Monitor
Operating Manual
English
SCALEOVIEW H17-1/H19-1/ H19-1W
Downloaded from ManualMonitor.com Manuals
Are there…
... any technical problems or other questions which you would like to be clarified?
Please contact
our help desk (see Warranty Booklet).
The latest information on our products, tips, updates, etc., can be found on the internet under:
http://www.fujitsu-siemens.com
Downloaded from ManualMonitor.com Manuals
Downloaded from ManualMonitor.com Manuals
This manual was produced by
Xerox Global Services
Published by
Fujitsu Siemens Computers GmbH
AG 08/06
Edition 2
Order no.: A26361-K1086-Z120-1-7619
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/
H19-1/H19-1W
Operating Manual
August 2006 edition
Downloaded from ManualMonitor.com Manuals
VESA, DDC and DPMS are registered trademarks of Video Electronics Standards
Association.
Copyright © Fujitsu Siemens Computers GmbH 2006
All rights, including rights of translation, reproduction by printing, copying or similar methods,
in part or in whole, are reserved.
Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility model or design,
are reserved.
Delivery subject to availability. Right of technical modification reserved.
Downloaded from ManualMonitor.com Manuals
Contents
Introduction........................................................................................................................................... 1
Important notes..................................................................................................................................... 2
Safety notes.................................................................................................................................. 2
Power cable.................................................................................................................................. 3
Transport ...................................................................................................................................... 4
Cleaning ....................................................................................................................................... 4
CE marking................................................................................................................................... 4
FCC Class B Compliance Statement ........................................................................................... 4
Declaration of Conformity............................................................................................................. 5
Energy Star Guidelines................................................................................................................. 5
Disposal and recycling ................................................................................................................. 6
Checking the contents of the consignment........................................................................................... 6
Installing an ergonomic video workstation............................................................................................ 7
Mounting and removing the monitor base ............................................................................................ 8
Mounting monitor base................................................................................................................. 8
Removing monitor base ............................................................................................................... 8
Connecting the monitor ................................................................................................................ 9
Connecting cables to the monitor................................................................................................. 9
Connecting cables to the computer............................................................................................ 10
Operation of the monitor..................................................................................................................... 11
Adjusting rake............................................................................................................................. 11
Switching the monitor on/off ....................................................................................................... 11
Notes on power management .................................................................................................... 12
Changing the monitor settings.................................................................................................... 13
Monitor settings using the OSD menu........................................................................................ 14
Troubleshooting.................................................................................................................................. 18
Notes regarding the DIN EN ISO 13406-2 standard .......................................................................... 20
Technical data .................................................................................................................................... 21
VESA-DDC-compatible VGA interface....................................................................................... 22
Preset operating modes ............................................................................................................. 22
Power supply plug ...................................................................................................................... 23
Monitor port DVI-D/DVI-I ............................................................................................................ 24
Pin assignment D-SUB............................................................................................................... 25
A26361-K1086-Z120-1-7619, edition 2
Downloaded from ManualMonitor.com Manuals
Contents
A26361-K1086-Z120-1-7619, edition 2
Downloaded from ManualMonitor.com Manuals
Introduction
Your new LCD (Liquid Crystal Display) monitor SCALEOVIEW H17-1/H19-1/H19-1W offers
numerous features and functions, for example:
● TFT display (Thin Film Transistor; active matrix)
● minimal space requirements thanks to slim casing
● optimum ergonomic characteristics (totally distortion-free, excellent picture definition and colour
purity right into the corners)
● high degree of brightness and good contrast
● high resolution: H17-1/H19-1 (1280 x 1024); H19-1W (1440 x 900)
● size of the display area comparable to that of a 19" (H17-1) or 21" (H19-1) CRT (Cathode Ray
Tube) monitor
● presentation of up to 16.2 million colours (in conjunction with an appropriate graphics card)
● automatic scanning of horizontal frequencies from 30 to 83 kHz and refresh rates (vertical
frequencies) from 55 to 75 Hz (absolutely flicker-free)
● digital screen controller with microprocessor for storing 49 different display modes
● freely adjustable colour alignment for matching the screen colours to the colours of various
input and output devices
● convenient operation via integrated OSD (On-Screen-display) menu
● VESA-DDC compatibility
● VESA-FPMPMI compatibility (Flat Panel Monitor Physical Mounting Interface) - mechanical
interface to swivel arm and wall bracket)
● plug&play capability
● power management for reducing power consumption when the computer is not in use
● compliance with the recommendations in accordance with TCO’03
In normal screen mode (dark characters against a light background) the monitor satisfies the
ergonomic requirements for the GS symbol.
This operating manual contains important information you require to start up and run your LCD
monitor.
A graphics card (screen controller) with VGA interface or a digital graphics card with DVI interface is
required to control the SCALEOVIEW H17-1/H19-1/H19-1W LCD monitor. The monitor processes
the data supplied to it by the screen controller. The screen controller/the associated driver software is
responsible for setting the modes (resolution and refresh rate).
When putting the monitor into operation for the first time, the screen display should be optimally
adapted to the screen controller used and adjusted in accordance with your needs (see the
"
Changing the monitor settings" section in the "Operation of the monitor" chapter).
Target group
You don't need to be an "expert" to perform the operations described here. Do, however, read the
Important notes" chapter in the operating manual of the computer and in this operating manual.
"
In the event of any problems occurring, please contact your sales outlet or our help desk.
A26361-K1086-Z120-1-7619, edition 2 1
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/H19-1/H19-1W
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
► Text which follows this symbol describes activities that must be performed in the order shown.
"Quotation marks" indicate names of chapters or terms.
This font indicates filenames and menu items.
This font indicates screen outputs.
Additional information
Details of how you set the resolution and refresh rate are provided in the documentation on your
screen controller/the associated driver software.
Pay particular attention to text marked with this symbol. Failure to observe this warning
endangers your life, destroys the device, or may lead to loss of data.
!
Supplementary information, remarks, and tips follow this symbol.
i
Important notes
In this chapter you will find information regarding safety which is essential to take note of
with your monitor.
!
Safety notes
This device complies with the relevant safety regulations for data processing equipment, including
electronic office machines for use in an office environment. If you have any questions, contact your
sales outlet or our help desk.
● The display surface of the LCD monitor is sensitive to pressure and scratches. You should
therefore be careful with the display surface so as to avoid lasting damage (Newton rings,
scratches).
● If the device is brought into the installation site from a cold environment, condensation can
form. Before operating the device, wait until it is absolutely dry and has reached approximately
the same temperature as the installation site.
● During installing and operating the device, please observe the instructions on environmental
conditions in the "
ergonomic video workstation
● To ensure sufficient ventilation, the intake and exhaust air openings of the monitor must never
be blocked.
● The monitor automatically sets itself to a mains voltage in the range of 100 V to 240 V. Ensure
that the local mains voltage lies within these limits.
● Ensure that the power socket on the device or the grounded mains outlet is freely accessible.
● The ON/OFF switch does not disconnect the device from the mains voltage. To completely
disconnect the mains voltage, remove the power plug from the socket.
2 A26361-K1086-Z120-1-7619, edition 2
Downloaded from ManualMonitor.com Manuals
Technical data" chapter as well as the instructions in the "Installing an
" chapter.
SCALEOVIEW H17-1/H19-1/H19-1W
● The monitor is equipped with a power cable that complies with safety standards.
● Lay all cables so that nobody can stand on them or trip over them. When attaching the device,
observe the relevant notes in the "
● If you use a different data cable from the one supplied, ensure that it is adequately shielded.
CE conformance and optimum picture quality are guaranteed only if you use the data cables
supplied.
● No data transfer cables should be connected or disconnected during a thunderstorm.
● Make sure that no objects (e.g. jewellery chains, paper clips, etc.) or liquids get inside the
device (danger of electric shock, short circuit).
● The device is not waterproof! Never immerse the device in water and protect it from spray
water (rain, sea water).
● In emergencies (e.g. damaged casing, elements or cables, penetration of liquids or foreign
matter), switch off the unit, disconnect the power plug and contact your sales outlet or our help
desk.
● The monitor must be disposed of in accordance with the local regulations for disposal of
special waste. The screen background lighting contains mercury. You must observe the
applicable handling and disposal safety regulations for fluorescent tubes.
● Only qualified technicians should repair the device. Unauthorised opening and incorrect repair
may greatly endanger the user (electric shock, fire risk).
● You may set only those resolutions and refresh rates specified in the "
Otherwise you may damage your monitor. If you are in any doubt, contact your sales outlet or
our help desk.
● Use a screen saver with moving images and activate the power management for your monitor
to prevent still images from "burning in".
● If you operate the monitor with the swivel arm or wall bracket, it may not be turned by 180°.
● We recommend that you place your device on an insensitive, non-slip surface. In view of the
multitude of different finishes and varnishes used on furniture, it is possible that the feet of the
device will mark the surface they stand on.
Connecting the monitor" chapter.
Technical data" chapter.
Power cable
To guarantee safe operation, use the cable supplied. Use the following guidelines if it is necessary to
replace the original cable set.
● The female/male receptacles of the cord set must meet IEC60320/CEE-22 requirements.
● The cable has to be HAR-certified or VDE-certified. The mark HAR or VDE will appear on the
outer sheath.
● For devices which are mounted on a desk or table, type SVT or SJT cable sets may be used.
For devices which sit on the floor, only SJT type cable sets may be used.
● The cable set must be selected according to the rated current for your device.
● If necessary, replace the original power cable with a regular grounded 3-core mains lead.
A26361-K1086-Z120-1-7619, edition 2 3
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/H19-1/H19-1W
Transport
● Transport the monitor with care and only in its original packaging or another corresponding
packaging fit to protect it against knocks and jolts.
● Never drop the LCD monitor (danger of glass breakage).
Cleaning
● Always pull out the power plug before you clean the monitor.
● Do not clean any interior parts yourself, leave this job to a service technician.
● Do not use any cleaning agents that contain abrasives or may corrode plastic.
● Ensure that no liquid will run into the system.
● Ensure that the ventilation areas of the monitor are free.
● The display surface of the LCD monitor is sensitive to pressure and scratches. Clean it only
using a soft, slightly moistened cloth.
Wipe the monitor casing with a dry cloth. If the monitor is particularly dirty, use a cloth which has
been moistened in mild domestic detergent and then carefully wrung out.
CE marking
The shipped version of this device complies with the requirements of the EEC directives
89/336/EEC "Electromagnetic compatibility" and 73/23/EEC "Low voltage directive".
FCC Class B Compliance Statement
The following statement applies to the products covered in this manual, unless otherwise specified
herein. The statement for other products will appear in the accompanying documentation.
NOTE:
This equipment has been tested and found to comply with the limits for a "Class B" digital device,
pursuant to Part 15 of the FCC rules and meets all requirements of the Canadian InterferenceCausing Equipment Standard ICES-003 for digital apparatus. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in strict
accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between equipment and the receiver.
● Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
● Consult the dealer or an experienced radio/TV technician for help.
4 A26361-K1086-Z120-1-7619, edition 2
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/H19-1/H19-1W
Fujitsu Siemens Computers GmbH is not responsible for any radio or television interference caused
by unauthorised modifications of this equipment or the substitution or attachment of connecting
cables and equipment other than those specified by Fujitsu Siemens Computers GmbH. The
correction of interferences caused by such unauthorised modification, substitution or attachment will
be the responsibility of the user.
The use of shielded I/O cables is required when connecting this equipment to any and all optional
peripheral or host devices. Failure to do so may violate FCC and ICES rules.
Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Product name: Colour LCD Monitor
Trade name: Fujitsu Siemens Computers Inc.
Model number(s): SCALEOVIEW H17-1/H19-1/H19-1W
Name of responsible party: Fujitsu Siemens Computers Inc.
Contact person: Schroettle-Henning, Bernd
Phone No.: (408) 746-8256
Fax No.: (408) 746-8299
We, Fujitsu Siemens Computers Inc., hereby declare that the equipment bearing the trade name and
model number specified above was tested confirming to the applicable FCC Rules under the most
accurate measurement standards possible, and that all the necessary steps have been taken and
are in force to assure that production units of the same equipment will continue to comply with the
Commissions requirements.
1250E. Arques Avenue
Sunnyvale, CA 94085
U.S.A.
Energy Star Guidelines
The Fujitsu Siemens LCD colour monitor SCALEOVIEW H17-1/H191/H19-1W is designed to conserve electricity by dropping to less than 2 W
when it goes into standby, suspend and OFF mode. With this new power
management the monitor SCALEOVIEW H17-1/H19-1/H19-1W qualifies
for the U.S. Environmental Protection Agency's (EPA) Energy Star
Computers award.
The EPA estimates that computer equipment uses 5 % percent of all business electricity and that
this is growing rapidly. If all desktop computers and peripherals enter a low-power mode when not in
use, the overall savings in electricity could amount to $ 2 thousand million annually. These savings
could also prevent the emission of 20 million tons of carbon dioxide into the atmosphere - the
equivalent of 5 million automobiles.
As an Energy Star Partner, Fujitsu Siemens Computers GmbH has determined that this product
meets the Energy Star guidelines for energy efficiency.
A26361-K1086-Z120-1-7619, edition 2 5
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/H19-1/H19-1W
Disposal and recycling
This device has been manufactured to the highest possible degree from materials which can be
recycled or disposed of in a manner that is not environmentally damaging. The device may be taken
back after use to be recycled, provided that it is returned in a condition that is the result of normal
use. Any components not reclaimed will be disposed of in an environmentally acceptable manner.
If you have any questions on disposal, please contact your local office, our help desk, or:
Germany Belgium Switzerland
Fujitsu Siemens Computers
GmbH
Remarketing und Recycling
D-33106 Paderborn
Tel.: +49 5251 / 81 80 10
Fax: +49 5251 / 81 80 15
http://www.fujitsu-siemens.de/wvm
RECUPEL
Boulevard Reyers, 80
B-1030 Brussels
Tel.: +32 2 / 706 86 16
Fax: +32 2 / 706 86 13
E-Mail: info@recupel.be
http://www.recupel.be
SWICO
Schweizerischer
Wirtschaftsverband der
Informations-,
Kommunikations- und
Organisationstechnik
A list of the SWICO
Acceptance places can be
found at:
http://www.swico.ch
Checking the contents of the consignment
The display surface of the LCD monitor is sensitive to pressure and scratches. Always
hold the device by the casing!
!
► Unpack all the individual parts.
► Check the delivery for damage incurred during transportation.
► Check whether the delivery agrees with the details in the delivery note.
The complete LCD monitor package includes:
– one monitor
– one monitor base
– one cover
– one data cable (D-SUB)
– one data cable (DVI-D: H17-1/H19-1)
– two audio cables
– one USB cable for the computer
– one power cable
– one CD
– one Warranty Booklet
– one "Getting Started" manual
Should you discover that the delivery does not correspond to the delivery note, notify your local sales
outlet immediately.
We recommend that you keep the original packaging material. You may need the
packaging in the future if you need to transport your device.
i
6 A26361-K1086-Z120-1-7619, edition 2
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/H19-1/H19-1W
Installing an ergonomic video workstation
Before you set up your equipment, you should select a suitable position for working at the monitor.
Please observe the following advice when installing a video workstation.
2
1
1
1 = Windows
Avoid direct and reflected glare.
Avoid glare from electric
lighting.
1 = approx. 90° and more
2 = approx. 90°
Remember to maintain correct
posture.
1
1 = Bearing surface for palms
of hands
2 = Reaching area for
frequently used equipment
Position the keyboard where it
is easiest to reach.
Example layout of monitor,
keyboard and copy-holder
0°
60°
1 = Preferable viewing sector
2 = Permissible viewing sector
Position the monitor for
optimum viewing. The viewing
distance to the monitor should
be approximately 50 cm.
65°
65°
22
30°
30°
Keep ventilated areas clear.
i
Depending on the situation, the use of a swivel arm or wall bracket (VESA FPMPMI), are available
from specialised dealers, may be advisable. For this purpose the monitor base must be removed
beforehand as described in the "
Mounting and removing the monitor base" chapter.
A26361-K1086-Z120-1-7619, edition 2 7
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/H19-1/H19-1W
Mounting and removing the monitor base
Mounting monitor base
When delivered the lower section of the monitor base is removed.
► Push the lower section of the monitor base (2) in the upper section (1).
► Fasten the screw (3).
Removing monitor base
Before you can use a swivel arm or a wall bracket, you must remove the entire monitor base.
► Switch off the monitor and pull the power plug out of the power socket.
The display surface is susceptible to scratching!
!
► Lay the monitor on its face on a soft surface.
8 A26361-K1086-Z120-1-7619, edition 2
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/H19-1/H19-1W
► Remove the cover (3) and disconnect all
cables.
► Remove the two screws under the
covers (1 and 2).
You can now mount a swivel arm or a wall
bracket as per VESA FPMPMI with 100 mm hole
spacing.
For instructions on how to mount the swivel arm
or wall bracket, please see the documentation for
the swivel arm or wall bracket.
Connecting the monitor
Please take note of the safety information in the "
!
CE conformance and optimum picture quality are guaranteed only if you use the data
cables supplied.
Do not cover the ventilation openings of the monitor.
The computer power plug must be pulled out!
► Be sure that the monitor and the computer are switched off.
Important notes" chapter.
Connecting cables to the monitor
The monitor ports are protected by a cover.
► Remove the cover.
1 = Power connector
2 = DVI-I connector (DIGITAL: H17-1/H19-1)
3 = D-SUB connector (ANALOG)
4 = AUDIO-IN connectors (green:
loudspeaker/headphones; pink:
microphone)
5 = Microphone port to computer
6 = USB port to computer
7 = Headphones outlet
8 = Microphone input
9 = USB port
10 = Security slot for "Kensington Lock"
11 = Holes for fixing swivel arm or wall bracket
A26361-K1086-Z120-1-7619, edition 2 9
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/H19-1/H19-1W
The data cables supplied have two 15-pin D-SUB connectors or two 24-pin DVI connectors for
connection to the monitor and to the computer.
► Select the suitable data cable for your computer.
Digital graphics card with DVI interface: DVI-I or DVI-D connector (H17-1/H19-1)
Graphics card with VGA interface: D-SUB connector
Information on the computer connections and interfaces is contained in the operating manual
for your computer.
► Connect one of the connectors of the data cable to the D-SUB connector (3) or the DVI-I
connector (2) on the monitor and secure the plug-in connection by tightening the safety screws.
The monitor automatically detects the input when only one signal source is connected.
i
► If necessary, insert one plug of each audio cable in the AUDIO IN (4) sockets on the monitor
and make sure they are properly engaged.
► If necessary, insert one plug of the USB cable in the USB port (6) on the monitor and make
► Plug the power cable supplied into the power connector (1) of the monitor.
► Mount the cover over the connections.
i
sure it is properly engaged.
A lock (Kensington Lock) can be mounted in the security slot (10) to protect the monitor
from theft. A Kensington Lock is not included in the consignment of the monitor.
Green: loudspeakers/headphones
Pink: microphone
Connecting cables to the computer
Information on the computer connections and interfaces is contained in the operating manual for your
computer.
► Connect the data cable to the (active) monitor port on the computer and secure the plug-in
► Insert the other plug of the each audio cable in the audio ports of the computer.
► Insert the other plug of the USB cable into a USB port of the computer.
► Plug the connector of the mains cable provided into the monitor outlet of the computer or into a
If your computer has two monitor ports ("onboard" screen controller and separate
graphics card), the monitor port for the separate graphics card is usually active.
i
connection by tightening the safety screws.
properly earthed outlet and ensure a safe connection.
10 A26361-K1086-Z120-1-7619, edition 2
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/H19-1/H19-1W
► Plug the power connector of the computer into a properly grounded mains outlet.
When you start working with your monitor for the first time you should install the
appropriate graphics drivers for your application software. Details of how to do this are
i
provided in the documentation on your screen controller/the associated driver software.
Operation of the monitor
The monitor offers the following possibilities that enable it to be optimally adjusted for the respective
user and the respective situation.
Adjusting rake
The rake of the monitor can be adjusted by -5° (forward) and +20° (back) from its vertical position.
► Grasp the monitor with both hands on the right and left edge of the casing and adjust it to the
desired rake.
Switching the monitor on/off
1 = Buttons for the OSD menu
(On-Screen-display)
2 = ON/OFF switch
3 = Power indicator
The ON/OFF switch (2) is used for switching the monitor on and off.
The power indicator (3) lights up blue when the monitor and computer are switched on. The power
indicator lights up orange when the monitor does not receive a video signal or is in the energy saving
mode. The power indicator goes off when the monitor is switched off.
A26361-K1086-Z120-1-7619, edition 2 11
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/H19-1/H19-1W
When you switch the computer system on, you must proceed in the following order:
► First switch on the LCD monitor with the ON/OFF switch (2).
► Then switch on the computer.
If your computer has a power management function (energy-saving mode), you should
read the "
i
Notes on power management" section in this chapter.
Notes on power management
If your computer is equipped with power management, the monitor can support this function fully.
Here the monitor does not distinguish between the individual energy-saving modes of the computer
(standby mode, suspend mode and OFF mode), as it is capable of immediately switching into the
mode with the highest energy-saving effect.
Stage ON Power-Saving Mode
Power indicator lights up blue lights up orange
Function the monitor is working
Power consumption normal < 42 W (H17-1)
normal < 50 W (H19-1W)
If your computer detects inactivity (no input) it sends an appropriate signal to the monitor to reduce
the power consumption (energy-saving mode). The power indicator of the monitor changes colour to
indicate the status change.
Once an input is made at the computer the screen contents are redrawn and full power is restored.
For detailed information on how energy-saving mode operates refer to the operating manual or
technical manual of the computer.
When the monitor is switched to the energy-saving mode by the power management
system a power consumption of up to 1 W is maintained to feed the circuit for redrawing
i
the screen contents.
To completely switch off the power consumption, switch off the computer or pull the plug of
the monitor power cable out of the monitor socket of the computer.
normally
normal < 45 W (H19-1)
the screen is dark
reduced to < 1 W
12 A26361-K1086-Z120-1-7619, edition 2
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/H19-1/H19-1W
Changing the monitor settings
When putting the monitor into operation for the first time, the screen display should be optimally
adapted to the screen controller used and adjusted in accordance with your needs.
Basic monitor settings with the CD supplied
If one of the operating systems Windows 95/98, Windows NT, Windows Me, Windows 2000,
Windows XP or OS/2 (with Windows emulation installed) is used, the basic monitor settings can be
set with the CD supplied.
► Insert the supplied CD into the CD-ROM drive.
► Open the
Your monitor should now already be properly adjusted. If none of the above operating systems is
used or minor corrections are to be made to the screen display, then change the monitor settings
with the OSD menu.
Changing the monitor settings with the buttons of the control panel
1 = Buttons for the OSD menu
(On-Screen-display)
Use the buttons of the control panel to make the following monitor settings directly while the OSD
menu is switched off.
Readme file on the CD and follow the instructions in the file.
2 = ON/OFF switch with power indicator
Performing auto-adjustment of the monitor
► Press the EXIT/AUTO button for approx. 1 second while the OSD menu is switched off.
Auto Processing message is displayed.
The
Picture quality and position are set to optimum values for your system.
Selecting input signal: H17-1/H19-1 (Analog1/Analog2/Digital); H19-1W (Analog1/Analog2)
► Press the 5/INPUT button for approx. 1 second for calling the Input select setting window.
► Press the
Selecting colour optimisation (MODE)
► Press the MODE button for calling the Mode setting window.
► Press the
A26361-K1086-Z120-1-7619, edition 2 13
Downloaded from ManualMonitor.com Manuals
/ or 5/INPUT button to select the desired input (analogue or digital DVI-D).
6
/ or 5/INPUT button to choose the desired colour optimisation.
6
SCALEOVIEW H17-1/H19-1/H19-1W
The following settings are offered:
Office suitable and optimised for word processing
Photo suitable and optimised for photo editing
Video suitable and optimised for videos
Games suitable and optimised for games
Max Speed suitable only for application with optimal response time. Not suitable for office
Activating/deactivating muting
► Press the 6/ button to switch the sound off and on again.
A message is displayed that the action has been performed.
applications.
Monitor settings using the OSD menu
With the buttons on the control panel, call up and use the integrated OSD (On-Screen display) menu.
To set the OSD menu, perform the following steps:
► Press the SELECT/MENU button to activate the OSD menu.
The main menu appears on the screen (on the left-hand side) with icons for the setting functions.
The OSD menu is available in different languages. The English menu names are used in
the following description (default setting). With the OSD function
i
you can select another language.
The first symbol (Brightness/Contrast) is
highlighted. In the right-hand part of the display
the associated functions are shown.
Language in the OSD Setup
► If necessary, press the
button to mark another icon (e.g.
adjust
).
► Press the SELECT/MENU button to select
the highlighted icon.
14 A26361-K1086-Z120-1-7619, edition 2
Downloaded from ManualMonitor.com Manuals
/ or 5/INPUT
6
SCALEOVIEW H17-1/H19-1/H19-1W
The corresponding setting window (here: Image Adjust) is displayed (on the right-hand side).
The first function (H-Position) is highlighted.
► If necessary, press the 6/ or 5/INPUT
button to mark another function.
► Press the SELECT/MENU button to select
the highlighted function.
► Press the
adjust the value for the selected function.
► Press the EXIT/AUTO button to exit the
function.
► If necessary, press the
button to mark another function or press the
EXIT/AUTO button to return to the main
menu.
All changes are stored automatically.
If you want to change other settings, select the corresponding function from the OSD main menu. All
possible adjustments of the main menu are described in the following.
Adjusting the brightness and contrast
Calling the Brightness / Contrast setting window
Brightness
Contrast
Black Level
Auto Level
i
Setting the brightness of the display
With this function you change the brightness of the background lighting.
Setting the contrast of the display
With this function you modify the contrast of bright colour tones.
Setting the brightness of the display
With this function you modify the contrast of dark colour tones.
Setting the brightness of the display
With this function you can automatically set the contrast.
Press the SELECT/MENU button to activate the function.
If the contrast is set too high, bright surfaces can no longer be distinguished from very
bright surfaces. If the contrast is set too low, the maximum brightness will not be achieved.
/ or 5/INPUT button to
6
/ or 5/INPUT
6
A26361-K1086-Z120-1-7619, edition 2 15
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/H19-1/H19-1W
Adjusting size and position
Calling the Image adjust setting window
H-Position
V-Position
Clock
Phase
Adjusting the volume
Adjusting the horizontal position
With this function you move the picture to the left or to the right.
Adjusting the vertical position
With this function you move the picture up or down.
Setting synchronisation
With this function you adjust the picture width to eliminate vertical picture
disturbances.
Eliminating picture interference
With this function you fine-tune your monitor to eliminate picture interference.
Calling the
Volume
Mute
Setting colour temperature and colours
Setting the volume for playback with the integrated loudspeakers
Switching the loudspeakers off or on
Calling the Colour setting window
Selecting the colour temperature - "Office Mode"
The "warmth" of the screen colours is set using the colour temperature. The colour
temperature is measured in K (= Kelvin). You can select from
9300 K, Native and Custom Colour.
Native
Custom Colour
In the user-defined setting you can change the colour ratios of the basic colours
(red, green, blue) as required.
Audio setting window
= Original colour of the LCD display
= User-defined colours
sRGB, 6500 K, 7500 K,
16 A26361-K1086-Z120-1-7619, edition 2
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/H19-1/H19-1W
Setting display of the OSD menu
Calling the OSD Setup setting window
Language
OSD
H-Position
OSD
V-Position
OSD
Timeout
Setting functions in the "Advanced" menu
Input Select
Resolution
Notifier
Factory Recall
Setting language for the OSD menu
With this function you select the language for the OSD menu. The following
languages are offered:
French Swedish English (default setting)
Spanish Dutch
English Italian Russian
Setting the horizontal position of the OSD menu
With this function you move the OSD menu to the left or to the right.
Setting the vertical position of the OSD menu
With this function you move the OSD menu up or down.
Setting the display duration of the OSD menu
With this function you select a value from 10 to 120 seconds.
If the set time expires without a setting being made, the OSD menu is automatically
faded out.
Calling the Advanced setting window
Selecting input signal
With this function you switch the monitor from the analogue to the digital mode and
vice versa, when two signal sources are connected (H17-1/H19-1).
The condition is that the graphic card used supports this function.
Displaying monitor data
The optimum resolution for the H17-1/H19-1 monitor is 1280 x 1024 pixels (H19-
1W: 1440 x 900). With the function activated (
screen after approx. 30 seconds if a different resolution is set.
Change the resolution to 1280 x 1024 (H17-1/H19-1), 1440 x 900 (H19-1W) to
achieve optimum picture quality. With the function deactivated (
appears.
Activating the factory settings
With this function all settings are reset to the factory settings without prompting for
confirmation.
Press the SELECT/MENU button to activate the function. The
message is displayed.
On), a message appears on the
Off), no message
Auto Processing
A26361-K1086-Z120-1-7619, edition 2 17
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/H19-1/H19-1W
Displaying information
Calling the
With this function the model designation, serial number, resolution, H/V frequency,
input signal and polarity of the synchronisation signal are displayed.
Information setting window
Troubleshooting
Should an error occur, first check the following points. If the distortion is still not eliminated, the
monitor should, if possible, be checked on another computer.
If you are unable to solve the problem, please inform our help desk.
Having this problem? Check the following points:
No screen display
(power indicator does not light)
No screen display
(power indicator lights)
Message:
No Signal
Message:
Frequency out of range:
## kHz / ## Hz
Please change the display
mode to 1280 x 1024 (1440 x
900) with 60 Hz.
Message:
For best picture quality,
please change resolution to
1280 x 1024(1440 x 900).
SELECT: Disable EXIT: Clear
► Check whether the monitor is switched on.
► Check whether the power cable on the monitor is
connected correctly.
► Check whether the computer is switched on.
► Check whether the computer is switched on.
► Check whether the data cable for the monitor is
correctly attached to the monitor port on the computer.
► Press any key on the computer keyboard – the
computer may be in energy saving mode.
► Alter the brightness and/or contrast until you get a
picture.
► Check whether the data cable for the monitor is
correctly attached to the monitor port on the computer.
► Check whether the computer is switched on.
The input signal (horizontal frequency and refresh rate) at
the displayed input does not correspond to the technical
monitor data.
► Adjust the video frequency range using the computer
software (see documentation for your computer or
your graphics card).
► Set the resolution to 1280 x 1024 (H17-1/H19-1) or
1440 x 900 (H19-1W) using the computer software.
18 A26361-K1086-Z120-1-7619, edition 2
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/H19-1/H19-1W
Having this problem? Check the following points:
Picture position not correct The monitor recognises an undefined mode (see the
Picture is shaking ► Check whether the data cable for the monitor is
Picture is wrongly adjusted ► Press the SELECT/MENU button to activate the
Picture disturbances (vertical lines)
Picture disturbances
(horizontal lines, picture noise)
Technical data" chapter).
"
► Press the EXIT/AUTO button to perform the auto-
adjustment of the screen.
► Set the picture position with the OSD menu (see the
Operation of the monitor" chapter).
"
correctly attached to the monitor port on the computer.
► Press the EXIT/AUTO button to perform the auto-
adjustment of the screen.
function
is displayed.
► Press the EXIT/AUTO button to perform the auto-
adjustment of the screen.
► Press the EXIT/AUTO button to perform the auto-
adjustment of the screen.
Factory Recall. The Auto Processing message
The screen becomes darker
A26361-K1086-Z120-1-7619, edition 2 19
Downloaded from ManualMonitor.com Manuals
The background lighting has a limited lifetime. If your
monitor display should become too dark, the background
lighting will have to be exchanged.
► Please contact our help desk.
SCALEOVIEW H17-1/H19-1/H19-1W
Notes regarding the DIN EN ISO 13406-2 standard
Permanently unlit or lit pixels
The standard of production techniques today cannot guarantee an absolutely fault-free screen
display. A few isolated constant lit or unlit pixels (picture elements) may be present. The maximum
permitted number of pixels faults is stipulated in the stringent international standard ISO 13406-2
(Class II).
Example:
A 17" or 19" flat-screen monitor with a resolution of 1280 x 1024 has 1280 x 1024 = 1310720 pixels.
Each pixel consists of three subpixels (red, green and blue), so there are almost 4 million subpixels
in total. In accordance with ISO 13406-2 (Class II), a maximum of 6 pixels and 7 subpixels may be
faulty.
Pixel A pixel consists of 3 subpixels, normally red, green and blue. A
Subpixel A subpixel is a separately addressable internal structure within a
Cluster A cluster contains two or more defective pixels or subpixels in a
pixel is the smallest element that can be generated by complete
functionality of the display.
pixel that enhances the pixel function.
5 x 5 pixel block.
20 A26361-K1086-Z120-1-7619, edition 2
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/H19-1/H19-1W
Technical data
Dimensions and weight (LCD monitor)
Visible diagonals: 43 cm (H17-1); 48 cm (H19-1)
Dot pitch: 0.264 mm (H17-1); 0.294 mm (H19-1); 0.285 mm (H19-1W)
Screen size: 337.9 mm x 270.3 mm (H17-1)
Maximal resolution: 1280 x 1024 pixels (H17-1/H19-1)
Dimensions (W x H x D) incl. monitor
base:
Dimensions box (W x H x D):
Weight: 3.75 kg (H17-1), 4.45 kg (including packaging)
Accessories: Power cable (1.8 m)
Storable display modes: 49
376.2 mm x 301 mm (H19-1)
410.4 mm x 256.5 mm (H19-1W)
1440 x 900 pixels (H19-1W)
383 mm x 412.7 mm x 180 mm (H17-1)
416.9 mm x 449 mm x 189.5 mm (H19-1)
447.8 mm x 404.4 mm x 189.5 mm (H19-1W)
454 mm x 129 mm x 487 mm (H17-1)
487 mm x 157 mm x 505 mm (H19-1)
498 mm x 154 mm x 475 mm (H19-1W)
5.1 kg (H19-1), 6.1 kg (including packaging)
4.85 kg (H19-1W), 6.95 kg (mit Verpackung)
D-SUB data cable (1.8 m)
DVI-D data cable (1.8 m) (H17-1/H19-1)
2 x audio cable (1.8 m)
USB cable (1.8 m)
Electrical data
Video: analogue, positive, 0.7 Vpp, 75 Ω
Synchronisation: Separate Sync. TTL, positive or negative
Horizontal frequency: 30 kHz .... 83 kHz (multi-scanning)
Refresh rate: 55 Hz .... 75 Hz
Maximum pixel rate: 135 MHz
Power supply: switches automatically
Total power consumption: < 42 W (H17-1); < 45 W (H19-1); < 50 W (H19-1W)
Sound output: 2 W left; 2 W right (type 7496SA)
A26361-K1086-Z120-1-7619, edition 2 21
Downloaded from ManualMonitor.com Manuals
digital: DVI-I/DVI-D
100 V - 240 V, 50 Hz - 60 Hz ± 2 Hz, 1.5 A - 0.7 A
in normal mode
< 1 W (Standby mode)
SCALEOVIEW H17-1/H19-1/H19-1W
Environmental conditions
Environment class 3K2, IEC 721
Rated range of operation:
Humidity:
Limit range of operation:
Humidity:
Condensation must be avoided.
15 °C .... 35 °C
20 % .... 85 %
5 °C .... 35 °C
20 % .... 85 %
VESA-DDC-compatible VGA interface
Your monitor is equipped with a VESA-DDC-compatible VGA interface. VESA-DDC (Video
Electronics Standard Association, Display Data Channel) is used as the communications interface
between the monitor and the computer. If your computer is equipped with a VESA-DDC-compatible
VGA interface, it can automatically read the data for ensuring optimum operation from your monitor
and select the appropriate settings.
If the monitor SCALEOVIEW H17-1/H19-1/H19-1W is not yet displayed in the list of
monitors, you can select the following monitor instead:
i
Fujitsu Siemens B17-1, B19-1, P17-1, P19-1, B17-2, B19-2, P17-2, P19-2, W19-1
Preset operating modes
The picture position and size have been set to optimum values at the factory for the
operating modes listed above. Depending on the screen controller used, it may be
i
necessary to adjust the display position and size. In this case, you can change and save
the settings (see the "
The following are the most frequently used of the preset operating modes:
Operation of the monitor" chapter).
SCALEOVIEW H17-1/H19-1
Horizontal frequency Refresh rate Screen resolution
31.5 kHz
31.5 kHz
37.5 kHz
37.9 kHz
46.9 kHz
48.4 kHz
60.0 kHz
64.0 kHz
79.9 kHz
For ergonomic reasons, a screen resolution of 1280 x 1024 pixels is recommended. Because of the
technology used (active matrix) an LCD monitor provides a totally flicker-free picture even with a
refresh rate of 60 Hz.
22 A26361-K1086-Z120-1-7619, edition 2
Downloaded from ManualMonitor.com Manuals
70 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
75 Hz
720 x 400
640 x 480
640 x 480
800 x 600
800 x 600
1024 x 768
1024 x 768
1280 x 1024
1280 x 1024
SCALEOVIEW H17-1/H19-1/H19-1W
SCALEOVIEW H19-1W
Horizontal frequency Refresh rate Screen resolution
31.5 kHz
31.5 kHz
37.5 kHz
37.9 kHz
46.9 kHz
48.4 kHz
60.0 kHz
64.0 kHz
44.96 kHz
49.7 kHz
59.9 kHz
For ergonomic reasons, a screen resolution of 1440 x 900 pixels is recommended. Because of the
technology used (active matrix) an LCD monitor provides a totally flicker-free picture even with a
refresh rate of 60 Hz.
70 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
60 Hz
60 Hz
60 Hz
720 x 400
640 x 480
640 x 480
800 x 600
800 x 600
1024 x 768
1024 x 768
1280 x 1024
1280 x 720
1280 x 800
1440 x 900
Power supply plug
0 V
A26361-K1086-Z120-1-7619, edition 2 23
Downloaded from ManualMonitor.com Manuals
+12 V DC
SCALEOVIEW H17-1/H19-1/H19-1W
Monitor port DVI-D/DVI-I
C1 C2
1
9
17
C3
C5
C4
Pin Meaning
1 TMDS Data2- 11 TMDS Data 1/3 Shield 21 not connected
2 TMDS Data2+ 12 not connected 22 TMDS Clock Shield
3 TMDS Data 2/4 Shield 13 not connected 23 TMDS Clock+
4 not connected 14 +5V Power 24 TMDS Clock-
5 not connected 15 Earth
6 DDC Clock 16 Hot Plug Detect C1 Analog R Video Out (*)
7 DDC Data 17 TMDS Data0- C2 Analog G Video Out (*)
8 Analogue Vertical
Sync
9 TMDS Data1- 19 TMDS Data 0/5 Shield C4 Analogue H-Sync. (*)
10 TMDS Data1+ 20 not connected C5 Analog Common GND
(*) = Not connected with DVI-D version
Pin Meaning
18 TMDS Data0+ C3 Analog B Video Out (*)
Pin Meaning
Return (*)
24 A26361-K1086-Z120-1-7619, edition 2
Downloaded from ManualMonitor.com Manuals
SCALEOVIEW H17-1/H19-1/H19-1W
Pin assignment D-SUB
1
5
6
10
11
15
Pin Meaning Pin Meaning
1 Video input red 9 +5 V (DDC)
2 Video input green 10 Sync. earth
3 Video input blue 11 Earth
4 Earth 12 DDC-Data
5 Earth 13 H. sync
6 Red video earth 14 V. sync
7 Green video earth 15 DDC Clock
8 Blue video earth
A26361-K1086-Z120-1-7619, edition 2 25
Downloaded from ManualMonitor.com Manuals
Loading...
