Data Sheet Fujitsu L19T-1 LED Display
Data Sheet
Fujitsu L19T-1 LED Display
All-round display: 47 cm (18.5-inch) widescreen Ease of use at a reasonable price
The L19T-1 LED comes in a 16:9 format with a trendy style. There is no compromise in
picture quality and energy efciency. It is the best choice to get display with restricted desk space. It is easy-to-use and once it is installed you never have to adjust it again ­proven Fujitsu quality.
Widescreen display with LED backlit panel in optimum 16:9 movie format
< 1W/inch typical power consumption and Energy Star compliant
5 ms fast response time (typ.) - perfect for ofce and internet
1366 x 768 HD resolution for good entertainment experience
Due to integrated speakers no further accessories needed
Page 1 / 4 http://ts.fujitsu.com/displays
Data Sheet Fujitsu L19T-1 LED Display
Technical details
Special features
LED backlit panel, ECO Status LED: 3 colors for 3 modes
Stand details
Stand removable Tilt angle -5° / +15°
Picture performance
Contrast - typical 1,000:1 Contrast - advanced 5,000,000:1 Response time typical 5 ms Viewing angle (h/v) - typical 176°/170° Color performance 16.7 million colors (Hi-FRC) Brightness - typical 250 cd/m²
Size and resolution
Aspect ratio 16:9 Diagonal Size 47 cm (18.5-inch) Resolution (native) 1366 x 768 pixel (recommended) Resolution (interpolated) 1024 x 768 pixel, 800 x 600 pixel, 640 x 480 pixel, 720 x 400 pixel Picture size 409.8 x 230.4 mm Pixel Pitch 0.3 mm
Frequencies
Horizontal 30 kHz to 83 kHz Vertical 55 - 76 Hz Frequencies - bandwidth 135 Mhz
Connectivity
VGA/D-SUB 1 x D-SUB Audio signal input 3.5 mm stereo phone jack Audio sound output 2 x 1 W
OSD Languages and setting options
Languages Arabic, Czech, Danish, Dutch, English, Finnish, French, German, Italian, Norwegian, Polish, Portuguese, Russian,
Spanish, Swedish, Turkish
Brightness / Contrast Brightness, Contrast Color 6500K, 7500K, 9300K, Native, sRGB, Custom Color Image adjust H-Position, V-Position, Sharpness, Clock, Phase Audio Mute, Volume Information Resolution/mode, Signal input
Power consumption (typical, w/o sound)
Soft switch off 0.4 W Power save mode 0.4 W Operating with EPA settings 15.7 W Operating maximum brightness 19.0 W
Electrical values
Rated voltage range 100 V - 240 V Rated frequency range 50 Hz - 60 Hz Protection class 1
Compliance
Europe CE, RoHS, WEEE, IT-Eco-Declaration Russia GOST USA/Canada FCC Class B, cUL
Page 2 / 4 http://ts.fujitsu.com/displays
Data Sheet Fujitsu L19T-1 LED Display
Australia/New Zealand C-Tick Saudi Arabia SASO Global ENERGY STAR® 5.0, ISO9241-307 (Pixel fault class I) Compliance link https://sp.ts.fujitsu.com/sites/certicates/default.aspx
Quality and Reliability
MTBF (demonstrated) 50000 h
Dimensions / Weight / Environmental
Dimension without stand (W x D x H) 440.37 x 50.93 x 274.93 mm Dimension with stand (W x D x H) 440.3 x 179.79 x 340.9 mm Weight (unpacked) 2.3 kg Operating ambient temperature 5 - 35°C
Miscellaneous
Miscellaneous VESA DDC/ CI, Standardized mounting interface VESA FP MP MI 100 mm, Kensington lock
Package content
Display delivered accessories Data cable 1.8 m, D-SUB (15-pin), Audio cable 1.8 m, Power cable for wall socket (Euro-Schuko-Type CEE7) 1.8 m,
User manual, Warranty booklet, Quickstart yer
Order information
Order Code S26361-K1343-V160 EAN-No. 4049699196966
Warranty
Standard Warranty 3 years Service level Collect & Return Service (depending on country) Service Weblink http://ts.fujitsu.com/Supportservice
Page 3 / 4 http://ts.fujitsu.com/displays
Data Sheet Fujitsu L19T-1 LED Display
More information
Fujitsu platform solutions
In addition to Fujitsu L19T-1 LED, Fujitsu
provides a range of platform solutions. They
combine reliable Fujitsu products with the
best in services, know-how and worldwide partnerships.
Dynamic Infrastructures
With the Fujitsu Dynamic Infrastructures approach, Fujitsu offers a full portfolio of IT
products, solutions and services, ranging from clients to datacenter solutions, Managed
Infrastructure and Infrastructure as-a­Service. How much you benet from Fujitsu
technologies and services depends on the
level of cooperation you choose. This takes IT exibility and efciency to the next level.
Computing Products
www.fujitsu.com/global/services/computing/
Software
www.fujitsu.com/software/
More information
Learn more about Fujitsu L19T-1 LED, please contact your Fujitsu sales representative or Fujitsu Business partner, or visit our website. http://ts.fujitsu.com/displays
Fujitsu green policy innovation
Fujitsu Green Policy Innovation is our worldwide project for reducing burdens on the
environment. Using our global know-how, we aim to resolve
issues of environmental energy efciency through IT. Please nd further information at http://www. fujitsu.com/global/about/environment/
Copyrights
All rights reserved, including intellectual property rights. Changes to technical data
reserved. Delivery subject to availability. Any
liability that the data and illustrations are complete, actual or correct is excluded. Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which by third parties for their own purposes may infringe the rights of such owner.
For further information see http://ts.fujitsu.
com/terms_of_use.html
Copyright © Fujitsu Technology Solutions
Disclaimer
Technical data are subject to modication and delivery subject to availability. Any liability
that the data and illustrations are complete, actual or correct is excluded. Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which by third parties for their own purposes may infringe the rights of such owner
Contact
FUJITSU Technology Solutions Website: http://ts.fujitsu.com 2011-01-10 CE-EN
