Frigidaire FFEW2426US Specifications
FFEW2426U S/W/B
S
W
B
SINGLE WALL OVEN
24" ELECTRIC
AVAILABLE
COLORS
Stainless
White
Black
PRODUCT DIMENSIONS
Height 31-7/16"
Width 23-7/8"
Depth 25-3/16"
MORE EASY-TO-USE FEATURES
Auto Shut-O
As an extra safety measure, the oven will
automatically shut off after 12 hours.
Built with American Pride
Designed, engineered and assembled
in the U.S.A.
CERTIFICATIONS
A.D.A. - Compliant
When properly installed, this model
is A.D.A.-qualified based on the
United States Access Board’s A.D.A./A.B.A.
Accessibility Guidelines and the Department
of Justice’s 2010 A.D.A. Standards for
Accessible Design.
SIGNATURE FEATURES
Quick Clean
Quickly clean your oven
in 2 hours with our quick
self-clean cycle.
Easy-to-Use
Ready-Select® Controls
Easily select options or control
cooking temperature with our
easy-to-use controls.
Vari-Broil™
Temperature Control
Vari-Broil™ allows you
to choose between two
heat levels.
Oven Rack Handles
Oven racks are designed with
space for you to easily pull out
the racks, even when wearing
an oven mitt.
frigidaire.com
FFEW2426U S/W/B
SINGLE WALL OVEN
24" ELECTRIC
FEATURES
Oven Control / Timing System Ready-Select®
Window Large
Exterior Door Finish
Handle Design
Oven Cleaning System Self Clean
Stainless Steel (S),
Color-Coordinated (W/B)
Stainless Steel (S),
Color-Coordinated (W/B)
OVEN CONTROLS
Bake / Broil Yes / Variable (Hi - Lo)
Delay Start Yes
Self-Clean / Clean Options Yes / 2, 3 Hours
Delay Clean Yes
Kitchen Timer Yes
Timed Cook Option Yes
Control Lock Yes
Auto Oven Shut-O Yes
Oven Lock-Out Yes
OVEN FEATURES
Capacity (Cu. Ft.) 3.3
Oven Light 1 Halogen
Rack Configuration 2 Standard
Broiling System Variable (Hi - Lo)
Bake / Broil Element (Watts) 2,100 / 3,400
OPTIONAL ACCESSORIES
10'-Long Armored Power Cable PN # 903056-9010
CERTIFICATIONS
A.D.A. Compliant
1
Yes
SPECIFICATIONS
Oven Interior ( H x W x D ) 17" x 17-3/4" x 18-3/4"
Power Supply Connection Location Left Bottom Rear
Voltage Rating 240V / 208V / 60Hz
Connected Load
(kW Rating) @ 240 / 208 Volts
Amps @ 240 / 208 Volts 15.4/13.5
Minimum Circuit Required (Amps) 20
Shipping Weight (Approx.) 115 Lbs.
1
When properly installed, this model is A.D.A.-qualified based on the United States
Access Board’s A.D.A./A.B.A. Accessibility Guidelines and the Department of Justice’s 2010
A.D.A. Standards for Accessible Design.
2
Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz AC only electrical
supply with ground required on separate circuit fused on both sides of line.
2
3.7 /2.8
PRODUCT DIMENSIONS
A - Height 31-7/16"
B - Width 23-7/8"
C - Depth 25-3/16"
D - Wrapper Height (Min. - Max.) 27-1/2" - 29-1/8"
E - Wrapper Width 21-3/4"
Depth with Door Open 90° 46-3/16"
CUTOUT DIMENSIONS
Height (Min.) 27-5/8"
Height (Max.) 28"
Width (Min.) 22"
Width (Max.) 22-1/2"
Depth (Min.) 23-1/2"
B
E
A
C
D
•
USA
10200 David Taylor Drive
•
CANADA
5855 Terry Fox Way
•
Charlotte, NC 28262
•
Mississauga, ON L5V 3E4
•
1-800-FRIGIDAIRE
•
1-800-265-8352
•
frigidaire.com
•
frigidaire.ca
Note: For planning purposes only. Always consult local and national electric, gas and plumbing codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
Specifications subject to change. Accessories information available on the web at frigidaire.com
© 2018 Electrolux Home Products, Inc.
FFEW2426U 05/18
