Data Sheet FUJITSU Server PRIMERGY RX2540 M5 Rack Server

Data Sheet

FUJITSU Server PRIMERGY RX2540 M5 Rack Server

The data center standard without compromise

FUJITSU Server PRIMERGY will give you the servers
you need to power any workload and changing
business requirements. As business processes
expand so does the need for applications. Each
has its own resource footprint, so you need a way
to optimize your computing to better serve your
users. PRIMERGY systems will help you match your
computing capabilities to your business priorities
with our complete portfolio of expandable
PRIMERGY tower servers for remote and branch

ofces, versatile rack-mount servers as well as
hyper-converged multi-node servers. They convince

by business proven quality with a wide range of

innovations, highest efciency cutting operational

cost and complexity, provide more agility in daily
operations, and integrate seamlessly to let help
you concentrate on core business functions.

FUJITSU Server PRIMERGY RX rack systems are

versatile rack-optimized servers providing best­in-class performance and energy efciency, and

thus form the “standard” in each data center.
PRIMERGY RX servers deliver more than 20 years of

development and production know-how resulting

in extremely low failure rates below market
average, and lead to continuous operations and
outstanding hardware availability.

DDR4 memory technology with up to 3TB and
optionally up to 12x Intel® Optane™ DC Persistent

Memory NV-DIMM modules it boosts application

performance so that it copes with the increasing
data growth and to shorten time to business
results. The modular design of the server offers
excellent expandability with up to 28 disk drives,
high storage density, up to 8 PCIe Gen 3 I/O
expansion slots. A variety of onboard DynamicLoM

options, plus its dual-port embedded LAN meet
future requirements, cost-optimized. The PRIMERGY
RX2540 M5 comes with two redundant hot-plug

power supply units, offering up to 96% energy

efciency. The Cool-safe® Advanced Thermal

Design allows operation in ambient temperatures
of up to 45 °C/104 °F. Having both these features
helps to reduce operational expenses.

PRIMERGY RX2540 M5

The FUJITSU Server PRIMERGY RX2540 M5 sets
higher standards for usability, scalability and cost

efciency. It is a 2U dual-socket rack server ideal

for running enterprise applications, collaboration
and messaging workloads as well as traditional

databases. In addition, it substantially simplies
carrying out infrastructure-related tasks such as

server virtualization and consolidation. As one
of the key innovations, versatile performance is
guaranteed by a new generation of processors.
The PRIMERGY RX2540 M5 can be equipped with
two of the Intel® Xeon® Processor Scalable Family
CPUs with up to 28 cores each. Along with new

Page 1 / 16 http://www.fujitsu.com/emeia/products/computing/servers/primergy/rack/rx2540m5/

Data Sheet FUJITSU Server PRIMERGY RX2540 M5 Rack Server

Features & Benefits

Main Features Benefits

Innovation meets Performance

 Wide choice of different types of Intel® Xeon® Scalable Processor

Family. Each processor offers up to 28 cores, up to 56 threads, 12

memory channels enabling a signicantly higher performance
and efciency. They rely on Intel® UltraPath Interconnect for an

increased data rate between the CPUs. Intel® Optane™ DC persistent
memory is an innovative memory technology that delivers a
unique combination of affordable large capacity and persistence

(non-volatility). It revolutionizes the data center memory-storage

hierarchy of the past and brings massive data sets closer to the CPU
for faster time to insight. In total, up to 7,680 GB main memory in

a mixed mode (non-volatile memory + DDR4 @ 2,933 MT/s) are

available. What’s more is the support for up to 2x GPGPUs for fast
processing.

Enhanced Features for enhanced Computing

 The RX2540 M5 comes with onboard LAN for basic LAN,

DynamicLoM via OCP slot for extended requirements. A mix&match

storage drive bay conguration offers the choice of either up to 8x

3.5-inch HDD/SSD + 1x ODD, 12x 3.5-inch or up to 24x 2.5-inch,
up to 8x PCIe 2.5-inch SSD + an additional rear option of 4x 2.5-

inch drives, complemented by internal M.2 devices for hypervisor
installations. Our power supply units with up to 96% energy

efciency and Fujitsu’s Cool-safe® Advanced Thermal Design for

higher ambient temperatures in the data center are available for
this server.

Foundation for Trust and Security

 Fujitsu ServerView Suite including tools for installation and

deployment, permanent status monitoring and control, free-of­charge BIOS, rmware and selected software updates plus TPM2.0

modules and latest operating system support are a great addition.

Revolutionize data center management

 Fujitsu ServerView Suite is a free-of-charge management software

including tools for installation and deployment, permanent status

monitoring and control as well as BIOS, rmware and selected

software updates. In addition FUJITSU Software Infrastructure

Manager (ISM) provides converged management across multiple
data centers. The new ISM Essential license, available free-of-charge

provides essential server management and converged monitoring
functions.

 Ready for the future and data growth scenarios with the

 The right Ethernet connection for all: Basic via onboard LAN,

 These features ensure lifecycle investment protection while the

 Fujitsu offers comprehensive infrastructure management and

performance of two processors – marking the standard of tomorrow
with an increase in computing power. Several innovations make

this new CPU generation (code-named “Cascade Lake”) even
more powerful than the current-generation Intel® Xeon® Scalable

processors, enabling robust compute capability and increased
memory bandwidth for demanding workloads. Intel® Optane™ DC
persistent memory technology will transform critical data workloads

– from cloud and databases, to in-memory analytics, and content

delivery networks but also for VDI, CAD or future technologies such

as Articial Intelligence of Virtual Reality applications.

extended with DynamicLoM via OCP guarantees the highest

exibility to integrate the server into existing infrastructures –

now and in future without overhauling the existing infrastructure.
Flexible expandability and diverse options for storage devices
permits for the integration of existing and new SSD and HDD as
needed. Less today, more in future – or vice versa. On top of that,
this server is not only “greener”, but also less expensive over time.

Cool-safe® ATD and highly efcient hot-plug power supplies save

energy costs.

comprehensive tools of the Fujitsu ServerView Suite ease the

administrators’ life. Moreover, hardware and software security

features are very important in a fast-paced world, especially

considering cybercrime.

server management solutions which is key to efcient data
center operations. They provides all the functions for exible and
automated 24x7 IT operations and improves end-user productivity

via intelligent and innovative system management solutions. ISM

helps improve data center efciency and overall IT Productivity with
converged infrastructure management, paving the path to software­dened data center.

Page 2 / 16 http://www.fujitsu.com/emeia/products/computing/servers/primergy/rack/rx2540m5/

Data Sheet FUJITSU Server PRIMERGY RX2540 M5 Rack Server

Technical details

PRIMERGY RX2540 M5

Base unit PRIMERGY RX2540

M5 LFF

Housing types Rack Rack Rack Rack Rack
Storage drive architecture 4x 3.5-inch SAS/SATA max. 12x 3.5-inch

Power supply Hot-plug Hot-plug Hot-plug Hot-plug Hot-plug
Product Type Dual Socket Rack

Server

Mainboard

Mainboard type D3384-B
Chipset Intel® C624
Processor quantity and type 1 - 2 x Intel® Xeon® Processor Scalable Family

Intel® Xeon® Bronze Processor Intel® Xeon® Bronze 3204 (6C, 1.90 GHz, TLC: 8.25 MB, Turbo: 1.90 GHz, 9.6 GT/s, Mem bus: 2,133 MHz, 85 W, AVX

Base 1.50 GHz, AVX Turbo 1.50 GHz)

PRIMERGY RX2540
M5 LFF

SAS/SATA/PCIe

Dual Socket Rack
Server

PRIMERGY RX2540
M5 SFF

16x 2.5-inch SAS/SATA/

PCIe

Dual Socket Rack
Server

PRIMERGY RX2540
M5 SFF

8x 2.5-inch SAS/SATA/

PCIe

Dual Socket Rack
Server

PRIMERGY RX2540
M5 SFF

24x 2.5-inch SAS/SATA

Dual Socket Rack
Server

Intel® Xeon® Silver Processor Intel® Xeon® Silver 4208 (8C, 2.10 GHz, TLC: 11 MB, Turbo: 2.50 GHz, 9.6 GT/s, Mem bus: 2,400 MHz, 85 W, AVX Base

1.60 GHz, AVX Turbo 2.00 GHz)

Intel® Xeon® Silver 4210 (10C, 2.20 GHz, TLC: 13.75 MB, Turbo: 2.70 GHz, 9.6 GT/s, Mem bus: 2,400 MHz, 85 W, AVX

Base 1.90 GHz, AVX Turbo 2.30 GHz)

Intel® Xeon® Silver 4214 (12C, 2.20 GHz, TLC: 16.5 MB, Turbo: 2.70 GHz, 9.6 GT/s, Mem bus: 2,400 MHz, 85 W, AVX

Base 1.80 GHz, AVX Turbo 2.40 GHz)

Intel® Xeon® Silver 4214Y (12C, 2.20 GHz, TLC: 16.5 MB, Turbo: 2.70 GHz, 9.6 GT/s, Mem bus: 2,400 MHz, 85 W, AVX

Base 1.80 GHz, AVX Turbo 2.40 GHz)

Intel® Xeon® Silver 4215 (8C, 2.50 GHz, TLC: 11 MB, Turbo: 3.00 GHz, 9.6 GT/s, Mem bus: 2,400 MHz, 85 W, AVX Base

2.00 GHz, AVX Turbo 2.60 GHz)

Intel® Xeon® Silver 4216 (16C, 2.10 GHz, TLC: 22 MB, Turbo: 2.70 GHz, 9.6 GT/s, Mem bus: 2,400 MHz, 100 W, AVX

Base 1.40 GHz, AVX Turbo 2.30 GHz)

Page 3 / 16 http://www.fujitsu.com/emeia/products/computing/servers/primergy/rack/rx2540m5/

Data Sheet FUJITSU Server PRIMERGY RX2540 M5 Rack Server

Intel® Xeon® Gold Processor Intel® Xeon® Gold processor 5215 (10C, 2.50 GHz, up to 3.0 GHz, 10.4 GT/s)

Intel® Xeon® Gold processor 5215L (10C, 2.50 GHz, up to 3.0 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 5215M (10C, 2.50 GHz, up to 3.0 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 5217 (8C, 3.00 GHz, up to 3.4 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 5218 (16C, 2.30 GHz, up to 2.8 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 5218B (16C, 2.30 GHz, up to 2.8 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 5220 (18C, 2.20 GHz, up to 2.7 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 5220S (18C, 2.70 GHz, up to 2.7 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 5222 (4C, 3.80 GHz, up to 3.9 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6209U (20C, 2.10 GHz, up to 2.8 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6210U (20C, 2.50 GHz, up to 3.2 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6212U (24C, 2.40 GHz, up to 3.1 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6222V (20C, 1.80 GHz, up to 2.4 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6226 (12C, 2.70 GHz, up to 3.5 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6230 (20C, 2.10 GHz, up to 2.8 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6230T (20C, 2.10 GHz, up to 2.8 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6234 (8C, 3.30 GHz, up to 4.0 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6238 (22C, 2.10 GHz, up to 2.8 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6238L (22C, 2.10 GHz, up to 3.7 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6238M (22C, 2.10 GHz, up to 3.7 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6240 (18C, 2.60 GHz, up to 3.3 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6240L (18C, 2.60 GHz, up to 3.3 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6240M (18C, 2.60 GHz, up to 3.3 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6240Y (18C, 2.60 GHz, up to 3.3 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6242 (16C, 2.80 GHz, up to 3.5 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6244 (8C, 3.60 GHz, up to 4.3 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6246 (12C, 3.30 GHz, up to 4.1 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6248 (20C, 2.50 GHz, up to 3.2 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6252 (24C, 2.10 GHz, up to 2.8 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6254 (18C, 3.10 GHz, up to 3.9 GHz, 10.4 GT/s)
Intel® Xeon® Gold processor 6262V (24C, 1.90 GHz, up to 2.5 GHz, 10.4 GT/s)

Page 4 / 16 http://www.fujitsu.com/emeia/products/computing/servers/primergy/rack/rx2540m5/

Data Sheet FUJITSU Server PRIMERGY RX2540 M5 Rack Server

Intel® Xeon® Platinum Processor Intel® Xeon® Platinum 8260 (24C, 2.40 GHz, TLC: 35.75 MB, Turbo: 3.10 GHz, 10.4 GT/s, Mem bus: 2,933 MHz, 165 W,

AVX Base 1.90 GHz, AVX Turbo 2.60 GHz)

Intel® Xeon® Platinum 8260L (24C, 2.40 GHz, TLC: 35.75 MB, Turbo: 3.10 GHz, 10.4 GT/s, Mem bus: 2,933 MHz, 165

W, AVX Base 1.90 GHz, AVX Turbo 2.60 GHz)

Intel® Xeon® Platinum 8260M (24C, 2.40 GHz, TLC: 35.75 MB, Turbo: 3.10 GHz, 10.4 GT/s, Mem bus: 2,933 MHz, 165

W, AVX Base 1.90 GHz, AVX Turbo 2.60 GHz)

Intel® Xeon® Platinum 8260Y (24C, 2.40 GHz, TLC: 35.75 MB, Turbo: 3.10 GHz, 10.4 GT/s, Mem bus: 2,933 MHz, 165

W, AVX Base 1.80 GHz, AVX Turbo 2.50 GHz)

Intel® Xeon® Platinum 8268 (24C, 2.90 GHz, TLC: 35.75 MB, Turbo: 3.50 GHz, 10.4 GT/s, Mem bus: 2,933 MHz, 205 W,

AVX Base 2.40 GHz, AVX Turbo 3.00 GHz)

Intel® Xeon® Platinum 8270 (26C, 2.70 GHz, TLC: 35.75 MB, Turbo: 3.40 GHz, 10.4 GT/s, Mem bus: 2,933 MHz, 205 W,

AVX Base 2.20 GHz, AVX Turbo 2.90 GHz)

Intel® Xeon® Platinum 8276 (28C, 2.20 GHz, TLC: 38.5 MB, Turbo: 3.00 GHz, 10.4 GT/s, Mem bus: 2,933 MHz, 165 W,

AVX Base 1.70 GHz, AVX Turbo 2.60 GHz)

Intel® Xeon® Platinum 8276L (28C, 2.20 GHz, TLC: 38.5 MB, Turbo: 3.00 GHz, 10.4 GT/s, Mem bus: 2,933 MHz, 165 W,

AVX Base 1.70 GHz, AVX Turbo 2.60 GHz)

Intel® Xeon® Platinum 8276M (28C, 2.20 GHz, TLC: 38.5 MB, Turbo: 3.00 GHz, 10.4 GT/s, Mem bus: 2,933 MHz, 165

W, AVX Base 1.70 GHz, AVX Turbo 2.60 GHz)

Intel® Xeon® Platinum 8280 (28C, 2.70 GHz, TLC: 38.5 MB, Turbo: 3.30 GHz, 10.4 GT/s, Mem bus: 2,933 MHz, 205 W,

AVX Base 2.20 GHz, AVX Turbo 2.90 GHz)

Intel® Xeon® Platinum 8280L (28C, 2.70 GHz, TLC: 38.5 MB, Turbo: 3.30 GHz, 10.4 GT/s, Mem bus: 2,933 MHz, 205 W,

AVX Base 2.20 GHz, AVX Turbo 2.90 GHz)

Intel® Xeon® Platinum 8280M (28C, 2.70 GHz, TLC: 38.5 MB, Turbo: 3.30 GHz, 10.4 GT/s, Mem bus: 2,933 MHz, 205

W, AVX Base 2.20 GHz, AVX Turbo 2.90 GHz)

Memory slots 24 (12 DIMMs per CPU, 6 channels with 2 slots per channel)
Memory slot type DIMM (DDR4 / DDR-T for non-volatile memory modules)
Memory capacity (min. - max.) 8 GB - 7.5 TB
Memory protection Advanced ECC

Memory Scrubbing
SDDC
Rank sparing memory support
Memory Mirroring support

Memory notes Max. 6 slots populated with DCPMM modules per CPU, please see relevant system congurator for details. Memory

Mirroring Mode with identical modules in both channel pairs of a bank (4 or 6 modules per bank) per CPU. Rank
Sparing Mode with minimum of 2 modules single ranked (1R) or dual ranked (2R) or 1 module quad ranked (4R) per

CPU.

Standard memory modules 8 GB (1 module(s) 8 GB) DDR4, registered, ECC, 2,933 MT/s, PC4-2933, DIMM, 1Rx8

16 GB (1 module(s) 16 GB) DDR4, registered, ECC, 2,933 MT/s, PC4-2933, DIMM, 2Rx8
16 GB (1 module(s) 16 GB) DDR4, registered, ECC, 2,933 MT/s, PC4-2933, DIMM, 1Rx4
32 GB (1 module(s) 32 GB) DDR4, registered, ECC, 2,933 MT/s, PC4-2933, DIMM, 2Rx4
64 GB (1 module(s) 64 GB) DDR4, registered, ECC, 2,933 MT/s, PC4-2933, DIMM, 2Rx4
128 GB (1 module(s) 128 GB) DDR4, registered, ECC, 2,933 MT/s, PC4-2933, LRDIMM, 4Rx4
64 GB (1 module(s) 64 GB) DDR4, registered, ECC, 2,933 MT/s, PC4-2933, LRDIMM, 4Rx4

Standard memory modules (for use in
combination with non-volatile memory
modules)

96 GB (6 module(s) 16 GB) DDR4, registered, ECC, 2,933 MT/s, PC4-2933, DIMM, 1Rx4
64 GB (4 module(s) 16 GB) DDR4, registered, ECC, 2,933 MT/s, PC4-2933, DIMM, 1Rx4
128 GB (8 module(s) 16 GB) DDR4, registered, ECC, 2,933 MT/s, PC4-2933, DIMM, 1Rx4
192 GB (6 module(s) 32 GB) DDR4, registered, ECC, 2,933 MT/s, PC4-2933, DIMM, 2Rx4
128 GB (4 module(s) 32 GB) DDR4, registered, ECC, 2,933 MT/s, PC4-2933, DIMM, 2Rx4
256 GB (8 module(s) 32 GB) DDR4, registered, ECC, 2,933 MT/s, PC4-2933, DIMM, 2Rx4
768 GB (6 module(s) 128 GB) DDR4, registered, ECC, 2,933 MT/s, PC4-2933, LRDIMM, 4Rx4
384 GB (6 module(s) 64 GB) DDR4, registered, ECC, 2,933 MT/s, PC4-2933, LRDIMM, 4Rx4
256 GB (4 module(s) 64 GB) DDR4, registered, ECC, 2,933 MT/s, PC4-2933, LRDIMM, 4Rx4
512 GB (8 module(s) 64 GB) DDR4, registered, ECC, 2,933 MT/s, PC4-2933, LRDIMM, 4Rx4

Page 5 / 16 http://www.fujitsu.com/emeia/products/computing/servers/primergy/rack/rx2540m5/

Data Sheet FUJITSU Server PRIMERGY RX2540 M5 Rack Server

Non-volatile memory modules 256 GB (2 module(s) 128 GB) DDR-T, registered, ECC, 2,666 MT/s, NVM, DCPMM, 1Rx4

512 GB (2 module(s) 256 GB) DDR-T, registered, ECC, 2,666 MT/s, NVM, DCPMM, 2Rx4
512 GB (4 module(s) 128 GB) DDR-T, registered, ECC, 2,666 MT/s, NVM, DCPMM, 1Rx4
1024 GB (4 module(s) 256 GB) DDR-T, registered, ECC, 2,666 MT/s, NVM, DCPMM, 2Rx4
768 GB (6 module(s) 128 GB) DDR-T, registered, ECC, 2,666 MT/s, NVM, DCPMM, 1Rx4
1536 GB (6 module(s) 256 GB) DDR-T, registered, ECC, 2,666 MT/s, NVM, DCPMM, 2Rx4
3072 GB (6 module(s) 512 GB) DDR-T, registered, ECC, 2,666 MT/s, NVM, DCPMM, 4Rx4

Interfaces

USB 3.0 ports 5 x USB 3.0 (2x front, 2x rear, 1x internal) - for base units with max. drives count: 1x USB 2.0 front only
Graphics (15-pin) 2 x VGA (thereof 1x front optional)
Serial 1 (9-pin) 1 x serial RS-232-C optional, usable for iRMC or system or shared
Management LAN (RJ45) 1 x dedicated management LAN port for iRMC S5 (10/100/1000 Mbit/s)

Management LAN trafc can be switched to shared onboard LAN controller port, speed and connector is related to

installed interface card.

Onboard or integrated Controller

RAID controller All hardware storage controller options are described under Components

For dedicated base units front AND rear storage drives may be connected to a single controller. Please see

SystemArchitect for conguration options and restrictions.

SATA Controller Intel® C624, 1 x SATA channel for ODD
LAN Controller Intel® C624

2 x 1 Gbit/s onboard
Optional DynamicLoM OCP adaptors:

4 x 1 Gbit/s Ethernet (RJ45)
2 x 10 Gbit/s Ethernet (RJ45)
2 x 10 Gbit/s SFP+
4 x 10 Gbit/s SFP+
All supported features are described in relevant system congurator.

Remote management controller Integrated Remote Management Controller (iRMC S5, 512 MB attached memory incl. graphics controller)

IPMI 2.0 compatible

GPU / coprocessor GFX/GPU support for dedicated base units. Please see relevant SystemArchitect for details and restrictions.
Onboard controller notes Onboard 8x S-ATA 6Gbit/s RAID Controller (RAID 0,1) for up to 8x S-ATA drives available.
Trusted Platform Module (TPM) Inneon / TPM 1.2 or TPM 2.0 module; TCG compliant (option)

Slots

PCI-Express 3.0 x8 3 x Low prole (2nd processor required for slot 4)
PCI-Express 3.0 x16 3 x Low prole (2nd processor required for slot 5 and 6)
Slot Notes One PCIe Gen3 x8 slot may be occupied with a Modular RAID controller if congured.

Important: 3 PCIe slots are supported with the rst processor. 6 PCIe slots are supported with two processors.
PCIe riser card options can expand number of slots by two (max. 8 in total) and support max. 4 full height slots.
Possible slot length described in relevant system congurator.

Drive bays

Storage drive bays 3.5-inch or 2.5-inch hot-plug SAS/SATA
Accessible drive bays 1 x 5.25/0.4-inch for CD-RW/DVD
Notes accessible drives All possible options described in relevant system congurator.
Optional hard disk bays 4x 2.5-inch hot-plug SAS/SATA rear option

Drive bays (Base unit specic)

Storage drive bays 4 x 3.5-inch hot-plug

SAS/SATA

Accessible drive bays 1 x 5.25/0.4-inch for

CD-RW/DVD

Optional accessible drives ODD 5.25” possible ODD 5.25” NOT

General system information

Number of fans 6

12 x 3.5-inch hot-plug

SAS/SATA

possible

16 x 2.5-inch hot-plug

SAS/SATA

1 x 5.25/0.4-inch for
CD-RW/DVD

ODD 5.25” possible ODD 5.25” possible ODD 5.25” NOT

8 x 2.5-inch hot-plug

SAS/SATA

1 x 5.25/0.4-inch for
CD-RW/DVD

24 x 2.5-inch hot-plug

SAS/SATA

possible

Page 6 / 16 http://www.fujitsu.com/emeia/products/computing/servers/primergy/rack/rx2540m5/

Data Sheet FUJITSU Server PRIMERGY RX2540 M5 Rack Server

General system information

Fan conguration redundant / hot-plug

Fan notes 3x2 redundant

Operating panel

Operating buttons On/off switch

Reset button
NMI button
ID button

Status LEDs System status (orange / yellow)

Identication (blue)
Hard disks access (green)
Power (amber / green)

At system rear side:

System status (orange / yellow)
Identication (blue)
LAN connection (green)
LAN speed (green / yellow)

BIOS

BIOS features UEFI compliant

Legacy BIOS compatibility customer conguration option

Secure boot support
ROM based setup utility
GPT support for boot drives larger than 2.2 TB

Memory Redundancy support (Mirroring, Sparing)

IPMI support
Recovery BIOS
BIOS settings save and restore
Local BIOS update from USB device
Online update tools for main Linux versions
Local and remote update via ServerView Update Manager
IPv4/IPv6 remote PXE & iSCSI boot support
Cryptographically Signed BIOS Firmware Update
HTTP and HTTPS Boot

PCIe Bifurcation congurable

Operating Systems and Virtualization Software

Certied or supported operating

systems and virtualization software

Operating system release link http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
Operating system notes Support of other Linux derivatives on demand

Windows Server 2019 Datacenter
Windows Server 2019 Standard
Windows Server 2019 Essentials
Windows Server Datacenter, version 1809
Windows Server Standard, version 1809

Hyper-V Server 2016

Windows Server 2016 Datacenter
Windows Server 2016 Standard
Windows Server 2016 Essentials
Windows Storage Server 2016 Standard
Windows Server Datacenter, version 1709
VMware vSphere™ 6.5
VMware vSphere™ 6.7
SUSE® Linux Enterprise Server 12
Red Hat® Enterprise Linux 7
Univention Corporate Server 4

Page 7 / 16 http://www.fujitsu.com/emeia/products/computing/servers/primergy/rack/rx2540m5/

Data Sheet FUJITSU Server PRIMERGY RX2540 M5 Rack Server

Server Management and Infrastructure Management

Standard Infrastructure Manager (ISM) Essential

Node Management
Health status Monitoring and Control
Capacity/Threshold Management
Power Management
Converged Management
Auto Discovery
Remote Management
Update Management
Logging and Auditing

ServerView Suite (Deploy)

ServerView Installation Manager
ServerView Scripting Toolkit

ServerView Suite (Control)
ServerView Operations Manager (incl. PDA and ASR & R)

ServerView Agents and CIM provider
ServerView Agentless Management
ServerView System Monitor

SVOM- Event Manager

ServerView RAID Manager

SVOM- Threshold Manager
Power Monitor (monitoring the Power Consumption)
Power Management (iRMC)
Storage Management (server) with SVOM/SV-RAID
ServerView Suite (Maintain)
iRMC S5 (Remote Management)
System Update Manager (BIOS, Firmware, Windows Drives and SV Agents)
Performance management (SVOM)

Asset Management
Primecollect
Customer Self Service
Online Diagnostics

ServerView Suite (Integrate)

ServerView Integration packs for MS System Center, VMware vCenter, VMware vRealize, Nagios, and HP SIM

Option ServerView Suite (Maintain)

ServerView eLCM

iRMC Advanced Pack incl. Advanced Video Redirection (AVR), video capturing and Virtual Media
ServerView Suite (Dynamize)
ServerView Virtual IO Manager (SVIOM)
Infrastructure Manager (ISM)
Automate device conguration

Mass OS installation
Node Management
Health status Monitoring and Control
Capacity/Threshold Management
Power Management
Converged Management
Auto Discovery

Virtual-IO Management

Network topology Management
Remote Management
Update Management
Logging and Auditing
Integrate in to
Enterprise Management

Vendor specic Management

Monitor 3rd party platforms

Server Management notes Regarding dependencies for ServerView Suite software products see dedicated product data sheets.

Dimensions / Weight

Rack (W x D x H) 482.4 mm (Bezel) / 445 mm (Body) x 770 x 86.6 mm
Mounting Depth Rack 740 mm
Height Unit Rack 2 U

Page 8 / 16 http://www.fujitsu.com/emeia/products/computing/servers/primergy/rack/rx2540m5/

Data Sheet FUJITSU Server PRIMERGY RX2540 M5 Rack Server

Dimensions / Weight

19” rackmount Yes
Mounting Cable depth rack 200 mm (1,000 mm Rack recommended)
Weight up to 25 kg
Weight notes Actual weight may vary depending on conguration
Rack integration kit Rack integration kit as option

Environment

Operating ambient temperature 5 - 45 °C (41 - 113 °F)
Operating temperature note Cool-safe® Advanced Thermal Design (above 35 °C or below 10 °C) depending on conguration. For detailed

information see relevant system congurator.

Ambient temperature limitation may differ for liquid cooled models. Please refer to the SystemArchitect for detailed
information.

Operating relative humidity 10 - 85 % (non condensing)
Operating environment FTS 04230 – Guideline for Data Center (installation specication)
Operating environment link http://docs.ts.fujitsu.com/dl.aspx?id=e4813edf-4a27-461a-8184-983092c12dbe
Noise emission Measured according to ISO 7779 and declared according to ISO 9296
Sound pressure (LpAm) Typical noise : 43 dB(A) (idle) / 43 dB(A) (operating)
Sound power (LWAd; 1B = 10dB) Typical noise : 6.1 B (idle) / 6.0 B (operating)
Noise notes Noise emissions depends on operation modes, system conguration and ambient temperature.

Typical hardware conguration which is the base for measurement according to ISO 7779: 2x PSU 450W. 2x CPU Xeon

85W, 4x RAM 16GB, 2x HDD 500GB SATA, 6x LAN 1 Gbit/s

Electrical values

Power supply conguration 1 x hot-plug power supply or 2x hot-plug power supply for redundancy

Hot-plug power supply redundancy Optional

Active power (max. conguration) 715 W
Apparent power (max. conguration) 753 VA
Heat emission (max. conguration) 2574.0 kJ/h (2439.7 BTU/h)

Rated current max. 7.68 A (100 V) / 2.98 A (240 V)
Active power note To estimate the power consumption of different congurations use the Power Calculator of the System Architect:

http://congurator.ts.fujitsu.com/public/

Power supply 450W hot-plug, 94% (Platinum efciency), 100-240V, 50 / 60Hz

800W hot-plug, 94% (Platinum efciency), 100-240V, 50 / 60Hz
800W hot-plug, 96% (Titanium efciency), 200-240V, 50 / 60Hz
1200W hot-plug, 94% (Platinum efciency), 100-240V, 50 / 60Hz; 110V range: 1000W, less than 110V: 900W
800W hot-plug, 92% (equivalent to Gold efciency) –48V DC
1300W hot plug, 94% (equivalent to Platinum efciency) 380V DC

Power supply notes Power Safeguard adapts system performance in case the power requirements exceeds supply limits.

!96% Titanium Power supply unit is only released for 200-240V

Compliance

Global CB

RoHS (Substance limitations in accordance with global RoHS regulations)
WEEE (Waste electrical and electronical equipment)

Germany GS
Europe CE
USA/Canada CSAc/us

FCC Class A

ICES-003 / NMB-003 Class A

Japan VCCI:V3 Class A + JIS 61000-3-2
Russia EAC
South Korea KC
China CCC
Australia/New Zealand RCM
Taiwan BSMI
India BIS R41004006

Page 9 / 16 http://www.fujitsu.com/emeia/products/computing/servers/primergy/rack/rx2540m5/

Data Sheet FUJITSU Server PRIMERGY RX2540 M5 Rack Server

Compliance

Compliance link https://sp.ts.fujitsu.com/sites/certicates
Compliance notes There is general compliance with the safety requirements of all European countries and North America. National

approvals required in order to satisfy statutory regulations or for other reasons can be applied for on request.
* Warning:
This is a class A product. In a domestic environment this product may cause radio interference in which case the user
may be required to take adequate measures.

Components

Backup Drives LTO6HH Ultrium, 2,500 GB, 160 MB/s, half height, SAS 6Gb/s

LTO7HH Ultrium, 2,500 GB, 300 MB/s, half height, SAS 6Gb/s
RDX Drive, 320 GB, 500 GB, 1 TB , 25 MB/s, half height, USB 3.0

Optical drives Blu-ray Disc™ Triple Writer, (6x BD-RW, 8x DVD, 24x CD), ultraslim, SATA I

DVD Super Multi ultra slim , (8x DVD; 24x CD), ultraslim, SATA I

Hard disk drives HDD SATA, 6 Gb/s, 12 TB, 7,200 rpm, 512e, hot-plug, 3.5-inch, business critical

HDD SATA, 6 Gb/s, 8 TB, 7,200 rpm, 512e, hot-plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 6 TB, 7,200 rpm, 512e, hot-plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 4 TB, 7,200 rpm, 512n, hot-plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 2 TB, 7,200 rpm, 512n, hot-plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 2 TB, 7,200 rpm, 512n, hot-plug, 2.5-inch, business critical
HDD SATA, 6 Gb/s, 2 TB, 7,200 rpm, 512e, hot-plug, 2.5-inch, business critical
HDD SATA, 6 Gb/s, 1 TB, 7,200 rpm, 512n, hot-plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 1 TB, 7,200 rpm, 512n, hot-plug, 2.5-inch, business critical
HDD SATA, 6 Gb/s, 1 TB, 7,200 rpm, 512e, hot-plug, 2.5-inch, business critical

Page 10 / 16 http://www.fujitsu.com/emeia/products/computing/servers/primergy/rack/rx2540m5/

Data Sheet FUJITSU Server PRIMERGY RX2540 M5 Rack Server

Hard disk drives HDD SAS, 12 Gb/s, 900 GB, 15,000 rpm, hot-plug, 3.5-inch, enterprise

HDD SAS, 12 Gb/s, 900 GB, 15,000 rpm, 512n, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 900 GB, 10,000 rpm, 512n, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 900 GB, 10,000 rpm, 512e, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 600 GB, 15,000 rpm, hot-plug, 3.5-inch, enterprise
HDD SAS, 12 Gb/s, 600 GB, 15,000 rpm, 512n, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 600 GB, 10,000 rpm, 512n, hot-plug, 3.5-inch, enterprise
HDD SAS, 12 Gb/s, 600 GB, 10,000 rpm, 512n, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 600 GB, 10,000 rpm, 512e, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 600 GB , 10,000 rpm, 512n, hot-plug, 2.5-inch, enterprise, SED
HDD SAS, 12 Gb/s, 300 GB, 15,000 rpm, hot-plug, 3.5-inch, enterprise
HDD SAS, 12 Gb/s, 300 GB, 15,000 rpm, 512n, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 300 GB, 10,000 rpm, 512n, hot-plug, 3.5-inch, enterprise
HDD SAS, 12 Gb/s, 300 GB, 10,000 rpm, 512n, hot-plug, 2.5-inch, enterprise, SED
HDD SAS, 12 Gb/s, 300 GB, 10,000 rpm, 512n, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 12 TB, 7,200 rpm, 512e, hot-plug, 3.5-inch, enterprise, SED
HDD SAS, 12 Gb/s, 12 TB, 7,200 rpm, 512e, hot-plug, 3.5-inch, business critical
HDD SAS, 12 Gb/s, 10 TB, 7,200 rpm, 512e, hot-plug, 3.5-inch, enterprise, SED
HDD SAS, 12 Gb/s, 8 TB, 7,200 rpm, 512e, hot-plug, 3.5-inch, business critical
HDD SAS, 12 Gb/s, 6 TB, 7,200 rpm, 512e, hot-plug, 3.5-inch, enterprise, SED
HDD SAS, 12 Gb/s, 6 TB, 7,200 rpm, 512e, hot-plug, 3.5-inch, business critical
HDD SAS, 12 Gb/s, 4 TB, 7,200 rpm, hot-plug, 3.5-inch, business critical
HDD SAS, 12 Gb/s, 2.4 TB, 10,000 rpm, 512e, hot-plug, 3.5-inch, enterprise
HDD SAS, 12 Gb/s, 2.4 TB, 10,000 rpm, 512e, hot-plug, 2.5-inch, enterprise, SED
HDD SAS, 12 Gb/s, 2.4 TB, 10,000 rpm, 512e, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 2 TB, 7,200 rpm, hot-plug, 3.5-inch, business critical
HDD SAS, 12 Gb/s, 2 TB, 7,200 rpm, 512n, hot-plug, 2.5-inch, business critical
HDD SAS, 12 Gb/s, 1.8 TB, 10,000 rpm, 512e, hot-plug, 3.5-inch, enterprise
HDD SAS, 12 Gb/s, 1.8 TB, 10,000 rpm, 512e, hot-plug, 2.5-inch, enterprise, SED
HDD SAS, 12 Gb/s, 1.8 TB, 10,000 rpm, 512e, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 1.2 TB, 10,000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 1.2 TB, 10,000 rpm, 512n, hot-plug, 3.5-inch, enterprise
HDD SAS, 12 Gb/s, 1.2 TB, 10,000 rpm, 512e, hot-plug, 2.5-inch, enterprise
HDD SAS, 12 Gb/s, 1.2 TB , 10,000 rpm, 512n, hot-plug, 2.5-inch, enterprise, SED
HDD SAS, 12 Gb/s, 1 TB, 7,200 rpm, hot-plug, 3.5-inch, business critical
HDD SAS, 12 Gb/s, 1 TB, 7,200 rpm, 512n, hot-plug, 2.5-inch, business critical

Page 11 / 16 http://www.fujitsu.com/emeia/products/computing/servers/primergy/rack/rx2540m5/

Data Sheet FUJITSU Server PRIMERGY RX2540 M5 Rack Server

Solid-State-Drive SSD SATA, 6 Gb/s, 960 GB, Read-Intensive, hot-plug, 3.5-inch, enterprise, 0.9 DWPD (Drive Writes Per Day for 5 years)

SSD SATA, 6 Gb/s, 960 GB, Read-Intensive, hot-plug, 2.5-inch, enterprise, 0.9 DWPD (Drive Writes Per Day for 5 years)
SSD SATA, 6 Gb/s, 960 GB, Mixed-use, hot-plug, 3.5-inch, enterprise, 3 DWPD (drive writes per day for 5 years)
SSD SATA, 6 Gb/s, 960 GB, Mixed-use, hot-plug, 2.5-inch, enterprise, 3 DWPD (drive writes per day for 5 years)
SSD SATA, 6 Gb/s, 480 GB, Read-Intensive, hot-plug, 3.5-inch, enterprise, 0.9 DWPD (Drive Writes Per Day for 5 years)
SSD SATA, 6 Gb/s, 480 GB, Read-Intensive, hot-plug, 2.5-inch, enterprise, 0.9 DWPD (Drive Writes Per Day for 5 years)
SSD SATA, 6 Gb/s, 480 GB, Mixed-use, hot-plug, 3.5-inch, enterprise, 3.6 DWPD (Drive Writes Per Day for 5 years)
SSD SATA, 6 Gb/s, 480 GB, Mixed-use, hot-plug, 2.5-inch, enterprise, 3.6 DWPD (Drive Writes Per Day for 5 years)
SSD SATA, 6 Gb/s, 240 GB, Read-Intensive, hot-plug, 3.5-inch, enterprise, 1.4 DWPD (Drive Writes Per Day for 5 years)
SSD SATA, 6 Gb/s, 240 GB, Read-Intensive, hot-plug, 2.5-inch, enterprise, 1.4 DWPD (Drive Writes Per Day for 5 years)
SSD SATA, 6 Gb/s, 240 GB, Mixed-use, hot-plug, 3.5-inch, enterprise, 3.6 DWPD (Drive Writes Per Day for 5 years)
SSD SATA, 6 Gb/s, 240 GB, Mixed-use, hot-plug, 2.5-inch, enterprise, 3.6 DWPD (Drive Writes Per Day for 5 years)
SSD SATA, 6 Gb/s, 7.68 TB, Read-Intensive, hot-plug, 3.5-inch, enterprise, 0.5 DWPD (Drive Writes Per Day for 5 years)
SSD SATA, 6 Gb/s, 7.68 TB, Read-Intensive, hot-plug, 2.5-inch, enterprise, 0.5 DWPD (Drive Writes Per Day for 5 years)
SSD SATA, 6 Gb/s, 3.84 TB, Read-Intensive, hot-plug, 3.5-inch, enterprise, 1.0 DWPD (Drive Writes Per Day for 5 years)
SSD SATA, 6 Gb/s, 3.84 TB, Read-Intensive, hot-plug, 2.5-inch, enterprise, 1.0 DWPD (Drive Writes Per Day for 5 years)
SSD SATA, 6 Gb/s, 3.84 TB, Mixed-use, hot-plug, 3.5-inch, enterprise, 3 DWPD (drive writes per day for 5 years)
SSD SATA, 6 Gb/s, 3.84 TB, Mixed-use, hot-plug, 2.5-inch, enterprise, 3 DWPD (drive writes per day for 5 years)
SSD SATA, 6 Gb/s, 1.92 TB, Read-Intensive, hot-plug, 3.5-inch, enterprise, 0.9 DWPD (Drive Writes Per Day for 5 years)
SSD SATA, 6 Gb/s, 1.92 TB, Read-Intensive, hot-plug, 2.5-inch, enterprise, 0.9 DWPD (Drive Writes Per Day for 5 years)
SSD SATA, 6 Gb/s, 1.92 TB, Mixed-use, hot-plug, 3.5-inch, enterprise, 3 DWPD (drive writes per day for 5 years)
SSD SATA, 6 Gb/s, 1.92 TB, Mixed-use, hot-plug, 2.5-inch, enterprise, 3 DWPD (drive writes per day for 5 years)
SSD M.2 SATA, 6 Gb/s, 480 GB, non hot plug, enterprise, 1.4 DWPD (Drive Writes Per Day for 5 years)
SSD M.2 SATA, 6 Gb/s, 240 GB, non hot plug, enterprise, 1.4 DWPD (Drive Writes Per Day for 5 years)

SSD M.2 SATA, 6 Gb/s, 240 GB, non hot plug, enterprise

SSD M.2 SATA, 6 Gb/s, 150 GB, non hot plug, enterprise, 1.5 DWPD (Drive Writes Per Day for 5 years)

SSD M.2 SATA, 6 Gb/s, 150 GB, non hot plug, enterprise

Page 12 / 16 http://www.fujitsu.com/emeia/products/computing/servers/primergy/rack/rx2540m5/

Data Sheet FUJITSU Server PRIMERGY RX2540 M5 Rack Server

Solid-State-Drive SSD SAS, 12 Gb/s, 960 GB, Read-Intensive, hot-plug, 3.5-inch, enterprise, 1 DWPD (Drive Writes Per Day for 5 years)

SSD SAS, 12 Gb/s, 960 GB, Read-Intensive, hot-plug, 2.5-inch, enterprise, 1 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 800 GB, Write-Intensive, hot-plug, 3.5-inch, enterprise, 10 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 800 GB, Write-Intensive, hot-plug, 2.5-inch, enterprise, 10 DWPD (Drive Writes Per Day for 5 years),

SED

SSD SAS, 12 Gb/s, 800 GB, Write-Intensive, hot-plug, 2.5-inch, enterprise, 10 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 800 GB, Mixed-use, hot-plug, 3.5-inch, enterprise, 3 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 800 GB, Mixed-use, hot-plug, 2.5-inch, enterprise, 3 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 480 GB, Read-Intensive, hot-plug, 3.5-inch, enterprise, 1 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 480 GB, Read-Intensive, hot-plug, 2.5-inch, enterprise, 1 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 400 GB, Write-Intensive, hot-plug, 3.5-inch, enterprise, 10 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 400 GB, Write-Intensive, hot-plug, 2.5-inch, enterprise, 10 DWPD (Drive Writes Per Day for 5 years),

SED

SSD SAS, 12 Gb/s, 400 GB, Write-Intensive, hot-plug, 2.5-inch, enterprise, 10 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 400 GB, Mixed-use, hot-plug, 3.5-inch, enterprise, 3 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 400 GB, Mixed-use, hot-plug, 2.5-inch, enterprise, 3 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 7.68 TB, Read-Intensive, hot-plug, 3.5-inch, enterprise, 0.9 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 3.84 TB, Read-Intensive, hot-plug, 3.5-inch, enterprise, 1 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 3.84 TB, Read-Intensive, hot-plug, 2.5-inch, enterprise, 1 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 3.2 TB, Mixed-use, hot-plug, 3.5-inch, enterprise, 2.3 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 3.2 TB, Mixed-use, hot-plug, 2.5-inch, enterprise, 2.3 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 1.92 TB, Read-Intensive, hot-plug, 3.5-inch, enterprise, 1 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 1.92 TB, Read-Intensive, hot-plug, 2.5-inch, enterprise, 1 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 1.6 TB, Write-Intensive, hot-plug, 3.5-inch, enterprise, 10 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 1.6 TB, Write-Intensive, hot-plug, 2.5-inch, enterprise, 10 DWPD (Drive Writes Per Day for 5 years),

SED

SSD SAS, 12 Gb/s, 1.6 TB, Write-Intensive, hot-plug, 2.5-inch, enterprise, 10 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 1.6 TB, Mixed-use, hot-plug, 3.5-inch, enterprise, 3 DWPD (Drive Writes Per Day for 5 years)
SSD SAS, 12 Gb/s, 1.6 TB, Mixed-use, hot-plug, 2.5-inch, enterprise, 3 DWPD (Drive Writes Per Day for 5 years)

PCIe SSD & SATA DOM SSD PCIe-SSD SFF, 750 GB, Write-Intensive, hot-plug, 2.5-inch, Flash drive, 30 DWPD (Drive Writes Per Day for 5 years)

PCIe-SSD SFF, 6.4 TB, Mixed-use, hot-plug, 2.5-inch, Flash drive, 3.2 DWPD (Drive Writes Per Day for 5 years)
PCIe-SSD SFF, 6.4 TB, Mixed-use, hot-plug, 2.5-inch, Flash drive, 3.0 DWPD (Drive Writes Per Day for 5 years)
PCIe-SSD SFF, 4 TB, Read-Intensive, hot-plug, 2.5-inch, Flash drive, 3.0 DWPD (Drive Writes Per Day for 5 years)
PCIe-SSD SFF, 4 TB, Read-Intensive, hot-plug, 2.5-inch, Flash drive, 0.6 DWPD (Drive Writes Per Day for 5 years)
PCIe-SSD SFF, 3.2 TB, Mixed-use, hot-plug, 2.5-inch, Flash drive, 3.1 DWPD (Drive Writes Per Day for 5 years)
PCIe-SSD SFF, 3.2 TB, Mixed-use, hot-plug, 2.5-inch, Flash drive, 3.0 DWPD (Drive Writes Per Day for 5 years)
PCIe-SSD SFF, 2 TB, Read-Intensive, hot-plug, 2.5-inch, Flash drive, 3.0 DWPD (Drive Writes Per Day for 5 years)
PCIe-SSD SFF, 2 TB, Read-Intensive, hot-plug, 2.5-inch, Flash drive, 0.6 DWPD (Drive Writes Per Day for 5 years)
PCIe-SSD SFF, 1.6 TB, Mixed-use, hot-plug, 2.5-inch, Flash drive, 3.0 DWPD (Drive Writes Per Day for 5 years)
PCIe-SSD SFF, 1 TB, Read-Intensive, hot-plug, 2.5-inch, Flash drive, 3.0 DWPD (Drive Writes Per Day for 5 years)
PCIe-SSD SFF, 1 TB, Read-Intensive, hot-plug, 2.5-inch, Flash drive, 1 DWPD (Drive Writes Per Day for 5 years)
PCIe-SSD AIC, 750 GB, Write-Intensive, HHHL, Flash drive, 30 DWPD (Drive Writes Per Day for 5 years)
PCIe-SSD AIC, 375 GB, Write-Intensive, HHHL, Flash drive, 30 DWPD (Drive Writes Per Day for 5 years)
PCIe-SSD AIC, 4 TB, Mixed-use, HHHL, Flash drive, 3.1 DWPD (Drive Writes Per Day for 5 years)
PCIe-SSD AIC, 2 TB, Mixed-use, HHHL, Flash drive, 3.0 DWPD (Drive Writes Per Day for 5 years)

Dual microSD 64GB Enterprise

SCSI / SAS Controller LSI PSAS CP400e LP SAS Ctrl. 12 Gbit/s 8 ports ext. PCIe 3.0 x8

Fujitsu PSAS CP403i SAS Ctrl. 12 Gbit/s 8 ports int. PCIe 3.0 x8
Fujitsu PSAS CP400i SAS Ctrl. 12 Gbit/s 8 ports int. PCIe 3.0 x8
Fujitsu PSAS CP400e FH SAS Ctrl. 12 Gbit/s 8 ports ext. PCIe 3.0 x8

Page 13 / 16 http://www.fujitsu.com/emeia/products/computing/servers/primergy/rack/rx2540m5/

Data Sheet FUJITSU Server PRIMERGY RX2540 M5 Rack Server

RAID Controller Fujitsu PRAID EP580i LP, RAID 5/6 Ctrl., SAS/SATA 12 Gbit/s, NVMe-PCIe 8 Gbit/s, 8 Gbit/s 16 ports int. RAID level: 0, 1,

10, 5, 50, 6, 60, 8 GB, Optional FBU based on LSI SAS3516

Fujitsu PRAID EP540i LP, RAID 5/6 Ctrl., SAS/SATA 12 Gbit/s, NVMe-PCIe 8 Gbit/s, 8 Gbit/s 16 ports int. RAID level: 0, 1,

10, 5, 50, 6, 60, 4 GB, Optional FBU based on LSI SAS3516

Fujitsu PRAID EP540e LP, RAID 5/6 Ctrl., SAS 12 Gbit/s, 8 ports ext.

RAID level: 0, 1, 10, 5, 50, 6, 60, 4 GB, Optional FBU based on LSI SAS3516

Fujitsu PRAID EP540e FH, RAID 5/6 Ctrl., SAS 12 Gbit/s, 8 ports ext.

RAID level: 0, 1, 10, 5, 50, 6, 60, 4 GB, Optional FBU based on LSI SAS3516

Fujitsu PRAID EP520i LP, RAID 5/6 Ctrl., SAS/SATA 12 Gbit/s, NVMe-PCIe 8 Gbit/s, 8 ports int. RAID level: 0, 1, 10, 5, 50,

6, 60, 2 GB, Optional FBU based on LSI SAS3516

Fujitsu PRAID EP420i, RAID 5/6 Ctrl., SAS/SATA 12 Gbit/s, 8 ports int.

RAID level: 0, 1, 10, 5, 50, 6, 60, 2 GB, Optional FBU based on LSI SAS3108

Fujitsu PRAID EP420i for SafeStore, RAID 5/6 Ctrl., SAS/SATA 12 Gbit/s, 8 ports int.

RAID level: 0, 1, 10, 5, 50, 6, 60, 2 GB, Optional FBU based on LSI SAS3108

Fujitsu PRAID EP400i, RAID 5/6 Ctrl., SAS/SATA 12 Gbit/s, 8 ports int.

RAID level: 0, 1, 10, 5, 50, 6, 60, 1 GB, Optional FBU based on LSI SAS3108

Fujitsu PRAID CP400i, RAID Ctrl., SAS/SATA 12 Gbit/s, 8 ports int.

RAID level: 0, 1, 1E, 10, 5, 50, No FBU support

Fibre Channel controller Fibre Channel Host Bus Adapter 1 x 32 Gbit/s Cavium QLE2740 MMF LC-style

Fibre Channel Host Bus Adapter 2 x 32 Gbit/s Cavium QLE2742 MMF LC-style
Fibre Channel Host Bus Adapter 1 x 32 Gbit/s Emulex LPe32000-M6-F MMF LC-style
Fibre Channel Host Bus Adapter 2 x 32 Gbit/s Emulex LPe32002-M6-F MMF LC-style
Fibre Channel Host Bus Adapter 1 x 16 Gbit/s Qlogic QLE2690 LC-style
Fibre Channel Host Bus Adapter 2 x 16 Gbit/s Qlogic QLE2692 LC-style
Fibre Channel Host Bus Adapter 1 x 16 Gbit/s Emulex LPe31000-M6-F MMF LC-style
Fibre Channel Host Bus Adapter 2 x 16 Gbit/s Emulex LPe31002-M6-F MMF LC-style

Communication, Network Converged Network Adapter 2 x 10 Gbit/s / 25 Gbit/s PCIe 3.0 x8 SFP28 ( Cavium )

Ethernet Ctrl. 1 x 100 Gbit/s PCIe 3.0 x16 QSFP28 ( Cavium )
Ethernet Ctrl. 1 x 100 Gbit/s PCIe 3.0 x16 QSFP28 ( Mellanox )
Ethernet Ctrl. 2 x 10 Gbit/s ; 1 Gbit/s PCIe 3.0 x8 RJ45 ( Cavium )
Ethernet Ctrl. 2 x 10 Gbit/s ; 1 Gbit/s PCIe 3.0 x8 RJ45 ( Intel® )
Ethernet Ctrl. 2 x 10 Gbit/s ; 1 Gbit/s PCIe 3.0 x8 SFP+ ( Cavium )
Ethernet Ctrl. 2 x 10 Gbit/s / 25 Gbit/s PCIe 3.0 x8 SFP28 ( Cavium )
Ethernet Ctrl. 2 x 10 Gbit/s / 25 Gbit/s PCIe 3.0 x8 SFP28 ( Intel® )
Ethernet Ctrl. 2 x 10 Gbit/s / 25 Gbit/s PCIe 3.0 x8 SFP28 ( Mellanox )
Ethernet Ctrl. 2 x 10 Gbit/s PCIe 3.0 x8 SFP+ ( Intel® )
Ethernet Ctrl. 2 x 1 Gbit/s PCIe 2.1 x4 RJ45 ( Intel® )
Ethernet Ctrl. 2 x 40 Gbit/s PCIe 3.0 x16 QSFP ( Mellanox )
Ethernet Ctrl. 4 x 10 Gbit/s ; 1 Gbit/s PCIe 3.0 x8 RJ45 ( Cavium )
Ethernet Ctrl. 4 x 10 Gbit/s ; 1 Gbit/s PCIe 3.0 x8 RJ45 ( Intel® )
Ethernet Ctrl. 4 x 10 Gbit/s PCIe 3.0 x8 SFP+ ( Intel® )
Ethernet Ctrl. 4 x 1 Gbit/s PCIe 2.1 x4 RJ45 ( Intel® )
InniBand HCA 1 x 100 Gbit/s PCIe 3.0 x16 QSFP for the US market max. one IB HCA 100Gb controller can be installed

( Mellanox )
InniBand HCA 2 x 100 Gbit/s PCIe 3.0 x16 QSFP for the US market max. one IB HCA 100Gb controller can be installed

( Mellanox )
Interface modul for Dynamic LoM 2 x 10 Gbit/s RJ45 ( Intel® )
Interface modul for Dynamic LoM 2 x 10 Gbit/s SFP+ ( Intel® )
Interface modul for Dynamic LoM 4 x 10 Gbit/s SFP+ ( Intel® )
Interface modul for Dynamic LoM 4 x 1 Gbit/s RJ45 ( Intel® )
MPO x 40 Gbit/s ( )
Omni Path 1 x PCIe 3.0 x16 ( Intel® )

Page 14 / 16 http://www.fujitsu.com/emeia/products/computing/servers/primergy/rack/rx2540m5/

Data Sheet FUJITSU Server PRIMERGY RX2540 M5 Rack Server

Graphics NVIDIA® Quadro® P400 , 2 GB, PCIe x16, 3 x miniDP

Rack infrastructure Rackmount kit full extraction (820mm), tool less mounting, length variable 559-914mm

Rack Mount Kit

Cable Management for 19-inch DataCenter / PRIMECENTER Racks
Cable Arm 2U for PRIMECENTER- and 3rd-party racks

Warranty

Warranty period 3 years
Warranty type Onsite warranty
Warranty Terms & Conditions www.fujitsu.com/support

Product Support Services - the perfect extension

Support Pack Options Globally available in major business areas:

9x5, Next Business Day Onsite Response Time

9x5, 4h Onsite Response Time (depending on country)
24x7, 4h Onsite Response Time (depending on country)

Recommended Service 24x7, Onsite Response Time: 4h - For locations outside of EMEIA please contact your local Fujitsu partner.
Service Lifecycle 5 years after end of product life
Service Weblink http://www.fujitsu.com/emeia/products/product-support-services/

Page 15 / 16 http://www.fujitsu.com/emeia/products/computing/servers/primergy/rack/rx2540m5/

Data Sheet FUJITSU Server PRIMERGY RX2540 M5 Rack Server

More information

Fujitsu products, solutions & services

In addition to FUJITSU Server PRIMERGY

RX2540 M5, Fujitsu provides a range of

platform solutions. They combine reliable

Fujitsu products with the best in services,
know-how and worldwide partnerships.

Fujitsu Portfolio

Built on industry standards, Fujitsu offers a full

portfolio of IT hardware and software products,
services, solutions and cloud offering, ranging
from clients to datacenter solutions and
includes the broad stack of Business Solutions,
as well as the full stack of Cloud offerings. This
allows customers to select from alternative
sourcing and delivery models to increase
their business agility and to improve their IT
operation’s reliability.

Computing Products

www.fujitsu.com/global/products/computing/

Software

www.fujitsu.com/software/

More information

Learn more about FUJITSU Server PRIMERGY

RX2540 M5, please contact your Fujitsu sales
representative or Fujitsu Business partner, or

visit our website.

www.fujitsu.com/primergy

Fujitsu green policy innovation

Fujitsu Green Policy Innovation is our
worldwide project for reducing burdens on the

environment.

Using our global know-how, we aim to

contribute to the creation of a sustainable
environment for future generations through IT.

Please nd further information at http://www.
fujitsu.com/global/about/environment

Copyrights

All rights reserved, including intellectual
property rights. Designations may be
trademarks and/or copyrights of the respective
owner, the use of which by third parties for
their own purposes may infringe the rights of
such owner. For further information see http://

www.fujitsu.com/fts/resources/navigation/
terms-of-use.html

Copyright 2019 FUJITSU LIMITED

Disclaimer

Technical data is subject to modication and
delivery subject to availability. Any liability

that the data and illustrations are complete,
actual or correct is excluded. Designations
may be trademarks and/or copyrights of the
respective owner, the use of which by third
parties for their own purposes may infringe
the rights of such owner.

Contact

FUJITSU LIMITED

Website: www.fujitsu.com
2019-06-11 WW-EN

Page 16 / 16 http://www.fujitsu.com/emeia/products/computing/servers/primergy/rack/rx2540m5/

All rights reserved, including intellectual property rights. Designations may be trademarks and/or copyrights of the respective
owner, the use of which by third parties for their own purposes may infringe the rights of such owner. For further information

see http://www.fujitsu.com/fts/resources/navigation/terms-of-use.html

Copyright 2019 FUJITSU LIMITED
