Fujitsu FMC-16LX, FLASH-CAN-100 User Manual

Fujitsu Microelectronics Europe

User Guide

F²MC-16LX FAMILY

FMEMCU-UG-900001-32

EVALUATION BOARD

FLASH-CAN-100

USER GUIDE

Change even page title here

Revision History

Date Version Issue

07.12.98 V1.0 P14,P16 connected to JP7, JP8 (RS232 interface for MB90F594A) must be changed

07.12.98 V1.0 Jumper on JP10, JP9 Pin2+3 must be changed to Pin 1+2 to connect to UART1

07.12.98 V1.2 Silk-Plot: Version number must be added.

07.12.98 V1.2 Silk-Plot: SIT/SOT is not correct. Must be changed.

07.12.98 V1.2 Silk-Plot: CAN100BOARD is not correct.

07.12.98 V1.2 Silk-Plot: In RS232 Jumper area - naming of pins must be changed from Pxx to Pinxx.

07.12.98 V1.2 Silk-Plot: In CAN Jumper area - naming of pins must be changed from Pxx to Pinxx.

07.12.98 V1.2 JP13 was not placed on the board.

07.12.98 V1.2 Allow connection of X4 (RS232 Sub-D-9 female) Pin 7+8 on the DIP switch S3 Pin 5.

13.01.99 V1.1 Page 6 of this manual - item 6.4 not X3 – must be X4

01.02.99 V1.2 Fig. 2 – Schematic of Flash-CAN-100P-M06 misprint: External voltage supply plug must have Gnd on the inside and +12V on the outside.

03.02.99 V1.2 Disclaimer added to manual

03.02.99 V1.2 Manual revised to include information about Flash programming software tools, which in now available in this package

12.02.99 V1.2a MB90580 series added – Can be used with this board also (only QFP 100 package!)

17.05.99 V2.0 Silk Plot changed to new Name: FLASH-CAN2-100P-M06

17.05.99 V2.0 New Socket Adapter for MCU used (NQPACK100RB)

17.05.99 V2.0 FLASH-CAN2-100P-M06 added in documentation

17.05.99 V2.0 Revised Silk plot in documentation

26.05.99 V2.0 Replace Pxx by Pixx in Chapter 5

26.05.99 V2.0 Chapter 6 – DIP-switch setting revised for asynchronous loader software

26.05.99 V2.0 Table1 + 2 added in this document

16.07.99 X0+X1 are not available on socket pin

16.07.99 V2.0: Connection of new socket adapter must be watched carefully. MCU might not have good contact

21.07.99 V2.1 Schematic of board added to this manual

05.08.99 V2.1 Attached Floppy modified to incl. Softune Worbench Projects see \readme.txt – Revision V1.2

UG-900001-32 - 2 - © Fujitsu Microelectronics Europe GmbH

Change odd page title here

Revision History

Date Version Issue

23.08.99 V2.2 Table 2. MB90F543 UART0 is wrong – it must be UART1

17.04.00 V2.3 Table 2 corrected now

17.04.00 V2.3 Chapter 1.1. Regarding connectivity problems added. FLASH-CAN-100P-M06 is available again

09.01.01 V2.4 Support added for MB90F42x series

25.01.01 V2.5 Support for MB90F546G/GS and MB90F548G/GS series added, Description of Connector JP11 added

19.09.01 V2.6 Support for MB90440G series added, new disclaimer added

05.10.01 V2.7 New disclaimer corrected

13.02.02 V2.8 chapter 5.1 (MB90470) added Hardware: U6 changed to MAX3232CPE

22.08.02 V2.9 new style; MB90435, MB90480 added

07/02/03 V3.0 Disclaimer corrected

V3.1 Series support, device list corrected

27.11.06 V3.2 Changed Socket Information

This document contains 20 pages.

Change even page title here

Warranty and Disclaimer

To the maximum extent permitted by applicable law, Fujitsu Microelectronics Europe GmbH restricts its warranties and its liability for the FLASH-CAN-100P-M06 Board and all its deliverables (eg. software include or header files, application examples, target boards, evaluation boards, engineering samples of IC’s etc.), its performance and any consequential damages, on the use of the Product in accordance with (i) the terms of the License Agreement and the Sale and Purchase Agreement under which agreements the Product has been delivered, (ii) the technical descriptions and (iii) all accompanying written materials. In addition, to the maximum extent permitted by applicable law,

ujitsu Microelectronics Europe GmbH disclaims all warranties and liabilities for the performance of

F the Product and any consequential damages in cases of unauthorised decompiling and/or reverse engineering and/or disassembling. Note, the FLASH-CAN-100P-M06 Board and all its deliverables are intended and must only be used in an evaluation laboratory environment.

1. Fujitsu Microelectronics Europe GmbH warrants that the Product will perform substantially in

accordance with the accompanying written materials for a period of 90 days form the date of receipt by the customer. Concerning the hardware components of the Product, Fujitsu Microelectronics Europe GmbH warrants that the Product will be free from defects in material and workmanship under use and service as specified in the accompanying written materials for a duration of 1 year from the date of receipt by the customer.

2. Should a Product turn out to be defect, Fujitsu Microelectronics Europe GmbH´s entire liability

and the customer´s exclusive remedy shall be, at Fujitsu Microelectronics Europe GmbH´s sole discretion, either return of the purchase price and the license fee, or replacement of the Product or parts thereof, if the Product is returned to Fujitsu Microelectronics Europe GmbH in original packing and without further defects resulting from the customer´s use or the transport. However, this warranty is excluded if the defect has resulted from an accident not attributable to Fujitsu Microelectronics Europe GmbH, or abuse or misapplication attributable to the customer or any other third party not relating to Fujitsu Microelectronics Europe GmbH.

3. To the maximum extent permitted by applicable law Fujitsu Microelectronics Europe GmbH

disclaims all other warranties, whether expressed or implied, in particular, but not limited to, warranties of merchantability and fitness for a particular purpose for which the Product is not designated.

4. To the maximum extent permitted by applicable law, Fujitsu Microelectronics Europe GmbH´s

and its suppliers´ liability is restricted to intention and gross negligence.

NO LIABILITY FOR CONSEQUENTIAL DAMAGES

To the maximum extent permitted by applicable law, in no event shall Fujitsu Microelectronics Europe GmbH and its suppliers be liable for any damages whatsoever (including but without limitation, consequential and/or indirect damages for personal injury, assets of substantial value, loss of profits, interruption of business operation, loss of information, or any other monetary or pecuniary loss) arising from the use of the Product.

Should one of the above stipulations be or become invalid and/or unenforceable, the remaining stipulations shall stay in full effect

UG-900001-32 - 4 - © Fujitsu Microelectronics Europe GmbH

Change odd page title here

Contents

REVISION HISTORY............................................................................................................ 2

WARRANTY AND DISCLAIMER ......................................................................................... 4

CONTENTS .......................................................................................................................... 5

1 OVERVIEW...................................................................................................................... 6

1.1 Abstract................................................................................................................... 6

1.2 Introduction ............................................................................................................. 6

1.3 Connectivity problems of the socket adapter ........................................................... 6

2 FEATURES...................................................................................................................... 7

3 SUPPORTED MICROCONTROLLER SERIES................................................................ 8

4 DELIVERABLES.............................................................................................................. 9

5 CONFIGURATION OF THE EVALUATION-BOARD ..................................................... 10

5.1 Modifications for use with MB90470 / MB90480 series.......................................... 12

5.1.1 Schematic of the modifications for MB90470 / MB90480 ......................... 13

6 USING THE ASYNCHRONOUS BOOT-LOADER ......................................................... 14

7 CONNECTORS.............................................................................................................. 15

7.1 Power connector (X1)............................................................................................ 15

7.2 Edge connector (J2, J3, J4, J5)............................................................................. 15

7.3 GND/VCC (JP11) .................................................................................................. 15

7.4 UART (X4)............................................................................................................. 16

7.5 CAN Interface (X2, X3).......................................................................................... 16

8 SILK-PLOT OF THE BOARD ........................................................................................ 17

9 SCHEMATIC OF THE BOARD ...................................................................................... 18

10 RELATED PRODUCTS ................................................................................................. 19

11 INFORMATION IN THE WWW....................................................................................... 20

Change even page title here

Chapter 1 Overview

1 Overview

1.1 Abstract

This user guide describes the basic features of the new FLASH-CAN-100P-M06/FLASHCAN2-100P-M06 board. This board can be used with almost all our 16LX microcontroller series supporting the FPT-100P-M06 package.

1.2 Introduction

The "Flash/CAN100"-board was developed in order to support customers and allow a fast software design start. Fujitsu emulators require a target system that provides Vcc and GND as well as an oscillation circuit. Additionally most of Fujitsu’s flash microcontroller support the burn-in flash programming algorithm.

For the FLASH-CAN-100P-M06 board an IC149-100-114-B5 socket adapter is used. The suitable emulation probe cable is the MB2132-457.

On the FLASH-CAN2-100P-M06 board a NQPACK100RB socket adapter is assembled. This requires the MB2132-464 for the connection to the emulator.

This board must only be used for test applications

in an evaluation laboratory environment.

1.3 Connectivity problems of the socket adapter

Some customers experience connectivity problems when connecting the MCU into the socket adapter. Only the small red screwdriver available in your box should be used to connect the cover (HQPACK) onto the socket (NQPACK).

If the four screws are not tightening equally, then it may cause a poor contact.

Do not screw the cover too tight (max 0.054 Nm). If you have connectivity problems then please loosen the screws and tighten again the screws equally.

Do not clean NQPACK, YQPACK, and YQSOCKET with steam. Cleaning material will contaminate inside of connector.

Customers using the FLASH-CAN-100P-M06 (with IC-149-100-114-B5 socket adapter) do usually not encounter this problem with the FLASH device.
