Data Sheet Fujitsu CELSIUS H700 Mobile Workstation
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Data Sheet
Fujitsu CELSIUS H700
Mobile Workstation
Workstation power on-the-go
CELSIUS H700
The CELSIUS H700 delivers workstation power in a notebook form factor. Featuring the latest Intel®
processors and powerful NVIDIA® Quadro® graphics, the CELSIUS H700 delivers uncompromising
performance without tethering you to the ofce. Secure and reliable, it is ideal for business
environments such as CAD and digital content creation.
Workstation performance
Higher productivity thanks to mobile workstation performance
Professional NVIDIA® Quadro® graphics, Intel® Core™ i5 & i7 processors with vPro™ technology
Unlimited connectivity
Online anywhere, anytime.
Optional integrated WLAN, 3G/UMTS and Bluetooth®
Ultimate security
Protect your data from non-authorized access
Integrated SmartCard reader and ngerprint sensor
Advanced Reliability
Protects your notebook against physical damage
Spill-resistant keyboard and hard disk drive ShockSensor
ISV certification
Excellent performance and absolute stability in professional environments
Comprehensive certication for workstation applications
Page 1 / 7 http://ts.fujitsu.com/celsius
Data Sheet Fujitsu CELSIUS H700 Mobile Workstation
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Components
Processor Intel® Core™ i7-840QM processor (1.86 GHz, 8 MB)
Intel® Core™ i7-740QM processor (1.73 GHz, 6 MB)
Intel® Core™ i7-820QM processor (1.73 GHz, 8 MB)
Intel® Core™ i7-720QM processor (1.6 GHz, 6 MB)
Intel® Core™ i7-640M processor (2.80 GHz, 4 MB)
Intel® Core™ i7-620M processor (2.66 GHz, 4 MB)
Intel® Core™ i5-560M processor (2.66 GHz, 3 MB)
Intel® Core™ i5-540M processor (2.53 GHz, 3 MB)
Intel® Core™ i5-520M processor (2.4 GHz, 3 MB)
Operating system
Operating system optional preinstalled Genuine Windows® 7 Professional 64-bit
Operating system compatible Genuine Windows® 7 Professional 32-bit
Genuine Windows® XP Professional
Operating system notes Driver support for Microsoft® Windows® XP Professional / 7 Professional
Memory modules 2 GB (1 module(s) 2 GB) DDR3, 1066 MHz, PC3-8500, SO DIMM
2 GB (1 module(s) 2 GB) DDR3, 1333 MHz, PC3-10600, SO DIMM
4 GB (1 module(s) 4 GB) DDR3, 1333 MHz, PC3-10600, SO DIMM
Supported capacity RAM (min.) 2 GB
Supported capacity RAM (max.) 8 GB
Memory slots total 2
Memory slot type DIMM (DDR3)
Hard disk drives (internal) SSD SATA, 256 GB, 2.5-inch, S.M.A.R.T.
SSD SATA, 128 GB, 2.5-inch, S.M.A.R.T.
SATA, 7200 rpm, 500 GB, 2.5-inch, S.M.A.R.T.
SATA, 7200 rpm, 320 GB, 2.5-inch, S.M.A.R.T.
SATA, 5400 rpm, 320 GB, 2.5-inch, S.M.A.R.T.
FDE, 5400 rpm, 320 GB, 2.5-inch, S.M.A.R.T.
Hard disk notes ShockSensor for HDD shock protection
One Gigabyte equals one billion bytes, when referring to hard disk drive capacity.
Accessible capacity may vary, also depending on used software
WLAN (optional) Atheros Minicard b/g/n
Intel® Centrino® 6200 802.11 a/b/g/n
Wireless technologies
Antennas 2 Dual band WLAN antennas, 2 UMTS antennas
WLAN notes Import and usage according to country-specic regulations.
3G/UMTS (optional) Sierra Wireless Gobi 2000 (downlink 7.2 Mbit/s, uplink 5.76 Mbit/s)
Bluetooth (optional) Bluetooth 2.1
Display 39.6 cm (15.6-inch), LED backlight, (HD+), Anti-glare display, magnesium, 1600 x 900 pixel, 300:1, 220 cd/m²
39.6 cm (15.6-inch), LED backlight, (Full HD), Anti-glare display, magnesium, 1920 x 1080 pixel
Modular bay options 2nd battery
2nd hard disk drive
Blu-ray Disc™ Triple Writer, SATA
DVD Super Multi
Weight saver
Page 2 / 7 http://ts.fujitsu.com/celsius
Data Sheet Fujitsu CELSIUS H700 Mobile Workstation
Base unit CELSIUS H700
General system information
Chipset Intel® QM57
BIOS features BIOS based on Phoenix SecureCore
Graphics
Max. resolution external display 2560 x 1600 pixel via DisplayPort and Dual Link DVI
Graphics brand name NVIDIA® Quadro® FX 880M
Graphics features DualView
Dedicated video memory 1 GB (GDDR3 VRAM)
Interfaces
DC-in 1
Audio: line-out / headphone 1
Audio: line-in / microphone 1
Internal microphones 2 digital array microphones
USB 2.0 total 4
VGA 1
DisplayPort 1
Serial (RS-232) 1
Ethernet (RJ-45) 1
FireWire (IEEE1394) 1
Kensington Lock support 2
PC Card slot (Type I/II) 1
Memory card slots 1 (SD/MS/MSPro)
Express card slots 1
SmartCard slot 1
SIM card slot 1
eSATA 1
Interface Module notes Anytime USB charge functionality
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Wired communication
LAN 10/100/1000 MBit/s Intel® 82577 LM
Multimedia
Audio type On board
Audio codec Realtek ALC269
Audio features Stereo speakers, 2 internal microphones
Camera Optional: Built-in webcam, 1.3 megapixel, VGA camera
Power supply
AC adapter 19 V / 100 W (5.27 A)
Rated voltage range 100 V - 240 V (AC Input)
Rated frequency range 50 Hz - 60 Hz
1st battery Li-Ion battery 8-cell, 5.800 mAh, 84 Wh
2nd battery (optional) Li-Ion, 3800 mAh, 41 Wh
Li-Ion battery 3-cell, 3800 mAh, 41 Wh
Battery features Dynamic charge supported (rapid charge)
Benchmark Mobile Mark 2005
Runtime 1st battery up to 5 h
Runtime 1st + 2nd battery up to 9 h
Battery notes Battery life may vary depending on product model, conguration, applications, power management settings and
features utilized. Battery recharge time depends on usage.
Page 3 / 7 http://ts.fujitsu.com/celsius
Data Sheet Fujitsu CELSIUS H700 Mobile Workstation
Dimensions / Weight / Environmental
Dimensions (W x D x H) 372 x 255 x 36 mm
Weight 2.75 kg
Weight notes Actual weight may vary depending on conguration
Operating ambient temperature 5 - 35°C
Operating relative humidity 20 - 80 % (relative humidity, non-condensing)
Additional Software
Additional software (preinstalled) Adobe Acrobat Reader
Application Panel
Display Manager
EasyGuide online user documentation
Nero Essentials S (burning software)
Norton Internet Security (incl. Firewall)
Power Saving Utility
ShockSensor Utility
SmartCase Logon+
Toshiba Bluetooth Stack (only with Windows Vista® or Windows® XP operating systems)
Wireless Selector Utility
Additional software (optional) Drivers & Utilities DVD (DUDVD)
UMTS connection manager (optional with UMTS)
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Manageability
Manageability features DeskUpdate Driver management
iAMT Intel® Active Manageability Technology v6.0 (not activated, not set up)
Intel® vPro™ technology
Manageability type DeskView 10.x client management including:
DeskView features On/Ofine remote client management
Detailed system inventory management and reports
BIOS Management
Remote power management
System notications
Security Remote Control
DeskView Helpdesk Integration
Supported standards WMI
PXE
BootP (made4you)
WoL (Wake on LAN)
Manageability link http://ts.fujitsu.com/solutions/it_infrastructure_solutions/manageability/featurender.html
Security
Physical security Kensington Lock support
System security Advanced Theft Protection
Computrace® enabled BIOS
Optional: Trusted platform module (TPM 1.2)
Norton Internet Security (incl. Firewall) 90 days version
User security Integrated Fingerprint Sensor
Separate SmartCard slot
Hard disk password
SystemLock BIOS SmartCard security
User and supervisor BIOS password
Compliance
Product CELSIUS H700
Germany GS
Europe CE
USA/Canada cCSAus
FCC Class B (depending on wireless conguration)
Page 4 / 7 http://ts.fujitsu.com/celsius
Data Sheet Fujitsu CELSIUS H700 Mobile Workstation
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Compliance
Global RoHS (EU & China)
Medical EMC standard IEC60601-1-2 in combination with medical kit
ENERGY STAR® 5.0 (depending on conguration)
Compliance link https://sp.ts.fujitsu.com/sites/certicates/default.aspx
Portreplicator interfaces (optional)
Port replicator/AC adapter/EU-cable kit Port replicator/AC adapter/GB-cable kit
DC-in 1 1
Audio: line-in 1 1
Audio: line-out 1 1
USB 2.0 total 4 4
DisplayPort 1 1
VGA 1 1
DVI 1 1
Serial (RS-232) 1 1
Ethernet (RJ-45) 1 1
Parallel 1 1
Kensington Lock support 2 2
eSATA 1 1
Warranty
Standard Warranty 3 years (depending on country)
Service level Collect & Return Service / Bring-in Service (depending on county specic requirements)
Maintenance and Support Services - the perfect extension
Recommended Service 5x9, Response Time: Next Business Day
Service Weblink http://ts.fujitsu.com/Supportservice
Recommended Accessories
MicroSaver® Combination
Notebook Lock
Prestige Case Midi
Protect your notebook-and the personal information you have stored-from
theft. Lock it with this easy-to-use, keyless 4-wheel combination lock from
Kensington, the leader in notebook security. .
Zip-down case with cushioned Notebook compartment; separate second
compartment for mobile accessories and documents; exterior compartment
with workstation for mobile accessories; cushioned shoulder strap; trolley
fastening strap an the back side For Tablet PC and Notebooks up to 370 x
295 x 50 mm
Order Code:
S26361-F1650-L500
Order Code:
S26391-F119-L60
Presenter IV Air
Page 5 / 7 http://ts.fujitsu.com/celsius
Do you often give presentations? Would you like to communicate pro
actively with your audience during your presentations? Step up to the plate
and make use of your freedom of movement with the Presenter IV Air
Whether you’re leang through informative material, adjusting audio les
or using the laser pointer to indicate special features, you have everything
reliably under control with this presenter.
Thanks to the 2D air mouse function you can even do away with the cable
mouse and navigate through your les with ease
Order Code:
S26381-K440-L100
Data Sheet Fujitsu CELSIUS H700 Mobile Workstation
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Wireless Laser Mouse WL5600
USB
HS S2000NC Headset
Prestige Case Midi
For everybody looking for something very special this is the the perfect
wireless pointing device. The Laser Mouse WL5600 offers much more
comfort and features than a usual mouse. It is tted with 10 buttons - 6 of
them are programmable. Together with the 4-way-scroll functionality (Tilt
Wheel Technology) it is the right tool for you. Work on different surfaces or
switch with one button-click between 800 and 1200 dpi. Your mouse will
always be powered thanks to the USB charger station containing a second
set of NiMH batteries. Manage your everyday work relaxed and efciently.
The HS S2000NC Headset offers more than current headsets. Besides superb
sound quality, the headset provides an impressive feature: a button to
switch off noise and disburden your ears of unwanted noise level.
Zip-down case with cushioned Notebook compartment; separate second
compartment for mobile accessories and documents; exterior compartment
with workstation for mobile accessories; cushioned shoulder strap; trolley
fastening strap an the back side For Tablet PC and Notebooks up to 370 x
295 x 50 mm
Order Code:
S26381-K419-L100
Order Code:
S26391-F7139-L3
Order Code:
S26391-F119-L60
Page 6 / 7 http://ts.fujitsu.com/celsius
Data Sheet Fujitsu CELSIUS H700 Mobile Workstation
More information
Windows®. Life without Walls™.
Fujitsu recommends Windows 7.
Fujitsu platform solutions
In addition to Fujitsu CELSIUS H700, Fujitsu
provides a range of platform solutions. They
combine reliable Fujitsu products with the
best in services, know-how and worldwide
partnerships.
Dynamic Infrastructures
With the Fujitsu Dynamic Infrastructures
approach, Fujitsu offers a full portfolio of IT
products, solutions and services, ranging
from clients to datacenter solutions, Managed
Infrastructure and Infrastructure as-a-
Service. How much you benet from Fujitsu
technologies and services depends on the
level of cooperation you choose. This takes IT
exibility and efciency to the next level.
Computing Products
www.fujitsu.com/global/services/computing/
Software
www.fujitsu.com/software/
More information
Learn more about Fujitsu CELSIUS
H700, please contact your Fujitsu sales
representative or Fujitsu Business partner, or
visit our website.
http://ts.fujitsu.com/celsius
Fujitsu green policy innovation
Fujitsu Green Policy Innovation is our
worldwide project for reducing burdens on the
environment.
Using our global know-how, we aim to resolve
issues of environmental energy efciency
through IT.
Please nd further information at http://www.
fujitsu.com/global/about/environment/
Copyrights
All rights reserved, including intellectual
property rights. Changes to technical data
reserved. Delivery subject to availability. Any
liability that the data and illustrations are
complete, actual or correct is excluded.
Designations may be trademarks and/or
copyrights of the respective manufacturer,
the use of which by third parties for their
own purposes may infringe the rights of such
owner.
For further information see http://ts.fujitsu.
com/terms_of_use.html
Copyright © Fujitsu Technology Solutions
Disclaimer
Technical data are subject to modication and
delivery subject to availability. Any liability
that the data and illustrations are complete,
actual or correct is excluded. Designations
may be trademarks and/or copyrights of the
respective manufacturer, the use of which
by third parties for their own purposes may
infringe the rights of such owner
Contact
FUJITSU Technology Solutions
Website: http://ts.fujitsu.com
2010-12-06 CE-EN
Page 7 / 7 http://ts.fujitsu.com/celsius
All rights reserved, including intellectual property rights. Changes to technical data reserved. Delivery subject to availability.
Any liability that the data and illustrations are complete, actual or correct is excluded.
Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which by third parties for their
own purposes may infringe the rights of such owner.
For further information see http://ts.fujitsu.com/terms_of_use.html
Copyright © Fujitsu Technology Solutions
Loading...
