AHD1S Series

Motherboard

User’s Manual

Statement:

This manual is the intellectual property of Foxconn, Inc. Although the information

in this manual may be changed or modied at any time, Foxconn does not obligate

itself to inform the user of these changes.

Trademark:

All trademarks are the property of their respective owners.

Version:

User’s Manual V1.0 for AHD1S Series motherboard.

Symbol description:

Caution : refers to important information that can help you to use motherboard

better, and tells you how to avoid problems.

Warning : indicating a potential risk of hardware damage or physical injury may

exist.

WEEE:

The use of this symbol indicates that this product may not be treated as household

waste. By ensuring this product is disposed of correctly, you will help prevent potential

negative consequences for the environment and human health, which could otherwise

be caused by inappropriate waste handling of this product. For more detailed

information about recycling of this product, please contact your local city ofce, your

household waste disposal service or the shop where you purchased this product.

More information:

If you want more information about our products, please visit Foxconn’s

website: http://www.foxconnchannel.com

All trade names are registered trademarks of respective manufacturers listed.

All images are for reference only, please refer to the physical motherboard for specic features.

Declaration of conformity

HON HAI PRECISION INDUSTRY COMPANY LTD

66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,

TAIPEI HSIEN, TAIWAN, R.O.C.

declares that the product

Motherboard AHD1S/AHD1S-K

is in conformity with

(reference to the specication under which conformity is declared in

accordance with 89/336 EEC-EMC Directive)

■ EN 55022:1998/A2: 2003 Limits and methods of measurements of radio

disturbance characteristics of information technology equipment

■ EN 61000-3-2/:2000 Electromagnetic compatibility (EMC)

Part 3: Limits

Section 2: Limits for harmonic current emissions

(equipment input current <= 16A per phase)

■ EN 61000-3-3/A1:2001 Electromagnetic compatibility (EMC)

Part 3: Limits

Section 2: Limits of voltage uctuations and icker in low

voltage supply systems for equipment with rated current <= 16A

■ EN 55024/A2:2003 Information technology equipment-Immunity

characteristics limits and methods of measurement

Signature : Place / Date : TAIPEI/2011

Printed Name : James Liang

Declaration of conformity

Trade Name: FOXCONN

Model Name:

Responsible Party: PCE Industry Inc.

Address: 458 E. Lambert Rd.

Fullerton, CA 92835

Telephone: 714-738-8868

Facsimile: 714-738-8838

Equipment Classication: FCC Class B Subassembly

Type of Product: Motherboard

Manufacturer: HON HAI PRECISION INDUSTRY

COMPANY LTD

Address: 66 , CHUNG SHAN RD., TU-CHENG

INDUSTRIAL DISTRICT, TAIPEI HSIEN,

TAIWAN, R.O.C.

AHD1S/AHD1S-K

Supplementary Information:

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions : (1) this device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

Tested to comply with FCC standards.

Signature : Date : 2011

Installation Precautions

■ Electrostatic discharge (ESD) is the sudden and momentary electric current that ows between two objects at different electrical potentials. Normally it

comes out as a spark which will quickly damage your electronic equipment. Please wear an electrostatic discharge (ESD) wrist strap when handling components such as a motherboard, CPU or memory.

■ Ensure that the DC power supply is turned off before installing or removing CPU, memory, expansion cards or other peripherals. It is recommended to unplug the AC power cord from the power supply outlet. Failure to unplug the power supply cord may result in serious damage to your system.

Please carefully read the following procedures to install your computer :

■ It is suggested to select high-quality, certied fans in order to avoid damage

to the motherboard and CPU due to high temperature. Never turn on the computer if the CPU fan is not properly installed.

■ We cannot guarantee that your system can operate normally when your CPU/Memory is overclocked. Normal operation depends on the overclocking capacity of your device.

■ If there is any, when connecting USB, audio, 1394a, RS232 COM, IrDA or

S/PDIF cables to the internal connectors on the motherboard, make sure their pinouts are matching with the connectors on the motherboard. Incorrect connections might damage the motherboard.

■ When handling the motherboard, avoid touching any metal leads or connectors.

■ If there is a PCI Express x16 graphics card installed in your system, we recommend using a 24-pin ATX power supply to get the best performance.

■ Before turning on the power, please make sure the power supply AC input voltage setting has been congured to the local standard.

■ To prevent damage to the motherboard, do not allow screws to come in contact

with the motherboard circuit or its components. Also, make sure there are no leftover screws or metal components placed on the motherboard or within the computer casing.

■ If you are uncertain about any installation steps or have a problem related to the use of the product, please consult a certied computer technician.

TABLE OF CONTENTS

Chapter 1 Product Introduction

Product Specications .................................................................. 2

Layout ........................................................................................... 4

Back Panel Connectors ................................................................ 5

Chapter 2 Installation

Install the Memory ........................................................................8

Install an Expansion Card ............................................................ 9

Install other Internal Connectors.................................................10

Jumpers ......................................................................................14

Install Driver and Utility ...............................................................15

Chapter 3 BIOS Setup

Enter BIOS Setup ....................................................................... 19

Main ............................................................................................20

Advanced ................................................................................... 22

Chipset .......................................................................................29

Boot ............................................................................................31

Power .........................................................................................32

Health .........................................................................................33

Security ..................................................................................... 34

Save & Exit ................................................................................ 36

Technical Support :

Support

Website :

http://www.foxconnchannel.com

Support Website :

http://www.foxconnsupport.com

Worldwide online contact Support :

http://www.foxconnsupport.com/inquiry.aspx

CPU Support List :

http://www.foxconnsupport.com/cpusupportlist.aspx

Memory, VGA Compatibility List :

http://www.foxconnsupport.com/complist.aspx

Thank you for buying Foxconn AHD1S Series motherboard. Foxconn

products are engineered to maximize computing power, providing only

what you need for break-through performance.

With advanced overclocking capability and a range of connectivity

features for today multi-media computing requirements, AHD1S/

AHD1S-K enables you to unleash more power from your computer.

This chapter includes the following information:

■ Product Specications

■ Layout

■ Back Panel Connectors

1-1 Product Specications

CPU Zacate Dual Core APU, Max processor power up to 18W

Chipset Hudson D1

Memory 2 x 240-pin DDR3 DIMMs

Expansion Slots 1 x PCI Express x16 slot (only support PCIE x 4 card )

VGA AMD Radeon HD 6310 Graphics

Storage Hudson D1 chipset:

LAN Realtek RTL8111E Gigabit LAN chip

Audio Realtek ALC662 audio chip:

USB Hudson D1 chipset:

Internal Connectors 1 x 24-pin ATX main power connector

For the latest CPU information, please visit:

http://www.foxconnsupport.com/cpusupportlist.aspx

Support up to 8GB of system memory

Dual Channel

support Direct X11 compliant

- 2 x SATA 2.0 connectors 300MB/s data transfer rate

- Support hot plug and NCQ (Native Command Queuing )

(co-lay Realtek RTL8105E 10/100Mb/s LAN chip)

- High Denition Audio

- 2/4/5.1-channel

- Support for S/PDIF Out

- Support Jack-Sensing function

- Support up to 10 x USB 2.0 ports (6 rear panel ports, 2 onboard USB

headers supporting 4 extra ports)

1 x 4-pin ATX 12V power connector

2 x SATA 2.0 connectors

2 x USB 2.0 connectors (supporting 4 x USB devices)

1 x CPU fan header (4-pin)

1 x System fan header (4-pin)

1 x Front panel connector

1 x Front Audio connector

1 x S/PDIF_OUT connector

1 x Speaker connector

1 x Chassis intrusion alarm header

1 x COM connector

1 x TPM connector

1 x CIR connector

DDR3 1066MHz architecture

(Continued on the next page)

Back Panel

Connectors

Hardware Monitor System voltage detection

PCI Express x16 Transfer rate per lane are 2.5GT/s for PCIe Gen 1 and 5GT/s for PCIe

Green Function Support ACPI (Advanced Conguration and Power Interface)

Bundled Software FOX ONE

Operating System Support for Microsoft® Windows® 7/Vista/XP

Form Factor Mini-ITX Form Factor, 6.7 inches x 6.7inches (17cm x17cm)

1 x PS/2 Keyboard port

1 x VGA port

1 x DVI-D port

1 x HDMI port

6 x USB 2.0 ports

1 x RJ-45 LAN port

6-channel Audio ports

CPU/System temperature detection

CPU/System fan speed detection

CPU overheating warning

CPU/System fan speed control

Gen 2. Low power consumption and power management features

Support S0 (normal), S1 (power on suspend), S3 (suspend to RAM),

S4 (suspend to disk), S5 (soft - off)

Support EuP function

FOX LiveUpdate

FOX LOGO

FOX DMI

1-2 Layout

1. COM Connector

2. TPM Connector

3. Clear CMOS Jumper

4. Front USB Connectors

5. Front Audio Connector

6. System Fan Header

7. SPDIF_OUT Connector

8. Chassis Intrusion Alarm Header

9. PCI Express x16 Slot

10. Front Panel Connector

11. CIR Connector

12. 24-pin ATX Power Connector

13. Speaker Connector

14. DDR3 DIMM Slots

15. SATA Connectors

16. Zacate Dual Core APU

17. Chipset: Hudson D1

18. 4-pin ATX 12V Power Connector

Note : The above motherboard layout is for reference only, please refer to the physical

motherboard for detail.

1-3 Back Panel Connectors

PS/2 Keyboard

Port

VGA Port

3 6

LAN Port

Line In

Line Out

Microphone In

USB Ports

DVI-D Port

HDMI Port

USB Ports Audio Ports

1. PS/2 Keyboard Port

Use the lower port (purple) to connect a PS/2 keyboard.

2. USB Ports

The USB port supports the USB 2.0/1.1 specication. Use this port for USB devices such as an

USB keyboard/mouse, USB printer, USB ash drive and etc.

3. VGA Port

To connect with external display devices, such as monitor or LCD display.

4. DVI-D Port

The DVI-D port supports DVI-D specication. Connect a monitor that supports DVI-D connection

to this port.

5. HDMI Port

The HDMI (High-Denition Multimedia Interface) provides an all-digital audio/video interface to

transmit the uncompressed audio/video signals and is HDCP compliant. Connect the HDMI audio/

video device to this port. The HDMI Technology can support a maximum resolution of 1920x1080p

but the actual resolutions supported depend on the monitor being used.

6. RJ-45 LAN Port

The Ethernet LAN port provides Internet connection at up to 10/100/1000Mb/s data rate.

LAN Type

Left: Active Right: Link

Status Description Status Description

Active

LED

Off No Link Off No Link

1000M

Green

Blinking

Data Activity

Off 10Mb/s Connection

Green 100Mb/s Connection

Orange 1000Mb/s Connection

Link

LED

7. Audio Ports

For the denition of each audio port, please refer to the table below :

Port 2-channel 4-channel 5.1-channel

Blue Line In Rear Speaker Out Rear Speaker Out

Green Line Out Front Speaker Out Front Speaker Out

Pink Microphone In Microphone In

* : Please refer to Chapter 4, and install the Realtek audio driver (in CD) to assign the audio

output ports for different applications of 2/4/5.1 channels. The fundamental audio outputs are

depicted in the table above.

Center/Subwoofer

Speaker Out

This chapter introduces the hardware and software installation proc-

ess, including the installation of the CPU, memory, power supply,

slots, pin headers and the mounting of jumpers. Caution should be

exercised during the installation of these modules. Please refer to the

motherboard layout prior to any installation and read the contents in

this chapter carefully.

This chapter includes the following information :

■ Install the Memory

■ Install other Internal Connectors

■ Jumpers

■ Install Driver and Utility

Please visit the following website for more supporting information about your motherboard.

CPU Support List:

http://www.foxconnsupport.com/cpusupportlist.aspx

Memory, VGA Compatibility List:

http://www.foxconnsupport.com/complist.aspx

2-1 Install the Memory

Read the following guidelines before you begin to install the memory :

■ Make sure that the motherboard supports the memory. It is recommended that memory

of the same capacity, brand, speed, and chips be used.

■ Always turn off the computer and unplug the power cord from the power outlet before

installing the memory to prevent hardware damage.

■ Memory modules have a foolproof design. A memory module can be installed in only

one direction. If you are unable to insert the memory, switch the direction.

■ Be sure to install DDR3 DIMMs on this motherboard.

144-Pin

Notch

96-Pin

If you take a look at front side of memory module, it has asymmetric pin counts on both sides

separated by a notch in the middle, so it can only t in one direction. Follow the steps below to

correctly install your memory modules into the sockets.

Step 1:

Spread the clips at both ends of the memory socket. Place the memory module onto the socket, then put

your ngers on top edge of the module, and push it down rmly and seat it vertically into the memory

socket.

Step 2:

The clips at both ends of the socket will snap into place when the memory module is securely inserted.

2-2 Install an Expansion Card

■ Make sure the motherboard supports the expansion card. Carefully read the manual

that came with your expansion card.

■ Always turn off the computer and unplug the power cord from the power outlet before

installing an expansion card to prevent hardware damage.

PCI Express x16

Follow the steps below to correctly install your expansion card in the expansion slot.

1. Locate an expansion slot that supports your card. Remove the metal slot cover from the chassis

back panel.

2. Align the card with the slot, and press down on the card until it is fully seated in the slot.

3. Make sure the metal contacts on the card are completely inserted into the slot.

4. Secure the card's metal bracket to the chassis back panel with a screw.

5. After installing all expansion cards, replace the chassis cover.

6. Turn on your computer. If necessary, go to BIOS Setup to make any required BIOS changes for

your expansion card(s).

7. Install the driver provided with the expansion card in your operating system.

Installing and Removing a PCI Express x16 Graphics Card :

• Installing a Graphics Card:

Gently insert the graphics card into the PCI Express x16 slot. Make

sure the graphics card is locked by the latch at the end of the PCI

Express x16 slot.

• Removing the Card:

Push the latch at the end of the PCI Express x16 slot to release the card and then pull the card straight up from the slot.

2-3 Install other Internal Connectors

Power Connectors

This motherboard uses an ATX power supply. In order not to damage any device, make sure all the devices have been installed properly before applying the power supply.

24-pin ATX power connector : PWR2

PWR2 is the ATX power supply connector. Make sure that the power supply cable and pins are

properly aligned with the connector on the motherboard. Firmly plug the power supply cable into the connector and make sure it is secure.

Pin # Denition Pin # Denition

1 3.3V 13 3.3V

2 3.3V 14 -12V

3 GND 15 GND

4 +5V 16 PS_ON(Soft On/Off)

5 GND 17 GND

6 +5V 18 GND

7 GND 19 GND

8 Power Good 20 NC

9 +5V SB(Stand by +5V) 21 +5V

10 +12V 22 +5V

11 +12V 23 +5V

12 3.3V 24 GND

PWR2

We recommend you using a 24-pin power supply.

If you are using a 20-pin power supply, you need

to align the ATX power connector according to the picture.

20-Pin Power

4-pin ATX 12 V Power Connector : PWR1

Connect the 4-pin ATX 12V power supply to PWR1 and provides power to the CPU.

3 1

Pin # Denition

+12V

GND

4 2

PWR1

1 GND

2 GND

3 +12V

4 +12V

Pin No. 24

S/PDIF OUT Connector : SPDIF_OUT1

The connector is used for S/PDIF output.

+5V

EMPTY

SPDIF_OUT

GND

SPDIF_OUT1

USB Connectors : F_USB1/2

In addition to the four USB ports on the rear panel, this product also provides two 10-pin USB headers on its motherboard. By connecting through USB cables with them, user can quickly expand another four USB ports on the front panel.

TPM Connector : TPM1

The TPM (Trusted Platform Module) provides the ability to the PC to run applications more secure and to make transactions and communication more trustworthy. To utilize this function, you should purchase additional device and install it.

COM Connector : COM1

This motherboard supports one serial RS232 COM port

for legacy compatibility. User must purchase another

RS232 cable with a 9-pin D-sub connector at one end to connect with the external RS232 device and another

end with 10-pin female connector to connect with COM1

connector in the motherboard.

EMPTY

LCLK#

LFRAME#

LRESET#

LAD3

VDD

LAD0

SB3V

GND

LPCPD#

RLSD

SOUT

GND

RTS

VCC

DD+

GND

F_USB 1/2

1 2

19 20

TPM1

COM1

VCC DD+

GND GND

GND

EMPTY

LAD2

LAD1

GND NC SERIRQ CLKRUN#

SIN

DTR

DSR

CTS

EMPTY

IrDA Connector : CIR

This connector supports infrared wireless transmitting and receiving device.

Front Panel Connector : FP1

This motherboard includes one connector for connecting the front panel switch and LED Indicators.

Hard Disk LED Connector (HDD-LED)

Connect to the chassis front panel IDE indicator LED. It

indicates the active status of the hard disks. This 2-pin

connector is directional with +/- sign.

Reset Switch (RESET-SW)

Attach the connector to the Reset switch on the front panel of the case; the system will restart when the switch is pressed.

Power LED Connector (PWR-LED)

Connect to the power LED indicator on the front panel of the chassis. The Power LED indicates the system’s status. When the system is in operation (S0 status), the LED is on. When the system gets into sleep mode (S1) , the LED

is blinking; When the system is in S3/S4 sleep state or power off mode (S5), the LED is off. This 2-pin connector

is directional with +/- sign.

Power Switch Connector (PWR-SW)

Connect to the power button on the front panel of the chassis. Push this switch allows the system to be turned on and off rather than using the power supply button.

EMPTY

GND NC

HDD-LED

RESET-SW

+5V

1 2

9 10

CIR

FP1

+5VSB

CIRRX

GND CIRTX

EMPTY

PWR-LED

PWR-SW

EMPTY

Serial ATA Connectors : SATA_1/2

The Serial ATA connector is used to connect with SATA Hard Disk or CD devices which supporting this feature. The current Serial ATA II interface allows up to 300MB/s data transfer rate.

SATA _1/2

1 GND TX+

TXGND

RXRX+

GND

Audio Connector : F_AUDIO1

The audio connector supports HD Audio standard. It provides the Front Audio output choice.

A_MIC2_L

A_MIC2_R

A_LINE2_R

SENSE_SEND

A_LINE2_L

AUD_GND

PRESENCEJ SENSE1_RETURN EMPTY

SENSE2_RETURN

109

F_AUDIO1

Fan Headers : CPU_FAN1, SYS_FAN1

There are two main fan headers on this motherboard. The fan speed can be controlled and monitored in “PC Health Status” section of the BIOS Setup. These fans can be automatically

turned off after the system enters S3, S4 and S5 sleeping

states.

Chassis Intrusion Alarm Header : C_INTRUSION1

The connector can be connected to a security switch on the chassis. The system can detect the chassis intrusion through the function of this connector. If eventually the chassis is closed, the system will send a message out.

INTRUDERJ

GND

C_INTRUSION1

Speaker Connector : SPEAKER1

The speaker connector is used to connect speaker of the chassis.

GND POWER SENSE CONTROL

CPU_FAN1/SYS_FAN1

PWR

EMPTY

SPKJ

SPEAKER1

2-4 Jumpers

For some features needed, users can change the jumper settings on this motherboard to modify them. This section explains how to use the various functions of this motherboard by changing the jumper settings. Users should read the following content carefully prior to modifying any jumper setting.

Description of Jumpers

1. For any jumper on this motherboard, Pin 1 can be identied by the bold silkscreen next to it.

However, in this manual, Pin 1 is simply labeled as “1”.

2. The following table explains different types of the jumper settings. "Closed" means placing a jumper

cap on the two pins to temporarily short them. The shorting can also be done by touching two pins by a screwdriver for a few seconds, but using jumper cap is recommended. It can prevent hazardous ESD (Electrical Static Discharge) problem.

Jumper Diagram Denition Description

Clear CMOS Jumper: CLR_CMOS

The motherboard uses CMOS RAM to store the basic hardware information (such as BIOS data, date, time information, hardware password...etc.). Clear CMOS data is the fast way to go back to

factory default when the BIOS settings were mistakenly modied.

The steps to clear CMOS data are :

1. Turn off the computer, unplug the power cord from the power outlet.

2. Remove jumper cap from pins 2-3, put it onto pins 1-2 to short them. This will clear CMOS

data.

3. Return the setting to its original with pins 2-3 closed.

4. Plug in the power cord to your computer and turn it on.

5. Go to BIOS Setup to congure new system as described in next chapter.

1-2 Set Pin 1 and Pin 2 closed

2-3 Set Pin 2 and Pin 3 closed

Normal (Default)

Clear

CLR_CMOS

■ Disconnect the power cable before adjusting the jumper settings.

■ Do not clear the CMOS while the system is turned on.

2-5 Install Driver and Utility

Utility CD Content

This motherboard comes with one Utility CD. You can simply put it into your CD/DVD-ROM drive, and the main menu will be displayed on your PC screen to guide you how to install.

1. Driver

Use these options to install all the drivers for your system. You should install the drivers in order, and you need to restart your computer after all the drivers have been installed.

Items for Windows XP/Vista:

A. AMD Chipset Driver B. Realtek HDA Audio Driver C. Realtek LAN Driver D. CIR Device Driver

Items for Windows 7:

A. AMD Chipset Driver B. Realtek HDA Audio Driver C. Realtek LAN Driver D. CIR Device Driver

2. Utility

Use these options to install additional software programs. FOX ONE is a very powerful user interface program which allows you to change your system setting without going to BIOS. Some auto features help user to improve (or overclock) your system without being a computer literate.

Items for Windows XP/Vista:

A. FOX ONE B. FOX LiveUpdate C. FOX LOGO D. FOX DMI E. Microsoft DirectX 9.0 F. Adobe Acrobat Reader

G. Norton Internet Security H. Browser Conguration Utility

Items for Windows 7:

A. FOX ONE B. FOX LiveUpdate C. FOX LOGO D. FOX DMI E. Adobe Acrobat Reader F. Norton Internet Security G. SmartView [For IE8]

Install Driver and Utility

This motherboard comes with one DVD, after installing the Operating System, you can simply put it into your DVD-ROM drive, and the main menu will be displayed on your PC screen to guide you how to install.

1. Install Driver

Use these options to install all the drivers for your system. You must click "AMD Chipset Driver" to install it rst. After that, you can click ”One Click Setup” and then choose the items you want to

install, or you can click on each individual driver to install it manually.

Manual Installation

Step by Step

Automatic Installation

by One Click

Drop to System Tray

Exit the program

Visit Foxconn's

Website

Show Utilities Show Drivers Browse CD

View the Us-

er’s Manual

Choose the items you

want to Install

(Windows XP/Vista)

Choose the items you

want to Install

(Windows 7)

2. Install Utility

Use these options to install additional software programs. And click “Use’s Manual” button to view the utility(FOX ONE, FOX LiveUpdate, FOX LOGO, FOX DMI) help manual.

(Windows XP/Vista)

(Windows 7)

This chapter tells how to change system settings through the

BIOS Setup menus. Detailed descriptions of the BIOS param-

eters are also provided.

You have to run the Setup Program when the following cases

occur :

1. An error message appears on the screen during the system

Power On Self Test (POST) process.

2. You want to change the default CMOS settings.

This chapter includes the following information :

■ Enter BIOS Setup

■ Main

■ Advanced

■ Chipset

■ Boot

■ Power

■ Health

■ Security

■ Save & Exit

Since BIOS could be updated some other times, the BIOS information described in this

manual is for reference only. We do not guarantee the content of this manual will remain

consistent with the newly released BIOS at any given time in the future. Please visit our

website for updated manual if it is available.

Enter BIOS Setup

The BIOS is the communication bridge between hardware and software, correctly setting up the BIOS parameters is critical to maintain optimal system performance. Power on the computer, when the message "Press <DEL> to enter Setup, <F7> to Boot Menu" appears at the bottom of the screen, you can press <DEL> key to enter Setup.

We do not suggest that you change the default values in the BIOS Setup, and we shall not be responsible for any damage which resulted from the change you made.

Use the arrow right/left keys to select a specic function and go to the submenu. Each function is explained below:

Main

It displays the basic system conguration, such as CPU Name, memory size, system date,

time and so on. They all can be viewed or set up through this menu.

Advanced

The advanced system features can be set up through this menu.

Chipset

The values for the chipset can be changed through this menu, and the system performance can be optimized.

Boot

Boot features can be set up through this menu. You can set the boot device priority and enable

"Quiet Boot" feature here.

Power

All the items related with Green function features can be setup through this menu.

Health

This setup enables you to read/change fan speeds, and displays temperatures and voltages of your CPU/System.

Security

The Administrator/User password can be set up through this menu to prevent unauthorized use of your computer. If you set a password, the system will ask you to key in correct password before boot or access to Setup.

Save&Exit

The optimal performance settings can be loaded through this menu. However, it may offer better performance in some ways (such as less I/O cards, less memory ...etc.), still, it may cause problem if you have more memory or I/O cards installed. It means, if your system loading is heavy, set to optimal default may sometimes come out an unstable system. What you need

now is to adjust BIOS setting one by one, trial and error, to nd out the best setting for your

current system. You also can save or discard the changes and exit BIOS setup here.

Main

12/30/2010]

Set the Date. Use Tab to switch between Date elements.

→ ←: Select Screen ↑ ↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Main Advanced Chipset Boot Power Health Security Save & Exit

Main

System Date [Thu System Time [09:44:21]

Access Level Administrator Model Name AHD1S BIOS Version A93F1B15 Build Date and Time 12/25/2010 14:27:07 Halt On [All, but keyboard]

CPU Brand Name: AMD E-350 Processor Total Memory 1024 MB (DDR3 1066) MAC Address 00-E0-4C-68-00-02

► System Date

<weekday><month><date> <year> format. Day—weekday from Sun. to Sat., this message is automatically displayed by BIOS (Read Only).

Month—month from 1 to 12.

Date—date from 1 to 31. Year—year, set up by users.

Use [ENTER], [TAB] or [SHIFT-TAB] to select a eld. Use [+] or [-] to input the value.

► System Time

This item allows you to congure the desired time. Use [ENTER], [TAB] or [SHIFT-TAB] to select a eld. Use [+] or [-] to input the value. The three elds of the setting are <hour> : <minute> : <second> respectively.

► Access Level

It displays your current access level. If you enter system with a user password, it will dispaly “User”. If no password is set or you enter system with administrator password, this item will dispaly “Administrator”.

► Model Name

This item shows the model name of this product.

► BIOS Version

It displays the current BIOS version. User can check this information and discuss with the eld

service people if a BIOS upgrade is needed.

► Build Date and Time

This item shows the BIOS building date and time.

► Halt On

This category determines whether or not the computer will stop if an error is detected during

powering up. [All Errors]: All errors can result in system halt. [No Errors]: No error can result in system halt. [All, but keyboard]: All errors but keyboard can result in system halt.

► CPU Brand Name

It displays the current CPU name.

► Total Memory

This item displays the total memory size. The size is depending on how many memory modules are installed in your system before powering on.

► MAC Address

This item displays the onboard LAN MAC address.

Advanced

Main Advanced Chipset Boot Power Health Security Save & Exit

▶ Trusted Computing

▶ CPU Configuration ▶ SATA Configuration ▶ USB Configuration ▶ Super IO Configuration ▶ Onboard Device Configuration ▶ Over Clocking Configuration

Advanced

Trusted Computing (TPM) settings

→ ←: Select Screen ↑ ↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

►Trusted Computing/CPU Conguration/SATA Conguration/USB Conguration//Super IO Conguration/Onboard Device Conguration/Over Clocking Conguration

Press <Enter> to go to relative submenu.

Trusted Computing

TPM Configuration

TPM SUPPORT [Disabled]

Current TPM Status Information NO TPM Hardware

Advanced

Enable or Disable TPM support. O.S. will not show TPM. Reset of platform is required.

► TPM SUPPORT

→ ←: Select Screen ↑ ↓: Select Item

Enter: Select

+/-: Change Opt.

F1: General Help

F2: Previous Values F3: Optimized Defaults

F4: Save & Exit

ESC: Exit

This item is used to decide whether to support TPM (Trusted Platform Module) device func-

tion. Default option is [Disabled]. If you want to support TPM, rst you need to install a TPM

device on the motherboard and set this item to [Enabled], then save changing and reset your computer, otherwise the operation system can not show the relative information.

CPU Conguration

Advanced

Disabled for Windowa XP

→ ←: Select Screen ↑ ↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

CPU Configuration

CPU Brand Name:AMD E-350 Processor CPU Speed:1600 MHZ 3000 MHz

Limit CPUID Maximum [Disabled] PSS Support [Enabled]

PSTATE Adjustment [PState 0]

PPC Adjustment [PState 0] NX Mode [Enabled] SVM Mode [Enabled]

► Limit CPUID Maximum

This item is used to enable or disable CPUID limited. when enable, the processor will limit the maximum CPUID. It is recommend that you leave it at the default setting of [Disable].

► PSS Support

This item is used to enable or disable the generation of ACPI _PPC, _PSS and _PCT objects.

► PSTATE Adjustment

This item is used to adjust startup P-state level, you could select PState 0-7.

► PPC Adjustment

This item is used to adjust _PPC object.

► NX Mode

This item is used to enable or disable No-execute page protection function.

► SVM Mode

This item is used to enable or disable CPU Virtualization.

SATA Conguration

SATA Configuration

SATA Port0 Not Present

SATA Port1 Not Present

Advanced

► SATA Port0/1

This item is used to display the information of the SATA Port.

USB Conguration

USB Configuration

USB Devices:

None

Legacy USB Support [Enabled]

Advanced

→ ←: Select Screen ↑ ↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Enables Legacy USB support, AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications.

→ ←: Select Screen ↑ ↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

► Legacy USB Support

This item is used to enable the support for USB devices on legacy OS. If you have a USB keyboard or mouse, set to enabled.

[Enabled]: This option will enable the legacy USB support. [Disabled]: This option will keep USB devices available only for EFI applications. [Auto]: This option will disable the legacy support if no USB devices are connected.

Super IO Conguration

Super IO Configuration

Super IO Chip NCT5573D

▶ Serial Port 0 Configuration

▶ CIR Controller Configuration

►Series Port 0 Conguration/CIR Controller Conguration/

Press <Enter> to go to relative submenu.

Advanced

→ ←: Select Screen ↑ ↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Series Port 0 Conguration

Serial Port 0 Configuration

Serial Port [Enabled] Device Settings IO=3F8h; IRQ=4;

Change Settings [Auto] Device Mode [Standard Serial Po...]

Advanced

Enable or Disable Serial Port (COM)

→ ←: Select Screen ↑ ↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

► Serial Port

This item is used to enable or disable the serial port (COM).

► Device Settings

This item shows the resource assigned to the serial port.

► Change Settings

This item is used to select an optimal settings for the serial port.

► Device Mode

This item is used to change the serial port mode.

CIR Controller Conguration

CIR Controller Configuration

CIR Conroller [Enabled]

Advanced

Enable or Disable CIR Controller

→ ←: Select Screen ↑ ↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

► CIR Controller

This item is used to enable or disable the onboard CIR controller.

Onboard Device Conguration

Onboard Device Configuration

Onboard SATA Controller [Enabled] Onboard SATA Mode [Native IDE] Onboard LAN Controller [Enabled] Onboard LAN PXE OpROM [Disabled]

Onboard USB Controller [Enabled]

Azalia HD Audio Controller [Enabled]

Advanced

Onboard SATA Controller

→ ←: Select Screen ↑ ↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

► Onboard SATA Controller

This item is used to enable or disable the onboard SATA controller.

► Onboard SATA Mode

This item allows you to set the operation mode of the SATA ports. Setting values are: [Native

IDE], [AHCI].

► Onboard LAN Controller

This item is used to enable or disable the onboard LAN controller.

► Onboard LAN PXE OpROM

This item is used to enable or disable onboard LAN boot option ROM.

► Onboard USB Controller

This item is used to enable or disable the USB controller.

► Azalia HD Audio Controller

This item is enable oe disable the Azalia HD audio.

Over Clocking Conguration

Over Clocking Configuration

Memory Voltage [Disabled]

Advanced

Memory Voltage Settings

► Memory Voltage

This item is used to change the memeory voltage.

→ ←: Select Screen ↑ ↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC: Exit

Chipset

Main Advanced Chipset Boot Power Health Security Save & Exit

▶ North Bridge

► North Bridge

Press <Enter> to go to its submenu.

North Bridge

North Bridge Configuration

Memory Information

Total Memory 1024 MB (DDR3 1066) Memory Slot1 Not Present Memory Slot2 1024 MB (DDR3 1066)

Memory Configuration

Integrated Graphics [Auto]

Chipset

North Bridge Parameters

→ ←: Select Screen

↑ ↓: Select Item

Enter: Select

+/-: Change Opt.

F1: General Help

F2: Previous Values

F3: Optimized Defaults

F4: Save & Exit

ESC: Exit

Integrated Graphics controller

► Total Memory

→ ←: Select Screen ↑ ↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values

F3: Optimized Defaults

F4: Save & Exit

ESC: Exit

This item displays the current using memory information.

► Memory Slot 1/2

These items display the memory size installed on each slot.

► Integrated Graphics

This item is used to select which graphics controller is used as the primary boot device.

Boot

Select the keyboard NumLock state

→ ←: Select Screen

↑ ↓: Select Item

Enter: Select

+/-: Change Opt.

F1: General Help

F2: Previous Values

F3: Optimized Defaults

F4: Save & Exit

ESC: Exit

Main Advanced Chipset Boot Power Health Security Save & Exit

Boot Configuration Bootup Numlock State [On]

Quiet Boot [Enabled]

CSM16 Module Version 07.63

Boot Option Priorities

► Bootup Numlock State

This item is used to select the keyboard numlock state. The defaulte setting is [On].

► Quiet Boot

This item is used to enable/disable the quiet boot. [Disabled] : Displays the normal POST messages. [Enabled] : Displays OEM customer logo instead of POST messages.

► Boot Option Priorities

BIOS auto detect the presence of boot devices, you can congure the priority for boot devices.

Power

Main Advanced Chipset Boot Power Health Security Save & Exit

ACPI Power Management

ACPI Sleep State [S3]

Resume By PS2 Keyboard [Enabled] Resume By USB Device(s) [Enabled] Resume By PCIE PME [Disabled] Resume By Modem Ring [Disabled] Resume By RTC [Disabled] Energy-using Products [Enabled] Restore AC Power Loss [Power Off]

Power

Enable/Disable PS2 Keyboard resume system

→ ←: Select Screen ↑ ↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values

F3: Optimized Defaults F4: Save & Exit ESC: Exit

► ACPI Sleep State

This motherboard only support “S3 (STR)” mode, the power will be down after a period of time. The status of the computer before it entering STR will be saved in memory, and the computer can quickly return to previous state when the STR function wakes.

► Resume by PS2 Keyboard

This item is used to enable/disable the PS2 keyboard to generate a wake up.

► Resume by USB Device(s)

This item is used to wake up the system by a USB device when it is staying at S3 state.

► Resume by Modem Ring

This item is used to enable/disable the Modem Ring to generate a wake up.

► Resume by RTC

This item is used to enable/disable RTC alarm event to generate a wake up. RTC is system real time clock.

► Energy-using Products

This item is used to enable/disable the EuP(Energy-using Products) feature. When enable, the

suspend power of the chipset will be cut off in S5 suspend mode in order to reduce the power

consumption of motherboard.

Enabled: S1/S3/S4 is normal, S5 wake up only by pressing the power button.

Disabled: Normal ACPI function.

► Restore AC Power Loss

This item is used to set which state the PC will take with when it resumes after an AC power loss.

Health

Main Advanced Chipset Boot Power Health Security Save & Exit

PC Health Status

Case Open Warning [Disabled]

CPU Temperature : +88 C

System Temperature : +42 C

CPU Fan Speed : N/A System Fan Speed : N/A

CPUVcore : +1.312 V

+3.3V : +3.392 V +12V SYS : +12.096 V +1.1V : +1.112 V AVCC : +3.408 V

3VSB : +3.280 V

VBAT : +3.184 V

CPU Warning Temperature [Disabled] CPU Shutdown Temperature [Disabled] Smart Fan Control [Disabled]

Health

Case Open Warning:Set disable to clear the status

→ ←: Select Screen ↑ ↓: Select Item Enter: Select +/-: Change Opt. F1: General Help F2: Previous Values

F3: Optimized Defaults F4: Save & Exit ESC: Exit

► Case Open Warning

This item is used to enable or disable case open warning function.

► CPU Temperature

These items show the current CPU temperature detected automatically by the system.

► System Temperature

These items show the current System temperature detected automatically by the system.

► CPU Fan Speed

This item shows the current CPU Fan speed detected automatically by the system.

► System Fan Speed

This item shows the current North Bridge Fan speed detected automatically by the system.

► CPU Vcore/+3.3V/+12V SYS/+1.1V/AVCC/3VSB/VBAT

These items show the Current CPU Ccore/+3.3V/+12V SYS/+1.1V/AVCC/3VSB/VBAt voltage

detected automatically by the system.

► CPU Warning Temperature

This option is used to set the warning temperature for the system. When the temperature of

CPU is higher than the set value, the motherboard will send out warning information.

► CPU Shutdown Temperature

This item is used to set the system temperature upper limit. When the temperature exceeds

the set value, the system will shut down automatically.

This function works only when your operating system is supporting ACPI.

► Smart Fan Function

This option is used to enable or disable smart fan function. Default value is [Disabled]. Only when this option is enabled, the CPU/system fan speed will change automatically with the

CPU/system temperature. "Smart Fan Automatic Mode" is the principle gure of CPU smart

fan function for your reference.

Security

Main Advanced Chipset Boot Power Health Security Save & Exit

Password Description

If ONLY the Administrator’s password is set, then this only limits access to Setup and is only asked for when entering Setup. If ONLY the User’s password is set, then this is a power on password and must be entered to boot or enter Setup. In Setup the User will have Administrator rights. The password must be 3 to 20 characters long.

Administrator Password

User Password

HDD Security Configuration HDD 0:ST3160815AS

Security

Set Setup Administrator Password

→ ←: Select Screen ↑ ↓: Select Item

Enter: Select

+/-: Change Opt.

F1: General Help

F2: Previous Values

F3: Optimized Defaults

F4: Save & Exit

ESC: Exit

► Administrator Password

This item is used to install or change administrator password.

Create New Password

After you input administrator password, it then will ask you to

conrm the password.

► User Password

Create New Password

This item is used to install or change user password.

► HDD Security Conguration

“HDD Security Configuration” appears only when you connect HDD to your system. Press “Enter” key on the item “HDD 0:ST3160815AS” to enter into the “HDD Password Configuration” interface, then press “Enter” on “Set HDD Password” to set, modify and clear HardDisk password. HDD Password need to be installed for enabling Security.

Save & Exit

Main Advanced Chipset Boot Power Health Security Save & Exit

Save Changes and Reset Discard Changes and Reset Restore Defaults

Boot Override

Save & Exit

Reset system setup after saving the changes.

→ ←: Select Screen

↑ ↓: Select Item

Enter: Select

+/-: Change Opt.

F1: General Help

F2: Previous Values

F3: Optimized Defaults F4: Save & Exit ESC: Exit

► Save Changes and Reset

If you select this option and press <Enter>, a message will be displayed in the screen. Select [Yes] to save your changes and reset computer, select [No] or <ESC> to return to the main menu.

► Discard Changes and Reset

If you select this option and press <Enter>, a message will be displayed in the screen.

Select [Yes] to exit setup utility and reset computer without saving your modications, select

[No] or <ESC> to return to the main menu.

► Restore Defaults

Optimal defaults are the best settings of this motherboard. Always load the Optimal defaults after updating the BIOS or after clearing the CMOS values. Select this option and press Enter, it will pop out a dialogue box to let you load the defaults. Select <Yes> and then press <Enter> to load the defaults. Select <No> and press <Enter>, it will not load. By this default, BIOS have set the optimal performance parameters of system to improve the performances of system components. But if the optimal performance parameters to be set cannot be supported by your hardware devices (for example, too many expansion cards were installed), the system might fail to work.

Foxconn R10-A1 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
