Page 1
Sprinter
É9065843002#ËÍ
9065843002
Order no. 6462 7664 13 Part no. 906 584 30 02 Edition ÄJ 2013-1a
Fuse Allocation Supplement
Page 2
Symbols
WARNING
G
Warning notes make you aware dangers
which could pose a threat to your health or
life, or to the health and life of others.
Environmental note
H
Environmental notes provide you with
information on environmentallyaware actions
or disposal.
!
Notes on material damage alert you to
dangers that could lead to damage to your
vehicle.
i
These symbols indicate useful
instructions or further information that
could be helpful to you.
X
This symbol designates an
instruction you must follow.
X
Several consecutive symbols
indicate an instruction with several
steps.
(Y page)
This symbol tells you where you
can find further information on a
topic.
YY
This symbol indicates a warning or
an instruction that is continued on
the next page.
DisplayDisplay
This text indicates a message on
the display and the rear view
camera monitor.
Vehicle distributor
In the USA: In Canada:
Mercedes-Benz
USA, LLC
One Mercedes Drive
Montvale, NJ
07645-0350
www.mbusa.com
www.mbsprinterusa.com
Customer
Assistance Center:
1-877-762-8267
Mercedes-Benz
Canada, Inc.
98 Vanderhoof Avenue
Toronto, ON M4G
4C9
www.mercedesbenz.ca
Customer Relations
Department:
1-800-387-0100
Mercedes-Benz USA, LLC and MercedesBenz Canada Inc. are Daimler companies.
Canada only:
"Authorized Sprinter Dealer" is defined as an
authorized Mercedes-Benz Sprinter Dealer.
Publication details
Internet
Further information about Mercedes-Benz
vehicles and about Daimler AG can be found
on the following websites:
www.mercedes-benz.com
www.daimler.com
Editorial office
You are welcome to forward any queries or
suggestions you may have regarding this
manual to the technical documentation team
at the following address:
Daimler AG, HPC: CAC, Customer Service,
70546 Stuttgart, Germany
©
Daimler AG: not to be reprinted, translated
or otherwise reproduced, in whole or in part,
without written permission.
Registered trademarks
ESP®is a registered trademark of Daimler AG.
As at 26.02.2013
Page 3
Index ....................................................... 2
Fuses supplement ................................. 3
Contents
1
9065843002
É9065843002#ËÍ
Page 4
Index
2
F
Fuses ...................................................... 3
Fuse box under the left front seat ...... 7
Main fuse box .................................... 3
R
Relays ..................................................... 3
Main fuse box .................................... 7
V
Voltage supply
Fuses ................................................. 3
Page 5
Fuses supplement
3
Fuses
General safety notes
WARNING
G
If you manipulate or bridge a faulty fuse or if
you replace it with a fusewith a higher
amperage, the electric cables could be
overloaded. This could result in a fire. There
is a risk of an accident and injury.
Always replace faulty fuses with the specified
new fuses having the correctamperage.
Faulty fuses must be replaced with fuses of
the same rating and whichhave the amperage
specified in the following overview. Fuses of
the same rating can be recognized by the
color and amperage. You can obtainadvice
from a qualified specialist workshop.
If a new fuse blows again, have the cause
determined and rectified at a qualified
specialist workshop.
The fuses and relays for the standard
equipment are located in the main fuse box
in the footwell on the left-hand side of the
vehicle.
Additional fuses and relays for the items of
optional equipment are located in the fuse
box under the left front seat and in its seat
base. Always have the fuses in the seat base
replaced at a qualified specialist workshop.
X
Switch off the ignition and the electrical
consumers before changing afuse.
Main fuse box
Fuse boxin the footwell on the left-hand side of the
vehicle.
X
To open: unlock quick-release fastener
1 and remove the cover.
X
To close: attach the bottom edge of the
cover and fold upwards.
The cover must engage.
X
Lockquick-release fastener 2.
Z
Page 6
Fuses supplement
4
Configuration
Fuses
The F87 fuse (30 A) for theDC/DCconverter
is under the SRB fuse and relay module in the
main fuse box. Have this fuse changed at a
qualified specialist workshop only.
SRB fuse and relay module
No. Consumer Fuse
rating
1 Horn 15 A
2 ESTL (electric steering
lock) ignition lock
3 Terminal 30 Z, vehicles
with a gasoline engine/
ignition lock/instrument
cluster
4 Light switch/switch unit
on center console
5 Windshield wipers 30 A
6 Terminal 87/5 10 A
7 MRM (jacket tube
module)
25 A
10 A
5 A
5 A
No. Consumer Fuse
rating
8 Terminal 87 (2) 20 A
9 Terminal 87 (1) 25 A
10 Terminal 87 (4) 10 A
11 Terminal 15 R vehicle 15 A
12 Air bag control unit 10 A
13 Cigarette lighter/glove
box lamp/radio/body
manufacturer loading
tailgate/personal
navigation device (PND)
power socket
14 Diagnostics
connection/light
switch/instrument
cluster/deactivating
reverse warning device/
anti-theft protection with
vehicle tracking
15 A
5 A
Page 7
Fuses supplement
5
No. Consumer Fuse
rating
15 Headlamp range
control/frontcompartment heating
16 Terminal 87 (3) 10 A
17 Air bag control unit 10 A
18 Terminal 15 vehicle/
7.5 A
brake light switch
19 Interiorlighting 7.5 A
20 Co-driver's door power
25 A
window switch/terminal
30/2 SAM (signal
acquisition and
actuation module)
21 Engine control unit 5 A
22 Brake system (ABS) 5 A
23 Terminal 87 (6), starter 10 A
24 Diesel engine, engine
10 A
components/control
unit, vehicles with a
natural gas engine NGT
25 12 V socket in the center
1
25 A
console
Fuse block F55/1
No. Consumer Fuse
5 A
7 Headlamp cleaning
8 Anti-theft alarm system
9 Additional turnsignal
Fuse block F55/2
No. Consumer Fuse
10 Radio
11 Mobile phone/
12 Blower, front/auxiliary
13 Auxiliary heating system
14 Seat heating 30 A
system
(ATA)/beacon/beacon
with siren
module
Radio NTG 2.5
tachograph/additional
recorder
heating blower setting 1
digital timer, radio
receiver/DIN slot basic
wiring/FleetBoard/antitheft protection with
vehicle tracking
rating
30 A
15 A
10 A
rating
15 A
20 A
7.5 A
30 A
7.5 A
No. Consumer Fuse
rating
1 Driver's door control unit 25 A
2 Diagnostics connection 10 A
3 Brake system (valves) 25 A
4 Brake system (delivery
40 A
pump)
5 Terminal 87 (2a), engine 10 A
6 Terminal 87 (1a), engine 10 A
1
Natural Gas Technology.
15 Brake system control
5 A
unit
16 Heating, rear
10 A
compartment heating/
air conditioning, front/
CD changer
17 Motion detector 7.5 A
Z
Page 8
Fuses supplement
6
No. Consumer Fuse
rating
Passengercompartment
illumination (reading
lamps or LED light strip)
Convenience lighting 10 A
Reading and loadcompartment lights
(couriervehicles)
18 Rear-compartment air-
conditioning system
7.5 A
10 A
7.5 A
No. Consumer Fuse
rating
5 Terminal 30 pre-fuse
boxes, SAM (signal
acquisition and
actuation module)/SRB
(fuse and relay module)
6 Connection point on the
base of the seat
7 Passenger compartment
air-conditioning system
PTC heater booster 150 A
150 A
Bridge
80 A
Pre-fuse box in the battery compartment in the
footwell on the left-hand side of the vehicle F59
No. Consumer Fuse
rating
1 Preglow relay
Secondary air pump
2 Air-conditioning system
cooling fan, cab
Cab 40 A
3 SAM (signal acquisition
and actuation module)/
SRB (fuse and relay
module)
4 Auxiliary battery/
retarder
Rear-compartment airconditioning system
80 A
40 A
60 A
80 A
150 A
80 A
Page 9
Fuses supplement
Relays in the main fuse box
No. Relays Description
R1 K40/9 Horn relay
R2 K40/9 Windshield wiper setting 1/2 relay
R3 K40/9 Starter relay, terminal 15
7
R4 K40/9 Windshield wipers on/off relay
R5 K40/9 Starter relay, terminal 50
R6 K40/9 Relay, terminal 15 R (normally opencontact)
R7 K40/9 Engine control unit relay, terminal 87
R8 K40/9 Relay, terminal 15 (reinforced relay)
X
Fuse box under the left front seat
To open: move the front seat to the highest
position.
X
Press both latching springs : down and
remove the cover.
X
To close: attach the bottom edge of the
cover and fold upwards.
The cover must engage.
Fuse box on the outside of the seat base
Z
Page 10
Fuses supplement
8
Configuration
Fuses
Fuse block F55/3
No. Consumer Fuse
rating
1 Mirror setting/rear
window defroster
2 Rear window wiper 30 A
3 Auxiliary heating, digital
timer/rear view
camera/neutral gate
switch, starting-off aid
and all-wheel drive/
engine run-on/DIN slot
basic wiring (roof)/
FleetBoard/anti-theft
protection with vehicle
tracking/emergency
hammer lighting in
passenger compartment
4 Tachograph/ADR
working speed
governor/power takeoff/AAG (trailer control
unit)
7.5 A
5 A
5 A
No. Consumer Fuse
rating
5 ECO Start/control unit
EGS (electronic gearbox
control)
6 All-wheel drive control
unit
7 ESM (electronic selector
module)
8 Loading tailgate/tipper
vehicle
9 Passenger-
compartment air
conditioning,
compressorclutch
5 A
10 A
5 A
10 A
10 A
7.5 A
Page 11
Fuses supplement
9
Fuse block F55/4
No. Consumer Fuse
rating
10 Terminal 30, body/
equipment
manufacturer
11 Terminal 15, body/
equipment
manufacturer
12 D+, body/equipment
manufacturer
13 Fuel pump (FSCM)
Fuel pump relay
14 Trailer power socket 20 A
15 Trailer recognitionunit 25 A
16 Tire pressure monitor/
PARKTRONIC
17 PSM control unit 25 A
18 PSM control unit 25 A
Fuse block F55/5
No. Consumer Fuse
19 Overhead control panel
withoutATA and without
rain sensor
Overhead control panel
with ATA
25 A
15 A
10 A
20 A
15 A
7.5 A
rating
25 A
5 A
No. Consumer Fuse
rating
21 Terminal 30, body
electrics (courier
vehicles)
Rear window defroster
without ATA
Rear window defroster
with ATA
22 Electrical step, co-
driver's door (bus)
Rear window defroster 2 15 A
Vehicle socket (courier
vehicles)
23 Electric system: non-MB
body
12 V left rear socket,
load/ passenger
compartment
24 12 V socket under the
base of driver's seat
25 12 V socket rear right,
cargo compartment/
passenger compartment
26 Hot-water auxiliary
heating
27 Auxiliary warm-air heater
Heater booster system
15 A
30 A
15 A
10 A
20 A
10 A
15 A
15 A
15 A
25 A
20 A
25 A
Overhead control panel
with rain sensor
20 License plate lamp
(courier vehicles)/
perimeter lamp/
entrance lighting (bus)
25 A
7.5 A
Z
Page 12
Fuses supplement
10
Fuse block F55/6
No. Consumer Fuse
rating
28 Starter auxiliary battery/
starterrelay power
supply
29 Terminal 87 (7), gas
7.5 A
system, vehicles with a
natural gas engine
1
(NGT)
SCR2control unit,
vehicles with exhaust
gas aftertreatment
Terminal 30, all-wheel
drive, control unit
30 Auxiliary heat exchanger
fan
Brake booster 30 A
31 Sliding door closing
assistance, left
Electric sliding door, left 30 A
Rear compartment
heating blower
32
SCR2relay supply,
vehicles with exhaust
gas aftertreatment
KEYLESS ENTRY 10 A
33 Sliding door closing
assistance, right
Electric sliding door,
right
Level control (ENR)
control unit
Compressor air
suspension
25 A
10 A
30 A
15 A
15 A
30 A
5 A
15 A
30 A
30 A
30 A
No. Consumer Fuse
rating
34
SCR2heater 3 DEF
15 A
supply reservoir,
vehicles with exhaust
gas aftertreatment
35
SCR2heater 2hose,
15 A
vehicles with exhaust
gas aftertreatment
36
SCR2heater 1delivery
10 A
pump, vehicles with
exhaust gas
aftertreatment
Fuse block F55/7
No. Consumer Fuse
rating
37 Unassigned —
38 Unassigned —
39 Body electrics (courier
7.5 A
vehicles)
Passenger compartment
7.5 A
air-conditioning system
Roof ventilator 15 A
Siren 15 A
40 Unassigned —
41 Unassigned —
42 Rear-compartment air-
30 A
conditioning system
43 Electrical step, sliding
10 A
door, right
44 Electrical step, sliding
10 A
door, left
45 Electrical step, control
system
5 A
1
Natural Gas Technology.
2
Selective Catalytic Reduction.
Page 13
Fuses in the seat base of the left front
seat
There are additional fuses in the seat base,
for example:
R
for the passenger compartment or rear
compartment air conditioning
R
for the windshield heating
R
for other vehicle assemblies, such as the
power-steering pump, auxiliary battery and
PTC heater
R
from the body manufacturers for retarders,
loading tailgates, hydraulic pump and
tippers
Always have the fuses in the seat base
replaced at a qualified specialist workshop.
Fuses supplement
11
Z
Page 14
Fuses supplement
12
Relays in the seat base of the left front seat
No. Relays Description
R1 Unassigned —
R2 K41 Load reliefrelay, terminal 15
R3 K41/5 Starter relay, terminal 15
R4 K64
K110
Secondary air injection/secondary air pump relay
SCR relay2, vehicles with exhaust gas aftertreatment
R5 K27 Fuel pump relay
R6 K23/1 Blower relay, front, blower setting 1
R7 K41/2 Load relief relay, terminal 15 R
R8 K6/1 Starter relay, additional battery
R9 K13/5 Rear window defroster relay 1
R10 K13/6
K51/15
R11 K117/3
K51/16
R12 K117/4
K51/17
R13 K41/3
K51/18
2
Selective Catalytic Reduction.
Rear window defroster relay 2
Snow plow relay, low-beam headlamps, left
Electrical step relay 1, sliding door, left
Snow plow relay, low-beam headlamps, right
Electrical step relay 2, sliding door, left
Snow plow relay, high-beam headlamps, left
Load relief relay, terminal 15 (2)
Snow plow relay, high-beam headlamps, right
Page 15
Fuses supplement
No. Relays Description
R14 K13/7 Windshield heating relay 1
R15 K88 Body manufacturer relay, terminal 15
R16 K88/1 Body manufacturer relay, terminal 61 (D+)
13
R17 K95
K93
K122
R18 K2 Headlamp cleaning system relay
R19 K51/10
K118
R20 K39/3 ATA (anti-theft alarm system) relay, horn
R21 K108
K116
K23/2
R22 K23/3 Blower relay, hot-air auxiliary heating, blower setting
R23 K39/1
K124/1
R24 K117/1 Electrical step relay 1, sliding door, right/co-driver's
R25 K117/2 Electrical step relay 2, sliding door, right/co-driver's
Loading tailgate relay
Comfort illumination relay
LED light strip relay, passengercompartment
lighting
Beacon with siren relay
Entrance lighting relay (bus)
Perimeter lamp relay
License plate lamp relay (courier vehicles)
Blower relay, hot-air auxiliary heating, blower setting
1
2
Siren relay
Terminal 61 (D+) relay, anti-theft protection with
vehicle tracking
door (bus)
door (bus)
R26 K121
K124
Reverse warning device off relay
Anti-theft protection with vehicle tracking relay
Other relays
No. Relays Description
— K57 Battery cutoff relay
— K57/4 Auxiliary battery relay, right-hand-drive vehicle
— K9 Air-conditioning system relay, auxiliary fan (duo)
Z
Page 16
Fuses supplement
14
No. Relays Description
— K9/2 Air-conditioning systemrelay, auxiliary fan (mono)
— K9/5 Passenger-compartment air conditioning relay,
auxiliary fan
Page 17
15
Page 18
16
Loading...
