Fujitsu NTT DOCOMO F-01A Instruction Manual

INSTRUCTION MANUAL

F-01A

ISSUE DATE:

NAME:

PHONE NUMBER:

MAIL ADDRESS:

‘08.X

CA92002-5471

2008.X (Issue 1)

●In case your FOMA terminal is misplaced or stolen, immediately contact DOCOMO to request suspension of usage.

●In case your FOMA terminal has troubles, bring it to the nearest DOCOMO repair handling service counter after returning to Japan.

■In Japanese only

Repairs

0120-800-000 (toll-free)

*

Available from

land-line

phones,

mobile phones and PHSs.

No prefix 113 (toll-free)

* Unavailable from land-line

phones etc.

■In English ■In Japanese only

General Inquiries <DOCOMO Information Center>

●Please check on the number before dialing.

●

For Applications or Repairs/After-Sales Service, please contact the above-mentioned information center or the DOCOMO Shop etc. near you on DOCOMO website or i-mode site.
DOCOMO website http://nttdocomo.co.jp/     i-mode site iMenu→お知らせ (News)→ドコモショップ (DOCOMO Shops)

No prefix 151 (toll-free)

* Unavailable from land-line

phones etc.

0120-005-250 (toll-free)

* Available from land-line phones,
mobile phones and PHSs.

* When calling from

F-01A

, dial [phone] to contact the DOCOMO

Information Center. (Press "0" key for 1 second or more to enter "+".)

Failures encountered overseas

Loss or theft of FOMA terminal or payment of cumulative cost overseas

<DOCOMO Information Center> (24 hours)(In Japanese only)

●From DOCOMO mobile phone

International access number for
your staying country (table 1)

* When calling from F-01A, dial [phone] to contact Network Technical
Operations Center. (Press "0" key for 1 second or more to enter "+".)

<Network Technical Operations Center> (24 hours)

●From DOCOMO mobile phone

International access number for
your staying country (table 1)

●From land-line phone <Universal number>

* For International access number for major countries (table1)/International
phone code for Universal number (table2), see PXXX, XXX in this manual.

International phone code for
Universal number (table 2)

●From land-line phone <Universal number>

* For International access number for major countries (table1)/International
phone code for Universal number (table2), see PXXX, XXX in this manual.

International phone code for
Universal number (table 2)

-81-3-5366-3114* (toll-free)

* Long distance call to Japan will be charged
when calling from a land-line phone.

-81-3-6718-1414* (toll-free)

* Long distance call to Japan will be charged
when calling from a land-line phone.

-800-0120-0151

*

* Local call charges may be required.

-800-5931-8600

*

* Local call charges may be required.

Li-ion

To promote environmental conservation, be sure to
return your used battery pack to NTT DOCOMO’s
sales outlets, our cooperate agencies or the shops
that collect used battery in your community.

Don't forget your mobile phone ･･･or your manners!

When using your mobile phone in a public place, don't forget to
show common courtesy and consideration for others around you.

RetailerNTT DOCOMO, INC.
ManufacturerFUJITSU LIMITED

INSTRUCTION MANUAL

F-01A

’08.X

Easy Search/Contents/Precautions

Before Using the Handset

Appendix/Troubleshooting

Convenient Functions

Network Services

Overseas Use

Character Entry

PC Connection

Voice/Videophone Calls/PushTalk

Phonebook

Sound/Screen/Light Settings

Security Settings

Mail

i-mode/i-motion/i-Channel/i-concier

Full Browser

Camera

Osaifu-Keitai/ToruCa

Map/GPS Function

Data Management

1Seg

i-αppli/i-Widget

Music

Index/Quick Manual

F-01A_E1kou

DOCOMO W-CDMA, GSM/GPRS System

Thank you for purchasing "F-01A" mobile terminal.

Before and during use of your FOMA terminal, be sure to thoroughly read this
manual and instruction manuals that come with other optional devices to ensure
you are able to correctly use you FOMA terminal. For more information, you may
contact us as mentioned on the back of this manual.
F-01A is your capable partner. Please treat it with care and enjoy using it for years.

Before using your FOMA terminal

･

Because your FOMA terminal uses wireless transmission, it may not function in
locations where it is difficult for radio waves to penetrate, such as tunnels,
underground passages and some buildings, in areas where radio waves are
weak, or out of service area. Even when you are high up in a tall building or
condominium and nothing blocks your view outside, your FOMA terminal may
not be able to receive or transmit signals. Also, communication may be
interrupted even when the signal meter on your FOMA terminal indicates there
are strong radio waves and you are not moving (traveling).

･

Use your FOMA terminal in a way that does not disturb others in public spaces,
crowded locations or quiet places.

･

Because your FOMA terminal uses radio waves to communicate, it is possible
that a third party may attempt to tap your calls. However, the W-CDMA, GSM/
GPRS system automatically applies a confidential communication function to all
calls, so even if a third party could somehow tap a call, they only hear noise.

･

Your FOMA terminal encodes voice communication as digital data. When you
are operating your FOMA terminal while moving to a location subject to weaker
radio wave conditions, the transmitted digital data may not be correctly
decoded and as a result the decoded voice may differ somewhat from the actual
voice.

･

Maintain a separate record of the data (Phonebook, Schedule, Notepad,
Recorded messages, Voice memos, Movie memo, etc.) you registered in your
FOMA terminal. Note that DOCOMO assumes no responsibility for any loss of
saved contents of data resulting from malfunction, repair, changing of the
model or other handling of FOMA terminal.

･

You are recommended to save important data to microSD card. Using DOCOMO
keitai datalink, you can transfer and save phonebook, mail, schedule and other
data to a PC.

･

The user hereby agrees that the user shall be solely responsible for the result of
the use of SSL.
Neither DOCOMO nor the cer tifier as listed herein makes any representation and
warranty as for the security in the use of SSL. If the data should be erased,
DOCOMO assumes no responsibility for the loss of any data.
Certifier : VeriSign Japan K.K., Cybertrust Japan Co., Ltd., GlobalSign K.K., RSA
Security Japan Ltd., SECOM Trust Systems Co., Ltd., Comodo CA Ltd.

･

This FOMA terminal supports FOMA Plus-Area and FOMA HIGH-SPEED Area.

･

FOMA terminal can be used only via the FOMA network provided by DOCOMO
and DOCOMO's roaming area.

Before using this manual

This FOMA terminal supports Kisekae Tool (→P108). When changing the design of
the menu screen using Kisekae Tool, the structure of some menus may be changed
according to the usage frequency depending on the menu type. Also, the number
assigned to menu item (item number) may not be applicable to some menu items.

Latest information about this manual can be downloaded from DOCOMO
website.

･

User's Manual Download
http://www.nttdocomo.co.jp/english/support/manual/index.html
*

The URL and contents are subject to change without prior notice.

F-01A.book Page 0 Tuesday, September 2, 2008 6:34 PM

1

F-01A_E1kou

How to use this manual

This manual provides the methods below for necessary function's easy search.

Searching from Easy Search

e

P4

Search for frequently used or convenient functions by plain words.

Searching from Menu list

e

P412

Search from menu displayed on the display of F-01A.

Searching from thumb indices

e

Front cover

Search from the index on the front cover.

*

See P2-3 for examples.

Searching from CONTENTS

e

P6

Search from CONTENTS categorized into chapters by functions.

Searching by main functions

e

P8

Search from featured functions or new functions of F906i.

Searching from the Index

e

P470

Search from the function name, item keyword or service name.

Using the Quick Manual

e

P480

You can cut out Quick Manual from this manual and carry it with you
anywhere.
Also refer to described "Quick Manual (Overseas Use)" when using
FOMA terminal overseas.

・

In this "Manual for F-01A", "F-01A" mobile terminal is usually referred to
as "FOMA terminal". Please be forewarned.

・

This manual explains functions performed with a microSD card. A
microSD card is required separately.
microSD card

→

P320

・

The images or illustration used in this manual are examples and may
differ from the actual displays.

・

The icons and screens that appear on the display and sub-display have
been initialized to the default settings selected from the combinations
prepared in FOMA terminal depending on FOMA terminal color.
This manual mainly gives descriptions assuming that Kisekae Tool is
set to "Rose".

→

P108

・

In this manual, "i-αppli compatible with Osaifu-Keitai which supports IC
card function" is referred to as "Osaifu-Keitai compatible i-

α

ppli".

・

The description of "authenticate" indicates the operating procedure for
entering the terminal security code (4-8 digits) or authenticating your
fingerprint in this manual.
Terminal security code

→

P116 Fingerprint authentication→P118

・

Unauthorized copying of parts of or this entire manual is prohibited.

・

The contents of this manual are subject to change without prior notice.

F-01A.book Page 1 Tuesday, September 2, 2008 6:34 PM

2

F-01A_E1kou

How to use this manual

Methods to search pages are described, taking "Answer machine" for example.

......................................................... 公共モード（ドライブモード） 66

...............................................................

.....

公共モード（電源 OFF） 67

相手の用件を録音／録

画したい

..............................

..........

伝言メモ

68

e 帳話電クートュシップ
f 歴履信着
g ルヤイダ

リ

h

伝言メモ／音声メモ

ha

伝言メモ設定

FFO

hb 覧一

モメ

言伝

hc音録モ

メ声

音

d 録登）MIU（ドーカAMOF

電話に出られないとき

すぐに電話に出られな

いときに保留にしたい

................ 応答保留 66

通話を控える必要があることを伝えたい

87
75
7

5

86
96

663

38

電話／テレビ電話

電話／テレビ電話に出られないとき／出られなかったとき

すぐに電話に出られないときに保留にする .......................... 応答保留

66

応答保留ガイダンスを設定する ..................

応答保留ガイダンス設定 66

公共モードを利用する .............................................................................. 66

電話に出られないときに用件を録音／録画する ..................

伝言メモ 68

伝言メモまたは音声メモを再生／削除する ........................................... 69

テレビ電話の設定

キャラ電を利用する ................................................................................. 70

通話中に相手側に送信する映像について設定する ............................... 70

テレビ電話中の画面表示について設定する ........................................... 71

テレビ電話の設定を変更する .............................

テレビ電話動作設定 71

テレビ電話の代替画像や保留画像などを設定する

Searching from thumb indices

Functions can be searched by using indices
in the order of the front cover, chapter top

page and function description page.
The chapter top page also gives the list of
detailed contents.

Searching from Easy Search

Functions frequently used and c onvenient
functions are categor ized by their purposes
and with s imple words.

Searching from Menu list

Functions can be searched from the words
displayed on the FOMA terminal screen.

仮

仮

仮

仮

仮

F-01A.book Page 2 Tuesday, September 2, 2008 6:34 PM

3

F-01A_E1kou

･

In this manual, operation by pressing keys is represented by graphic symbols.→P26"Names and functions of parts"

･

The representations and meanings of operating procedures are as shown below.

･

In this manual, to select an item by placing the cursor with

udlr

(Multi-cursor key) and pressing g (Enter key) is referred to as "select". Regarding

an operation to enter characters in the entry field, the final step of pressing

g

[OK] is omitted.

･

This manual uses the default settings to describe operations. If the settings are changed, the displays or operations of FOMA terminal may differ from the
ones described in this manual. For the default settings, see Menu List.

→

P412

Representation example Meaning

m

(1 sec. or more)

Press m for 1 second or more.

m

[Settings & NW services]

572e1-3

On the stand-by display, m, move the cursor to [Settings & NW services] and press g. Successively, press

572

, then press any of 1-3.

68

電話／テレビ電話

伝言メモ

電話に出られないときに用件を録音／録画する

伝言メモを起動しておくと、電話に出られないときに応答ガイダンスが流れ、
相手の用件が録音または録画されます。

･ 音声電話とテレビ電話を合わせて最大4 件、1件につき約30 秒間録音また

は録画できます。

◆伝言メモを起動する

伝言メモを起動するかどうかを設定します。

･ FOMA端末を開いている状態で操作してください。

1

サイドキー［▲］（1秒以上）

e1e1または2

伝言メモを起動すると、待受画面に が表示されます。

クイック伝言メモで対応する〈クイック伝言メモ〉

伝言メモを起動していなくても、着信中にサイドキー［▲］を1 秒以上押す
と、その着信に限り伝言メモを1回だけ動作させられます。この操作は、伝
言メモを開始に設定する操作ではありません。

お知らせ

･ 応答ガイダンス中、伝言メモ録音または録画中でも nを押すと電話に出ること

ができます。テレビ電話の場合はIを押しても出られます。a を押すと、相手
には代替画像が送信されます。このとき、電話を受けるまでの録音内容や録画内
容は記録されません。

･ FOMA 端末が圏外にいるときや電源が切れているときは、伝言メモは動作しませ

ん。留守番電話サービスをご利用ください。

･ 伝言メモが 4件録音または録画されると、待受画面に が表示され、伝言メモお

よびクイック伝言メモは動作しません。不要な伝言メモを削除してください。留
守番電話サービスまたは転送でんわサービスを開始にしている場合は各サービス
が動作します。

･ オリジナルマナーモード中は、オリジナルマナーモードの「伝言メモ」の設定に

従います。

2

相手のメッセージが録音または録画される

･ 開始時と終了時に相手には確認音（ピーッ）が鳴ります。また、開始

時から約25秒後に終了予告音（ ピピッ）が鳴ります。

3

録音または録画が終了すると、電話が切れる

Function name

This name is
listed in Index.

Outline and
supplementary
description of
the function

Detailed
description

and
convenient
information
about the

function

Supplementary
description of
the operation

Typical
operating
procedure

* The page shown here represents an example. Images may differ from actual page in this manual.

Index related to thumb index

仮

F-01A.book Page 3 Tuesday, September 2, 2008 6:34 PM

4

Easy Search/Contents/Precautions

F-01A_E1kou

Easy Search

Functions which you want to know can be searched for using friendly words.

Convenient functions for calls

Showing/Hiding your phone number ..................

Caller ID notification

56

Putting the call on hold ..............................................................

On hold

61

Changing the volume of the other party's voice ............

Listen volume

61

Switching from voice call to videophone call

......................................................................

Switching to videophone call

62

When you cannot answer the call

Putting the call on hold when you cannot answer it immediately

..........................................................................................

Respond and Hold

71

Notifying the caller that you have to refrain from talking

............................................................................

Public mode (Drive mode)

72

.............................................................................

Public mode (Power OFF)

72

Recording the other party's voice or image ..............

Answer machine

73

Changing sound, lighting color and vibration

Setting different ring tone etc. for incoming calls from specific parties

..............................................................................................

Alert by contact

88

Changing ring alert ..................................................................

Ring alert

97

Changing loudness of ring tone .....................................

Adjust volume

98

Making vibration when there is an incoming call

........................................................................................

Vibrate alert/effect

99

Muting keypad sound ......................................................

Keypad sound

100

Setting silent mode ..............................................................

Silent mode

101

Changing the color of keypad light ...................................

Keypad light

106

Changing color such as light ..................................................

Light alert

112

Changing displays

Meanings of icons on display ....................................

Display overview

30

Switching the menu display ...............

Selecting functions from menu

36

Changing stand-by display ..........................................

Stand-by display

102

Displaying a calendar on stand-by display ..........

Info/calendar layout

103

Changing font size ....................................................................

Font size

113

Safety and security

Hiding contents of phonebook .....................................

Secret attribute

93

Locking FOMA remotely in case of misplacement etc.

.............................................................................................

Omakase Lock*1122

Rejecting calls with no caller IDs .............................

Anonymous caller

133

Rejecting calls from parties not saved in phonebook

...........................................................................................

Unregistered caller

134

Saving data such as phonebook in case of data loss

................................................................................

Data Security Service*2134

F-01A.book Page 4 Tuesday, September 2, 2008 6:34 PM

5

Easy Search/Contents/Precautions

F-01A_E1kou

Making full use of mail

Sending Deco-mail ..................................................................

Deco-mail

143

Sending images and/or melodies .......................................

Attachment

148

Automatically sorting mails ...............................................

Sort method

164

Making full use of camera

Saving shot still images to microSD card .................................

Save to

213

Changing image size .............

Still image settings/Recording settings

218

Viewing shot still images ............................................

Displaying image

308

Making full use of 1Seg

Watching 1Seg ..................................................................

Activate 1Seg

232

Recording 1Seg ..............................................................

1Seg recording

238

Reserving watching/recording 1Seg

................................................................

Watching/Recording reservation

239

Changing settings of images and sounds .........................

User setting

243

Other convenient functions

Reading QR and/or bar code .........................................

Bar code reader

225

Listening to music ..............................................................

Music player

250

Using GPS function ...........................................................

GPS function

292

Using microSD card ..........................................................

microSD card

320

Sending or receiving data via infrared communication

...............................................................................

Infrared communication

333

Using alarm clock .................................................................

Alarm clock

347

Using calculator ......................................................................

Calculator

360

Using a mobile phone overseas .......................................

Overseas use

396

Updating software .......................................................

Software update

454

Keeping security software updated .........................

Scanning function

458

*1

A charged service.

*2

A charged service requiring subscription.

●

For procedures to search for other functions, see "How to use this manual".→P1

●

Quick Manual introduces you procedures for using convenient functions.→P480

F-01A.book Page 5 Tuesday, September 2, 2008 6:34 PM

6

Easy Search/Contents/Precautions

F-01A_E1kou

CONTENTS

■

Before using your FOMA terminal

Inside front cover

■

How to use this manual ...................................1

■

Easy Search ....................................................... 4

■

Main functions of F-01A ...................................8

■

Precautions (ALWAYS FOLLOW THESE

DIRECTIONS) ..................................................10

■

Handling instructions .....................................17

■

Waterproofness .............................................. 20

■

Basic package and optional accessories ...... 24

Before Using the Handset ...... 25

Names and functions of parts Available styles
Display overview Selecting menu Touch
panel Pointing device Motion sensor Using
UIM (FOMA card) Installing/Removing battery
pack Charging battery Battery level Power
ON/OFF Select language Date & time Caller
ID notification User information etc.

Phone/Videophone/PushTalk

Calls ....................................... 59

Making calls Redial/Received calls Chaku-moji
186/184 Tone signal (DTMF) Call option
WORLD CALL Receiving calls Any key answer
Close settings Respond and Hold Public
mode Recorded messages Using Chara-den
Videophone settings Notify of switchable
mode Making/Receiving PushTalk calls
PushTalk phonebook PushTalk alert etc.

Phonebook ............................. 85

Phonebook new entry Alert by contact Group
settings Search/Edit/Delete phonebook
Secret attribute Quick dial etc.

Sound/Screen/Light Settings

................................................ 95

Ring alert Alarm sound Adjust volume
Vibrate alert/effect Silent mode Timed theme
Stand-by display Call image Mail image
Select startup menu Style theme Light alert
Clock display format Select language etc.

Security Settings.................. 115

Security code Terminal security code change
PIN code Fingerprint authentication All lock
Omakase Lock Self mode Personal data lock
Keypad dial lock Privacy mode Side key hold
Lock on close/Lock when immobile Accept/
Reject call Data security service Reset Delete
all data Initializing remotely Remote control
etc.

Mail .......................................141

Creating/Sending i-mode mail Deco-mail
Decome-Anime Attachment Saving i-mode
mail Quick mail Receiving i-mode mail Check
new message Operating Inbox/Outbox Mail
settings MessageR/F Area Mail Creating/
Sending SMS etc.

i-mode/i-motion/i-Channel/i-

concier ..................................179

Site display Change i-mode password Go to
location Bookmark Screen memo
Downloading from site Uploading to site i­mode settings Operating certificate i-motion
i-Channel i-Channel ticker i-concierge etc.

Full Browser..........................201

Viewing websites for a PC Setting for Full
Browser etc.

Camera..................................209

Still camera Movie camera Sound recorder
Advanced settings Setting for shooting Bar
code reader etc.

F-01A.book Page 6 Tuesday, September 2, 2008 6:34 PM

7

Easy Search/Contents/Precautions

F-01A_E1kou

1Seg ......................................229

Channel setting 1Seg watching Program

guide i-

α

ppli Reserve program Data
broadcasting TVlink Multi window Recording
Remote controller with microphone etc.

Music ....................................245

Setting program Operating Music&Video
Channel Saving music data Playing/
Managing music data BGM play Remote
controller with microphone etc.

i-αppli/i-Widget......................259

Downloading Starting i-αppli i-αppli To i-

α

ppli stand-by display i-αppli call Managing

i-

α

ppli i-Widget etc.

Osaifu-Keitai/ToruCa.............281

iC transfer service Starting Osaifu-Keitai
compatible i-

α

ppli Downloading ToruCa IC

card lock etc.

Map/GPS Function ................291

Position location GPS compatible i-αppli
Location request Notify location Loc. history
Loc. history Map setting Setting GPS etc.

Data Management ................ 307

Displaying/Editing image Playing/Editing
movie/i-motion Machi-chara Chara-den
Playing melody microSD card Managing data
Infrared communication/iC transmission
Displaying PDF Displaying Word, Excel,
PowerPoint files Displaying recording data of
1Seg etc.

Convenient Functions .......... 343

Multiaccess Multitask Quick search Auto
power ON/OFF Countdown timer Alarm clock
Scheduler Shortcut icons Custom menu Side
key shortcut Fake call Voice memo/Movie
memo Call duration/Call cost Calculator
Notepad Dictionaries Pedometer Earphone/
Microphone with switch Bluetooth etc.

Character Entry .................... 373

5-touch input method Save phrase Copying/
Cutting characters KUTEN code input Save
word Password manager DL dictionary 2­touch input Text input method Touch entry
etc.

Network Services ................. 385

Voice Mail service Call waiting Call
forwarding service Nuisance call barring
service Caller ID request service Dual network
service English guidance Service numbers
Arrival call act Remote control Multi number
2in1 OFFICEED Additional service etc.

Overseas use......................... 395

Overview of international roaming service
(WORLD WING) Services available Preparing
and checking for overseas use Making/
Receiving a call Network search mode PLMN
setting 3G/GSM setting Area service status
Roaming guidance Bar calls at roaming
Services available overseas etc.

PC Connection...................... 405

Data communication DOCOMO keitai datalink
etc.

Appendix/Troubleshooting ...411

Menu list Combination of Multiaccess/
Multitask functions Services available
Options and related devices Error messages
Warranty and After-Sales Service Software
update Scanning function SAR certification
information Intellectual property rights etc.

Index/Quick Manual .............. 469

Index Quick Manual Quick Manual (Overseas
Use)

F-01A.book Page 7 Tuesday, September 2, 2008 6:34 PM

8

Easy Search/Contents/Precautions

F-01A_E1kou

Main functions of F-01A

i-concier

i-concier is a service to use FOMA terminal conveniently in which a character on
the stand-by display (Machi-chara) notifies you of useful information and you
can download schedules (i-schedule) from a site.
With i-concier, downloaded schedule or ToruCa is automatically updated with
the latest information, and address information etc. of stores and companies are
automatically added to the phonebook.

→

P200

i-αppli call

i-αppli call is a function allows a third party or content providers to prompt
predetermined i-

α

ppli to be activated and it is used for activating other party's

applications to play a versus game etc.

→

P275

i-Widget

i-Widget is a function that allows you to easily access frequently-used contents
and tools (widget ap plications) such as calculator, clock, a TV program gui de and
stock price information. You can also check the latest information at a glance by
activating widget view.

→

P279

1Seg

You can watch "1Seg" that is a a terrestrial digital TV broadcasting for mobile
devices.
You can also shoot a still image and record video that supports Dubbing+10
(P323) while watching 1Seg.

→

P230

International Roaming

While staying overseas, you can use the same FOMA terminal, phone number
and mail address as those used in Japan (3G/GSM Areas are supported).

→

P396

And, Japanese-English/Japanese-Chinese version of "

しゃべって翻訳

for F
(Speech Translation for F)", an application that interprets your Japanese into
English or Chinese and your English or Chinese into Japanese, is preinstalled.

→

P266

Waterproofness

Waterproof to IPX5 and IPX7 standards if the external connection jack cap is
strictly closed as well as the back cover is mounted and locked.

→

P20
You can talk or send/receive e-mail in the rain, or use the handset in a bath or
near a swimming pool. You can hand wash a dirty handset with tap water.

Flip style and touch operations

Using the flip style, in which the display is rotated out, you can operate by
touching the display or sliding your finger on the display.

→

P39

Pointing device

Pointing operation can be performed with fingerprint sensor. Since the cursor or
pointer can be moved by moving a finger from side to side and up and down
instead of using multi-cursor key, and items can be selected by double-tapping
(tapping twice with a finger), i-

α

ppli or Full Browser can be operated more

intuitively.

→

P44

Motion sensor

You can stop alarm sound by double-tapping FOMA terminal or enjoy watching
light or Flash graphics change by tilting FOMA terminal.

→

P45

Super dual microphones and Super clear-voice 2

2 microphones that have different functions identify the distance to the sound
source and cut noises without deteriorating your voice quality. Also, when Voice
clear is set to ON, noise equalizer adjusts a sound according to a voice range and
emphasizes other party's voice. These two functions allow you to communicate
by delivering each other's voice even in noisy places.

Automatic lighting of sub-display

You can turn on the sub-display light only by picking up and tilting FOMA
terminal.

→

P106

Rainbow key light

You can change the keypad light color to 7 colors.→P106

Machi-chara

A moving character can be displayed in the stand-by display. You can also
download it.

→

P108, 190

Fingerprint authentication

Fingerprint authentication can be performed with FOMA terminal folded. Also,
you can restrict the use of FOMA terminal more strictly by setting "Fingerprint
access" that does not accept security code authentication.

→

P118

L02.fm Page 8 Thursday, September 4, 2008 2:50 PM

Easy Search/Contents/Precautions

9

F-01A_E1kou

Lock when immobile and Immobile sensor

In addition to Lock on close that locks each time FOMA terminal is folded, FOMA
terminal is equipped with Lock when immobile that locks key operations when
no operation is made for the specified time. When Immobile sensor is set to
"ON", Lock when immobile is activated when no operati ons for the specified time
and no movements of FOMA terminal are detected together.

→

P131

High-performance camera

FOMA terminal is equipped with a 511 million pixels camera that has functions
such as a face detection to distinguish people's face, local contrast correction
and high-sensitive shooting mode. Just touch the screen to focus in flip style. A
still image is saved according to the orientation of camera when the image is
shot.

→

P210

Pedometer widget

Pedometer is provided as i-Widget. A character changes according to the
number of steps.

→

P265

Quick search

On the stand-by display or while performing a function, search functions of i­mode, Full Browser, map application, dictionary, phonebook or mail can be used
by pressing Search key.

→

P345

Shortcut icons

Only by selecting the icon pasted on the stand-by display for function, file or mail
being created, you can start the target operation quickly. And, icon on the stand­by display can be changed freely.

→

P353

Pedometer

FOMA terminal can be used as a pedometer, and walking distance, consumed
calories or quantity of burnt fat can be calculated.

→

P362

Bluetooth

A wireless connection can be established between the FOMA terminal and a
Bluetooth device. You can talk with handsfree or listen to music while keeping
the FOMA terminal in a bag etc.

→

P365

Other functions

･

Videophone call→P60

･

Chaku-moji→P65

･

Kisekae Tool→P108

･

Security Settings→P116

･

i-mode mail/Deco-mail/Deco-mail pictogram→P142

･

1Seg→P230

･

Chaku-uta full®/Uta-hodai/Music&Video Channel*/MUSIC Player/Video clip

→

P246

･

i-αppli/Mega i-αppli/Chokkan Game→P260

･

Osaifu-Keitai/ToruCa→P282

･

Map/GPS Function→P292

･

Network services→P386

･

High-speed communication compatibility→P406

*

A charged service requiring subscription.

*

"Chaku-uta full" is registered trademark of Sony Music Entertainment (Japan) Inc.

F-01A.book Page 9 Tuesday, September 2, 2008 6:34 PM

10

Easy Search/Contents/Precautions

F-01A_E1kou

Precautions (ALWAYS FOLLOW THESE
DIRECTIONS)

・

Before using your FOMA terminal, or when necessary, read the
precautions below to ensure safe use and handling. After
reading this manual, keep it carefully.

・

These precautions are intended to protect you and others
around you. Read and follow them carefully to avoid injury,
damage to the product or damage to property.

■

The signs below differentiate between the levels of danger that
can occur if the product is not used within the specified
guidelines.

■

The symbols below show specific directions.

■

Precautions contain the description below.

Handling FOMA terminal, battery pack, adapter (including battery charger)

and UIM (common)........................................................................................ 11

Handling FOMA terminal .................................................................................. 12

Handling battery pack........................................................................................ 14

Handling optional devices (AC Adapter/DC Adapter/Desktop Holder/In-Car

Holder) ............................................................................................................ 15

Handling UIM ..................................................................................................... 16

Handling mobile phones near electronic medical equipment ....................... 16

DANGER

This sign denotes that death or serious
injury may directly result from
improper use.

WARNING

This sign denotes that death or serious
injury may result from improper use.

CAUTION

This sign denotes that bodily injury or
damage to property may result from
improper use.

This symbol denotes that the action is prohibited.

This symbol denotes that disassembling the phone or its
components is not allowed.

This symbol denotes that using the phone or its components
with wet hands is not allowed.

This symbol denotes that using the phone or its components
in a bathroom or other highly humid area is not allowed.

This symbol denotes that an instruction must be obeyed at all
times.

This symbol denotes that the equipment should be
unplugged.

Don't

No disassembly

No wet hands

No liquids

Do

Unplug

F-01A.book Page 10 Tuesday, September 2, 2008 6:34 PM

11

Easy Search/Contents/Precautions

F-01A_E1kou

◆

Handling FOMA terminal, battery
pack, adapter (including battery
charger) and UIM (common)

DANGER

Do not use, store, or leave the
equipment in hot areas such as near
flames or in areas under strong direct
sunlight such as inside a vehicle.

May cause the equipment to be deformed or
malfunction, and battery pack to leak, heat,
burst or ignite, and the capability or life to be
reduced or shortened. Overheating on parts
of the case may cause burns or injuries.

Do not disassemble or remodel the
equipment. Do not solder items onto
the equipment.

May cause fire, injuries, electric shock, or
malfunction. It may also cause the battery
pack to leak, heat, burst or ignite.

Do not let the equipment get wet.

Contact with water or other liquids can cause
heating, electric shock, fire, malfunctions or
injuries. Take care of the place for use and
treatment of the equipment.

Use the battery pack and adapter
(including battery charger) specified
by NTT DOCOMO for your FOMA
terminal.

Use of equipment not specified by DOCOMO
can cause FOMA terminal, battery pack and
other parts to leak, heat, burst, catch fire or
malfunction.
Battery Pack F10
Desktop Holder F27
FOMA AC Adapter 01/02
FOMA DC Adapter 01/02
FOMA Dry Battery Adapter 01
FOMA USB Cable with Charge Function 01/
02
FOMA Portable Charging Adapter 01
FOMA AC Adapter 01 for Global use
*

Contact a sales outlet such as DOCOMO Shop for
information on other compatible products.

WARNING

Do not put the battery pack, FOMA
terminal, adapter (including battery
charger) or UIM in microwave ovens or
other heating appliances or high­pressure containers.

May cause the battery pack to leak, heat,
burst or ignite, FOMA terminal, adapter
(including battery charger) or UIM to heat,
smoke, ignite, or damage circuits.

Do not throw the equipment or give
hard shock to it.

May cause the battery pack to leak, heat,
burst or ignite, and the equipment to
malfunction or catch fire.

Keep conductive materials (metal
pieces, pencil lead, etc.) from coming
in contact with the charging jack or
external connection jack. Do not put
those materials inside the terminal.

May be subject to electrical short and could
cause fire or malfunction.

Turn FOMA terminal OFF before
entering a place such as a gas station
where flammable gases are generated.
Do not charge the battery. The gas
may catch fire.

When using Osaifu-Keitai in a place as a gas
station, turn OFF the terminal before using it.
(When IC card lock is activated, deactivate it
before turning OFF the terminal.)

If the equipment starts giving off a
strange smell, overheats, becomes
discolored or deformed during use,
charging or in storage, immediately
perform the following operations.

1. Remove the power plug from the wall
outlet or cigarette lighter socket.

2. Turn FOMA terminal OFF.

3. Remove the battery pack from FOMA
terminal.

May cause the equipment to heat, burst or
ignite or the battery pack to leak if you keep
using the equipment.

Don't

No disassembly

No liquids

Do

Don't

Don't

Don't

Do

Do

F-01A.book Page 11 Tuesday, September 2, 2008 6:34 PM

12

Easy Search/Contents/Precautions

F-01A_E1kou

CAUTION

Do not leave the equipment on
unstable or sloping surfaces.

May cause malfunction or injuries.

Do not store the equipment in
extremely humid, dusty or hot areas.

May cause malfunction.

Children using the equipment should
be instructed in proper operation by an
adult. Do not allow them to use the
equipment without adult supervision.

May cause injuries.

Store the equipment out of reach of
small children.

May be accidentally swallowed or cause
injuries.

Be careful especially when using
FOMA terminal connected to the
adapter (including battery charger)
continuously for a long time.

If you execute i-αppli, use videophone call or
watch 1Seg while charging the battery pack,
FOMA terminal, battery pack and adapter
(including battery charger) may become hot.
Directly touching a hot part for a long time,
you may have redness, itching or rash on
your skin, or it may result in low­temperature burns depending on your
constitution and/or health condition.

◆

Handling FOMA terminal

WARNING

Do not direct the infrared data port
toward your eye and transmit signals.

May affect your eyes. Faulty operation could
result from directing the infrared data port
toward other infrared equipment and
transmitting signals.

Do not turn on the light by getting the
lighting part closer to other person's
eyes.

May impair eyesight. And may cause
accidents like injury etc., by dazzling or
astounding other people.

Do not put FOMA terminal in the place
such as the dashboard near the air­bag, where the influence of air-bag
explosion is expected.

When the air-bag explodes, FOMA terminal
may hit yourself or others and could cause
injury, equipment malfunction or damage.

When you use electronic medical
equipment, do not keep the terminal in
your chest pocket or inside pocket.

Using your FOMA terminal near medical
electronic equipment could cause
equipment failure.

Do not put foreign objects such as
liquid like water, metal pieces or
burnable things into UIM or microSD
card slot.

May cause fire, electric shock or
malfunction.

Do not turn on the light aiming directly
at the driver of the car etc.

May disturb driving and cause an accident.

Turn FOMA terminal OFF in areas
where use is prohibited, such as in
airplanes and hospitals.

May cause electronic equipment or
electronic medical equipment to fail or
malfunction.
If the function which automatically turns ON
the power is set, cancel the setting before
turning the power OFF.
When using the phone in a medical facility,
be sure to observe the regulations of the
facility. If you do prohibited act such as using
the phone in an airplane, you may be
punished according to law.

When you talk by setting handsfree,
always keep FOMA terminal away
from your ear.
And, when connecting the earphone/
microphone to FOMA terminal and
play a game or music, adjust the
volume moderately.

Too loud volume may cause a hearing loss.
And, if you cannot hear the sound around
you clearly, it may cause an accident.

Don't

Don't

Do

Do

Do

Don't

Don't

Don't

Don't

Don't

Don't

Do

Do

F-01A.book Page 12 Tuesday, September 2, 2008 6:34 PM

13

Easy Search/Contents/Precautions

F-01A_E1kou

If you have weak heart, be careful
when setting the Vibrate alert
(vibration) or alert volume setting.

Could affect heart function.

If it starts thunder while using the
terminal outdoors, turn the power
OFF immediately, and move to a safe
location.

May be subject to lightning strike and could
cause electric shock.

Turn FOMA terminal OFF near high­precision electronic control equipment
or electronic equipment using low­power signals.

May cause the equipment to fail or
malfunction.
*

Examples of electronic equipment to avoid.
Hearing aids, implanted pacemakers or
defibrillators, other electronic medical equipment,
fire alarms, automatic doors and other automatic
control equipment.
Users wearing implanted pacemakers or
defibrillators or other electronic medical
equipment should check with the manufacturer or
sales outlet about the effect of radio frequencies
on the equipment.

When the display or camera lens is
accidentally broken, be careful of
broken glass or exposed internal parts
of FOMA terminal.

Surfaces of display and camera lens are
made of plastic panels and they are
structured for the glass not to scatter,
however, if you mistakenly touch broken or
exposed parts, you may be injured.

CAUTION

Do not swing FOMA terminal by its
strap.

May cause the terminal damage or failure, or
injury to yourself or others.

When using the motion tracking or
motion sensor, check the safety
around you, hold FOMA terminal
firmly, and do not shake it
unnecessarily.

The motion tracking and motion sensor are
functions to operate by tilting or shaking
FOMA terminal. There is a risk that FOMA
terminal hits people or objects around you
by shaking it too much, causing a serious
accident or damage.

If you put a metal strap or the like to
FOMA terminal, be careful not to let
the strap hit people or objects around
you when performing motion tracking
or using motion sensor.

Accidents such as injury, malfunction or
damage may result.

Do not place magnetic disks or cards
with magnetic stripes near FOMA
terminal or place inside and fold the
terminal.

Data stored on media such as cash cards,
credit cards, telephone cards and floppy
disks may be erased if the storage medium is
placed near the phone.

Do not bring magnetized objects close
to FOMA terminal.

Bringing strong magnetism close may cause
a malfunction.

If the display part is accidentally
broken and liquid crystal leaks out, do
not put the liquid in your mouth,
inhale, or make contact with your skin.
If the liquid gets into your eyes or
mouth, rinse it with clean water and
see a doctor immediately.
And, if the liquid adheres to skin or
clothing, use alcohol etc. to wipe it off,
then wash with soap.

May cause loss of sight or skin problems.

Do not bring the speaker close to your
ear when the ring alert is sounding or
you are playing a melody with FOMA
terminal.

May cause hearing loss.

In rare cases, using the phone in some
vehicle models can cause the vehicle's
electronic equipment to malfunction
or fail.

In this case, do not use the phone because it
may hamper safe driving.

Do

Do

Do

Do

Don't

Don't

Don't

Don't

Don't

Don't

Don't

Do

F-01A.book Page 13 Tuesday, September 2, 2008 6:34 PM

14

Easy Search/Contents/Precautions

F-01A_E1kou

Mobile phones can give some users
skin problems such as itching, allergic
reactions or rashes. If you develop skin
problems, stop using the phone
immediately, and see a doctor.

FOMA terminal contains metal in the parts
below.

When opening or closing FOMA
terminal, take care not to have your
fingers or strap caught by the terminal.

May cause injuries or damages.

When watching 1Seg, take a certain
distance from the display in a fully
bright place.

May cause your eyesight to be impaired.

◆

Handling battery pack

■

Check that the battery type matches the
type displayed on the battery pack label.

DANGER

Do not connect a wire or other metal
objects to the jack. And, do not carry or
store FOMA terminal with objects like
a metal necklace.

May cause the battery pack to leak, heat,
burst or ignite.

Do not try to force the battery pack
onto FOMA terminal if you are having
trouble installing it. Always install it
after checking that it is correctly
oriented.

May cause the battery pack to leak, heat,
burst or ignite.

Do not throw the battery pack into the
fire.

May cause the battery pack to leak, heat,
burst or ignite.

Do not nail the battery pack, hit with a
hammer or step on it.

May cause the battery pack to leak, heat,
burst or ignite.

If the battery pack's fluid contacts
eyes, immediately flush the eyes with

clean water and see a doctor right
away. Do not rub the eyes.

May cause loss of sight.

WARNING

If the battery pack seems to have
abnormalities such as deformation or
scratches due to an external impact or
falling, stop using it immediately.

May cause the battery pack to leak, heat,
burst or ignite, and the equipment to
malfunction or catch fire.

If the battery pack does not have a full
charge after being charged for the
specified time, stop charging it.

May cause the battery pack to leak, heat,
burst or ignite.

If the battery pack leaks or gives off a
strange smell, immediately remove it
from the vicinity of open flames.

The vapors from leaking battery pack fluid
may ignite or explode.

Be careful not to let your pet bite the
battery pack.

May cause the battery pack to leak, heat,
burst or ignite, and the equipment to
malfunction or catch fire.

Place of use Material Surface finishing

Model name panel on the
back

Stainless Coating

Fingerprint sensor Stainless Trivalent chrome

plating

Metal part of
the TV
antenna

Front edge,
Center part,
Lower hinge

Brass Ni plating

Extendable
shaft

Stainless None

Upper hinge Stainless Ni plating, NiPd

plating

Charging jack Copper Gold plating

Do

Do

Do

Display Battery type

Li-ion Li-ion battery

Don't

Don't

Don't

Don't

Do

Don't

Do

Do

Do

F-01A.book Page 14 Tuesday, September 2, 2008 6:34 PM

15

Easy Search/Contents/Precautions

F-01A_E1kou

CAUTION

Do not discard old battery packs
together with other garbage.

May cause igniting or environmental
destruction. Tape the terminals of old
battery packs to insulate them, and then
bring them into a sales outlet such as
DOCOMO Shop. If your local municipality
has a battery recycling program, dispose of
them as provided for.

Do not charge a wet battery pack.

May cause heat generation, ignition or
rupture of the battery pack.

If the battery pack's fluid contacts skin
or clothes, immediately flush the
contacted area thoroughly with clean
water.

May hurt the skin.

◆

Handling optional devices (AC
Adapter/DC Adapter/Desktop
Holder/In-Car Holder)

WARNING

Do not use the adapter (including
battery charger) cord or power cord if
it gets damaged.

May cause electric shock, heat or fire.

Do not use the AC adapter or desktop
holder (battery pack's battery charger)
in a bathroom or other highly humid
area.

May cause electric shock.

Always use the DC adapter with a
negative-ground vehicle. Do not plug it
into a positive-ground vehicle.

May cause fire.

When it starts to thunder, do not touch
FOMA terminal and adapter (including
battery charger).

May be subject to lightning strike and could
cause electric shock.

Do not short the charging jack while it
is connected to the outlet or cigarette
lighter socket. Do not touch the
charging jack with a part of your body
such as your hand or finger.

May cause fire, malfunction, electric shock
or injuries.

Place battery charger and desktop
holder in a stable location while
charging. Do not cover or wrap battery
charger and desktop holder with a
cloth, blanket, etc.

May cause FOMA terminal to be removed or
the optional devices to be heated, resulting
in fire or troubles.

Do not place heavy objects on the
adapter (including battery charger)
cord or power cord.

May cause electric shock or fire.

Do not touch the adapter (including
battery charger) cord or outlet with
wet hands.

May cause electric shock.

Only use with the specified power
source and voltage.

If incorrect voltage is used, this may cause
fire or failure. When using FOMA terminal
overseas, use AC Adapter for global use.
AC adapter : AC100V
DC adapter : 12 or 24V DC (specific for

negative ground vehicle)

AC adapter for global use : Between 100V

and 240V AC (Connect to the AC outlet for
internal household use)

If the DC adapter's fuse blows, replace
it only with the specified fuse.

Using other fuses may cause fire or
equipment failure. For the specified fuse, see
the instructions that come with the DC
adapter.

Wipe off any dust that accumulates on
the power plug.

May cause fire.

When you connect the AC adapter to
an outlet, make sure not to touch with
metal such as metal straps and firmly
connect to the outlet.

May cause electric shock, electrical short or
fire.

When you disconnect the adapter
(including battery charger) from the
outlet or cigarette lighter socket, do
not pull the adapter (including battery

Don't

Don't

Do

Don't

Don't

Don't

Don't

Don't

Don't

Don't

No wet hands

Do

Do

Do

Do

Do

F-01A.book Page 15 Tuesday, September 2, 2008 6:34 PM

16

Easy Search/Contents/Precautions

F-01A_E1kou

charger) cord or power cord with
excessive force; instead hold the plug
to disconnect.

Pulling the cord could damage it, possibly
leading to electric shock or fire.

Always remove the power plug from
the outlet when not using the adapter
for an extended period.

May cause electric shock, fire or
malfunction.

Immediately remove the power plug
from the outlet or cigarette lighter
socket if water or other fluids get into
the adapter.

May cause electric shock, smoke or fire.

Always remove the power plug from
the cigarette lighter socket when
cleaning the equipment.

May cause electric shock.

◆

Handling UIM

CAUTION

Be careful of the cut surface when
removing UIM (ICs).

May hurt hands or fingers.

◆

Handling mobile phones near
electronic medical equipment

■

These precautions are based on the
guidelines produced at the
Electromagnetic Compatibility
Conference Japan, regarding the
protection of electronic medical
equipment from radio waves emitted by
mobile phone units.

WARNING

Obey the following rules inside
medical facilities.

･

Do not bring FOMA terminal into
operating rooms (ORs), intensive care
units (ICUs) or coronary care units (CCUs).

･

Turn FOMA terminal OFF in hospital
wards.

･

Turn FOMA terminal OFF in hospital
lobbies and corridors if electronic medical
equipment could be nearby.

･

If the medical facility has specified zones
where use or possession of mobile
devices is prohibited, obey those
instructions.

･

If the function to automatically turn ON
the power is set, cancel the setting before
turning the power OFF.

Turn FOMA terminal OFF in crowded
trains or other public places where
pacemaker or defibrillator wearers
could be nearby.

FOMA terminal's signals may affect the
operation of implanted pacemakers or
defibrillators, and other devices.

Wearers of implanted pacemakers or
defibrillators must carry and use
FOMA terminal at least 22 cm away
from the implanted device.

FOMA terminal's signals may affect the
operation of implanted pacemakers or
defibrillators, and other devices.

When electronic medical equipment
other than implanted pacemakers or
defibrillators are in use outside of
medical facilities (such as in home care
settings), check with the device
manufacturer to determine how the
device is affected by electrical signals.

FOMA terminal's signals may affect the
performance of electronic medical
equipment.

Unplug

Unplug

Unplug

Do

Do

Do

Do

Do

F-01A.book Page 16 Tuesday, September 2, 2008 6:34 PM

17

Easy Search/Contents/Precautions

F-01A_E1kou

Handling instructions

◆

General

・

F-01A is waterproof, however, do not allow water to seep into the handset and do
not allow accessories or optional devices to get wet.

- This FOMA terminal is waterproof to IPX5 and IPX7 standards if the external connection jack
cap is strictly closed as well as the back cover is mounted and locked, however, it is not
completely waterproof. In the rain or with the handset wet, do not remove/insert the battery
pack or open/close the external connection jack cap or the back cover. Seeped water may cause
corrosion inside the terminal. Accessories and optional devices are not waterproof.
Malfunctions deemed to have been caused by water are not covered by the warranty. Since
these conditions are outside the scope of the warranty, a repair, if at all possible, is charged.

・

Clean FOMA terminal with a dry soft cloth (such as a cloth for eyeglasses).

- The display of FOMA terminal may have been applied special coating to improve clearness of
the color LCD. When cleaning FOMA terminal, rubbing it roughly with a dry cloth can scratch
the display. Take care when handling the unit, and clean it with a dry soft cloth (such as a cloth
for eyeglasses). Drops of water or dirt left on the display can cause stains or remove the
coating.

- If FOMA terminal is wiped with alcohol, paint thinner, benzine or detergent, the printing may
disappear or color may fade.

・

Clean the jack occasionally with a dry cotton swab.

- If the jack is dirty, the contact may become poor and the power may shut OFF. A dirty jack
can result in poor charging, so clean it with a dry cloth or cotton swab.

・

Do not place FOMA terminal near an air-conditioner outlet.

- The rapid change in temperature may cause condensation, causing internal corrosion and
malfunction.

・

When using, be careful not to subject excessive force to FOMA terminal or the
battery.

- If FOMA terminal is crammed into a brimming bag or placed in a pocket and sat on, display,
internal PCBs or battery pack may be damaged or malfunction. And, if external devices are
plugged into the external connection jack or earphone/microphone jack, the breakage of the
connector or malfunction may result.

・

Carefully read the separate instructions that come with FOMA terminal, adapter
(including battery charger) and desktop holder.

・

Do not rub or scrape the display with a metal piece etc.

- It may scratch the display, causing malfunction or damage.

◆

FOMA terminal

・

Avoid extreme temperature.

- Use the FOMA terminal where the ambient temperature ranges between 5 and 40℃ (for
temperatures of 36

℃

or higher, such as in a room with a bath, limit usage to a short period of

time) and the ambient humidity ranges between 45 and 85%.

・

FOMA terminal may affect land-line phones, TVs or radios in use nearby, so use
it as far as possible from these appliances.

・

Maintain a separate record of the data you saved in your FOMA terminal.

- If the data is deleted, DOCOMO assumes no responsibility for the loss of any data.

・

Do not plug external devices into the external connection jack or the earphone/
microphone jack at a slant, or do not pull it forcibly while it is plugged.

- May cause malfunction or damage.

・

Do not fold FOMA terminal with the strap held inside.

- May cause malfunction or damage.

・

It is normal for FOMA terminal to become warm during use or charging. Continue
to use it.

・

Do not leave FOMA terminal with the camera in areas under strong direct
sunlight.

- May cause discoloring or burn-in of materials.

・

The terminal should normally be used with the external connection jack cap
closed.

- Dust and/or water brought into FOMA terminal cause troubles.

・

Do not use FOMA terminal with the back cover removed.

- It may cause the battery to come off, or may cause a malfunction or damage.

・

Do not put an extremely thick sticker etc. on the display or keypad.

- May cause malfunction.

・

Do not give a hard shock to the fingerprint sensor and take care not to scratch its
surface.

- May not only cause the fingerprint sensor to malfunction, but also disable authentication or
pointing operation.

F-01A.book Page 17 Tuesday, September 2, 2008 6:34 PM

18

Easy Search/Contents/Precautions

F-01A_E1kou

・

Clean the fingerprint sensor by wiping with a dry soft cloth (e.g. eyeglass cleaner).

- Any soil or water attached to the surface of the fingerprint sensor may cause fingerprint scan
failure, which may lead to reduction of the authentication performance, an error where the
sensor operates as authenticating when the finger is not in contact or disability of pointing
operation.

・

Do not turn FOMA terminal OFF while using microSD card.

- It may cause data loss or malfunction.

◆

Battery pack

・

The battery pack is a consumable part.

- Replace the battery pack if FOMA terminal has extremely short operation time on a full
charge, though it may vary by operating conditions. Purchase a new battery pack of the
specified type.

・

Charge the battery in an area within the proper ambient temperature range (5-35

℃

).

・

Always charge before using it for the first time or after extended disuse.

・

The operation time provided by the battery pack varies by the operating
environment and battery pack's deterioration.

・

The battery pack may swell out as it comes to near the end of its lifetime
depending on the usage conditions, but it is not a problem.

・

Do not preserve or leave the battery pack as it is empty.

- It may cause the battery pack performance to be degraded or its lifetime to be shortened.

◆

Adapter (including battery charger)

・

Charge the battery in an area within the proper ambient temperature range (5-35

℃

).

・

Do not charge the battery in the areas below.

- In areas of excessive humidity, dust or vibrations

- Near land-line phones or TVs/radios

・

It is normal for the adapter (including battery charger) to become warm while
charging. Continue to use it.

・

When using the DC adapter for charging, keep the vehicle engine running.

- The vehicle's battery could become flat.

・

When using an outlet with a mechanism preventing unplugging, follow the
handling instructions for that outlet.

・

Do not give strong shock. Do not deform the charging jack.

- May cause malfunction.

・

When folding the desktop holder, take care to avoid catching your fingers or
adapter cables (including the charger cord) in the holder.

- May cause injuries or damage.

◆

UIM

・

Do not use excessive force to install/remove UIM.

・

It is normal for UIM to become warm during use. Continue to use it.

・

Note that DOCOMO assumes no responsibility for malfunctions occurring as the
result of inserting and using a UIM with another IC card reader/writer.

・

Always keep UIM ICs clean.

・

Clean UIM with a soft, dry cloth (such as a cloth for eyeglasses).

・

Maintain a separate record of the data you saved in UIM.

- If the data is deleted, DOCOMO assumes no responsibility for the loss of any data.

・

To preserve the environment, bring the old UIM to a sales outlet such as
DOCOMO Shop.

・

Avoid extreme temperature.

・

Take care not to scratch, touch accidentally or short IC.

- May cause data loss or malfunction.

・

Do not drop UIM or subject it to shocks.

- May cause malfunction.

・

Do not bend UIM or place heavy objects on it.

- May cause malfunction.

・

Do not install UIM into FOMA terminal with a label or sticker put on UIM.

- May cause malfunction.

◆

Bluetooth devices

・

This FOMA terminal is equipped with the security features, that are compliant
with Bluetooth standards for communication via Bluetooth. However, depending
on the settings, there may not be enough security. Be aware of security risks
when using Bluetooth.

・

DOCOMO assumes no responsibility for any information which may be leaked
during communication via Bluetooth.

・

With this FOMA handset, you can use a Bluetooth headset, handsfree, audio, dial­up connection and object push device. An audio/video remote control may be
available with an audio device (for Bluetooth compatible devices).

・

Frequency bands
Frequency bands used by FOMA terminal Bluetooth function are as below.

F-01A.book Page 18 Tuesday, September 2, 2008 6:34 PM

19

Easy Search/Contents/Precautions

F-01A_E1kou

a

2.4 : Radio equipment that uses the 2400 MHz band.

b

FH : The modulation is the FH-SS method.

c

1 : The expected interference distance is 10 m or shorter.

d

: All bandwidths between 2400 MHz and 2483.5 MHz are used,
and the bandwidth used by mobile object identification devices cannot be
avoided.

Cautions on using Bluetooth devices

In the bandwidth used by this handset, in addition to home electric appliances
such as a microwave oven and industri al/scientific/medical devices, in-plant radio
stations used to identify mobile objects used in production lines of a factory that
require a license, specified low power radio stations, or amateur radio stations
that do not require a license (hereafter "other radio stations") can be in operation.

1. Before using this terminal, check whether other radio stations are in operation
in your neighborhood.

2. If radio wave interference occurs between the terminal and "other radio
stations", use the terminal in a different location or "Turn the power OFF" to
avoid the radio wave interference.

3. For more detailed information, contact "General Inquiries" using the phone
number on the back of this manual.

◆

FeliCa reader/writer

・

FeliCa reader/writer function of FOMA terminal uses weak waves requiring no
licenses for radio stations.

・

It uses 13.56 MHz frequency band. When using other reader/writers in your
surroundings, keep FOMA terminal away sufficiently from them. Before using the
FeliCa reader/writer, confirm that there are no radio stations using the same
frequency band nearby.

◆

CAUTION

・

Do not use a remodeled FOMA terminal. Using a remodeled terminal violates the
Radio Law.
FOMA terminal is certified according to technical standard conformance of
specified wireless equipment based on the Radio Law, and as a proof of it, the
"Technical Compliance Mark " is depicted on the engraved sticker of FOMA
terminal.
If you remodel FOMA terminal by removing its screws, your certification of
technical standard conformance becomes invalid.
Do not use FOMA terminal with its certification of technical standard
conformance invalid as it violates the Radio Law.

・

Be careful when you use FOMA terminal while driving a car etc.
Using a mobile phone while driving is subject to penal regulations.
If you inevitably receive a call, tell the caller that you will "call back" by handsfree,
then park in a safe place and call back.

・

Use FeliCa reader/writer function only in Japan.
FeliCa reader/writer function of FOMA terminal conforms to Japanese radio
standards.
If you use this function overseas, you may be punished.

・

Use the Bluetooth function only in Japan.
The Bluetooth function of the FOMA terminal is compliant with wireless
standards and is authorized for use only in Japan.
If you use this function overseas, you may be punished.

abdc

2.4FH1

F-01A.book Page 19 Tuesday, September 2, 2008 6:34 PM
