Ford Mountaineer 2006 User Manual

Table of Contents

Introduction 4 Instrument Cluster 12

Warning and control lights 12 Gauges 18

Entertainment Systems 21

AM/FM stereo with CD 21 AM/FM stereo cassette with CD 25 AM/FM stereo with in-dash six CD 29

Climate Controls 35

Manual heating and air conditioning 35 Automatic temperature control 37 Auxiliary passenger climate control 40 Rear window defroster 41

Lights 42 Driver Controls 53

Windshield wiper/washer control 53 Steering wheel adjustment 54 Power windows 58 Mirrors 60 Speed control 61 Message center 71

Locks and Security 101

Keys 101 Locks 101 Anti-theft system 104

Table of Contents

Seating and Safety Restraints 117

Seating 117 Safety restraints 129 Airbags 144 Child restraints 158

Tires, Wheels and Loading 173

Tire Information 175 Tire Inflation 178 Tire Pressure Monitoring System (TPMS) 189 Vehicle loading 194 Trailer towing 201 Recreational towing 207

Driving 209

Starting 209 Brakes 212 Traction control/AdvanceTrac 214 Transmission operation 219

Roadside Emergencies 237

Getting roadside assistance 237 Hazard flasher switch 239 Fuel pump shut-off switch 239 Fuses and relays 240 Changing tires 248 Lug Nut Torque 258 Jump starting 259 Wrecker towing 264

Customer Assistance 266

Reporting safety defects (U.S. only) 272

Table of Contents

Cleaning 273 Maintenance and Specifications 280

Engine compartment 282 Engine oil 285 Battery 290 Engine Coolant 292 Fuel information 298 Air filter(s) 311 Part numbers 311 Refill capacities 312 Lubricant specifications 314

Accessories 321 Index 323

All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Ford may change the contents without notice and without incurring obligation.

Introduction

CALIFORNIA Proposition 65 Warning

WARNING: Engine exhaust, some of its constituents, and

certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

CONGRATULATIONS

Congratulations on acquiring your new Mercury. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.

For more information on Ford Motor Company and its products visit the following website:

• In the United States: www.ford.com

• In Canada: www.ford.ca

• In Mexico: www.ford.com.mx

• In Australia: www.ford.com.au

Additional owner information is given in separate publications. This Owner’s Guide describes every option and model variant available

and therefore some of the items covered may not apply to your particular vehicle. Furthermore, due to printing cycles it may describe options before they are generally available.

Remember to pass on the Owner’s Guide when reselling the vehicle. It is an integral part of the vehicle.

Introduction

Fuel pump shut-off switch: In the event of an accident the

safety switch will automatically cut off the fuel supply to the engine. The switch can also be activated through sudden vibration (e.g. collision when parking). To reset the switch, refer to the Fuel pump shut-off switch in the Roadside Emergencies chapter.

SAFETY AND ENVIRONMENT PROTECTION

Warning symbols in this guide

How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.

Warning symbols on your vehicle

When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind.

Protecting the environment

We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol.

Introduction

BREAKING-IN YOUR VEHICLE

Your vehicle does not need an extensive break-in. Try not to drive continuously at the same speed for the first 1,000 miles (1,600 km) of new vehicle operation. Vary your speed frequently in order to give the moving parts a chance to break in.

Drive your new vehicle at least 500 miles (800 km) before towing a trailer. For more detailed information about towing a trailer, refer to Trailer towing in the Tires, Wheels and Loading chapter.

Do not add friction modifier compounds or special break-in oils during the first few thousand miles (kilometers) of operation, since these additives may prevent piston ring seating. See Engine oil in the Maintenance and Specifications chapter for more information on oil usage.

SPECIAL NOTICES New Vehicle Limited Warranty

For a detailed description of what is covered and what is not covered by your vehicle’s New Vehicle Limited Warranty, refer to the Warranty Guide that is provided to you along with your Owner’s Guide.

Special instructions

For your added safety, your vehicle is fitted with sophisticated electronic controls.

Please read the section Supplemental restraint system (SRS)

in the Seating and Safety Restraints chapter. Failure to follow the specific warnings and instructions could result in personal injury.

Front seat mounted rear-facing child or infant seats should

NEVER be placed in front of an active passenger airbag.

Introduction

Service Data Recording

Service data recorders in your vehicle are capable of collecting and storing diagnostic information about your vehicle. This potentially includes information about the performance or status of various systems and modules in the vehicle, such as engine, throttle, steering or brake systems. In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle.

Event Data Recording

Other modules in your vehicle — event data recorders — are capable of collecting and storing data during a crash or near crash event. The recorded information may assist in the investigation of such an event. The modules may record information about both the vehicle and the occupants, potentially including information such as:

• how various systems in your vehicle were operating;

• whether or not the driver and passenger seatbelts were buckled;

• how far (if at all) the driver was depressing the accelerator and/or the

brake pedal;

• how fast the vehicle was traveling; and

• where the driver was positioning the steering wheel.

To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority. Other parties may seek to access the information independently of Ford Motor Company and Ford of Canada.

Introduction

Notice to owners of pickup trucks and utility type vehicles

Utility vehicles have a significantly higher rollover rate than

other types of vehicles.

Before you drive your vehicle, please read this Owner’s Guide carefully. Your vehicle is not a passenger car. As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of vehicle control, vehicle rollover, personal injury or death.

Be sure to read Driving off road in the Driving chapter.

Using your vehicle with a snowplow

Do not use this vehicle for snowplowing.

Your vehicle is not equipped with a snowplowing package.

Using your vehicle as an ambulance

Do not use this vehicle as an ambulance.

Your vehicle is not equipped with the Ford Ambulance Preparation Package.

Cell phone use

The use of Mobile Communications Equipment has become increasingly important in the conduct of business and personal affairs. However, drivers must not compromise their own or others’ safety when using such equipment. Mobile Communications can enhance personal safety and security when appropriately used, particularly in emergency situations. Safety must be paramount when using mobile communications equipment to avoid negating these benefits.

Mobile Communication Equipment includes, but is not limited to cellular phones, pagers, portable email devices, in-vehicle communications systems, telematics devices and portable two-way radios.

A driver’s first responsibility is the safe operation of the vehicle.

The most important thing you can do to prevent a crash is to avoid distractions and pay attention to the road. Wait until it is safe to operate Mobile Communications Equipment.

Introduction

Middle East/North Africa vehicle specific information

For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner’s Guide; therefore, a supplement has been supplied that complements this book. By referring to the pages in the provided supplement, you can properly identify those features, recommendations and specifications that are unique to your vehicle. Refer to this

Owner’s Guide for all other required information and warnings.

Introduction

These are some of the symbols you may see on your vehicle.

Vehicle Symbol Glossary

Safety Alert

Fasten Safety Belt Airbag - Front

Airbag - Side Child Seat

Child Seat Installation Warning

Child Seat Tether Anchor

Anti-Lock Brake System

Powertrain Malfunction Speed Control

Master Lighting Switch Hazard Warning Flasher

Fog Lamps-Front Fuse Compartment

See Owner’s Guide

Child Seat Lower Anchor

Brake System

Brake Fluid Non-Petroleum Based

Fuel Pump Reset Windshield Wash/Wipe

Windshield Defrost/Demist

Rear Window Defrost/Demist

Vehicle Symbol Glossary

Introduction

Power Windows Front/Rear

Child Safety Door Lock/Unlock

Power Window Lockout

Interior Luggage Compartment Release Symbol

Panic Alarm Engine Oil

Engine Coolant

Engine Coolant Temperature

Do Not Open When Hot Battery

Avoid Smoking, Flames, or Sparks

Battery Acid

Explosive Gas Fan Warning

Power Steering Fluid

Maintain Correct Fluid Level

Emission System Engine Air Filter

MAX

MIN

Passenger Compartment Air Filter

Check Fuel Cap

Jack

Low Tire Pressure Warning

Instrument Cluster

WARNING LIGHTS AND CHIMES

Standard instrument cluster

Optional instrument cluster

Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works. If any light remains on after starting the vehicle, refer to the respective system warning light for additional information.

Note: Some Warning Lights will display in the Message Center as words and function the same as the warning light.

Instrument Cluster

Note: Depending on which options your vehicle has, some indicators may not be present in your vehicle.

Service engine soon: The Service engine soon indicator light

illuminates when the ignition is first turned to the ON position to check the bulb. Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to On board diagnostics (OBD-II) in the Maintenance and Specifications chapter. If the light is blinking, engine misfire is occurring which could damage your catalytic converter. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced immediately by your authorized dealer.

Under engine misfire conditions, excessive exhaust temperatures

could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire.

Powertrain malfunction indicator: Illuminates when a powertrain or a AWD fault has been detected. Contact your authorized dealer as soon as possible.

• Standard instrument cluster

• Optional instrument cluster

Brake system warning light: To confirm the brake system warning light is functional, it will momentarily illuminate when the ignition is turned to the ON position when the engine is not running, or in a position between ON and START, or by applying the parking brake when the ignition is turned to the ON position. If the brake system warning light does not illuminate at this time, seek service immediately from your authorized dealer. Illumination after releasing the parking brake indicates low brake fluid level and the brake system should be inspected immediately by your authorized dealer.

BRAKE

Instrument Cluster

Driving a vehicle with the brake system warning light on is

dangerous. A significant decrease in braking performance may occur. It will take you longer to stop the vehicle. Have the vehicle checked by your authorized dealer.

Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system serviced immediately by your authorized dealer. Normal braking is still functional unless the brake warning light also is illuminated.

Airbag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains on, have the system serviced immediately by your authorized dealer. A chime will also sound when a malfunction in the supplemental restraint system has been detected.

Safety belt: Reminds you to fasten your safety belt. A chime will also sound to remind you to fasten your safety belt.

Charging system: Illuminates when the battery is not charging properly.

• Standard instrument cluster

ABS

• Optional instrument cluster

Engine oil pressure: Illuminates when the oil pressure falls below the normal range. Check the oil level and add oil if needed. Refer to Engine oil in the Maintenance and Specifications chapter.

Instrument Cluster

Engine coolant temperature: Illuminates when the engine coolant temperature is high. Stop the vehicle as soon as possible, switch off the engine and let cool. Refer to Engine coolant in the Maintenance and Specifications chapter.

• Standard instrument cluster

• Optional instrument cluster

Never remove the coolant reservoir cap while the engine is

running or hot.

Low tire pressure warning:

Illuminates when your tire pressure is low. If the light remains on at start up or while driving, the tire pressure should be checked. Refer to Inspecting and Inflating Your Tires in the Tires, Wheels and Loading chapter. When the ignition is first turned to ON, the light will illuminate for 3 seconds to ensure the bulb is working. If the light does not turn ON, have the system inspected by your authorized dealer. For more information on this system, refer to Understanding Your Tire Pressure Monitoring System in the Tires, Wheels and Loading chapter.

Check fuel cap: Illuminates when the fuel cap may not be properly installed. Continued driving with this light on may cause the Service engine soon warning light to come on. Refer to Fuel filler cap in the Maintenance and Specifications chapter.

• Standard instrument cluster

Instrument Cluster

• Optional instrument cluster

Speed control: Illuminates when the speed control is activated. Turns off when the speed control system is deactivated.

O/D off: Illuminates when the overdrive function of the transmission has been turned off, refer to the Driving chapter. If the light flashes steadily or does not illuminate, have the transmission serviced soon, or damage may occur.

AdvanceTract: Flashes when the AdvanceTract with RSC system is active. Illuminates solid when the system has been disabled (by the driver or as a result of a system failure), refer to the Driving chapter for more information.

All wheel drive (AWD):

Illuminates when AWD is engaged. If the light fails to illuminate when the ignition is turned ON, or remains on, have the system serviced immediately by your authorized dealer.

Door ajar: Illuminates when the ignition is in the ON position and any door, liftgate or the liftgate glass is open.

O/D

OFF

4x4

Instrument Cluster

Low fuel: Illuminates when the fuel level in the fuel tank is at or near empty (refer to Fuel gauge in this chapter).

Low washer fluid: Illuminates when the windshield washer fluid is low.

Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators stay on or flash faster, check for a burned out bulb.

High beams: Illuminates when the high beam headlamps are turned on.

Key-in-ignition warning chime: Sounds when the key is left in the ignition in the OFF/LOCK or ACCESSORY position and the driver’s door is opened.

Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened.

Turn signal warning chime: Sounds when the turn signal lever has been activated to signal a turn and not turned off after the vehicle is driven more than 1–1/2 miles ((2.4 km).

Parking brake ON warning chime: Sounds when the parking brake is set, the engine is running and the vehicle is driven more than 3 mph (5 km).

Instrument Cluster

GAUGES

Speedometer: Indicates the current vehicle speed.

Engine coolant temperature gauge: Indicates engine coolant

temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.

Never remove the coolant reservoir cap while the engine is

running or hot.

Instrument Cluster

Odometer: Registers the total miles (kilometers) of the vehicle.

• Standard instrument cluster

• Optional instrument cluster

Refer to Message Center in the Driver Controls chapter on how to switch the display from Metric to English.

Trip odometer: Registers the miles (kilometers) of individual journeys.

• Standard instrument cluster Press the TRIP/RESET control once

to switch from the odometer to the TRIP A feature. Press the control again to select the TRIP B feature. To reset the trip, press and hold the control again until the trip reading is 0.0 miles.

• Optional instrument cluster Press and release the message

center INFO button until TRIP A mode appears in the display. Press the control again to select the TRIP B feature. Press the RESET button to reset.

Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine.

Instrument Cluster

Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade.

Refer to Filling the tank in the

Maintenance and Specifications

chapter for more information. The FUEL icon and arrow indicates which side of the vehicle the fuel

door is located.

Entertainment Systems

AUDIO SYSTEMS AM/FM Single CD/MP3 sound system (if equipped)

Accessory delay: Your vehicle is equipped with accessory delay. With this feature, the window switches, radio and moon roof (if equipped) may be used for up to ten minutes after the ignition is turned off or until either front door is opened.

/ Tuner: Press to

manually go up or down the radio frequency. Also use in menu mode to select various settings.

2. MUTE/Phone: Press to mute the playing media. Press again to return to the playing media.

3. MENU: Press to toggle through the following modes:

Setting the clock: Press MENU until SET HOURS or SET MINUTES is displayed. Use to disengage clock mode.

/ to manually increase/decrease Press MENU again

Entertainment Systems

Autoset: Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2. Press

MENU to access. Use When the six strongest stations are filled, the station stored in preset 1

will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets. Use on/off.

Bass: Press

/ to adjust the bass setting.

/ to set.

/ to turn

Treble: Press

Balance: Press

speakers. Fade: Press

speakers. Speed sensitive volume: Radio volume automatically changes slightly

with vehicle speed to compensate for road and wind noise. Press MENU to access and use / to adjust. The recommended level is 1–3. Level 0 (SPEED OFF) turns the feature off and level 7 is the maximum

setting. Track/Folder Mode: Available only on MP3 discs in CD mode.

Press In Track mode, press

current disc. In Folder mode, press SEEK to scroll through tracks within the selected folder.

Compression: Brings soft and loud CD passages together for a more consistent listening level when in CD mode. Press MENU until

compression status is displayed. Press / to turn the feature on/off.

4. AUX: Press to toggle between FES/DVD, AUX and Satellite Radio modes (if equipped). If no auxiliary sources are available, NO AUX AUDIO will be displayed.

/ to toggle between Track and Folder mode.

/ to adjust the treble setting.

/ to adjust the audio between the left and right

/ to adjust the audio between the front and rear

SEEK to scroll through all tracks on the

Entertainment Systems

5. SEEK : Press to access the next strong station or CD track.

6. Play/Pause: This control is operational in CD and DVD mode (if equipped). When a CD or DVD is playing in the FES system, press this control to play or pause the current CD or DVD. The CD/DVD status will display in the radio display.

7. SHUFFLE: Press to play tracks in random order.

8. FOLDER : In folder mode, press to access next folder on MP3 discs, if available.

FOLDER: In folder mode,

9. press to access the previous folder on MP3 discs, if available.

10. FF (Fast forward): Press to manually advance in a CD track.

11. REW (Rewind): Press to manually reverse in a CD track.

12. Memory presets: To set a station, select the desired frequency band, AM, FM1 or FM2. Tune to the desired station. Press and hold a preset button until sound returns and PRESET # SAVED appears in the display. You can save up to 18 stations, six in AM, six in FM1 and FM2.

13. TEXT/SCAN: Press and hold SCAN for a brief sampling of radio stations or CD tracks. Press again to stop. In CD/MP3 mode, press TEXT to display track title, artist name, and disc title and file name (if available).

Entertainment Systems

14. SEEK: Press to access the previous strong station or CD track.

15. AM/FM: Press to select AM/FM1/FM2 frequency band.

16. ON/OFF/Volume: Press to turn ON/OFF. Turn to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.

17. CD: Press to enter CD mode. If a CD is already loaded into the system, CD play will begin where it ended last. If no CD is loaded, NO DISC will appear in the display.

18. CD eject: Press to eject a CD.

19. CD slot: Insert a CD label side up.

Entertainment Systems

AM/FM Single CD/MP3/Cassette sound system (if equipped)

/ Tuner: Press to

1. manually go up or down the radio

frequency. Also use in menu mode to select various settings.

2. SEEK next strong station, tape selection or CD track.

3. MUTE/Phone: Press to mute the playing media. Press again to return to the playing media.

4. MENU: Press to toggle through the following modes:

: Press to access the

Entertainment Systems

Setting the clock: Press MENU until SET HOURS or SET MINUTES is displayed. Press

Autoset: Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2 . Press

MENU to access. Use When the six strongest stations are filled, the station stored in preset 1

will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets. Use on/off.

/ to adjust the hours/minutes.

/ to set.

/ to turn

Bass: Press

Treble: Press

Balance: Press

speakers. Fade: Press

speakers. Speed sensitive volume: Radio volume automatically changes slightly

with vehicle speed to compensate for road and wind noise. Use to adjust. Recommended level is 1–3. Level 0 (SPEED OFF) turns the

feature off and level 7 is the maximum setting. Compression: Brings soft and loud CD passages together for a more

consistent listening level when in CD mode. Press MENU until compression status is displayed. Press

Dolbyt noise reduction: Dolbyt noise reduction works in tape mode to reduce hiss and static during playback. The Dolbyt noise reduction system is manufactured under license from Dolby Laboratories Licensing Corporation. Dolbyt and the double-D symbol are registered trademarks of Dolbyt Laboratories Licensing Corporation.

Track/Folder Mode: Available only on MP3 discs in CD mode. Press

In Track mode, press current disc. In Folder mode, press SEEK to scroll through tracks within the selected folder.

/ to adjust the bass setting.

/ to adjust the treble setting.

/ to adjust the audio between the left and right

/ to adjust the audio between the front and rear

/ to turn the feature on/off.

/ to toggle between Track and Folder mode.

SEEK to scroll through all tracks on the

Entertainment Systems

5. AUX: Press to toggle between FES/DVD and AUX modes. If no auxiliary sources are available, NO AUX AUDIO will be displayed. To return to radio mode, press AM/FM.

6. Tape eject: Press to eject a tape.

7. Play/Pause: This control is operational in CD, tape and DVD mode (if equipped). When a CD or DVD is playing in the FES system, press this control to play or pause the current CD/DVD. The CD/DVD status will display in the radio display.

8. SHUFFLE: Press to play CD tracks in random order.

9. FOLDER mode, press to access next folder on MP3 discs, if available.

10. mode, press to access the previous folder on MP3 discs, if available.

11. FF (Fast forward): Press to manually advance in a CD track or cassette.

12. REW (Rewind): Press to manually reverse in a CD track or cassette.

13. Memory presets: To set a station, select the desired frequency band, AM, FM1 or FM2. Tune to the desired station. Press and hold a preset button until sound returns and PRESET # SAVED appears in the display. You can save up to 18 stations, six in AM, six in FM1 and FM2.

14. Tape: Insert a tape facing to the right.

FOLDER: When in folder

: When in folder

Entertainment Systems

15. Tape direction: Press to enter tape mode. Press while in play mode to change which side of the tape is playing.

16. AM/FM: Press to select AM/FM1/FM2 frequency band.

17. ON/OFF/Volume: Press to turn ON/OFF. Turn to increase/decrease volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.

18. CD: Press to enter CD mode. If a CD is already loaded into the system, CD play will begin where it ended last. If no CD is loaded, NO DISC will appear in the display.

19. CD eject: Press to eject a CD.

20. CD slot: Insert a CD label side up.

21. previous strong station, tape selection or CD track.

22. TEXT/SCAN: Press and hold SCAN for a brief sampling of radio stations, tape selections or CD tracks. Press again to stop. In CD/MP3 mode, press TEXT to display track title, artist name, and disc title and file name (if available).

SEEK:Press to access the

Entertainment Systems

Audiophile AM/FM In-dash Six CD/MP3 sound system (if equipped)

Accessory delay: Your vehicle is equipped with accessory delay. With this feature, the window switches, radio and moon roof (if equipped) may be used for up to ten minutes after the ignition switch is turned off or until either front door is opened.

/ Tune/Disc selector:

1. Press and release to manually

advance up/down the radio frequency or to select a desired disc. Press and hold for a fast advance through radio frequencies or all loaded discs. Also use in menu mode to select various settings.

2. MUTE/Phone: Press to mute the playing media. Press again to return to the playing media.

3. MENU: Press to toggle through the following modes:

Setting the clock: Press until SET HOUR or SET MINS is displayed. Press

/ to adjust the hours/minutes.

Entertainment Systems

RBDS (Radio Broadcast Digital Signal) ON/OFF: Press / to turn RBDS ON or OFF.

Program Type:If RBDS is ON, press type, then use

broadcasting the desired program type. SHOW RBDS Info: If RBDS is ON, this allows you to display the name

of the FM radio station or program type. Press type, station name or none.

RBDS: Allows you to search RBDS (Radio Broadcast Digital Signal) equipped stations for the following music formats: Classical, Country, Jazz, Oldies, R&B, Religious, Rock, Soft, Top 40 and Information (Inform). RBDS is only available in FM mode.

Autoset: Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2 .

Use When the six strongest stations are filled, the station stored in preset 1

will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets. Use on/off.

Bass: Press

/ to turn on/off.

SEEK or SCAN to search for FM radio stations

/ to adjust the bass setting.

/ to find the desired program

/ to show program

/ to turn

Treble: Press

Balance: Press

speakers. Fade: Press

speakers. Speed sensitive volume: Radio volume automatically changes slightly

with vehicle speed to compensate for road and wind noise. Use to adjust. Recommended level is 1–3. Level 0 (SPEED OFF) turns the

feature off and level 7 is the maximum setting. Occupancy mode: Use

SEATS, DRIVERS SEAT or REAR SEATS.

/ to adjust the treble setting.

/ to adjust the audio between the left and right

/ to adjust the audio between the front and rear

/ to select and optimize sound for ALL

+ 298 hidden pages
