Foxconn 45CMX User Manual

Statement:

This manual is the intellectual property of Foxconn, Inc. Although the

information in this manual may be changed or modified at any time,

Foxconn does not obligate itself to inform the user of these changes.

Trademark:

All trademarks are the property of their respective owners.

Version:

User’s Manual V1.1 for 45CMX/45GMX Series motherboard.

Symbol description:

Note: refers to important information that can help you to use motherboard

better.

Attention: indicates that it may damage hardware or cause data loss,

and tells you how to avoid such problems.

Warning: means that a potential risk of property damage or physical

injury exists.

More information:

If you want more information about our products, please visit Foxconn’s

website: http://www.foxconnchannel.com

WEEE: The use of the symbol indicates that this product may not be

treated as household waste. By ensuring this product is disposed of

correctly, you will help prevent potential negative consequences for the

environment and human health, which could otherwise be caused by

inappropriate waste handling of this product. For more detailed informa-

tion about recycling of this product, please contact your local city office,

your household waste disposal service or the shop where you pur-

chased the product.

Declaration of conformity

HON HAI PRECISION INDUSTRY COMPANY LTD

66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,

TAIPEI HSIEN, TAIWAN, R.O.C.

declares that the product

Motherboard

45CMX/45CMX-K/45GMX

is in conformity with

(reference to the specification under which conformity is declared in

accordance with 89/336 EEC-EMC Directive)

þ EN 55022: 1998/A2: 2003Limits and methods of measurements of radio disturbance

characteristics of information technology equipment

þ EN 61000-3-2/:2000 Electromagnetic compatibility (EMC)

Part 3: Limits
Section 2: Limits for harmonic current emissions
(equipment input current <= 16A per phase)

þ EN 61000-3-3/A1:2001 Electromagnetic compatibility (EMC)

Part 3: Limits
Section 2: Limits of voltage fluctuations and flicker in low-voltage
supply systems for equipment with rated current <= 16A

þ EN 55024/A2:2003 Information technology equipment-Immunity characteristics limits

and methods of measurement

Signature : Place / Date : TAIPEI/2007

Printed Name : James Liang Position/ Title : Assistant President

Declaration of conformity

Trade Name: FOXCONN

Model Name: 45CMX/45CMX-K/45GMX

Responsible Party: PCE Industry Inc.

Address: 458 E. Lambert Rd.

Fullerton, CA 92835

Telephone: [phone]

Facsimile: 714-738-8838

Equipment Classification: FCC Class B Subassembly

Type of Product: Motherboard

Manufacturer: HON HAI PRECISION INDUSTRY

COMPANY LTD

Address: 66 , CHUNG SHAN RD., TU-CHENG

INDUSTRIAL DISTRICT, TAIPEI HSIEN,

TAIWAN, R.O.C.

Supplementary Information:

This device complies with Part 15 of the FCC Rules. Operation is subject to the follow-

ing two conditions : (1) this device may not cause harmful interference, and (2) this

device must accept any interference received, including interference that may cause

undesired operation.

Tested to comply with FCC standards.

Signature : Date : 2007

Table of Contents

Chapter

Specifications............................................................................................ 2

Jumpers ...................................................................................................18

Chapter

Enter BIOS Setup.................................................................................20

Main menu............................................................................................20

1. Standard CMOS Features..........................................................21

2. FOX Central Control Unit............................................................23

3. Advanced BIOS Features..........................................................25

4. Advanced Chipset Features.......................................................26

5. Integrated Peripherals...............................................................28

6. Power Management Setup........................................................28

7. PC Health Status........................................................................29

8. Load Optimized Defaults...........................................................31

9. Set Supervise Password...........................................................31

10. Set User Password...................................................................31

11. Save & Exit Setup.......................................................................32

12. Exit Without Saving....................................................................32

Chapter

FOX ONE...............................................................................................34

FOX LiveUpdate...................................................................................38

FOX LOGO............................................................................................40

FOX DMI................................................................................................41

Main Features

1

1

BIOS Description

2

2

Directions for Bundled Software

3

3

Attention:

1.Attach the CPU and heatsink using silica gel to ensure full contact.

2.It is suggested to select high-quality, certified fans in order to avoid
damaging the motherboard and CPU due to high temperature.

3. Never turn on the computer if the CPU fan is not properly installed.

4.Ensure that the DC power supply is turned off before inserting or
removing expansion cards or other peripherals, especially when
you insert or remove a memory module. Failure to switch off the DC
power supply may result in serious damage to your system or

memory module.

Attention:

We cannot guarantee that your system will operate normally while

overclock. Normal operation depends on the overclock capacity of

your device.

Attention:

Since BIOS programs are upgrated from time to time, the BIOS

description in this manual is just for reference. We do not guarantee

that the content of this manual will remain consistent with the actual

BIOS version at any given time in the future.

Attention:

The pictures of objects used in this manual are just for your reference.

Please refer to the physical motherboard.

Attention:

Please visit the Foxconn global English website (http://www.

foxconnchannel.com) to download the latest BIOS file and drivers

for this motherboard.

Chapter

Thank you for buying Foxconn’s 45CMX/45GMX Series

motherboard. This series of motherboard is one of our new

products, and offers superior performance, reliability and

quality, at a reasonable price. This motherboard adopts the

advanced Intel® 945GC/945G + ICH7 chipset, providing a com-

puter platform with high integration, powerful compatibility and

high performance-price ratio for users.

This chapter includes the following information:

v Specifications

v Jumpers

1

1

Chapter 1 Main Features

Specifications - - English

Size

CPU

Chipset

Front Side Bus

Memory

Expansion Slots

Audio

LAN

·Micro ATX form factor : 244mm x 203mm

·LGA775 socket for Intel® CoreTM 2 Duo, Pentium® 4

Extreme Edition, Pentium® D, Pentium® 4, Celeron®,

Celeron® D processors

·Northbridge: Intel® 945GC/945G

·Southbridge: Intel® ICH7

·1333(OverClock)/1066/800/533 MHz

·2 x 240-pin DIMM slots

·Supports Dual-Channel DDR2 667/533/400

·Supports up to 4GB

·1 x PCI Express x16 slot

·1 x PCI Express x1 slot

·2 x PCI slots

·Realtek 6-channel Audio CODEC

·Supports S/PDIF output, Jack-Sensing function, Intel

High Definition Audio

·Realtek 10/100 Mb/s LAN Controller / Realtek Gigabit

LAN Controller

®

Storage

Rear Panel I/O

2

·2 x Ultra DMA 100/66/33 devices

·4 x SATA 300MB/s devices

·1 x PS/2 Mouse Port

·1 x PS/2 Keyboard Port

·1 x Serial Port

·1 x Parallel Port

·1 x VGA Port

·4 x USB 2.0 Ports

·1 x RJ45 LAN Port

·6-channel Audio Ports

(continued on the next page)

Chapter 1 Main Features

Internal I/O

Connectors

Support CD

·2 x USB 2.0 headers (supports 4 USB 2.0 ports)

·4 x SATA connectors

·1 x Floppy connector

·1 x IDE connector

·1 x Chassis intruder header (INTR)

·1 x CD_IN header

·1 x Speaker header (optional)

·1 x S/PDIF_OUT header

·1 x COM2 header (optional)

·1 x Front Audio connector

·1 x 24-pin ATX Power Connector

·1 x 4-pin ATX_12V Power Connector

·1 x IrDA header

·1 x CPU Fan connector

·1 x System Fan connector

·1 x NB Fan connector (optional)

·Front panel connector

·Driver

·Utility

·Specifications are subject to change without notice

3

第一章

主要性能

产品规格- -

尺寸

中央处理器

芯片组

系统总线

内存

扩展槽

音频

简体中文

·uATX 结构: 244mm x 203mm

·支持采用 LGA775 封装的 Intel® CoreTM 2 Duo,

Pentium® 4 Extreme Edition, Pentium® D, Pentium
4, Celeron

®

, Celeron® D 处理器

·北桥：Intel® 945GC/945G

·南桥：Intel® ICH7

·1333(OverClock)/1066/800/533 MHz

·2 个 240针脚内存插槽

· 支持双通道 DDR2 667/533/400

· 内存总容量最大可达 4GB

·1 个 PCI Express x16 插槽

·1 个 PCI Express x1 插槽

·2 个 PCI 插槽

·Realtek 6 声道音频编解码器

·支持 S/PDIF 输出,Jack-Sensing 功能,Intel

High Definition Audio

®

®

LAN

存储

后面板I/O

4

·Realtek 10/100 Mb/s LAN Controller/ Realtek
Gigabit LAN Controller

·2 个 Ultra DMA 100/66/33 设备

·4 个 SATA 300MB/s 设备

·1 个 PS/2 鼠标接口

·1 个 PS/2 键盘接口

·1 个 串行接口

·1 个 并行接口

·1 个 VGA 接口

·4 个 USB 2.0 接口

·1 个 RJ45 网络接口

·6声道音频接口

(下页继续)

第一章

主要性能

内置连接器

实用程序光盘

·规格若有任何更改，恕不另行通知

·2 个 USB 2.0 接头（提供 4 USB 2.0 接口）

·4 个 SATA 接头

·1 个 软驱接口

·1 个 IDE 接口

·1 个 机箱开启侦测接头(INTR)

·1 个 CD_IN 接头

·1 个 Speaker 接头(选配)

·1 个 S/PDIF_OUT 接头

·1 个 COM2 接头(选配)

·1 个 前置音频接头

·1 个 24 针ATX 电源接口

·1 个 4 针 ATX_12V 电源接口

·1 个 红外线通讯接头

·1 个 CPU 风扇接头

·1 个 系统风扇接头

·1 个 北桥风扇接头(选配)

·前端面板接头

·驱动程序

·应用程序

5

Kapitel 1 Hauptmerkmale

Technische Daten--Deutsch

Größe

CPU

Chipsatz

Front Side Bus

Speicher

Erweiterungs
steckplätze

Audio

LAN

·Micro ATX-Formfaktor: 244 mm x 203 mm

·LGA775-Sockel für Intel®_CoreTM 2 Duo-, Pentium®_4

Extreme Edition-, Pentium®_D-, Pentium®_4-, Celeron®­ Celeron® _D-Prozessoren

·Northbridge: Intel 945GC/945G

·Southbridge: Intel ICH7

·1333(Übertaktung)/1066/800/533 MHz

·2 x 240-polige DIMM-Steckplätze

· Unterstützt Dual-Channel DDR2 667/533/400

·Unterstützt bis 4GB

·1 x PCI Express x16-Steckplatz

·1 x PCI Express x1-Steckplatz

·2 x PCI-Steckplätze

·Realtek 6-Kanal-Audio CODEC

·Unterstützt S/PDIF-Ausgang, Anschlusserkennung, Intel®

High Definition Audio

·Realtek 10/100 Mb/s LAN / Realtek Gigabit LAN

Speichergeräte

I/O-Anschlüsse an

der Rückseite

6

·2 x Ultra DMA 100/66/33-Geräte

·4 x SATA-Geräte, 300 MB/s

·1 x PS/2-Mausanschluss

·1 x PS/2-Tastaturanschluss

·1 x Seriellanschluss

·1 x Parallelanschluss

·1 x VGA-Port

·4 x USB 2.0-Ports

·1 x RJ45-LAN-Port

·6-Kanal-Audio-Ports

(Fortsetzung auf der nächsten Seite)

Kapitel 1 Hauptmerkmale

Interne I/O­Anschlüsse

Support-CD

·2 x USB 2.0-Anschlussleisten (Unterstützung für 4 USB

2.0-Ports)

·4 x SATA-Anschlüsse

·1 x Diskettenlaufwerkanschluss

·1 x IDE-Anschluss

·1 x Gehäuse-offen-Anschluss (INTR)

·1 x CD_IN-Anschluss

·1 x Lautsprecher-Anschluss (optional)

·1 x S/PDIF_OUT-Anschluss

·1 x COM2-Anschluss (optional)

·1 x Front-Audio-Anschluss

·1 x ATX Power, 24-polig-Anschluss

·1 x ATX_12V Power, 4-polig-Anschluss

·1 x IrDA-Anschluss

·1 x CPU-Lüfter-Anschluss

·1 x Systemlüfter-Anschluss

·1 x NB-Lüfter-Anschluss (optional)

·Frontbedienfeld-Anschluss

·Treibe

·Dienstprogramme

·Angaben können sich ohne Vorankündigung ändern.

7

Capítulo 1 Principales funciones

Características- - Español

Tamaño

CPU

Conjunto de chips

Bus frontal

Memoria

Ranuras
de expansión

Audio

LAN

·Micro ATX factor de forma: 244mm x 203mm

·Conector LGA775 para procesadores Intel® CoreTM 2

Duo, Pentium® 4 Extreme Edition, Pentium® D, Pentium® 4,
Celeron®, Celeron® D

·Northbridge: Intel 945GC/945G

·Southbridge: Intel ICH7

·1333(OverClock)/1066 /800/533 MHz

·2 x ranuras DIMM de 240-pin

·Compatible DDR 2 de doble canal 667/533/400

·Compatible con hasta 4GB

·1 x ranura PCI Express x16

·1 x ranura PCI Express x1

·2 x ranuras PCI

·Realtek 6 canales Audio CODEC

·Compatible salida S/PDIF, sensible a conexión, sonido

Intel® de Alta Definición

·Realtek 10/100 Mb/s LAN / Realtek Gigabit LAN

Almacenamiento

Panel de E/S

trasero

8

·2 x dispositivos Ultra DMA 100/66/33

·4 x dispositivos SATA 300MB/s

·1 x Puerto de ratón PS/2

·1 x Puerto de teclado PS/2

·1 x Puerto Serie

·1 x Puerto Paralelo

·1 x Puerto de VGA

·4 x Puertos USB 2.0

·1 x Puerto LAN RJ45

·Puertos de 6 canales Audio

(continúa en la página siguiente)

Capítulo 1 Principales funciones

Conectores

internos de E/S

CD de soporte

·2 x Cabeceras USB 2.0 (admite 4 puertos USB 2.0)

·4 x Conectores SATA

·1 x Conector de disco flexible

·1 x Conector de IDE

·1 x Cabecera de intrusos en bastidor (INTR)

·1 x Cabecera de CD_IN

·1 x Cabecera de altavoz (opcional)

·1 x Cabecera S/PDIF_OUT

·1 x Conector de COM2(opcional)

·1 x Conector de Audio frontal

·1 x Conector de 24-pin ATX Power

·1 x Conector de 4-pin ATX_12V Power

·1 x Cabecera de IrDA

·1 x Conector de ventilador de CPU

·1 x Conector de ventilador de Sistema

·1 x Conector de ventilador NB (opcional)

·Conector de panel frontal

·Controlador

·Utilidades

·Las características se encuentran sujetas a cambios sin aviso previo.

9

Capítulo 1 Principais características

Especificações- -Portugués

Tamanho

CPU

Chipset

FSB (Front Side

Bus)

Memória

Ranhuras de
expansão

Áudio

LAN

·Factor de forma Micro ATX de 244 x 203 mm

·Socket LGA775 para processadores Intel®_ CoreTM 2

Duo, Pentium®_4 Extreme Edition, Pentium®_D,
Pentium®_4, Celeron®, Celeron®_D

·Northbridge: Intel 945GC/945G

·Southbridge: Intel ICH7

·1333(OverClock)/1066 /800/533 MHz

·2 ranhuras DIMM de 240 pinos

·Suporta módulos de memória DDR2 667/533/400 de canal

duplo

·Suporta até 4 GB

·1 ranhura PCI Express x16

·1 ranhura PCI Express x1

·2 ranhuras PCI

·Realtek com 6 canais, codec de áudio

·Suporta saída S/PDIF, função Jack-Sensing, áudio de alta

definição da Intel®

·Realtek 10/100 Mb/s LAN / Realtek Gigabit LAN

Armazenamento

Entrada/Saída

pelo painel

traseiro

10

·2 dispositivos Ultra DMA 100/66/33

·4 dispositivos SATA de 300 MB/s

·1 x Porta para rato PS/2

·1 x Porta para Teclado PS/2

·1 x Porta série

·1 x Porta paralela

·1 x Porta VGA

·4 x Portas USB 2.0

·1 x Porta LAN RJ45

·Portas 6 canais, áudio

(continua na página seguinte)

Capítulo 1 Principais características

Conectores

internos de
entrada/saída

CD de suporte

·2 x Conectores USB 2.0 (para 4 portas USB 2.0)

·4 x Conectores SATA

·1 x Conector da unidade de disquetes

·1 x Conector IDE

·1 x Conector para detecção de intrusão no chassis(INTR)

·1 x Conector CD_IN

·1 x Conector de altifalante (opcional)

·1 x Conector S/PDIF_OUT

·1 x Conector COM2 (opcional)

·1 x Conector Áudio frontal

·1 x Conector de alimentação ATX de 24 pinos

·1 x Conector de alimentação ATX de 4 pinos e de 12 V

·1 x Conector IrDA

·1 x Conector da ventoinha da CPU

·1 x Conector da ventoinha do sistema

·1 x Conector da ventoinha NB (opcional)

·Conector de painel frontal

·Controlador

·Utilitários

·As especificações estão sujeitas a alteração sem aviso prévio.

11

Capitolo 1 Caratteristiche principali

Specifiche- -Italiano

Dimensioni

CPU

Chipset

FSB (Front Side

Bus)

Memoria

Alloggi
d’espansione

Audio

LAN

·Formato micro ATX: 244 mm x 203 mm

·Socket LGA775 per processori Intel® CoreTM 2 Duo,

Pentium® 4 Extreme Edition, Pentium® D, Pentium®
4, Celeron®, Celeron® D

·Northbridge: Intel 945GC/945G

·Southbridge: Intel ICH7

· 1333(OverClock)/1066 /800/533 MHz

·2 alloggi DIMM 240 pin

·Supporto DDR2 667/533/400 Dual-Channel

·Supporto fino a 4GB

·1 Alloggio PCI Express x16

·1 Alloggio PCI Express

·2 Alloggi PCI

·Realtek 6-canali audio CODEC

·Supporto output S/PDIF, funzione di rilevamento

connettori, Intel® High Definition Audio

·Realtek 10/100 Mb/s LAN / Realtek Gigabit LAN

Archivio

Pannello

posteriore I/O

12

·2 dispositivi Ultra DMA 100/66/33

·4 dispositivi SATA 300MB/s

·1 x Porta mouse PS/2

·1 x Porta tastiera PS/2

·1 x Porta Seriale

·1 x Porta Parallela

·1 x Porta VGA

·4 x Porta USB 2.0

·1 x Porta LAN RJ45

·Porta 6-canali audio

(segue alla pagina successiva)

Capitolo 1 Caratteristiche principali

Connettori I/O

interni

CD di supporto

·2 x Collettori USB 2.0 (supportano 4 porte USB 2.0)

·4 x Connettori SATA

·1 x Connettore Floppy

·1 x Connettore IDE

·1 x Collettore intrusione telaio (INTR)

·1 x Collettore CD_IN

·1 x Collettore altoparlante(optional)

·1 x Collettore S/PDIF_OUT

·1 x Collettore COM2 (optional)

·1 x Connettore Audio frontale

·1 x Connettore potenza ATX 24 pin

·1 x Connettore potenza ATX_12V 4 pin

·1 x Connettore IrDA

·1 x Connettore ventolina CPU

·1 x Connettore ventolina di sistema

·1 x Connettore ventolina NB (optional)

·Connettore pannello frontale

·Driver

·Utilità

·Le specifiche tecniche sono soggette a cambiamenti senza preavviso.

13

Глава 1 Основные характеристики

Технические характеристики- -Русский

Размер

Процессор

Набор микросхем

Частота
системной шины

Память

Слоты
расширения

Звук

ЛВС

·Форм-фактор микро-ATX размером 244 х 203 мм

·Гнездо LGA775 для процессоров Intel®_ CoreTM 2 Duo,

Pentium®_4 Extreme Edition, Pentium®_D, Pentium®_4,
Celeron®, Celeron®_D

·Северный мост: Intel 945GC/945G

·Южный мост: Intel ICH7

·1333(разгон), 1066, 800, 533 МГц

·2 240-контактных гнезда DIMM

·Поддержка Двухканальная память DDR2 667, 533, 400

·Поддержка до 4 Гб

·1 слот PCI Express x16

·1 слот PCI Express x1

·2 слота PCI

·Realtek 6 каналов, звуковой КОДЕК

·Поддержка Выход S/PDIF, функция определения

разъема, поддержка технологии Intel® High Definition

Audio

·Realtek 10/100 Мбит/с ЛВС , Realtek Gigabit ЛВС

Устройство
хранения

Входы и
выходы на
задней панели

14

·2 устройств с интерфейсом Ultra DMA 100, 66, 33

·4 устройств с интерфейсом SATA и скоростью

передачи данных 300 Мб/с

·1 Порт мыши PS/2

·1 Порт Клавиатура PS/2

·1 Последовательный порт

·1 Параллельный порт

·1 Порт VGA

·4 Порты USB 2.0

·1 Разъем ЛВС RJ45

·Порты 6 каналов, звуковой

(продолжение на следующей странице)

Глава 1 Основные характеристики

Встроенные
входы и
выходы

Поддержка
компакт-дисков

·2 Разъемы USB 2.0 (поддержка 4 портов USB 2.0)

·4 Разъемы SATA

·1 Разъем дисковода гибких дисков

·1 Разъем IDE

·1 Разъем датчика открывания корпуса (INTR)

·1 Разъем CD_IN

·1 Разъем динамик (дополнительный)

·1 Разъем выход S/PDIF

·1 Разъем COM2 (дополнительный)

·1 Передний звуковой разъем

·1 Разъем 24-контактный ATX

·1 Разъем 4-контактый ATX_12V

·1 Разъем ИК-порт

·1 Разъем bентилятор процессора

·1 Разъем системный вентилятор

·1 Разъем bентилятор северного моста

(дополнительный)

·Передняя панель разъем

·Драйвер

·Служебная программа

·Технические характеристики могут изменяться без уведомления.

15

ﻞﺼﻔﻟا1ﺔﯿﺴﯿﺋﺮﻟا ﺺﺋﺎﺼﺨﻟا

تﺎﻔﺻاﻮﻤﻟا

ﺔ ﯿﺑﺮﻌﻟ- -

Ÿ عﻮﻧ ﻦﻣ ﺔﯾوﺎﺣ ATX سﺎﻘﻣ 244 ﻢﻣ× 203ﻢﻣ

Ÿ ﺲﺒﻘﻣ LGA775 تﺎﺠﻟﺎﻌﻤﻟ Intel®_ CoreTM 2 Duo

ﺔﯾﺰﻛﺮﻤﻟا ﺔﺠﻟﺎﻌﻤﻟا ةﺪﺣو

و Pentium®_4 Extreme Editionو Pentium®_Dو Pentium®_4 و

Celeron®و Celeron®_D.

ﻢﺠﺤﻟا

Ÿ ﻲﻟﺎﻤﺸﻟا ﺮﺴﺠﻟا)Northbridge(: Intel 945GC/945G
Ÿ ) ﻲﺑﻮﻨﺠﻟا ﺮﺴﺠﻟاSouthbridge(: Intel ICH7

Ÿ 1333)ﻞﻣﺎﺣ يﺮﺼﺑ( / 1066 / 800 / 533ﺰﺗﺮھ ﺎﺠﯿﻣ
Ÿ دﺪﻋ2 تﺎﺤﺘﻓDIMM × 240 ﺎﺳﻮﺑد

Ÿ ةﺎﻨﻘﻟا ﻲﺋﺎﻨﺛ ﻢﯿﻤﺼﺘﻟا ﻢﻋدDual-Channel DDR2 667/533/400
Ÿ ﻰﻟإ ﻞﺼﯾ ﻢﻋد4ﺖﯾﺎﺑ ﺎﺠﯿﺟ

Ÿ دﺪﻋ1 ﺢﺘﻓة PCI Express x16
Ÿ دﺪﻋ1 ﺔﺤﺘﻓPCI Express x1
Ÿ دﺪﻋ2 تﺎﺤﺘﻓ PCI

Ÿ ﺔﯿﻨﻘﺘﺑ تاﻮﻨﻗ ﺖﺴﺑ ﻲﺗﻮﺻ ﺰﯿﻣﺮﺗRealtek
Ÿ جﺮﺧ ﻢﻋدS/PDIFﺔﯿﻨﻘﺗ ،ﺲﺒﻘﻤﻟا رﺎﻌﺸﺘﺳا ﺔﻔﯿﻇو ،Intel® High Definition Audio

ﻖﺋﺎﻗﺮﻟا

ﻲﻣﺎﻣﻷا ﺐﻧﺎﺠﻟا ﻞﻗﺎﻧ

ةﺮﻛاﺬﻟا

ﺔﻌﺳﻮﺘﻟا تﺎﺤﺘﻓ

تﻮﺼﻟا

ﺔﯿﻠﺤﻤﻟا لﺎﺼﺗﻻا ﺔﻜﺒﺷ

Ÿ Realtek 10/100 Mb/s LAN / Realtek Gigabit LAN

Ÿ دﺪﻋ2 ةﺰﮭﺟأ Ultra DMA 100/66/33
Ÿ دﺪﻋ4 ةﺰﮭﺟأSATA 300MB/s

Ÿ دﺪﻋ1 سوﺎﻣ ﺬﻔﻨﻣPS/2
Ÿ دﺪﻋ1 ﺢﯿﺗﺎﻔﻣ ﺔﺣﻮﻟ ﺬﻔﻨﻣPS/2
Ÿ دﺪﻋ1 ﻲﻠﺴﻠﺴﺗ ﺬﻔﻨﻣ
Ÿ دﺪﻋ1 يزاﻮﺘﻣ ﺬﻔﻨﻣ
Ÿ دﺪﻋ1 ﺬﻔﻨﻣVGA
Ÿ دﺪﻋ4 ﺬﻓﺎﻨﻣUSB 2.0
Ÿ دﺪﻋ1 ﺔﯿﻠﺤﻣ لﺎﺼﺗا ﺔﻜﺒﺷ ﺬﻔﻨﻣRJ45
Ÿ ﺔﯿﻨﻘﺘﺑ تاﻮﻨﻗ ﺖﺴﺑ ﻲﺗﻮﺻ ﺬﻓﺎﻨﻣ

ﻦﯾﺰﺨﺘﻟا

ﺬﻓﺎﻨﻣ ﺔﺣﻮﻠﻟ جﺮﺨﻟا/ﻞﺧﺪﻟا

ﺔﯿﻔﻠﺨﻟا

ﺔﯿﻟﺎﺘﻟا ﺔﺤﻔﺼﻟا ﻊﺑﺎﺗ

16

جﺮﺨﻟا / ﻞﺧﺪﻟا ﻞﯿﺻﻮﺗ ﺬﻓﺎﻨﻣ

Ÿ دﺪﻋ2 فاﺮﻃأ ﻞﯿﺻﻮﺗ USB 2.0) ﻢﻋﺪﺗ 4 ﺬﻓﺎﻨﻣ USB 2.0(
Ÿ دﺪﻋ4 ﻞﯿﺻﻮﺗ ﺬﻓﺎﻨﻣSATA
Ÿ دﺪﻋ1ﺔﻧﺮﻤﻟا صاﺮﻗﻷا كﺮﺤﻣ ﻞﯿﺻﻮﺗ ﺬﻔﻨﻣ
Ÿ دﺪﻋ1 ﻞﯿﺻﻮﺗ ﺬﻔﻨﻣ IDE
Ÿ دﺪﻋ1 ﻞﯿﺻﻮﺗ فﺮﻃ Intruder ﻞﻜﯿﮭﻠﻟ) (INTR
Ÿ دﺪﻋ1ﺔﻋﺎﻤﺴﻟا ﻞﯿﺻﻮﺗ فﺮﻃ ) ي ر ﺎﯿﺘﺧا (
Ÿ دﺪﻋ1 ﻞﯿﺻﻮﺗ فﺮﻃ CD_IN
Ÿ دﺪﻋ1 جﺮﺧ ﻞﯿﺻﻮﺗ فﺮﻃ S/PDIF
Ÿ دﺪﻋ1 ﻞﯿﺻﻮﺗ فﺮﻃCOM2) ي ر ﺎﯿﺘﺧا (
Ÿ ﻲﻣﺎﻣﻷا تﻮﺼﻟا ﻞﺻﻮﻣ
Ÿ دﺪﻋ1 ﺔﻗﺎﻃ ﻞﺻﻮﻣ ATX ء، 24 سﻮﺑد
Ÿ دﺪﻋ1 ﺔﻗﺎﻃ ﻞﺻﻮﻣ ATX_12V ×4 ﺲﯿﺑﺎﺑد
Ÿ دﺪﻋ 1 ﻞﯿﺻﻮﺗ فﺮﻃ IrDA
Ÿ دﺪﻋ1ﺔﯾﺰﻛﺮﻤﻟا ﺔﺠﻟﺎﻌﻤﻟا ةﺪﺣﻮﻟ ﺔﺣوﺮﻣ
Ÿ دﺪﻋ1 مﺎﻈﻨﻟا ﺔﺣوﺮﻤﻟ ﻞﺻﻮﻣ
Ÿ دﺪﻋ 1 ﺔﺣوﺮﻣ NB) ير ﺎﯿﺘﺧا (
Ÿ ﺔﯿﻣﺎﻣﻷا ﺔﺣﻮﻠﻟا ﻞﺻﻮﻣ

مﺪ ﻤﻟا صﺮﻘﻟا ﻢﻋد Ÿ ﻞﯿﻐﺸﺘﻟا ﺞﻣﺎﻧﺮﺑ

Ÿ تا ود ﻷا

ﻞﺼﻔﻟا1ﺔﯿﺴﯿﺋﺮﻟا ﺺﺋﺎﺼﺨﻟا

ﺔﯿﻠﺧاﺪﻟا

Ÿ .ﻖﺒﺴﻣ رﺎﻄﺧإ نوﺪﺑ تﺎﻔﺻاﻮﻤﻟا ﺮﯿﻐﺘﺗ ﺪ ﻗ

17

Chapter 1 Main Features

Jumpers

This section explains how to setup jumpers. You should read the following
content carefully prior to modifying any jumper settings.

Attention:

The jumpers on the motherboard, pin 1 can be identified by the
bold silkscreen next to it. And in this manual, pin 1 is simply la­beled as “ 1”.

Clear CMOS Jumper: CLR_CMOS

The CLR_CMOS jumper allows you to clear the data in CMOS. The data
includes system setup information such as system password, data, time,
and system setup parameters. To clear and reset the system parameters
to default setup, please do as follows:

1. Turn off the computer and unplug the power cord
from the power supply.

2. Move the jumper cap from pins 2-3 (default) to pins
1-2. Keep the cap on pins 1-2 for several seconds,
then move the cap back to pins 2-3.

3. Plug the power cord and turn on the computer.

CLR_ CMOS

Normal

(default)

Clear

1

1

USB device wake-up Jumper: USBPWR1/USBPWR2

1.Set the jumper to pins 1-2 (+5V) to wake up the

computer from S1 sleep mode using the connected

USB devices.

2.Set the jumper to pins 2-3 (+5VSB) to wake up the

computer from S3 and S4 sleep modes using the

+5V

(Default)

+5VSB

1

1

connected USB devices. At the same time, a corres-

ponding setting must be set in BIOS as below:

USBPWR1/ USBPWR2

Set “CMOS Setup” -> “Power Management Setup” ->

“Power Management Events” -> “USB KB Wake-Up

From S3” to “Enabled”.

Note:

1. USBPWR1 is for the internal USB connectors, USBPWR2 is for the rear USB ports.

2. The USB device wake-up feature requires a power supply that can provide 500mA

on +5VSB lead for each USB port; otherwise, the system will not power up.

3. The total current consumed must not exceed the power supply capability (+5VSB)

whether under normal condition or in sleep mode.

18

Chapter 2 BIOS Description

Chapter

This chapter introduces how to change system settings

through the BIOS Setup menus. Detailed descriptions of the

BIOS parameters are also provided.

You have to run the Setup Program when the following cases

occur:

1.An error message appears on the screen during the system

2.You want to change the default CMOS settings.

This chapter includes the following information:

2

POST process.

v Enter BIOS Setup

v Main Menu

v Standard CMOS Features

v FOX Central Control Unit

v Advanced BIOS Features

v Advanced Chipset Features

v Integrated Peripherals

v Power Management Setup

v PC Health Status

v Load Optimized Defaults

v Set Supervise Password

v Set User Password

v Save & Exit Setup

v Exit Without Saving

19

Chapter 2 BIOS Description

Enter BIOS Setup

The BIOS is the communication bridge between hardware and software.
Correctly setting up the BIOS parameters is critical to maintain optimal system
performance. Power on the computer, when the following message briefly
appears at the bottom of the screen during the POST (Power On Self Test),
press <Del> key to enter the BIOS CMOS Setup Utility.

Press TAB to show POST screen, DEL to enter SETUP, ESC to enter Boot

Menu.

Note:

We do not suggest that you change the default parameters in the BIOS Setup,
and we shall not be responsible for any damage that results from any changes
that you make.

Main Menu

The main menu displays a list of options that are available. Use the arrow keys
to highlight an item, and execute the item by pressing <Enter>.

Main Menu

The items in the main menu are explained as below:

1. Standard CMOS Features

The basic system configuration can be set up through this menu.

2. FOX Central Control Unit

The special features can be set up by this menu.

3. Advanced BIOS Features
The advanced system features can be set up through this menu.

4. Advanced Chipset Features
The values for the chipset can be changed through this menu, and the sys-

tem performance can be optimized.

5. Integrated Peripherals
All onboard peripherals can be set up through this menu.

20

Chapter 2 BIOS Description

6. Power Management Setup

Through this menu you can set up all the items of Green function features.

7. PC Health Status

This menu will display the current status of your PC.

8. Load Optimized Defaults
You can load the optimal performance settings by this menu; however, the
stable default values may be affected.

9. Set Supervisor Password
The supervisor password can be set up through this menu.

10. Set User Password

The user password can be set up through this menu.

11. Save & Exit Setup

Save CMOS value settings to CMOS and exit setup.

12. Exit Without Saving
Abandon all CMOS value changes and exit setup.

1.Standard CMOS Features

This sub-menu is used to set up the standard CMOS parameters, such as the
date, time, floppy drive and so on. Select the item by the arrow keys, and then
use the <+> or <-> keys to choose the setting values.

Standard CMOS Features Menu

1.1 Date/Time

This item allows you to set up the desired time and date (usually as the
current date and time) with <day><month><date><year> / <hour><minute>
<second> format.

Day—weekday from Sun. to Sat.

Month—month from 1 to 12
Date—date from 1st to 31

st

Year—year, set up by users.

21

Chapter 2 BIOS Description

Use <ENTER>, <TAB> to select a field. Use <+>or <-> to configure system

time and date.

1.2 IDE Channel 0/1/2/3 Master/Slave

These categories identify the HDD types of 1 IDE channel installed in the
computer system. There are three choices provided for the Enhanced IDE
BIOS: None, Auto, and Manual. “None” means no HDD is installed or set;
“Auto” means the system can detect the hard disk and select the HDD mode
automatically when booting up; by choosing “Manual” and changing Access
Mode to “CHS”, the related information should be entered manually. Enter the
information directly from the keyboard and press < Enter>:

Cylinder number of cylinders Head number of heads

Precomp write pre-compensation Landing Zone landing zone

Sector number of sectors

Award (Phoenix) BIOS can support 3 HDD modes: CHS, LBA and Large.

CHS For HDD<528MB

LBA For HDD>528MB & supporting LBA (Logical Block Addressing)

Large For HDD>528MB but not supporting LBA

Note: Set to [Auto] , the system can detect the hard disk and select the

HDD mode automatically when booting up. Suggest you select this option.

1.3 Drive A

This option allows you to select the kind of FDD to be installed, including
[None], [360K, 5.25 in], [1.2M, 5.25 in], [720K, 3.5 in], [1.44M, 3.5 in] and
[2.88 M, 3.5 in].

1.4 Halt On

This category determines whether or not the computer will stop if an error
is detected during powering up.

All Errors Whenever the BIOS detects a nonfatal error, the system

will stop and you will be prompted.

No Errors The system boot will not stop for any errors that may

be detected.

All, But Keyboard The system boot will not stop for a keyboard error; but

it will stop for all other errors.

All, But Diskette The system boot will not stop for a diskette error; but

it will stop for all other errors.

All, But Disk/Key The system boot will not stop for a keyboard or disk

error; but it will stop for other errors.

22

Chapter 2 BIOS Description

1.5 Installed Memory

This is a Display-Only Category, showing the capacity of your installed memory.

1.6 BIOS ID

This option displays the information about BIOS ID.

2.FOX Central Control Unit

FOX Central Control Unit Menu

2.1 SuperBIOS Protect

SuperBIOS Protect function protects your BIOS from being affected by viruses,
e.g.CIH.

2.2 Current CPU Frequency

This option shows the current frequency of CPU.

2.3 Current FSB Frequency

This option shows the current frequency of FSB.

2.4 Current DRAM Frequency

This option shows the current frequency of DRAM.

2.5 Auto Detect PCI Clk

This option is used to auto detect PCI slots. When enabled, the system will
move (turn off) the empty PCI slot clock to reduce EMI (Electromagnetic
Interference).

2.6 CPU Clock Ratio

This option is used to set the ratio of an unlocked CPU. Using different CPU,
the setting values are different.

2.7 Ratio Free

This option is only used to CPU whose frequency is more than 3.4 GHz. When

you use this type CPU, “CPU Clock Ratio” value is fixed at 14X.

2.8 FOX Intelligent Stepping

You can select different overclock option by this item. The available setting

values are: Default, Manual, Step1, Step2, Step 3.

23

Chapter 2 BIOS Description

2.9 DRAM Configuration

DRAM Configuration Menu

DRAM Timing Selectable

This item determines DRAM clock/ timing using SPD or manual configuration.

CAS Latency Time

This item determines CAS Latency. The available setting values are: 5, 4, 3, 6
and Auto.

DRAM RAS# to CAS# Delay

This item allows you to select a delay time between the CAS and RAS strobe
signals. The available setting values are: 2, 3, 4, 5, 6 and Auto.

DRAM RAS# Precharge

This item allows you to select the DRAM RAS# precharge time. The available
setting values are: 2, 3, 4, 5, 6 and Auto.

Precharge Delay(tRAS)

This item allows you to set the precharge delay time. The available setting
values are: Auto, 4 -15.

System Memory Frequency

This item is used to set the memory frequency of your system. The avail­able setting values are: Auto, 400 MHz, 533 MHz, 667 MHz.

Attention: When you use the CPU that FSB is 1333 MHz, the available
setting values are: Auto, 500 MHz, 667 MHz, 834 MHz.

2.10 CPU Clock

When “FOX Intelligent Stepping” is set to “Manual”, this option is used to set

the CPU clock.

2.11 PCI Express Clock

When “FOX Intelligent Stepping” is set to “Manual”, this option is used to set
the PCI Express clock.

24

Chapter 2 BIOS Description

2.12 CPU Voltage Regulator

When “FOX Intelligent Stepping” is set to “Manual”, this option is used to
regulate the CPU voltage.

2.13 DRAM Voltage Regulator

When “FOX Intelligent Stepping” is set to “Manual”, this option is used to
regulate the DRAM voltage.

2.14 Spread Spectrum

When “FOX Intelligent Stepping” is set to “Manual”, If you enable this potion, it
can significantly reduce the EMI (Electromagnetic Interference) generated
by the system.

3.Advanced BIOS Features

Advanced BIOS Features Menu

3.1 CPU Feature

You can press <Enter> to set the items of CPU feature.

3.2 Removable Device Priority

This option is used to select the priority for removable devices, e.g. floppy.

3.3 Hard Disk Boot Priority

This option is used to select the priority for HDD startup. After pressing
<Enter>, you can select the HDD using the Up / Down arrow keys,

and change the HDD priority using <PageUp> / <PageDn> or <+> / <->;

you can exit this menu by pressing <Esc>.

3.4 CPU L1 & L2 Cache

This option is used to turn on or off the L1 and L2 CPU cache.

3.5 Hyper-Threading Technology

This option is used to enable or disable Hyper-Threading technology.

3.6 First/Second/Third Boot Device

This option allows you to set the boot device’s sequence.

25

Chapter 2 BIOS Description

3.7 Boot Other Device

When enabled, the system will boot from some other devices if the first/

second/third boot devices failed.

3.8 Boot Up Floppy Seek

This option controls whether the BIOS checks for a floppy drive while booting
up. If it cannot detect one (either due to improper configuration or physical
unavailability), it will appear an error message.

3.9 Boot Up NumLock Status

This item allows you to select the power-on status for the NumLock. The

available setting values are: On and Off.

3.10 Security Option

When it is set to “Setup”, a password is required to enter the CMOS Setup
screen; When it is set to “System”, a password is required not only to enter
CMOS Setup, but also to start up your PC.

3.11 APIC Mode

This option is used to enable or disable APIC function.

3.12 Delay For HDD (Secs)

This option is used to set the delay time of selecting the HDD controller.

3.13 Full Screen LOGO Show

This option allows you to enable or disable the full screen logo.

3.14 Small Logo (EPA) Show

This item allows you to enable or disable the EPA logo.

4.Advanced Chipset Features

Advanced Chipset Features Menu

4.1 System/ Video BIOS Cacheable

Select ”Enabled” to allow caching of the system/video BIOS which may im­prove performance. If any other program writes to this memory area, a system
error may result.

26

Chapter 2 BIOS Description

4.2 PEG/Onchip VGA Control

This item is used to enable or disable PEG and onboard VGA.

4.3 PEG Force X1

When enabled, the PCI-E x16 slot will be forced to work in the PCI-E x1 mode.
When disabled, the PCI-E x16 slot will be allowed to work in the PCI-E x16
mode.
Note: This item is only available when external display card is installed.

4.4 On-Chip Frame Buffer Size

This item is used to set the VGA frame buffer size.

Note: This item is only available when onboard VGA is used.

4.5 DVMT Mode

This item is used to set the DVMT mode.

Note: This item is only available when onboard VGA is used.

4.6 DVMT/FIXED Memory Size

This item is used to set the DVMT/FIXED memory size.

Note: This item is only available when onboard VGA is used.

4.7 Boot Display

This item is used to select the display type used when your PC starts up. The
available setting values are: Auto, CRT, TV and EFP.

Note: This item is only available when onboard VGA is used.

4.8 Init Display First

This item is used to select the initial display device used when your PC starts
up.

4.9 PCI Express x1 Port

This option is used to enable or disable PCI Express x1 slot .

4.10 PCI-E Compliancy Mode

This option is used to select PCI-E compliancy mode.

4.11 Maximum Payload Size

This option is used to set maximum TLP payload size for PCI Express devices.
The unit is byte.

27

Chapter 2 BIOS Description

5.Integrated Peripherals

Integrated Peripherals Menu

5.1 OnChip IDE Device

This sub-menu is used for the configuration of IDE devices. You can press

<Enter> to set the available values of items.

5.2 Onboard Device

This sub-menu is used for the configuration of onboard devices.

5.3 SuperIO Device

This sub-menu is used for the configuration of I/O devices, such as serial

port, parallel port and so on.

5.4 USB Device Setting

This sub-menu is used for the configuration of USB devices.

6.Power Management Setup

Power Management Setup Menu

6.1 ACPI Function

ACPI( Advanced Configuration and Power Interface) is a standard that de­ fines power and configuration management interfaces between an operating
system and the BIOS. In other words, it is a standard that describes how

28

Chapter 2 BIOS Description

computer components work together to manage system hardware. In order
to use this function the ACPI specification must be supported by the OS (for
example, Windows2000 or WindowsXP).

6.2 ACPI Suspend Type

This option is used to set the energy saving mode of the ACPI function.
When you select “S1 (POS)” mode, the power will not shut off and the
supply status will remain as it is, in S1 mode the computer can be resumed
at any time. When you select “S3 (STR)” mode, the power will be cut off after
a delay period. The status of the computer before it enters STR will be saved
in memory, and the computer can quickly return to previous status when the
STR function wakes.

6.3 Soft-Off by PWR-BTTN

This option is used to set the power status after you press power button.
When select “Instant-off”, once press power button, the power will turn off
immediately; When select “Delay 4 sec”, the power will be off after the power
button is pressed more than 4 seconds.

6.4 HPET Support
This option allows you to enable or disable High Precision Event Timer function.

If you use windows vista processing system, we intensively suggest that you
set this option to “Enabled”.

6.5 HPET Mode
This option is used to set the High Precision Event Timer mode. The available

setting values are: 32-bit mode, 64-bit mode. It can be available only when
“HPET” is enabled.

6.6 Power Management Events
You can press <Enter> to set the parameters of power management events.

7.PC Health Status

PC Health Status Menu

7.1 Case Open Warning

This option is used to enable or disable case open warning function.

29

Chapter 2 BIOS Description

7.2 Shutdown Temperature

This option is used to set the high limit system temperature. When the
temperature exceeds the setting value, the motherboard will automatically cut
off power to the computer.

7.3 Warning Temperature

This option is used to set the warning temperature for the system. When the
temperature of CPU is higher than setting value, the motherboard will send
off warning information.

7.4 CPU Vcore/+ 3.3V/+5V/+12V/VDDR

The current voltages will be automatically detected by the system.

7.5 CPU/System Temperature

The current CPU/System temperature will be automatically detected by the
system.

7.6 CPU Fan/System Fan Speed

The current CPU fan/System fan speed automatically detected by the

system.

7.7 Smart Fan Control

This option is used to enable or disable smart fan function. Only when this
option is enabled, you can set some correlative parameters. “ Smart Fan
Automatic Mode” is the principle figure of CPU smart fan for your reference.

Smart Fan Automatic Mode

“Start 1 Temp(℃) ”allows you set the start 1 temperature which is initial
temperature of smart fan.

“Start 1 PWM Value” allows you to set the initial PWM value of smart fan.

“Slope 1 Integer Fraction” is used to set the integer fraction of slope 1 of
smart fan curve.

“ Slope 1 Decimal Fraction” is used to set the decimal fraction of slope 1 of
smart fan curve.

30

Chapter 2 BIOS Description

“Delta 1 Temp(℃) ” is used to set the temperature delta. When the change
amplitude of temperature achieves the value, the PWM value will increase or
decrease by slope 1.

“Start 2 Temp(℃)”, “Slope 2 Integer Fraction”, “Slope 2 Decimal Fraction”,
“Delta 2 Temp(℃)” is the same with slope 1 curve. The only one difference

is that the value of slope 2 is different from slope 1.
For example, slope 1= 2.500, slope 2 integer fraction = 1, slope 2 decimal
fraction = 0.125, slope 2 = 2.500+1+0.125 = 3.625.

In the automatic mode, the PWM value is subject to the temperature inputs by
linear changing. When the temperature reading is between start 1 temperature
and full limit, the PWM value changes depending on the temperature reading if
the reading exceeds the delta. If the temperature increase X℃, the PWM value
will increase X*slope.

“Sys Start 1 Temp(℃)”, “Sys Start 1 PWM Value”, “Sys Slope 1 Integer

Fraction”, “Sys Slope 1 Decimal Fraction”, “Sys Delta 1 Temp(℃)”, “Sys
Start 2 Temp(℃)”, “Sys Slope 2 Integer Fraction”, “Sys Slope 2 Decimal
Fraction”,“Sys Delta 2 Temp(℃)” is a group of parameters of system smart

fan. Its principle is the same with CPU smart fan.

8.Load Optimized Defaults

This menu can let you load the optimized defaults set by BIOS, which have set
the optimized performance parameters of system to improve the performances
of system components. You can select <Y> or <N> and then press <Enter> to
load or not load the optimized defaults.

9-10. Set Supervisor/User Password

The access rights and permissions associated with the Supervisor password are

higher than those of a regular User password. The Supervisor password can be

used to start the system or modify the CMOS settings. The User password can

also start the system. While the User password can be used to view the current

CMOS settings, these settings cannot be modified using the User password.

When you select the Set Supervisor/User Password option, the following message

will appear in the center of the screen, which will help you to set the password:

Enter Password:

Enter your password, not exceeding 8 characters, then press <Enter>. The

password you enter will replace any previous password. When prompted, key in

the new password and press <Enter>.

If you do not want to set a password, just press <Enter> when prompted to enter

a password, and in the screen the following message will appear. If no password

31

Chapter 2 BIOS Description

is keyed in, any user can enter the system and view/modify the CMOS settings.

Password Disabled!!!

Press any key to continue …

Under the menu “Advanced BIOS Features”, if you select “System” from the

Security Option, you will be prompted to enter a password once the system is

started or whenever you want to enter the CMOS setting program. If the

incorrect password is entered, you will not be permitted to continue.

Under the menu “Advanced BIOS Features”, if you select “Setup” from the

Security Option, you will be prompted to enter a password only when you

enter the CMOS setting program.

11.Save and Exit Setup

When you select this option and press <Enter>, the following message will
appear in the center of the screen:

SAVE to CMOS and EXIT (Y/N)?Y

Press <Y> to save your changes in CMOS and exit the program; press <N> or
<ESC> to return to the main menu.

12.Exit Without Saving

If you select this option and press <Enter>, the following message will appear

in the center of the screen:

Quit Without Saving (Y/N)?Y

Press <Y> to exit CMOS without saving your modifications; press <N> or
<ESC> to return to the main menu.

32

Chapter 4 Driver CD Introduction

Chapter

This chapter will introduce how to use attached software.

This chapter provides the following information:

v FOX ONE
v FOX LiveUpdate

v FOX LOGO

v FOX DMI

3

3

33

Chapter 3 Directions for Bundled Software

FOX ONE

FOX ONE is a powerful utility for easily modifying system settings. It also allows
users to monitor various temperature values, voltage values, frequency and fan
speed at any time.

Supported Operating Systems:

-Windows 2000 -Windows 2003 (32-bit and 64-bit)

-Windows XP (32-bit and 64-bit) -Windows Vista (32-bit and 64-bit)

Using FOX ONE:

The very first time you run FOX ONE, F.I.S. Calibration function (FOX Intelligent
Stepping) will require you to calibrate the CPU’s loading. Click “OK” to process
and start the Utility.

Note: Only when your computer supports F.I.S. Calibration function(FOX
Intelligent Stepping), the calibraion process will appear, or you can start
FOX ONE directly.

1. Main Page

Show CPU Information

34

Use the toolbar to navigate to
other pages

Alert Lamp

Switch Button

Skin Button

Exit

Minimum

Configuration
Homepage

Monitor Frequency/Voltage/Fan speed/Temperature value

Chapter3 Directions for Bundled Software

Alert Lamp

When the system is in healthy status, the alert lamp color is green. When in
abnormal status, the color will turn red.

Switch Button

Click this button, it will simplify the window to HW monitor information bar as the
below figure shows. The bar could help you to monitor whether your system is in the

healthy status or not at any time.

Click here to return to
previous window

HW monitor information bar

Skin Button

Click this button, you will see the additive figures, such as “Crystal”and “Rock”.You
may select your favorite skin.

Configuration

This page allows you to select monitor interval time (ms) and temperature unit. It
also provides “Auto start up” function. Besides, click “Selection” to determine
which items will be shown in simple mode. In “F.I.S. Calibration”section, we
recommend you re-calibrate the CPU’s loading by clicking “calibration” button
after changing the CPU or memory modules, then restart the computer to apply
new setting. Attention: F.I.S. calibration function is optional.

Monitor

Interval

Selection

Calibration

Apply the changesResume default setting

Homepage

Click this button to visit Foxconn global English website.

Close

Temperature
Unit

Start Up

Configuration

35

Chapter 3 Directions for Bundled Software

2. CPU Page - CPU Control

This page is used to select and run the CPU frequency to determine the current
performance level of the system. You can adjust the CPU frequency manually or
select “Auto Overclock”. Besides, it also provides “FOX Intelligent Stepping”, but
this function is optional.

Go to CPU page

Auto
Overclocking

Adjust manually

Select the different
benchmarks

Resume default setting

Apply the changes

3. Freq. Page - Frequency Control

In this page, you can set memory and PCIe frequency manually.
Note: The function of PCIe Frequency is optional.

Go to Freq. page

Select the option

Adjust manually

Resume default setting Apply the changes

36

Chapter3 Directions for Bundled Software

4. Limit Setting page

This page includes five different sections. “CPU Temp.” and “Sys. Temp.” will help
you to set high limit temperature. “CPU Fan”, “Sys. Fan” and “FAN1 fan” are used
to set low limit rpm. All of them have alert function.

Go to Limit Setting page

Set high limit by dragging the lever

Show current CPU temperature value

Enable alert function
when the CPU
temperature is higher
than high limit value

Show current high
limit value of CPU
temperature

5. Voltage Page - Voltage Control (Optional)

This page allows you to set CPU, memory and North Bridge voltage manually.

Go to Voltage page

Select the option

Adjust manually

Resume default setting Apply the changes

6. Fan Page - Fan Control

This page allows you to enable Smart Fan function and set fan speed manually.

37

Chapter 3 Directions for Bundled Software

Go to Fan page

Enable or disable
smart fan function

Set fan speed by
dragging the lever

Apply the changesResume default setting

FOX LiveUpdate

FOX LiveUpdate is a useful utility to backup and update the system BIOS online
or locally. Drivers and utilities aslo can be updated online.

Supported Operating Systems:

-Windows 2000 -Windows 2003 (32-bit and 64-bit)

-Windows XP (32-bit and 64-bit) -Windows Vista (32-bit and 64-bit)

Using FOX LiveUpdate:

1. Local Update

“BIOS Info” tells you the system BIOS information; “Backup BIOS” could
backup your system BIOS, click this button ,then input a BIOS name and save
it; “Update BIOS” helps to update your system BIOS from local BIOS files,
please follow the request to finish the operation.

Exit

Link to website

Toolbar

38

Minimum

Show current

BIOS information

Chapter3 Directions for Bundled Software

2. Online Update

This function enables you to update your system BIOS, Drivers, Utilities and all of
them from Internet. Click “start”, it will search for the new BIOS, Drivers and
Utilities from Internet. Then follow the request to finish the update operation.

Current

Click here

3. Configure

“Option” provides “auto search options”, “auto search Fox LiveUpdate” and “version
filter”. After setting “auto search options” and “auto search Fox LiveUpdate”, the utility
will work in the background and the related information will show in a pop balloon
notification and a dialogue box; click the “System” button, you can set the backup BIOS
location and select different kinds of skin for the utility; “Advance” helps you to flash
BIOS, boot Block and clear CMOS, and we recommend you keep the default setting
unchanged to avoid damage.

information

Search for new
BIOS, Drivers and
Utilities from Internet

Click here

Set auto
search options

Select to search
for the latest Fox
LiveUpdate

Select to search
for different kinds
of versions

Apply the changesResume default setting

39

Chapter 3 Directions for Bundled Software

4. About & Help

This page shows some information about FOX LiveUpdate.

Information about

Click here

FOX LiveUpdate

FOX LOGO

FOX LOGO is a simple and useful utility to backup, change and delete the boot
Logo. The boot Logo is the image that appears on screen during the Power-On
Self-Tests (POST).

Supported Operating Systems:

-Windows 2000 -Windows 2003 (32-bit and 64-bit)

-Windows XP (32-bit and 64-bit) -Windows Vista (32-bit and 64-bit)

Using FOX LOGO:

Main Page

Main screen

Backup

Change

Delete

Warning:

When you change Logo or delete current Logo, the system will flash BIOS
file automatically. During this time, DO NOT shut down the system and the
application, or the motherboard would be damaged seriously.

40

Exit

Minimize

Website

About

Chapter3 Directions for Bundled Software

FOX DMI

FOX DMI is a full DMI information viewer, and it supports three kinds of DMI Data
format :Report, Data Fields and memory Dump.

Supported Operating Systems:

-Windows 2000 -Windows 2003 (32-bit and 64-bit)

-Windows XP (32-bit and 64-bit) -Windows Vista (32-bit and 64-bit)

Using FOX DMI:

Please operate this utility as the comments show.

Click here to select
the DMI Data format

Click here to
select the type

41
