PRIMERGY RX220
System configurator and order-information guide
January 2006
Contents
Instructions
Configuration diagram
Configurator
0 System software
I Basic unit
II Processor
III Memory
IV Graphics
V Accessible drives
VI Hard disk drives
VII SCSI controller
VIII Fibre-Channel controller
IX Disk array
X Communication/Network
XI System Management Products (RemoteView)
XII Miscellaneous
XIII Country specific power cord
Change report
PRIMERGY Server
System configurator and order-information guide
PRIMERGY RX220 Status 2005-12-20
Instructions
This document contains basic product and configuration information that will enable you to configure your system via
PC-/System-Architect
Only these tools will ensure a fast and proper configuration of your PRIMERGY server or your complete
PRIMERGY Rack system.
You can configure your individual PRIMERGY server in order to adjust your specific requirements.
The System configurator is divided into several chapters that are identical to the current price list and PC-/System-Architect.
Please follow the lines. If there is a junction, you can choose which way or component you would like to take. Go through
the configurator by following the lines from the top to the bottom.
Section
In one chapter you can only select as many components (here 4x) as the arrow indicates.
Please note that there are information symbols which indicate necessary information.
Further information in the internet see:
http://www.primergy.com
(internet)
http://extranet.fujitsu-siemens.com/primergy
(extranet)
Prices and availability see price list and PC-/System-Architect.
Subject to change and errors excepted.
X times
III
S26361-XXX-XXX S26361-XXX-XXX
Memory XXX MB Memory XXX MB
max. X times per system max. X times per system
Memory, example
There are X memory slots which can be equipped with XXX MB
It is permissible to make up to X passes through the memory upgrade options
4x
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
2 of 15
PRIMERGY RX220 Status 2005-12-20
Configuration diagram PRIMERGY RX220
System unit ( I )
Bank I (2 Modules)
Opteron 2xx Standard
Bank II (2 Modules)
Bank III (2 Modules)
Opteron 2xx
Bank IV (2 Modules)
System configurator and order-information guide
Power supply
5.25"x0.5" Empty/CD/ DVD-ROM
Memory ( III ) Processor ( II )
Note: Memory is directly connected to the CPU.
So, if only one CPU is configured only 2 banks are possible. Accessible drives ( V )
Extension slots Hard disk drives ( VI )
SCSI Controller ( VII )
Disk Array ( IX )
Communication/Network ( X )
System Management ( XI ) 3.5"x1" id-0
Miscellaneous ( XIII )
Slot 1: PCI-X 64 Bit / 133 MHz, Standard - long 3.5"x1" id-1
Slot 2: PCI-Express x8, Standard - short
Key:
Included in basic unit
Option
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
3 of 15
PRIMERGY-Software Configurators and Release Lists
Start PRIMERGY RX220
PRIMERGY RX220 Status 2005-12-20
with OEM-Software
without OEM-Software
not possible under ESX or GSX
- SuSE Linux Enterprise Server
*)
http://extranet.fujitsu-siemens.com/ascc
**)
http://vil.mch.fsc.net/vil/pc/vil/primergy/overview/prince/index_en.htm
for internal users:
http://vil.mch.fsc.net/vil/oec/special/primergy/index_en.htm
for partners:
http://vilpart.fujitsu-siemens.de/vil/oec/special/primergy/index_en.htm
SW - Configurator 32 bit
for PRIMERGY Server Usage of OEM SW from MS is for PRIMERGY Server
VMware-Software software is not allowed,
- VCMS VirtualCenter Management Server apart from few VMware
- GSX Server and GSX Virtual Infrastructure Node add-ons
- P2V Assistant Enterprise Edition
For all SW products please refer to the corresponding software configurator accessible via
the Extranet under Configuration & Tools, -All configurations, -Software, URL see below.
Microsoft - Software: W Linux - Software: L **)
- Windows Server 2003,
Web Edition (only English) - Red Hat Enterprise Linux
Standard Edition
Enterprise Edition
- Additional loose
Client-Access-Licenses (CALs)
(not for Web Edition)
CITRIX-Software for
Windows: W-MF
- Presentation Server
LoadBalancing
Additional User Licences
Adaptive Services Control Center (ASCC)*)
ASCC Satellite Node
SLES, RHEL, W2K3
Later use of OEM operating system
Manageability Software: V**) Details eg. version numbers are published
- RemoteView Software on the page referred to
- RemoteView Service Board
- RemoteView Diagnosis
- RemoteDeploy
- vPMS 2005std
- Altiris Server Deployment
Backup-Software /
Application-Software: U
- ARCserve
- openSM2
You'll find single software configurators and release lists (OS-matrix / system management / security) under following addresses:
Continue with PRIMERGY
HW configurator
Pay attention to the ASCC release and ordering information in the Extranet under
Pay attention to release and order information in PRINCE -> Operating System
Enterprise Products PRIMERGY Server
Fujitsu Siemens Computers
4 of 15
PRIMERGY-Software Configurators and Release Lists
Start PRIMERGY RX220
PRIMERGY RX220 Status 2005-12-20
with OEM-Software
without OEM-Software
- SuSE Linux Enterprise Server
http://extranet.fujitsu-siemens.com/primecluster
for internal users:
http://vil.mch.fsc.net/vil/oec/special/primergy/index_en.htm
for partners:
http://vilpart.fujitsu-siemens.de/vil/oec/special/primergy/index_en.htm
SW - Configurator EM64T
for PRIMERGY Server for PRIMERGY Server
For all SW products please refer to the corresponding software is not allowed.
software configurator accessible via the Extranet under
"Configuration & Tools, -All configurations, -Software,
URL see below.
Microsoft - Software: W Linux - Software: L *) **)
only - Windows Server 2003, only
EM64T x64 Standard Edition EM64T - Red Hat Enterprise Linux
x64 Enterprise Edition
- Additional loose
Client-Access-Licenses (CALs)
only VMware GSX Server
EM64T and GSX Virtual Infrastructure Node
Manageability Software: V**) Details eg. version numbers are published
only - RemoteView Software on the page referred to
EM64T - RemoteView Service Board
- RemoteView Diagnosis
*) Pay attention to the PRIMECLUSTER release and ordering information in the Extranet under
Later use of OEM operating system
**) Pay attention to release and order information in PRINCE -> Operating System
http://vil.mch.fsc.net/vil/pc/vil/primergy/overview/prince/index_en.htm
You'll find single software configurators and release lists (OS-matrix / system management / security) under following addresses:
Continue with PRIMERGY
HW configurator
Enterprise Products PRIMERGY Server
Fujitsu Siemens Computers
5 of 15
System configurator and order-information guide
Start PRIMERGY RX220
PRIMERGY RX220 Status 2005-12-20
Cables included in basic unit
Connections
Cable
PRIMERGY RX220
1.
IDE CD/DVD
¡
¡
2.
SATA cables HDDs
¥
¥
3.
Power cable
Section
I
Basic unit
System unit consisting of:
* 1U Housing including standard power supply
* Fans
- Fans for Power Supply and Chassis
* Drives / Bays
- 2 bays 1" for SATA hot-plug or "easy change" HD
- 1 bay (for accessible drives) with
- 1 IDE-CD- or DVD- or CD-RW-ROM 0,5" height
Systemboard with:
- Dual Processor Board with Opteron 940 pin socket (s. section II)
- 8 memory slots (s. section III)
- SATA RAID controller on-board (s. section IX)
- Dual LAN on-board 10/100/1000TX (s. section X)
- Graphics controller (s. section IV)
- 2 PCI Slots:
1x PCI-X 64 Bit / 133 MHz standard long
1x PCI-Express x8 standard short 1xx mm
- BMC (Baseboard Management Controller) Servermanagement Chip on board
External Interfaces:
- 1x RS-232-C (serial, 9 pins) (usable for BMC or OS or shared)
- 1x keyboard (PS/2)
- 1x mouse (PS/2)
- 1x VGA (15 pins)
- 4x USB 2.0 (2x front and 2x rear)
- 2x LAN RJ45
Cables:
1. IDE cable for CD/DVD.
2. SATA cables for up to 2 internal HDDs
3. Power cable
Software:
- ServerStart packet incl. ServerBooks CD, ServerSupport CD and ServerView
- Documentation engl. (multilingual on CD)
Mounting kit for PRIMERGY RX220 is part of the basic unit
- 1 pair of telescopic rails (650 - 790mm)
- 1 bracket DC-PC-Rack
Mounting kit for mounting of servers in in FSC 19" PRIMECENTER- racks
and all server racks conforming to EIA standard EIA-310-D for 19" racks.
Therefore the mounting kit is variable in depth from 650 - 790mm
A
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
6 of 15
System configurator and order-information guide
A
PRIMERGY RX220 Status 2005-12-20
All Basic units include a pair of identical Memory Modules.
Maximum Memory expendability depends on chosen base unit!
1U Rack server for 19'' racks 1U Rack server for 19'' racks
Basic unit with: Basic unit with:
- 1x Opteron ( 1MB SLC ) single core processor - 1x Opteron ( 2x 1MB SLC ) dual core processor
Opteron 244 (1.80 GHz) Opteron 265 (1.8 GHz)
Opteron 244 1MB 1GB S26361-K986-V121 Opteron 265 2x 1MB 2GB S26361-K986-V212
Opteron 244 1MB 2GB S26361-K986-V122 Opteron 265 2x 1MB 4GB S26361-K986-V214
Opteron 244 1MB 4GB S26361-K986-V124
Opteron 246 (2.00 GHz) Opteron 270 (2.0 GHz)
Opteron 246 1MB 1GB S26361-K986-V131 Opteron 270 2x 1MB 2GB S26361-K986-V222
Opteron 246 1MB 2GB S26361-K986-V132 Opteron 270 2x 1MB 4GB S26361-K986-V224
Opteron 246 1MB 4GB S26361-K986-V134
Opteron 248 (2.20 GHz) Opteron 275 (2.2 GHz)
Opteron 248 1MB 1GB S26361-K986-V141 Opteron 275 2x 1MB 2GB S26361-K986-V232
Opteron 248 1MB 2GB S26361-K986-V142 Opteron 275 2x 1MB 4GB S26361-K986-V234
Opteron 248 1MB 4GB S26361-K986-V144
Opteron 250 (2.40 GHz)
Opteron 250 1MB 1GB S26361-K986-V151
Opteron 250 1MB 2GB S26361-K986-V152
Opteron 250 1MB 4GB S26361-K986-V154
Opteron 252 (2.60 GHz)
Opteron 265 2x 1MB 1GB S26361-K986-V211
Opteron 270 2x 1MB 1GB S26361-K986-V221
Opteron 275 2x 1MB 1GB S26361-K986-V231
Opteron 252 1MB 1GB S26361-K986-V161
Opteron 252 1MB 2GB S26361-K986-V162
Opteron 252 1MB 4GB S26361-K986-V164
Opteron 254 (2.80 GHz)
Opteron 254 1MB 1GB S26361-K986-V171
Opteron 254 1MB 2GB S26361-K986-V172
Opteron 254 1MB 4GB S26361-K986-V174
PRIMERGY Rack
S26361-F1647-E302 S26361-F1331-L200
Installation ex works for one Mounting kit for PRIMERGY19" Classic rack
server or subsystem. RMK CR RX220 complete for mounting in PRIMERGY Classic racks
Hereby the rack will be delivered It is necessary to leave one height unit between each server in
completely pre-mounted and
all wired connections are tested. prim_racks_0603 are to be fulfilled.
With racks 12U, 24U, 38U:
Systems and components
will be delivered installed in the rack
With racks 46U:
Systems and components "Rack-mounting ex factory"
will be delivered separately This service is to be ordered once
To be ordered only together with per installable server/storage
a PRIMERGY PRIMECENTER rack subsystem, in order to get the
e.g.: mounted into the PRIMERGY racks.
S26361-K826-V10x In case of the 46 U PRIMERGY Rack,
refer configurator PC-Rack this service has to be ordered,
max. 1x per System to get the mounting kits and the
order to arrange the cables. Restrictions from the Inform:
server/storage subsystem
cables installed.
B
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
7 of 15
System configurator and order-information guide
B
PRIMERGY RX220 Status 2005-12-20
1x or 3x
Section
II
2nd. CPU
S26361-F3167-E244 S26361-F3167-E246 S26361-F3167-E248
Opteron 244 with 1.8 GHz Opteron 246 with 2.0 GHz Opteron 248 with 2.2 GHz
with 1MB SLC on Chip with 1MB SLC on Chip with 1MB SLC on Chip
(SLC=Second Level Cache) (SLC=Second Level Cache) (SLC=Second Level Cache)
and passive heat sink and passive heat sink and passive heat sink
occupies CPU socket occupies CPU socket occupies CPU socket
max. 1x per system max. 1x per system max. 1x per system
S26361-F3167-E250 S26361-F3167-E252 S26361-F3167-E254
Opteron 250 with 2.4 GHz Opteron 252 with 2.6 GHz Opteron 254 with 2.8 GHz
with 1MB SLC on Chip with 1MB SLC on Chip with 1MB SLC on Chip
(SLC=Second Level Cache) (SLC=Second Level Cache) (SLC=Second Level Cache)
and passive heat sink and passive heat sink and passive heat sink
occupies CPU socket occupies CPU socket occupies CPU socket
max. 1x per system max. 1x per system max. 1x per system
S26361-F3167-E265 S26361-F3167-E270 S26361-F3167-E275
Opteron 265 with 1.8 GHz Opteron 270 with 2.0 GHz Opteron 275 with 2.2 GHz
with 2x 1MB SLC on Chip with 2x 1MB SLC on Chip with 2x 1MB SLC on Chip
(SLC=Second Level Cache) (SLC=Second Level Cache) (SLC=Second Level Cache)
and passive heat sink and passive heat sink and passive heat sink
occupies CPU socket occupies CPU socket occupies CPU socket
max. 1x per system max. 1x per system max. 1x per system
Processor
There are 2 processor 940 pin sockets available. One CPU is included in each basic unit.
It is also possible to upgrade a dual-processor system later on.
Two processors with different clock frequencies or different caches are not possible.
A multi-processor operating system is required for a dual-processor system.
Section
Section
III
S26361-F3166-E521 S26361-F3166-E522
Main memory 1GB Main memory 2GB
PC3200 registered DDR RAM PC3200 registered DDR RAM
consisting of two modules consisting of two modules
occupies 2 slots / 1 bank occupies 2 slots / 1 bank
max. 1x or 3x per system max. 1x or 3x per system
S26361-F3166-E523 S26361-F3166-E524
Main memory 4GB Main memory 8GB
PC3200 registered DDR RAM PC3200 registered DDR RAM
consisting of two modules consisting of two modules
occupies 2 slots / 1 bank occupies 2 slots / 1 bank
max. 1x or 3x per system max. 1x or 3x per system
IV
Memory
There are 8 memory slots available (4 banks, each bank consists of two slots => 2 modules per bank are necessary).
They can optionally be equipped with 512MB, 1GB, 2GB (or 4GB if available) registered DDR 400 PC3200 SDRAM modules.
In every basic unit the first memory bank is already equipped with either 1GB, 2GB or 4GB memory,
so the memory extensions can still be configured up to three times for the second, third and fourth memory bank.
Note: Memory is directly connected to the CPU. So, if only one CPU is configured only 4 modules are possible.
Then 1x memory extension can be ordered. For a Dual CPU configuration 3x memory extension can be ordered.
Maximum configurable memory extension is 16 GB (or 28GB when 4 GB modules are available), depending on basic unit.
ECC with memory scrubbing and Chipkill is standard for RX220.
Graphics
as soon as available
Graphics controller on-board (ATI Radeon, 16MB)
C
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
8 of 15
System configurator and order-information guide
C
PRIMERGY RX220 Status 2005-12-20
Section
V
SNP:SY-F2313E1-P S26361-F3123-E1 S26361-F3236-E1
CD-ROM 0,5" 24xATAPI CD-RW / DVD drive 0.5" DVD-RW 8x super multi drive
Connector: LD50 24/24/24x / 8x ATAPI all formats, DUAL/DL, DVD-RAM
incl. description (Ger/US) only W2K, W3K and Linux only W2K, W3K and Linux
0.5" * 5.25", anthracite bezel 0.5 x 5.25", anthracite bezel 0.5 x 5.25", anthracite bezel
max. 1x per system max. 1x per system max. 1x per system
Accessible drives
Setup RX220 by ServerStart is supported with following configurations:
no Floppy, no DVD, no CD:
remote installation only ( PXE service & DHCP server required)
built in CD/DVD or USB CD/DVD, no Floppy disk drive:
UNC Network share reachable or USB Floppy connected
USB Floppy, no CD/DVD:
USB CD/DVD connected
One of the following USB devices must be used for integrating the drivers during installation
process if no automized (e.g. Serverstart / Altiris / RIS / ADS / …) installation is done:
1) USB DVD-ROM:
Traveller III DVD-ROM drive
2) USB DVD+-RW:
Traveller III DVD DL super multi drive
3) FDD USB (external):
external USB FDD
4) USB Keyboard:
KBPC PX D, professional keyboard
5) USB Mouse:
Optical Wheel Mouse
6) USB Memorybird: Memorybird 256 MB S26391-F6046-L256
Memorybird 1GB
S26391-F3152-L200
(USB cable included)
S26391-F3152-L300
(USB cable included)
S26391-F264-L226
(USB cable included)
S26381-K340-V120
S26381-K403-L100
S26391-F6046-L24
Section
S26361-F3219-E80 S26361-F3219-E160 S26361-F3219-E250 S26361-F3199-E1
Hard disk 80GB SATA standard Hard disk 160GB SATA standard Hard disk 250GB SATA standard Upgrade kit hot-plug hard disks
7.200 rpm, <9,0 ms, 8MB Cache 7.200 rpm, <9,0 ms, 8MB Cache 7.200 rpm, <9,0 ms, 8MB Cache including SATA backplane
SATA 3Gb/s SATA 3Gb/s SATA 3Gb/s
easy change easy change easy change
occupies 1" bay occupies 1" bay occupies 1" bay
max. 2x per system max. 2x per system max. 2x per system
max. 2x
VI
Hard disk drives
Every base unit is prepared for easy change SATA standard hard disks.
An option for hot plug hard disks is possible to order.
max. 1x per system
S26361-F3218-E80 S26361-F3218-E160 S26361-F3218-E250
Hard disk 80GB Hard disk 160GB Hard disk 250GB
7200rpm,<9.0 ms, 8MB Cache 7200rpm,<9.0 ms, 8MB Cache 7200rpm,<9.0 ms, 8MB Cache
SATA 3Gb/s SATA 3Gb/s SATA 3Gb/s
hot plug/hot replace tray hot plug/hot replace tray hot plug/hot replace tray
occupies 1" bay occupies 1" bay occupies 1" bay
max. 2x per system max. 2x per system max. 2x per system
D
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
9 of 15
System configurator and order-information guide
PRIMERGY RX220 Status 2005-12-20
D
configuration of
PCI-X 133 MHz slot long PCI-Express x8 slot short
only 1x per System only 1x per System
E
Section
SCSI-Controller
VII
SCSI-controller for
external drives and peripheral devices
S26361-F2399-E1
SCSI U160 controller
Adaptec SCSI Card 29160 for the connection
1 channel: LVD + Fast/ Ultra (decoupl.)
LVD connect. for HD, without cable
Fast/Ultra connect. for acc. drives delivered without
64/66 PCI, min 180 mm
int: Fast 50 pol oder Ultra HD68
+ LVD HD68; ext: HD68(LVD) external cabling
SW: see configurator
max. 1x per system
E F
Only released for
SX10. All contr.
of external storage
systems are
cables. For the
of external storage
systems.
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
10 of 15
System configurator and order-information guide
PRIMERGY RX220 Status 2005-12-20
F
Fibre-Channel Controller
With Qlogic Controller
as soon as available
PCI-X 133 MHz slot long PCI-Express x8 slot short
only 1x per System only 1x per System
G
Section
VIII
No mix and match for Qlogic and Emulex Fibre Channel Controllers possible.
H
With Emulex Controller
S26361-F3141-E10 S26361-F3141-E1
2GBit/s FC Controller 2GBit/s FC Controller
Emulex Emulex
LP1050, full height bracket LP1050Ex
max. 1 channel 2GBit/sec FC controller 1 channel 2GBit/sec FC controller
1x LC Interface for 50um Fiber LC Interface for 50um fiber
PCI-X 64Bit / 133MHz, 170mm
3.3V / 5V tolerant signaling PCI-Express x4, 170mm
max. 1x per system
All controllers for the connection of external storage systems are delivered without cables.
For the configuration of external cabling see the configurator for external storage systems.
max. 1x per system
G
H
With Qlogic Controller
S26361-F3097-E1
2GBit/s FC Controller
Qlogic
QLA2340
1 channel 2GBit/sec FC controller
LC Interface for 50um fiber
PCI-X 64Bit / 133MHz, 170mm
3.3V / 5V tolerant signaling
max. 1x per system
For Fibre Channel SAN also other componets like switches, SFPs and optical wires are
orderable (for details see price liste)
J
I
All controllers for the connection of external storage systems are delivered without cables.
For the configuration of external cabling see the configurator for external storage systems.
For Fibre Channel SAN also other componets like switches, SFPs and optical wires are
orderable (for details see price liste)
I J
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
11 of 15
System configurator and order-information guide
PRIMERGY RX220 Status 2005-12-20
J
PCI-X 133 MHz slot long PCI-Express x8 slot short
only 1x per System only 1x per System
K
Sections
On board
SATA RAID Controller
RAID 0, 1
Promise PDC20319u
2-channel SATA 150 RAID Controller
max. 150MB/s, with cable
32/66 PCI
int.: 2 x SATA 150
SW:
IX
2-channel Ultra 320 SCSI controller for Disk Array
Disk Array
S26361-F3006-E128 S26361-F3090-E256
2-channel RAID Controller U320 2-channel RAID Controller U320
LSI LSI
320-2 320-2x
128MB SDRAM ECC Cache 256MB SDRAM ECC Cache
default with TBBU default with TBBU
plug: internal 2x HD68; plug: internal 2x HD68;
external: 2x VHDCI external: 2x VHDCI
without cable without cable
64/66 PCI controller, 180mm 64/133 PCI-X controller, 180mm
3.3V and 5V tolerant signaling 3.3V and 5V tolerant signaling
max. 1x per system max. 1 x per system
Attention
2-channel RAID
Controller only
usable for
external HDDs (SX30)
K L
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
12 of 15
System configurator and order-information guide
PRIMERGY RX220 Status 2005-12-20
L M
Section
Dual Gigabit Ethernet Contr. Teaming: Failover, Load Balancing
onboard The Intel LAN Controllers 10/100TX. 1000SX , 1000TX
Broadcom can be used with the on-board controller in Teaming Mode.
ext: 2x RJ 45 connector
PCI-X 133 MHz slot long PCI-Express x8 slot short
only 1x per System only 1x per System
max. 2x
Gigabit
Ethernet cards
Communication / Network Communication / Network Low Profile
X
A) Adapters with Teaming capability 10-1000TX /SX
S26361-F3142-E1 S26361-F3143-E1
Gigabit Ethernet Contr. 1000TX Gigabit Ethernet Contr. dual 1000TX
Intel Pro/1000 MT Adapter Eth. Ctrl 2x1Gbit PCIe PRO/1000P Cu
PCI 32 (33/66MHz), min 122 mm Intel Pro/1000P dual Server Adapter
ext: for RJ45-plug, Cat 5 PCIe x4, 170mm
connection with Cat 5 cabling
SW: VLAN, Fast Etherchannel
max. 1x per system
S26361-F3054-E1
Gigabit Ethernet Contr. 1000SX
Eth. Ctrl 1x1Gbit PCI-X Pro/1000MF LC
Intel PRO/1000 MF Server Adapter
Adapter Teaming Support
PCI-X (PCI64/133), min 165 mm
ext:LC-connector
SW: VLAN, Fast Etherchannel
max. 1x per system
S26361-F3053-E1
Gigabit Ethernet Contr. 1000TX
Eth. Ctrl 1x1Gbit PCI-X Pro/1000MT Cu
Intel PRO/1000 MT Server Adapter
Adapter Teaming Support
PCI-X (PCI64/133), min 165 mm
ext: for RJ45-connector, Cat 5
connection with Cat 5 cabling
SW: VLAN, Fast & Gbit Etherchannel
max. 1x per system
Adapter Teaming Support
ext: for RJ45-plug, Cat 5
connection with Cat 5 cabling
SW: VLAN, Fast & Gbit Etherchannel
max. 1x per system
S26361-F3011-E1 S26361-F3227-E1
Gigabit Ethernet Contr dual 1000TX Gigabit Ethernet Contr dual 1000TX
Eth. Ctrl 2x1Gbit PCI-X PRO/1000MT Cu Eth. Ctrl 2x1Gbit PCI-X PRO/1000GT Cu
Intel Pro/1000MT dual Server Adapter Intel Pro/1000GT dual Server Adapter
Adapter Teaming Support
PCI-X (PCI64/66), min 163 mm ext: for RJ45-plug, Cat 5
ext: for RJ45-plug, Cat 5 max. 1x per system
connection with Cat 5 cabling
SW: VLAN, Fast & Gbit Etherchannel
max. 1x per system
M N
while stocks last
PCI-X (PCI64/133)
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
13 of 15
N
PRIMERGY RX220 Status 2005-12-20
System configurator and order-information guide
Section
Section
XI
S26361-F1790-E221 S26361-F2425-E103
RemoteView Software V5.0 RSB S2 LP 3HU
Installation and configuration of
RemoteView Web and LAN FrontEnd
RSB, BMC-Manager, RTDS and FreeDOS
Online manuals
XIII
System Management Products (RemoteView)
Miscellaneous
S26361-F1652-L4
Modem external 56kbps (V.90)
MultiTech
MT5643ZBA-Global
international approval
incl. 2m Telephon cord RJ11/RJ11
Adapter Plug RJ11/TAE
Serial Interface cable DB25m / DB9f
AC-Adapter w. German Power Cord
occupies one COM port
max. 1x per system
RemoteView Service Board S2
Low Profile Version with 3 U bracket
for one standard PCI-slot
incl. cables and RV SW
max. 1x per system
S26361-F2425-E305
RSB S2 LP external power supply
RemoteView Service Board S2
low profile external power supply
including power cable
with Euro- and Euro socket connector
In connection with rack configurations
the install variant of the modem
(S26361-F1652-E4) has to be ordered
(see rack configurator)
Section
End PRIMERGY RX220
XIV
Country specific power cord
Options and other peripherals
For other options, refer to separate "Product specific options"
These options are supplied lose with the shipment
For suitable peripherals for this product, please refer to the section "Peripherals/communication"
Country specific power cords are not required for rack versions, except for USA&Canada.
Power cords are shipped in a rack version with inlet connector for non-heating apparatus.
Description in englisch. Both included in basic unit.
(1x with Standard PSU, 2x with hot plug upgrade)
T26139-Y1742-E10 USA, Canada
For shipments to USA&Canada, you have to order
one power cord (1,8m, grey) per power supply.
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
14 of 15
System configurator and order-information guide
Change Report
Date
Order number
Changes
PRIMERGY RX220 Status 2005-12-20
2005-12-15
2005-12-12
2005-12-12
2005-10-21
S26361-F3227-E1 Gigabit Ethernet Controller dual 1000TX - now available
S26361-F1790-E221 RemoteView Software V5.0 - now available
S26361-F1790-E220 RemoteView Software V4.0 - no longer available
First release
Fujitsu Siemens Computers
Enterprise Products PRIMERGY Server
15 of 15
Loading...
