802.11 a/n/ac Module

PCE4502AN

User’s Manual

Hardware Specification

Standard

IEEE802.11a; IEEE802.11n; IEEE802.11ac

RF

QCA9882

Interface

64-bit PCI-E

Operating Voltage

3.3v

Antenna Connectors

I-PEX x2

Radio specification

Data rate

867Mbps

Channel

Data rate

Typical Rx Sensitivity

(dBm combined)

802.11a

6Mbps

≦-92 dBm

54 Mbps

≦-74 dBm

802.11a/n_HT20

MCS 0/8

≦-91 dBm

MCS 7/15

≦-72 dBm

802.11n_HT40

MCS 0/8

≦-90 dBm

MCS 7/15

≦-70 dBm

802.11ac_HT80

MCS 0

≦-87 dBm

MCS 9

≦-62 dBm

Antenna Specification

(Internal Antennas)

Antenna

2 x Antennas

Type

Internal PIFA

Antenna

Peak Gain (dBi)

5150~5250MHz

5250~5350MHz

5470~5725MHz

5725~5850MHz

Ant0

5.74

5.91

6.13

3.78

Ant1

5.50

5.40

4.74

4.29

Environment

Operation temperature

0-40 deg C

PRODUCT DESCRIPTION

The PCE4502AN is adapting the next generation Wi-Fi technology, 802.11ac. It provides
the great improvement in performance compare with 802.11n by utilizing 2Tx / 2Rx
technology to achieve 867Mbps throughput on the 5GHz bands.

PRODUCT SPECIFICATION

* All RF parameters tolerance are +2/-1 dBm

Any changes or modifications not expressly approved by the manufacturer could void the user's authority to
operate this equipment.
