Fujitsu MC8355, WL0025 User Manual

User’s

Guide

Learn how to use your

Fujitsu STYLISTIC® Q550 Tablet PC

Fujitsu America, Inc.has made every ef fort to ensu re the accu racy and completeness of this document. Because ong oing development ef forts are made to continually improve the capabilities of our products, however, the data contained herein represents Fujitsu design objectives and is provided for comparative purposes; actual results may vary based on a variety of factors. This product data does not constitute a warranty. Specifications are subject to change without knowledge.

Fujitsu and the Fujitsu logo are registered trademarks of Fujitsu Limited; STYLISTIC is a registered trademark of Fujitsu America, Incorporated.

Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. The SD Logo is is registered with the U.S. Patent and Trademark Office and with other trademark offices around the world by SD-3C, LLC. Intel, Intel Core, and Intel Atom are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other

countries. OmniPass is a trademark of Softex, Inc. Broadcom is a registered trademark of Broadcom Corporation.smartcard Norton Internet Security is a trademark of Symantec Corporation in the United States and other countries.

AirPrime is a trademark of Sierra Wi reless Inc. Gobi3000 is a trademark of Qualcomm Inc. Nuance and XT9 are either registered trademarks or trademarks of Nuance Communications, Incorporated. Adobe and Adobe Reader are registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

Ralink is a registered trademark of Ralink Technolo gy Corporation. Bluetooth and the Bluetooth logo are registered trademarks of Bluetooth SIG, Inc. Realtek is a trademark of Realtek Semiconductor Corp. Wi-Fi is a trademark of the Wireless Ethernet Compatibility Alliance (WECA).

All other products are trademarks or registered trademarks of their respective companies. All other trademarks mentioned herein are the property of their respective owners

Copyright 2011 Fujitsu America, Incorporated. All rights reserved. No part of this publication may be copied , reproduced, or translated, without the prior written consent of Fujitsu America, Incorporated. No part of this p ublication may be stored or transmitted in any electronic form without the prior consent of Fujitsu America, Incorporated. B5FJ-9941-01ENZ0-00

USER GUIDE FOR WIRELESS BROADBAND CONNECTION

IF YOU HAVE THE OPTIONAL WIRELESS WAN (WWAN) DEVICE INSTALLED IN YOUR TABLET PC, THE WWAN USER’S

GUIDE IS LOCATED AT: 



http://solutions.us.fujitsu.com/www/content/support/mobile/support_notices

LEASE CLICK “3G MINI-CARD GOBI3000 REGULATORY AND SAFETY INFORMATION” TO OPEN THE FULL USER GUIDE

CONTAINING WARNINGS AND PRECAUTIONS ASSOCIATED WITH RF SAFETY WHEN USING THE WWAN DEVICE.

DECLARATION OF CONFORMITY

according to FCC Part 15

Responsible Party Name: Fujitsu America, Incorporated Address: 1250 E. Arques Avenue,

Sunnyvale, CA 94085 Telephone: (408) 746-6000 Declares that product: Base Model Configuration: STYLISTIC Q550 Tablet PC

Complies with Part 15 of the FCC Rules.

This device complies with Part 15 of the FCC rules. Operations are subject to the following two conditions: (1) This device may not cause harmful interference, (2) This device must accept any interference received,  including interference that may cause undesired operation.

IMPORTANT SAFETY INSTRUCTIONS

AC adapter output polarity:

This unit requires an AC adapter to operate. Use only UL Listed I.T.E. Class II Adapters with an output rating of 19 VDC, with a current of

2.1A (40 W).

When using your tablet PC, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following:

CAUTION: HOT SURFACE: THE BOTTOM OF THIS COMPUTER CAN BECOME HOT WHEN USED FOR

LONG PERIODS OF TIME. WHEN USING THIS DEVICE, TAKE CAUTION TO LIMIT LONG TERM OR CONTINUOUS USE WHILE RESTING IT ON EXPOSED SKIN, SUCH AS THE LAP.

• Do not use this product near water for example, near a bathtub, washbowl, kitchen sink or laundry tub, in a wet basement

or near a swimming pool.

• Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode.

Check with local codes for possible special disposal instructions.

SAVE THESE INSTRUCTIONS

For Authorized Repair Technicians Only

ANGER OF EXPLOSION IF LITHIUM (CLOCK) BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY

WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER. DISPOSE OF USED BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTION.

OR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH THE SAME TYPE AND

RATING FUSE.

Recycling your battery

Over time, the batteries that run your mobile computer will begin to hold a charge for a shorter amount of time; this is a natural occurrence for all batteries. When this occurs, you may want to replace the battery with a fresh one*. If you replace it, it is important that you disp ose of the old battery properly because batteries contain materials that could cause environmental damage if disposed of improperly.

Fujitsu is very concerned with environmental protection, and has enlisted the services of the Rechargeable Battery Recycling Corporation (RBRC)**, a non-profit public service organization dedicated to protecting our environment by recycling old batteries at no cost to you.

RBRC has drop-off points at tens of thousands of locations throughout the United States and Canada. To find the location nearest you, go to www.RBRC.org

If there are no convenient RBRC locations near you, you can also go to the EIA Consumer Education Initiative website (http://EIAE.org/) and search for a convenient disposal location.

Remember – protecting the environment is a cooperative effort, and you should make every effort to protect it for current and future generations.

* To order a new battery for your Fujitsu mobile computer, go to the Fujitsu shopping site at www.shopfujitsu.com in the US or

www.fujitsu.ca/products/notebooks in Canada.

** RBRC is an independent third party to which Fujitsu provides funding for battery recycling; RBRC is in no way affiliated with

Fujitsu.

or call 1-800-822-8837.

Contents

Preface

About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Conventions Used in the Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Fujitsu Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Chapter 1 Getting to Know Your Tablet PC

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Locating the Connectors and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Front Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Back Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Status Indicator Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Display Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Adjusting Display Panel Brightness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Active Digitizer/Touchscreen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Active Digitizer Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Using the Capacitive Touchscreen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Accessing the OnScreen TouchPad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Using the Nuance SoftKeyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Caring for the Pen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Tablet PC Buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Chapter 2 Getting Started with Your Tablet PC

Power Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Connecting the Power Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Starting Your STYLISTIC Tablet PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Boot Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Hard Disk Drive Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

BIOS Setup Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Booting the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Starting Windows the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Registering Your STYLISTIC Tablet PC with Fujitsu . . . . . . . . . . . . . . . 42

Installing ClickMe!. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Power Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Power/Suspend/Resume Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Sleep Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Hibernation Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Windows Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Restarting the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Powering Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Chapter 3 User-Installable Features

Lithium Polymer Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Recharging the Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Replacing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Secure Digital Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Installing SD Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Removing an SD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Chapter 4 Troubleshooting Your Tablet PC

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Identifying the Problem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Specific Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Power On Self Test Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Restoring Your Pre-installed Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Re-installing Individual Drivers and Applications. . . . . . . . . . . . . . . . . . . 65

Restoring the Operating System for Windows. . . . . . . . . . . . . . . . . . . . . . 66

Chapter 5 Care and Maintenance

Caring for your Tablet PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Cleaning your Tablet PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Storing your Tablet PC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Traveling with your Tablet PC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Media Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Secure Digital Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Chapter 6 System Specifications

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Configuration Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Microprocessor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Chipset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Video. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Mass Storage Device Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Communications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Security Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Device Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Dimensions and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Environmental Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Popular Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Included Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Learning About Your Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Appendix A: WLAN User’s Guide

Before Using the Optional Wireless LAN. . . . . . . . . . . . . . . . . . . . . . . . . . 87

Wireless LAN Device Covered by this Document. . . . . . . . . . . . . . . . . . . 87

Characteristics of the WLAN Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Wireless LAN Modes Using this Device . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Deactivating/Disconnecting the WLAN Device . . . . . . . . . . . . . . . . . . . . 90

Deactivation Using the Wireless On/Off Switch . . . . . . . . . . . . . . . . . . . . 91

Disconnection Using the Icon in the Taskbar. . . . . . . . . . . . . . . . . . . . . . . 91

Activating the WLAN Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Configuring the Wireless LAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Configuring the WLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Connection to the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Troubleshooting the WLAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

WLAN Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Using the Bluetooth Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

What is Bluetooth. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Where to Find Information About Bluetooth. . . . . . . . . . . . . . . . . . . . . . . 97

Appendix B: Fingerprint Sensor Device

Introducing the Fingerprint Sensor Device . . . . . . . . . . . . . . . . . . . . . . . . 99

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Installing OmniPass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

User Enrollment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

Using OmniPass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

Configuring OmniPass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

OmniPass Control Center. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Appendix C: FujitsuHL User Guide

FujitsuHL Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Starting FujitsuHL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Closing FujitsuHL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

About FujitsuHL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Home Launcher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Gadget Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Launcher Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

Photo Launcher. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

Documents Launcher . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Camera Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

Photo Viewer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

Preface

About This Guide

The STYLISTIC Q550 Tablet PC is a high-performance pen-based computer that has been designed to support MicrosoftWindows 7 Professional edition.

This manual explains how to operate your Tablet PC hardware and built-in system software. The STYLISTIC Q550 Tablet PC is a completely self-contained unit with a 10.1” WXGA LED backlit

IPS display with 160 degree vertical and horizontal viewing angles. It has a powerful interface that enables it to support a variety of optional features.

Conventions Used in the Guide

Pages with additional information about a specific topic are cross-referenced within the text. On screen buttons or menu items appear in bold. Example: Click OK to restart your Tablet PC.

THE INFORMATION ICON HIGHLIGHTS INFORMATION THAT WILL ENHANCE YOUR UNDERSTANDING OF

THE SUBJECT MATERIAL.

HE CAUTION ICON HIGHLIGHTS INFORMATION THAT IS IMPORTANT TO THE SAFE OPERATION OF YOUR

COMPUTER, OR TO THE INTEGRITY OF YOUR FILES. PLEASE READ ALL CAUTION INFORMATION CAREFULLY.

THE WARNING ICON HIGHLIGHTS INFORMATION THAT CAN BE HAZARDOUS TO EITHER YOU, YOUR T

ABLET PC, OR YOUR FILES. PLEASE READ ALL WARNING INFORMATION CAREFULLY.

Fujitsu Contact Information

Service and Support

You can contact Fujitsu Service and Support in the following ways:

• Toll free: 1-800-8Fujitsu (1-800-838-5487)

• Website: http://www.computers.us.fujitsu.com/support

Before you place the call, you should have the following information ready so that the customer support representative can provide you with the fastest possible solution:

• Product name

• Product configuration and serial numbers

• Purchase date

• Conditions under which the problem occurred

• Any error messages that have occurred

• Type of device connected, if any

Fujitsu Shopping Online

You can go directly to the online by going to the website at: www.shopfujitsu.com.

Limited Warranty

Your STYLISTIC Q550 Tablet PC is backed by a Fujitsu International Limited Warranty. Check the service kit that came with your tablet PC for the Limited Warranty period and terms and conditions.

- About This Guide

Chapter 1

Getting to Know Your Tablet PC

Overview

The STYLISTIC Q550 T ablet PC is a high-performance pen-based computer that has been designed to support Microsoft Windows7 Professional edition.

This chapter provides an overview of the STYLISTIC Q550 T ablet PC and its many features.

Figure 1. STYLISTIC Q550 Tablet PC

Locating the Connectors and Controls

Front Web Camera

Display

Pen Tether Attachment Point

Wireless Device Switch

Application Buttons

Status Indicators

Power/Suspend/ Resume Switch

DC Input Connector

Speaker

Docking Cradle Connector

Features and controls that you use to operate your T ablet PC are outlined below and illustrated in Figures 2 and 3. Details on using these features and controls are provided later in this manual.

Front Features

Front Web Camera

The front-facing VGA web camera allows you to take pictures of yourself to send over the internet. For information on using the microphone and web cam, see the documentation associated with the FujitsuHL application.

Figure 2. STYLISTIC Q550 Tablet PC Features (Bottom, Right View)

- Locating the Connectors and Controls

Display

The 10.1” Wide XGA display offers 160 degree vertical and horizontal viewing angles.

Pen Tether Attachment Point

The pen tether attachment point is used to connect your pen -- or stylus -- to the system to prevent its loss.

Wireless Device On/Off switch

The wireless device on/off switch is used to turn the optional WLAN, WWAN, and Bluetooth devices on and off. Switching the device off when not in use will help to extend battery life.

Application Buttons

Allow you to quickly launch pre-defined applications and utilities, rotate your screen, and perform CtlAlt-Del by pressing a button. See “Tablet PC Buttons” on page 33.

System Status Indicators

Indicate the operational status of the Tablet PC power and battery charge level. See “Status Indicator Panel” on page 18.

Power/Suspend/Resume Switch

Allows you to turn on, off, sleep, resume, hibernate or wake the T ablet PC in order to optimize battery life. See “Starting Your STYLISTIC Tablet PC” on page 37.

DC input connector:

Allows you to connect the AC adapter or auto adapter.

Speaker

The speaker allows you to hear sound from the system.

Docking Cradle Connector

Allows you to connect the optional STYLISTIC Docking Cradle.

- Locating the Connectors and Controls

Battery Release Latches

Rear Web Camera

SD Card Slot

Fingerprint Sensor

Built-in Microphone

USB 2.0 Port

SmartCard Slot Line Out/

Headphone Jack

HDMI Port

Built-in Microphone

Removable Battery

Figure 3. STYLISTIC Q550 Tablet PC Features (Back View)

Back Features

Battery Release Latches

Used to release the removable battery.

Rear Web Camera

The 1.3 megapixel rear web camera allows you to take pictures of objects in front of you for sharing over the internet. For information on using the camera, see the documentation associated with the FujitsuHL application.

- Locating the Connectors and Controls

SD Card Slot

The Secure Digital (SD) card slot allows you to insert a flash memory card for data storage. Flash memory cards allow you to transfer data to and from a variety of different digital devices. See “Secure Digital Cards” on page 53.

Fingerprint Sensor

The fingerprint sensor allows you to start your system by swiping your finger over the sensor. See “Introducing the Fingerprint Sensor Device” on page 99.

Built-in Microphones

The built-in microphones allow you to input analog audio.

USB 2.0 port

Allows you to connect Universal Serial Bus-compliant devices (compliant with USB Standard Revision

2.0) to the T ablet PC. Four additional USB ports are located on the optional STYLISTIC Docking Cradle.

Smart Card Slot

The dedicated Smart Card slot allows you to insert a Smart Card on which you can store such data as medical information or electronic “cash”.

Line Out/Headphone Jack

Allows you to connect a set of stereo headphones.

HDMI Port

The HDMI port is used to connect compatible digital devices with your computer (such as a highdefinition television or AV receiver).

Removable Lithium Polymer Battery

Can be removed and replaced with a charged battery. See “Lithium Polymer Battery” on page 47.

- Locating the Connectors and Controls

Status Indicator Panel

Power

Charge/

DC in

Icons appear under each of the system status LEDs in the status display indicating the status of system power and battery charge status. The location of icons in the Status display is shown in Figure 4.

T able 1 explains how the LEDs associated with the individual icons are displayed, and describes what the variations of that display indicate. (If an icon is not displayed, it indicates that the related system function is off or inactive.

Figure 4. Status Display Icons

- Status Indicator Panel

Table 1. Status Display Conditions

In the following table, a “blinking” LED flashes at the rate of once per second; an LED that is “blinking, slow” flashes at the rate of one second on, five seconds off.

Icon Mode/State LED State Remarks

Power

Charge/DC In

• On State

Blue, continuous

The system is powered on and ready for use.

• Idle Mode

• Sleep Blue, blinking The system has suspended and saved active settings to RAM.

•Off State

Off The system has suspended and

saved settings and data to the hard

• Hibernate

• On State

Green AC adapter and battery are available

disk drive.

and charged battery level is 50-100%.

• Idle Mode

Orange AC adapter and battery are available

•Sleep

and charged battery level is less than 50%.

• Hibernate

Green, blinking Tablet PC is in Suspend mode, AC

•Off State

adapter and battery are available and charged battery level is 50-100%.

Orange, blinking

Tablet PC is in Suspend mode, AC adapter and battery are available and charged battery level is less than 50%.

Off The AC Adapter is not available.

- Status Indicator Panel

Display Panel

Your STYLISTIC Q550 Tablet PC contains an LCD display panel that is backlit for easier viewing in bright environments. The slate design of your Tablet PC allows you to easily hold the unit and rotate it 90o, 180o, or 270o in either direction. This display is used as a tablet, much as you would a pad of paper.

Adjusting Display Panel Brightness

To adjust brightness with the power management utility: Click Start -> Contr ol Panel. In View by:, select one of the icon views. Select Display, then click Adjust

brightness in the left pane. Under Select a power plan, select the plan settings you want to use. Drag Screen brightness: bar (at the bottom of the window) to the left or right, depending on your preference.

Figure 5. Tablet PC Display Panel

- Display Panel

Holding the Tablet PC

The STYLISTIC Q550 can be held in any of four orientations, depending upon how you would like to use it. There are primary and secondary landscape orientations and primary and secondary portrait orientations. The primary orientations are the most practical (for example, when the primary portrait orientation is used, the web camera is at the top of the display).

Primary Landscape Orientation

Primary Portrait

Orientation

Secondary Landscape Orientation Secondary Portrait

Orientation

- Display Panel

Active Digitizer/Touchscreen

Active Digitizer Display

The integrated active digitizer allows you to use the included stylus (also called a “pen”) as a pointing device. (For detailed information about caring for

your stylus, go to “Caring for the Pen” on page 27.)

You can use the stylus to click, double-click, drag items and icons, write text, or to draw like a pen or pencil in applications that support this behavior, such as drawing or painting programs. See the documentation that came with your application for details.

• DO NOT USE EXCESSIVE FORCE WHEN TAPPING OR WRITING ON THE SCREEN WITH THE STYLUS.

XCESSIVE FORCE COULD RESULT IN DAMAGE TO THE LED AND/OR ACTIVE DIGITIZER.

• TO PURCHASE ADDITIONAL OR REPLACEMENT STYLUSES, VISIT THE FUJITSU ACCESSORIES WEBSITE

AT: WWW.SHOPFUJITSU.COM.

Figure 6. Using the Active Digitizer Display

- Active Digitizer/Touchscreen

Clicking on Active Digitizer Display

To left-click, touch the object you wish to select and then lift the stylus tip immediately.

Figure 7. Clicking on the Active Digitizer Display

Figure 8. Right-clicking Active Digitizer

Right-Clicking on Active Digitizer

Right-click can be accomplished by holding the front of the toggle button down while tapping on the screen. To change the settings for the rightclick feature, go to Start -> Control Panel -> Pen and T ouch. In the Pen Options tab, select “Press and Hold” then click the [Settings] button.

- Active Digitizer/Touchscreen

Double-Clicking

To double-click, touch the item twice, and then immediately remove the stylus tip.

Dragging

Dragging means moving an item with the stylus by touching the screen, moving and then lifting the stylus. T o drag, touch the Active Digitizer Display with your stylus on the item you wish to move. While continuing to touch the screen with the stylus, drag the item to its new location by moving the stylus across the screen, and then lifting the stylus to release it.

Figure 9. Double-clicking the Display

- Active Digitizer/Touchscreen

Figure 10. Dragging on the Display

Calibrating the Display

In order to ensure accurate tracking between the stylus and cursor, you must run the Calibration Utility before you use the system for the first time, or after you change the display resolution.

To run the calibration utility:

1 Go to Start -> Control Panel. 2 Double-click the Tablet PC Settings icon and select the Display tab 3 Click the [Calibrate] button, then select whether you want to calibrate pen input or touch input. 4 Adjust the display of your Tablet PC to a comfortable angle and find the (+) symbol in the upper-left corner of

the display.

DO NOT USE EXCESSIVE FORCE WHEN TAPPING ON THE SCREEN DURING CALIBRATION. USE OF

EXCESSIVE FORCE COULD RESULT IN DAMAGE TO THE LED AND/OR TOUCH PANEL.

5 Using the stylus or your finger (depending upon which type of input you are calibrating), firmly touch the screen

directly on the (+) symbol. Lift the stylus from the screen and the target will move to a different location on the screen.

6 Repeat step 5 until you have selected all of the (+) symbols. 7 Once you have selected all the symbols, press the [OK] button. 8 Touch the stylus to various points on the screen to verify that the screen is correctly calibrated. If you are not

satisfied with the screen’s calibration, press the [Calibrate]) button to begin again.

- Active Digitizer/Touchscreen

Using the Capacitive Touchscreen

Certain configurations of this Tablet PC have an optional dual digitizer that allows you to use either the stylus or your finger(s) as a pointing device. This type of display also allows you to use “gestures” to perform such actions as scroll, zoom, and rotate.

• GESTURE SUPPORT IS DETERMINED BY THE APPLICATION IN USE.

• THE STYLUS TAKES PRECEDENCE OVER FINGER TOUCH. IF THE STYLUS IS WITHIN ACTIVE RANGE OF

THE SCREEN, FINGER TOUCH WILL BE DISABLED.

• WHEN ONE FINGER IS USED ON THE TOUCHSCREEN, IT BEHAVES IN THE SAME MANNER AS A STYLUS.

Right-clicking the touchscreen

T o perform a right-click action using two fingers, press the first finger at the location you want to perform a right-click, then quickly tap and release the second finger on the screen.

Gesture Mode 

To initiate gesture mode, two fingers must touch the screen within 200 ms of each other. If the second finger touches the screen after 200 ms has elapsed, the second finger is ignored. If more than two fingers touch the screen in that time, Advanced Gesture Mode is activated instead. When Gesture Mode is activated, no cursor movement is sent to the system.

When both fingers are removed, Gesture mode ends. When a third finger is added, gesture mode ends and Advanced gesture mode is activated. Note that if a gesture can’t be recognized, no action is taken. In that case, remove both fingers from the screen and try again.

Scrolling Gesture

To scroll through long documents or on a web page, place both fingers on the screen (one finger quickly followed by the second). If at least one finger has moved at least 3 mm, a scroll is considered. If both fingers are moving in the same direction and parallel (given a tolerance of 5 mm), Scroll Mode is activated. If one finger is stationary, it is not considered a scroll. If either finger is lifted, Scroll Mode is canceled.

Zoom Gesture

The zoom gesture is especially helpful when viewing pictures. To zoom in, place two fingers on the item you want to enlarge (one finger quickly followed by the second), then spread them away from each other.

- Active Digitizer/Touchscreen

If at least one finger has moved at least 10 mm, a zoom event is considered. If the distance between the fingers has changed by at least 10 mm, and both fingers have stayed on approximately the same line, Zoom Mode is entered. If either finger strays more than 10 mm from the "zoom line" created when the fingers first made contact, the zoom is canceled.

To zoom out, place two fingers on the item you want to reduce (one finger quickly followed by the second), then move them towards each other.

Rotate Gesture

To change the orientation of an object on the screen, place two fingers on the image you want to rotate (one finger quickly followed by the second), then move them in opposite directions (as if you were turning a knob). The direction the item turns is dependant upon the direction you move your fingers.

If at least one finger moves at least 12 mm, a rotate is considered. If one finger is stationary (moving less than 5 mm in any direction), and the other is moving, a rotate is considered. If the fingers begin moving in the same direction, the rotation is canceled. If the distance between the fingers changes by more than 10 mm, the rotation is canceled.

Accessing the OnScreen TouchPad

Your tablet has a handy on-screen touchpad that offers a variety of helpful functions. Features of the OnScreen TouchPad include:

• Virtual Mouse Emulator: The Virtual Mouse Emulator works in much the same manner as a

hardware mouse. With the virtual mouse, you can scroll, drag, and click, as well as perform [Ctl]+[Click] and [Shift]+[Click] actions.

• Application Launch/Key Macro: This window provides access to five pages, each of which can

contain up to twenty buttons. Each button can be programmed to open an application, a folder, document, or key (such as [Esc], [ Alt+X] and [Page Up]).

• Digital Keyboard: This window provides a soft keyboard for use in mathematical procedures. It

works in much the same way as the Windows standard calculator.

To access the OnScreen TouchPad, go to the Start Menu > All Programs > Fujitsu OnScreen TouchPad. To learn more about the utility, click on Usage and Help.

- Active Digitizer/Touchscreen

Using the Nuance SoftKeyboard

For general information about using the Nuance SoftKeyboard, please refer to your Getting Started Guide that came with the system. If you have questions about the Nuance SoftKeyboard, or you would like to learn more, click the Help icon (it looks like a question mark) in the Nuance taskbar.

Caring for the Pen

• ONLY USE THE PEN PROVIDED WITH YOUR TABLET PC. DO NOT USE SUBSTITUTE PEN TIPS THAT WERE NOT

SPECIALLY DESIGNED FOR YOUR TABLET PC. REPLACE THE STYLUS TIP IF IT IS WORN. THE WARRANTY DOES NOT COVER A SCRATCHED SCREEN.

• WHILE WRITING, DO NOT TO SCRATCH THE SURFACE OF THE DISPLAY (E.G., WITH A WRISTWATCH OR BRACELET).

HE PEN OF YOUR TABLET PC IS AN ELECTRONIC INSTRUMENT WHICH CAN BE DAMAGED IF USED INCORRECTLY.

HANDLE THE PEN WITH CARE. THE FOLLOWING LIST CONTAINS GUIDELINES FOR PROPER PEN HANDLING:

• DO NOT GESTURE WITH THE PEN OR USE IT AS A POINTER.

• NEVER USE THE PEN ON ANY OTHER SURFACE THAN THE SCREEN OF YOUR TABLET PC.

• DO NOT TRY TO TURN THE THUMB GRIP ON THE PEN.

• NEVER STORE THE PEN WITH THE TIP BEARING THE WEIGHT OF THE PEN. IF THE PEN IS STORED WITH THE TIP

POINTING DOWN, THIS MAY HAVE AN ADVERSE EFFECT ON THE PEN MECHANISM (PARTICULARLY UNDER HIGH TEMPERATURES). IN THIS CASE THE PEN TIP MAY REACT AS THOUGH IT IS CONSTANTLY BEING PRESSED DOWN.

• THE PEN CAN BE INFLUENCED BY ELECTROMAGNETIC FIELDS (CURSOR QUIVERS OR JUMPS). THERE MAY BE A FEW

AREAS ON THE SCREEN WHERE THE CURSOR QUIVERS SLIGHTLY IN SPITE OF PRESSING THE PEN DOWN FIRMLY.

Changing the Pen Settings

There are a few changes you can make to your pen settings in order to make it more suitable to your needs (such as changing the pressure sensitivity). T o do so, go to Start > Control Panel and select one of the icon views from the “View by:” dropdown. Click on the Pen and T o uch icon to open the window from which you can change a variety of pen settings.

- Active Digitizer/Touchscreen

Changing the Pen Battery

Pen Cap

AAAA-battery

Pen Barrel

Pen Tip

• DO NOT REMOVE THE TIP OF THE PEN TO REPLACE THE

BATTERY; REMOVE ONLY THE CAP ON THE TOP OF THE PEN.

• THERE IS A RISK OF EXPLOSION IF THE BATTERY IS

REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES IN ACCORDANCE WITH LOCAL INSTRUCTIONS.

The pen contains a AAAA-battery . Before proceeding, be sure to have a new battery available.

1 Remove the rear Pen Cap (Figure 11). 2 Remove the battery from the pe n ba rr e l . 3 Insert the new battery into the pen barrel in the same orientation

as the one that was removed.

4 Close the rear Pen Cap.

Replacing the Pen Tip

Figure 11. Replacing the Battery

With use, the pen tip may become worn or may pick up foreign particles that can scratch the screen. A damaged or worn tip may not move freely, causing unpredictable results when using the pen. If a problem like this should occur, you should replace the pen tip.

1 Pull the tip from the barrel. 2 Using one of the new tips that were supplied with your pen,

insert the pointed end of the tip into the barrel and push it in firmly until it is in place

- Active Digitizer/Touchscreen

Figure 12. Replacing the Pen Tip

Installing a Pen Tether

To prevent dropping or losing your pen, you should attach it to your system using the pen tether that is included with the system.

To attach the pen tether to your Tablet PC, perform the following steps:

1 Attach the end of the pen tether with the smaller loop

to your pen. T o do so, push the end of th e tether under the slot on the top of the pen, then thread the opposite end of the tether through the loop.

2 Attach the end of the pen tether with the larger loop to

the attachment point on the right side of your tablet. To do so, insert the end of the pen tether through the attachment point, then feed the pen through the lar ge loop in the tether.

Figure 13. Installing a Pen Tether

- Active Digitizer/Touchscreen

Tablet PC Buttons

Keyboard Button

Rotation Button

Ctl-Alt-Del

The three Tablet PC buttons are located on the right-hand side of a horizontallyoriented system. Two of the buttons have secondary functions. The secondary functions are activated by pressing and holding the button.

Figure 14. Application buttons

TL-ALT-DEL IS THE ONLY APPLICATION BUTTON THAT CAN BE USED WHILE THE SYSTEM IS LOGGING

ON OR WHEN THE SYSTEM IS LOCKED (I.E., WHEN YOU HAVE THE LOGON OR COMPUTER LOCKED WINDOW SHOWING ON YOUR DESKTOP).

- Tablet PC Buttons

Button Icon

and Name

Keyboard

Button

Rotation

Button

Primary

Function

(Press)

Launch TabTip

Screen Rotate

Secondary

Function

(Press and

Hold)

Launch

FujitsuHL

Enable/

Disable Auto

Rotate

Press at

Splash Screen*

Boot Menu Enter

BIOS Setup

Utility

In BIOS Setup

Utility

Down

Description

Pressing the Keyboard button invokes the T abTip utility. Pressing and holding the button launches the FujitsuHL utility that provides shortcuts to a variety of commonly accessed tools and tasks, including the web camera application. If you press

the Keyboard button while the Fujitsu logo appears during system boot, the Boot Menu will open. While you are in the BIOS Setup utility, this button can be used as an [Enter] key.

When you press the Rotate button, the system screen orientation changes from portrait (vertical) to landscape (horizontal) or from landscape to portrait. When you would like to use the Tablet PC as an eBook, for example, you would use the portrait orientation, when accessing spreadsheets, you would more typically use a landscape orientation. Pressing and holding the button enables and disables the Auto Rotate function. If you press the Rotation button while the Fujitsu logo appears during system boot, the BIOS Setup Utility will open. While you are in the BIOS Setup

utility, this button can be used as a Down key

Ctl-Alt-Del

Button

Pressing the Ctl-Alt-Del button for approximately one second causes it to act as if Ctl-Alt-Del had actually been entered from a keyboard. If you

press the Ctrl+Alt+Del button while the Fujitsu logo appears during system boot, the Application Menu will appear. While you are in the BIOS Setup utility , this button can be used as an Up key.

Ctrl + Alt + Del None

Application

* “Press at Splash Screen”refers to the action that occurs when you press the button when the Fujitsu logo appears when you first start up the system.

- Tablet PC Buttons

Chapter 2

Getting Started with Your Tablet PC

Power Sources

Y our Fujitsu STYLISTIC Tablet PC has three possible power sources: a primary Lithium Polymer battery , an AC adapter or an optional Auto/Airline adapter.

Connecting the Power Adapters

The AC adapter or optional Auto/Airline adapter provides power for operating your Tablet PC and charging the batteries.

Connecting the AC Adapter

1 Plug the DC output cable into the DC power jack of your STYLISTIC Tablet PC. 2 Plug the AC adapter into an AC electrical outlet.

Connecting the Optional Auto/Airline Adapter

1 Plug the DC output cable into the DC power jack on your Tablet PC. 2 Plug the Auto/Airline adapter into the cigarette lighter of an automobile, or, 3 Plug the Auto/Airline adapter into the DC power jack on an airplane seat.

Figure 15. Connecting the AC Adapter

DC Power Jack

AC Adapter

Switching from AC Adapter Power or the Auto/Airline Adapter to Battery Power

1 Be sure that you have at least one charged battery installed. 2 Remove the AC adapter or the Auto/Airline adapter.

THE LITHIUM POLYMER BATTERY IS NOT CHARGED UPON PURCHASE. INITIALLY, YOU WILL NEED TO

CONNECT EITHER THE AC ADAPTER OR THE AUTO/AIRLINE ADAPTER TO USE YOUR TABLET PC.

- Power Sources

Starting Your STYLISTIC Tablet PC

Power On

Power/Suspend/Resume Switch

The Power/Suspend/Resume switch is used to turn on your STYLISTIC T ablet PC from its off state. Once you have connected your AC adapter or charged the internal Lithium Polymer battery , you can power on your Tablet PC.

HEN YOU TURN ON YOUR STYLISTIC TABLET PC BE SURE YOU HAVE A POWER SOURCE. THIS

MEANS THAT AT LEAST ONE BATTERY IS INSTALLED AND CHARGED, OR THAT THE AC OR AUTO/AIRLINE ADAPTER IS CONNECTED AND HAS POWER.

T o turn on your STYLISTIC T ablet PC from its off state, slide the Power/Suspend/Resume switch, locate d on the bottom edge of the right side (when the system is held horizontally). When you are done working you can either leave your T ablet PC in Suspend mode or you can turn it off. See “Sleep Mode” on page 43 and “Powering Off” on page 46.



Figure 16. Power/Suspend/Resume Switch

- Starting Your STYLISTIC Tablet PC

When you power on your STYLISTIC, it will perform a Power On Self T est (POST) to check the internal parts and configuration for correct functionality . If a fault is found, your STYLISTIC Tablet PC will emit an audio warning and/or an error message will be displayed. See “Power On Self Test Messages” on page 64. Depending on the nature of the problem, you may be able to continue by starting the operating system or by entering the BIOS setup utility and revising the settings.

After satisfactory completion of the POST, your Tablet PC will load your operating system.

NEVER TURN OFF YOUR STYLISTIC TABLET PC DURING THE POWER ON SELF TEST (POST) OR IT

WILL CAUSE AN ERROR MESSAGE TO BE DISPLAYED WHEN YOU TURN YOUR STYLISTIC TABLET PC ON THE NEXT TIME. See “Power On Self Test Messages” on page 64.

Boot Sequence

The procedure for starting-up your Tablet PC is termed the Bootup sequence and involves your Tablet PC’ s BIOS. When your STYLISTIC Tablet PC is first turned on, the main system memory is empty, and it needs to find instructions to start up your T ablet PC. This information is in the BIOS program. Each time you power up or restart your T ablet PC, it goes through a boot sequence which displays a Fujitsu logo until your operating system is loaded. During booting, your T ablet PC is performing a standard boot sequence including a Power On Self Test (POST). When the boot sequence is completed without a failure and without a request for the BIOS Setup Utility, the system displays the operating system’s opening screen.

The boot sequence is executed when:

• You turn on the power to your STYLISTIC Tablet PC.

• You restart your Tablet PC from the Windows Shut Down dialog box.

• The software initiates a system restart. Example: When you install a new application.

- Starting Your STYLISTIC Tablet PC

Hard Disk Drive Passwords

To provide additional security for your data, you can assign passwords to your hard disk drive(s). This feature is managed in the system BIOS Setup Utility . See BIOS Setup Utility below for information about accessing the utility.

REMEMBER YOUR PASSWORDS. IF YOU SET AND FORGET YOUR USER AND MASTER HARD DISK

PASSWORDS, FUJITSU WILL NOT BE ABLE TO RESET IT. YOU MAY LOSE DATA AND HAVE TO REPLACE YOUR SYSTEM BOARD OR HARD DISK DRIVE.

BIOS Setup Utility

The BIOS Setup Utility is a program that sets up the operating environment for your STYLISTIC T a blet PC. Your BIOS is set at the factory for normal operating conditions, therefore there is no need to set or change the BIOS’ environment to operate your Tablet PC.

The BIOS Setup Utility configures:

• Device control feature parameters, such as changing I/O addresses and boot devices.

• System Data Security feature parameters, such as passwords.

Entering the BIOS Setup Utility

N ORDER TO NAVIGATE THROUGH THE BIOS SETUP UTILITY, YOU MUST HAVE AN EXTERNAL

KEYBOARD ATTACHED TO YOUR TABLET.

To enter the setup utility, do the following:

1 Turn on or restart your STYLISTIC Tablet PC. 2 To enter the BIOS Setup Utility, either press the Rotation button (or press the [F2] key if you have an external

keyboard) when the Fujitsu logo appears on the screen. This will open the main menu of the BIOS Setup Utility with the current settings displayed.

- Starting Your STYLISTIC Tablet PC

3 Press the [RIGHT ARROW] or [LEFT ARROW] key to scroll through the other setup menus to review or alter

the current settings.

BIOS Guide

A guide to your Tablet PC’s BIOS is available online. Please visit our service and support website at http://www.computers.us.fujitsu.com/support, then select User’s Guides under Online Support. Select your Product, Series, and Model, then click [Go]. Under the Manuals tab, select the BIOS Guide.

Booting the System

We strongly recommend that you not attach any external devices until you have gone through the initial power on sequence.

When you turn on your Tablet PC for the first time, it will display a Fujitsu logo on the screen. If you do nothing the system will load the operating system, and then the Windows Welcome will begin.

Starting Windows the first time

IMPORTANT: DURING THE SETUP PROCEDURE, DO NOT DISCONNECT THE POWER SUPPLY, PRESS ANY

BUTTONS, OR USE ANY PERIPHERAL DEVICES SUCH AS A MOUSE OR KEYBOARD.

In order to ensure that you receive the most benefits from the Windows operating system, it should be registered the first time you use it.

- Starting Your STYLISTIC Tablet PC

1 First of all, you will need to read and accept the End User License Agreements (EULAs).

• IF YOU REJECT THE TERMS OF THE LICENSE AGREEMENTS YOU WILL BE ASKED TO REVIEW THE

LICENSE AGREEMENTS FOR INFORMATION ON RETURNING WINDOWS OR TO SHUT DOWN YOUR

STYLISTIC T

ABLET PC.

• YOU CANNOT USE YOUR T ABLET PC UNTIL YOU HAVE ACCEPTED THE LICENSE AGREEMENTS. IF YOU

STOP THE PROCESS YOUR TABLET PC WILL RETURN TO THE BEGINNING OF THE WINDOWS WELCOME

ROCESS, EVEN IF YOU SHUT YOUR TABLET PC DOWN AND START IT UP AGAIN.

2 Y ou will be prompted to enter your User Name and Password and you will be given a chance to select an icon

for your account.

3 The next screen asks for a Computer Name. 4 You will next see a "Help protect Windows automatically” screen in which the default choice is "Use

recommended settings”. The other two choices are "In st all im port ant up dates only" and "Ask me later". Select from the three choices.

5 On the next screen set your time and date settings. 6 You will next see the "Select your computer's current location" screen. Make your selection from Home, Work

(Default), and Public location.

7 The "Thank you" screen follows and an offer for free TBD Norton Internet Security is extended. Following are

several screens while Windows checks the system performance.

8 Windows will then boot up for the first time. As noted above, the first time you initialize your system, the screen

will be blank for approximately two minutes. This is normal. During this period, do not disconnect the power supply, press any buttons, or use any peripheral devices such as mouse or keyboard.

Registering Windows with Microsoft

To register your copy of Windows, be sure to go to the Microsoft's website at: http://windows.microsoft.com/en-US/windows7/help/register.

- Starting Your STYLISTIC Tablet PC

Registering Your STYLISTIC Tablet PC with Fujitsu

ClickMe!

You can register your STYLISTIC by going to our website at: http://solutions.us.fujitsu.com/. You will need to be set up with an Internet Service Provider (ISP) to register online.



Installing ClickMe!

BEFORE INSTALLING THE CLICKME! UTILITY, BE SURE THE WIRELESS LAN SWITCH IS TURNED ON.

The first time you boot up your system, you will see a “Primary Settings for the PC” window . This window explains the installations which will be performed by the Click Me! utility. If you click [Execute], ClickMe! will begin installing. If after clicking the button you receive a “User Account Control” window , you will be asked for your permission to continue. Click [Continue] to continue. If you cancel the operation, the ClickMe! icon will appear on your desktop for later installation.

HERE MAY BE SOME THIRD-PARTY APPLICATIONS THAT DO NOT GET INSTALLED USING THE CLICKME!

UTILITY. FOR MORE INFORMATION, REFER TO YOUR GETTING STARTED GUIDE.

- Starting Your STYLISTIC Tablet PC

Power Management

Your Fujitsu STYLISTIC Tablet PC has many options and features for conserving battery power. Some of these features are automatic and need no user intervention. However, others depend on the parameters you set to best suit your operating conditions, such as those for the display brightness. Internal power management for your Tablet PC may be controlled from settings made in your operating system, prebundled power management application, or from settings made in BIOS setup utility.

Besides the options available for conserving battery power, there are also some things that you can do to prevent your battery from running down as quickly. For example, you can create an appropriate power saving profile, put your Tablet PC into Sleep mode when it is not performing an operation, and you can limit the use of high power devices. As with all mobile, battery powered computers, there is a trade-off between performance and power savings.

Power/Suspend/Resume Switch

When your T ablet PC is active, the Power/Suspend/Resume switch can be used to manually put the Tablet PC into Sleep mode. Push the Power/Suspend/Resume switch when the Tablet PC is active, but not actively accessing anything, and immediately release the button.

If your T ablet PC is suspended, pushing the Power/Suspend/Resume switch returns it to active operation. You can tell whether the system is Suspended by looking at the Power indicator . If the indicator is visible and not flashing, your T ablet PC is fully operational. If the indicator is visible and flashing, the Tablet PC is in Sleep mode. If the indicator is not visible, the power is off or your Tablet PC is in Hibernation mode.

Sleep Mode

Sleep mode in Windows saves the contents of your system memory during periods of inactivity by maintaining power to critical parts. This mode turns off the CPU, display , hard drive, and all other internal components except those necessary to maintain system memory and for restarting.

Your Tablet PC can be put in sleep mode by:

• Pressing the Power/Suspend/Resume switch when your system is turned on.

- Power Management

• Selecting “Sleep” after clicking [Start] then clicking the small arrow at the bottom right of the

window.

• Timing out from lack of activity.

• Allowing the battery to reach the Dead Battery Warning condition.

Your Tablet PC’s system memory typically stores the file on which you are working, open application information, and any other data required to support operations in progress. When you resume operation from Sleep mode, your Tablet PC will return to the point where it left off. You must use the Power/Suspend/Resume switch to resume operation, and there must be an adequate power source available, or your Tablet PC will not resume.

• IF RUNNING YOUR TABLET PC ON BATTERY POWER, BE AWARE THAT THE BATTERY CONTINUES TO

DISCHARGE WHILE YOUR TABLET PC IS IN SLEEP MODE, THOUGH NOT AS QUICKLY AS WHEN FULLY OPERATIONAL.

• DISABLING THE POWER/SUSPEND/RESUME SWITCH PREVENTS IT FROM BEING USED TO PUT THE

TABLET PC INTO SLEEP OR HIBERNATION MODE. THE BUTTON RESUME FUNCTION CANNOT BE

DISABLED.

• IF YOUR TABLET PC IS ACTIVELY ACCESSING INFORMATION WHEN YOU ENTER THE SLEEP OR

IBERNATION MODE, CHANGES TO OPEN FILES ARE NOT LOST. THE FILES ARE LEFT OPEN AND MEMORY IS KEPT ACTIVE DURING SLEEP MODE OR THE MEMORY IS TRANSFERRED TO THE INTERNAL HARD DRIVE DURING HIBERNATION MODE.

• THE MAIN ADVANTAGE OF USING HIBERNATION IS THAT POWER IS NOT REQUIRED TO MAINTAIN YOUR

DATA. THIS IS PARTICULARLY IMPORTANT IF YOU WILL BE LEAVING YOUR T ABLET PC IN A SUSPENDED STATE FOR A PROLONGED PERIOD OF TIME. THE DRAWBACK OF USING HIBERNATION MODE IS THAT IT LENGTHENS THE POWER DOWN AND POWER UP SEQUENCES AND RESETS PERIPHERAL DEVICES.

- Power Management

Hibernation Feature

The Hibernation feature saves the contents of your T ablet PC’s system memory to the hard drive as a part of the Suspend/Resume mode. Hibernation is enabled by default.

Defining Power Button Action

To determine what occurs when the power button is pressed, follow these steps:

1 From the Start menu, select Control Panel, then select the Power Options icon. 2 Select “Choose what the power button does” or “Choose what closing the lid does”, then make your selections

(Do Nothing, Sleep, Hibernate, or Shut Down).

Windows Power Management

The Power Options icon located in the Windows Control Panel allows you to configure some of the power management settings. For example, you can use the Power Options to set the timeout values for turning off the display and hard disks whether you are running the Tablet PC on battery power or one of the adapters.

Restarting the System

If your system is on and you need to restart it, be sure that you use the following procedure.

1 Click the [Start] button, and then move the mouse over the small arrow at the bottom right of the right-hand

pane.

2 Select Restart from the list.

TURNING OFF YOUR STYLISTIC TABLET PC WITHOUT EXITING WINDOWS OR TURNING ON YOUR T

ABLET PC WITHIN 10 SECONDS OF THE SYSTEM BEING SHUT OFF MAY CAUSE AN ERROR WHEN YOU

START THE NEXT TIME.

- Power Management

Powering Off

If you turn off the power while accessing a disk there is a risk of data loss. To ensure that your Tablet PC shuts down without error, use the Windows shut down procedure.

BE SURE TO CLOSE ALL FILES, EXIT ALL APPLICATIONS, AND SHUT DOWN YOUR OPERATING SYSTEM

PRIOR TO TURNING OFF THE POWER. IF FILES ARE OPEN WHEN YOU TURN THE POWER OFF, YOU WILL LOSE ANY CHANGES THAT HAVE NOT BEEN SAVED, AND MAY CAUSE DISK ERRORS.

Using the correct procedure to shut down from Windows allows your Tablet PC to complete its operations and turn off power in the proper sequence to avoid errors. The proper sequence is:

1 Click the [Start] button, and then move the mouse over the small arrow at the bottom right of the right-hand

pane.

2 Select Shut Down from the list.

If you are going to store your Tablet PC for a month or more, see Care and Maintenance Section.

- Power Management

Chapter 3

User-Installable Features

Lithium Polymer Battery

Your STYLISTIC Tablet PC has a Lithium Polymer battery that provides power for operating your Tablet PC when no external power source is available. The battery is durable and long lasting, but should not be exposed to extreme temperatures, high voltages, chemicals or other hazards.

The Lithium Polymer battery operating time may become shorter if it is used under the following conditions:

• When used at temperatures that exceed a low of 5°C or a high of 35°C (41° to 95° F). Extreme

temperatures not only reduce charging efficiency, but can also cause battery deterioration. The Charging icon on the Status Indicator panel will flash when you try to char ge a battery that is outside its operating temperature range.

• When using a high current device such as an external optical drive or the hard drive, using the AC

adapter will conserve your battery life.

DO NOT LEAVE A FAULTY BATTERY IN YOUR TABLET PC. IT MAY DAMAGE YOUR AC ADAPTER, OPTIONAL A

UTO/AIRLINE ADAPTER, OR YOUR TABLET PC ITSELF. IT MAY ALSO PREVENT OPERATION OF YOUR

ABLET PC BY DRAINING ALL AVAILABLE CURRENT INTO THE BAD BATTERY.

• ACTUAL BATTERY LIFE WILL VARY BASED ON SCREEN BRIGHTNESS, APPLICATIONS, FEATURES, POWER

MANAGEMENT SETTINGS, BATTERY CONDITION AND OTHER CUSTOMER PREFERENCES. HARD DRIVE USAGE MAY ALSO HAVE A SIGNIFICANT IMPACT ON BATTERY LIFE. THE BATTERY CHARGING CAPACITY IS REDUCED AS THE BATTERY AGES. IF YOUR BATTERY IS RUNNING LOW QUICKLY, YOU SHOULD REPLACE IT WITH A NEW ONE.

• UNDER FEDERAL, STATE, OR LOCAL LAW IT MAY BE ILLEGAL TO DISPOSE OF BATTERIES BY PUTTING

THEM IN THE TRASH. PLEASE TAKE CARE OF OUR ENVIRONMENT AND DISPOSE OF BATTERIES PROPERLY. CHECK WITH YOUR LOCAL GOVERNMENT AUTHORITY FOR DETAILS REGARDING RECYCLING OR DISPOSING OF OLD BATTERIES. IF YOU CANNOT FIND THIS INFORMATION ELSEWHERE, CONTACT YOUR SUPPORT REPRESENTATIVE AT 1-800-8FUJITSU (1-800-838-5487)

Recharging the Batteries

If you want to know the condition of the primary Lithium Polymer battery, check the Battery Level indicator located on the Status Indicator panel. The indicator changes as the battery level changes.

The Lithium Polymer battery is recharged internally using the AC adapter or Auto/Airline adapter. To recharge the battery make sure the battery that needs to be charged is installed in your STYLISTIC Tablet PC and connect the AC or Auto/Airline adapter.

AKE SURE THAT THE PERCENTAGE CHARGE IS INDICATED BY THE BATTERY CHARGING INDICATOR ON

THE STATUS INDICATOR PANEL.

There is no memory effect on the Lithium Polymer battery therefore you do not need to discharge the battery completely before recharging. The charge times will be significantly longer if your Tablet PC is in use while the battery is charging. If you want to charge the battery more quickly, put your Tablet PC into Sleep mode, or turn it off while the adapter is charging the battery. (See Power Management on page 43

for more information on Sleep mode and shutdown procedure)

- Lithium Polymer Battery

USING HEAVY CURRENT DEVICES OR FREQUENT EXTERNAL OPTICAL DRIVE ACCESSES MAY PREVENT

CHARGING COMPLETELY.

Low Battery State

When the battery is running low , a low battery notification message will appear. If you do not respond to the low battery message, the batteries will continue to discharge until they are too low to operate. When this happens, your Tablet PC will go into Sleep mode. There is no guarantee that your data will be saved once the Tablet PC reaches this point.

• ONCE THE LOW BATTERY NOTIFICATION MESSAGE APPEARS, YOU NEED TO SAVE ALL YOUR ACTIVE DATA AND

PUT YOUR TABLET PC INTO SLEEP MODE UNTIL YOU CAN PROVIDE A NEW POWER SOURCE. YOU SHOULD PROVIDE A CHARGED BATTERY, AN AC POWER ADAPTER, OR AUTO/AIRLINE ADAPTER AS SOON AS POSSIBLE.

• WHEN YOU ARE IN SLEEP MODE THERE MUST ALWAYS BE AT LEAST ONE POWER SOURCE ACTIVE. IF YOU

REMOVE ALL POWER SOURCES WHILE YOUR STYLISTIC TABLET PC IS IN SLEEP MODE, ANY DATA THAT HAS NOT BEEN SAVED TO THE HARD DRIVE WILL BE LOST.

Dead Battery Suspend mode shows on the Status indicator just like the normal Sleep mode. Once your T ablet PC goes into Dead Battery Suspend mode you will be unable to resume operation until you provide a source of power either from an adapter, or a charged battery. Once you have provided power, you will need to press the Power/Suspend/Resume switch to resume operation.

In the Dead Battery Suspend mode, your data can be maintained for some time, but if a power source is not provided promptly, the Power indicator will stop flashing and go out, meaning that you have lost the data that was not stored. Once you provide power, you can continue to use your Tablet PC while an adapter is charging the battery.

Shorted Batteries

The Status Indicator panel indicator associated with the Battery Level indicator displays the operating level available in that battery. If this display shows a flashing red LED, it means the battery is damaged and must be replaced so it does not damage other parts of your STYLISTIC Tablet PC.

- Lithium Polymer Battery

Replacing the Battery

With the purchase of an additional battery, you can have a fully charged spare to swap with one that is not charged. There are two ways to swap batteries, cold-swapping and hot-swapping:

Cold-swapping Batteries

To cold-swap batteries in your battery bay, follow these easy steps:

1 Have a charged battery ready to install. 2 Perform one of the following two steps:

• Click the Fujitsu Battery Swap Utility icon on the desktop. Follow the instructions that appear to

put the system into Hibernate mode. Using this procedure saves your data and the system powers down. It is then safe to swap the batteries.

• Save your data, then power down the system. It is then safe to swap the batteries.

3 Note that the battery latch on the left is spring loaded, while the latch on the right is not. Unlock the battery by

first pushing the right latch backwards, then pushing and holding the left latch (Figure latch, lift the battery out at the lift point (Figure 18).

4 To install a battery, first verify that the right latch is pushed back. While pushing the left latch ba ck and hol ding

it, insert a new battery into the bay (Figures forward.

19 and 20). Lock the battery in place by sliding the right latch

17). While holding the left

- Lithium Polymer Battery

5 Plug in the AC adapter and turn the power on.

Lift Point

Figure 17. Unlocking the Battery Figure 18. Removing the Battery

Figure 19. Replacing the Battery Figure 20. Locking the Battery

Hot-swapping Batteries

- Lithium Polymer Battery

To hot-swap batteries in your battery bay follow these easy steps:

BE SURE TO PLUG IN AN AC ADAPTER PRIOR TO REMOVING THE BATTERY. THERE IS NO BRIDGE

BATTERY PRESENT TO SUPPORT THE SYSTEM WHILE THE BATTERY IS BEING REPLACED. IF YOU DO NOT USE AN AC ADAPTER YOU WILL LOSE ANY UNSAVED FILES.

1 Plug an AC Adapter into the system and connect it to a power outlet. 2 Follow steps 3 through 5 in “Cold Swapping Batteries”.

F THE LITHIUM POLYMER BATTERY CONNECTOR IS NOT FULLY SEATED, YOU MAY NOT BE ABLE TO USE

YOUR TABLET PC OR CHARGE YOUR BATTERY.

- Lithium Polymer Battery

Secure Digital Cards

SD Card

SD Card Slot (relative location on rear)

SD Card

SD Card Slot

Y our STYLISTIC Tablet PC supports Secure Digital (SD) cards, on which you can store and transfer data to and from a variety of digital devices. These cards use flash memory architecture, which means they don’t need a power source to retain data. Note that SD and SDHC Cards are supported, but SDXC Cards are not.

SD Cards allow portable storage among a variety of devices, such as cell phones, GPS systems, digital cameras, and PDAs. SD Cards transfer data quickly, with low battery consumption.

Figure 21. SD Card Slot - Front Access Figure 22. SD Card Slot - Rear Access

Installing SD Cards

When holding the Tablet PC in horizontal position with the front facing you and the web camera on the left, the SD Card slot is located at the top left edge of the system, in the rear (Figures 21 and 22). T o install an SD Card, follow these steps:

- Secure Digital Cards

INSTALLING OR REMOVING AN SD CARD DURING YOUR STYLISTIC TABLET PC’S SHUTDOWN OR

BOOTUP PROCESS MAY DAMAGE THE CARD AND/OR YOUR STYLISTIC TABLET PC.

O NOT INSERT A CARD INTO A SLOT IF THERE IS WATER OR ANY OTHER SUBSTANCE ON THE CARD AS

YOU MAY PERMANENTLY DAMAGE THE CARD, YOUR STYLISTIC TABLET PC, OR BOTH.

1 See your specific card manual for instructions on the installation of your card. Some cards may require that your

Tablet PC is off while installing them.

2 Make sure there is no card currently in the slot. If there is, see Removing an SD Card. 3 With the product label facing in the same dir ec tio n as the display screen, insert your card into the slot. 4 Push the card firmly into the slot until it is seated in the connector.

Removing an SD Card

To remove an SD Card, follow these easy steps:

EE YOUR CARD MANUAL FOR SPECIFIC INSTRUCTIONS ON THE REMOVAL OF YOUR CARD. SOME CARDS

MAY REQUIRE YOUR STYLISTIC TABLET PC TO BE IN SLEEP MODE OR OFF WHILE REMOVING THEM.

1 Select Safely Remove Hardware from the System Tray. Highlight the card in the list, then click [Stop]. 2 Push the SD Card in until it unlatches. It will then eject from the slot for removal.

- Secure Digital Cards

Chapter 4

Troubleshooting Your Tablet PC

Troubleshooting

There may be occasions when you encounter simple setup or operating problems that you can solve on the spot, or problems with peripheral devices that can be solved by replacing the device. The information in this section helps you isolate and resolve some of these straightforward issues and identify failures that require service.

Identifying the Problem

If you encounter a problem, go through the following procedure before pursuing complex troubleshooting:

1 Turn off your STYLISTIC Tablet PC. 2 Make sure the AC adapter is plugged into your Tablet PC and to an active AC power source. 3 Make sure that any cards installed are seated properly. If it appears that there is a problem with a card, remove

the card from the slot, thus eliminating it as a possible cause of failure.

4 Make sure that any devices connecte d to the ex te rn al co nn ectors are plugged in properly. Yo u can als o

disconnect such devices, thus eliminating them as possible causes of failure.

5 Turn on your Tablet PC. Make sure it has been off at least 10 seconds before you turn it back on. 6 Go through the boot sequence. 7 If the problem has not been resolved, refer to the Troubleshooting Table that follows for more detailed

troubleshooting information.

IF YOU KEEP NOTES ABOUT WHAT YOU HAVE TRIED, YOUR SUPPORT REPRESENTATIVE MAY BE

ABLE TO HELP YOU MORE QUICKLY BY GIVING ADDITIONAL SUGGESTIONS OVER THE PHONE.

8 If you have tried the solutions suggested in the Tr oubleshooting Table without success, contact your support

representative:

Toll free: 1-800-8Fujitsu (1-800-838-5487) 

Web site: http://www.computers.us.fujitsu.com/support. Before you place the call, you should have the following information ready so that the customer support

representative can provide you with the fastest possible solution:

• Product name

• Product configuration number

• Product serial number

• Purchase date

• Conditions under which the problem occurred

• Any error messages that have occurred

• Type of device connected, if any

See the Configuration Label on the bottom of your Tablet PC for configuration and serial numbers.

- Troubleshooting

Specific Problems

Using the Troubleshooting Table

When you have problems with your T ablet PC, try to find the symptoms under the Problem column of the troubleshooting table for the feature giving you difficulty. You will find a description of common causes for that symptom under the column Possible Cause and what, if anything, you can do to correct the condition under Possible Solutions. All possible causes or solutions may not apply to your Tablet PC.

T roubleshooting Table

Audio Problems. . . . . . . . . . . . . . .page 58

Hard Drive Problems. . . . . . . . . . .page 58

Keyboard or Mouse Problems. . . .page 58

Pen Input Problems. . . . . . . . . . . .page 59

USB Device Problems. . . . . . . . . .page 59

Power Failures . . . . . . . . . . . . . . . .page 60

Shutdown and Startup Problems . .page 62

Video Problems . . . . . . . . . . . . . . .page 62

Miscellaneous Problems . . . . . . . .page 63

- Troubleshooting

Problem Possible Cause Possible Solutions Audio Problems

There is no sound coming from the built-in speaker.

Hard Drive Problems

You cannot access your hard drive.

Keyboard or Mouse Problems

You have installed an optional external keyboard or mouse, and it does not seem to work.

The volume is turned too low. Adjust the volume control on your Tablet PC and operating

system. Click the Volume icon in the system tray on the bottom right of the screen. (It looks like a speaker). If the Mute box has a red circle on it, click on it to deselect it.

Headphones are plugged into your Tablet PC.

The wrong drive designator was used by an application when a bootable disc was

Plugging in headphones disables the built-in speaker. Remove the headphones.

Verify drive designator used by application is in use by the operating system. When the operating system is booted from a CD, drive designations are automatically adjusted.

used to start the Tablet PC. Security is set so your operat-

Verify your password and security settings. ing system cannot be started without a password.

Your external device is not

Re-install your device. See “Device Ports” on page 82. properly installed.

Your operating system is not set up with correct software

Check your device and operating system documentation and

activate the proper driver. driver for that device.

You have connected an external keyboard or a mouse and it seems to be locking up the system.

Your operating system is not setup with correct driver.

Check your device and operating system documentation and

activate the proper driver. Your system has crashed. Try to restart your Tablet PC.

- Troubleshooting

Problem Possible Cause Possible Solutions Pen Input Problems

Cursor is not tracking the pen.

Tablet is not responding to the pen

Memory Problems

Your System screen in the Control Panel does not show the correct amount of installed memory.

USB Device Problems

Your system doesn’t recognize a USB device you installed, or the device doesn’t work properly.

Display needs to be calibrated

See “Calibrating the Display” on page 24. for more information.

System may have crashed. If the Tablet PC does not respond to the pen, connect an

external keyboard to the system to see if it responds to keyboard commands. If the system doesn’t respond to a keyboard, the application or system may have crashed, and it may be necessary to reboot the system. If the system responds to a keyboard but not to a pen, contact your local help desk or reseller, or call Fujitsu Service and Support at 1800-8Fujitsu (1-800-838-5487) for further assistance.

You have a memory failure.

The device is not properly

Check for Power On Self Test (POST) messages. See

“Power On Self Test Messages” on page 64.

Remove and re-install the device.

installed. The device may have been

Close the application and restart your Tablet PC. installed while an application was running, so your system is not aware of its installation.

Y our device may not have the correct software driver active.

- Troubleshooting

See your software documentation and activate the correct

driver.

Problem Possible Cause Possible Solutions Power Failures

Y ou turn on your T ablet PC and nothing seems to  happen.

Your STYLISTIC Tablet PC turns off all by itself.

The installed battery is completely discharged or there is no power adapter installed.

The battery is installed but is faulty or very low.

Check the Status Indicator Panel to determine the presence

and condition of the battery. See “Status Indicator Panel” on

page 18. Install a charged battery or a Power adapter.

When the battery reaches a critically low level, the system is

forced into Sleep mode to avoid a total system power failure.

To correct this problem, either connect an external power

supply (such as the AC adapter), or install a charged battery

in the Tablet PC. System is at a critical thermal

limit.

To avoid damage to heat-sensitive components, the system

enters sleep mode when it gets too hot. System operation

cannot be resumed until the Tablet PC cools off to a tolerable

temperature. Move the Tablet PC to a cooler location. AC power adapter is not

plugged in properly. The power adapter has no

power from the AC or airline outlet.

Verify that your adapter is connected correctly. See “Power

Sources” on page 35.

Move the AC cord to a different outlet, or check for a line

switch or tripped circuit breaker. If you are using an auto/air-

line adapter in a car be sure the ignition switch is in the On or

Accessories position. The power adapter is faulty. Try a different power adapter. The power management

parameters are set for auto timeouts which are too short for your operating needs.

Move the mouse to restore operation. If that fails, push

Power/Suspend/Resume switch. Check your power manage-

ment settings, or close your applications and go to Power

Options located in the Control Panel to adjust timeouts to

better suit your needs. Y our power adapter has failed

or lost its power source.

- Troubleshooting

Make sure the adapter is plugged in and the outlet has

power.

Problem Possible Cause Possible Solutions

Your STYLISTIC Tablet PC turns off all by itself.

(continued)

Your Tablet PC will not work on battery alone.

The battery seems to  discharge too quickly.

You ignored a low battery alarm until the battery entered

Install a power adapter, then push the Power/Sus-

pend/Resume switch. See “Power Sources” on page 35. Dead Battery Suspend mode.

You have a battery failure. Verify the condition of the battery using the Status Indicator

panel. If the battery is shorted, replace or remove it. See

“Status Indicator Panel” on page 18.

The installed battery is dead. Replace the battery with a charged one or use an adapter. No battery is installed. Install a charged battery. Battery is improperly inst all ed. Verify that the battery is properly connected by re-installing it. Your installed battery is faulty. Verify the condition of the battery using the Status Indicator

panel and replace or remove any batteries that are shorted.

See “Status Indicator Panel” on page 18.

The power savings features may be disabled.

The brightness is turned all the way up.

You’re running an application

Check the Power Options menu settings and adjust accord-

ing to your operating needs.

Turn down the brightness adjustment. The higher the bright-

ness the more power your display uses.

Use a power adapter for this application when at all possible. that uses a lot of power due to frequent drive access, or use of wireless devices.

The battery is very old. Replace the battery. The battery was exposed to

Replace the battery. high temperatures.

The battery is too hot or too cold.

Restore the Tablet PC to normal operating temperature.

Charging icon on the Status Indicator panel will flash when

battery is outside of operating range.

- Troubleshooting

Problem Possible Cause Possible Solutions Shutdown and Startup Problems

The Suspend/Resume  switch does not work.

The system powers up and displays power on information, but fails to load the operating system.

An error message is displayed on the screen during the boot sequence.

Your Tablet PC appears to change setup parameters when you start it.

Video Problems

Suspend/Resume  switch is disabled.

To enable the button, go to Control Panel -> Power Options

and click on the Advanced tab. In the Power buttons area,

select the “Change what the power button does” option. There may be application

Close all applications and try the button again. software. conflict

You have a secured system requiring a password to load your operating system.

The boot sequence settings of the setup utility are not compatible with your configuration.

Make sure you have the right password. Enter the setup util-

ity and verify the Security settings and modify them as

accordingly. See “BIOS Setup Utility” on page 39.

Set the operating source by pressing the [F12] key while the

Fujitsu logo is on screen or use the [F2] key and enter the

setup utility and adjust the source settings from the Boot

menu. See “BIOS Setup Utility” on page 39. Hard drive was not detected. Use BIOS setup utility to auto detect the internal hard drive. Power On Self Test (POST)

has detected a problem.

See the Power On Self Test (POST) messages to determine

the meaning and severity of the problem. Not all messages

are errors; some are simply status indicators. See “Power On

Self Test Messages” on page 64.

BIOS setup changes were not saved when made and you

Make sure you select Save Changes And Exit when exiting

the BIOS setup utility. exited the setup utility.

The display is blank when you turn on your Tablet PC.

Power management timeouts are set for short intervals and you didn’t see the display go on and off again.

- Troubleshooting

Move the mouse to restore operation. If that fails, push the

Power/Suspend/Resume switch. (The display may be shut

off by Sleep mode, Auto Suspend or Video Timeout)

Problem Possible Cause Possible Solutions

The Tablet PC turned on with a series of beeps and the display is blank.

The display goes blank by itself after you have been using it.

The display has bright or dark spots.

Miscellaneous Problems

Error message displayed on the screen during operation of an application.

Power On Self Test detected a failure which does not allow the display to operate.

Power management timeouts are set for short intervals and you failed to notice the display come on and go off again.

The Tablet PC has gone into Sleep or Hibernate mode because you have not used it for a period of time.

If the spots are very tiny and few in number, this is normal for a large LCD display.

If the spots are numerous or large enough to interfere with your operation needs.

Application software often has its own set of error message displays.

Contact your support representative.

Push the Power/Suspend/Resume switch. (The display may

be shut off by Sleep Mode, Auto Suspend or Video Timeout)

Push Power/Suspend/Resume switch. Check power man-

agement settings, or close applications and go to the Power

Savings menu of the setup utility to adjust timeout values 

to suit your needs. See “BIOS Setup Utility” on page 39.

This is normal; do nothing.

Display is faulty; contact your support representative.

See your application manual and help displays screens for

more information. Not all messages are errors some may

simply be status.

- Troubleshooting

Power On Self Test Messages

The following is a list of error-and-status messages that the Phoenix BIOS and/or your operating system can generate and an explanation of each message. Error messages are marked with an *. If an error message is displayed that is not in this list, write it down and check the operating system documentation on screen and in the manual. If you can find no reference to the message, contact a support representative.

*Invalid NVRAM Data

Problem with NVRAM access. In the unlikely case that you see this message you may have a display problem. You can continue operating but should contact your support representative for more information.

*Operating system not found

Operating system cannot be located on either drive A: or drive C: Enter the setup utility and see if both the fixed disk, and drive A: are properly identified and that the boot sequence is set correctly . Unless you have changed your installation greatly , the operating system should be on drive C:. If the setup utility is correctly set, your hard drive may be corrupted.

*Real time clock error - Check date and time settings

Real-time clock fails BIOS test. May require board repair . Contact your support representative.

- Troubleshooting

Restoring Your Pre-installed Software

Packed with your system you will find two discs for recovering your pre-installed software:

• Drivers and Applications Restore Disc

• Recovery and Utility Disc

Drivers and Applications Restore Disc

The Drivers and Applications Restore (DAR) disc included with your system contains sets of device drivers and Fujitsu utilities (in specific directories) that are unique to your computer configuration.

IF YOU HAVE ACCESS TO THE INTERNET, VISIT THE FUJITSU SUPPORT WEBSITE AT HTTP://

WWW.COMPUTERS.US.FUJITSU.COM/SUPPORT TO CHECK FOR THE MOST CURRENT INFORMATION, DRIVERS AND HINTS ON HOW TO PERFORM RECOVERY AND SYSTEM UPDATES.

Re-installing Individual Drivers and Applications

The Drivers and Applications disc can be used to selectively re-install drivers and/or applications that may have been un-installed or corrupted.

HERE MAY BE CERTAIN FREE THIRD-PARTY APPLICATIONS PRE-INSTALLED ON YOUR SYSTEM THAT ARE

NOT ON THE DAR DISC. THE LATEST VERSIONS OF THE APPLICATIONS CAN BE DOWNLOADED FROM THE THIRD-PARTY’S WEBSITE.

To re-install drivers and/or applications:

1 Boot up the system and insert the DAR disc after Windows has started. A Fujitsu Installer screen is displayed

after the disc is inserted.

2 After reading the License Agreement, click [I agree]. 3 A window will appear containing a list of applications, drivers, and utilities that you can install from the DAR disc.

- Restoring Your Pre-installed Software

THE COMPONENTS LISTED ARE COLOR-CODED IN TERMS OF THEIR INSTALL STATUS. BLUE INDICATES

THAT THE COMPONENT CAN BE INSTALLED. GREEN INDICATES THAT THE COMPONENT NEEDS TO BE INSTALLED SEPARATELY. GREY INDICATES A COMPONENT THAT IS ALREADY INSTALLED; GREY ITEMS CAN BE REINSTALLED, BUT PRIOR TO INSTALLATION YOU WILL RECEIVE A REMINDER THAT THE COMPONENT IS ALREADY INSTALLED.

4 In the list, check off all the components you want to install. If you want to install all components, click [Select

All]. Clicking [Select All] will select all of the blue-coded components; you must select grey and green components separately.

5 Once you have selected the components you wish to install, click [Install Selected Subsystems]; the

components will be installed.

6 After the components are installed, click [OK], then click [Yes] when asked if you want to reboot the system.

Recovery and Utility disc

The Recovery and Utility disc contains six utilities:

Recovery and Utility tabs

• Diagnostics tab: The Diagnostics tool is designed for use by IT professionals. It is not likely you

will need to use this tool. When you select devices from the Diagnosis window then click [Execute], several tests are performed on the selected components.

• Recovery tab: The Recovery tab contains two tools: 

Restoring the Factory Image (only C: drive) and Restoring the Factory Image (full hard drive recovery). You can use these tools to perform a full hard drive recovery.

• Utility tab: The Utility tab contains three tools: Hard Disk Data Delete, Restore Recovery and

Utility, and Windows Complete PC Restore.

• The Hard Disk Data Delete utility is used to delete all data on the hard disk and prevent the

data from being reused. NOTE: Do not use the Hard Disk Data Delete utility unless you are absolutely certain that you want to erase your entire hard disk, including all partitions.

• Restore Recovery and Utility allows you to restore the first hidden partition.

- Restoring Your Pre-installed Software

• Windows Complete PC Restore utility allows you to restore an image created with W indows

Backup and Restore Center. Windows Complete PC Restore will overwrite the data on your hard disk drive.

• The Diagnostics utility allows the IT professional to determine device status/condition by

executing diagnostics tests on selected system components.

To use the disc, follow the instructions in the “Using the Recovery and Utility Disc” booklet that is packaged with the disc.

- Restoring Your Pre-installed Software

Chapter 5

Care and Maintenance

Caring for your Tablet PC

If you use your STYLISTIC Tablet PC carefully, you will increase its life and reliability. This section provides some tips for looking after the Tablet PC and its devices.

THE SYSTEM CONTAINS COMPONENTS THAT CAN BE SEVERELY DAMAGED BY ELECTROSTATIC

DISCHARGE (ESD). TO MINIMIZE RISK TO THE COMPONENTS, OBSERVE THE FOLLOWING PRECAUTIONS:

• IF YOU DROP YOUR TABLET PC OR DAMAGE THE HOUSING IN ANY WAY, IMMEDIATELY TURN OFF POWER

AND DISCONNECT THE POWER PLUG. FAILURE TO DO SO COULD RESULT IN A SHORT CIRCUIT, SMOKE, AND/OR FIRE. CONTACT FUJITSU SERVICE AND SUPPORT BY PHONE AT 1-80 0-8FUJITSU (1-8 00-838-

5487),

HTTP://WWW.COMPUTERS.US.FUJITSU.COM/SUPPORT TO LEARN HOW TO GET THE SYSTEM REPAIRED.

• BEFORE DOCKING OR UNDOCKING YOUR TABLET PC (WHEN USING A DOCKING CRADLE), IT IS GOOD

PRACTICE TO TOUCH A GROUNDED METAL OBJECT TO DISCHARGE STATIC ELECTRICITY IN YOUR BODY.

• ELECTRICAL EQUIPMENT MAY BE HAZARDOUS IF MISUSED. OPERATIONS OF THIS PRODUCT OR SIMILAR

PRODUCTS, MUST ALWAYS BE SUPERVISED BY AN ADULT. DO NOT ALLOW CHIL DR EN ACCESS TO THE INTERIOR OF ANY ELECTRICAL PRODUCTS AND DO NOT PERMIT THEM TO HANDLE ANY CABLES.

BY EMAIL AT 8FUJITSU@US.FUJITSU.COM, OR THROUGH THE WEBSITE AT

• Your STYLISTIC is a durable but sensitive electronic device. Treat it with respect and care.

• Make a habit of transporting it in a suitable carrying case.

• Do not attempt to service the computer yourself. Always follow installation instructions closely.

• Keep it away from food and beverages.

• If you accidentally spill liquid on your STYLISTIC Tablet PC:

1 Turn it off. 2 Position it so that the liquid can run out and let it dry out for 24 hours, or longer if needed. 3 If your Tablet PC will not boot after it has dried out, call your support representative.

• Do not use your Tablet PC in a wet environment (near a bathtub, swimming pool).

• Always use the AC adapter and batteries that are approved for your Tablet PC.

• Avoid exposure to sand, dust and other environmental hazards.

• Do not expose your T ablet PC to direct sunlight for long periods of time as temperatures above 140°

F (60° C) may damage your Tablet PC.

• Do not put heavy or sharp objects on the computer.

Cleaning your Tablet PC

• Always disconnect the power plug. (Pull the plug, not the cord.)

• Clean your STYLISTIC Tablet PC with a damp, lint-free cloth. Do not use abrasives or solvents.

• Use a soft cloth to remove dust from the screen. Never use glass cleaners.

• Always shut down the computer, unplug the power adapter, and remove the battery when cleaning

or disinfecting the computer exterior or LCD display.

Cleaning guidelines using recommended off-the-shelf cleaners

Computer exterior. To clean the exterior, use one of the following off-the-shelf products:

• Office Depot® #154-616 Notebook Cleaning Kit

• Meridrew Enterprises Klear Screen® Wipes

• 3M CL563 Cleaner Wipes

Note: After cleaning with one of these products, gently polish with a dry, soft, lint-free cloth until the solution is no longer visible.

- Care and Maintenance

Disinfecting STYLISTIC computers

Wipe the surface with a soft cloth wipe and a 50% ethano l solution or use another ethanol-based germicide which has been registered as a hospital disinfectant by the EPA.

• USE OF INCORRECT CLEANERS CAN RESULT IN OPTICAL IMPAIRMENT OF THE LCD AND/OR DAMAGE TO THE

COMPUTER. ALWAYS REFER TO THE CLEANER MANUFACTURER'S GUIDELINES AND MATERIAL SAFETY DATA SHEETS FOR PROPER HANDLING AND USE OF THE PRODUCTS.

• NEVER USE AMMONIA, ACIDIC, OR ALKALINE CLEANERS OR ORGANIC CHEMICALS SUCH AS PAINT THINNER,

ACETONE, PROPYL OR ISOPROPYL ALCOHOL, OR KEROSENE. IT MAY DAMAGE SURFACE FINISHES AND THE COATING OF THE LCD SCREEN.

• NEVER USE COMPRESSED AIR FOR CLEANING YOUR COMPUTER.

Storing your Tablet PC

• If storing your T ablet PC for a month or longer , turn it off, fully char ge the battery , then remove and

store all Lithium Polymer batteries.

• Store your Fujitsu STYLISTIC in a cool, dry location. Temperatures should remain between 13ºF 

(-25ºC) and 140ºF (60ºC).

• Store your tablet and batteries separately. If you store your system with a battery installed, the

battery will discharge, and battery life will be reduced. In addition, a faulty battery might damage your system.

• ALWAYS POWER OFF THE COMPUTER BEFORE TRANSPORTING AND/OR PACKAGING IT. AFTER SHUTTING DOWN

THE SYSTEM, WAIT UNTIL THE STATUS LED PANEL INDICATES POWER OFF CONDITION (I.E., NO LIGHTS ARE ILLUMINATED).

• IT IS POSSIBLE THAT THE UNIT MAY NOT AUTOMATICALLY GO TO POWER OFF OR HIBERNATE MODE WHEN YOU

CLOSE THE LID. THIS SITUATION MAY OCCUR DUE TO PRE-OS BOOT PASSWORD SECURITY SETTINGS OR SOME OTHER APPLICATION RUNNING ON THE COMPUTER.

• ATTEMPTING TO TRANSPORT THE COMPUTER WHILE POWER IS ON MAY DAMAGE THE TABLET PC DUE TO SHOCK

OR OVERHEATING.

- Care and Maintenance

Traveling with your Tablet PC

• Do not transport your Tablet PC while it is turned on.

• You should carry your Tablet PC with you while traveling, rather than checking it in as baggage.

• Never put your Tablet PC through a metal detecto; have it hand-inspected by security personnel.

You can however , put your Tablet PC through a properly tuned X-ray machine. To avoid problems, place it close to the entrance of the machine and remove it as soon as possible or have it handinspected by security personnel. Security officials may require you to turn your system on, so make sure you have a charged battery on hand.

• Take the necessary plug adapters if you're traveling overseas. Check the following diagram to

determine which plug adapter you'll need or ask your travel agent.

Outlet Type Location Outlet Type Location

United States, Canada, parts of Latin

America, Mexico, Japan, Korea,

the Philippines, Taiwan

Russia and the Commonwealth of Independent

States (CIS), most of Europe, parts of Latin

America, the Middle East, parts of Africa, Hong

Kong, India, most of South Asia

United Kingdom,

Ireland, Malaysia,

Singapore, parts of Africa

China, Australia, New

Zealand

Batteries

Caring for your Battery

• Always handle batteries carefully.

• Do not short-circuit the battery terminals (that is, do not touch both terminals with a metal object).

Do not carry lose batteries in a pocket or purse where they may mix with coins, keys, or other metal objects. Doing so may cause an explosion or fire.

- Care and Maintenance

• Do not drop, puncture, disassemble, mutilate or incinerate the battery.

• Recharge batteries only as described in this manual and only in ventilated areas.

• Do not leave batteries in hot locations for more than a day or two. Intense heat can shorten the life

of your battery.

• Do not leave a battery in storage for longer than 6 months without recharging it.

Increasing Battery Life

• Power your Tablet PC through the AC or optional auto/airline adapter whenever possible.

• If your tablet runs on battery power all day, connect it to an AC adapter overnight to recharge it.

• Keep brightness to the lowest level comfortable.

• Set the power management for maximum battery life.

• Put your Tablet PC in Sleep mode when it is turned on and you are not actually using it.

• Limit your media drive access.

• Disable the Media Player auto insert notification function.

Media Care

Caring for your Media (when optional external optical drive is installed)

Media discs are precision devices and will function reliably if given reasonable care.

• Always store your media disc in its case when it is not in use.

• Always handle discs by the edges and avoid touching the surface.

• Avoid storing any media discs in extreme temperatures.

• Do not bend or scratch media discs or set heavy objects on them.

• Do not spill liquids or get dust on media discs.

• Never write on the label surface with a ballpoint pen or pencil. Always use a felt pen.

• If a disc is dirty, use only a DVD/CD cleaner or wipe it with a clean, soft, lint free cloth starting

from the inner edge and wiping to the outer edge.

- Care and Maintenance

• If a disc is subjected to a sudden change in temperature, condensation may form on the surface.

Wipe moisture off with a soft, li nt free cloth and let it dry at room temperature. DO NOT use a hair dryer or heater to dry media discs.

Caring for an Optional Optical Drive

An optional optical drive is durable but you must treat it with care. Please pay attention to the following points:

• The drive rotates the compact disc at a very high speed. Do not carry it around or subject it to shock 

or vibration with the power on.

• Avoid using or storing the drive where it will be exposed to extreme temperatures.

• Avoid using or storing the drive where it is damp or dusty.

• Avoid using or storing the drive near magnets or devices that generate strong magnetic fields.

• Avoid using or storing the drive where it will be subjected to shock or vibration.

• Do not disassemble or dismantle the optical drive.

• Use of a commercially available lens cleaner is recommended for maintenance of your drive.

Secure Digital Cards

Caring for your Cards

Secure Digital Cards are durable, but you must treat them with care. The documentation supplied with your card will provide specific information, but you should pay attention to the following points:

• To keep out dust and dirt, store cards in their protective sleeves when they are not installed.

• Avoid prolonged exposure to direct sunlight or excessive heat.

• Keep the cards dry.

• Do not flex or bend the cards, and do not place heavy objects on top of them.

• Do not force cards into the slot.

• Avoid dropping cards, or subjecting them to excessive vibration.

- Care and Maintenance

Chapter 6

AOUXXXXXXXXXXXXX

STQ550, AtomZ670, W7Pro, 2GB, 62G, WLAN, 10.1WXGA

FPC P/N: FPCMXXXXX

Configuration P/N:

Hard Drive

Part Number

Processor

Model #

Memory

Operating System

Screen Size/Type

Configuration ID

Communications

System Specifications

Specifications

This section provides the hardware and environmental specifications for your Fujitsu STYLISTIC T ablet PC. Specifications of particular configurations will vary.

Configuration Label

The configuration label located on the bottom of your T ablet PC contains specific information regarding the options you’ve chosen for your T ablet PC. Following is an example configuration label.

Microprocessor

Intel® Atom™ Z670 processor (1.5 GHz)

Chipset

• Intel SM35

Memory

System Memory

• DDR2-800 MHz SDRAM memory module.

• Fixed 2GB of total memory (onboard).

Cache Memory

512 kB L2 cache on-die

Video

Video Color and Resolution

Anti-glare 10.1" Wide XGA LED backlit IPS display

• Internal: 1280 x 800 pixel resolution, 16M colors

• External: 1280x720 pixel resolution, 16M colors

• Simultaneous: 1280 x 800, 16M colors

• 160° vertical and horizontal viewing angles

Digitizer

N-trig® DuoSense® technology . Dual Digitizer, consisting of active digitizer and capacitive touch panel (uses active stylus input and up to four finger touch input).

Video RAM

Intel® GMA600 video graphics controller with 3D Accelerator. Maximum 759 MB UMA VRAM

- Specifications

Audio

• Realtek codec ALC269

• Headphones: Stereo headphone jack, 3.5 mm, 1 V

or less, minimum impedance 32 Ohms

rms

• One built-in speaker, 18 mm diameter

• Two built-in dual analog microphones

Mass Storage Device Options

Hard Drive Options

• FDE Solid State Drive, S-ATA/300 (3.0Gbps), 62 GB, with TRIM command support

• FDE Solid State Drive, S-ATA/300 (3.0Gbps), 30 GB, with TRIM command support

Communications

• WLAN: Ralink RT3572 802.11a/b/g/n Wireless LAN USB Device

• Bluetooth: Broadcom BCM20702 Bluetooth USB device for wireless personal area network

communication

• WWAN: Optional integrated 3G Wireless Wide Area Network, Gobi3000 (Sierra Wireless

AirPrime™ MC8355)

Security Features

Trusted Platform Module

The STYLISTIC Q550 Tablet PC may have an optional Trusted Platform Module (TPM) installed for added system security.

Fingerprint Recognition Sensor

Swipe sensor for biometric security.

SmartCard Slot

Integrated SmartCard slot (requires third-party application)

- Specifications

Device Ports

On the STYLISTIC Tablet PC:

• SD Card slot

• One USB 2.0 (Universal Serial Bus) connectors for input/output devices

• One DC In connector

• One HDMI connector

• Docking port (100-pin, to dock with optional STYLISTIC Docking Cradle)

• One stereo headphone jack

• 1.3 megapixel rear-facing web camera, VGA front-facing web camera

On the Optional STYLISTIC Docking Cradle

• Four USB 2.0 connectors for input/output devices

• One DC-in connector

• One docking connector (100-pin, to dock with Tablet PC

Power

Battery Otions

• Lithium Polymer Battery, 2 cells, 7.2V, 19Wh, 2620 mAh

• Lithium Polymer Battery, 4 cells, 7.2V 38Wh 5240 mAh

AC Adapter

Autosensing 100-240V AC, supplying 19V DC, 2.1A, 40W to the Tablet PC; includes an AC cable

Power Management

Conforms to ACPI (Advanced Configuration and Power Interface).

- Specifications

Dimensions and Weight

Overall Dimensions

Approximately 10.8" (w) x 7.56" (d) x 0.64" (h) (275 x 192 x 16.2 mm)

Environmental Requirements

Temperature

Operating: 41° to 95° F (5° to 35° C). Non-operating: 5° to 140° F (–15° to 60° C)

Humidity

Operating: 20% to 85%, relative, non-condensing. Non-operating: 8% to 85%, relative, non-condensing

Altitude

Operating: 10,000 feet (3,048 m) maximum

Popular Accessories

For ordering or additional information on Fujitsu accessories please visit our Web site at  www.shopfujitsu.com or call 1-800-FUJITSU.

Included Software

Depending on your pre-installed operating system, your T ablet PC comes with software for playing audio and video files of various formats. In addition there is virus protection software and Power Management software. The following list indicates the software included with your system.

• Adobe® Reader

• Norton Internet Security™ (60-day free trial)

• FujitsuHL

• OmniPass® Fingerprint application

• Nuance® Keyboard/Handwriting Input

• Microsoft Office Starter 2010

- Specifications

Learning About Your Software

Tutorials

All operating systems and most application software have tutorials built into them upon installation. We highly recommend that you step through the tutorial before you use an application.

Manuals

Included with your Tablet PC you will find manuals for your installed operating system and other preinstalled software. Any manuals that are not included, are available online through the help system of the software. We recommend that you review these manuals for general information on the use of these applications.

Adobe Reader

The Adobe Reader allows you to view, navigate, and print PDF files from across all of the major computing platforms.

FujitsuHL

FujitsuHL provides a variety of tools and shortcuts to commonly-used applications and utilities. Among the features offered by FujitsuHL are the camera application for use with the built-in web camera, a calculator, and links to applications such as Explorer.

Norton Internet Security - TBD TBD

Your system is preinstalled with a free 60-day trial version of Symantec’s Norton Internet Security™. Norton Internet Security is a suite of tools designed to protect your Tablet PC from computer viruses, hackers, spyware, and spam. It assists in the protection of data currently on your hard disk from destruction or contamination. The trial version is activated upon your acceptance of software license agreement. After 60 days, you will need to purchase a subscription from Symantec to download latest virus, spyware, and spam definitions.

- Specifications

OmniPass® Fingerprint application

The fingerprint sensor uses Softex OmniPass which provides password management capabilities to Microsoft Windows operating systems. OmniPass lets you use a "master password" for all Windows, applications, and on-line passwords, and presents a convenient user interface through which you can securely manage passwords, users, and multiple identities for each user.

Nuance® XT9® Keyboard/Handwriting Input

A predictive text application that allows you to quickly complete your tasks with a number of tools, including next-word prediction, enhanced word completion, automatic spell correction, auto-accenting, and smart punctuation.

Microsoft Office Starter 2010 (32-bit)

Microsoft Office Starter 2010 includes reduced-functionality versions of Microsoft Word and Microsoft Excel that include advertising.Microsoft PowerPoint, Microsoft Outlook, and Microsoft Publisher are not included. Customers must purchase an Office 2010 Disc, PKC (Product Key Card), or select one of the full Microsoft Office 2010 suites to activate full-featured Office software on the PC.

Fujitsu offers a PKC (Product Key Card) for Microsoft Office Home and Student 2010 and Microsoft Office Home and Business 2010 (32-bit). Simply enter your product key and you’re ready to go!

Another option is to purchase a full Microsoft Office 2010 suite from either your computer reseller or online from Microsoft.

Operating System

The following operating system configuration is installed on your system:

Microsoft Windows 7 Professional Edition

- Specifications

Regulatory Information

Notice

Changes or modifications not expressly approved by Fujitsu could void this user’s authority to operate the equipment.

FCC NOTICES

Notice to Users of Radios and Television

This equipment has been tested and found to comply with the limit for class B digital devices, pursuant to parts 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver .

• Connect the equipment into an outlet that is on a different circuit than the receiver.

• Consult the dealer or an experienced radio/TV technician for help.

Shielded interconnect cables must be employed with this equipment to ensure compliance with the pertinent RF emission limits governing this device.

DOC (INDUSTRY CANADA) NOTICES

Notice to Users of Radios and Television

This Class B digital apparatus meets all requirements of Canadian Interference-Causing Equipment Regulation s. CET appareil numérique de la class B respecte toutes les exigence du Réglement sur le matérial brouilleur du Canada.

- Regulatory Information

Appendix A: WLAN User’s Guide

FCC Regulatory Information

Please note the following regulatory information related to the optional wireless LAN device.

Regulatory Notes and Statements

Wireless LAN, Health and Authorization for use

Radio frequency electromagnetic energy is emitted from W ireless LAN devices. The energy levels of these emissions, however , are far much less than the electromagnetic energy emissions from wireless devices such as mobile phones. Wireless LAN devices are safe for use by consumers because they operate within the guidelines found in radio frequency safety standards and recommendations. The use of Wireless LAN devices may be restricted in some situations or environments, such as:

• On board an airplane, or

• In an explosive environment, or

• In situations where the interference risk to other devices or services is perceived or identified as har mful.

In cases in which the policy regarding use of Wireless LAN devices in specific environments is not clear (e.g., airports, hospitals, chemical/oil/gas industrial plants, private buildings), obtain authorization to use these devices prior to operating the equipment.

Regulatory Information/Disclaimers

Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment. The manufacturer is not responsible for any radio or television interference caused by unauthorized modification of this device, or the substitution or attachment of connecting cables and equipment other than those specified by the manufacturer. It is the responsibility of the user to correct any interference caused by such unauthorized modification, substitution or attachment. The manufacturer and its authorized resellers or distributors will assume no liability for any damage or violation of government regulations arising from failure to comply with these guidelines.

This device must not be co-located or operated in conjunction with any other antenna or transmitter. For IEEE 802.11a Wireless LAN: For operation within 5.15~5.25 GHz frequency range, it is restricted to indoor

environments, and the antenna of this device must be integral.

Federal Communications Commission statement

This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause interference, and, (2) This device must

accept any interference, including interference that may cause undesired operation of this device.

FCC Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures:

1 Reorient or relocate the receiving antenna. 2 Increase the distance between the equip m en t an d th e re ce ive r. 3 Connect the equipment to an outlet on a circuit different from the one the receiver is connected to. 4 Consult the dealer or an experienced radio/TV technician for help.

FCC Radio Frequency Exposure statement

The available scientific evidence does not show that any health proble ms are as soci ated with usi ng low power wireless devices. Ther e is no proof, however, that these low power wireless devices are absolutely safe. Low power wireless devices emit low levels of radio frequency energy (RF) in the microwave range while being used. Whereas high levels of RF can produce health effects (by heating tissue), exposure to low-level RF that does not produce heating effects causes no known adverse health effects. Many studies of low-level RF exposure have not found any biological effects. Some studies have suggested that some biological effects might occur, but such findings have not been confirmed by additional research.

The wireless LAN radio device has been tested and found to comply with FCC radiation exposure limits set forth for an uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65.

Export restrictions

This product or software contains encryption code which may not be exported or transferred from the US or Canada without an approved US Department of Commerce export license. This device complies with Part 15 of FCC Rules., as well as ICES 003 B / NMB 003 B. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation. Modifications not expressly authorized by Fujitsu America, Inc. may invalidate the user's right to operate this equipment.

Canadian Notice

The device for the 5150 - 5250 MHz band is only for indoor usage to reduce the potential for harmful interference to co-channel mobile satellite systems.

The maximum antenna gain of 6 dBi permitted (for devices in the 5250 - 5350 MHz, 5470 - 5725 MHz and 5725 - 5825 MHz bands) to comply with the e.i.r.p. limit as stated in A9.2 of RSS210.

In addition, users are cautioned to take note that high power radars are allocated as primary users (meaning they have priority) of 5250 - 5350 MHz and 5650 - 5850 MHz and these radars could cause interference and/or damage to LE-LAN devices.

Before Using the Optional Wireless LAN

This manual describes the procedures required to properly set up and configure the optional integrated Wireless LAN USB device (referred to as "WLAN device" in the rest of the manual). Before using the WLAN device, read this manual carefully to ensure its correct operation. Keep this manual in a safe place for future reference.

Wireless LAN Device Covered by this Document

This document is applicable to systems containing the following device:

• Integrated Ralink RT3572 802.11a/b/g/n Wireless LAN USB Device

Characteristics of the WLAN Device

• The WLAN device is a USB module attached to the main board of the mobile computer.

• The WLAN device operates in license-free RF bands, eliminating the need to procure an FCC operating

license. The WLAN operates in the 2.4GHz Industrial, Scientific, and Medical (ISM) RF band and the lower , middle, and upper bands of the 5GHz Unlicensed National Information Infrastructure (UNII) bands.

• The WLAN devices are capable of four operating modes, IEEE802.11a, IEEE802.11b, IEEE802.11g, and

IEEE802.11n

• The WLAN devices are Wi-Fi certified and operate (as a pplicable) at a the maximum dat a rate of 150 Mbp s

(theoretical) in IEEE802.11n mode; 54 Mbps in IEEE802.11a or IEEE802.11g mode; and 11 Mbps in IEEE802.11b mode.

• The WLAN devices support the following encryption methods - WEP, TKIP, CKIP, and AES encryption.

• The Wireless LAN devices are compliant with the following standards: WPA, WPA2, CCX1.0, CCX2.0,

CCX3.0, CCX4.0, and CCX5.0.

Before Using the Optional Wireless LAN

Wireless LAN Modes Using this Device

Ad Hoc Mode

"Ad Hoc Mode" refers to a wireless network architecture where wireless network connectivity between multiple computers is established without a central wireless network device, typically known as Access Point(s). Connectivity is accomplished using only client devices in a peer-to-peer fashion. That is why Ad Hoc networks are also known as peer-to-peer networks. Ad Hoc networks are an easy and inexpensive method for establishing network connectivity between multiple computers. Ad Hoc mode requires that the SSID, network authentication, and encryption key settings are identically configured on all computers in the Ad Hoc network.

Figure 23. Ad Hoc Mode Network

Before Using the Optional Wireless LAN

Access Point (Infrastructure) Mode

ADSL modem, cable modem, or similar

Internet

Wired LAN

Access Point*

Wireless LAN

*An optional hub for a wired LAN may be required depending upon the type of access point used.

Infrastructure mode refers to a wireless network architecture in which devices communicate with wireless or wired network devices by communicating through an Access Point. In infrastructure mode, wireless devices can communicate with each other or with a wired network. Corporate wireless networks operate in infrastructure mode because they require access to the WLAN in order to access services, devices, and computers (e.g., file servers, printers, databases).

Figure 24. Access Point (Infrastructure) Mode Network

Before Using the Optional Wireless LAN

How to Handle This Device

The WLAN device is an optional device that may come pre-installed in your mobile computer. Under normal circumstances, it should not be necessary for you to remove or re-install it. The operating system that your mobile computer comes with has been pre-configured to support the WLAN device.

• The Wireless LAN devices support IEEE802.11a, IEEE802.11b, IEEE802.11g, and IEEE802.11n.

• The WLAN devices operate in the 2.4 GHz ISM band and the 5 GHz lower, middle, and upper UNII bands.

• Microwave ovens may interfere with the operation of WLAN devices since they operate in the same 2.4 GHz

frequency range as IEEE802.1 1b/g/n devices. Interference by microwaves does not occur with IEEE802.11a radio which operates in the 5 GHz RF band.

• Wireless devices that transmit in the 2.4 GHz range may interfere with operation of WLAN devices in

IEEE802.11b/g/n modes. Symptoms of interference include reduced throughput, intermittent disconnects, and many frame errors. It is HIGHLY recommended that these interfering devices b e powered of f to ensure proper operation of the WLAN device.

Deactivating/Disconnecting the WLAN Device

Disconnecting the WLAN device may be desired in certain circumstances (to extend battery life) or where certain environments require it (i.e. hospitals, clinics, airplanes, etc.). The WLAN device can be deactivated by using the Wireless On/Of f Switch, and it can be disconnected in Windows using the WLAN icon in the system tray (Note that disconnecting via the icon in the system tray does not turn off the radio; it continues to transmit and receive even though it’s not connected.).

BEFORE USING THE WIRELESS LAN DEVICE, YOU MUST FIRST INSTALL CLICKME! TO ENSURE THAT

THE CORRECT SOFTWARE FOR YOUR DEVICE IS INSTALLED. SEE “INSTALLING CLICKME!” ON PAGE 42.

Before Using the Optional Wireless LAN

Deactivation Using the Wireless On/Off Switch

Wireless Device Switch

The WLAN device can be deactivated quickly and efficiently by toggling the Wireless Device On/Off Switch to the Off position. The switch has no effect on non-Wireless LAN models.

Figure 25. Wireless LAN/Bluetooth On/Off Switch Location

Disconnection Using the Icon in the Taskbar

Note that disconnecting via the icon in the system tray does not turn off the radio; it continues to transmit and receive even though it’s not connected.

1 Right-click the WLAN icon in the taskbar at the bottom right of your screen. 2 Choose Disconnect from a network.

Activating the WLAN Device

Activation of the WLAN device can be accomplished using the same methods as the deactivation process

• Using the Wireless On/Off Switch

• In Windows, by right-clicking the WLAN icon then clicking “Connect to a network”

Before Using the Optional Wireless LAN

Configuring the Wireless LAN

The WLAN device can be configured to establish wireless network connectivity using the software that is built into Windows. Support for most industry standard security solutions is contained in this software.

Pre-defined parameters will be required for this procedure. Please consult with your network administrator for these parameters:

Configuring the WLAN

1 Click the Start bu tton, then select Control Panel. 2 If the Control Panel is not in Classic View, select Classic View from the left panel. Double-click the Network

Connections icon.

3 Double-click on the Wireless Network Connection icon. 4 Click on [View Wireless Networks] 5 Choose a wireless network. 6 Click [Connect]. 7 Enter the Network Key, if required. 8 Enter any required information. It may be necessary to consult with your network administrator for some of the

information.

9 If you require assistance, go to [Start] -> Help and Support -> Networking and the Web. Select the main topic

in which you are interested, then type in relevant keywords in the Search box.

Connection to the network

After you have configured your computer, you can connect to an active network by performing the following steps:

1 Click on the WLAN icon in the system tray. 2 Select “Connect to a network”. 3 Select a network from the list that appears, and click the [Connect] button.

After you have configured your computer, you can connect to an active network by clicking on the Wireless Network icon in the system tray:

Configuring the Wireless LAN

Troubleshooting the WLAN

Troubleshooting

Causes and countermeasures for troubles you may encounter while using your wireless LAN are described in the following table. If you are unfamiliar with the steps required, consult your System Administrator or go to [Start] -> Help and Support -> Networking and the Web

Problem Possible Cause Possible Solution

Unavailable network  connection

Incorrect network name (SSID) or network key

Weak received signal strength and/or link quality

The WLAN device has been deactivated or disabled

The computer to be connected is turned off

Ad hoc connection: verify that the network names (SSID’s) and network keys (WEP) of all computers to be connected have been configured correctly. SSID’s and WEP key values must be identical on each machine.

Access Point (Infrastructure) connection: set network name (SSID) and network key to the same values as those of the access point.

Set the Network Authentication value identically to that of the Access Point. Please consult your network administrator for this value, if necessary.

Ad hoc connection: Retry connection after shortening the distance to the destination computer or removing any obstacles for better sight.

Access Point (Infrastructure) connection: Retry connection after shortening the distance to the access point or removing any obstacles for better transmission.

Check if the wireless switch is turned On. Go to Start -> Control Panel, and double-click on Windows Mobility Center. If the wireless network is off, click the [Turn wireless on] button.

Check if the computer to be connected is turned ON.

Troubleshooting the WLAN

Problem Possible Cause Possible Solution

Unavailable network



connection (continued)

RF interference from Access Points or other wireless networks

Wireless network authentication has failed

Incorrectly configured network settings

Incorrect IP address configuration

The use of identical or overlapping RF channels can cause interference with the operation of the WLAN device. Change the channel of your Access Point to a channel that does not overlap with the interfering device.

Re-check your Network Authentication, Encryption, and Security settings. Incorrectly configured security settings such as an incorrectly typed WEP key, a misconfigured LEAP username, or an incorrectly chosen authentication method will cause the LAN device to associate but not authenticate to the wireless network.

Recheck the configuration of your network settings.

This only applies to networks using static IP addresses. Please contact your network administrator for the correct settings.

Troubleshooting the WLAN

WLAN Specifications

Specifications

Item Specification

Type of network The integrated Ralink RT3572 802.11a/b/g/n Wireless LAN USB Device conforms to

Transfer rate (Automatic switching) 150 Mbps maximum data rate Active frequency • 802.11n: 2.4 GHz or 5 GHz

Typical operating distances** • 802.11a: 40 ft. (12 m) @ 54 Mbps; 300 ft. (91 m) @ 6 Mbps

Number of channels • 802.11a: 8 independent channels

IEEE 802.11a, 802.11b/g, and 802 .11n, Wi-Fi based*.

• 802.11b/g: 2400~2473 MHz

• 802.11a: 4900 ~ 5850 MHz

• 802.11b: 100 ft. (30 m) @ 11 Mbps; 300 ft. (91 m) @ 1 Mbps

• 802.11g: 100 ft. (30 m) @ 54 Mbps; 300 ft. (91 m) @ 1 Mbps

• 802.11n: Estimated double the operating distance of 802.11g and 802.11a in

their respective frequencies.

• 802.11b/g: 11 channels, 3 non-overlapping channels

• 802.11n: 2.4 GHz - 3 non-overlapping channels when Channel Bonding is not

used; 2 non-overlapping channels when Channel Bonding is used.

5 GHz - 12 non-overlapping UNII channels with or without Channel Bonding Security Encryption Types - WEP, TKIP, AES***, WPA 1.0 compliant Maximum recommended number

of computers to be connected over wireless LAN (during ad hoc connection)

10 units or less ****

WLAN Specifications

* “Wi-Fi based” indicates that the interconnectivity test of the organization which guarantees the interconnectivity of

wireless LAN (Wi-Fi Alliance) has been passed.

** The communication ranges shown above will increase or decrease depending on factors such as number of walls, reflective

material, or interference from external RF sources.

*** Encryption with network key (WEP) is performed using the above number of bits, however, users can set 40 bits/ 104

bits after subtracting the fixed length of 24 bits.

**** Depending on practical environments, the allowable number of computers to be connected may be decreased.

WLAN Specifications

Using the Bluetooth Device

The optional Integrated Bluetooth (V. 3.0) module is a wireless device installed in selected Fujitsu mobile computers.

What is Bluetooth

Bluetooth technology is designed as a short-range wireless link between mobile devices, such as laptop computers, phones, printers, and cameras. Bluetooth technology is used to create Personal Area Networks (PANs) between devices in short-range of each other.

THE WIRELESS LAN/BLUETOOTH ON/OFF SWITCH WILL POWER OFF BOTH THE OPTIONAL WIRELESS LAN

AND BLUETOOTH DEVICES AT THE SAME TIME. TO ENABLE OR DISABLE EITHER ONE OF THE

DEVICES INDIVIDUALLY, PERFORM THE FOLLOWING STEPS:

1 Slide the Wireless LAN/Bluetooth on /o ff switch to On position . 2 Right-click on the Bluetooth icon in the Windows notification area on the right side of the

taskbar.

3 Select Turn Adapter On (or Off). 4 Click [OK].

Where to Find Information About Bluetooth

For additional information about Bluetooth Technology, visit the Bluetooth Web site at: www.bluetooth.com.

Using the Bluetooth Device

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. The Bluetooth antenna is located on the front edge of the right palm rest and is exempt from minimum distance criteria due to its low power.

The transmitters in this device must not be co-located or operated in conjunction with any other antenna or transmitter.

Canadian Notice

To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing.

Warranty

Users are not authorized to modify this product. Any modifications invalidate the warranty. This equipment may not be modified, altered, or changed in any way without signed written permission

from Fujitsu. Unauthorized modification will void the equipment authorization from the FCC and Industry Canada and the warranty.

Using the Bluetooth Device

Appendix B: Fingerprint Sensor Device

Fingerprint Sensor Device

Introducing the Fingerprint Sensor Device

Your system has a fingerprint sensor device at the bottom left below the display screen.

Figure 26. Fingerprint sensor

With a fingerprint sensor , you can avoid having to enter a username and password every time you want to:

• Log onto Windows

• Resume from sleep mode

• Cancel a password-protected screen saver

• Log into home pages that require a username and password

After you have “enrolled” - or registered - your fingerprint, you can simply swipe your fingertip over the sensor for the system recognize you.

The fingerprint sensor uses Softex OmniPass which provides password management capabilities to Microsoft Windows operating systems. OmniPass enables you to use a "master password" for all Windows, applications, and on-line passwords.

OmniPass requires users to authenticate themselves using the fingerprint sensor before granting access to the Windows desktop. This device results in a secure authentication system for restricting access to your computer, applications, web sites, and other password-protected resources.

OmniPass presents a convenient graphical user interface, through which you can securely manage passwords, users, and multiple identities for each user.

Getting Started

This section guides you through the preparation of your system for the OmniPass fingerprint recognition application. You will be led through the OmniPass installation process. You will also be led through the procedure of enrolling your first user into OmniPass.

Installing OmniPass

If OmniPass has already been installed on your system, skip this section and go directly to “User Enrollment” on page 102. You can determine whether OmniPass has already been installed by checking to see if the following are present:

• The gold key-shaped OmniPass icon in the system tray at the bottom right of the screen.

• The Softex program group in the Programs group of the Start menu

System Requirements

The OmniPass application requires space on your hard drive; it also requires specific Operating Systems (OS’s). The minimum requirements are as follows:

• Windows XP Professional operating system or later

100

- Introducing the Fingerprint Sensor Device

• At least 35 MB available hard disk space

Installing the OmniPass Application

If OmniPass is already installed on your system, go to “User Enrollment” on page 102. Otherwise continue with this section on software installation.

• INSTALLATION OF THE APPLICATION REQUIRES THAT YOU HAVE AN EXTERNAL OPTICAL DRIVE ATTACHED TO

YOUR SYSTEM.

• FOR INSTALLATION, OMNIPASS REQUIRES THAT THE USER INSTALLING OMNIPASS HAVE ADMINISTRATIVE

PRIVILEGES TO THE SYSTEM. IF YOUR CURRENT USER DOES NOT HAVE ADMINISTRATIVE PRIVILEGES, LOG OUT AND THEN LOG IN WITH AN ADMINISTRATOR USER BEFORE PROCEEDING WITH OMNIPASS INSTALLATION.

To install OmniPass on your system you must:

1 Insert the installation media for the OmniPass application into the appropriate drive. If you are installing from

CD-ROM or DVD-ROM, you must find and launch the OmniPass installation program (setup.exe) from the media.

2 Follow the directions provided in the OmniPass installation program. Specify a loca tion to which you would like

OmniPass installed

3 Once OmniPass has completed installation you will be prompted to restart you system. Once your system has

rebooted you will be able to use OmniPass. If you choose not to restart immediately after installation, OmniPass will not be available for use until the next reboot.

4 The installation program automatically places an icon (Softex OmniPass) in the Windows Control Panel as well

as a golden key shaped icon in the taskbar.

. It is recommended that you NOT install OmniPass in the root directory (e.g. C:\).

Verifying Information about OmniPass

After you have completed installing OmniPass and restarted your system, you may wish to check the version of OmniPass on your system.

To check the version information of OmniPass:

1 From the Windows Desktop, double-click the key-shaped OmniPass icon in the taskbar (usually located in the

lower right corner of the screen), or,

101

- Introducing the Fingerprint Sensor Device

Click the Start button, select Settings, and click Control Panel. Double-click Softex OmniPass in the Control Panel, and the OmniPass Control Center will appear. If it does not appear, then the program is not properly installed, or, Click the Start button, select Programs, and from the submenu select the Softex program group, from that submenu click OmniPass Control Center.

2 Select the About tab at the top of the OmniPass Control Center. The About tab window appears with version

information about OmniPass.

Uninstalling OmniPass

FOR UNINSTALLATION, OMNIPASS REQUIRES THAT THE USER UNINSTALLING OMNIPASS HAVE

ADMINISTRATIVE PRIVILEGES TO THE SYSTEM. IF YOUR CURRENT USER DOES NOT HAVE ADMINISTRATIVE PRIVILEGES, LOG OUT AND THEN LOG IN WITH AN ADMINISTRATOR USER BEFORE PROCEEDING WITH OMNIPASS UNINSTALLATION.

To remove the OmniPass application from your system:

1 Click Start on the Windows taskbar. Select Settings, and then Control Panel. 2 Double-click Add/Remove Programs. 3 Select OmniPass, and then click Change/Remove. 4 Follow the directions to uninstall the OmniPass application. 5 Once OmniPass has finished uninstalling, reboot your system when prompted.

User Enrollment

Before you can use any OmniPass features you must first enroll a user into OmniPass.

Master Password Concept

102

- Introducing the Fingerprint Sensor Device

Fujitsu MC8355, WL0025 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Preface

About This Guide

Conventions Used in the Guide

Fujitsu Contact Information

Getting to Know Your Tablet PC

Overview

Locating the Connectors and Controls

Front Features

Back Features

Status Indicator Panel

Display Panel

Adjusting Display Panel Brightness

Active Digitizer/Touchscreen

Active Digitizer Display

Using the Capacitive Touchscreen

Accessing the OnScreen TouchPad

Using the Nuance SoftKeyboard

Caring for the Pen

Tablet PC Buttons

Getting Started with Your Tablet PC

Power Sources

Connecting the Power Adapters

Starting Your STYLISTIC Tablet PC

Power On

Boot Sequence

Hard Disk Drive Passwords

BIOS Setup Utility

Booting the System

Starting Windows the first time

Registering Your STYLISTIC Tablet PC with Fujitsu

Installing ClickMe!

Power Management

Power/Suspend/Resume Switch

Sleep Mode

Hibernation Feature

Windows Power Management

Restarting the System

Powering Off

User-Installable Features

Lithium Polymer Battery

Recharging the Batteries

Replacing the Battery

Secure Digital Cards

Installing SD Cards

Removing an SD Card

Troubleshooting Your Tablet PC

Troubleshooting

Identifying the Problem

Specific Problems

Power On Self Test Messages

Restoring Your Pre-installed Software

Drivers and Applications Restore Disc

Care and Maintenance

Caring for your Tablet PC

Cleaning your Tablet PC

Storing your Tablet PC

Traveling with your Tablet PC

Batteries

Media Care

Secure Digital Cards

System Specifications

Specifications

Configuration Label

Microprocessor

Chipset

Memory

Video

Audio

Mass Storage Device Options

Communications

Security Features

Device Ports

Power

Dimensions and Weight

Environmental Requirements

Popular Accessories
