monitoring and correction.
Support is likewise provided for hot-spare memory technology, in which a
memory bank is used like a replacement bank. If a memory module fails, the
bank with the defective memory is automatically deactivated and the
replacement bank is activated (provided it has been configured for appropriately
in the BIOS). The deactivated memory bank is no longer used and the faulty
memory module can be replaced at the next opportunity. In order to be able to
use the hot-spare memory function, all occupied memory banks must have an
identical memory configuration.
Memory modules can be protected against failure through mirroring (memory
mirroring, requires two or four memory modules).
ASR&R (Automatic Server Reconfiguration and Restart) restarts the system in
the event of an error and automatically "hides" the defective system components.
The PDA (Prefailure Detection and Analysis) technology from Fujitsu Siemens
Computers analyzes and monitors all components that are critical for system
reliability.
The onboard SAS controller supports the RAID levels 0, 1, 10, 5 and 50, thus
increasing system availability and reliability.
Additional reliability is provided by the hot-plug HDD modules, fans, power
supply units and expansion cards.
12 Operating manual RX600 S4
Preface Features
iRMC S2 with integrated service LAN port
I The features of the iRMC S2 Advanced Video Redirection and Remote
Storage are available as an option.
The iRMC S2 (integrated Remote Management Controller) is a BMC with
integrated service LAN port and expanded functionality that was previously only
available with additional plug-in cards. In this way, the iRMC S2 enables
complete control of PRIMERGY servers, regardless of system status, and thus
particularly the control of PRIMERGY servers that are in the “out-of-band”
system status.
Major functions supported by the iRMC S2 include the following:
● Browser access via iRMC's own Web server
● Secure communication (SSH, SSL)
● Power Management for the managed server (depending on its system
status)
● Power Consumption Management
● Connecting virtual drives as remote storage
● Text-based and graphic console bypass (Advanced Video Redirection)
● Command Line Interface (CLP)
● Simple, interactive or script-based iRMC S2 configuration
● Customer Self Service (CSS)
● iRMC-s own user management
● Multi-computer, global iRMC user administration using an LDAP Directory
Service
● Automatic network configuration via DNS / DHCP
● Power supply of the iRMC S2 via the system standby supply
● Full-coverage alarm management
● System Event Log (SEL) reading and processing
More information about the iRMC S2 can be found in the “iRMC S2 - integrated
Remote Management Controller” manual.
RX600 S4 Operating manual 13
Features Preface
Server management
Server management is implemented using the ServerView software supplied
combined with PDA (Prefailure Detection and Analysis) technology from Fujitsu
Siemens Computers. PDA reports the threat of a system error or overload at an
early stage, allowing preventive measures to be taken.
ServerView enables the management of all PRIMERGY servers in the network
via a central console. The following key functions and others are supported by
ServerView:
● Round-the-clock monitoring, regardless of server status
● High-performance, graphical console bypass (AVR) protected by
HTTPS/SSL (128-bit)
● Remote storage via USB
● Remote power on (Wake On LAN)
● Automatic switch-off when the housing is opened (housing monitoring)
● Temperature monitoring of the CPU and the surrounding area
● Watchdog timer for Automatic Server Reconfiguration and Restart (ASR&R)
in the event of failure of memory modules or processors
● Power monitoring
● End-of-life monitoring of fans with prompt notification before failure
● Watchdog timer for monitoring the operating system and applications with
ASR&R
Further information on the ServerView server management is provided in the
associated documentation.
14 Operating manual RX600 S4
Preface Features
ServerStart
You can configure the PRIMERGY server quickly and precisely with the
ServerStart software provided. User-guided menus are available for installing
the server operating system (for further details see section “Configuring the
server” on page 69).
Service and support
PRIMERGY servers are service-friendly and modular, enabling quick and easy
maintenance.
For easier and immediate recognition, handles and locks (touch points) are
color coded. Blue touch points are for components that can be replaced without
tools. Green touch points are for hot-plug components that can be replaced or
inserted during operation without the need for tools (see also “CSS compo-
nents” on page 81).
You can use the ServerView Local Service Display on the front panel of the
server to check the status of the key system components at any time without
opening the housing. Further information on ServerView Local Service Display
is provided in the associated documentation.
For further information, please refer to the diagnosis LEDs on the hot-plug
components (power supply unit, fans, expansion cards, HDD modules).
The Global Flash program supplied with the Fujitsu Siemens Computers utilities
supports a fast remote BIOS update via the LAN interface; the BIOS can be
updated locally via USB. The optional RemoteView remote testing and
diagnostic system enables you to remotely maintain your server.
RX600 S4 Operating manual 15
Features Preface
ServerView Remote Management
ServerView Remote Management is the remote management solution from
Fujitsu Siemens Computers for PRIMERGY servers. ServerView Remote
Management and the relevant hardware components integrated on the system
board allow remote monitoring and maintenance as well as fast restoration of
operation in the event of errors.
Remote monitoring and maintenance avoids time-consuming and costly on-site
repairs and reduces service costs. This leads to a reduction in the total cost of
ownership and an excellent return on investment for the remote management
solution.
The administrator can access all system information and information from the
sensors such as fan speeds or voltages via the iRMC S2's Web interface (see
section “iRMC S2 with integrated service LAN port” on page 13). He can also
start the text-based or graphic console bypass (Advanced Video Redirection,
AVR) and get information about remote storage.
I The features of the iRMC S2 Advanced Video Redirection and Remote
Storage are available as an option.
16 Operating manual RX600 S4
Preface Notational conventions
1.4 Notational conventions
The following notational conventions are used in this manual:
Text in italics indicates commands or menu items.
“Quotation marks” indicate names of chapters and terms that are being
emphasized.
Ê describes activities that must be performed in the order
shown.
V CAUTION! pay particular attention to texts marked with this symbol.
Failure to observe this warning may endanger your life,
destroy the system or lead to the loss of data.
I indicates additional information, notes and tips.
1.5 Technical data
Electrical data (hot-plug power supply unit)
Rated voltage range 110 V - 240 V
Frequency 50 Hz - 60 Hz
Rated current with basic configuration 1.6 A (240 V)
Max. rated current 5.0 A (240 V)
Effective power 1150 W
Apparent power 1195 VA
Heat dissipation 4140 KJ/h (3924 BTU)
Main power fuse 16 A
Protection class I
RX600 S4 Operating manual 17
Technical data Preface
Compliance with regulations and standards
Product safety and
ergonomics
Electromagnetic
compatibility
Interference
emissions
Interference
immunity
Harmonic current EN 61000-3-2
Flicker EN 61000-3-3
CE marking to EU
directives
Environmental
conditions
Noise emission ETSI 300 753 Class 3.1
IEC 60950-1 / EN 60950-1, UL/CSA 60950-1,
CNS 14336 / GB 4943 / EN 50371
EN 55022 class A; FCC class A; CNS 13438 class A;
VCCI class A; AS/NZS CISPR 22 class A;
GB 9254 class A; GB 17625; ETSI EN 300 386 V1.3.1
EN 55024, EN 300386
Low Voltage Directive 2006/95/EC
(product safety)
Electromagnetic compatibility 2004/108/EC
ETSI 300 019-2-3 Class 3.1 (T3.1)
Mechanical values
Width 482.6 mm
Depth 737.0 mm
Height 176.0 mm (4 HU)
Installation depth in rack 700.0 mm
Cable depth in rack 100.0 mm (1000 mm rack recommended)
18 Operating manual RX600 S4
Preface Technical data
Weight
Approx. 40 kg (depending on configuration).
Ventilation clearance
At least 200 mm on the front and rear.
Ambient conditions
Environment class 3K2
Environment class 2K2
EN 60721 / IEC 721 Part 3-3
EN 60721 / IEC 721 Part 3-2
Temperature:
Operation (3K2) 10 °C .... 35 °C
Transport (2K2) -25 °C .... 60 °C
Humidity 10% ... 85%
Condensation during operation must be avoided!
Noise level
Sound power level L
Sound pressure level at bystander position L
(ISO 9296) < 7.0 B (standby)
WAd
pAm
(ISO 9296) (at < 23 °C)
< 7.0 B(operation)
< 55 dB (A) (standby)
< 55 dB (A)(operation)
RX600 S4 Operating manual 19
2 Overview of the installation steps
This chapter contains an overview of the steps necessary to install your server.
Links guide you to sections where you can find more detailed information on the
individual steps:
Ê At first, please take notice of the safety instructions in chapter “Important
information” on page 23 and following.
Ê Transport the server to the place where you want to install it.
Ê Unpack all parts, check the contents of the package for visible transport
damage and check whether the items delivered match the details on the
delivery note (see section “Unpacking the server” on page 38).
Ê Make sure that all necessary manuals (see “Documentation overview” on
page 8) are available; print out the PDF files if required.
Ê Fit the server in the rack (see section “Rack installation/removal of server”
on page 39).
Ê Wire the server. Follow the instructions in the sections “Connecting devices
to the server” on page 49 and “Notes on connecting/disconnecting cables”
on page 54.
Ê Connect the server to the mains (see section “Connecting the server to the
mains” on page 52).
Ê Familiarize yourself with the controls and indicators on the front and rear of
the server (see section “Controls and indicators” on page 55).
RX600 S4 Operating manual 21
Overview of the installation steps
Ê Configure the server and install the desired operating system and applica-
tions. Here you can choose from two possibilities:
– Remote configuration and installation with ServerStart:
The ServerStart disc 1 supplied allows you to conveniently configure the
server and install the operating system.
Details on how to operate ServerStart, as well as some additional information, can be found in the “ServerView Suite - ServerStart” manual,
supplied as a PDF file.
Configuration information can also be found in section “Configuration
with ServerStart” on page 70.
– Local configuration and installation with or without ServerStart (see
section “Configuration with ServerStart” on page 70 or section “Configu-
ration without ServerStart” on page 71).
22 Operating manual RX600 S4
3 Important information
In this chapter you will find essential information regarding safety when working
on your server.
3.1 Safety instructions
I The following safety instructions are also provided in the manual “Safety
notes and other important information”.
This device meets the relevant safety regulations for IT equipment. If you have
any questions about whether you can install the server in the intended
environment, please contact your sales outlet or our customer service team.
V CAUTION!
● The actions described in this manual should only be performed by
technical specialists.
● Repairs to the device that do not relate to CSS failures must only be
carried out by service personnel. Please note that unauthorized interference with the system will void the warranty and exempt the
manufacturer from all liability.
● Any failure to observe the guidelines in this manual, and any improper
repairs could expose the user to risks (electric shock, energy
hazards, fire hazards) or damage the equipment.
RX600 S4 Operating manual 23
Safety instructions Important information
Before starting up
V CAUTION!
● During installation and before operating the device, observe the
instructions on environmental conditions for your device (see
“Technical data” on page 17).
● If the server has been moved from a cold environment, condensation
may form both inside and on the outside of the machine.
Wait until the server has acclimatized to room temperature and is
absolutely dry before starting it up. Material damage may be caused
to the server if this requirement is not met.
● Only transport the server in the original packaging or in packaging
that protects it from impacts and jolts.
Installation and operation
V CAUTION!
● This unit should not be operated in ambient temperatures above
35 °C.
● If the unit is integrated into an installation that draws power from an
industrial power supply network with an IEC309 connector, the power
supply's fuse protection must comply with the requirements for nonindustrial power supply networks for type A connectors.
● The unit automatically adjusts itself to a mains voltage in a range of
110 V - 240 V. Ensure that the local mains voltage lies within these
limits.
● This device must only be connected to properly grounded shock-
proof sockets or insulated sockets of the rack's internal power supply
with tested and approved power cables.
● Ensure that the device is connected to a grounded shockproof socket
close to the device.
24 Operating manual RX600 S4
Important information Safety instructions
V CAUTION!
● Ensure that the power sockets on the device and the grounded shock-
proof sockets are freely accessible.
● The On/Off button or the main power switch (if present) does not
isolate the device from the mains power supply. To disconnect it
completely from the mains power supply, unplug all network power
plugs from the grounded shockproof sockets.
● Always connect the server and the attached peripherals to the same
power circuit. Otherwise you run the risk of losing data if, for example,
the server is still running but a peripheral device (e.g. memory
subsystem) fails during a power outage.
● Data cables must be adequately shielded.
● The EN 50173 and EN 50174-1/2 standards apply for LAN cabling.
The minimum requirement is the use of a category 5 screened LAN
cable for 10/100 Mbps Ethernet, or a category 5e cable for Gigabit
Ethernet. The requirements from the ISO/IEC 11801 specification
must also be met.
● Route the cables in such a way that they do not create a potential
hazard (make sure no-one can trip over them) and that they cannot
be damaged. When connecting the server, refer to the relevant
instructions in this manual.
● Never connect or disconnect data transmission lines during a storm
(risk of lightning strike).
● Make sure that no objects (e.g. jewelry, paperclips etc.) or liquids can
get inside the server (risk of electric shock, short circuit).
● In emergencies (e.g. damaged casing, controls or cables, penetration
of liquids or foreign bodies), switch off the server immediately, remove
all power plugs and contact your sales outlet or customer service
team.
RX600 S4 Operating manual 25
Safety instructions Important information
V CAUTION!
● Proper operation of the system (in accordance with IEC 60950-1/
EN 60950-1) is only ensured if the casing is completely assembled
and the rear covers for the installation slots have been fitted (electric
shock, cooling, fire protection, interference suppression).
● Only install system expansions that satisfy the requirements and
rules governing safety and electromagnetic compatibility and those
relating to telecommunication terminals. If you install other expansions, they may damage the system or violate the safety regulations.
Information on which system expansions are approved for installation
can be obtained from our customer service center or your sales
outlet.
● The components marked with a warning notice (e.g. lightning symbol)
may only be opened, removed or exchanged by authorized, qualified
personnel. Exception: hot-plug power supply units/CCS components
can be replaced.
● The warranty is void if the server is damaged during installation or
replacement of system expansions.
● Only set screen resolutions and refresh rates that are specified in the
operating manual for the monitor. Otherwise, you may damage your
monitor. If you are in any doubt, contact your sales outlet or customer
service center.
26 Operating manual RX600 S4
Important information Safety instructions
Batteries
V CAUTION!
● Incorrect replacement of batteries may lead to a risk of explosion. The
batteries may only be replaced with identical batteries or with a type
recommended by the manufacturer (see the technical manual for the
system board).
● Do not throw batteries into the trash can. They must be disposed of
in accordance with local regulations concerning special waste.
● The battery must be disposed of in accordance with local regulations
concerning special waste.
● Replace the lithium battery on the system board in accordance with
the instructions in the technical manual for the system board.
● All batteries containing pollutants are marked with a symbol (a
crossed-out garbage can). In addition, the marking is provided with
the chemical symbol of the heavy metal decisive for the classification
as a pollutant:
Cd Cadmium
Hg Mercury
Pb Lead
RX600 S4 Operating manual 27
Safety instructions Important information
Working with CDs/DVDs and CD/DVD drives
When working with devices with CD/DVD drives, these instructions must be
followed.
V CAUTION!
● Only use CDs/DVDs that are in perfect condition in your server's
CD/DVD drive, in order to prevent data loss, equipment damage and
injury.
● Check each CD/DVD for damage, cracks, breakages etc. before
inserting it in the drive.
Note that any additional labels applied may change the mechanical
properties of a CD/DVD and cause imbalance.
Damaged and imbalanced CDs/DVDs can break at high drive speeds
(data loss).
Under certain circumstances, sharp CD/DVD fragments can pierce
the cover of the CD/DVD drive (equipment damage) and can fly out
of the device (danger of injury, particularly to uncovered body parts
such as the face or neck).
I You can prevent mechanical damage and damage to the CD/DVD drive,
as well as premature CD/DVD wear, by observing the following suggestions:
– Only insert CDs/DVDs in the drive when needed and remove them
after use.
– Store the CDs/DVDs in suitable sleeves.
– Protect the CDs/DVDs from exposure to heat and direct sunlight.
Laser information
The CD/DVD drive complies with IEC 60825-1 laser class 1.
V CAUTION!
The CD/DVD drive contains a light-emitting diode (LED), which under
certain circumstances produces a laser beam stronger than laser
class 1. Looking directly at this beam is dangerous.
Never remove parts of the CD/DVD drive casing!
28 Operating manual RX600 S4
Important information Safety instructions
Modules with Electrostatic-Sensitive Devices
Modules with electrostatic-sensitive devices are identified by the following
sticker:
Figure 1: ESD label
When you handle components fitted with ESDs, you must always observe the
following points:
● Switch off the system and remove the power plugs from the power outlets
before installing or removing components with ESDs.
● You must always discharge static build-up (e.g. by touching a grounded
object) before working with such components.
● Any devices or tools that are used must be free of electrostatic charge.
● Wear a suitable grounding cable that connects you to the external chassis of
the system unit.
● Always hold components with ESDs at the edges or at the points marked
green (touch points).
● Do not touch any connectors or conduction paths on an ESD.
● Place all the components on a pad which is free of electrostatic charge.
I For a detailed description of how to handle ESD components, see the
relevant European or international standards (EN 61340-5-1,
ANSI/ESD S20.20).
RX600 S4 Operating manual 29
CE conformity Important information
Other important information:
● During cleaning, observe the instructions in section “Cleaning the server” on
page 71.
● Keep this operating manual and the other documentation (such as the
technical manual, CD) close to the device. All documentation must be
included if the equipment is passed on to a third party.
3.2 CE conformity
The system complies with the requirements of the EC directives
2004/108/EC regarding “Electromagnetic Compatibility” and
2006/95/EC “Low Voltage Directive”. This is indicated by the CE
marking (CE = Communauté Européenne).
30 Operating manual RX600 S4
Important information FCC Class A Compliance Statement
3.3 FCC Class A Compliance Statement
If there is an FCC statement on the device, then:
The following statement applies to the products covered in this manual, unless
otherwise specified herein. The statement for other products will appear in the
accompanying documentation.
NOTE:
This equipment has been tested and found to comply with the limits for a
“Class A” digital device, pursuant to Part 15 of the FCC rules and meets all
requirements of the Canadian Interference-Causing Equipment Standard
ICES-003 for digital apparatus. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in strict accordance with the instructions, may cause harmful
interference to radio communications. However, there is no warranty that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between equipment and the receiver.
● Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
● Consult the dealer or an experienced radio/TV technician for help.
Fujitsu Siemens Computers is not responsible for any radio or television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those
specified by Fujitsu Siemens Computers. The correction of interferences
caused by such unauthorized modification, substitution or attachment will be the
responsibility of the user.
The use of shielded I/O cables is required when connecting this equipment to
any and all optional peripheral or host devices. Failure to do so may violate FCC
and ICES rules.
RX600 S4 Operating manual 31
Transporting the server Important information
WARNING:
This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
3.4 Transporting the server
V CAUTION!
Only transport the server in its original packaging or in packaging that
protects it from impacts and jolts. Do not unpack the server until it is at
its installation location.
If you need to lift or transport the server, ask other people to help you.
Never lift or carry the device by the handles on the front panel.
32 Operating manual RX600 S4
Important information Notes on installing in the rac
k
3.5 Notes on installing in the rack
V CAUTION!
● For safety reasons, at least two people are required to install the
rack model because of its weight and size.
● Never lift the server into the rack using the handles on the front panel.
● When connecting and disconnecting cables, observe the relevant
instructions in the “Important Information” chapter of the technical
manual for the corresponding rack. The technical manual is supplied
with the corresponding rack.
● When installing the rack, make sure that the anti-tilt mechanism is
correctly fitted.
● For safety reasons, no more than one unit may be removed from the
rack at any one time during installation and maintenance work.
● If several units are simultaneously removed from the rack, there is a
risk that the rack could tip over.
● The rack must be connected to the power supply by an authorized
specialist (electrician).
● If the rack model is integrated into an installation that draws power
from an industrial power supply network with an IEC309 type
connector, the power supply's fuse protection must comply with the
requirements for non-industrial power supply networks for the type A
connector.
RX600 S4 Operating manual 33
Environmental protection Important information
3.6 Environmental protection
Environmentally-friendly product design and development
This product has been designed in accordance with the Fujitsu Siemens
Computers standard for “environmentally friendly product design and development”. This means that key factors such as durability, selection and labeling
of materials, emissions, packaging, ease of dismantling and recycling have
been taken into account.
This saves resources and thus reduces the harm done to the environment.
Energy-saving information
Devices that do not need to be constantly switched on should be switched off
until they are needed as well as during long breaks and after completion of work.
Packaging information
Do not throw away the packaging. You may need it later for transporting the
system. If possible, the equipment should only be transported in its original
packaging.
Information on handling consumables
Please dispose of printer consumables and batteries in accordance with the
applicable national regulations.
In accordance with EU directives, batteries must not be disposed of with
unsorted domestic waste. They can be returned free of charge to the manufacturer, dealer or an authorized agent for recycling or disposal.
All batteries containing pollutants are marked with a symbol (a crossed-out
garbage can). They are also marked with the chemical symbol for the heavy
metal that causes them to be categorized as containing pollutants:
Cd Cadmium
Hg Mercury
Pb Lead
34 Operating manual RX600 S4
Important information Environmental protection
Labels on plastic casing parts
Please avoid sticking your own labels on plastic parts wherever possible, since
this makes it difficult to recycle them.
Returns, recycling and disposal
The device must not be disposed of with domestic waste. This
device is labeled in compliance with European directive
2002/96/EC on waste electrical and electronic equipment (WEEE).
This directive sets the framework for returning and recycling used
equipment and is valid across the EU. When returning your used
device, please use the return and collection systems available to
you. Further information can be found at www.fujitsu-
siemens.com/recycling.
Details regarding the return and recycling of devices and consumables within
Europe can also be found in the “Returning used devices” manual, via your local
Fujitsu Siemens Computers branch or from our recycling center in Paderborn:
Fujitsu Siemens Computers
Recycling Center
D-33106 Paderborn
Tel. +49 5251 8 18010
Fax +49 5251 8 18015
RX600 S4 Operating manual 35
4 Hardware installation
V CAUTION!
● Follow the safety instructions in the chapter “Important information”
on page 23.
● Do not expose the server to extreme environmental conditions (see
“Ambient conditions” on page 19). Protect the server from dust,
humidity and heat.
● Make sure that the server is acclimatized for the time indicated in this
table before putting it into operation.
Temperature difference (°C) Minimum acclimatization time
(hours)
53
10 5
15 7
20 8
25 9
30 10
Table 1: Acclimatization time
In table “Acclimatization time”, the temperature difference refers to
the difference between the operating environment temperature and
the temperature to which the server was exposed previously (outside,
transport or storage temperature).
RX600 S4 Operating manual 37
Unpacking the server Hardware installation
4.1 Unpacking the server
V CAUTION!
Follow the safety instructions in chapter “Important information” on
page 23.
The server must always be lifted or carried by at least two people.
Do not unpack the server until it is at its installation location.
Ê Transport the server to the place where you want to set it up.
Ê Unpack all individual parts.
Keep the original packaging in case you want to transport the server again.
Ê Check the delivery for any damage during transport.
Ê Check whether the items delivered match the details on the delivery note.
The product name and serial number of the product can be found on the identification rating plate.
Ê Notify your supplier immediately should you discover that the items delivered
do not correspond to the delivery note.
38 Operating manual RX600 S4
Hardware installation Rack installation/removal of server
4.2 Rack installation/removal of server
V CAUTION!
● Follow the safety instructions and the rack installation instructions in
chapter “Important information” on page 23.
● At least two people are needed to position the server into/out of the
rack.
● The rack may tip over if more than one unit is removed at the same
time.
Rack requirements
The rack systems from Fujitsu Siemens Computers (PRIMECENTER Rack,
DataCenter Rack) ideally support installation of PRIMERGY server systems.
Installation in the currently standard rack systems of various manufacturers (3rd
party rack) is possible in so far as they support the
EIA-310-D standard for 19 inch racks.
I The Classic Rack is not supported for the PRIMERGY RX600 S4.
To accommodate the ventilation concept and ensure proper ventilation, any
unused areas in the rack must be sealed using dummy covers.
The power is supplied via the multiple socket outlets fitted in the rack.
The main features of the rack systems from Fujitsu Siemens Computers are as
follows:
PRIMECENTER Rack
– In connection with so-called assembly brackets frontally bolted telescopic
rails or sliding rails.
Two of these assembly brackets and/or the sliding rails are provided with a
linear alignment possibility to ensure also an adjustment to different rack
depths.
– Enhanced cable management in the lateral rack area.
RX600 S4 Operating manual 39
Rack installation/removal of server Hardware installation
DataCenter Rack
– Directly laterally bolted telescopic rails or sliding rails (except within the rear
left area where a support bracket is used).
– Enhanced cable management in the lateral rack area.
The mounting of the rails in the different racks is described in the next sections.
Installation of the cable management is described in detail in the Technical
Manual for the respective rack.
For rack systems from other manufacturers:
3rd party rack
Certain general conditions must be met:
– Installation dimensions (see also figure 2 on page 41):
1 Front of rack
2 Rear of rack
A Rack depth (comparison PRIMECENTER Rack 940/1000/1100 mm)
B Rack width (comparison PRIMECENTER Rack 700 mm)
C Clearance for 19” installation level
C1 Front 19” installation level
C2 Rear 19” installation level
D Cable routing area (cable area depth) and ventilation
E Space for front panel and ventilation
F Space for right and left support systems
P PRIMERGY rack installation depth
a1 Front left support upright
a2 Front right support upright
b1 Rear left support upright
b2 Rear right support upright
40 Operating manual RX600 S4
Hardware installation Rack installation/removal of server
Figure 2: Mechanical requirements
RX600 S4 Operating manual 41
Rack installation/removal of server Hardware installation
– You must ensure that the safety mechanisms on the server, e.g. stoppers or
retaining systems, are functioning correctly.
– The shape of the rack support uprights must ensure that the rails can be
bolted to the front.
– Frontally bolted telescopic rails or sliding rails.
The rails have a linear alignment feature to ensure that they can be adjusted
to different rack depths.
– No support of the cable management (delivered with the mounting kit).
– Climatic conditions.
An unobstructed air intake in the rack front and air discharge in the rear
cover of the rack are essential for ventilation of the installed server.
In principle the ventilation concept envisages that the necessary cooling is
achieved by the horizontal self-ventilation of the installed devices (air flow
from the front to the rear).
– Power supply:
For installation in 3rd party racks, you must ensure that the appropriate
socket strips are present.
42 Operating manual RX600 S4
Hardware installation Rack installation/removal of server
4.2.1 Mounting in the PRIMECENTER Rack
For mounting the server in the PRIMECENTER Rack the following parts are
necessary:
– a support bracket with two M5x10 screws including centering disks
– a rack mount kit, comprising two telescopic rails (left/right), completely
mounted
– eight M5 centering fasteners (two each for front and rear, two each left and
right)
I You can find general information regarding server installation in the rack
in the technical manual for the PRIMECENTER rack.
When mounting the left telescopic rail in the PRIMECENTER Rack, the supplied
support bracket must first be mounted on the rear left support upright.
2
1
Figure 3: Mounting the support bracket to the left rear support upright
Ê Position the support bracket at the corresponding height on the rear left
support upright (1).
Place the knobs in the corresponding holes.
Ê Fasten the support bracket with the two supplied centering fasteners M5 (2).
RX600 S4 Operating manual 43
Rack installation/removal of server Hardware installation
I For better orientation the height units are marked on the support
uprights.
1
3
2
Figure 4: Mounting the telescopic rails in the PRIMECENTER Rack
Ê Position the left vario support system with mounted telescopic rail (1) on the
support bracket (insert retaining bolts).
Ê Press the left rail together until its front end passes behind the front left
support upright, then release.
Ê Fasten the rod with a screw (M5) to the left front support upright (2).
I No nuts are required to secure the telescopic rails as the fixing holes
on the rails are threaded.
Ê Insert the cage nut at the height of the server's knurled screw in the left front
support upright (3).
Ê Repeat the steps for the right vario support system with mounted telescopic
rail (fastened to the front and rear right support upright).
Ê Insert the cage nut at the height of the server's knurled screw in the right
front support upright.
44 Operating manual RX600 S4
Hardware installation Rack installation/removal of server
Ê Fit the PRIMECENTER Rack cable management as described in the
technical manual for the PRIMECENTER Rack.
Ê Insert the server (see section “Inserting the server” on page 46).
Ê Route the cables once the server has been inserted, as described in the
Technical Manual for the PRIMECENTER Rack.
4.2.2 Installation in the DataCenter Rack
See section “Mounting in the PRIMECENTER Rack” on page 43.
4.2.3 Installation in 3rd party racks
See section “Mounting in the PRIMECENTER Rack” on page 43.
RX600 S4 Operating manual 45
Rack installation/removal of server Hardware installation
4.2.4 Inserting the server
V CAUTION!
At least two people are needed to position the server in the rack.
Ê Fully extend the fitted telescopic rails. They must click into place so that they
can no longer be moved.
Figure 5: Inserting the server
Ê Lift the server onto the right and left system support rod and press it into the
corresponding recesses on the upper edges of both system support rods
with the three screw fasteners right and left.
46 Operating manual RX600 S4
Hardware installation Rack installation/removal of server
The following steps can then be carried out by one person only.
2
1
Figure 6: Unlock telescopic rails and push server into the rack
Ê Press the safety catch (1) on the outside of the two rails upwards in the
direction of the arrow and push the server into the rack in the direction of the
arrow (2).
RX600 S4 Operating manual 47
Rack installation/removal of server Hardware installation
11
Figure 7: Securing the server
Ê Place the cage nuts for fastening the front panel in the corresponding holes
of the front support uprights and fasten the server using two knurled
screws (1).
To remove the server, follow this procedure in reverse. When removing the
server, make sure that the two system support rods (see figure 5 on page 46)
are pulled out parallel right and left.
48 Operating manual RX600 S4
Hardware installation Connecting devices to the server
4.3 Connecting devices to the server
The ports for external devices are on the front and rear of the server. The
additional ports available on your server depend on the expansion cards
installed (e.g. optional SCSI port).
I Some of the devices that can be connected may require special software,
e.g. drivers (see the documentation for the connected device).
12
Figure 8: Ports on the front
On the front of the server are a monitor port (1) and three USB ports (2).
I The two monitor ports on the front and rear (see figure 9 on page 50) can
only be used alternatively; the port not used is automatically deactivated.
RX600 S4 Operating manual 49
Connecting devices to the server Hardware installation
The standard ports on the rear are marked with symbols, and some are colorcoded:
12 3
Figure 9: Ports on the left side of the rear
1 2 x USB ports 3 Serial port COM1 (turquoise)
2 Monitor port (blue)
50 Operating manual RX600 S4
Hardware installation Connecting devices to the server
There are further ports at the rear right, see figure 10.
1
2
Figure 10: Ports on the right side of the rear
1 Service LAN port 3 LAN port 1
2 2 x LAN ports 4 LAN port 2
Ê Connect the data cables to the server and peripherals.
3
4
I Connect keyboard and mouse via USB. There are no separate PS/2
ports for them.
RX600 S4 Operating manual 51
Connecting the server to the mains Hardware installation
4.4 Connecting the server to the mains
The server has two hot-plug power supply units. This ensures redundant power
supply. If one power supply unit is defective, the other then guarantees
unimpaired operation. Each hot-plug power supply unit can be replaced during
operation (see “Replacing the hot-plug power supply unit” on page 82).
V CAUTION!
The server is automatically set to a mains voltage in the range 110 V 240 V. Make sure that your local mains voltage is within this range.
2
2
Figure 11: Connecting the server to the mains
Ê Connect the insulated connectors of the power cables to the server's two
power supply units (1).
Ê Connect the power plugs to the insulated sockets of the mains socket strip
in the rack (2).
1
1
I A phase redundancy in the power supply of the server can be set up as
two hot-plug power supply units are installed.
In this case, each of the power supply units is either connected to two
different phases or to two separate circuits of the internal power supply
network.
52 Operating manual RX600 S4
Hardware installation Connecting the monitor
Figure 12: Securing the power cord in the cable clamp
Ê Secure the power cords in the cable clamps so the insulated connectors
cannot be disconnected from the server accidentally.
4.5 Connecting the monitor
Ê Plug the data cable for the monitor into the monitor port on the server. Alter-
natively, the monitor port at the front or the rear of the server can be used.
Ê Connect the power cable of the monitor to a grounded mains outlet of the in-
house mains and/or into the mains socket strip of the rack.
RX600 S4 Operating manual 53
Notes on connecting/disconnecting cables Hardware installation
4.6 Notes on connecting/disconnecting cables
V CAUTION!
Always read the documentation supplied with the device you wish to
connect.
Never connect, or disconnect cables during a thunderstorm.
Never pull on a cable when disconnecting it. Always take hold of the
cable by the plug.
Follow the sequence described below to connect or disconnect external
devices to or from the server:
Connecting cables
Ê Turn off all power and equipment switches.
Ê Disconnect all power plugs from the grounded shockproof sockets.
Ê Connect all cables to the server and peripherals.
Ê Plug all data communication cables into the utility sockets.
Ê Plug all power cables into the grounded shockproof sockets.
Disconnecting cables
Ê Turn off all power and equipment switches.
Ê Disconnect all power plugs from the grounded shockproof sockets.
Ê Unplug all data communication cables from the utility sockets.
Ê Disconnect the relevant cables from the server and all the peripherals.
54 Operating manual RX600 S4
5 Starting up and operation
V CAUTION!
Follow the safety instructions in chapter “Important information” on
page 23.
5.1 Controls and indicators
5.1.1 Front of server
123 4567
891011
Figure 13: Front - detailed view: port and control panel
1 Monitor port 7 ID indicator
2 3 x USB ports 8 ID button
3 Hard disk activity indicator 9 On/Off button
4 2 x LAN activity indicator 10 Reset button
5 CSS/Global Error indicator 11 NMI button
6 Power-on indicator
RX600 S4 Operating manual 55
Controls and indicators Starting up and operation
123 45 6
Figure 14: Front - overall view
1 ServerView Local Service Display 4 Hard disk drive indicators
2 CD/DVD drive activity indicator 5 Accessible drive (optional)
3 Fan indicator 6 Fan indicator
5.1.1.1 Controls
NMI NMI button
I Do not press! The NMI button may only be used by service
personnel.
/ / Reset button
Pressing the reset button reboots the system.
On/Off button
When the system is switched off, it can be switched on again by
pressing the On/Off button. When the system is operating, pressing
the On/Off button will switch off the system.
I The On/Off button does not disconnect the server from the
mains voltage. To disconnect from the mains completely,
remove the power plug(s).
56 Operating manual RX600 S4
Starting up and operation Controls and indicators
ID ID button
Lights up (blue) on the front and on the rear of the server when the
ID button is pressed. The two ID indicators are synchronized.
5.1.1.2 Indicators on the control panel
Hard disk activity indicator (green/orange)
Lights up or flashes green if one of the SAS hard disk drives
controlled by the SAS Controller is being accessed.
Lights up or flashes orange if an error or another event has
occurred (see “Indicators on the HDD modules” on page 60).
LAN activity indicator (green) for the LAN ports 1 and 2 at the rear
Flashes during a LAN transfer.
I The display is synchronous with the LAN indicators on the
rear of the server (see “LAN indicators” on page 62).
RX600 S4 Operating manual 57
Controls and indicators Starting up and operation
CSS CSS/Global Error indicator (yellow/orange)
Generally, the three possible states of this indicator have the
following meanings:
!
– Does not light up when the system is OK.
– If the event is still acute after a power failure, the indicator is
activated after the restart.
– Lights up when a prefailure event was detected. The indicator
also lights up in standby mode.
– Flashes when an error was detected. The indicator also
flashes in standby mode.
For more details on the indicated errors, you can consult the
System Event Log (SEL), the ServerView Local Service Display,
ServerView S2 or the ServerView Remote Management via
iRMC's own Web server.
Depending on the color, the states „light up“ and „flash“ have the
following meanings:
–CSS (yellow)
Lights up yellow if a prefailure event was detected for a CSS
component.
Flashes yellow if an error was detected that you can fix
yourself with the CSS concept (see “Customer Self Service
(CSS)” on page 9).
– Global Error (orange)
Lights up orange if a prefailure event was detected for a nonCSS component.
Flashes orange if an error was detected for a service incident.
– CSS/Global Error (yellow/orange)
Lights up and/or flashes alternately yellow and/or orange
if several prefailure events and/or errors were detected at the
same time (see above).
58 Operating manual RX600 S4
Starting up and operation Controls and indicators
Power-on indicator (green/orange)
Lights up green when the server is switched on and ready.
Flashes green when the server is switched on and is in sleep
mode (ACPI state S1).
Lights up orange when the server is switched off (ACPI state S5).
Does not light when the server is switched off.
ID ID indicator (blue)
Lights up blue when the system has been selected by pressing
the ID button. To deactivate, press the button again.
The ID indicator can also be activated via ServerView S2 and its
status reported to ServerView S2.
5.1.1.3 Indicators on the accessible drives/components
CD/DVD drive activity indicator
Lights up green when the storage medium is being accessed.
ServerView Local Service Display
You can use the slot mechanism to pull out the ServerView Local Service
Display from the server housing and read the information. Press the front of the
module to release the lock.
You can also pivot the ServerView Local Service Display down by an angle of
120° from its normal position. This makes reading easier when the server is
located very high in the rack.
Further information on using the ServerView Local Service Display is provided
in the "LocalView" manual.
RX600 S4 Operating manual 59
Controls and indicators Starting up and operation
5.1.1.4 Indicators on the HDD modules
1
2
Figure 15: Indicators on an HDD module
1 HDD BUSY (green)
– Lights up: HDD in active phase
– Does not light: HDD inactive (drive inactive)
2 HDD FAULT (orange)
– Does not light: no HDD error
– Lights up: HDD Faulty or Rebuild Stopped (drive defective/needs
replacing, a rebuild process was stopped or the HDD module is not
correctly inserted)
– Slow flashing: HDD Rebuild (the data is being restored after changing
a drive)
– Fast flashing: HDD Identify
– Four fast blinks/pause: HDD Predicted Fault (probable drive error)
– Two fast flashes/pause: HDD Hot Spare (hot-spare drive active) The
corresponding drive has failed).
If a hard disk drive continuously indicates an error, the drive should be replaced
as soon as possible. This can be done during operation (see “Hot-plug hard disk
drives” on page 89).
60 Operating manual RX600 S4
Starting up and operation Controls and indicators
5.1.1.5 Indicator on the fan modules
1
Figure 16: Fan status indicator (right fan module)
The server has two fan modules each with two hot-plug system fans. The fan
status indicator (1) visible at the front relates to both fans in a module.
Fan indicator Meaning
does not light Both fans in that fan module are OK.
lights orange At least one fan is defective. That fan module has to be
replaced (see “Replacing hot-plug CPU fans” on page 84).
RX600 S4 Operating manual 61
Controls and indicators Starting up and operation
5.1.2 Rear of server
5.1.2.1 LAN indicators
1
2
3
4
3
4
Figure 17: LAN indicators (rear right)
1 LAN activity indicator (service LAN)
4
3
3
4
Lights up green if a LAN connection exists.
Does not light up if no LAN connection exists.
Flashes green when a LAN transfer is in progress.
2 LAN transfer rate indicator (service LAN)
Lights up green for a LAN transfer rate of 100 Mbps.
Does not light up for a LAN transfer rate of 10 Mbps.
3 LAN activity indicator (standard LAN)
Lights up green if a LAN connection exists.
Does not light up if no LAN connection exists.
Flashes green when a LAN transfer is in progress.
4 LAN transfer rate indicator (standard LAN)
Lights yellow for a LAN transfer rate of 1 Gbps.
Lights up green for a LAN transfer rate of 100 Mbps.
Does not light up for a LAN transfer rate of 10 Mbps.
62 Operating manual RX600 S4
Starting up and operation Controls and indicators
I The LAN activity indicators are synchronous with the LAN indicators on
the front of the server (see “Indicators on the control panel” on page 57).
5.1.2.2 CSS indicator
1
Figure 18: CSS indicator (rear right)
1 CSS indicator (yellow)
Does not light up when the system is OK. No service incident or critical
event has occurred.
Flashes yellow if an error occurred that you can fix yourself with the CSS
concept (see “Customer Self Service (CSS)” on page 9). For more details
on the error, you can consult the ServerView Local Service Display or
ServerView S2.
Lights up yellow if a prefailure event was detected for a CSS component.
Details of the event can be found in the System Event Log or using
ServerView. The indicator also lights up in standby mode.
If the event is still acute after a power failure, the indicator is activated after
the restart.
RX600 S4 Operating manual 63
Controls and indicators Starting up and operation
5.1.2.3 Global Error indicator
1
Figure 19: Global Error indicator (rear right)
1 Global Error indicator (orange)
Does not light up when the system is OK. No service incident or critical
event has occurred.
Flashes orange when a critical event has occurred. Details of the event can
be found in the BIOS Setup, in the System Event Log or using ServerView.
The indicator also flashes in standby mode.
Lights up orange if a prefailure event was detected for a non-CSS
component. Details of the event can be found in the System Event Log or
using ServerView. The indicator also lights up in standby mode.
If the event is still acute after a power failure, the indicator is activated after
the restart.
64 Operating manual RX600 S4
Starting up and operation Controls and indicators
5.1.2.4 ID indicator and ID button
1
2
Figure 20: ID indicator and ID button (rear right)
1 ID indicator (blue)
Lights up blue when the system has been selected by pressing the ID
button (2). To deactivate, press the button again.
The ID indicator can also be activated via ServerView and its status
reported to ServerView.
2 ID button
Lights up synchronously on the front and rear of the server when the ID
button is pressed.
RX600 S4 Operating manual 65
Controls and indicators Starting up and operation
5.1.2.5 Indicators on the hot-plug power supply units
1
2
3
Figure 21: Indicators on the power supply units (right power supply unit)
1 Switch-on indicator (green)
Lights up when the server is switched on.
2 Fault indicator (orange)
Lights up if there is a fault in the power supply unit.
3 Power indicator (green)
Lights up if network connection has been established.
In normal server operation, LED 1 and 3 light up permanently, LED 2 does not
light up. As soon as LED 2 indicates a fault by lighting up, the affected power
supply unit should be replaced as soon as possible. This can be done during
operation (see “Replacing the hot-plug power supply unit” on page 82).
66 Operating manual RX600 S4
Starting up and operation Switching the server on and off
5.2 Switching the server on and off
V CAUTION!
It nothing appears on the screen but flickering stripes after switching on
the server, switch the server off immediately (see chapter “Trouble-
shooting and tips” on page 75).
The On/Off button does not disconnect the server from the mains. To
completely disconnect it from the mains voltage, remove the power plugs
from the sockets.
Switching the server on
The power-on indicator at the front does not light up (item 6 in figure 13 on
page 55). The power indicator on the power supply units lights up if the server
is connected to the mains (item 3 in figure 21 on page 66).
– Starting up for the first time:
Ê Press the On/Off button (item 9 in figure 13 on page 55).
Power-on indicator lights up green.
Ê Insert ServerStart disc 1 in the DVD drive.
Ê Follow the on-screen instructions (see also section “Configuration with
ServerStart” on page 70 or section “Configuration without ServerStart”
on page 71).
– System already installed:
Ê Press the On/Off button (item 9 in figure 13 on page 55).
Power-on indicator lights up green.
The server is switched on, performs a system test and boots the
operating system.
RX600 S4 Operating manual 67
Switching the server on and off Starting up and operation
Switching the server off
The power-on indicator lights up green (item 6 in figure 13 on page 55).
Ê Shut down the operating system properly.
The server is switched off automatically and goes into standby mode. The
power-on indicator lights up orange.
I If the operating system does not switch the server off automatically, press
the On/Off button for at least four seconds and/or send a corresponding
control signal.
Other On/Off options
Besides the On/Off button, the server can be switched ON and OFF in the
following ways:
– Specified switch-on time/switch-off time
The server is switched ON or OFF at a time specified in the ServerView
program
– Ring Indicator
The server is switched on by an internal or external modem.
– Wake On LAN (WOL)
The server is switched on by a command via the LAN (Magic Packet).
– After power failure
The server automatically reboots following a power failure (depending of the
settings in the BIOS).
– Power button override
The server can be switched off immediately by pressing and holding the
On/Off button (approx. 4-5 sec.).
V CAUTION!
There is a risk that data may be lost.
– IPMI
The server is switched on from an IPMI console (via the COM1 serial
interface or the RJ45 LAN interface).
68 Operating manual RX600 S4
Starting up and operation Configuring the server
5.3 Configuring the server
This section contains information about configuring the server and installing the
operating system.
I Make sure that the energy saving functions are disabled in the BIOS
Setup during server operation.
5.3.1 Configuring onboard SAS RAID controller
You can configure the RAID either before or during ServerStart. Using ServerStart is recommended.
The onboard SAS RAID controllers are configured either with the WEBBIOS
Configuration Utility (call with CTRL-H during BIOS POST) or with the ServerStart disc 1 using ServerViewRAID.
More information can be found in the controller documentation on the ServerBooks DVD under “Controllers”.
I Descriptions of operating systems not covered in the RAID controller
manual are provided in the corresponding readme files on the driver
CDs.
RX600 S4 Operating manual 69
Configuring the server Starting up and operation
5.3.2 Configuration with ServerStart
The ServerStart disc 1 supplied allows you to conveniently configure the server
and install the operating system. Menu-guided configuration includes server
configuration with the SCU and RAID controller configuration with ServerViewRAID.
The ServerStart advantages
– Automatic configuration of your server’s hardware and disk arrays.
– Installation assistance for all leading server operating systems.
– Creation of configuration files for unattended installation of several
PRIMERGY servers with identical hardware configurations.
– Installation of drivers and additional software.
I The software that can be installed depends on your server’s hardware
configuration. This configuration is detected automatically.
I Descriptions of operating systems not covered in the RAID controller
manual are provided in the corresponding readme files on the driver
CDs.
To find out how to operate ServerStart and for further information, refer to the
associated manual.
If you are using ServerStart, you can skip the following section on how to
configure the server and install the operating system. Continue from section
“Cleaning the server” on page 71.
70 Operating manual RX600 S4
Starting up and operation Cleaning the server
5.3.3 Configuration without ServerStart
Configuring onboard SAS RAID controller
Configure the controller as described in section “Configuring onboard SAS
RAID controller” on page 69.
Installing the operating system
Ê Insert the CD for the operating system you want to install.
Ê Reboot the server.
Ê Follow the instructions on screen and in the manual for the operating
system.
If your server is equipped with a RAID controller, please read how to install the
desired operating system in the related manual.
5.4 Cleaning the server
V CAUTION!
Switch the server off and disconnect the power plugs from the grounded
shockproof sockets.
Do not clean any interior parts yourself; leave this job to a service
technician.
Do not use any cleaning agents that contain abrasives or may corrode
plastic.
Ensure that no liquid enters the system. Ensure that the ventilation areas
of the server and the monitor are clear.
Clean the keyboard and the mouse with a disinfecting cloth.
Wipe the server and monitor casing with a dry cloth. If particularly dirty, use a
cloth that has been moistened in a mild domestic detergent and then carefully
wrung out.
RX600 S4 Operating manual 71
6 Property and data protection
6.1 Mechanical access protection
The lockable rack door protects the server against unauthorized access.
6.2 BIOS Setup security functions
The Security menu in BIOS Setup offers various options for protecting your data
from unauthorized access. For example, you can assign passwords for users
and administrators. By combining these options you can achieve optimum
protection for your system.
I A detailed description of the Security menu and how to assign passwords
can be found in the BIOS Setup documentation of the system board
D2244 on the PRIMERGY ServerBooks DVD.
RX600 S4 Operating manual 73
7 Troubleshooting and tips
V CAUTION!
Follow the safety instructions in the “Safety notes and other important
information” manual and in chapter “Important information” on page 23.
If a fault occurs, attempt to resolve it using the measures described:
– in this chapter,
– in the documentation for the connected devices,
– in the help systems of the software used.
If you fail to correct the problem, proceed as follows:
Ê Make a list of the steps performed and the circumstances that led to the fault.
Also make a list of any error messages that were displayed.
Ê Switch off the server.
Ê Contact our customer service team.
7.1 Power-on indicator remains unlit
The power-on indicator remains dark after you switch on your device.
Power cable incorrectly connected
Ê Make sure that the power cable(s) is/are correctly connected to the server
and the grounded socket(s).
Power supply overloaded
Ê Disconnect the server power plug(s) from the power socket(s).
Ê Wait a few seconds before you plug it/them into the grounded socket(s)
again.
Ê Switch on your server.
RX600 S4 Operating manual 75
Server switches itself off Troubleshooting and tips
7.2 Server switches itself off
Server Management has detected an error
Ê Check the error list or the ErrorLog file in the ServerView program, and
attempt to eliminate the error.
7.3 Screen remains blank
Monitor is switched off
Ê Switch on your monitor.
Screen has gone blank
Ê Press any key on the keyboard.
or
Ê Deactivate screen saver. Enter the appropriate password.
Brightness control is set to dark
Ê Set the brightness control on the monitor to light. For detailed information,
refer to the operating manual supplied with your monitor.
Power cable or monitor cable not connected
Ê Switch off the monitor and the server.
Ê Check whether the power cable is properly connected to the monitor and to
the grounded socket.
Ê Check whether the monitor cable is properly connected to the server and
monitor (if it is plugged in with a connector). If a separate graphics card is
installed in the server, then the monitor cable must be connected to the
graphics card.
Ê Switch on the monitor and the server.
76 Operating manual RX600 S4
Troubleshooting and tips Flickering stripes on monitor screen
7.4 Flickering stripes on monitor screen
V CAUTION!
Switch off the server immediately. Risk of damaging the server.
Monitor does not support the set horizontal frequency
Ê Find out which horizontal frequency your monitor screen supports. You will
find the horizontal frequency (also known as line frequency or horizontal
deflection frequency) in the documentation for your monitor.
Ê Refer to the documentation for your operating system or the software for the
screen controller for details of how to set the correct horizontal frequency for
your monitor, and follow the procedure accordingly.
7.5 No screen display or display drifts
The wrong horizontal frequency or resolution has been selected for the
monitor or for the application program.
Ê Find out which horizontal frequency your monitor screen supports. You will
find the horizontal frequency (also known as line frequency or horizontal
deflection frequency) in the documentation for your monitor.
Ê Refer to the documentation for your operating system or the software for the
screen controller for details of how to set the correct horizontal frequency for
your monitor, and follow the procedure accordingly.
RX600 S4 Operating manual 77
Incorrect date and time Troubleshooting and tips
7.6 Incorrect date and time
Ê Set the date and time in the operating system or in the BIOS Setup under
the Main menu, using System Date and System Time respectively.
I Note that the operating system may affect the system time. For example,
the operating system time may deviate from the system time under Linux,
and would overwrite the system time in the default setting on shutdown.
If the date and time are still wrong after the server has been switched off and
back on again, replace the lithium battery (for a description refer to the Technical
Manual for the D2244 system board) or contact our customer service team.
7.7 Drives reported as “dead” when starting system
RAID controller configuration incorrect
Ê Check and correct the settings for the drives using the RAID controller utility.
Further information is provided in the manual for the RAID controller.
78 Operating manual RX600 S4
Troubleshooting and tips Added drive reported as defective
7.8 Added drive reported as defective
RAID controller is not configured for this drive
The drive was probably installed when the system was switched off.
Ê Reconfigure the RAID controller for the drive using the corresponding utility.
Information is provided in the documentation for the RAID controller.
or
Ê Remove and reinstall the drive while the system is switched ON.
If the hard disk drive continues to be shown as defective, then replace it (see
“Hot-plug hard disk drives” on page 89).
7.9 Error message on screen
The meaning of the error message is explained in the manual for the BIOS
Setup and in the documentation for the relevant components and programs on
the PRIMERGY ServerBooks DVD.
RX600 S4 Operating manual 79
8 CSS components
This chapter describes how to handle CSS components and how to identify
defective CSS components and replace them yourself.
I Further information on the CSS concept is provided in the “Customer Self
Service (CSS)” manual on the ServerBooks DVD.
Upgrades, updates and replacement of non-CSS components are
described in the “Options Guide” or in the service supplement and may
only be performed by authorized specialist personnel.
V CAUTION!
Follow the safety instructions in the chapter “Important information” on
page 23.
RX600 S4 Operating manual 81
Hot-plug components CSS components
8.1 Hot-plug components
This section describes how to handle the hot-plug components and/or how to
modify your server hardware (e.g. adding/replacing hot-plug power supply units
or hot-plug HDD modules).
The hot-plug procedure increases the availability of system operation and
guarantees a high degree of data integrity and failsafe performance.
8.1.1 Replacing the hot-plug power supply unit
The server has two hot-plug power supply units. This ensures redundant power
supply. If one power supply unit fails, the other unit ensures operation can
continue uninterrupted. The defective power supply unit can be replaced online.
V CAUTION!
When replacing a non-defective hot-plug power supply unit in a nonredundant configuration (only one power supply unit), the server must
be switched off first.
82 Operating manual RX600 S4
CSS components Hot-plug components
1
2
3
Figure 22: Unlocking and removing the power supply unit
Ê Remove the cable of the defective power supply unit.
Ê Briefly press the green point (1).
This releases the locking lever.
Ê Rotate the locking lever in the direction of the arrow (2).
Ê Completely remove the defective power supply unit at the locking lever from
the slot (3).
V CAUTION!
Never leave the slot for the power supply unit empty for more than two
minutes during operation. Otherwise, excessive temperatures could
damage system components.
Ê Slide the new power supply unit with open locking lever into the empty slot
until it clicks into place.
Ê Press the locking lever on the housing until it engages.
I Make sure that the new power supply unit engages correctly in the
mounting location and is locked in position.
This is the only way to prevent the power supply unit from sliding out
of its mountings and being damaged during transportation.
Ê Connect the newly installed power supply unit.
RX600 S4 Operating manual 83
Hot-plug components CSS components
If everything is functioning correctly, the green LEDs 1 and 3 (see “Indicators
on the hot-plug power supply units” on page 66) at the rear of the power
supply unit will now light up.
8.1.2 Replacing hot-plug CPU fans
The server has two pairs of redundant hot-plug CPU fan (2+2). Each pair of fans
is mounted in a fan module that is accessible from the front of the server.
A possible fan fault is reported by the CSS indicator lighting up on the front and
rear of the server or displayed on the ServerView Local Service Display (for
more information about the behavior of these indicators, see chapter “Starting
up and operation” on page 55 and the "Customer Self Service (CSS)" manual
on the ServerBooks DVD).
A CPU fan failure is reported by the CSS indicator flashing on the front and rear
of the server or displayed on the ServerView Local Service Display (for more
information about the behavior of these indicators, see chapter “Starting up and
operation” on page 55 and the "Customer Self Service (CSS)" manual on the
ServerBooks DVD). The fan failure is also reported by the indicator on the fan
module in question (see “Indicator on the fan modules” on page 61).
84 Operating manual RX600 S4
CSS components Hot-plug components
1
3
2
Figure 23: Unlocking fan module left and removing it
Ê Briefly press the green point (1).
The handle (2) is released.
Use the handle to pull out the defective fan module.
V CAUTION!
Never leave the fan module slot empty for more than two minutes
during operation. Otherwise, excessive temperatures could damage
system components.
Ê Insert the new fan module in the empty slot and press the handle until it
engages.
The new fan module is tested by Server Management. The LED (3) then
either does not light at all (fan is OK) or lights up orange (fan is not OK).
RX600 S4 Operating manual 85
Hot-plug components CSS components
8.1.3 Replacing hot-plug main memory fans
V CAUTION!
The actions described in this section may only be performed by
personnel with the appropriate technical training. Any unauthorized
openings and improper repairs could expose the user to risks
(electric shock, fire hazards) and could also damage the equipment.
Please observe the safety information in chapter “Important infor-
mation” on page 23.
The server has two redundant fan units (1+1). Each fan unit consists of two
separate hot-plug fans. The fans are only accessible when the server is open.
A possible fan fault is reported by the CSS indicator lighting up on the front and
rear of the server or displayed on the ServerView Local Service Display (for
more information about the behavior of these indicators, see chapter “Starting
up and operation” on page 55 and the "Customer Self Service (CSS)" manual
on the ServerBooks DVD).
A fan failure is reported by the CSS indicator flashing on the front and rear of
the server or displayed on the ServerView Local Service Display (for more information about the behavior of these indicators, see chapter “Starting up and
operation” on page 55 and the "Customer Self Service (CSS)" manual on the
ServerBooks DVD).
When the server is open, the faulty fan can be identified by the corresponding
LED (see figure 24 on page 87) and can be replaced while the system is
running.
86 Operating manual RX600 S4
CSS components Hot-plug components
Ê Open the housing cover (see “Opening/closing the housing” on page 114).
1
1
Figure 24: Diagnostic LED on main memory fan
Ê Use the diagnostic LED (1) to identify the faulty fan.
The diagnostic LED lights up/flashes orange.
2
1
1
1
1
Figure 25: Exchanging the fan
Ê Take hold of the fan by the green touch points (1) and lift it out of the
housing (2).
Ê Set the fan down on the outside of the server.
RX600 S4 Operating manual 87
Hot-plug components CSS components
V CAUTION!
Never set a removed/defective fan down inside the server. Risk of
short circuit!
Mounting is performed in the reverse order.
I The new fans are measured with explicit commands in Server
Management. Depending on the result, the corresponding LED is set to
orange (fan is not in order).
Ê Close the housing cover (see “Opening/closing the housing” on page 114).
88 Operating manual RX600 S4
CSS components Hot-plug components
8.1.4 Hot-plug hard disk drives
Up to eight hot-plug hard disk drives can be installed in the PRIMERGY
RX600 S4 Server.
The hard disk drives which can be ordered for the PRIMERGY RX600 S4 are
supplied already mounted in an installation frame so that defective hard disk
drives can be replaced and new drives can be added during operation. The hard
disk drive and installation frame together make up the HDD module.
V CAUTION!
● The hard disk drive must not be removed from the installation frame
by anyone except a service technician.
● The HDD modules (drives) must all be marked clearly so that they
can be put back in their original places after an upgrade. If this is not
done, existing data can be lost.
● The hot-plug function is only possible in conjunction with a corre-
sponding RAID configuration.
Further information about the RAID configuration or RAID level can
be found in the RAID controller documentation.
RX600 S4 Operating manual 89
Hot-plug components CSS components
8.1.4.1 Handling hard disk drives and HDD modules
Hard disk drives incorporated in the HDD modules are highly sensitive electromagnetic devices and must be handled with great care. Incorrect handling can
cause partial or total failure of the hard disk drives. These failures can result in
data errors and to a loss of data or to total corruption of the hard disk drive.
Observe the following rules to prevent such problems occurring:
● Only store and transport HDD modules within the limits stipulated in the
specification.
● When transporting HDD modules (even over short distances), always use
the original packaging (ESD label).
● Never expose HDD modules to a temperature shock. Avoid the formation of
condensation inside and on the outside of the hard disk drive.
V CAUTION!
The HDD module must be acclimatized in its operating environment
for an acclimatization time before it is started up for the first time.
Temperature difference (°C)
(operating environment/
Minimum acclimatization time
(hours)
outside)
53
10 5
15 7
20 8
25 9
30 10
Table 2: Acclimatization times for HDD modules
● Always set the HDD module down carefully, with the large surface facing
downwards to prevent it from tipping over.
90 Operating manual RX600 S4
CSS components Hot-plug components
8.1.4.2 Removing/installing the dummy module
Free slots are provided with dummy modules. Remove the dummy module
before installing an additional HDD module.
1
2
1
Figure 26: Removing the dummy module
Ê Press both tabs on the dummy module together until the locking mechanism
disengages (1).
Ê Pull the dummy module out of the bay (2).
To install a dummy module, follow the same procedure in reverse order.
V CAUTION!
Store the dummy module in a safe place. If you have removed a HDD
module and do not install a new one in its place, put the dummy module
back in its place for cooling, to comply with EMC regulations (regulations
regarding electromagnetic compatibility), and for protection against fire.
Ensure that the dummy module engages correctly in the bay.
RX600 S4 Operating manual 91
Hot-plug components CSS components
8.1.4.3 Installing/removing the HDD module
Unlocking the HDD module
1
2
Figure 27: Unlocking the HDD module
Ê Release the locking mechanism by pressing the locking button (1).
Ê Push the handle of the HDD module fully in the direction of the arrow (2).
The HDD module is now unlocked.
92 Operating manual RX600 S4
CSS components Hot-plug components
Installing the HDD module
Ê Unlock the HDD module as described in section “Unlocking the HDD
module” on page 92.
Figure 28: Pushing the HDD module into the slot
Ê Carefully push the HDD module into the empty slot until it stops.
RX600 S4 Operating manual 93
Hot-plug components CSS components
Figure 29: Lock the HDD module
Ê Push the handle completely until the locking mechanism engages.
94 Operating manual RX600 S4
CSS components Hot-plug components
Removing the HDD module
V CAUTION!
● Only remove an HDD module during operation if the drive is not
currently being accessed. Observe the control LEDs for the corresponding HDD modules (see “Indicators on the HDD modules” on
page 60).
● Under no circumstances should you remove a HDD module while the
system is in operation if you are not sure that the hard disk drive is
operated by a RAID controller and belongs to a disk array that is
operating in RAID level 1, 5, 10 or 50.
A HDD module can only be replaced during operation in conjunction
with a corresponding RAID configuration.
● All HDD modules (drives) must be uniquely identified so that they can
be reinstalled in their original mounting locations later. If this is not
done, existing data can be lost.
If you want to remove a HDD module during operation, proceed as follows:
Ê If you want to remove a HDD module that is not defective, the drive must be
first set to "Offline" via the software (RAID controller configuration software).
Ê Unlock the HDD module as described in section “Unlocking the HDD
module” on page 92.
Ê Pull the HDD module out a few centimeters.
Ê Wait for at least 60 seconds.
I This period is necessary for the RAID controller to recognize that a
HDD module has been removed and for the hard disk drive to come
to a stop.
Ê Pull the HDD module out completely.
RX600 S4 Operating manual 95
Hot-plug components CSS components
Ê Install the new HDD module, as described in “Unlocking the HDD module”
on page 92 and “Installing the HDD module” on page 93.
V CAUTION!
If you have removed a HDD module and do not install a new one in
its place, put the dummy module back in its place for cooling, to
comply with EMC regulations (regulations regarding electromagnetic
compatibility), and for protection against fire. Ensure that the dummy
module engages correctly in the bay.
96 Operating manual RX600 S4
CSS components Hot-plug components
8.1.5 Hot-plug expansion cards
V CAUTION!
The actions described in this section may only be performed by
personnel with the appropriate technical training. Any unauthorized
openings and improper repairs could expose the user to risks
(electric shock, fire hazards) and could also damage the equipment.
Please observe the safety information in chapter “Important infor-
mation” on page 23.
V CAUTION!
Each slot in the server must have either an expansion card or a dummy
module. A dummy module comprises a retaining plate with an attached
removal tool.
The following operations are possible during operation:
– Replacement of expansion cards (see “Removing a hot-plug expansion
card” on page 98 and “Installing a hot-plug expansion card” on page 103)
I Only expansion cards of the same type and with the same settings
may be exchanged. If the expansion cards do not match, the new
expansion card will not be commissioned.
– Adding more expansion cards (see “Removing a dummy module” on
page 102 and “Installing a hot-plug expansion card” on page 103)
Ê You should read the accompanying documentation supplied with the
expansion card beforehand.
RX600 S4 Operating manual 97
Hot-plug components CSS components
1
2
3
4
5
6
7
Figure 30: Slots with and without hot-plug functionality
I Slots 1 - 4 (green locks) are hot-plug slots.
Slots 5 - 7 (blue locks) are slots without hot-plug functionality. The server
must be switched off before expansion cards are replaced or inserted in
these slots. The procedure is described in the Options Guide / Service
Supplement.
8.1.5.1 Removing a hot-plug expansion card
Ê Open the housing cover (see “Opening/closing the housing” on page 114).
Ê If required by the operating system (e.g. Windows 2000), start the PCI hot-
plug software. You will find information about this in the readme file on the
ServerStart Disc 1.
98 Operating manual RX600 S4
CSS components Hot-plug components
2
1
3
Figure 31: Deactivating, unlocking and removing the board
Ê Deactivate the expansion card using either the relevant PCI hot-plug
software or by pressing the optical waveguide (1).
Ê Wait until the optical waveguide (1) no longer lights up.
The slot is now zero potential.
Ê If necessary, remove all cables from the expansion card.
Ê Open the expansion card lock by lifting it up (2).
The expansion card is now mechanically unlocked.
Ê Hold the removal tool by the green handle and pull it out of the PCI slot
together with the expansion card (3).
I Do not pull on the expansion card itself.
RX600 S4 Operating manual 99
Hot-plug components CSS components
Removing expansion card from the removal tool
V CAUTION!
When removing the expansion card from the removal tool, pay particular
attention to the engaging hooks that fasten the board to the removal tool
(see figure 32 on page 100). Do not lift them by more than approx. 1 mm,
in other words only as far until the expansion card is released. Otherwise
you could damage the engaging hooks.
1
1
2
Figure 32: Removing the expansion card from the removal tool
Ê Lift the green movable engaging hooks no more than approx. 1 mm (1)
until the expansion card is completely released.
Ê Take the expansion card out (2) and put it aside.
100 Operating manual RX600 S4
Loading...
